PLANET Technology does not warrant that the hardware will work properly in all environments and applications, and makes no
warranty and representation, either implied or expressed, with respect to the quality, performance, merchantability, or fitness for
a particular purpose. PLANET has made every effort to ensure that this User's Manual is accurate; PLANET disclaims liability
for any inaccuracies or omissions that may have occurred.
Information in this User's Manual is subject to change without notice and does not represent a commitment on the part of
PLANET. PLANET assumes no responsibility for any inaccuracies that may be contained in this User's Manual. PLANET makes
no commitment to update or keep current the information in this User's Manual, and reserves the right to make improvements to
this User's Manual and/or to the products described in this User's Manual, at any time without notice.
If you find information in this manual that is incorrect, misleading, or incomplete, we would appreciate your comments and
suggestions.
FCC Warning
This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to Part 15 of the FCC
Rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated
in a commercial environment. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and
used in accordance with the Instruction manual, may cause harmful interference to radio communications. Operation of this
equipment in a residential area is likely to cause harmful interference in which case the user will be required to correct the
interference at whose own expense.
CE Mark Warning
This is a Class A product. In a domestic environment, this product may cause radio interference, in which case the user may be
required to take adequate measures.
Energy Saving Note of the Device
This power required device does not support Standby mode operation.
For energy saving, please remove the power cable to disconnect the device from the power circuit.
Without removing power cable, the device will still consuming power from the power source. In the view of Saving the Energy
and reduce the unnecessary power consuming, it is strongly suggested to remove the power connection for the device if this
device is not intended to be active.
WEEE Warning
To avoid the potential effects on the environment and human health as a result of the presence of
hazardous substances in electrical and electronic equipment, end users of electrical and electronic
equipment should understand the meaning of the crossed-out wheeled bin symbol. Do not dispose of
WEEE as unsorted municipal waste and have to collect such WEEE separately.
1.3 How to Use This Manual............................................................................................................................22
2.1.1 Switch Front Panel ..............................................................................................................................................29
2.1.2 LED Indications ...................................................................................................................................................30
2.2 Install the Switch........................................................................................................................................32
3.4 Web Management.......................................................................................................................................41
4. WEB CONFIGURATION...................................................................................................... 43
4.1 Main Web Page...........................................................................................................................................46
4.2.1 System Information..............................................................................................................................................49
4.2.2 IP Configuration...................................................................................................................................................50
4.2.10 CPU Load ..........................................................................................................................................................63
4.2.11 System Log........................................................................................................................................................64
4.2.15 Web Firmware Upgrade.....................................................................................................................................68
4.2.20 System Reboot ..................................................................................................................................................73
4.3.2 SNMP System Configuration ...............................................................................................................................76
4.3.4 SNMP System Information ..................................................................................................................................79
4.4 Port Management.......................................................................................................................................87
4.4.1 Port Configuration................................................................................................................................................87
4.4.2 Port Statistics Overview.......................................................................................................................................89
4.4.3 Port Statistics Detail.............................................................................................................................................90
4.4.5 Port Mirror............................................................................................................................................................93
4.5 Link Aggregation........................................................................................................................................97
4.5.3 LACP System Status .........................................................................................................................................102
4.5.4 LACP Port Status...............................................................................................................................................103
4.5.5 LACP Port Statistics...........................................................................................................................................104
4.6.7 VLAN Port Status...............................................................................................................................................118
4.6.9 Port Isolation......................................................................................................................................................121
4.6.10.1 Two separate 802.1Q VLAN .................................................................................................................. 123
4.6.10.2 VLAN Trunking between two 802.1Q aware switch ...............................................................................126
4.6.10.3 Port Isolate ............................................................................................................................................127
4.6.12 MAC-based VLAN Status ................................................................................................................................130
4.6.13 IP Subnet-based VLAN....................................................................................................................................130
4.7 Spanning Tree Protocol...........................................................................................................................135
4.7.1 Theory ...............................................................................................................................................................135
4.7.2 STP System Configuration ................................................................................................................................141
4.7.3 Bridge Status .....................................................................................................................................................143
4.7.4 CIST Port Configuration.....................................................................................................................................144
4.7.8 Port Status.........................................................................................................................................................151
4.7.9 Port Statistics.....................................................................................................................................................153
4.8.4 IGMP Snooping Port Group Filtering .................................................................................................................161
4.8.5 IGMP Snooping Status ......................................................................................................................................162
4.8.6 IGMP Group Information....................................................................................................................................163
4.8.10 MLD Snooping Port Group Filtering.................................................................................................................169
4.8.11 MLD Snooping Status ......................................................................................................................................170
4.8.12 MLD Group Information ...................................................................................................................................171
4.8.13 MLDv2 Information ..........................................................................................................................................172
4.8.16 MVR Groups Information .................................................................................................................................177
4.8.17 MVR SFM Information .....................................................................................................................................178
4.9 Quality of Service.....................................................................................................................................180
4.9.2 Port Policing ......................................................................................................................................................181
4.9.3 Port Classification..............................................................................................................................................182
4.9.4 Port Scheduler...................................................................................................................................................184
4.9.5 Port Shaping......................................................................................................................................................184
4.9.5.1 QoS Egress Port Schedule and Shapers ................................................................................................185
4.9.6 Port Tag Remarking...........................................................................................................................................187
4.9.6.1 QoS Egress Port Tag Remarking.............................................................................................................188
4.9.7 Port DSCP .........................................................................................................................................................189
4.9.11 QoS Control List...............................................................................................................................................194
4.9.11.1 QoS Control Entry Configuration ...........................................................................................................195
4.9.12 QoS Status ......................................................................................................................................................198
4.9.13 Storm Control Configuration ............................................................................................................................199
4.10 Access Control Lists..............................................................................................................................207
4.10.1 Access Control List Status ...............................................................................................................................207
4.10.2 Access Control List Configuration ....................................................................................................................208
4.11.3 Network Access Server Configuration..............................................................................................................227
4.11.6 Authentication Server Configuration.................................................................................................................245
4.12.1 Port Limit Control.............................................................................................................................................265
4.12.6 Port Security Status .........................................................................................................................................272
4.12.7 Port Security Detail..........................................................................................................................................274
4.13.1 MAC Address Table Configuration ................................................................................................................... 284
4.13.2 MAC Address Table Status ..............................................................................................................................286
4.14.6 Port Statistics...................................................................................................................................................305
4.15.3 Remote IP Ping Test ........................................................................................................................................309
4.17.2 sFlow Status ....................................................................................................................................................318
4.18.7 RMON History Configuration ...........................................................................................................................327
4.18.8 RMON History Detail .......................................................................................................................................328
4.18.9 RMON History Status.......................................................................................................................................330
5. COMMAND LINE INTERFACE..........................................................................................337
5.1 Accessing the CLI....................................................................................................................................337
Logon to the Console ..........................................................................................................................................337
Configure IP address...........................................................................................................................................338
6. Command Line Mode....................................................................................................... 341
6.1 System Command....................................................................................................................................341
System Configuration ..........................................................................................................................................341
System Log Configuration ...................................................................................................................................342
System Version ...................................................................................................................................................343
System Log Server Mode ....................................................................................................................................343
System Name......................................................................................................................................................344
System Contact ...................................................................................................................................................344
System Log Server Address................................................................................................................................345
System Location..................................................................................................................................................345
System Log Level................................................................................................................................................346
System Timezone................................................................................................................................................346
8
User’s Manual of XGSW-28040
System Log Lookup.............................................................................................................................................347
System Log Clear................................................................................................................................................347
System Reboot....................................................................................................................................................348
System Restore Default.......................................................................................................................................348
System Load .......................................................................................................................................................349
6.2 IP Command..............................................................................................................................................350
IP Configuration...................................................................................................................................................350
IP DHCP..............................................................................................................................................................351
IP Setup...............................................................................................................................................................351
IP Ping.................................................................................................................................................................352
IP DNS ................................................................................................................................................................352
IP DNS Proxy ......................................................................................................................................................353
IP NTP Configuration...........................................................................................................................................356
IP NTP Mode.......................................................................................................................................................356
IP NTP Server Add ..............................................................................................................................................357
IP NTP Server IPv6 Add ......................................................................................................................................357
IP NTP Server Delete ..........................................................................................................................................358
6.3 Port Management Command...................................................................................................................359
Port Configuration ...............................................................................................................................................359
Port Mode............................................................................................................................................................359
Port Flow Control.................................................................................................................................................360
Port State.............................................................................................................................................................361
Port Maximum Frame..........................................................................................................................................361
Port Power...........................................................................................................................................................362
Port Excessive.....................................................................................................................................................362
Port Statistics.......................................................................................................................................................363
Port VeriPHY .......................................................................................................................................................363
Port SFP..............................................................................................................................................................364
Port Description...................................................................................................................................................364
6.4 MAC Address Table Command...............................................................................................................365
MAC Configuration ..............................................................................................................................................365
MAC Add .............................................................................................................................................................365
MAC Delete .........................................................................................................................................................366
MAC Lookup........................................................................................................................................................366
MAC Age Time ....................................................................................................................................................367
MAC Learning .....................................................................................................................................................367
9
User’s Manual of XGSW-28040
MAC Dump..........................................................................................................................................................368
MAC Statistics .....................................................................................................................................................368
MAC Flush...........................................................................................................................................................369
VLAN Link Type...................................................................................................................................................373
VLAN Name Add .................................................................................................................................................377
VLAN Name Delete .............................................................................................................................................378
VLAN Name Lookup............................................................................................................................................378
Security Switch User Configuration .....................................................................................................................383
Security Switch User Add....................................................................................................................................383
Security Switch User Delete ................................................................................................................................384
Security Switch SNMP Community Add ..............................................................................................................404
Security Switch SNMP Community Delete ..........................................................................................................404
Security Switch SNMP Community Lookup.........................................................................................................405
Security Switch SNMP User Add.........................................................................................................................405
Security Switch SNMP User Delete..................................................................................................................... 406
Security Switch SNMP User Changekey ............................................................................................................. 406
Security Switch SNMP User Lookup ...................................................................................................................407
Security Switch SNMP Group Add.......................................................................................................................407
Security Switch SNMP Group Delete ..................................................................................................................408
Security Switch SNMP Group Lookup.................................................................................................................408
Security Switch RMON History Add.....................................................................................................................413
Security Switch RMON History Delete ................................................................................................................414
Security Switch RMON History Lookup ...............................................................................................................414
Security Network Limit Port .................................................................................................................................420
Security Network NAS Configuration...................................................................................................................423
Security Network NAS Mode ...............................................................................................................................423
Security Network NAS State................................................................................................................................424
Security Network NAS Reauthentication .............................................................................................................425
Security Network NAS ReauthPeriod ..................................................................................................................425
Security Network NAS EapolTimeout .................................................................................................................. 426
Security Network NAS Agetime...........................................................................................................................426
Security Network NAS Holdtime..........................................................................................................................427
Security Network NAS RADIUS_QoS .................................................................................................................427
Security Network NAS RADIUS_VLAN ...............................................................................................................428
Security Network NAS Guest_VLAN ...................................................................................................................428
Security Network NAS Authenticate .................................................................................................................... 429
12
User’s Manual of XGSW-28040
Security Network NAS Statistics..........................................................................................................................430
STP Version ........................................................................................................................................................ 453
STP Tx Hold ........................................................................................................................................................454
STP Status ..........................................................................................................................................................458
STP Port Configuration........................................................................................................................................460
STP Port Mode....................................................................................................................................................460
STP Port Edge ....................................................................................................................................................461
STP Port AutoEdge .............................................................................................................................................461
STP Port P2P ......................................................................................................................................................462
STP Port RestrictedRole .....................................................................................................................................462
STP Port RestrictedTcn .......................................................................................................................................463
STP Port bpduGuard ...........................................................................................................................................463
STP Port Statistic.................................................................................................................................................464
STP Port Mcheck.................................................................................................................................................464
STP MSTI Port Configuration ..............................................................................................................................465
STP MSTI Port Cost............................................................................................................................................465
STP MSTI Port Priority ........................................................................................................................................466
6.9 Link Aggregation Command...................................................................................................................467
LACP Status ........................................................................................................................................................472
LLDP Info ............................................................................................................................................................479
LLDPMED Port Policy .........................................................................................................................................483
LLDPMED Fast ...................................................................................................................................................485
LLDPMED Info ....................................................................................................................................................485
6.13 Quality of Service Command ................................................................................................................486
QoS Port Classification Class..............................................................................................................................486
QoS Port Classification DPL................................................................................................................................486
QoS Port Classification Tag .................................................................................................................................487
QoS Port Classification Map................................................................................................................................488
QoS Port Classification DSCP.............................................................................................................................488
QoS Port Policer Mode........................................................................................................................................489
QoS Port Policer Rate .........................................................................................................................................489
QoS Port Policer Unit ..........................................................................................................................................490
QoS Port Scheduler Mode...................................................................................................................................490
QoS Port Scheduler Weight ................................................................................................................................491
QoS Port QueueShaper Mode ............................................................................................................................491
QoS Port QueueShaper Rate..............................................................................................................................492
15
User’s Manual of XGSW-28040
QoS Port QueueShaper Excess..........................................................................................................................492
QoS Port TagRemarking Mode............................................................................................................................493
QoS Port TagRemarking PCP .............................................................................................................................493
QoS Port TagRemarking DEI...............................................................................................................................494
QoS Port TagRemarking DPL..............................................................................................................................494
QoS Port TagRemarking Map..............................................................................................................................495
QoS Port DSCP Translation ................................................................................................................................495
QoS Port DSCP Classification.............................................................................................................................496
QoS Port DSCP EgressRemark .......................................................................................................................... 497
QoS Port Storm Unicast ......................................................................................................................................499
QoS Port Storm Multicast ....................................................................................................................................500
QoS Port Storm Unknownt ..................................................................................................................................501
Mirror Port ...........................................................................................................................................................505
Firmware Information ..........................................................................................................................................507
MVR VLAN Port ..................................................................................................................................................512
MVR Status .........................................................................................................................................................514
MVR Group .........................................................................................................................................................515
Voice VLAN Port Mode........................................................................................................................................521
Loop Protect Port Configuration ..........................................................................................................................524
Loop Protect Port Mode.......................................................................................................................................524
Loop Protect Port Action......................................................................................................................................525
IPMC State ..........................................................................................................................................................529
IPMC Status ........................................................................................................................................................533
IPMC Group ........................................................................................................................................................533
IPMC Version ......................................................................................................................................................534
IPMC Parameter URI ..........................................................................................................................................537
SMTP Mail From..................................................................................................................................................548
SMTP Mail Subject..............................................................................................................................................548
SMTP Mail to 1....................................................................................................................................................548
SMTP Mail to 2....................................................................................................................................................548
APPENDEX B : GLOSSARY.................................................................................................556
19
User’s Manual of XGSW-28040
1. INTRODUTION
Thank you for purchasing PLANET Layer 2 10G Managed Switch, XGSW-28040 series. Terms of “Managed Switch” means
the Switches mentioned titled in the cover page of this user’s manual, i.e. XGSW-28040.
1.1 Packet Contents
Open the box of the Managed Switch and carefully unpack it. The box should contain the following items:
Check the contents of your package for following parts:
The Managed Switch
User’s Manual CD
Quick Installation Guide
Rack Mount Accessory Kit
Power Cord
RubberFeet
RS-232 DB9 Male Console Cable
SFP Dust Caps
If any of these are missing or damaged, please contact your dealer immediately, if possible, retain the carton including the
original packing material, and use them against to repack the product in case there is a need to return it to us for repair.
x1
x1
x1
x1
x1
X4
x1
X8
1.2 Product Description
Cost-effective 10Gbps Uplink Capacitated Managed Switch Solution for SMB
The XGSW-28040 is PLANET’s first Layer 2 IPv6 / IPv4 management Gigabit switch built in with four 10Gbps uplink slots to
greatly support SMB network achieve 10Gbps high performance in a cost-effective way because 10GbE interface usually could
be available in Layer 3 Switch but Layer 3 Switch could be too expensive to SMB. The four 10Gbps interface in the
XGSW-28040 is 10G SFP+ that is in the same size as commonly seen Gigabit SFP slot and also is the main standard for
10Gbps transceiver. The XGSW-28040 can work with PLANET ENW-9800 series or the third brand 10Gbps server adapter to
help SMB build up 10Gbps Ethernet network providing 10Gbps NAS (Network Attached Storage) or heavy transmission of video
streaming service at affordable price. Each of the SFP+ slot supports Dual-Speed, 10GBase-SR/LR or 1000Base-SX / LX; that
means, the administrator now can flexibly choose the suitable SFP/SFP+ transceiver according to not only the transmission
distance but also the transmission speed required.
Cost-effective IPv6 Managed Gigabit Switch Solution for SMB
Nowadays, lots of electronic products or mobile devices can browse the Internet, which means the need of IP Address
increases. However, the current IPv4 network infrastructure is not capable enough to provide IP Address to each single users /
20
User’s Manual of XGSW-28040
Clients. The situation forces the ISP to build up the IPv6 (Internet Protocol version 6) network infrastructure speedily. To fulfill
the demand, PLANET releases the IPv6 management Gigabit Ethernet Switch, the XGSW-28040 which supports both IPv4
and IPv6 management functions. It can work with original network structure (IPv4) and also support the new network structure
(IPv6) in the future. With easy and friendly management interfaces and plenty of management functions included, the
XGSW-28040 is the best choice for ISP to build the IPv6 FTTx edge service and for SMB to connect with the IPv6 network.
High Performance
The XGSW-28040 provides 24 10/100/1000Mbps Gigabit Ethernet ports with 4 shared 100/1000X SFP slots + 4 10G/1G SFP+
slot. It boasts high performance architecture of switch that is capable for providing the non-blocking switch fabric and wire-speed
throughput as high as 128Gbps, which greatly simplifies the tasks of upgrading the LAN for catering to increasing bandwidth
demands.
Robust Layer 2 Features
The XGSW-28040 can be programmed for advanced switch management functions such as dynamic Port link aggregation,
Q-in-Q VLAN, private VLAN, Rapid Spanning Tree protocol, Layer 2 to Layer 4 QoS, bandwidth control and IGMP Snooping.
The XGSW-28040 provides 802.1Q Tagged VLAN, and the VLAN groups allowed will be maximally up to 255. Via aggregation
of supporting ports, the XGSW-28040 allows the operation of a high-speed trunk combining multiple ports. It enables maximum
up to 14 groups of 16 ports for trunking, and supports fail-over as well.
Excellent Traffic Control
The XGSW-28040 is loaded with powerful traffic management and QoS features to enhance services offered by telecoms. The
functionality includes QoS features such as wire-speed Layer 4 traffic classifiers and bandwidth limiting that are particular useful
for multi-tenant unit, multi business unit, Telco, or Network Service Provide applications. It also empowers the enterprises to
take full advantages of the limited network resources and guarantees the best performance in VoIP and Video conferencing
transmission.
Efficient Management
For efficient management, the XGSW-28040 Managed Ethernet Switch is equipped with console, WEB and SNMP
management interfaces. With the built-in Web-based management interface, the PLANET XGSW-28040 offers an easy-to-use,
platform-independent management and configuration facility. The XGSW-28040 supports standard Simple Network
Management Protocol (SNMP) and can be managed via any standard-based management software. For text-based
management, the XGSW-28040 can be accessed via Telnet and the console port. Moreover, the XGSW-28040 offers secure
remote management by supporting SNMPv3 connection which encrypts the packet content at each session.
Powerful Security
PLANET XGSW-28040 offers comprehensive Layer 2 to Layer 4 Access Control List (ACL) for enforcing security to the edge. It
can be used to restrict network access by denying packets based on source and destination IP address, TCP/UDP ports or
defined typical network applications. Its protection mechanism also comprises of 802.1x port-based and MAC-based user and
device authentication. With the private VLAN function, communication between edge ports can be prevented to ensure user
privacy. The network administrators can now construct highly secured corporate networks with considerably less time and effort
than before.
Flexibility and Extension Solution
The four mini-GBIC SFP slots built in the XGSW-28040 support Dual-Speed, 100Base-FX and 1000Base-SX/LX SFP (Small
Form-factor Pluggable) fiber-optic modules, that means, the administrator now can flexibly choose the suitable SFP transceiver
according to not only the transmission distance but also the transmission speed required. The distance can be extended from
550 meters (Multi-Mode fiber) up to above 10/50/70/120 kilometers (Single-Mode fiber or WDM fiber). They are well suited for
21
User’s Manual of XGSW-28040
applications within the enterprise data centers and distributions.
1.3 How to Use This Manual
This User Manual is structured as follows:
Section 2, INSTALLATION
The section explains the functions of the Switch and how to physically install the Managed Switch.
Section 3, SWITCH MANAGEMENT
The section contains the information about the software function of the Managed Switch.
Section 4, WEB CONFIGURATION
The section explains how to manage the Managed Switch by Web interface.
Section 5, COMMAND LINE INTERFACE
The section describes how to use the Command Line interface (CLI).
Section 6, CLI CONFIGURATION
The section explains how to manage the Managed Switch by Command Line interface.
Section 7, SWITCH OPERATION
The chapter explains how to does the switch operation of the Managed Switch.
Section 8, TROUBSHOOTING
The chapter explains how to trouble shooting of the Managed Switch.
Appendix A
The section contains cable information of the Managed Switch.
22
User’s Manual of XGSW-28040
1.4 Product Features
Physical Port
24-Port 10/100/1000Base-T RJ-45 copper
4 100/1000Base-X mini-GBIC/SFP slots , shared with Port-21 to Port-24
4 10GBase-SR/LR SFP+ slots, compatible with 1000Base-SX/LX/BX SFP
RS-232 DB9 console interface for basic management and setup
Layer 2 Features
Prevents packet loss with back pressure (Half-Duplex) and IEEE 802.3x PAUSE frame flow control (Full-Duplex)
High performance of Store-and-Forward architecture and runt/CRC filtering eliminates erroneous packets to optimize
the network bandwidth
Storm Control support:
broadcast / Unicast
Support VLAN
IEEE 802.1Q Tagged VLAN
Up to 256 VLANs groups, out of 4095 VLAN IDs
Provider Bridging (VLAN Q-in-Q) support (IEEE 802.1ad)
Private VLAN Edge (PVE)
Protocol-based VLAN
MAC-based VLAN
Voice VLAN
Support Spanning Tree Protocol
STP, IEEE 802.1d Spanning Tree Protocol
RSTP, IEEE 802.1w Rapid Spanning Tree Protocol
MSTP, IEEE 802.1s Multiple Spanning Tree Protocol, spanning tree by VLAN
BPDU Guard
Support Link Aggregation
802.3ad Link Aggregation Control Protocol (LACP)
Cisco ether-channel (Static Trunk)
Maximum 14 trunk groups, up to 8 ports per trunk group
Up to 16Gbps bandwidth(Duplex Mode)
Provide Port Mirror (many-to-1)
Port Mirroring to monitor the incoming or outgoing traffic on a particular port
Loop protection to avoid broadcast loops
Quality of Service
8 priority queues on all switch ports
Traffic classification:
- IEEE 802.1p CoS
23
- IP TOS / DSCP / IP Precedence
- IP TCP/UDP port number
- Typical network application
Strict priority and Weighted Round Robin (WRR) CoS policies
Build-in RADIUS client to co-operate with the RADIUS servers
TACACS+ login users access authentication
RADIUS / TACACS+ users access authentication
IP-Based Access Control List (ACL)
MAC-Based Access Control List
Source MAC / IP address binding
DHCP Snooping to filter untrusted DHCP messages
Dynamic ARP Inspection discards ARP packets with invalid MAC address to IP address binding
IP Source Guard prevents IP spoofing attacks
IP address access management to prevent unauthorized intruder
Management
Switch Management Interfaces
- Console / Telnet Command Line Interface
- Web switch management
- SNMP v1, v2c, and v3 switch management
- SSH / SSL secure access
Four RMON groups (history, statistics, alarms, and events)
IPv6 IP Address / NTP / DNS management
Built-in Trivial File Transfer Protocol (TFTP) client
BOOTP and DHCP for IP address assignment
Firmware upload/download via HTTP / TFTP
DHCP Relay
DHCP Option82
24
User’s Manual of XGSW-28040
User Privilege levels control
NTP (Network Time Protocol)
Link Layer Discovery Protocol (LLDP) Protocol
Cable Diagnostic technology provides the mechanism to detect and report potential cabling issues
Reset button for system reboot or reset to factory default
PLANET Smart Discovery Utility for deploy management
The front panel LEDs indicates instant status of port links, data activity and system power; helps monitor and troubleshoot when
needed. Figure 2-2 & Figure 2-3 shows the LED indications of these Managed Switches.
XGSW -28040 LED indication
Figure 2-2 XGSW-28040 LED for Front Panel
2-3 XGSW-28040 LED Rear Panel
Figure
30
■ System
LED Color Function
User’s Manual of XGSW-28040
SYS Green
PWR Green
■ Per 10/100/1000Mbps port
LED Color Function
1000
Green
LNK/ACT
10/100
Orange
LNK/ACT
■ Per 10G SF P+ interfaces
LED Color Function
Lights to indicate the system is working.
Lights to indicate that the Switch has power.
Lights to indicate the port is running in 1000Mbps speed and successfully established.
Blink: indicate that the switch is actively sending or receiving data over that port.
Lights to indicate the port is running in 10/100Mbps speed and successfully established.
Blink: indicate that the switch is actively sending or receiving data over that port.
10G
Green
LNK/ACT
1G
Orange
LNK/ACT
■ Alert
LED Color Function
FAN1 Alert Green
FAN2 Alert Green
Lights to indicate the port is running in 10Gbps speed and successfully established.
Blink: indicate that the switch is actively sending or receiving data over that port.
Lights to indicate the port is running in 1Gbps speed and successfully established.
Blink: indicate that the switch is actively sending or receiving data over that port.
Lights to indicate that the FAN1 failure
Lights to indicate that the FAN2 failure
2.1.3 Switch Rear Panel
The rear panel of the Managed Switch indicates an AC inlet power socket, which accepts input power from 100 to 240V AC,
50-60Hz. Figure 2-4 shows the rear panel of these Managed Switches
XGSW-28040 Rear Panel
Figure 2-4 Rear panel of XGSW-28040
31
User’s Manual of XGSW-28040
■ AC Power Receptacle
For compatibility with electric service in most areas of the world, the Managed Switch’s power supply automatically adjusts
to line power in the range 100-240VAC and 50/60 Hz.
Plug the female end of the power cord firmly into the receptalbe on the rear panel of the Managed Switch. Plug the other
end of the power cord into an electric service outlet then the power will be ready.
The device is a power-required device, it means, it will not work till it is powered. If your networks should
active all the time, please consider using UPS (Uninterrupted Power Supply) for your device. It will
Power Notice:
■ SFP+ slots
10GBase-SR/LR slot, SFP+ (Enchanced Small Factor Pluggable) transceiver module: From 550 meters (Multi-mode fiber),
up to 10kilometers (Single-mode fiber).
prevent you from network data loss or network downtime.
In some area, installing a surge suppression device may also help to protect your Managed Switch from
being damaged by unregulated surge or current to the Switch or the power adapter.
Factor Pluggable) transceiver module: From 550 meters (Multi-mode fiber), up to 10/30/50/70/120
kilometers (Single-mode fiber).
2.2 Install the Switch
This section describes how to install your Managed Switch and make connections to the Managed Switch. Please read the
following topics and perform the procedures in the order being presented. To install your Managed Switch on a desktop or shelf,
simply complete the following steps.
2.2.1 Desktop Installation
To install the Managed Switch on desktop or shelf, please follows these steps:
Step1: Attach the rubber feet to the recessed areas on the bottom of the Managed Switch.
Step2: Place the Managed Switch on the desktop or the shelf near an AC power source, as shown inFigure 2-5.
32
User’s Manual of XGSW-28040
Figure 2-5 Place the Managed Switch on the desktop
Step3: Keep enough ventilation space between the Managed Switch and the surrounding objects.
When choosing a location, please keep in mind the environmental restrictions discussed in Chapter 1,
Section 4, and Specification.
Step4:Connect the Managed Switch to network devices.
Connect one end of a standard network cable to the 10/100/1000 RJ-45 ports on the front of the Managed Switch
Connect the other end of the cable to the network devices such as printer servers, workstations or routers…etc.
Connection to the Managed Switch requires UTP Category 5 network cabling with RJ-45 tips. For more
information, please see the Cabling Specification in Appendix A.
Step5:Supply power to the Managed Switch.
Connect one end of the power cable to the Managed Switch.
Connect the power plug of the power cable to a standard wall outlet.
When the Managed Switch receives power, the Power LED should remain solid Green.
2.2.2 Rack Mounting
To install the Managed Switch in a 19-inch standard rack, please follows the instructions described below.
Step1: Place the Managed Switch on a hard flat surface, with the front panel positioned towards the front side.
Step2: Attach the rack-mount bracket to each side of the Managed Switch with supplied screws attached to the package.
Figure 2-6 shows how to attach brackets to one side of the Managed Switch.
33
User’s Manual of XGSW-28040
Figure 2-6 Attach brackets to the Managed Switch.
You must use the screws supplied with the mounting brackets. Damage caused to the parts by
using incorrect screws would invalidate the warranty.
Step3: Secure the brackets tightly.
Step4: Follow the same steps to attach the second bracket to the opposite side.
Step5: After the brackets are attached to the Managed Switch, use suitable screws to securely attach the brackets to the rack,
as shown in Figure 2-7.
Figure 2-7 Mounting XGSW-28040 in a Rack
Step6: Proceeds with the steps 4 and steps 5 of session 2.2.1 Desktop Installation to connect the network cabling and supply
34
User’s Manual of XGSW-28040
power to the Managed Switch.
2.2.3 Installing the SFP / SFP+ transceiver
The sections describe how to insert an SFP / SFP+ transceiver into an SFP / SFP+ slot.
The SFP /SFP+ transceivers are hot-pluggable and hot-swappable. You can plug-in and out the transceiver to/from any SFP /
SFP+ port without having to power down the Managed Switch. As the Figure 2-8 appears.
Figure 2-8 Plug-in the SFP / SFP+ transceiver
Approved PLANET SFP / SFP+ Transceivers
PLANET Managed Switch supports both Single mode and Multi-mode SFP / SFP+ transceiver. The following list of approved
PLANET SFP / SFP+ transceivers is correct at the time of publication:
1. It recommends using PLANET SFP / SFP+s on the Managed Switch. If you insert a SFP / SFP+
transceiver that is not supported, the Managed Switch will not recognize it.
2. Port 25 to Port 28 are SFP+ slots that support 10G SFP+ transceiver & Gigabit SFP transceiver.
3. Port 22 to Port 24 are shared SFP slot that support Gigabit & Fast Ethernet SFP transceiver.
In the installation steps below, this Manual use Gigabit SFP transceiver as the example. However,
the steps for Fast Ethernet SFP & 10G SFP+ transceiver are similar.
1. Make sure both side of the SFP transceiver are with the same media type, for example: 1000Base-SX to 1000Base-SX,
1000Bas-LX to 1000Base-LX.
2. Check the fiber-optic cable type match the SFP transceiver model.
To connect to 1000Base-SX SFP transceiver, use the Multi-mode fiber cable- with one side must be male duplex LC
connector type.
To connect to 1000Base-LX SFP transceiver, use the Single-mode fiber cable-with one side must be male duplex LC
connector type.
Conn ect the fiber cable
1. Attach the duplex LC connector on the network cable into the SFP transceiver.
2. Connect the other end of the cable to a device – switches with SFP installed, fiber NIC on a workstation or a Media
Converter..
3. Check the LNK/ACT LED of the SFP slot on the front of the Managed Switch. Ensure that the SFP transceiver is operating
correctly.
4. Check the Link mode of the SFP port if the link failed. Co works with some fiber-NICs or Media Converters, set the Link
mode to “1000 Force” or “100 Force” is needed.
Remove the transceiver module
1. Make sure there is no network activity by consult or check with the network administrator. Or through the management
36
interface of the switch/converter (if available) to disable the port in advance.
2. Remove the Fiber Optic Cable gently.
3. Turn the handle of the MGB module to horizontal.
4. Pull out the module gently through the handle.
User’s Manual of XGSW-28040
Figure 2-11 Pull out the SFP transceiver
Never pull out the module without pull the handle or the push bolts on the module. Direct pull
out the module with violent could damage the module and SFP module slot of the Managed
Switch.
37
User’s Manual of XGSW-28040
3. SWITCH MANAGEMENT
This chapter explains the methods that you can use to configure management access to the Managed Switch. It describes the
types of management applications and the communication and management protocols that deliver data between your
management device (workstation or personal computer) and the system. It also contains information about port connection
options.
This chapter covers the following topics:
Requirements
Management Access Overview
Administration Console Access
Web Management Access
SNMP Access
Standards, Protocols, and Related Reading
3.1 Requirements
Workstations of subscribers running Windows 2000/XP, 2003, Vista/7, 2008, MAC OS9 or later, Linux, UNIX or
other platform compatible with TCP/IP protocols.
Workstation installed with Ethernet NIC (Network Interface Card)
Serial Port connect (Terminal)
Above PC with COM Port (DB9 / RS-232) or USB-to-RS-232 converter
Ethernet Port connect
Network cables - Use standard network (UTP) cables with RJ45 connectors.
Above Workstation installed with WEB Browser and JAVA runtime environment Plug-in
It is recommended to use Internet Explore 7.0 or above to access Managed Switch.
38
User’s Manual of XGSW-28040
3.2 Management Access Overview
The Managed Switch gives you the flexibility to access and manage it using any or all of the following methods:
An administration console
Web browser interface
An external SNMP-based network management application
The administration console and Web browser interface support are embedded in the Managed Switch software and are
available for immediate use. Each of these management methods has their own advantages. Table 3-1 compares the three
management methods.
Method Advantages Disadvantages
Console
Web Browser
SNMP Agent
No IP address or subnet needed
Text-based
Telnet functionality and HyperTerminal
built into Windows
95/98/NT/2000/ME/XP operating
systems
Secure
Ideal for configuring the switch remotely
Compatible with all popular browsers
Can be accessed from any location
Most visually appealing
Communicates with switch functions at
the MIB level
Based on open standards
Must be near switch or use dial-up connection
Not convenient for remote users
Modem connection may prove to be unreliable
or slow
Security can be compromised (hackers need
only know the IP address and subnet mask)
May encounter lag times on poor connections
Requires SNMP manager software
Least visually appealing of all three methods
Some settings require calculations
Security can be compromised (hackers need
only know the community name)
Table 3-1 Management Methods Comparison
3.3 Administration Console
The administration console is an internal, character-oriented, and command line user interface for performing system
administration such as displaying statistics or changing option settings. Using this method, you can view the administration
console from a terminal, personal computer, Apple Macintosh, or workstation connected to the switch's console (serial) port.
There are two ways to use this management method: via direct access or modem port access. The following sections describe
these methods. For more information about using the console, refer to Chapter 5 Command Line Interface Console Management.
39
User’s Manual of XGSW-28040
Figure 3-1 Console management
Direct Access
Direct access to the administration console is achieved by directly connecting a terminal or a PC equipped with a
terminal-emulation program (such as HyperTerminal) to the Managed Switch console (serial) port.
When using this management method, a straight DB9 RS-232 cable is required to connect the switch to the PC. After
making this connection, configure the terminal-emulation program to use the following parameters:
The default parameters are:
115200 bps
8 data bits
No parity
1 stop bit
Figure 3-2 Terminal parameter settings
You can change these settings, if desired, after you log on. This management method is often preferred because you can
remain connected and monitor the system during system reboots. Also, certain error messages are sent to the serial port,
regardless of the interface through which the associated action was initiated. A Macintosh or PC attachment can use any
terminal-emulation program for connecting to the terminal serial port. A workstation attachment under UNIX can use an emulator
such as TIP.
40
User’s Manual of XGSW-28040
3.4 Web Management
The Managed Switch offers management features that allow users to manage the Managed Switch from anywhere on the
network through a standard browser such as Microsoft Internet Explorer. After you set up your IP address for the switch, you can
access the Managed Switch's Web interface applications directly in your Web browser by entering the IP address of the
Managed Switch.
Figure 3-3 Web management
You can then use your Web browser to list and manage the Managed Switch configuration parameters from one central location,
just as if you were directly connected to the Managed Switch's console port. Web Management requires either Microsoft
Internet Explorer 7.0 or later, Safari or Mozilla Firefox 1.5 or later.
Figure 3-4 Web main screen of Managed Switch
41
User’s Manual of XGSW-28040
3.5 SNMP-Based Network Management
You can use an external SNMP-based application to configure and manage the Managed Switch, such as SNMPc Network
Manager, HP Openview Network Node Management (NNM) or What’s Up Gold. This management method requires the SNMP
agent on the switch and the SNMP Network Management Station to use the same community string. This management
method, in fact, uses two community strings: the get community string and the set community string. If the SNMP Net-work
management Station only knows the set community string, it can read and write to the MIBs. However, if it only knows the get
community string, it can only read MIBs. The default gets and sets community strings for the Managed Switch are public.
Figure 3-5 SNMP management
42
User’s Manual of XGSW-28040
4. WEB CONFIGURATION
This section introduces the configuration and functions of the Web-Based management.
About Web-based Management
The Managed Switch offers management features that allow users to manage the Managed Switch from anywhere on the
network through a standard browser such as Microsoft Internet Explorer.
The Web-Based Management supports Internet Explorer 7.0. It is based on Java Applets with an aim to reduce network
bandwidth consumption, enhance access speed and present an easy viewing screen.
By default, IE7.0 or later version does not allow Java Applets to open sockets. The user has to
explicitly modify the browser setting to enable Java Applets to use network ports.
The Managed Switch can be configured through an Ethernet connection, make sure the manager PC must be set on same the
IP subnet address with the Managed Switch.
For example, the default IP address of the SGSW Managed Switch is 192.168.0.100, then the manager PC should be set at
192.168.0.x (where x is a number between 1 and 254, except 100), and the default subnet mask is 255.255.255.0.
If you have changed the default IP address of the Managed Switch to 192.168.1.1 with subnet mask 255.255.255.0 via console,
then the manager PC should be set at 192.168.1.x (where x is a number between 2 and 254) to do the relative configuration on
manager PC.
Figure 4-1-1 Web Management
43
User’s Manual of XGSW-28040
Logging on the switch
1. Use Internet Explorer 7.0 or above Web browser. Enter the factory-default IP address to access the Web interface. The
factory-default IP Address as following:
http://192.168.0.100
2. When the following login screen appears, please enter the default username "admin" with password “admin” (or the
username/password you have changed via console) to login the main screen of Managed Switch. The login screen in
Figure 4-1-2 appears.
Figure 4-1-2 Login screen
Default User name: admin
Default Password: admin
After entering the username and password, the main screen appears as Figure 4-1-3.
44
User’s Manual of XGSW-28040
Figure 4-1-3 Default main page
Now, you can use the Web management interface to continue the switch management or manage the Managed Switch by Web
interface. The Switch Menu on the left of the web page let you access all the commands and statistics the Managed Switch
provides.
1. It is recommended to use Internet Explore 7.0 or above to access Managed Switch.
2. The changed IP address take effect immediately after click on the Save button, you need to
use the new IP address to access the Web interface.
3. For security reason, please change and memorize the new password after this first setup.
4. Only accept command in lowercase letter under web interface.
45
User’s Manual of XGSW-28040
4.1 Main Web Page
The SGSW Managed Switch provides a Web-based browser interface for configuring and managing it. This interface allows you
to access the Managed Switch using the Web browser of your choice. This chapter describes how to use the Managed Switch’s
Web browser interface to configure and manage it.
Main Functions Menu
Copper Port Link Status
SFP / SFP+ Port Link Status
F
igure 4-1-4 Main Page
Panel Display
The web agent displays an image of the Managed Switch’s ports. The Mode can be set to display different information for the
ports, including Link up or Link down. Clicking on the image of a port opens the Port Statistics page.
The port states are illustrated as follows:
Main Menu
Using the onboard web agent, you can define system parameters, manage and control the Managed Switch, and all its ports, or
monitor network conditions. Via the Web-Management, the administrator can setup the Managed Switch by select the functions
those listed in the Main Function. The screen in Figure 4-1-5 appears.
Help Button
State Disabled Down Link
RJ-45 Ports
SFP / SFP+ Ports
Main Screen
46
