Planet Z-Wave Quick Installation Manual

1. Introduction

Thanks for choosing PLANET’s Z-Wave™ home automation device. PLANET HZS Series is a
Z-Wave™ enabled device that adopts the two-way RF mesh network technology and thus,
it is fully compatible with any Z-Wave™ enabled network and its security framework. Every
mains powered Z-Wave™ enabled device acts as a signal repeater and multiple devices
result in more possible transmission routes which help eliminate “RF dead spots”.

PLANET HZS Series include:

The HZS-100 monitors movement and sends Z-Wave™ signal when movement is detected
inside the building. With temperature sensor built inside, it will send the signal out when
temperature changes.

The HZS-200 is designed to sense smoke that comes into the detector chamber. When the
detector detects a certain density of smoke, the smoke detector will sound.

The HZS-300 sends Z-Wave™ signal when a door or window is opened and closed, or
humidity, temperature and luminosity change.

The HZS-531A-US/HZS-532E-DE will send On/Off signal to the appliance that is attached
to this module by receiving Z-Wave™ signal from controller or manual switch.

When these devices are secure and included into the Z-Wave™ network, the above
communication will be encrypted.

2. Verify the Contents Inside the Package Box

The package should contain the following items. If any item is missing or damaged, please
contact the seller immediately.

Model Package Contents

HZS-100 PIR Sensor x 1

CR123A Lithium Battery x 1
Accessory Bag (including two screws, an adhesive tape and a bracket)
Quick Installation Guide x 1

HZS-200 Smoke Detector x 1

CR123A Lithium Battery x 1
Bracket Holder x 1
Screw Kit x 1 (including two screws and two plastic anchors)
Quick Installation Guide x 1

HZS-300 4-in-1 Sensor x 1

AAA Battery x 2
Accessory Bag (including two screws, an adhesive tape for magnet, an
adhesive tape for sensor, a magnet and a bracket for magnet)
Quick Installation Guide x 1

HZS-531A-US/
HZS-532E-DE

US-type / EU-type Energy Meter x 1
Quick Installation Guide x 1
