1. Introduction
The PLANET 802.11g Wireless ADSL 2/2+ Router, ADW-4401v2, provides office
and residential users the ideal solution for sharing a high-speed ADSL 2/2+ broadband
Internet connection on a 54Mbps wireless network and a 10/100Mbps Fast Ethernet
backbone. It can support downstream transmission rates of up to 24Mbps and upstream
transmission rates of up to 3.5Mbps. The product supports PPPoA (RFC 2364 - PPP
over ATM Adaptation Layer 5), RFC 2684 encapsulation over ATM (bridged or
routed), PPP over Ethernet (RFC 2516), and IPoA (RFC1483) to establish a connection
with ISP.
Via the user-friendly management interface, ADW-4401v2 can be managed by
workstations running standard web browsers. Furthermore, ADW-4401v2 provides
DHCP server, NAT, virtual server, DMZ, access control, IP filter, PPTP/IPSec/L2TP
pass-through, DNS Proxy, DDNS, and UPnP capability.
The ADW-4401v2 also serves as an Internet firewall, protecting your network from
being accessed by outside users. It provides the natural firewall function (Network
Address Translation, NAT). All incoming and outgoing IPs are monitored and filtered.
Moreover, it can be configured to block internal users from accessing to the Internet.
1.1 Feature
Internet Access Features
Shared Internet Access. All users on the LAN or WLAN can access the
Internet through the ADW-4401v2 using only a single external IP Address.
The local (invalid) IP Addresses are hidden from external sources. This
process is called NAT (Network Address Translation).
Built-in ADSL 2/2+ Modem. The ADW-4401v2 provides ADSL 2/2+
modem, and supports all common ADSL connections.
IPoA, PPPoE, PPPoA, Direct Connection Support. Various WAN
connections are supported by ADW-4401v2.
Auto-detection of Internet Connection Method. In most situations, the
ADW-4401v2 can test your ADSL and Internet connection to determine the
connection method used by your ISP.
Fixed or Dynamic IP Address. On the Internet (WAN port) connection, the
ADW-4401v2 supports both Dynamic IP Address (IP Address is allocated on
connection) and Fixed IP Address.
Advanced Internet Functions
Virtual Servers. This feature allows Internet users to access Internet servers
on your LAN. The required setup is quick and easy.
Firewall. Supports simple firewall with NAT technology and provides option
for blocking access from Internet, like Web, FTP, Telnet, SNMP, and ICMP.
Universal Plug and Play (UPnP) UPnP allows automatic discovery and
configuration of the Broadband Router. UPnP is supported by Windows ME,
XP, or later.
Dynamic DNS Support. DDNS, when used with the Virtual Servers feature,
allows users to connect to Servers on your LAN using a Domain Name, even
if you have a dynamic IP address which changes every time you connect.
7
VPN Pass through Support. PCs with VPN (Virtual Private Networking)
software using PPTP, L2TP and IPSec are transparently supported - no
configuration is required.
RIP1/2 Routing. It supports RIP1/2 routing protocol for routing capability.
Simple Network Management Protocol (SNMP). It is an easy way to remotely
manage the router via SNMP.
Wireless Features
Standards Compliant. The ADW-4401v2 complies with the IEEE802.11g
(DSSS) specifications for Wireless LANs. Maximum of 54Mbps are
supported.
Supports both 802.11b and 802.11g Wireless Stations. The 802.11g
standard provides for backward compatibility with the 802.11b standard, so
both 802.11b and 802.11g Wireless stations can be used simultaneously.
WEP support. Support for WEP (Wired Equivalent Privacy) is included.
Key sizes of 64 Bit and 128 Bit are supported.
WPA-PSK support. WPA-PSK_TKIP and WAP-PSK_AES encryption are
supported.
Wireless MAC Access Control. The Wireless Access Control feature can
check the MAC address (hardware address) of Wireless stations to ensure that
only trusted Wireless Stations can access your LAN.
LAN Features
4-Port Switch. The ADW-4401v2 incorporates a 4-port 10/100BaseT
switching hub, making it easy to create or extend your LAN.
DHCP Server Support. Dynamic Host Configuration Protocol provides a
dynamic IP address to PCs and other devices upon request. The
ADW-4401v2 can act as a DHCP Server for devices on your local LAN and
WLAN.
1.2 Package Contents
ADW-4401v2 Unit
Power Adapter
Quick Installation Guide
User’s Manual CD
RJ-11 (ADSL) cable
RJ-45 cable
1.3 Physical Details
Front Panel
8
Front Panel LED definition
connect networked devices, such as PCs, print servers remote hard
he modem and
port (1, 2, 3, or 4). If the LED is flashing, the Router is actively sending or
LED
PWR
WLAN
ADSL
LAN
1-4
State
ON
OFF
Flashing
ON
Flashing
ON
Flashing
OFF
Description
When the router is powered on and in ready state
When the router is powered off.
When wireless AP is ready
Successful connection between ADSL modem and telecom's
network
Modem is trying to establish a connection to telecom’s network
Link
TX or RX activity
No Link
These four LAN (Local Area Network) ports are where you will
drives, and anything else you want to put on your network
Rear Panel
Rear panel Port and Button Definition
Connector
POWER
Power connector with 12V AC 1.0 A
POWER
The power button is for turn on or turns off the router.
Button
ADSL
Connector
The RJ-11 connector allows data communication between t
the ADSL network through a twisted-pair phone wire
Router is successfully connected to a device through the corresponding
LAN (1-4)
Description
receiving data over that port.
Reset
Button
The reset button, the router restore the default settings when press this
button until reboot
9
2. Installation
This chapter offers information about installing your router. If you are not familiar with
the hardware or software parameters presented here, please consult your service
provider for the values needed.
2.1 System Requirement
1. Personal computer (PC)
2. Pentium III 266 MHz processor or higher
3. 128 MB RAM minimum
4. 20 MB of free disk space minimum
5. RJ45 Ethernet Port
2.2 Hardware Installation
This section describes how to connect and configure the ADW-4401.
To PC /Hub
To ADSL Line
Power Adapter
Step 1. Connect the ADSL Line
Connect the router directly to the wall jack using the included ADSL cable.
Step 2. Connect a Workstation to the Router's LAN port
There are two methods to connect the router and workstation. The one use the crossover
Ethernet cable to connect directly between them. The other use straight Ethernet cable
to connect router with hub (or switch), then go to the workstation.
Step 3. Connect the Power Adapter to the Router
Connect the power adapter to the port labeled POWER on the rear panel of router.
Step 4. Connect All Cables to the Network
The procedure for connecting cables differs depending on whether or not your
10
telephone equipment is connected to a POTS splitter.
2.3 Configuring the Network Properties
Configuring PC in Windows XP
1. Go to Start / Control Panel (in Classic View). In the Control Panel,
double-click on Network Connections
2. Double-click Local Area Connection.
3. In the Local Area Connection Status window, click Properties.
11
4. Select Internet Protocol (TCP/IP) and click Properties.
5. Select the Obtain an IP address automatically and the Obtain DNS
server address automatically radio buttons.
6. Click OK to finish the configuration.
Configuring PC in Windows 2000
1. Go to Start / Settings / Control Panel. In the Control Panel, double-click on
Network and Dial-up Connections.
12
2. Double-click Local Area Connection.
3. In the Local Area Connection Status window click Properties.
4. Select Internet Protocol (TCP/IP) and click Properties.
5. Select the Obtain an IP address automatically and the Obtain DNS server
address automatically radio buttons.
6. Click OK to finish the configuration.
13
Configuring PC in Windows 98/Me
1. Go to Start / Settings / Control Panel. In the Control Panel, double-click on
Network and choose the Configuration tab.
2. Select TCP/IP ->
NE2000 Compatible, or the name of your Network Interface Card (NIC) in your
PC.
3. Select the Obtain an IP address automatically radio button.
4. Then select the DNS Configuration tab.
5. Select the Disable DNS radio button and click OK to finish the configuration.
14
Configuring PC in Windows NT4.0
1. Go to Start / Settings / Control Panel. In the Control Panel, double-click on
Network and choose the Protocols tab.
2. Select TCP/IP Protocol and click Properties.
3. Select the Obtain an IP address from a DHCP server radio button and click OK.
15
3 Configuration
3.1 Determine your connection settings
Before you configure the router, you need to know the connection information
supplied by your ADSL service provider.
3.2 Connecting the ADSL Router to your network
Unlike a simple hub or switch, the setup of the ADSL Router consists of more than
simply plugging everything together. Because the Router acts as a DHCP server, you
will have to set some values within the Router, and also configure your networked
PCs to accept the IP Addresses the Router chooses to assign them.
Generally there are several different operating modes for your applications. And you
can know which mode is necessary for your system from ISP. These modes are router,
bridge, PPPoE+NAT, and PPPoA+NAT.
3.3 Configuring with Web Browser
It is advisable to change the administrator password to safeguard the security of your
network.
To configure the router, open your browser, type 'http: //192.168.0.1' into the address
bar and click 'Go' to get to the login page.
Save this address in your Favorites for future reference.
At the User name prompt, type 'admin'. And the Password prompt, type 'admin'. You
can change these later if you wish. Click 'OK'.
16
3.3.1 Quick Setup Guide
You can use "Quick Setup" to setup the router as follows, and the router will connect
to the Internet via ADSL line.
Click "Quick Start" to get into the quick setup procedures.
17
Click "RUN WIZARD" to start up this procedure.
Step 1 - Click "Next" to setup your new administrator's password.
18
Step 2 - Click "Next" to setup your time zone.
Step 3 - Click "Next" to setup your Internet connection type. You can have this
information from your Internet Service Provider.
Enter the connection information provided by your ISP.
19
Loading...
