Planet Technology BT-410U, BT-420U User Manual
Class 1 / Class 2
Bluetooth V2.0 USB Adapter
BT-410U/420U
User’s Guide
Copyright
Copyright (C) 2005 PLANET Technology Corp. All rights reserved.
The products and programs described in this User’s Manual are licensed products of PLANET
Technology, This User’s Manual contains proprietary information protected by copyright, and
this User’s Manual and all accompanying hardware, software, and documentation are copyrighted.
No part of this User’s Manual may be copied, photocopied, reproduced, translated, or reduced
to any electronic medium or machine-readable form by any means by electronic or mechanical.
Including photocopying, recording, or information storage and retrieval systems, for any purpose
other than the purchaser's personal use, and without the prior express written permission of
PLANET Technology.
Disclaimer
PLANET Technology does not warrant that the hardware will work properly in all environments
and applications, and makes no warranty and representation, either implied or expressed, with
respect to the quality, performance, merchantability, or fitness for a particular purpose.
PLANET has made every effort to ensure that this User’s Manual is accurate; PLANET disclaims liability for any inaccuracies or omissions that may have occurred.
Information in this User’s Manual is subject to change without notice and does not represent a
commitment on the part of PLANET. PLANET assumes no responsibility for any inaccuracies
that may be contained in this User’s Manual. PLANET makes no commitment to update or keep
current the information in this User’s Manual, and reserves the right to make improvements to
this User’s Manual and/or to the products described in this User’s Manual, at any time without
notice.
If you find information in this manual that is incorrect, misleading, or incomplete, we would
appreciate your comments and suggestions.
CE mark Warning
The is a class B device, In a domestic environment, this product may cause radio interference,
in which case the user may be required to take adequate measures.
Trademarks
The PLANET logo is a trademark of PLANET Technology. This documentation may refer to
numerous hardware and software products by their trade names. In most, if not all cases, these
designations are claimed as trademarks or registered trademarks by their respective companies.
WEEE regulation
To avoid the potential effects on the environment and human health as a result of
the presence of hazardous substances in electrical and electronic equipment, end
users of electrical and electronic equipment should understand the meaning of the
crossed-out wheeled bin symbol. Do not dispose of WEEE as unsorted municipal
waste and have to collect such WEEE separately.
ii
Revision
User’s Manual for PLANET Class1/Class2 Bluetooth V2.0 USB Adapter:
Model: BT-410U, BT-420U
Rev: 1.0 (October, 2005)
Part No. EM-BT410U
iii
TABLE OF CONTENTS
CHAPTER 1 INTRODUCTION.................................................................................1
1.1 Features........................................................................................................................1
1.2 Package Contents ........................................................................................................2
CHAPTER 2 INSTALLATION ..................................................................................3
2.1 Software Installation...................................................................................................3
2.2 Software Un-installation.............................................................................................6
2.3 Hardware Installation.................................................................................................6
2.4 Initial Bluetooth Configuration..................................................................................8
CHAPTER 3 BLUETOOTH SOFTWARE.............................................................12
3.1 About Bluetooth Software........................................................................................ 12
3.2 Bluetooth Tray........................................................................................................... 12
3.3 Access My Bluetooth Places......................................................................................13
3.4 Icon Used For Bluetooth Devices And Services......................................................13
CHAPTER 4 BASIC OPERATION ........................................................................16
4.1 Start or Stop Bluetooth.............................................................................................16
4.2 Create A Connection From The Bluetooth Icon In The System Tray..................16
4.3 Create A Connection Using The Bluetooth Setup Wizard ....................................16
4.4 Create A Connection From Entire Bluetooth Neighborhood................................16
CHAPTER 5 FIND BLUETOOTH DEVICES........................................................18
5.1 Periodic Search For Devices.....................................................................................18
5.2 Find A Service............................................................................................................18
5.3 Bluetooth Connection Status....................................................................................19
5.4 Send To Bluetooth.....................................................................................................20
CHAPTER 6 CONFIGURE BLUETOOTH............................................................21
6.1 Access The Bluetooth Configuration Panel.............................................................21
6.2 Bluetooth Services VS. Bluetooth Applications......................................................21
6.3 Bluetooth Exchange Folder ......................................................................................21
6.4 General Configuration Settings ...............................................................................21
6.5 Bluetooth Applications..............................................................................................22
6.6 Bluetooth Services..................................................................................................... 32
6.7 Hardware Settings ..................................................................................................... 40
6.8 Accessibility Settings.................................................................................................41
6.9 Discovery Settings .....................................................................................................42
CHAPTER 7 SECURITY .........................................................................................44
7.1 Authentication ...........................................................................................................44
7.2 Authorization.............................................................................................................44
7.3 Bluetooth Device Identity .........................................................................................44
7.4 Encryption..................................................................................................................44
7.5 Link Key..................................................................................................................... 44
7.6 Pairing Devices ..........................................................................................................45
7.7 Passkey....................................................................................................................... 45
7.8 Secure Connection.....................................................................................................45
7.8 Security Request Dialog Box....................................................................................45
i
APPENDIX A TROUBLE SHOOTING.................................................................46
APPENDIX B SPECIFICATION ...........................................................................49
ii
Chapter 1
Introduction
The BT-410U/420U is designed to connect USB port of a desktop or laptop PC, and allows the
computer to build a short-range wireless connection to other Bluetooth devices like cellular
phones, PDAs, and computers. Since the transmission medium of BT-410U/420U is air,
PLANET also enhances both connection protection and data security mechanism to the product
which helps people share and access trigger information. Compliant with Bluetooth specification
Version 2.0 + EDR, BT-410U/420U can provide transfer rate up to 3Mbps, which is higher than
Bluetooth v1.2 device.
The BT-410U/420U provides services of virtual serial port, dial-up networking, fax, file transfer,
information exchange, information synchronization, and network access. With powerful bundled
software, it’s not difficult to implement configuration and management even there are so many
functions. Most popular operating system support, including Windows 98SE, ME, 2000, XP and
Server 2003, makes the application of BT-410U/420U more flexible.
Link your notebook with your handheld, mobile phone, printer, audio gateway and
other Bluetooth devices within your personal area network (PAN) via a secure shortrange wireless radio link. Get rid of all those hassle cables and automatically share
documents, browse the Internet and synchronize calendars, address books and more.
1
1.1 Features
¾ Compatible with Bluetooth Core Specification Version 2.0 + EDR (Enhanced Data
Rate)
¾ Bluetooth Manager Utility eases the difficulties of configuration and management
¾ Date rate up to 3Mbps
¾ Lower power consumption through reduced duty cycle
¾ Simplification of multi-link scenarios due to more available bandwidth
¾ Backwards compatible to Bluetooth V1.1/V1.2 specifications
¾ Further improved BER (Bit Error Rate) performance
¾ Connection protection and data security enhanced mechanism
¾ Up to 8 devices Point-to-MultiPoint topology expands your PAN coverage
¾ Various services provided: Virtual Serial Port, Dial-up Networking, Fax, File Trans-
fer, Information Exchange, Information Synchronization, and Network Access
¾ Multilingual support in Bluetooth utility
¾ Most popular OS support: Windows 98SE/Me/2000/XP and Server 2003
¾ BT-410U has suppor Bluetooth Class 1, it can provide bigger cover area for user to
connect their Bluetooth device longer
1
Bluetooth USB Adapter User Guide
1.2 Package Contents
The following items should be included:
• 1 * Bluetooth V2.0 USB Adapter
• 1 * CD-ROM (includes Driver, Utility, Manual)
• 1 * Quick Installation Guide
If any of the above items are damaged or missing, please contact your dealer immediately.
2
Chapter 2
Installation
2
2.1 Software Installation
Note: The Bluetooth Software should be installed well prior to the hardware installa-
tion. If the hardware install to PC before software installed, Windows will install this
Bluetooth device with its built-in driver. That will make the Bluetooth device work
incorrect.
1. Insert the CD-ROM into the CD-ROM drive to initiate the autorun program. Once
completed, a menu screen will appear.
2. To install the Bluetooth software, click on the "Bluetooth Software" hyperlink to
activate the installation procedure for the application program.
If the autorun program is not executed, you can start the installation as follows.
• Click on Start Menu/ Run.
• Enter “D:\Utility\setup.exe” in the appeared box, where “D” is the letter of your
CD-ROM drive.
• Click on “OK” button.
3. On the Welcome screen, click the Next button.
4. When the License Agreement screen is displayed, read the License Agreement,
then select “I accept the terms in the license agreement” and click the Next but-
ton.
3
Bluetooth USB Adapter User Guide
5. On the Destination Folder screen, click the Change button to browse to a new
destination folder for the Bluetooth software. Otherwise, click the Next button to
accept the default folder.
6. The InstallShield Wizard is ready to install the Bluetooth software. If you need to
review or change any settings, click the Back button. Click the Cancel button to
exit the Wizard. Otherwise, click the Install button
4
7. In Windows 2000/XP/Server 2003, you may see the screen below, click OK at the
following message. In Win98/Me, installation may ask you to insert Windows Resource CD. Please insert your Win98/Me CD and click Yes.
8. This screen will prompt you the Bluetooth device is not found. Please press Can-
cel to continue.
9. When finished, click Finish to end the Installation Wizard.
5
Bluetooth USB Adapter User Guide
10. Please click Yes to restart your computer.
2.2 Software Un-installation
1. In Windows, go to Start →Settings→ Control Panel→ Add or Remove Programs.
2. Select “PLANET Bluetooth Software” and click the “Remove” button.
2.3 Hardware Installation
Note: The hardware installation should be only performed after the software is
well installed.
Precaution
Before the installation, make sure the USB port exists in your computer and is enabled.
To check this, go to My ComputerÆControl Panel ÆSystem. Open the Device
Manager tab. If the Universal Serial Bus controller device is found, it means your
USB port is installed and enabled. If not, either no USB port is installed or the USB
bios is not properly enabled. In this case, consult your computer dealer for USB support.
6
Procedures
1. Please make sure you have see the bluetooth icon in the system tray like below.
2. Plug your BT-410U/420U into the PC USB port.
3. Windows will detect the device and ask the driver. Please select Install the
software automatically (Recommended) and click Next.
4. Please click Finish to completed driver installation.
7
Bluetooth USB Adapter User Guide
5. When the driver installed. You will see the bluetooth icon turn into white like
below.
2.4 Initial Bluetooth Configuration
Double click this icon to make the initial Bluetooth configuration.
1. The following message is shown to prompt you to select the location where you
want to show the Bluetooth icon. Select the location and click Next.
2. On the Device Name and Type screen, enter the required information:
8
Computer Name—other Bluetooth-enabled devices, when inquiring about devices within radio range, will see this user-configured device name.
The name can be changed after the installation process through the Bluetooth
Software Configuration Panel.
Computer Type—click the down arrow and choose Desktop or Laptop from
the drop-down list. The device type can be changed after the installation process
through the Bluetooth Software Configuration Panel.
Click the Next button.
3. Click Next to configure the Bluetooth services that this computer will offer to the
Bluetooth devices.
9
Bluetooth USB Adapter User Guide
4. Select the services you want this computer to offer and click the Configure if you
need further configuration. Click Next to continue.
5. The following message is shown. Please wait for a while for the software installa-
tion process to complete.
6. After the service install to your PC, you may click Skip to finish the service instal-
lation or click Next and refer to step 7 to start search the Bluetooth device which
you want to connect.
10
7. Please click Finish to complete the Bluetooth Configuration Wizard.
8. After click Next in step 5, you will see this screen that will show you all the Blue-
tooth devices which you can find. If the device you want to connect is not display
in this screen, please select what kind of device you want to find in the pull-down
list and click “Search Again”. When the Bluetooth device is found, please click
Next to connect to this device.
11
Chapter 3
Bluetooth Software
3
3.1 About Bluetooth Software
The Bluetooth for Windows software consists of the following components:
‧ Microsoft® Windows® Explorer Extensions—Provide access to Bluetooth
devices in the immediate vicinity using Windows Explorer.
‧ My Bluetooth Places—Graphical user interface (GUI) that provides access to
Bluetooth devices in the immediate vicinity. Also provides access to configure the
local devices and access to perform other Bluetooth tasks.
‧ BTTray Security Manager—Controls and manages Bluetooth security levels. Also
enables you to grant or deny access and to filter what can be accessed on a Bluetooth
device.
‧ Bluetooth for Windows Configuration Panel—Configures your Bluetooth for
Windows (BTW) software using the Windows Control Panel.
‧ Stack Server—Provides an interface for the operating system to control Bluetooth
devices and to ensure that Bluetooth connections operate together correctly. The
stack server has a built-in Security Manager that protects the Bluetooth device from
unauthorized access.
‧ Bluetooth Setup wizard—Facilitates the configuration and modification of your
Bluetooth environment. The wizard can be used to configure or change local services
or to establish connections to remote devices based on service type or device type.
‧ Quick Connect—Facilitates fast connections based on service type. You are able
to quickly find devices that support a particular service and establish a connection to
that service. During this process, a shortcut to the service is created in My Bluetooth
Places, which can be used for subsequent connections.
3.2 Bluetooth Tray
The Bluetooth tray resides in the Windows system tray, which is normally located in
the lower-right corner of the screen. The Bluetooth tray provides fast access to most
Bluetooth operations.
From the Bluetooth tray you can:
‧ Access My Bluetooth Places—double-click the Bluetooth icon, or right-click the
Bluetooth icon and then select Explore My Bluetooth Places.
‧ Access the Bluetooth Setup Wizard. This wizard will help you:
Configure how this computer accesses a service on another Bluetooth device
Locate remote Bluetooth devices
Configure the way that this computer provides services to remote Bluetooth
devices
Set the name and type of this Bluetooth device, e.g., “John's PC” and “Desk-
top.”
‧ Access the Bluetooth Configuration Panel—right-click the Bluetooth icon, and
then select Advanced Configuration.
‧ Access the Quick Connect option—right-click the Bluetooth icon, select Quick
Connect, and then select the type of service to which you wish to connect.
‧ Start/Stop Bluetooth on this computer
12
Loading...
