PLANET XGS3-24042 User Manual

Download
XGS3-24042
XGS3 Command Guide
Command G uide
XGS3-24242
24-Port Gigabit with 4 Optional 10G slots Layer 3 Managed Stackable Switch
1-1
XGS3 Command Guide
Content
CHAPTER 1 COMMANDS FOR BASIC SWITCH CONFI GURATION ..........................1-50
1.1 COMMANDS FOR BASIC CONFIGURATION ............................................................................................ 1-50
1.1.1 Authe nti cat ion lin e login ........................................................................................................................ 1-50
1.1.2 banner ................................................................................................................................................... 1-51
1.1.3 boot img ................................................................................................................................................ 1-51
1.1.4 boot startup-config ................................................................................................................................ 1-52
1.1.5 clock set ................................................................................................................................................ 1-53
1.1.6 config .................................................................................................................................................... 1-53
1.1.7 debug ssh-server .................................................................................................................................. 1-54
1.1.8 disable................................................................................................................................................... 1-54
1.1.9 enable ................................................................................................................................................... 1-54
1.1.10 enable password ................................................................................................................................. 1-55
1.1.11 end ...................................................................................................................................................... 1-55
1.1.12 exec-timeout ....................................................................................................................................... 1-56
1.1.13 exit ...................................................................................................................................................... 1-56
1.1.14 help ..................................................................................................................................................... 1-57
1.1.15 hostname ............................................................................................................................................ 1-57
1.1.16 ip host ................................................................................................................................................. 1-58
1.1.17 ipv6 host.............................................................................................................................................. 1-58
1.1.18 ip http server ....................................................................................................................................... 1-59
1.1.19 language ............................................................................................................................................. 1-59
1.1.20 login .................................................................................................................................................... 1-60
1.1.21 password ............................................................................................................................................. 1-60
1.1.22 reload .................................................................................................................................................. 1-61
1.1.23 service passw ord-encryption ............................................................................................................... 1-61
1.1.24 service terminal-length ........................................................................................................................ 1-62
1.1.25 sysContact .......................................................................................................................................... 1-62
1.1.26 sysLocation ......................................................................................................................................... 1-63
1.1.27 set default ........................................................................................................................................... 1-63
1.1.28 setup ................................................................................................................................................... 1-64
1.1.29 show clock .......................................................................................................................................... 1-64
1.1.30 show cpu usage .................................................................................................................................. 1-65
1.1.31 show memory usage ........................................................................................................................... 1-65
1.1.32 show privilege ..................................................................................................................................... 1-66
1.1.33 show temperature ............................................................................................................................... 1-66
1.1.34 show tech-support ............................................................................................................................... 1-66
1-2
XGS3 Command Guide
1.1.35 show version ....................................................................................................................................... 1-67
1.1.36 username ............................................................................................................................................ 1-67
1.1.37 web language ...................................................................................................................................... 1-68
1.1.38 write .................................................................................................................................................... 1-69
1.2 COMMANDS FOR TELNET ................................................................................................................... 1-69
1.2.1 authentication ip access-class .............................................................................................................. 1-69
1.2.2 authentication ipv6 acce ss-class ........................................................................................................... 1-69
1.2.3 authentication line login ........................................................................................................................ 1-70
1.2.4 authentication security ip........................................................................................................................ 1-71
1.2.5 authentication security ip v 6 .................................................................................................................... 1-71
1.2.6 authorization ......................................................................................................................................... 1-72
1.2.7 terminal length ...................................................................................................................................... 1-73
1.2.8 terminal monitor .................................................................................................................................... 1-73
1.2.9 telnet ..................................................................................................................................................... 1-74
1.2.10 telnet server enable ............................................................................................................................ 1-75
1.2.11 telnet-server max-connection .............................................................................................................. 1-75
1.2.12 ssh-server authentication-retries ......................................................................................................... 1-76
1.2.13 ssh-server enable ............................................................................................................................... 1-76
1.2.14 ssh-server host-key create rsa ............................................................................................................ 1-76
1.2.15 ssh-server max-connection ................................................................................................................. 1-77
1.2.16 ssh-server timeout .............................................................................................................................. 1-78
1.2.17 show ssh-server .................................................................................................................................. 1-78
1.2.18 show telnet login ................................................................................................................................. 1-79
1.2.19 who ..................................................................................................................................................... 1-79
1.3 COMMANDS FOR CONFIGURING SWITCH IP ......................................................................................... 1-79
1.3.1 interface vlan ......................................................................................................................................... 1-79
1.3.2 ip address ............................................................................................................................................. 1-80
1.3.3 ipv6 address .......................................................................................................................................... 1-81
1.3.4 ip bootp-client enable ............................................................................................................................ 1-81
1.3.5 ip dhcp-client enable ............................................................................................................................. 1-82
1.4 COMMANDS FOR SNMP..................................................................................................................... 1-83
1.4.1 debug snmp mib ................................................................................................................................... 1-83
1.4.2 debug snmp kernel ............................................................................................................................... 1-83
1.4.3 rmon enable .......................................................................................................................................... 1-83
1.4.4 show private-mib oid ............................................................................................................................. 1-84
1.4.5 show snmp ............................................................................................................................................ 1-84
1.4.6 show snmp engineid ............................................................................................................................. 1-86
1.4.7 show snmp group .................................................................................................................................. 1-86
1.4.8 show snmp mib ..................................................................................................................................... 1-87
1-3
XGS3 Command Guide
1.4.9 show snmp status ................................................................................................................................. 1-87
1.4.10 show snmp user .................................................................................................................................. 1-88
1.4.11 show snmp view .................................................................................................................................. 1-88
1.4.12 snmp-server commun it y ...................................................................................................................... 1-89
1.4.13 snmp-server enable ............................................................................................................................ 1-90
1.4.14 snmp-server enable traps ................................................................................................................... 1-90
1.4.15 snmp-server engineid ......................................................................................................................... 1-91
1.4.16 snmp-server group .............................................................................................................................. 1-92
1.4.17 snmp-server host ................................................................................................................................ 1-92
1.4.18 snmp-server securityip ........................................................................................................................ 1-93
1.4.19 snmp-server secur ity ip ........................................................................................................................ 1-94
1.4.20 snmp-server trap-source ..................................................................................................................... 1-94
1.4.21 snmp-server user ................................................................................................................................ 1-95
1.4.22 snmp-server view ................................................................................................................................ 1-96
1.5 COMMANDS FOR SWITCH UPGRADE ................................................................................................... 1-97
1.5.1 copy（FTP） ........................................................................................................................................ 1-97
1.5.2 copy（TFTP） ...................................................................................................................................... 1-98
1.5.3 ftp-dir ..................................................................................................................................................... 1-99
1.5.4 ftp-server enable ................................................................................................................................. 1-100
1.5.5 ftp-server timeout ................................................................................................................................ 1-100
1.5.6 ip ftp .................................................................................................................................................... 1-101
1.5.7 show ftp ............................................................................................................................................... 1-101
1.5.8 show tftp .............................................................................................................................................. 1-102
1.5.9 tftp-server enable ................................................................................................................................ 1-102
1.5.10 tftp-server retransmission-number .................................................................................................... 1-103
1.5.11 tftp-server transmission-timeout ........................................................................................................ 1-103
CHAPTER 2 FILE SYSTEM COMMANDS ...................................................................2-105
2.1 CD .................................................................................................................................................. 2-105
2.2 COPY .............................................................................................................................................. 2-105
2.3 DELETE ........................................................................................................................................... 2-106
2.4 DIR .................................................................................................................................................. 2-107
2.5 FORM AT .......................................................................................................................................... 2-107
2.6 MKDIR ............................................................................................................................................. 2-108
2.7 PWD ................................................................................................................................................ 2-108
2.8 RENAME .......................................................................................................................................... 2-109
2.9 RMDIR ............................................................................................................................................. 2-109
CHAPTER 3 COMMANDS FOR CLUSTER ................................................................. 3-111
3.1 CLEAR CLUSTER NODES ................................................................................................................... 3-111
1-4
XGS3 Command Guide
3.2 CLUSTER AUTO-ADD ......................................................................................................................... 3-111
3.3 CLUSTER COMMANDER ..................................................................................................................... 3-112
3.4 CLUSTER IP-POOL ............................................................................................................................ 3-112
3.5 CLUSTER KEEPALIVE INTERVAL ......................................................................................................... 3-113
3.6 CLUSTER KEEPALIVE LOSS-COUNT .................................................................................................... 3-114
3.7 CLUSTER MEMBER ........................................................................................................................... 3-115
3.8 CLUSTER MEMBER AUTO-TO-USER .................................................................................................... 3-115
3.9 CLUSTER RESET MEMBER ................................................................................................................. 3-116
3.10 CLUSTER RUN ................................................................................................................................ 3-116
3.11 CLUSTER UPDATE MEMBER ............................................................................................................. 3-117
3.12 DEBUG CLUSTER ............................................................................................................................ 3-118
3.13 DEBUG CLUSTER PACKETS ............................................................................................................. 3-118
3.14 SHOW CLUSTER ............................................................................................................................. 3-119
3.15 SHOW CLUSTER MEMBERS ............................................................................................................. 3-120
3.16 SHOW CLUSTER CANDIDATES.......................................................................................................... 3-121
3.17 SHOW CLUSTER TOPOLOGY ............................................................................................................ 3-122
3.18 RCOMMAND COMMANDER ............................................................................................................... 3-124
3.19 RCOMMAND MEMBER ..................................................................................................................... 3-124
CHAPTER 4 COMMANDS FOR NETWORK PORT CONFIGURATION .....................4-125
4.1 COMMANDS FOR ETHERNET PORT CONFIGURATION .......................................................................... 4-125
4.1.1 bandwidth ............................................................................................................................................ 4-125
4.1.2 combo-forced-mode ............................................................................................................................ 4-126
4.1.3 clear counters interface ....................................................................................................................... 4-126
4.1.4 flow control .......................................................................................................................................... 4-127
4.1.5 interface ethernet ................................................................................................................................ 4-128
4.1.6 loopback.............................................................................................................................................. 4-128
4.1.7 mdi ...................................................................................................................................................... 4-129
4.1.8 name ................................................................................................................................................... 4-129
4.1.9 negotiation .......................................................................................................................................... 4-130
4.1.10 port-rate-statistics interval ................................................................................................................. 4-131
4.1.11 port-scan-mode ................................................................................................................................. 4-131
4.1.12 rate-suppression ............................................................................................................................... 4-132
4.1.13 rate-violation ..................................................................................................................................... 4-133
4.1.14 show interface ................................................................................................................................... 4-133
4.1.15 shutdown ........................................................................................................................................... 4-138
4.1.16 speed-duplex .................................................................................................................................... 4-138
4.1.17 virtual-cable-test ................................................................................................................................ 4-139
CHAPTER 5 COMMANDS FOR PORT ISOLATION FUNCTION ................................5-141
1-5
XGS3 Command Guide
5.1 ISOL ATE-PORT GROUP ...................................................................................................................... 5-141
5.2 ISOL ATE-PORT GROUP SWITCHPORT I NTERFACE ................................................................................ 5-141
5.3 ISOL ATE-PORT APPLY ....................................................................................................................... 5-142
5.4 SHOW ISOLATE-PORT GROUP ............................................................................................................ 5-143
CHAPTER 6 COMMANDS FOR PORT LOOPBACK DETE CTION FUNCTION .........6-144
6.1 DEBUG LOOPBACK-DETECTION ......................................................................................................... 6-144
6.2 LOOPBACK-DETECTION CONTROL ..................................................................................................... 6-144
6.3 LOOPBACK-DETECTION CONTROL-RECOVERY TIMEOUT ...................................................................... 6-145
6.4 LOOPBACK-DETECTION INTERVAL-TIME ............................................................................................. 6-146
6.5 LOOPBACK-DETECTION SPECIFIED-VLAN ........................................................................................... 6-146
6.6 SHOW L OOPBACK-DETECTION .......................................................................................................... 6-147
CHAPTER 7 COMMANDS FOR ULDP ........................................................................7-148
7.1 DEBUG ULDP ................................................................................................................................... 7-148
7.2 DEBUG ULDP ERROR ........................................................................................................................ 7-148
7.3 DEBUG ULDP EVENT ......................................................................................................................... 7-149
7.4 DEBUG ULDP FSM INTERFACE ETHERNET ........................................................................................... 7-149
7.5 DEBUG ULDP INTERFACE ETHERNET .................................................................................................. 7-150
7.6 DEBUG ULDP PACKET ....................................................................................................................... 7-150
7.7 ULDP A G G R ESSI VE-MODE ................................................................................................................. 7-151
7.8 ULDP ENABLE .................................................................................................................................. 7-151
7.9 ULDP DISABLE ................................................................................................................................. 7-152
7.10 ULDP HELLO-INTERVAL ................................................................................................................... 7-152
7.11 ULDP MANUAL-SHUTDOWN ............................................................................................................. 7-153
7.12 ULDP RESET .................................................................................................................................. 7-153
7.13 SHOW ULDP ................................................................................................................................... 7-154
CHAPTER 8 COMMANDS FOR LLDP FUNCTION ........................................................ 8-1
8.1 CLEAR LLDP REMOTE-TABLE ................................................................................................................ 8-1
8.2 DEBUG LLDP ........................................................................................................................................ 8-1
8.3 DEBUG LLDP PACKETS ......................................................................................................................... 8-2
8.4 LLDP ENABLE ...................................................................................................................................... 8-2
8.5 LLDP ENABLE (PORT) ........................................................................................................................... 8-3
8.6 LLDP MODE .......................................................................................................................................... 8-3
8.7 LLDP MSGTXHOLD ............................................................................................................................... 8-4
8.8 LLDP NEIGHBORS MAX-NUM .................................................................................................................. 8-5
8.9 LLDP NOTIFICATION INTERVAL ............................................................................................................... 8-5
8.10 LLDP TOOMANYNEIGHBORS ............................................................................................................... 8-6
8.11 LLDP TRANSMIT DELAY ....................................................................................................................... 8-6
1-6
XGS3 Command Guide
8.12 LLDP TRANSMIT OPTIONAL TLV............................................................................................................ 8-7
8.13 LLDP TRAP ........................................................................................................................................ 8-8
8.14 LLDP TX-INTERVAL ............................................................................................................................. 8-8
8.15 SHOW DEBUGGING LLDP ..................................................................................................................... 8-9
8.16 SHOW LLDP ..................................................................................................................................... 8-10
8.17 SHOW LLDP INTERFACE ETHERNET .................................................................................................... 8-10
8.18 SHOW LLDP NEIGHBORS INTERFACE ETHERNET ................................................................................. 8-11
8.19 SHOW LLDP TRAFFIC ........................................................................................................................ 8-12
CHAPTER 9 COMMANDS FOR PORT CHANNEL .......................................................9-13
9.1 DEBUG PORT-CHANNEL ...................................................................................................................... 9-13
9.2 INTERFACE PORT-CHANNEL ................................................................................................................ 9-14
9.3 LACP PORT-PRIORITY ......................................................................................................................... 9-14
9.4 LACP SYSTEM-PRIORITY ..................................................................................................................... 9-15
9.5 LACP TIMEOUT ................................................................................................................................... 9-15
9.6 LOAD-BALANCE ................................................................................................................................. 9-16
9.7 PORT-GROUP ..................................................................................................................................... 9-16
9.8 PORT-GROUP MODE ........................................................................................................................... 9-17
9.9 SHOW PORT-GROUP ........................................................................................................................... 9-18
CHAPTER 10 COMMANDS FOR JUMBO ...................................................................10-21
10.1 JUMBO ENABLE ............................................................................................................................. 10-21
CHAPTER 11 COMMANDS FOR EFM OAM ............................................................... 11-22
11.1 CLEAR ETHERNET-OAM ................................................................................................................... 11-22
11.2 DEBUG ETHERNET-OAM ERROR ....................................................................................................... 11-22
11.3 DEBUG ETHERNET-OAM FSM ........................................................................................................... 11-23
11.4 DEBUG ETHERNET-OAM PACKET ...................................................................................................... 11-23
11.5 DEBUG ETHERNET-OAM TIMER ........................................................................................................ 11-24
11.6 ETHERNET-OAM ............................................................................................................................. 11-24
11.7 ETHERNET-OAM ERRORED-FRAME THRESHOLD HIGH ........................................................................ 11-25
11.8 ETHERNET-OAM ERRORED-FRAME THRESHOLD LOW ........................................................................ 11-25
11.9 ETHERNET-OAM ERRORED-FRAME WINDOW ..................................................................................... 11-26
11.10 ETHERNET-OAM ERRORED-FRAME-PERIOD THRESHOLD HIGH ......................................................... 11-26
11.11 ETHERNET-OAM ERRORED-FRAME-PERIOD THRESHOLD LOW .......................................................... 11-27
11.12 ETHERNET-OAM ERRORED-FRAME-PERIOD WINDOW ....................................................................... 11-28
11.13 ETHERNET-OAM ERRORED-FRAME-SECONDS THRESHOLD HIGH ...................................................... 11-29
11.14 ETHERNET-OAM ERRORED-FRAME-SECONDS THRESHOLD LOW ....................................................... 11-29
11.15 ETHERNET-OAM ERRORED-FRAME-SECONDS WINDOW ................................................................... 11-30
11.16 ETHERNET-OAM ERRORED-SYMBOL-PERIOD THRESHOLD HIGH ....................................................... 11-31
1-7
XGS3 Command Guide
11.17 ETHERNET-OAM ERRORED-SYMBOL-PERIOD THRESHOLD LOW ........................................................ 11-32
11.18 ETHERNET-OAM ERRORED-SYMBOL-PERIOD WINDOW ..................................................................... 11-32
11.19 ETHERNET-O AM LINK-MONITOR ..................................................................................................... 11-33
11.20 ETHERNET-OAM MODE .................................................................................................................. 11-33
11.21 ETHERNET-OAM PERIOD ............................................................................................................... 11-34
11.22 ETHERNET-OAM REMOTE-FAILURE ................................................................................................. 11-35
11.23 ETHERNET-OAM REMOTE-LOOPBACK ............................................................................................ 11-35
11.24 ETHERNET-OAM REMOTE-LOOPBACK SUPPORTED.......................................................................... 11-36
11.25 ETHERNET-O AM TIMEOUT.............................................................................................................. 11-37
11.26 SHOW ETHERNET-OAM .................................................................................................................. 11-37
11.27 SHOW ETHERNET-OAM EVENTS ..................................................................................................... 11-41
11.28 SHOW ETHERNET-OAM LINK-EVE NTS CO NFIG URATION .................................................................... 11-43
11.29 SHOW ETHERNET-OAM LOOP BACK STATUS .................................................................................... 11-44
CHAPTER 12 VLAN CONFIGURATION ......................................................................12-46
12.1 COMMANDS FOR VLAN CONFIGURATION........................................................................................ 12-46
12.1.1 debug gvrp event .............................................................................................................................. 12-46
12.1.2 debug gvrp packet............................................................................................................................. 12-46
12.1.3 dot1q-tunnel enable .......................................................................................................................... 12-47
12.1.4 dot1q-tunnel tpid ............................................................................................................................... 12-48
12.1.5 garp timer join ................................................................................................................................... 12-49
12.1.6 garp timer leave ................................................................................................................................ 12-49
12.1.7 garp timer leaveall ............................................................................................................................. 12-50
12.1.8 gvrp (Global) ..................................................................................................................................... 12-50
12.1.9 gvrp (Port) ......................................................................................................................................... 12-51
12.1.10 no garp timer ................................................................................................................................... 12-51
12.1.11 name ............................................................................................................................................... 12-52
12.1.12 private-vlan ..................................................................................................................................... 12-53
12.1.13 private-vlan association................................................................................................................... 12-54
12.1.14 show dot1q-tunnel ........................................................................................................................... 12-54
12.1.15 show garp timer .............................................................................................................................. 12-55
12.1.16 show gvrp fsm information .............................................................................................................. 12-56
12.1.17 show gvrp leaveAll fsm information ................................................................................................. 12-56
12.1.18 show gvrp leavetimer running ......................................................................................................... 12-57
12.1.19 show gvrp port-member .................................................................................................................. 12-58
12.1.20 show gvrp port registerd vlan .......................................................................................................... 12-58
12.1.21 show gvrp timer running information ............................................................................................... 12-59
12.1.22 show gvrp vlan registerd port .......................................................................................................... 12-60
12.1.23 show vlan ........................................................................................................................................ 12-60
12.1.24 show vlan-translation ...................................................................................................................... 12-62
1-8
XGS3 Command Guide
12.1.25 switchport access vla n .................................................................................................................... 12-62
12.1.26 switchport forbidde n vl an ................................................................................................................ 12-63
12.1.27 switchport hybrid all o w ed vlan ........................................................................................................ 12-64
12.1.28 switchport hybrid native vlan ........................................................................................................... 12-65
12.1.29 switchport interfac e ......................................................................................................................... 12-65
12.1.30 switchport mode .............................................................................................................................. 12-66
12.1.31 switchport mode trunk allow-null ..................................................................................................... 12-67
12.1.32 switchport trunk allowed vlan .......................................................................................................... 12-68
12.1.33 switchport trunk native vlan ............................................................................................................. 12-68
12.1.34 vlan ................................................................................................................................................. 12-69
12.1.35 vlan internal ..................................................................................................................................... 12-70
12.1.36 vlan ingress enable ......................................................................................................................... 12-70
12.1.37 vlan-translation ................................................................................................................................ 12-71
12.1.38 vlan-translation enable .................................................................................................................... 12-72
12.1.39 vlan-translation miss drop ............................................................................................................... 12-72
12.2 COMMANDS FOR DYNAMIC VLAN CONFIGURATION ......................................................................... 12-74
12.2.1 dynamic-vlan mac-v la n prefer ........................................................................................................... 12-74
12.2.2 dynamic-vlan subnet-vlan prefer ....................................................................................................... 12-74
12.2.3 mac-vlan ........................................................................................................................................... 12-75
12.2.4 mac-vlan vlan .................................................................................................................................... 12-75
12.2.5 protocol-vlan ..................................................................................................................................... 12-76
12.2.6 show dynamic-vlan prefer ................................................................................................................. 12-77
12.2.7 show mac-vlan .................................................................................................................................. 12-78
12.2.8 show mac-vlan interface ................................................................................................................... 12-78
12.2.9 show protocol-vlan ............................................................................................................................ 12-79
12.2.10 show subnet-vlan ............................................................................................................................ 12-79
12.2.11 show subnet-vlan interface .............................................................................................................. 12-80
12.2.12 subnet-vlan ..................................................................................................................................... 12-80
12.2.13 switchport mac-vlan e nable ............................................................................................................. 12-81
12.2.14 switchport subnet-vlan enable ......................................................................................................... 12-82
12.3 COMMANDS FOR VOICE VLAN CONFIGURATION ............................................................................. 12-82
12.3.1 show voice-vlan ................................................................................................................................ 12-82
12.3.2 switchport voice-vlan enable ............................................................................................................. 12-83
12.3.3 voice-vlan .......................................................................................................................................... 12-83
12.3.4 voice-vlan vlan .................................................................................................................................. 12-84
CHAPTER 13 COMMANDS FOR MAC ADDRESS TABL E CONFIGURATION .........13-86
13.1 COMMANDS FOR MAC ADDRESS TABLE CONFIGURATION ............................................................... 13-86
13.1.1 clear mac-address-table dynamic ..................................................................................................... 13-86
13.1.2 mac-address-table aging-time ........................................................................................................... 13-86
1-9
XGS3 Command Guide
13.1.3 mac-address-table static | static-multic ast | blackhole....................................................................... 13-87
13.1.4 show mac-address-table ................................................................................................................... 13-88
13.2 COMMANDS FOR MAC ADDRESS BINDING CONFIGURATION .............................................................. 13-89
13.2.1 clear port-security dynamic ............................................................................................................... 13-89
13.2.2 mac-address-table periodic-monitor-time .......................................................................................... 13-90
13.2.3 show port-security ............................................................................................................................. 13-90
13.2.4 show port-security address ............................................................................................................... 13-91
13.2.5 show port-security interface .............................................................................................................. 13-92
13.2.6 switchport port-security ..................................................................................................................... 13-93
13.2.7 switchport port-s ecu rity conv ert ........................................................................................................ 13-93
13.2.8 switchport port-security lock .............................................................................................................. 13-94
13.2.9 switchport port-security mac-address ............................................................................................... 13-94
13.2.10 switchport port-security maximum ................................................................................................... 13-95
13.2.11 switchport port-security timeout ....................................................................................................... 13-96
13.2.12 switchport port-security violation ..................................................................................................... 13-96
CHAPTER 14 OMMANDS FOR MSTP ........................................................................14-98
14.1 COMMANDS FOR MSTP ................................................................................................................. 14-98
14.1.1 abort .................................................................................................................................................. 14-98
14.1.2 exit .................................................................................................................................................... 14-98
14.1.3 instance vlan ..................................................................................................................................... 14-99
14.1.4 name ................................................................................................................................................. 14-99
14.1.5 no .................................................................................................................................................... 14-100
14.1.6 revision-level ................................................................................................................................... 14-101
14.1.7 show................................................................................................................................................ 14-101
14.1.8 spanning-tree .................................................................................................................................. 14-102
14.1.9 spanning-tree cost........................................................................................................................... 14-102
14.1.10 spanning-tree digest-snooping ...................................................................................................... 14-103
14.1.11 spanning-tree format ..................................................................................................................... 14-104
14.1.12 spanning-tree forward-time ........................................................................................................... 14-105
14.1.13 spanning-tree hello-time ................................................................................................................ 14-105
14.1.14 spanning-tree link-type p2p ........................................................................................................... 14-106
14.1.15 spanning-tree maxage .................................................................................................................. 14-107
14.1.16 spanning-tree max-hop ................................................................................................................. 14-107
14.1.17 spanning-tree mcheck ................................................................................................................... 14-108
14.1.18 spanning-tree mode ...................................................................................................................... 14-109
14.1.19 spanning-tree mst configuration .................................................................................................... 14-109
14.1.20 spanning-tree mst cost .................................................................................................................. 14-110
14.1.21 spanning-tree mst loopguard ......................................................................................................... 14-111
14.1.22 spanning-tree mst port-priority ...................................................................................................... 14-112
1-10
XGS3 Command Guide
14.1.23 spanning-tree mst priority .............................................................................................................. 14-112
14.1.24 spanning-tree mst rootguard ......................................................................................................... 14-113
14.1.25 spanning-tree portfast ................................................................................................................... 14-114
14.1.26 spanning-tree port-priority ............................................................................................................. 14-114
14.1.27 spanning-tree priority .................................................................................................................... 14-115
14.1.28 spanning-tree rootguard ................................................................................................................ 14-116
14.1.29 spanning-tree tcflush (Global mode) ............................................................................................. 14-116
14.1.30 spanning-tree tcflush (Port mode) ................................................................................................. 14-117
14.1.31 spanning-tree transmit-hold-count................................................................................................. 14-118
14.2 COMMANDS FOR MONITOR AND DEBUG ........................................................................................ 14-118
14.2.1 debug spanning-tree ....................................................................................................................... 14-118
14.2.2 show mst-pending ........................................................................................................................... 14-119
14.2.3 show spanning-tree ......................................................................................................................... 14-120
14.2.4 show spanning-tr ee mst config ....................................................................................................... 14-122
CHAPTER 15 COMMANDS FOR QOS AND PBR .................................................... 15-124
15.1 ACCOUNTING ............................................................................................................................... 15-124
15.2 CLASS ......................................................................................................................................... 15-124
15.3 CLASS-MAP ................................................................................................................................. 15-125
15.4 CLEAR MLS QOS STATISTICS ......................................................................................................... 15-126
15.5 DROP .......................................................................................................................................... 15-126
15.6 MATCH ........................................................................................................................................ 15-127
15.7 MLS QOS AGGREGATE-POLICY ...................................................................................................... 15-128
15.8 MLS Q OS COS .............................................................................................................................. 15-130
15.9 MLS QOS INTERNA L -PRIORITY ....................................................................................................... 15-130
15.10 MLS QOS MAP ............................................................................................................................ 15-131
15.11 MLS QOS INTERNAL-PRIORITY ..................................................................................................... 15-133
15.12 MLS QOS QUEUE WEIGHT ............................................................................................................ 15-133
15.13 MLS QOS TRUST ......................................................................................................................... 15-134
15.14 PASS-THROUGH-COS .................................................................................................................. 15-135
15.15 PASS-THROUGH-DSCP ................................................................................................................ 15-135
15.16 POLICY ...................................................................................................................................... 15-136
15.17 POLICY AGGREGATE ................................................................................................................... 15-138
15.18 POLICY-MAP .............................................................................................................................. 15-138
15.19 SERVICE-POLICY INPUT .............................................................................................................. 15-139
15.20 SERVICE-POLICY INPUT VLAN ...................................................................................................... 15-140
15.21 SET INTERNAL PRIORITY ............................................................................................................. 15-140
15.22 SHOW CLASS-MAP ..................................................................................................................... 15-141
15.23 SHOW POLICY-MAP..................................................................................................................... 15-142
15.24 SHOW MLS QOS INTERFA CE ........................................................................................................ 15-143
1-11
XGS3 Command Guide
15.25 SHOW MLS QOS MAPS ................................................................................................................ 15-145
15.26 SHOW MLS QOS VLAN ................................................................................................................. 15-148
15.27 SHOW MLS QOS AGGREGATE-POLICY .......................................................................................... 15-149
15.28 TRANSMIT .................................................................................................................................. 15-150
CHAPTER 16 COMMANDS FOR FOR FLOW-BASED REDIRECT ION ................... 16-151
16.1 ACCESS-GROUP REDIRECT TO INTERFACE ETHERNET ..................................................................... 16-151
16.2 SHOW FLOW-BASED-REDIRECT ..................................................................................................... 16-152
CHAPTER 17 COMMANDS FOR EGRESS QOS ...................................................... 17-153
17.1 MLS QOS EG R ESS GREEN REMARK ................................................................................................ 17-153
17.2 MLS QOS MAP .............................................................................................................................. 17-153
17.3 SERVICE-POLICY OUTPUT ............................................................................................................. 17-157
17.4 SERVICE-POLICY OUTPUT VLAN ..................................................................................................... 17-157
17.5 SET ............................................................................................................................................. 17-158
17.6 SHOW MLS QOS EGRESS GREEN REMARK ...................................................................................... 17-159
17.7 SHOW MLS QOS MAPS .................................................................................................................. 17-159
CHAPTER 18 COMMANDS FOR FLEXIBLE QINQ .................................................. 18-160
18.1 ADD ............................................................................................................................................ 18-160
18.2 MATCH ........................................................................................................................................ 18-161
18.3 SERVICE-POLICY .......................................................................................................................... 18-162
18.4 SET ............................................................................................................................................. 18-162
CHAPTER 19 COMMANDS FOR LAYER 3 FORWARDING ..................................... 19-164
19.1 COMMANDS FOR LAYER 3 INTERFACE ........................................................................................... 19-164
19.1.1 bandwidth ........................................................................................................................................ 19-164
19.1.2 description ....................................................................................................................................... 19-165
19.1.3 description (VRF mode) .................................................................................................................. 19-165
19.1.4 interface loopback ........................................................................................................................... 19-166
19.1.5 interface vlan ................................................................................................................................... 19-166
19.1.6 ip vrf ................................................................................................................................................ 19-167
19.1.7 ip vrf forwarding vrfName ................................................................................................................ 19-168
19.1.8 rd ..................................................................................................................................................... 19-168
19.1.9 route-target ..................................................................................................................................... 19-169
19.1.10 show ip route vrf ............................................................................................................................ 19-170
19.1.11 show ip vrf ..................................................................................................................................... 19-170
19.1.12 shutdown ....................................................................................................................................... 19-171
19.2 COMMANDS FOR IPV4/V6 CONFIGURATION .................................................................................... 19-172
19.2.1 clear ip traffic ................................................................................................................................... 19-172
19.2.2 clear ipv6 neighbor .......................................................................................................................... 19-172
1-12
XGS3 Command Guide
19.2.3 debug ip icmp .................................................................................................................................. 19-172
19.2.4 debug ip packet ............................................................................................................................... 19-173
19.2.5 debug ipv6 packet ........................................................................................................................... 19-174
19.2.6 debug ipv6 icmp .............................................................................................................................. 19-174
19.2.7 debug ipv6 nd ................................................................................................................................. 19-175
19.2.8 debug ipv6 tunnel packet ................................................................................................................ 19-176
19.2.9 description ....................................................................................................................................... 19-176
19.2.10 ipv6 proxy enable .......................................................................................................................... 19-177
19.2.11 ip address ...................................................................................................................................... 19-178
19.2.12 ipv6 address .................................................................................................................................. 19-178
19.2.13 ipv6 route ...................................................................................................................................... 19-179
19.2.14 ipv6 redirect .................................................................................................................................. 19-180
19.2.15 ipv6 nd dad attempts ..................................................................................................................... 19-180
19.2.16 ipv6 nd ns-interval ......................................................................................................................... 19-181
19.2.17 ipv6 nd suppress-ra ...................................................................................................................... 19-182
19.2.18 ipv6 nd ra-lifetime .......................................................................................................................... 19-182
19.2.19 ipv6 nd min-ra-interval................................................................................................................... 19-183
19.2.20 ipv6 nd max-ra-interval.................................................................................................................. 19-183
19.2.21 ipv6 nd prefix ................................................................................................................................. 19-184
19.2.22 ipv6 nd ra-hoplimit ......................................................................................................................... 19-185
19.2.23 ipv6 nd ra-mtu ............................................................................................................................... 19-185
19.2.24 ipv6 nd reachable-time .................................................................................................................. 19-186
19.2.25 ipv6 nd retrans-timer ..................................................................................................................... 19-186
19.2.26 ipv6 nd other-config-flag ................................................................................................................ 19-187
19.2.27 ipv6 nd managed-config-flag ......................................................................................................... 19-187
19.2.28 ipv6 neighbor ................................................................................................................................ 19-187
19.2.29 interface tunnel ............................................................................................................................. 19-188
19.2.30 show ip interface ........................................................................................................................... 19-189
19.2.31 show ip traffic ................................................................................................................................ 19-189
19.2.32 show ipv6 interface ....................................................................................................................... 19-191
19.2.33 show ipv6 route ............................................................................................................................. 19-193
19.2.34 show ipv6 neighbors ..................................................................................................................... 19-194
19.2.35 show ipv6 traffic ............................................................................................................................ 19-195
19.2.36 show ipv6 redirect ......................................................................................................................... 19-196
19.2.37 show ipv6 tunnel ........................................................................................................................... 19-197
19.2.38 tunnel source ................................................................................................................................ 19-198
19.2.39 tunnel destination .......................................................................................................................... 19-198
19.2.40 tunnel nexthop .............................................................................................................................. 19-199
19.2.41 tunnel mode .................................................................................................................................. 19-199
1-13
XGS3 Command Guide
19.3 COMMANDS FOR IP ROUTE AGGREGATION ................................................................................... 19-200
19.3.1 ip fib optimize .................................................................................................................................. 19-200
19.4 COMMANDS FOR URPF ............................................................................................................... 19-201
19.4.1 show urpf ........................................................................................................................................ 19-201
19.4.2 urpf enable ...................................................................................................................................... 19-201
19.5 COMMANDS FOR ARP CONFIGURATION ........................................................................................ 19-201
19.5.1 arp ................................................................................................................................................... 19-201
19.5.2 clear arp-cache ............................................................................................................................... 19-202
19.5.3 clear arp traffic ................................................................................................................................ 19-202
19.5.4 debug arp ........................................................................................................................................ 19-203
19.5.5 ip proxy-arp ..................................................................................................................................... 19-204
19.5.6 show arp ......................................................................................................................................... 19-204
19.5.7 show arp traffic ................................................................................................................................ 19-205
19.6 COMMANDS FOR HARDWARE TUNNEL CAPACITY........................................................................... 19-206
19.6.1 hardware tunnel-capacity ................................................................................................................ 19-206
CHAPTER 20 COMMANDS FOR ARP SCANNING PREVENTION ..............................20-1
20.1 ANTI-ARPSCAN ENABLE .................................................................................................................... 20-1
20.2 ANTI-ARPSCAN PORT-BASED THRESHOLD .......................................................................................... 20-1
20.3 ANTI-ARPSCAN IP-BASED THRES HOL D ............................................................................................... 20-2
20.4 ANTI-ARPSCAN TRUST ...................................................................................................................... 20-3
20.5 ANTI-ARPSCAN TRUST IP .................................................................................................................. 20-3
20.6 ANTI-ARPSCAN RECOVERY ENABLE ................................................................................................... 20-4
20.7 ANTI-ARPSCAN RECOVERY TIME ........................................................................................................ 20-5
20.8 ANTI-ARPSCAN LOG ENABLE ............................................................................................................. 20-5
20.9 ANTI-ARPSCAN TRAP ENABLE ........................................................................................................... 20-6
20.10 SHOW ANTI-ARPSCAN ..................................................................................................................... 20-6
20.11 DEBUG ANTI-ARPSCAN ................................................................................................................... 20-8
CHAPTER 21 COMMANDS FOR PREVENTING ARP, ND SPOOFING .......................21-9
21.1 IP ARP-SECURITY UPDATEPROTECT ................................................................................................... 21-9
21.2 IPV6 ND-SECURITY UPDATEPROTECT ................................................................................................. 21-9
21.3 IP ARP-SECURITY LEARNPROTECT ................................................................................................... 21-10
21.4 IPV6 ND-SECURITY LEARNPROTECT ................................................................................................ 21-10
21.5 IP ARP-SECURITY CONVERT ............................................................................................................ 21-11
21.6 IPV6 ND-SECURITY CONVERT .......................................................................................................... 21-11
21.7 CLEAR IP ARP DYNAMIC .................................................................................................................. 21-12
21.8 CLEAR IPV6 ND DYNAMIC ................................................................................................................ 21-12
CHAPTER 22 COMMAND FOR ARP GUARD ............................................................22-14
1-14
XGS3 Command Guide
22.1 ARP-GUARD IP ............................................................................................................................... 22-14
CHAPTER 23 COMMAND FOR ARP LOCAL PROXY ................................................23-15
23.1 IP LOCAL PROXY-ARP ..................................................................................................................... 23-15
CHAPTER 24 COMMANDS FOR GRATUITOUS ARP CONFIGURATION .................24-16
24.1 IP GRATUITOUS-ARP ....................................................................................................................... 24-16
24.2 SHOW IP GRATUITOUS-ARP ............................................................................................................. 24-17
CHAPTER 25 COMMANDS FOR KEEPALIVE GATEWAY .........................................25-18
25.1 KEEPALIVE GATEWAY ..................................................................................................................... 25-18
25.2 SHOW IP INTERFACE ....................................................................................................................... 25-18
25.3 SHOW KEEPALIVE GATEWAY ............................................................................................................ 25-19
CHAPTER 26 COMMANDS FOR DHCP .....................................................................26-20
26.1 COMMANDS FOR DHCP SERVER CONFIGURATION .......................................................................... 26-20
26.1.1 bootfile .............................................................................................................................................. 26-20
26.1.2 clear ip dhcp binding ......................................................................................................................... 26-20
26.1.3 clear ip dhcp conflict ......................................................................................................................... 26-21
26.1.4 clear ip dhcp server statisti cs ............................................................................................................ 26-22
26.1.5 client-identifier ................................................................................................................................... 26-22
26.1.6 debug ip dhcp client .......................................................................................................................... 26-23
26.1.7 debug ip dhcp relay ........................................................................................................................... 26-23
26.1.8 debug ip dhcp server ........................................................................................................................ 26-23
26.1.9 default-router ..................................................................................................................................... 26-24
26.1.10 dns-server ....................................................................................................................................... 26-24
26.1.11 domain-name .................................................................................................................................. 26-25
26.1.12 hardware-address ........................................................................................................................... 26-25
26.1.13 host ................................................................................................................................................. 26-26
26.1.14 ip dhcp conflict logging .................................................................................................................... 26-27
26.1.15 ip dhcp excluded-address ............................................................................................................... 26-28
26.1.16 ip dhcp pool ..................................................................................................................................... 26-28
26.1.17 ip dhcp conflict ping-detection enable ............................................................................................. 26-29
26.1.18 ip dhcp ping packets ....................................................................................................................... 26-29
26.1.19 ip dhcp ping timeout ........................................................................................................................ 26-30
26.1.20 lease ............................................................................................................................................... 26-31
26.1.21 netbios-name-server ....................................................................................................................... 26-31
26.1.22 netbios-node-type ........................................................................................................................... 26-32
26.1.23 network-address ............................................................................................................................. 26-33
26.1.24 next-server ...................................................................................................................................... 26-33
26.1.25 option .............................................................................................................................................. 26-34
1-15
XGS3 Command Guide
26.1.26 service dhcp .................................................................................................................................... 26-35
26.1.27 show ip dhcp binding ...................................................................................................................... 26-35
26.1.28 show ip dhcp conflict ....................................................................................................................... 26-36
26.1.29 show ip dhcp relay information option ............................................................................................. 26-36
26.1.30 show ip dhcp server statist ic s ......................................................................................................... 26-37
26.2 COMMANDS FOR DHCP REL AY CONFIGURATION ............................................................................ 26-38
26.2.1 ip forward-protocol udp bootps .......................................................................................................... 26-38
26.2.2 ip helper-address .............................................................................................................................. 26-39
26.2.3 show ip forward-protocol ................................................................................................................... 26-39
26.2.4 show ip helper-address ..................................................................................................................... 26-40
CHAPTER 27 COMMANDS FOR DHCPV6 .................................................................27-41
27.1 CLEAR IPV6 DHCP BINDING ............................................................................................................. 27-41
27.2 CLEAR IPV6 DHCP CONFLICT ........................................................................................................... 27-41
27.3 CLEAR IPV6 DHCP STATIS TI CS ......................................................................................................... 27-42
27.4 DEBUG IPV6 DHCP CLIENT PACKET .................................................................................................. 27-42
27.5 DEBUG IPV6 DHCP DETAIL ............................................................................................................... 27-43
27.6 DEBUG IPV6 DHCP RELAY PACKET ................................................................................................... 27-43
27.7 DEBUG IPV6 DHCP SERVER ............................................................................................................. 27-44
27.8 DNS-SERVER ................................................................................................................................. 27-44
27.9 DOMAIN-NAME ............................................................................................................................... 27-45
27.10 EXCLUDED-ADDRESS ................................................................................................................... 27-45
27.11 IPV6 ADDRESS ............................................................................................................................. 27-46
27.12 IPV6 DHCP CLIENT PD ................................................................................................................... 27-47
27.13 IPV6 DHCP CLIENT PD HINT ........................................................................................................... 27-48
27.14 IPV6 DHCP POOL .......................................................................................................................... 27-48
27.15 IPV6 DHCP RELAY DES T INATION .................................................................................................... 27-49
27.16 IPV6 DHCP SERVER ...................................................................................................................... 27-50
27.17 IPV6 GENERAL-PREFIX ................................................................................................................. 27-51
27.18 IPV6 LOCAL POOL ........................................................................................................................ 27-51
27.19 LIFETIME ..................................................................................................................................... 27-52
27.20 NETWORK-ADDRESS .................................................................................................................... 27-53
27.21 PREFIX-DELEGATION .................................................................................................................... 27-54
27.22 PREFIX-DELEGATION POOL ........................................................................................................... 27-54
27.23 SERVICE DHCPV6 ......................................................................................................................... 27-55
27.24 SHOW I P V6 DHCP ......................................................................................................................... 27-56
27.25 SHOW I P V6 DHCP BINDING ............................................................................................................ 27-56
27.26 SHOW I P V6 DHCP CONFLICT .......................................................................................................... 27-57
27.27 SHOW I P V6 DHCP INTERFACE ........................................................................................................ 27-57
27.28 SHOW I P V6 DHCP POOL ................................................................................................................ 27-58
1-16
XGS3 Command Guide
27.29 SHOW I P V6 DHCP STATISTICS ........................................................................................................ 27-58
27.30 SHOW I P V6 GENERAL-PREFIX ....................................................................................................... 27-61
27.31 SHOW I P V6 LOCAL POOL .............................................................................................................. 27-61
CHAPTER 28 COMMANDS FOR DHCP OPTION 82 ..................................................28-62
28.1 DEBUG IP DHCP RELAY PACKET ....................................................................................................... 28-62
28.2 IP DHCP RELAY INFORMATION OPTION .............................................................................................. 28-62
28.3 IP DHCP RELAY INFORMATION OPTION DELIMITER ............................................................................. 28-63
28.4 IP DHCP RELAY INFORMATION OPTION REMOTE-ID ............................................................................ 28-63
28.5 IP DHCP RELAY INFORMATION OPTION REMOTE-ID FORMAT ............................................................... 28-64
28.6 IP DHCP RELAY INFORMATION OPTION SELF-DEFINED REMOTE-ID ...................................................... 28-65
28.7 IP DHCP RELAY INFORMATION OPTION SELF-DEFINED REMOTE-ID FORM AT ......................................... 28-66
28.8 IP DHCP RELAY INFORMATION OPTION SELF-DEFINED SUBSCRIBER-ID ............................................... 28-66
28.9 IP DHCP RELAY INFORMATION OPTION SELF-DEFINED SUBSCRIBER-ID FORMAT .................................. 28-67
28.10 IP DHCP RELAY INFORMATION OPTION SUBSCRIBER-ID .................................................................... 28-68
28.11 IP DHCP RELAY INFORMATION OPTION SUBSCRIBER-ID FORM AT ....................................................... 28-68
28.12 IP DHCP RELAY INFORMATION POLICY ............................................................................................ 28-69
28.13 IP DHCP SERVER RELAY INFORMATION ENABLE .............................................................................. 28-70
28.14 SHOW IP DHCP RELAY INFORMATION OPTION .................................................................................. 28-71
CHAPTER 29 COMMANDS FOR DHCPV6 OPTION37, 38 ........................................29-72
29.1 COMMANDS FOR DHCPV6 OPTION37, 38 ....................................................................................... 29-72
29.1.1 address range ................................................................................................................................... 29-72
29.1.2 class .................................................................................................................................................. 29-73
29.1.3 ipv6 dhcp class ................................................................................................................................. 29-73
29.1.4 ipv6 dhcp relay remote-id .................................................................................................................. 29-74
29.1.5 ipv6 dhcp relay remote-id option ....................................................................................................... 29-74
29.1.6 ipv6 dhcp relay subscriber-id ............................................................................................................ 29-75
29.1.7 ipv6 dhcp relay subscriber-id option .................................................................................................. 29-76
29.1.8 ipv6 dhcp relay subscriber-id select delimit er .................................................................................... 29-76
29.1.9 ipv6 dhcp server remote-id option ..................................................................................................... 29-77
29.1.10 ipv6 dhcp server select relay-forw ................................................................................................... 29-77
29.1.11 ipv6 dhcp server subscriber-id option .............................................................................................. 29-78
29.1.12 ipv6 dhcp snooping remote-id ......................................................................................................... 29-78
29.1.13 ipv6 dhcp snooping remote-id option .............................................................................................. 29-79
29.1.14 ipv6 dhcp snooping remote-id policy ............................................................................................... 29-80
29.1.15 ipv6 dhcp snooping subscriber-id .................................................................................................... 29-80
29.1.16 ipv6 dhcp snooping subscriber-id option ......................................................................................... 29-81
29.1.17 ipv6 dhcp snooping subscriber-id policy ......................................................................................... 29-82
29.1.18 ipv6 dhcp snooping subscriber-id select delimiter ........................................................................... 29-82
1-17
XGS3 Command Guide
29.1.19 ipv6 dhcp use class ......................................................................................................................... 29-83
29.1.20 remote-id subscriber-id ................................................................................................................... 29-84
29.2 COMMANDS FOR MONITORING AND DEBUGGING ............................................................................. 29-84
29.2.1 debug ipv6 dhcp detail ...................................................................................................................... 29-84
29.2.2 debug ipv6 dhcp relay packet ........................................................................................................... 29-85
29.2.3 debug ipv6 dhcp snooping pack et ..................................................................................................... 29-86
29.2.4 show ipv6 dhcp relay option .............................................................................................................. 29-87
29.2.5 show ipv6 dhcp snooping option ....................................................................................................... 29-87
CHAPTER 30 COMMANDS FOR DHCP SNOOPING .................................................30-89
30.1 DEBUG IP DHCP SNOOPING BINDING ................................................................................................ 30-89
30.2 DEBUG IP DHCP SNOOPING EVENT ................................................................................................... 30-89
30.3 DEBUG IP DHCP SNOOPING PACKET ................................................................................................. 30-90
30.4 DEBUG IP DHCP SNOOPING PACKET INTERFACE................................................................................ 30-90
30.5 DEBUG IP DHCP SNOOPING UPDATE ................................................................................................. 30-90
30.6 ENABLE TRUSTVIEW KEY ................................................................................................................ 30-91
30.7 IP DHCP SNOOPING......................................................................................................................... 30-92
30.8 IP DHCP SNOOPING ACTION ............................................................................................................. 30-92
30.9 IP DHCP SNOOPING ACTION MAXNUM .............................................................................................. 30-93
30.10 IP DHCP SNOOPING BINDING ......................................................................................................... 30-94
30.11 IP DHCP SNOOPING BINDING ARP ................................................................................................... 30-94
30.12 IP DHCP SNOOPING BINDING DOT1X ............................................................................................... 30-95
30.13 IP DHCP SNOOPING BINDING USER ................................................................................................. 30-96
30.14 IP DHCP SNOOPING BINDING USER-CONTROL ................................................................................. 30-96
30.15 IP DHCP SNOOPING BINDING USER-CONTROL MAX-USER ................................................................. 30-97
30.16 IP DHCP SNOOPING INFORMATION ENABLE ..................................................................................... 30-98
30.17 IP DHCP SNOOPING INFORMATION O P TION ALLOW-UNTRUSTED ....................................................... 30-99
30.18 IP DHCP SNOOPING INFORMATION OPTION DELIMITER ..................................................................... 30-99
30.19 IP DHCP SNOOPING INFORMATION OPTION REMOTE-ID .................................................................. 30-100
30.20 IP DHCP SNOOPING INFORMATION OPTION SELF-DEFINED REMOTE-ID ............................................ 30-101
30.21 IP DHCP SNOOPING INFORMATION O P TI O N SELF-DEFINED REMOTE-ID FORMAT ............................... 30-101
30.22 IP DHCP SNOOPING INFORMATION OPTION SELF-DEFINED SUBSCRIBER-ID ..................................... 30-102
30.23 IP DHCP SNOOPING INFORMATION OPTION SELF-DEFINED SUBSCRIBER-ID FORMAT ........................ 30-103
30.24 IP DHCP SNOOPING INFORMATION OPTION SUBSCRIBER-ID ........................................................... 30-103
30.25 IP DHCP SNOOPING INFORMATION OPTION SUBSCRIBER-ID FORM AT .............................................. 30-104
30.26 IP DHCP SNOOPING LIMIT-RATE ................................................................................................... 30-105
30.27 IP DHCP SNOOPING TRUST .......................................................................................................... 30-106
30.28 IP USER HELPER-ADDRESS ......................................................................................................... 30-106
30.29 IP USER PRIVATE PACKET VERSION TWO ...................................................................................... 30-107
30.30 SHOW IP DHCP SNOOPING ........................................................................................................... 30-108
1-18
XGS3 Command Guide
30.31 SHOW IP DHCP SNOOPING BINDING ALL ....................................................................................... 30-111
30.32 SHOW TRUSTVIEW STATUS .......................................................................................................... 30-112
CHAPTER 31 COMMANDS FOR ROUTING POLICY ............................................... 31-113
31.1 IP PREFIX-LIST DESCRIPTION ......................................................................................................... 31-113
31.2 IP PREFIX-LIST SEQ ...................................................................................................................... 31-114
31.3 IP PREFIX-LIST SEQUENCE-NUMBER .............................................................................................. 31-115
31.4 MATCH AS-PATH ........................................................................................................................... 31-115
31.5 MATCH COMMUNITY ...................................................................................................................... 31-116
31.6 MATCH INTERFACE ....................................................................................................................... 31-116
31.7 MATCH IP ..................................................................................................................................... 31-117
31.8 MATCH IPV6 ADDRESS .................................................................................................................. 31-118
31.9 MATCH IPV6 NEXT-HOP ................................................................................................................. 31-118
31.10 MATCH METRIC .......................................................................................................................... 31-119
31.11 MATCH ORIG I N ........................................................................................................................... 31-119
31.12 MATCH ROUTE-TYPE ................................................................................................................... 31-120
31.13 MATCH TAG ................................................................................................................................ 31-121
31.14 ROUTE-MAP ............................................................................................................................... 31-121
31.15 SET AGGREGATOR ..................................................................................................................... 31-122
31.16 SET AS-PATH .............................................................................................................................. 31-123
31.17 SET ATOMIC-AGGREGATE ........................................................................................................... 31-123
31.18 SET COMM-LIST ......................................................................................................................... 31-124
31.19 SET COMMUNITY ........................................................................................................................ 31-124
31.20 SET EX TC OMMUNITY ................................................................................................................... 31-125
31.21 SET IP NEXT-HOP ........................................................................................................................ 31-126
31.22 SET LOCAL-PREFERENCE ........................................................................................................... 31-126
31.23 SET METRIC ............................................................................................................................... 31-127
31.24 SET METRIC-TYPE ...................................................................................................................... 31-127
31.25 SET ORIGIN ................................................................................................................................ 31-128
31.26 SET ORIGINATOR-ID .................................................................................................................... 31-129
31.27 SET TAG .................................................................................................................................... 31-129
31.28 SET VPNV4 NEXT-HOP ................................................................................................................ 31-130
31.29 SET WEIGHT ............................................................................................................................... 31-130
31.30 SHOW IP PREFIX-LIST <LIST-NAME> ............................................................................................ 31-131
31.31 SHOW IP PREFIX-LIST<DETAIL|SUMMARY> ................................................................................... 31-132
31.32 SHOW ROUTE-MAP ..................................................................................................................... 31-133
31.33 SHOW ROUTER-ID ...................................................................................................................... 31-133
CHAPTER 32 COMMANDS FOR STATIC ROUTE .................................................... 32-135
32.1 IP ROUTE ..................................................................................................................................... 32-135
1-19
XGS3 Command Guide
32.2 IP ROUTE VRF .............................................................................................................................. 32-136
32.3 SHOW IP ROUTE ........................................................................................................................... 32-137
32.4 SHOW IP ROUTE VRF ..................................................................................................................... 32-138
CHAPTER 33 COMMANDS FOR RIP........................................................................ 33-140
33.1 ACCEPT-LIFETIME ......................................................................................................................... 33-140
33.2 ADDRESS-FA MILY IPV4 .................................................................................................................. 33-141
33.3 CLEAR IP RIP ROUTE ..................................................................................................................... 33-141
33.4 DEBUG RIP................................................................................................................................... 33-142
33.5 DEBUG RIP REDISTRIBUTE MESSAGE SEND .................................................................................... 33-143
33.6 DEBUG RIP REDISTRIBUTE ROUTE RECEIVE .................................................................................... 33-143
33.7 DEFAULT-INFORMATION ORIGINATE................................................................................................ 33-144
33.8 DEFAULT-METRIC ......................................................................................................................... 33-144
33.9 DISTANCE .................................................................................................................................... 33-145
33.10 DISTRIBUTE-LIST ........................................................................................................................ 33-146
33.11 EXIT-ADDRESS-FAMILY ................................................................................................................ 33-146
33.12 IP RIP AGGREGATE-ADDRESS ...................................................................................................... 33-147
33.13 IP RIP AUTHENTICATION KEY-CHAIN ............................................................................................. 33-147
33.14 IP RIP AUTHENTICATION MODE ..................................................................................................... 33-148
33.15 IP RIP AUTHENTICATION STRING .................................................................................................. 33-149
33.16 IP RIP AUTHENTICATION CISCO-COMPATIBLE ................................................................................ 33-150
33.17 IP RIP RECEIVE-PACKET .............................................................................................................. 33-150
33.18 IP RIP RECEIVE VER SION ............................................................................................................. 33-151
33.19 IP RIP SEND-PACKET ................................................................................................................... 33-151
33.20 IP RIP SEND VERSIO N .................................................................................................................. 33-152
33.21 IP RI P SPLIT-HORIZON ................................................................................................................. 33-153
33.22 KEY ........................................................................................................................................... 33-153
33.23 KEY CHAIN ................................................................................................................................. 33-154
33.24 KEY-STRING ............................................................................................................................... 33-154
33.25 MAXIMUM-PREFIX ....................................................................................................................... 33-155
33.26 NEIGHBOR ................................................................................................................................. 33-156
33.27 NETWORK .................................................................................................................................. 33-156
33.28 OFFSET-LIST .............................................................................................................................. 33-157
33.29 PASSIVE-INTERFACE ................................................................................................................... 33-158
33.30 RECV-BUFFER-SIZE .................................................................................................................... 33-158
33.31 REDISTRIBUTE ........................................................................................................................... 33-159
33.32 ROUTE ...................................................................................................................................... 33-160
33.33 ROUTER RIP ............................................................................................................................... 33-160
33.34 SEND-LIFETIME .......................................................................................................................... 33-161
33.35 SHOW DEBUGGING RIP ............................................................................................................... 33-162
1-20
XGS3 Command Guide
33.36 SHOW IP PROTOCOLS RIP ........................................................................................................... 33-162
33.37 SHOW IP RIP .............................................................................................................................. 33-164
33.38 SHOW IP RIP DATABASE .............................................................................................................. 33-164
33.39 SHOW IP RIP INTERFACE ............................................................................................................. 33-165
33.40 SHOW IP RIP AGGREGATE ........................................................................................................... 33-166
33.41 TIMERS BASIC ............................................................................................................................ 33-166
33.42 VERSION .................................................................................................................................... 33-167
CHAPTER 34 COMMANDS FOR RIPNG .................................................................. 34-169
34.1 CLEAR IPV6 ROUTE ...................................................................................................................... 34-169
34.2 DEFAULT-INFORMATION ORIGINATE................................................................................................ 34-169
34.3 DEFAULT-METRIC ......................................................................................................................... 34-170
34.4 DISTANCE .................................................................................................................................... 34-171
34.5 DISTRIBUTE-LIST .......................................................................................................................... 34-171
34.6 DEBUG IPV6 RIP ........................................................................................................................... 34-172
34.7 DEBUG IPV6 RIP REDISTRIBUTE MESSAGE SEND ............................................................................. 34-173
34.8 DEBUG IPV6 RIP REDISTRIBUTE ROUTE REC EIVE ............................................................................ 34-173
34.9 IPV6 RIP AGGREGATE-ADDRESS .................................................................................................... 34-174
34.10 IPV6 RIP SPLIT-HORIZON ............................................................................................................. 34-174
34.11 IPV6 ROUTER RIP ....................................................................................................................... 34-175
34.12 NEIGHBOR ................................................................................................................................. 34-176
34.13 OFFSET-LIST .............................................................................................................................. 34-176
34.14 PASSIVE-INTERFACE ................................................................................................................... 34-177
34.15 REDISTRIBUTE ........................................................................................................................... 34-178
34.16 REDISTRIBUTE OSPF .................................................................................................................. 34-178
34.17 ROUTE ...................................................................................................................................... 34-179
34.18 ROUTER IPV6 RIP ....................................................................................................................... 34-179
34.19 SHOW DEBUGGING IPV6 RIP ........................................................................................................ 34-180
34.20 SHOW I P V6 RIP INTERFACE ......................................................................................................... 34-180
34.21 SHOW I P V6 RIP REDISTRIBUTE .................................................................................................... 34-181
34.22 SHOW I P V6 PROTOCOLS RIP ....................................................................................................... 34-182
34.23 SHOW I P V6 RIP .......................................................................................................................... 34-183
34.24 SHOW I P V6 RIP DATABASE .......................................................................................................... 34-183
34.25 SHOW I P V6 RIP AGGREGATE ....................................................................................................... 34-184
34.26 SHOW I P V6 RIP REDISTRIBUTE .................................................................................................... 34-185
34.27 TIMERS BASIC ............................................................................................................................ 34-185
CHAPTER 35 COMMANDS FOR OSPF .................................................................... 35-187
35.1 AREA AUTHENTICATION ................................................................................................................ 35-187
35.2 AREA DEFAULT-COST .................................................................................................................... 35-187
1-21
XGS3 Command Guide
35.3 AREA FILTER-LIST ........................................................................................................................ 35-188
35.4 AREA NSSA .................................................................................................................................. 35-189
35.5 AREA RANGE ............................................................................................................................... 35-190
35.6 AREA STUB .................................................................................................................................. 35-191
35.7 AREA VIRTUAL-LINK ..................................................................................................................... 35-191
35.8 AUTO-COST REFERENCE-BANDWIDTH............................................................................................ 35-193
35.9 COMPATIBL E RFC1583 ................................................................................................................. 35-193
35.10 CLEAR IP OSPF PROCESS ........................................................................................................... 35-194
35.11 DEBUG OSPF EVENTS ................................................................................................................. 35-194
35.12 DEBUG OSPF IFSM ...................................................................................................................... 35-195
35.13 DEBUG OSPF LSA ....................................................................................................................... 35-195
35.14 DEBUG OSPF NFSM .................................................................................................................... 35-195
35.15 DEBUG OSPF NSM ...................................................................................................................... 35-196
35.16 DEBUG OSPF PACKET ................................................................................................................. 35-196
35.17 DEBUG OSPF ROUTE .................................................................................................................. 35-197
35.18 DEBUG OSPF REDISTRIBUTE MESSAGE SEND ............................................................................... 35-197
35.19 DEBUG OSPF REDISTRIBUTE ROUTE RE CEIVE ............................................................................... 35-198
35.20 DEFAULT-INFORMATION ORIGINATE ............................................................................................. 35-198
35.21 DEFAULT-METRIC ....................................................................................................................... 35-199
35.22 DISTANCE .................................................................................................................................. 35-200
35.23 DISTRIBUTE-LIST ........................................................................................................................ 35-201
35.24 FILTER-POLICY ........................................................................................................................... 35-202
35.25 HOST AREA ................................................................................................................................ 35-202
35.26 IP OSPF AUTHENTICATION ........................................................................................................... 35-203
35.27 IP OSPF AUTHENTICATION-KEY .................................................................................................... 35-204
35.28 IP OSPF COST ............................................................................................................................ 35-204
35.29 IP OSP F DATABASE-FILTER .......................................................................................................... 35-205
35.30 IP OSPF DEAD -INTERVAL ............................................................................................................. 35-205
35.31 IP OSPF DISABLE ALL ................................................................................................................. 35-206
35.32 IP OSPF HELLO-INTERVAL ........................................................................................................... 35-207
35.33 IP OSPF MESSAGE-DIGEST-KEY ................................................................................................... 35-207
35.34 IP OSPF MTU .............................................................................................................................. 35-208
35.35 IP OSPF MTU-IGNORE ................................................................................................................. 35-209
35.36 IP OSPF NETWORK ..................................................................................................................... 35-209
35.37 IP OSPF P R I ORITY ....................................................................................................................... 35-210
35.38 IP OSPF RETRANSMIT-INTERVAL .................................................................................................. 35-211
35.39 IP OSPF TRANSMIT-DELAY ........................................................................................................... 35-211
35.40 KEY ........................................................................................................................................... 35-212
35.41 KEY CHAIN ................................................................................................................................. 35-213
1-22
XGS3 Command Guide
35.42 LOG-ADJACENCY-CHANGES DETAIL ............................................................................................ 35-213
35.43 MAX-CONCURRENT-DD ............................................................................................................... 35-214
35.44 NEIGHBOR ................................................................................................................................. 35-214
35.45 NETWORK AREA ......................................................................................................................... 35-215
35.46 OSPF ABR-TYPE ......................................................................................................................... 35-216
35.47 OSPF ROUTER-ID ........................................................................................................................ 35-217
35.48 OVERFLOW DATABASE ............................................................................................................... 35-217
35.49 OVERFLOW DATABASE EXTERNAL ............................................................................................... 35-218
35.50 PASSIVE-INTERFACE ................................................................................................................... 35-219
35.51 REDISTRIBUTE ........................................................................................................................... 35-219
35.52 REDISTRIBUTE OSPF .................................................................................................................. 35-220
35.53 ROUTER OSPF ............................................................................................................................ 35-221
35.54 SHOW IP OSPF ........................................................................................................................... 35-221
35.55 SHOW IP OSPF BORDER-ROUTERS ............................................................................................... 35-223
35.56 SHOW IP OSPF DATABASE ........................................................................................................... 35-223
35.57 SHOW IP OSPF INTERFACE .......................................................................................................... 35-225
35.58 SHOW IP OSPF NEIGHBOR ........................................................................................................... 35-226
35.59 SHOW IP OSPF REDISTRIBUTE ..................................................................................................... 35-227
35.60 SHOW IP OSPF ROUTE ................................................................................................................ 35-227
35.61 SHOW IP OSPF VIRTUAL-LINKS .................................................................................................... 35-228
35.62 SHOW IP ROUTE PROCESS-DETAIL ............................................................................................... 35-229
35.63 SHOW IP PROTOCOLS ................................................................................................................. 35-230
35.64 SUMMARY-ADDRESS................................................................................................................... 35-231
35.65 TIMERS SPF ............................................................................................................................... 35-231
CHAPTER 36 COMMANDS FOR OSPFV3 ............................................................... 36-233
36.1 AREA DEFAULT COST .................................................................................................................... 36-233
36.2 AREA RANGE ............................................................................................................................... 36-233
36.3 AREA STUB .................................................................................................................................. 36-234
36.4 AREA VIRTUAL-LINK ..................................................................................................................... 36-235
36.5 ABR-TYPE .................................................................................................................................... 36-236
36.6 DEFAULT-METRIC ......................................................................................................................... 36-236
36.7 DEBUG IPV6 OSPF EVENTS ............................................................................................................ 36-237
36.8 DEBUG IPV6 OSPF IFSM ................................................................................................................ 36-238
36.9 DEBUG IPV6 OSPF LSA ................................................................................................................. 36-238
36.10 DEBUG IPV6 OSPF N FSM ............................................................................................................. 36-238
36.11 DEBUG IPV6 OSPF NSM ............................................................................................................... 36-239
36.12 DEBUG IPV6 OSPF PACK ET ......................................................................................................... 36-239
36.13 DEBUG IPV6 OSPF REDISTRIBUTE MESSAGE SEND ........................................................................ 36-240
36.14 DEBUG IPV6 OSPF REDISTRIBUTE ROUTE RECEIVE ....................................................................... 36-240
1-23
XGS3 Command Guide
36.15 DEBUG IPV6 OSPF ROUTE ........................................................................................................... 36-240
36.16 IPV6 OSPF COST ........................................................................................................................ 36-241
36.17 IPV6 OSPF DEAD -INTERVAL ......................................................................................................... 36-241
36.18 IPV6 OSPF DISP LAY ROUTE S INGLE-LINE ...................................................................................... 36-242
36.19 IPV6 OSPF HEL LO-INTERVAL ....................................................................................................... 36-243
36.20 IPV6 OSPF PRIORITY ................................................................................................................... 36-244
36.21 IPV6 OSPF RETRANSMIT-INTERVAL .............................................................................................. 36-244
36.22 IPV6 OSPF TRANSMIT-DELAY ....................................................................................................... 36-245
36.23 IPV6 ROUTER OSPF .................................................................................................................... 36-246
36.24 MAX-CONCURRENT-DD ............................................................................................................... 36-247
36.25 PASSIVE-INTERFACE ................................................................................................................... 36-247
36.26 REDISTRIBUTE ........................................................................................................................... 36-248
36.27 REDISTRIBUTE OSPF .................................................................................................................. 36-249
36.28 ROUTER-ID ................................................................................................................................ 36-249
36.29 ROUTER IPV6 OSPF .................................................................................................................... 36-250
36.30 SHOW I P V6 OSPF ....................................................................................................................... 36-251
36.31 SHOW I P V6 OSPF DATABASE ....................................................................................................... 36-251
36.32 SHOW I P V6 OSPF INTERFACE ...................................................................................................... 36-253
36.33 SHOW I P V6 OSPF NEIGHBOR ....................................................................................................... 36-255
36.34 SHOW I P V6 OSPF ROUTE ............................................................................................................ 36-256
36.35 SHOW I P V6 OSPF REDISTRIBUTE ................................................................................................. 36-256
36.36 SHOW I P V6 OSPF TOPOLOGY ...................................................................................................... 36-257
36.37 SHOW I P V6 OSPF VIR TUAL-LINKS ................................................................................................ 36-258
36.38 SHOW I P V6 ROUTE PROCESS-DETAIL ........................................................................................... 36-258
36.39 TIMERS SPF ............................................................................................................................... 36-259
CHAPTER 37 COMMANDS FOR BGP AND MBGP4+ ............................................. 37-260
37.1 ADDRESS-FAMILY ......................................................................................................................... 37-260
37.2 AGGREGATE-ADDRESS ................................................................................................................. 37-261
37.3 BGP AGGREGATE-NEXTHOP-CHECK .............................................................................................. 37-262
37.4 BGP ALWAYS-COMPARE-MED ........................................................................................................ 37-262
37.5 BGP ASNOTATION ASDOT .............................................................................................................. 37-263
37.6 BGP BESTPATH AS-PATH IGNORE ................................................................................................... 37-263
37.7 BGP BESTPATH COMPARE-CONFED-ASPATH ................................................................................... 37-264
37.8 BGP BESTPATH COMPARE-ROUTERID ............................................................................................. 37-265
37.9 BGP BESTPATH MED ..................................................................................................................... 37-265
37.10 BGP CLIENT-TO-CLIENT REFLECTION ........................................................................................... 37-266
37.11 BGP CLUSTER-ID ........................................................................................................................ 37-267
37.12 BGP CONFEDERATION IDENTIFIER ................................................................................................ 37-267
37.13 BGP CONFEDERATION PEERS ...................................................................................................... 37-268
1-24
XGS3 Command Guide
37.14 BGP DAMPENING ........................................................................................................................ 37-269
37.15 BGP DEFAULT ............................................................................................................................ 37-269
37.16 BGP DETERMINISTIC-MED ........................................................................................................... 37-270
37.17 BGP ENFORCE-FIRST-AS ............................................................................................................. 37-271
37.18 BGP FAST-EXTERNAL-FAILOVER .................................................................................................. 37-271
37.19 BGP INBOUND-ROUTE-FILTER ...................................................................................................... 37-272
37.20 BGP INBOUND-MAX-ROUTE-NUM ................................................................................................. 37-272
37.21 BGP LOG-NEIGHBOR-CHANGES ................................................................................................... 37-273
37.22 BGP NETWORK IMPORT-CHECK ................................................................................................... 37-273
37.23 BGP RFC1771-PATH-SELECT ...................................................................................................... 37-274
37.24 BGP RFC1771-STRICT ................................................................................................................ 37-274
37.25 BGP ROUTER-ID ......................................................................................................................... 37-275
37.26 BGP SCAN-TIME ......................................................................................................................... 37-275
37.27 CLEAR IP BGP ............................................................................................................................ 37-276
37.28 CLEAR IP BGP DAMPENING .......................................................................................................... 37-277
37.29 CLEAR IP BGP FLAP-STATISTICS .................................................................................................. 37-277
37.30 DEBUG BGP ............................................................................................................................... 37-278
37.31 DEBUG BGP REDISTRIBUTE MESSAGE SEND ................................................................................. 37-278
37.32 DEBUG BGP REDISTRIBUTE ROUTE RECEIVE ................................................................................ 37-279
37.33 DEBUG IPV6 BGP REDISTRIBUTE MESSAGE SEND ......................................................................... 37-279
37.34 DEBUG IPV6 BGP REDISTRIBUTE ROUTE RECEIVE ......................................................................... 37-280
37.35 DISTANCE .................................................................................................................................. 37-280
37.36 DISTANCE BGP ........................................................................................................................... 37-281
37.37 EXIT-ADDRESS-FAMILY ............................................................................................................... 37-281
37.38 IMPORT MAP .............................................................................................................................. 37-282
37.39 IP AS-PATH ACCESS-LIST ............................................................................................................ 37-283
37.40 IP COMMUNITY-LIST .................................................................................................................... 37-284
37.41 IP EXTCOMMUNITY-LIST .............................................................................................................. 37-284
37.42 NEIGHBOR ACTIVATE .................................................................................................................. 37-285
37.43 NEIGHBOR ADVERTISEMENT-INTERVAL ........................................................................................ 37-286
37.44 NEIGHBOR ALLOWAS-IN .............................................................................................................. 37-286
37.45 NEIGHBOR AS-OVERRIDE ............................................................................................................ 37-287
37.46 NEIGHBOR ATTRIBUTE-UNCHANGED ............................................................................................ 37-288
37.47 NEIGHBOR CAPABILITY ............................................................................................................... 37-289
37.48 NEIGHBOR CAPABILITY ORF PREFIX-LIST ..................................................................................... 37-289
37.49 NEIGHBOR COLLIDE-ESTABLISHED .............................................................................................. 37-290
37.50 NEIGHBOR DEFAULT-ORIGINATE .................................................................................................. 37-291
37.51 NEIGHBOR DESCRIPTION ............................................................................................................ 37-292
37.52 NEIGHBOR DISTRIBUTE-LIST ....................................................................................................... 37-292
1-25
XGS3 Command Guide
37.53 NEIGHBOR DONT-CAPABILITY-NEGOTIATE .................................................................................... 37-293
37.54 NEIGHBOR EBGP-MULTIHOP ........................................................................................................ 37-294
37.55 NEIGHBOR ENFORCE-MULTIHOP .................................................................................................. 37-295
37.56 NEIGHBOR FILTER-LIST ............................................................................................................... 37-295
37.57 NEIGHBOR INTERFACE ................................................................................................................ 37-296
37.58 NEIGHBOR MAXIMUM-PREFIX ...................................................................................................... 37-297
37.59 NEIGHBOR NEXT-HOP-SELF......................................................................................................... 37-298
37.60 NEIGHBOR OVERRIDE-CAPABILITY ............................................................................................... 37-298
37.61 NEIGHBOR PASSIVE .................................................................................................................... 37-299
37.62 NEIGHBOR PEER-GROUP (CREATING) .......................................................................................... 37-300
37.63 NEIGHBOR PEER-GROUP (CONFIGURING GROUP MEMBERS) ......................................................... 37-300
37.64 NEIGHBOR PORT ........................................................................................................................ 37-301
37.65 NEIGHBOR PREFIX-LIST .............................................................................................................. 37-302
37.66 NEIGHBOR REMOTE-AS ............................................................................................................... 37-302
37.67 NEIGHBOR REMOVE-PRIVATE-AS ................................................................................................ 37-303
37.68 NEIGHBOR ROUTE-MAP .............................................................................................................. 37-304
37.69 NEIGHBOR ROUTE-REFLECTOR-CLIENT........................................................................................ 37-305
37.70 NEIGHBOR ROUTE-SERVER-CLIENT ............................................................................................. 37-305
37.71 NEIGHBOR SEND-COMMUNITY ..................................................................................................... 37-306
37.72 NEIGHBOR SHUTDOWN ............................................................................................................... 37-307
37.73 NEIGHBOR SOFT-RECONFIGURATION INBOUND ............................................................................. 37-307
37.74 NEIGHBOR SOO .......................................................................................................................... 37-308
37.75 NEIGHBOR STRICT-CAPABILITY-MATCH ........................................................................................ 37-309
37.76 NEIGHBOR TIMERS ..................................................................................................................... 37-310
37.77 NEIGHBOR TIMERS CONNECT ...................................................................................................... 37-310
37.78 NEIGHBOR UNSUPPRESS-MAP ..................................................................................................... 37-311
37.79 NEIGHBOR UPDATE-SOURCE ....................................................................................................... 37-312
37.80 NEIGHBOR VERSION 4 ................................................................................................................ 37-312
37.81 NEIGHBOR WEIGHT ..................................................................................................................... 37-313
37.82 NETWORK (BGP) ....................................................................................................................... 37-314
37.83 REDISTRIBUTE (BGP) ................................................................................................................ 37-314
37.84 REDISTRIBUTE OSPF .................................................................................................................. 37-315
37.85 REDISTRIBUTE OSPF (MBGP4+) ................................................................................................ 37-316
37.86 ROUTER BGP ............................................................................................................................. 37-316
37.87 SET VPNV4 NEXT-HOP ................................................................................................................ 37-317
37.88 SHOW IP BGP ............................................................................................................................. 37-318
37.89 SHOW IP BGP ATTRIBU T E-INFO .................................................................................................... 37-319
37.90 SHOW IP BGP COMMUNITY .......................................................................................................... 37-319
37.91 SHOW IP BGP COMMUNITY-INFO .................................................................................................. 37-320
1-26
XGS3 Command Guide
37.92 SHOW IP BGP COMMUNITY-LIST ................................................................................................... 37-321
37.93 SHOW IP BGP DAMPENING........................................................................................................... 37-321
37.94 SHOW IP BG P FILTER-LIST ........................................................................................................... 37-323
37.95 SHOW IP BGP INCONSISTENT-AS .................................................................................................. 37-324
37.96 SHOW IP BGP NEIGHBORS ........................................................................................................... 37-324
37.97 SHOW IP BGP PATHS ................................................................................................................... 37-325
37.98 SHOW IP BGP PREFIX-LIST .......................................................................................................... 37-326
37.99 SHOW IP BGP QUOTE-REGEXP ..................................................................................................... 37-327
37.100 SHOW I P BGP REGEXP .............................................................................................................. 37-328
37.101 SHOW I P BGP ROUTE-MAP ........................................................................................................ 37-328
37.102 SHOW I P BGP SCAN .................................................................................................................. 37-329
37.103 SHOW IP BG P SUMMARY ........................................................................................................... 37-329
37.104 SHOW IP BGP VIEW ................................................................................................................... 37-331
37.105 SHOW IP BGP VIEW NEIGHBORS ................................................................................................ 37-331
37.106 SHOW IP BGP VRF .................................................................................................................... 37-332
37.107 SHOW IP BGP VPNV4 ................................................................................................................ 37-334
37.108 SHOW IPV6 BGP REDISTRIBUTE ................................................................................................. 37-334
37.109 TIMERS BGP ............................................................................................................................. 37-335
CHAPTER 38 COMMANDS FOR BLACK HOLE ROUTING .........................................38-1
38.1 IP ROUTE NULL0 .............................................................................................................................. 38-1
38.2 IPV6 ROUTE NULL0 .......................................................................................................................... 38-1
CHAPTER 39 COMMANDS FOR GRE TUNNEL CONFIGUR ATION ...........................39-2
39.1 DEBUG GRE ..................................................................................................................................... 39-2
39.2 IP ADDRESS ..................................................................................................................................... 39-3
39.3 IP ROUTE ......................................................................................................................................... 39-3
39.4 IPV6 ADDRESS ................................................................................................................................. 39-4
39.5 IPV6 ROUTE ..................................................................................................................................... 39-4
39.6 LOOPBACK-GROUP (GLOBAL) .......................................................................................................... 39-5
39.7 LOOPBACK-GROUP (PORT) .............................................................................................................. 39-5
39.8 LOOPBACK-GROUP (TUNNEL INTERFACE) ......................................................................................... 39-6
39.9 SHOW GRE TUNNEL .......................................................................................................................... 39-7
39.10 SHOW INTERFACE TUNNEL .............................................................................................................. 39-7
39.11 TUNNEL DESTINATION ..................................................................................................................... 39-8
39.12 TUNNEL MODE GRE IP ..................................................................................................................... 39-8
39.13 TUNNEL MODE GRE IPV6 ................................................................................................................. 39-9
39.14 TUNNEL SOURCE ............................................................................................................................ 39-9
CHAPTER 40 COMMANDS FOR ECMP ..................................................................... 40-11
1-27
XGS3 Command Guide
40.1 LOAD-BALANCE ............................................................................................................................. 40-11
40.2 MAXIMUM-PATHS ............................................................................................................................ 40-11
CHAPTER 41 COMMANDS FOR BFD ..........................................................................41-1
41.1 BFD AUTHENTICATION KEY ................................................................................................................ 41-1
41.2 BFD AUTHENTICATION KEY MD5 ........................................................................................................ 41-1
41.3 BFD AUTHENTICATION KEY TEXT ....................................................................................................... 41-2
41.4 BFD ECHO ....................................................................................................................................... 41-3
41.5 BFD ECHO-SOURCE-IP ...................................................................................................................... 41-3
41.6 BFD ECHO-SOURCE-IPV6 .................................................................................................................. 41-4
41.7 BFD ENABLE .................................................................................................................................... 41-4
41.8 BFD INTERVAL .................................................................................................................................. 41-5
41.9 BFD MIN-ECHO-RECV-INTERVAL ........................................................................................................ 41-6
41.10 BFD MODE ..................................................................................................................................... 41-7
41.11 DEBUG BFD .................................................................................................................................... 41-7
41.12 IP OSPF BFD ENABLE ...................................................................................................................... 41-8
41.13 IP ROUTE BFD ................................................................................................................................ 41-8
41.14 IPV6 OSPF BFD ENABLE .................................................................................................................. 41-9
41.15 IPV6 OSPF BFD ENABLE INSTANCE-ID ............................................................................................ 41-10
41.16 IPV6 RIP BFD ENABLE ................................................................................................................... 41-10
41.17 IPV6 ROUTE BFD .......................................................................................................................... 41-11
41.18 NEIGHBOR ................................................................................................................................... 41-11
41.19 RIP BFD ENABLE .......................................................................................................................... 41-12
41.20 SHOW BFD NEIGHBOR .................................................................................................................. 41-12
CHAPTER 42 COMMANDS FOR BGP GR ...................................................................42-1
42.1 BGP GRACEFUL-RESTART ................................................................................................................. 42-1
42.2 BGP GRACEFUL-RESTART RESTART-TIME ........................................................................................... 42-1
42.3 BGP GRACEFUL-RESTART STALE-PATH-TIME ...................................................................................... 42-2
42.4 BGP SELECTIO N-DEFERRAL-TIME ...................................................................................................... 42-2
42.5 NEIGHBOR CAPABILITY GRACEFUL-RESTART ..................................................................................... 42-3
42.6 NEIGHBOR RESTART-TIME ................................................................................................................. 42-3
CHAPTER 43 COMMANDS FOR OSPF GR .................................................................43-1
43.1 CAPABIL ITY RESTART GRACEFUL ...................................................................................................... 43-1
43.2 DEBUG OSPF EVENTS GR .................................................................................................................. 43-1
43.3 OSPF GRACEFUL-RESTART GRACE-PERIOD........................................................................................ 43-2
43.4 OSPF GRACEFUL-RESTART HELPER MAX-GRACE-PERIOD ................................................................... 43-2
43.5 OSPF GRACEFUL-RESTART HELPER NEVER ........................................................................................ 43-3
43.6 SHOW IP OSPF ................................................................................................................................. 43-3
1-28
XGS3 Command Guide
43.7 SHOW IP OSPF GRACEFUL-RESTART .................................................................................................. 43-4
CHAPTER 44 IPV4 MULTICAST PROTOCOL ..............................................................44-6
44.1 PUBLIC COMMANDS FOR MULTICAST ................................................................................................ 44-6
44.1.1 show ip mroute .................................................................................................................................... 44-6
44.2 COMMANDS FOR PIM-DM ................................................................................................................ 44-7
44.2.1 debug pim timer sat ............................................................................................................................ 44-7
44.2.2 debug pim timer srt ............................................................................................................................. 44-7
44.2.3 ip mroute ............................................................................................................................................. 44-8
44.2.4 ip pim bsr-border ................................................................................................................................. 44-9
44.2.5 ip pim dense-mode ............................................................................................................................. 44-9
44.2.6 ip pim dr-priority ................................................................................................................................ 44-10
44.2.7 ip pim exclude-genid ......................................................................................................................... 44-10
44.2.8 ip pim hello-holdtime ......................................................................................................................... 44-11
44.2.9 ip pim hello-interval ........................................................................................................................... 44-12
44.2.10 ip pim multica st -routing ................................................................................................................... 44-12
44.2.11 ip pim neighbor-filter ........................................................................................................................ 44-13
44.2.12 ip pim scope-border ........................................................................................................................ 44-14
44.2.13 ip pim state-refresh origination-interval ........................................................................................... 44-14
44.2.14 show ip pim interface ...................................................................................................................... 44-15
44.2.15 show ip pim mroute dense-mode .................................................................................................... 44-15
44.2.16 show ip pim neighbor ...................................................................................................................... 44-17
44.2.17 show ip pim nexthop ....................................................................................................................... 44-18
44.3 COMMANDS FOR PIM-SM .............................................................................................................. 44-19
44.3.1 clear ip pim bsr rp-set........................................................................................................................ 44-19
44.3.2 debug pim event ............................................................................................................................... 44-19
44.3.3 debug pim mfc .................................................................................................................................. 44-20
44.3.4 debug pim mib .................................................................................................................................. 44-20
44.3.5 debug pim nexthop ........................................................................................................................... 44-21
44.3.6 debug pim nsm ................................................................................................................................. 44-21
44.3.7 debug pim packet .............................................................................................................................. 44-22
44.3.8 debug pim state ................................................................................................................................ 44-22
44.3.9 debug pim timer ................................................................................................................................ 44-23
44.3.10 ip mroute ......................................................................................................................................... 44-24
44.3.11 ip multicast unresolved-ca che agi ng-time ....................................................................................... 44-25
44.3.12 ip pim accept-register ...................................................................................................................... 44-25
44.3.13 ip pim bsr-border ............................................................................................................................. 44-26
44.3.14 ip pim bsr-candidate ........................................................................................................................ 44-26
44.3.15 ip pim cisco -register-checksum ....................................................................................................... 44-27
44.3.16 ip pim dr-priority .............................................................................................................................. 44-28
1-29
XGS3 Command Guide
44.3.17 ip pim exclude-genid ....................................................................................................................... 44-28
44.3.18 ip pim hello-holdtime ....................................................................................................................... 44-29
44.3.19 ip pim hello-interval ......................................................................................................................... 44-30
44.3.20 ip pim ignore-rp-set-priority ............................................................................................................. 44-30
44.3.21 ip pim jp-timer ................................................................................................................................. 44-31
44.3.22 ip pim multica st -routing ................................................................................................................... 44-32
44.3.23 ip pim neighbor-filter ....................................................................................................................... 44-32
44.3.24 ip pim register-rate-limit................................................................................................................... 44-33
44.3.25 ip pim register-rp-reachability .......................................................................................................... 44-33
44.3.26 ip pim register-source...................................................................................................................... 44-34
44.3.27 ip pim register-suppression ............................................................................................................. 44-35
44.3.28 ip pim rp-address ............................................................................................................................ 44-35
44.3.29 ip pim rp-candidate ......................................................................................................................... 44-36
44.3.30 ip pim rp-register-kat ....................................................................................................................... 44-37
44.3.31 ip pim scope-border ........................................................................................................................ 44-37
44.3.32 ip pim sparse-mode......................................................................................................................... 44-38
44.3.33 show ip pim bsr-router..................................................................................................................... 44-39
44.3.34 show ip pim interface ...................................................................................................................... 44-39
44.3.35 show ip pim mroute sparse-mode ................................................................................................... 44-40
44.3.36 show ip pim neighbor ...................................................................................................................... 44-41
44.3.37 show ip pim nexthop ....................................................................................................................... 44-42
44.3.38 show ip pim rp-hash ........................................................................................................................ 44-43
44.3.39 show ip pim rp mapping .................................................................................................................. 44-44
44.4 COMMANDS FOR MSDP CONFIGURATION ....................................................................................... 44-44
44.4.1 cache-sa-holdtime ............................................................................................................................. 44-44
44.4.2 cache-sa-maximum ........................................................................................................................... 44-45
44.4.3 cache-sa-state .................................................................................................................................. 44-46
44.4.4 clear msdp peer ................................................................................................................................ 44-46
44.4.5 clear msdp sa-cache ......................................................................................................................... 44-47
44.4.6 clear msdp stat ist ic s .......................................................................................................................... 44-47
44.4.7 connect-source ................................................................................................................................. 44-48
44.4.8 debug msdp all .................................................................................................................................. 44-48
44.4.9 debug msdp event s ........................................................................................................................... 44-49
44.4.10 debug msdp filter ............................................................................................................................. 44-49
44.4.11 debug msdp fsm .............................................................................................................................. 44-50
44.4.12 debug msdp keepal iv e .................................................................................................................... 44-50
44.4.13 debug msdp nsm............................................................................................................................. 44-51
44.4.14 debug msdp packet ......................................................................................................................... 44-51
44.4.15 debug msdp peer ............................................................................................................................ 44-52
1-30
XGS3 Command Guide
44.4.16 debug msdp timer ........................................................................................................................... 44-52
44.4.17 default-rpf-peer ............................................................................................................................... 44-53
44.4.18 description ....................................................................................................................................... 44-53
44.4.19 exit-peer-mode ................................................................................................................................ 44-54
44.4.20 mesh-group ..................................................................................................................................... 44-54
44.4.21 originating-rp ................................................................................................................................... 44-55
44.4.22 peer ................................................................................................................................................. 44-56
44.4.23 redistribute ...................................................................................................................................... 44-56
44.4.24 remote-as ........................................................................................................................................ 44-57
44.4.25 router msdp ..................................................................................................................................... 44-58
44.4.26 sa-filter ............................................................................................................................................ 44-58
44.4.27 sa-request ....................................................................................................................................... 44-59
44.4.28 sa-request-filter ............................................................................................................................... 44-60
44.4.29 show msdp global ........................................................................................................................... 44-60
44.4.30 show msdp local-sa-cache .............................................................................................................. 44-61
44.4.31 show msdp peer .............................................................................................................................. 44-62
44.4.32 show msdp sa-cache ...................................................................................................................... 44-63
44.4.33 show msdp sa-cache summary ....................................................................................................... 44-65
44.4.34 show msdp statistics ....................................................................................................................... 44-66
44.4.35 show msdp summary ...................................................................................................................... 44-67
44.4.36 shutdown ......................................................................................................................................... 44-67
44.4.37 ttl-threshold ..................................................................................................................................... 44-68
44.5 COMMANDS FOR ANYCAST RP V4 ............................................................................................... 44-69
44.5.1 debug pim anycast-rp ....................................................................................................................... 44-69
44.5.2 ip pim anycast-rp ............................................................................................................................... 44-69
44.5.3 ip pim anycast-rp ............................................................................................................................... 44-70
44.5.4 ip pim anycast-rp self-rp-address ...................................................................................................... 44-71
44.5.5 ip pim rp-candidate ........................................................................................................................... 44-71
44.5.6 show debugging pim ......................................................................................................................... 44-72
44.5.7 show ip pim anycast-rp first-hop ....................................................................................................... 44-73
44.5.8 show ip pim anycast-rp non-first-hop ................................................................................................ 44-73
44.5.9 show ip pim anycast-rp status ........................................................................................................... 44-74
44.6 COMMANDS FOR PIM-SSM ........................................................................................................... 44-75
44.6.1 ip multicast ssm ................................................................................................................................ 44-75
44.7 COMMANDS FOR DVMRP .............................................................................................................. 44-76
44.7.1 debug dvmrp ..................................................................................................................................... 44-76
44.7.2 ip dvmrp enable ................................................................................................................................ 44-77
44.7.3 ip dvmrp metric ................................................................................................................................. 44-77
44.7.4 ip dvmrp multicast-routing ................................................................................................................. 44-78
1-31
XGS3 Command Guide
44.7.5 ip dvmrp output-report-delay ............................................................................................................. 44-78
44.7.6 ip dvmrp reject-non-pruners .............................................................................................................. 44-79
44.7.7 ip dvmrp tunnel ................................................................................................................................. 44-80
44.7.8 show ip dvmrp ................................................................................................................................... 44-80
44.7.9 show ip dvmrp interface .................................................................................................................... 44-81
44.7.10 show ip dvmrp neighbor .................................................................................................................. 44-82
44.7.11 show ip dvmrp prune ....................................................................................................................... 44-82
44.7.12 show ip dvmrp route ........................................................................................................................ 44-83
44.8 COMMANDS FOR DCSCM .............................................................................................................. 44-84
44.8.1 access-list (Multicast Destination Control) ........................................................................................ 44-84
44.8.2 access-list (Multicast Source Control) ............................................................................................... 44-85
44.8.3 ip multicast destination-control access-group ................................................................................... 44-86
44.8.4 ip multicast destination-control access-group (sip) ........................................................................... 44-87
44.8.5 ip multicast destination-control access-group (vmac) ....................................................................... 44-88
44.8.6 ip multicast policy .............................................................................................................................. 44-88
44.8.7 ip multicast sou rc e -control ................................................................................................................ 44-89
44.8.8 ip multicast sou rc e -control access-group .......................................................................................... 44-89
44.8.9 multicast destination-control .............................................................................................................. 44-90
44.8.10 show ip multicast destination-control............................................................................................... 44-91
44.8.11 show ip multicast destination-control access-list ............................................................................. 44-91
44.8.12 show ip multicast policy................................................................................................................... 44-92
44.8.13 show ip multicast source-control ..................................................................................................... 44-92
44.8.14 show ip multicast source-control acc ess-list ................................................................................... 44-93
44.9 COMMANDS FOR IGMP .................................................................................................................. 44-94
44.9.1 clear ip igmp group ........................................................................................................................... 44-94
44.9.2 debug igmp event ............................................................................................................................. 44-94
44.9.3 debug igmp packet ............................................................................................................................ 44-95
44.9.4 ip igmp access-group ........................................................................................................................ 44-95
44.9.5 ip igmp immediate-leave ................................................................................................................... 44-96
44.9.6 ip igmp join-group ............................................................................................................................. 44-97
44.9.7 ip igmp last-member-query-interval ................................................................................................... 44-97
44.9.8 ip igmp limit ....................................................................................................................................... 44-98
44.9.9 ip igmp query-interval ........................................................................................................................ 44-98
44.9.10 ip igmp query-max-response-time ................................................................................................... 44-99
44.9.11 ip igmp query-timeout .................................................................................................................... 44-100
44.9.12 ip igmp robust-variable .................................................................................................................. 44-100
44.9.13 ip igmp static-group ....................................................................................................................... 44-101
44.9.14 ip igmp version .............................................................................................................................. 44-102
44.9.15 show ip igmp groups ..................................................................................................................... 44-102
1-32
XGS3 Command Guide
44.9.16 show ip igmp interfac e .................................................................................................................. 44-104
44.10 COMMANDS FOR IGMP SNOOPING ............................................................................................. 44-105
44.10.1 clear ip igmp snooping vlan ........................................................................................................... 44-105
44.10.2 clear ip igmp snooping vlan <1-4094> mrouter-port ...................................................................... 44-105
44.10.3 debug igmp snooping all/packet/event/timer/mf c .......................................................................... 44-106
44.10.4 ip igmp snooping ........................................................................................................................... 44-106
44.10.5 ip igmp snooping proxy ................................................................................................................. 44-107
44.10.6 ip igmp snooping vlan ................................................................................................................... 44-107
44.10.7 ip igmp snooping vlan immedi ate-leave ........................................................................................ 44-108
44.10.8 ip igmp snooping vlan l2-general-querier ...................................................................................... 44-108
44.10.9 ip igmp snooping vlan l2-general-querier-source .......................................................................... 44-109
44.10.10 ip igmp snooping vlan l2-general-querier-version ....................................................................... 44-110
44.10.11 ip igmp snooping vlan limit .......................................................................................................... 44-110
44.10.12 ip igmp snooping vlan mrouter-port interface ............................................................................... 44-111
44.10.13 ip igmp snooping vlan mrouter-port learnpim .............................................................................. 44-112
44.10.14 ip igmp snooping vlan mrpt ......................................................................................................... 44-112
44.10.15 ip igmp snooping vlan query-interval ........................................................................................... 44-113
44.10.16 ip igmp snooping vlan query-mrsp .............................................................................................. 44-113
44.10.17 ip igmp snooping vlan query-robustness ..................................................................................... 44-114
44.10.18 ip igmp snooping vlan report source-address ............................................................................. 44-115
44.10.19 ip igmp snooping vlan specific-query-mrsp ................................................................................. 44-115
44.10.20 ip igmp snooping vlan static-group .............................................................................................. 44-116
44.10.21 ip igmp snooping vlan suppression-query-time ........................................................................... 44-117
44.10.22 show ip igmp snooping ................................................................................................................ 44-117
44.11 COMMANDS FOR IGMP PROXY................................................................................................... 44-119
44.11.1 clear ip igmp proxy agggroup ........................................................................................................ 44-119
44.11.2 debug igmp proxy all ..................................................................................................................... 44-119
44.11.3 debug igmp proxy event ................................................................................................................ 44-120
44.11.4 debug igmp proxy mfc ................................................................................................................... 44-120
44.11.5 debug igmp proxy packet .............................................................................................................. 44-121
44.11.6 debug igmp proxy timer ................................................................................................................. 44-121
44.11.7 ip igmp proxy ................................................................................................................................. 44-122
44.11.8 ip igmp proxy aggregate ................................................................................................................ 44-122
44.11.9 ip igmp proxy downstream ............................................................................................................ 44-123
44.11.10 ip igmp proxy limit ........................................................................................................................ 44-123
44.11.11 ip igmp proxy multicast-source .................................................................................................... 44-124
44.11.12 ip igmp proxy unsolicited-report interval ...................................................................................... 44-124
44.11.13 ip igmp proxy unsolicited-report robustness ................................................................................ 44-125
44.11.14 ip igmp proxy upstream ............................................................................................................... 44-125
1-33
XGS3 Command Guide
44.11.15 ip multicas t ssm ........................................................................................................................... 44-126
44.11.16 ip pim bsr-border ......................................................................................................................... 44-127
44.11.17 show debugging igmp proxy ........................................................................................................ 44-127
44.11.18 show ip igmp proxy ...................................................................................................................... 44-128
44.11.19 show ip igmp proxy mroute ......................................................................................................... 44-129
44.11.20 show ip igmp proxy upstream groups .......................................................................................... 44-130
CHAPTER 45 IPV6 MULTICAST PROTOCOL ..............................................................45-1
45.1 PUBLIC COMMANDS FOR MULTICAST ................................................................................................ 45-1
45.1.1 show ipv6 mroute ................................................................................................................................ 45-1
45.2 COMMANDS FOR PIM-DM6 .............................................................................................................. 45-2
45.2.1 debug ipv6 pim timer sat ..................................................................................................................... 45-2
45.2.2 debug ipv6 pim timer srt ...................................................................................................................... 45-2
45.2.3 ipv6 mroute ......................................................................................................................................... 45-3
45.2.4 ipv6 pim bsr-border ............................................................................................................................. 45-4
45.2.5 ipv6 pim dense-mode .......................................................................................................................... 45-4
45.2.6 ipv6 pim dr-priority .............................................................................................................................. 45-5
45.2.7 ipv6 pim exclude-genid ....................................................................................................................... 45-5
45.2.8 ipv6 pim hello-holdtime ....................................................................................................................... 45-6
45.2.9 ipv6 pim hello-interval ......................................................................................................................... 45-7
45.2.10 ipv6 pim multicast-routing ................................................................................................................. 45-7
45.2.11 ipv6 pim neighbor-filter ...................................................................................................................... 45-8
45.2.12 ipv6 pim scope-border....................................................................................................................... 45-9
45.2.13 ipv6 pim state-refresh origination-interval ......................................................................................... 45-9
45.2.14 show ipv6 pim interface................................................................................................................... 45-10
45.2.15 show ipv6 pim mroute dense-mode ................................................................................................ 45-11
45.2.16 show ipv6 pim neighbor .................................................................................................................. 45-12
45.2.17 show ipv6 pim nexthop.................................................................................................................... 45-13
45.3 COMMANDS FOR PIM-SM6 ............................................................................................................ 45-14
45.3.1 clear ipv6 pim bsr rp-set .................................................................................................................... 45-14
45.3.2 debug ipv6 pim events ...................................................................................................................... 45-14
45.3.3 debug ipv6 pim mfc ........................................................................................................................... 45-15
45.3.4 debug ipv6 pim mib ........................................................................................................................... 45-15
45.3.5 debug ipv6 pim nexthop .................................................................................................................... 45-16
45.3.6 debug ipv6 pim nsm .......................................................................................................................... 45-16
45.3.7 debug ipv6 pim packet ...................................................................................................................... 45-17
45.3.8 debug ipv6 pim state ......................................................................................................................... 45-17
45.3.9 debug ipv6 pim timer ......................................................................................................................... 45-18
45.3.10 ipv6 mroute ..................................................................................................................................... 45-19
45.3.11 ipv6 multicast unresolv ed-cache aging-time .................................................................................... 45-20
1-34
XGS3 Command Guide
45.3.12 ipv6 pim accept-register .................................................................................................................. 45-20
45.3.13 ipv6 pim bsr-border ......................................................................................................................... 45-21
45.3.14 ipv6 pim bsr-candidate .................................................................................................................... 45-21
45.3.15 ipv6 pim cisco-register-checksum ................................................................................................... 45-22
45.3.16 ipv6 pim dr-priority .......................................................................................................................... 45-23
45.3.17 ipv6 pim exclude-genid ................................................................................................................... 45-23
45.3.18 ipv6 pim hello-holdtime ................................................................................................................... 45-24
45.3.19 ipv6 pim hello-interval ..................................................................................................................... 45-25
45.3.20 ipv6 pim ignore-rp-set-priority ......................................................................................................... 45-26
45.3.21 ipv6 pim jp-timer .............................................................................................................................. 45-26
45.3.22 ipv6 pim multicast-routing ............................................................................................................... 45-27
45.3.23 ipv6 pim neighbor-filter .................................................................................................................... 45-27
45.3.24 ipv6 pim register-rate-limit ............................................................................................................... 45-28
45.3.25 ipv6 pim register-rp-reachability ...................................................................................................... 45-28
45.3.26 ipv6 pim register-source .................................................................................................................. 45-29
45.3.27 ipv6 pim register-suppression ......................................................................................................... 45-30
45.3.28 ipv6 pim rp-address ........................................................................................................................ 45-30
45.3.29 ipv6 pim rp-candidate ...................................................................................................................... 45-31
45.3.30 ipv6 pim rp-register-kat ................................................................................................................... 45-32
45.3.31 ipv6 pim scope-border..................................................................................................................... 45-32
45.3.32 ipv6 pim sparse-mode ..................................................................................................................... 45-33
45.3.33 show ipv6 pim bsr-router ................................................................................................................. 45-33
45.3.34 show ipv6 pim interface................................................................................................................... 45-34
45.3.35 show ipv6 pim mroute sparse-mode ............................................................................................... 45-35
45.3.36 show ipv6 pim neighbor .................................................................................................................. 45-37
45.3.37 show ipv6 pim nexthop.................................................................................................................... 45-37
45.3.38 show ipv6 pim rp-hash .................................................................................................................... 45-38
45.3.39 show ipv6 pim rp mapping .............................................................................................................. 45-39
45.4 COMMANDS FOR ANYCAST RP V6 ............................................................................................... 45-39
45.4.1 debug ipv6 pim anycast-rp ................................................................................................................ 45-39
45.4.2 ipv6 pim anycast-rp ........................................................................................................................... 45-40
45.4.3 ipv6 pim anycast-rp ........................................................................................................................... 45-40
45.4.4 ipv6 pim anycast-rp self-rp-address .................................................................................................. 45-41
45.4.5 ipv6 pim rp-candidate ........................................................................................................................ 45-42
45.4.6 show debugging ipv6 pim .................................................................................................................. 45-43
45.4.7 show ipv6 pim anycast-rp first-hop .................................................................................................... 45-43
45.4.8 show ipv6 pim anycast-rp non-first-hop ............................................................................................ 45-44
45.4.9 show ipv6 pim anycast-rp status ....................................................................................................... 45-45
45.5 COMMANDS FOR PIM-SSM6 ......................................................................................................... 45-46
1-35
XGS3 Command Guide
45.5.1 ipv6 pim ssm ..................................................................................................................................... 45-46
45.6 COMMANDS FOR IPV6 DCSCM...................................................................................................... 45-47
45.6.1 ipv6 access-list(ipv6 multicast source control) .................................................................................. 45-47
45.6.2 ipv6 access-list(multicast destination control) ................................................................................... 45-48
45.6.3 ipv6 multicast destinati on-control access-group ................................................................................ 45-48
45.6.4 ipv6 multicast destinati on-control access-group (sip) ........................................................................ 45-49
45.6.5 ipv6 multicast destinati on-control access-group (vmac) .................................................................... 45-50
45.6.6 ipv6 multicast policy .......................................................................................................................... 45-51
45.6.7 ipv6 multicast source-control ............................................................................................................. 45-51
45.6.8 ipv6 multicast source-control access-group ...................................................................................... 45-52
45.6.9 multicast destination-control .............................................................................................................. 45-52
45.6.10 show ipv6 multicast destination-control ........................................................................................... 45-53
45.6.11 show ipv6 multicast destination-control access-list ......................................................................... 45-54
45.6.12 show ipv6 multicast policy ............................................................................................................... 45-54
45.6.13 show ipv6 multicast source-control ................................................................................................. 45-55
45.6.14 show ipv6 multicast source-control access-list ................................................................................ 45-55
45.7 COMMANDS FOR MLD ................................................................................................................... 45-56
45.7.1 clear ipv6 mld group .......................................................................................................................... 45-56
45.7.2 debug ipv6 mld events ...................................................................................................................... 45-57
45.7.3 debug ipv6 mld packet ...................................................................................................................... 45-57
45.7.4 ipv6 mld access-group ...................................................................................................................... 45-58
45.7.5 ipv6 mld immediate-leave ................................................................................................................. 45-58
45.7.6 ipv6 mld join-group ............................................................................................................................ 45-59
45.7.7 ipv6 mld join-group mode source ...................................................................................................... 45-60
45.7.8 ipv6 mld last-member-query-interval ................................................................................................. 45-60
45.7.9 ipv6 mld limit ..................................................................................................................................... 45-61
45.7.10 ipv6 mld query-interval .................................................................................................................... 45-62
45.7.11 ipv6 mld query-max-response-time ................................................................................................. 45-62
45.7.12 ipv6 mld query-timeout .................................................................................................................... 45-63
45.7.13 ipv6 mld static-group ....................................................................................................................... 45-64
45.7.14 ipv6 mld version .............................................................................................................................. 45-64
45.7.15 show ipv6 mld groups ..................................................................................................................... 45-65
45.7.16 show ipv6 mld interface................................................................................................................... 45-66
45.7.17 show ipv6 mld join-group ................................................................................................................ 45-66
45.8 COMMANDS FOR MLD SNOOPING CONFIGURATION ......................................................................... 45-67
45.8.1 clear ipv6 mld snooping vlan ............................................................................................................. 45-67
45.8.2 clear ipv6 mld snooping vlan <1-4094> mrouter-port ........................................................................ 45-68
45.8.3 debug mld snooping all/pac ket/event/timer/mfc ................................................................................ 45-68
45.8.4 ipv6 mld snooping ............................................................................................................................. 45-69
1-36
XGS3 Command Guide
45.8.5 ipv6 mld snooping vlan...................................................................................................................... 45-69
45.8.6 ipv6 mld snooping vlan immediate-leave .......................................................................................... 45-70
45.8.7 ipv6 mld snooping vlan l2-general-querier ........................................................................................ 45-71
45.8.8 ipv6 mld snooping vlan limit .............................................................................................................. 45-71
45.8.9 ipv6 mld snooping vlan mrouter -port interface .................................................................................. 45-72
45.8.10 ipv6 mld snooping vlan mrouter-port learnpim6 .............................................................................. 45-73
45.8.11 ipv6 mld snooping vlan mrpt ............................................................................................................ 45-73
45.8.12 ipv6 mld snooping vlan query-interval ............................................................................................. 45-74
45.8.13 ipv6 mld snooping vlan query-mrsp ................................................................................................ 45-74
45.8.14 ipv6 mld snooping vlan query-robustness ....................................................................................... 45-75
45.8.15 ipv6 mld snooping vlan static-group ................................................................................................ 45-75
45.8.16 ipv6 mld snooping vlan suppression-query-time ............................................................................. 45-76
45.8.17 show ipv6 mld snooping .................................................................................................................. 45-77
CHAPTER 46 COMMANDS FOR MULTICAST VLAN ..................................................46-1
46.1 MULTICAST-VLAN ............................................................................................................................. 46-1
46.2 MULTICAST-VLAN ASSOCIATION......................................................................................................... 46-1
CHAPTER 47 COMMANDS FOR ACL ..........................................................................47-2
47.1 ABSOLUTE-PERIODIC/PERIODIC ......................................................................................................... 47-2
47.2 ABSOLUTE STAR T............................................................................................................................. 47-3
47.3 ACCESS-LIST (IP EXTEN D ED) ............................................................................................................. 47-4
47.4 ACCESS-LIST (IP STANDARD) ............................................................................................................ 47-6
47.5 ACCESS-LIST(MAC EXTENDED).......................................................................................................... 47-7
47.6 ACCESS-LIST(MAC-IP EXTENDED) ...................................................................................................... 47-8
47.7 ACCESS-LIST(MAC STANDARD) ....................................................................................................... 47-10
47.8 CLEAR ACCESS-GROUP (IN | OUT) STATI STIC INTE R FACE ................................................................... 47-11
47.9 FIREWALL ...................................................................................................................................... 47-11
47.10 IP ACCESS EXTENDED ................................................................................................................... 47-12
47.11 IP ACCESS STAN DARD .................................................................................................................. 47-13
47.12 IPV6 ACCESS-LIST ........................................................................................................................ 47-13
47.13 IPV6 ACCESS STANDARD .............................................................................................................. 47-15
47.14 IPV6 ACCESS EXTENDED ............................................................................................................... 47-15
47.15 {IP|IPV6|MAC|MAC-IP} ACCESS-GROUP .......................................................................................... 47-16
47.16 MAC ACCESS EXTENDED ............................................................................................................... 47-17
47.17 MAC-IP ACCESS EXTEND ED ........................................................................................................... 47-18
47.18 PERMIT | DENY (IP EXTEN D ED)....................................................................................................... 47-18
47.19 PERMIT | DENY(IP STANDARD) ....................................................................................................... 47-20
47.20 PERMIT | DENY(IPV6 EXTENDED) ................................................................................................... 47-20
47.21 PERMIT | DENY(IPV6 STANDARD) ................................................................................................... 47-22
1-37
XGS3 Command Guide
47.22 PERMIT | DENY(MAC EXTENDED) ................................................................................................... 47-22
47.23 PERMIT | DENY(MAC-IP EXTENDED) ............................................................................................... 47-24
47.24 SHOW ACCESS-LISTS ................................................................................................................... 47-26
47.25 SHOW ACCESS-GROUP ................................................................................................................. 47-27
47.26 SHOW FIREWALL .......................................................................................................................... 47-28
47.27 SHOW I P V6 ACCESS-LISTS ............................................................................................................ 47-28
47.28 SHOW TIME-RANGE ...................................................................................................................... 47-29
47.29 TIME-RANGE ................................................................................................................................ 47-30
CHAPTER 48 COMMANDS FOR 802.1X ......................................................................48-1
48.1 DEBUG DOT1X DETAIL ...................................................................................................................... 48-1
48.2 DEBUG DOT1X ERROR ...................................................................................................................... 48-1
48.3 DEBUG DOT1X FSM .......................................................................................................................... 48-2
48.4 DEBUG DOT1X PACKET ..................................................................................................................... 48-3
48.5 DOT1X ACCEPT-MAC ........................................................................................................................ 48-3
48.6 DOT1X EAPOR ENABLE ..................................................................................................................... 48-4
48.7 DOT1X ENABLE ................................................................................................................................ 48-5
48.8 DOT1X GUEST-VLAN ......................................................................................................................... 48-5
48.9 DOT1X MACFIL TER ENABLE............................................................................................................... 48-6
48.10 DOT1X MAX-REQ ............................................................................................................................ 48-7
48.11 DOT1X USER FREE-RESOURCE ........................................................................................................ 48-7
48.12 DOT1X MAX-USER MACBASED ........................................................................................................ 48-8
48.13 DOT1X MAX-USER USERBASED ....................................................................................................... 48-9
48.14 DOT1X PORT-CONTROL .................................................................................................................. 48-9
48.15 DOT1X PORT-METHOD .................................................................................................................. 48-10
48.16 DOT1X PRIVATECLIENT ENABLE .................................................................................................... 48-11
48.17 DOT1X PRIVATECLIENT PROTECT ENABLE ...................................................................................... 48-12
48.18 DOT1X RE-AUTHENTICATE ............................................................................................................ 48-12
48.19 DOT1X RE-AUTHENTICATION ......................................................................................................... 48-13
48.20 DOT1X TIMEOUT QUIET-PERIOD ..................................................................................................... 48-13
48.21 DOT1X TIMEOUT RE-AUTHPERIOD.................................................................................................. 48-14
48.22 DOT1X TIMEOUT TX-PERIOD .......................................................................................................... 48-14
48.23 DOT1X UNICAST ENABLE .............................................................................................................. 48-15
48.24 SHOW DOT1X ............................................................................................................................... 48-16
48.25 USER-CONTROL LIMIT IPV4 ........................................................................................................... 48-17
48.26 USER-CONTROL LIMIT IPV6 ........................................................................................................... 48-18
CHAPTER 49 COMMANDS FOR THE NUMBE R LIMITATION FUNCTION OF MAC AND
IP IN PORT, VLAN ..........................................................................................................49-1
49.1 DEBUG IP ARP COUNT ....................................................................................................................... 49-1
1-38
XGS3 Command Guide
49.2 DEBUG IPV6 ND COUNT ..................................................................................................................... 49-1
49.3 DEBUG SWITCHPORT ARP COUNT ...................................................................................................... 49-2
49.4 DEBUG SWITCHPORT MAC COUNT ..................................................................................................... 49-2
49.5 DEBUG SWITCHPORT ND COUNT ........................................................................................................ 49-3
49.6 DEBUG VLAN MAC COUNT ................................................................................................................. 49-4
49.7 IP ARP DYNAMIC MAXIMUM ................................................................................................................ 49-4
49.8 IPV6 ND DYNAMIC MAXIMUM .............................................................................................................. 49-5
49.9 MAC-ADDRESS QUERY TIMEOUT ........................................................................................................ 49-6
49.10 SHOW ARP-DYNAMIC COUNT ........................................................................................................... 49-6
49.11 SHOW MAC-ADDRESS DYNAMIC COUNT............................................................................................ 49-7
49.12 SHOW ND-DYNAMIC COUNT ............................................................................................................. 49-8
49.13 SWITCHPORT ARP DYNAMIC MAXIMUM ............................................................................................. 49-8
49.14 SWITCHPORT MAC-ADDRESS DYNAMIC MAXIMUM ............................................................................. 49-9
49.15 SWITCHPORT MAC-ADDRESS VIOL ATION ........................................................................................ 49-10
49.16 SWITCHPORT ND DYNAMIC MAXIMU M ............................................................................................. 49-11
49.17 VLAN MAC-ADDRESS DYNAMIC MAXIMUM ....................................................................................... 49-12
CHAPTER 50 COMMANDS FOR AM CONFIGURATION .............................................50-1
50.1 AM EN ABLE ..................................................................................................................................... 50-1
50.2 AM PORT ......................................................................................................................................... 50-1
50.3 AM IP-POOL ..................................................................................................................................... 50-2
50.4 AM MAC-IP-POOL ............................................................................................................................. 50-2
50.5 NO AM ALL ....................................................................................................................................... 50-3
50.6 SHOW AM ........................................................................................................................................ 50-3
CHAPTER 51 COMMANDS FOR TACACS+ .................................................................51-1
51.1 TACACS-SERVER AUTH EN TICATION HOST ........................................................................................... 51-1
51.2 TACACS-SERVER KEY ....................................................................................................................... 51-2
51.3 TACACS-SERVER NAS-IPV4 ............................................................................................................... 51-2
51.4 TACACS-SERVER TIMEOUT ................................................................................................................ 51-3
51.5 DEBUG TACACS-SERVER .................................................................................................................. 51-4
CHAPTER 52 COMMANDS FOR RADIUS ....................................................................52-1
52.1 AAA ENABLE .................................................................................................................................... 52-1
52.2 AAA-ACCOUNTING ENABLE ............................................................................................................... 52-1
52.3 AAA-ACCOUNTING UPDATE ............................................................................................................... 52-2
52.4 DEBUG AAA PACKET ......................................................................................................................... 52-2
52.5 DEBUG AAA DETAIL ATTRIBUTE ......................................................................................................... 52-3
52.6 DEBUG AAA DETAIL CONNECTION ...................................................................................................... 52-4
52.7 DEBUG AAA DETAIL EVENT ................................................................................................................ 52-4
1-39
XGS3 Command Guide
52.8 DEBUG AAA ERROR .......................................................................................................................... 52-5
52.9 RADIUS NAS-IPV4 ............................................................................................................................. 52-5
52.10 RADIU S NAS-IPV6 ........................................................................................................................... 52-6
52.11 RADIUS-SERVER ACCOUNTING HOST ............................................................................................... 52-7
52.12 RADIUS-SERVER AUT HEN TICATION HOST ......................................................................................... 52-8
52.13 RADIUS-SERVER DEAD-TIME ........................................................................................................... 52-9
52.14 RADIUS-SERVER KEY ...................................................................................................................... 52-9
52.15 RADIUS-SERVER RETRANSMIT ....................................................................................................... 52-10
52.16 RADIUS-SERVER TIMEOUT ............................................................................................................. 52-11
52.17 RADIUS-SERVER ACCOUNTING-INTERIM-UPDATE TIMEOUT .............................................................. 52-11
52.18 SHOW AAA AUTHENTICATED-USER ................................................................................................ 52-12
52.19 SHOW AAA AUTHENTICATING-USER ............................................................................................... 52-13
52.20 SHOW AAA CONFIG ....................................................................................................................... 52-13
52.21 SHOW RADIUS AUTHENTICATED-US ER COUNT ................................................................................ 52-15
52.22 SHOW RADIUS AUTHENTICATING-USER COUNT ............................................................................... 52-15
52.23 SHOW RADIUS COUNT ................................................................................................................... 52-15
CHAPTER 53 COMMANDS FOR SSL CONFIGURATION ............................................53-1
53.1 IP HTTP SECURE-SERVER .................................................................................................................. 53-1
53.2 IP HTTP SECURE-PORT ..................................................................................................................... 53-1
53.3 IP HTTP SECURE- CIPHERSUITE ......................................................................................................... 53-2
53.4 SHOW IP HTTP SECURE-SERVER STATUS ............................................................................................ 53-3
53.5 DEBUG SSL ...................................................................................................................................... 53-3
CHAPTER 54 COMMANDS FOR IPV6 SECURITY RA .................................................54-1
54.1 IPV6 SECURITY-RA ENABLE ............................................................................................................... 54-1
54.2 IPV6 SECURITY-RA ENABLE ............................................................................................................... 54-1
54.3 SHOW IPV6 SECURITY-RA ................................................................................................................. 54-2
54.4 DEBUG IPV6 SECURITY-RA ................................................................................................................ 54-2
CHAPTER 55 COMMANDS FOR VLAN-ACL ...............................................................55-1
55.1 CLEAR VACL STATI STIC VLAN ............................................................................................................ 55-1
55.2 SHOW VACL VLAN ............................................................................................................................ 55-1
55.3 VACL IP ACCESS-GROUP ................................................................................................................... 55-3
55.4 VACL IPV6 ACCESS-GROUP ............................................................................................................... 55-3
55.5 VACL MAC ACCE SS-GROUP ............................................................................................................... 55-4
55.6 VACL MAC-IP ACCESS-GROUP ........................................................................................................... 55-4
CHAPTER 56 COMMANDS FOR MAB .........................................................................56-1
56.1 AUTHENTICATION MAB ...................................................................................................................... 56-1
56.2 CLEAR MAC -AUTHENTICATION-BYPASS BINDING................................................................................. 56-1
1-40
XGS3 Command Guide
56.3 DEBUG MAC-AUTHENTICATION-BYPASS ............................................................................................. 56-2
56.4 MAC-AUTHENTICATION-BYPASS BINDING-LIMIT................................................................................... 56-2
56.5 MAC-AUTHENTICATION-BYPASS ENABLE ............................................................................................ 56-3
56.6 MAC-AUTHENTICATION-BYPASS GUEST-VLAN ..................................................................................... 56-3
56.7 MAC-AUTHENTICATION-BYPASS SPOOFING-GARP-CHECK ................................................................... 56-4
56.8 MAC-AUTHENTICATION-BYPASS TIMEOUT LINKUP-PERIOD ................................................................... 56-5
56.9 MAC-AUTHENTICATION-BYPASS TIMEOUT OFFLINE-DETECT ................................................................ 56-5
56.10 MAC-AUTHENTICATION-BYPASS TIMEOUT QUIET-PERIOD ................................................................... 56-6
56.11 MAC-AUTHENTICATION-BYPASS TIMEOUT REAUTH-PERIOD ............................................................... 56-6
56.12 MAC-AUTHENTICATION-BYPASS TIMEOUT STALE-PERIOD .................................................................. 56-7
56.13 MAC-AUTHENTICATION-BYPASS USERNAME-F ORM AT ........................................................................ 56-8
56.14 SHOW MAC-AUTHENTICATION-BYPASS............................................................................................. 56-8
CHAPTER 57 COMMANDS FOR PPPOE INTERM EDIATE AGENT ............................57-1
57.1 DEBUG PPP OE INTERMEDIATE AGENT PACKET {RECEIVE | SEND} INTERFACE ETHERNET <INTERFACE-NAME>
.............................................................................................................................................................. 57-1
57.2 PPPOE INTERMEDIATE-AGENT ........................................................................................................... 57-1
57.3 PPPOE INTERMEDIATE-AGENT (PORT) ............................................................................................... 57-2
57.4 PPPOE INTERMEDIATE-AGENT ACCESS-NODE-ID ................................................................................ 57-3
57.5 PPPOE INTERMEDIATE-AGENT CIRCUIT-ID .......................................................................................... 57-3
57.6 PPPOE INTERMEDIATE-AGENT IDENTIFIER-STRING OPTION DELIMITER .................................................. 57-4
57.7 PPPOE INTERMEDIATE-AGENT REMOTE-ID .......................................................................................... 57-5
57.8 PPPOE INTERMEDIATE-AGENT TRUST ................................................................................................ 57-6
57.9 PPPOE INTERMEDIATE-AGENT VENDOR-TAG STRIP ............................................................................. 57-6
57.10 SHOW PPPOE INTERMEDIATE-AGENT ACCESS-NODE-ID ..................................................................... 57-7
57.11 SHO W PPPOE INTERMEDIATE-AGENT IDENTIFIER-STRING OPTION DELIMI TER ...................................... 57-7
57.12 SHOW PPPOE INTERMEDIATE-AGENT INFO ....................................................................................... 57-8
CHAPTER 58 COMMANDS FOR SAVI .........................................................................58-1
58.1 COMMANDS FOR SAVI ..................................................................................................................... 58-1
58.1.1 ipv6 cps prefix ..................................................................................................................................... 58-1
58.1.2 ipv6 cps prefix check enable ............................................................................................................... 58-1
58.1.3 ipv6 dhcp snooping trust ..................................................................................................................... 58-2
58.1.4 ipv6 nd snooping trust ......................................................................................................................... 58-2
58.1.5 savi check binding ............................................................................................................................... 58-3
58.1.6 savi enable .......................................................................................................................................... 58-4
58.1.7 savi ipv6 binding num ......................................................................................................................... 58-4
58.1.8 savi ipv6 check source binding ........................................................................................................... 58-5
58.1.9 savi ipv6 check source ip-address mac-address ................................................................................. 58-6
58.1.10 savi ipv6 {dhcp-only | slaac-only | dhcp-slaac} enable ...................................................................... 58-6
1-41
XGS3 Command Guide
58.1.11 savi ipv6 mac-binding-limit ................................................................................................................ 58-7
58.1.12 savi max-dad-dalay ........................................................................................................................... 58-8
58.1.13 savi max-dad-prepare-delay ............................................................................................................. 58-8
58.1.14 savi max-slaac-life ............................................................................................................................ 58-9
58.1.15 savi timeout bind-protect ................................................................................................................... 58-9
58.2 COMMANDS FOR MONITOR AND DEBUG .......................................................................................... 58-10
58.2.1 Monitor and Debugg ......................................................................................................................... 58-10
CHAPTER 59 COMMANDS FOR WEB PORTAL CONFIGURATION ...........................59-1
59.1 CLEAR WEBPORTAL BINDING ............................................................................................................ 59-1
59.2 DEBUG WEBPORTAL BINDING ............................................................................................................ 59-1
59.3 DEBUG WEBPORTAL ERROR .............................................................................................................. 59-2
59.4 DEBUG WEBPORTAL EVENT .............................................................................................................. 59-2
59.5 DEBUG WEBPORTAL PACKET ............................................................................................................ 59-3
59.6 IP DHCP SNOOPING BINDING WEBPORTAL .......................................................................................... 59-4
59.7 SHOW WEBPORTAL .......................................................................................................................... 59-4
59.8 SHOW WEBPORTAL BINDING ............................................................................................................. 59-5
59.9 WEBPORTAL BINDING-LIMIT .............................................................................................................. 59-6
59.10 WEBPORTAL ENABLE ..................................................................................................................... 59-6
59.11 WEBPORTAL ENABLE (PORT) .......................................................................................................... 59-7
59.12 WEBPORTAL N AS-IP ....................................................................................................................... 59-8
59.13 WEBPORTAL REDIRECT ................................................................................................................... 59-8
CHAPTER 60 COMMANDS FOR VRRP ........................................................................60-9
60.1 ADVERTISEMENT-INTERVAL ............................................................................................................... 60-9
60.2 CIRCUIT-FAILOVER ......................................................................................................................... 60-10
60.3 DEBUG VRRP ................................................................................................................................. 60-11
60.4 DISABLE ........................................................................................................................................ 60-11
60.5 ENABLE ......................................................................................................................................... 60-12
60.6 INTERFACE .................................................................................................................................... 60-12
60.7 PREEMPT-MODE ............................................................................................................................. 60-13
60.8 PRIORITY ....................................................................................................................................... 60-13
60.9 ROUTER VRRP................................................................................................................................ 60-14
60.10 SHOW VRRP ................................................................................................................................. 60-15
60.11 VIRTUAL-IP .................................................................................................................................. 60-16
CHAPTER 61 COMMANDS FOR IPV6 VRRPV3 CONFIGURATION ............................61-1
61.1 ADVERTISEMENT-INTERVAL ............................................................................................................... 61-1
61.2 CIRCUIT-FAILOVER ........................................................................................................................... 61-2
61.3 DEBUG IPV6 VRRP ............................................................................................................................ 61-2
1-42
XGS3 Command Guide
61.4 DISABLE .......................................................................................................................................... 61-3
61.5 ENABLE ........................................................................................................................................... 61-3
61.6 PREEMPT-MODE ............................................................................................................................... 61-4
61.7 PRIORITY ......................................................................................................................................... 61-5
61.8 ROUTER IPV6 VRRP .......................................................................................................................... 61-5
61.9 SHOW IPV6 VRRP ............................................................................................................................. 61-6
61.10 VIRTUAL-IPV6 INTERFACE ............................................................................................................... 61-7
CHAPTER 62 COMMANDS FOR MRPP .......................................................................62-1
62.1 CONTROL-VLAN ............................................................................................................................... 62-1
62.2 CLEAR MRPP STATISTICS .................................................................................................................. 62-1
62.3 DEBUG MRPP ................................................................................................................................... 62-2
62.4 ENABLE ........................................................................................................................................... 62-2
62.5 FAIL-TIMER ...................................................................................................................................... 62-3
62.6 HELLO-TIMER ................................................................................................................................... 62-4
62.7 MRPP ENABLE .................................................................................................................................. 62-4
62.8 MRPP POLL-TIME .............................................................................................................................. 62-5
62.9 MRPP RING ...................................................................................................................................... 62-5
62.10 MRPP RING PRI MARY-PORT ............................................................................................................. 62-6
62.11 MRPP RING SECONDARY-PORT ........................................................................................................ 62-7
62.12 NODE-MODE .................................................................................................................................. 62-7
62.13 SHOW MRPP .................................................................................................................................. 62-8
62.14 SHOW MRPP STAT ISTICS ................................................................................................................. 62-8
CHAPTER 63 COMMANDS FOR ULPP ........................................................................63-1
63.1 CLEAR ULPP FLUSH COUNTER INTERFACE ......................................................................................... 63-1
63.2 CONTROL VLAN ................................................................................................................................ 63-1
63.3 DEBUG ULPP ERROR ........................................................................................................................ 63-2
63.4 DEBUG ULPP EVENT ......................................................................................................................... 63-2
63.5 DEBUG ULPP FLUSH CONTENT INTERFACE ......................................................................................... 63-3
63.6 DEBUG ULPP FLUSH {SEND | RECEIVE} INTERFACE ............................................................................. 63-4
63.7 DESCRIPTION ................................................................................................................................... 63-4
63.8 FLUSH DISABLE ARP ......................................................................................................................... 63-5
63.9 FLUSH DISABLE MAC ........................................................................................................................ 63-5
63.10 FLUSH ENABLE ARP ....................................................................................................................... 63-6
63.11 FLUSH ENABLE MAC ....................................................................................................................... 63-6
63.12 PREEMPTION DELAY ....................................................................................................................... 63-7
63.13 PREEMPTION MODE ........................................................................................................................ 63-7
63.14 PROTECT VLAN-REFERENCE-INSTANCE ........................................................................................... 63-8
63.15 SHOW ULPP FLUSH COUNTER INTERFACE ........................................................................................ 63-8
1-43
XGS3 Command Guide
63.16 SHOW ULPP FLUSH-RECEIVE-PORT ................................................................................................. 63-9
63.17 SHOW ULPP GROUP ........................................................................................................................ 63-9
63.18 ULPP CONTROL VLAN ................................................................................................................... 63-10
63.19 ULPP FLUSH DISABLE ARP ............................................................................................................ 63-11
63.20 ULPP FLUSH DISABLE MAC............................................................................................................ 63-11
63.21 ULPP FLUSH ENABLE AR P ............................................................................................................. 63-12
63.22 ULPP FLUSH ENABLE MAC ............................................................................................................ 63-12
63.23 ULPP GROUP ............................................................................................................................... 63-13
63.24 ULPP GROUP MASTER .................................................................................................................. 63-13
63.25 ULPP GROUP SLAVE ..................................................................................................................... 63-14
CHAPTER 64 COMMANDS FOR ULSM .......................................................................64-1
64.1 DEBUG ULSM EVENT ......................................................................................................................... 64-1
64.2 SHOW ULSM GROUP ......................................................................................................................... 64-1
64.3 ULSM GROUP ................................................................................................................................... 64-2
64.4 ULSM GROUP {UPLINK | DOWNLINK} .................................................................................................. 64-2
CHAPTER 65 COMMANDS FOR MIRRORING CONFIGURATION ..............................65-4
65.1 MONITOR SESSION SOURCE INTE RFACE ............................................................................................. 65-4
65.2 MONITOR SESSION SOURCE INTERFACE ACCESS-LIST ......................................................................... 65-4
65.3 MONITOR SESSIO N D ESTINATION INTERFACE ...................................................................................... 65-5
65.4 SHOW MONITOR ............................................................................................................................... 65-6
CHAPTER 66 COMMANDS FOR RSPAN CONFIGURATION ......................................66-1
66.1 REMOTE-SPAN ................................................................................................................................. 66-1
66.2 MONITOR SESSION REMOTE VLAN ..................................................................................................... 66-1
66.3 MONITOR SESSION REFLECTOR-PORT ................................................................................................ 66-2
CHAPTER 67 COMMANDS FOR SFLOW .....................................................................67-1
67.1 SFLOW AGENT-ADDRESS .................................................................................................................. 67-1
67.2 SFLOW ANALYZER ............................................................................................................................ 67-1
67.3 SFLOW COUNTER-INTERVAL .............................................................................................................. 67-2
67.4 SFLOW DATA-LEN ............................................................................................................................. 67-2
67.5 SFLOW D E STINATION ........................................................................................................................ 67-3
67.6 SFLOW HEADER-LEN ........................................................................................................................ 67-4
67.7 SFLOW PRIORITY .............................................................................................................................. 67-4
67.8 SFLOW RATE .................................................................................................................................... 67-5
67.9 SHOW SFLOW .................................................................................................................................. 67-6
CHAPTER 68 COMMANDS FOR SNTP ........................................................................68-8
68.1 CLOCK TIMEZONE............................................................................................................................. 68-8
1-44
XGS3 Command Guide
68.2 DEBUG SNTP .................................................................................................................................... 68-8
68.3 SNTP POL LTIME ................................................................................................................................ 68-9
68.4 SNTP SERVER .................................................................................................................................. 68-9
68.5 SHOW SNTP ................................................................................................................................... 68-10
CHAPTER 69 COMMANDS FOR NTP ..........................................................................69-1
69.1 CLOCK TIMEZONE............................................................................................................................. 69-1
69.2 DEBUG NTP ADJUST ......................................................................................................................... 69-1
69.3 DEBUG NTP AUTHENTICATION ........................................................................................................... 69-2
69.4 DEBUG NTP EVENTS ......................................................................................................................... 69-2
69.5 DEBUG NTP PACKET ......................................................................................................................... 69-3
69.6 DEBUG NTP SYNC ............................................................................................................................. 69-3
69.7 NTP ACCESS-GROUP ........................................................................................................................ 69-4
69.8 NTP AUTHENTICATE .......................................................................................................................... 69-4
69.9 NTP AUTHENTICATION-KEY ............................................................................................................... 69-5
69.10 NTP BROADCAST CLIENT ................................................................................................................ 69-5
69.11 NTP BROADCAST SERVER COUNT .................................................................................................... 69-6
69.12 NTP DISABLE ................................................................................................................................. 69-6
69.13 NTP ENABLE .................................................................................................................................. 69-7
69.14 NTP IPV6 MULTICAST CL IENT ........................................................................................................... 69-7
69.15 NTP MULTICAST CLIENT .................................................................................................................. 69-8
69.16 NTP SERVER .................................................................................................................................. 69-8
69.17 NTP TRUSTED-KEY ......................................................................................................................... 69-9
69.18 SHOW NTP STATUS ......................................................................................................................... 69-9
69.19 SHOW NTP SESSION ..................................................................................................................... 69-10
CHAPTER 70 COMMANDS FOR DNSV4/V6 ................................................................70-1
70.1 CLEAR DYNAMIC-HOST ..................................................................................................................... 70-1
70.2 DEBUG DNS ..................................................................................................................................... 70-1
70.3 DNS-SERVER ................................................................................................................................... 70-2
70.4 DNS LOOKUP ................................................................................................................................... 70-3
70.5 SHOW DNS NAME-SERVER ................................................................................................................ 70-3
70.6 SHOW DNS DOMAIN-LIST ................................................................................................................... 70-4
70.7 SHOW DNS HOSTS ............................................................................................................................ 70-4
70.8 SHOW DNS CONFIG ........................................................................................................................... 70-5
70.9 SHOW DNS CLIENT ........................................................................................................................... 70-5
70.10 IP DOMAIN-LOOKUP ........................................................................................................................ 70-6
70.11 IP DOMAIN-LIST .............................................................................................................................. 70-6
70.12 IP DNS SERVER .............................................................................................................................. 70-7
70.13 IP DNS SERVER QUEUE MAXIMUM .................................................................................................... 70-7
1-45
XGS3 Command Guide
70.14 IP DNS SERVER QUEUE TIMEOUT ..................................................................................................... 70-8
CHAPTER 71 COMMANDS FOR SUMMER TIME ........................................................71-1
71.1 CLOCK SUMMER-TIME ABSOLUTE ...................................................................................................... 71-1
71.2 CLOCK SUMMER-TIME RECURRING .................................................................................................... 71-2
71.3 CLOCK SUMMER-TIME RECURRING .................................................................................................... 71-2
CHAPTER 72 COMMANDS FOR SHOW ......................................................................72-3
72.1 CLEAR HISTORY ALL-USERS .............................................................................................................. 72-3
72.2 CLEAR LOGGING .............................................................................................................................. 72-4
72.3 HISTORY ALL-USERS MAX-LENGTH .................................................................................................... 72-4
72.4 LOGGING ......................................................................................................................................... 72-5
72.5 LOGGING EXECUTED-COMMANDS ...................................................................................................... 72-6
72.6 LOGGING LOGHOST SEQUENCE-NUMBER ........................................................................................... 72-6
72.7 PING................................................................................................................................................ 72-7
72.8 PING6.............................................................................................................................................. 72-9
72.9 SHOW DEBUGGING ......................................................................................................................... 72-11
72.10 SHOW FLASH ............................................................................................................................... 72-12
72.11 SHOW HISTORY ............................................................................................................................ 72-12
72.12 SHOW HISTORY ALL-USERS ........................................................................................................... 72-13
72.13 SHOW LOGGING BUFFERED .......................................................................................................... 72-14
72.14 SHOW LOGGING EXECUTED-COMMANDS STATE .............................................................................. 72-14
72.15 SHOW LOGGING SOURCE .............................................................................................................. 72-15
72.16 SHOW MEMORY ............................................................................................................................ 72-15
72.17 SHOW RUNNING-CONFIG ............................................................................................................... 72-16
72.18 SHOW STARTUP-CONFIG ............................................................................................................... 72-17
72.19 SHOW SWITCHPORT INTERFACE .................................................................................................... 72-17
72.20 SHOW TCP ................................................................................................................................... 72-18
72.21 SHOW TCP IPV6 ............................................................................................................................ 72-19
72.22 SHOW TELNET LOGIN.................................................................................................................... 72-19
72.23 SHOW TEMPERATURE ................................................................................................................... 72-20
72.24 SHOW TECH-SUPPORT .................................................................................................................. 72-20
72.25 SHOW UDP ................................................................................................................................... 72-21
72.26 SHOW UDP IPV6 ........................................................................................................................... 72-21
72.27 SHOW VERSION ............................................................................................................................ 72-22
72.28 TRACEROUTE .............................................................................................................................. 72-22
72.29 TRACEROUTE6 ............................................................................................................................ 72-23
CHAPTER 73 COMMANDS FOR RELO AD SWITCH AFTER SPECIFIED TIME .........73-1
73.1 RELOAD AFTER ................................................................................................................................ 73-1
1-46
XGS3 Command Guide
73.2 RELOAD CANCEL ............................................................................................................................. 73-1
73.3 SHOW RELOAD ................................................................................................................................. 73-2
CHAPTER 74 COMMANDS FOR DEBUGGING AND DIAGNOSIS FOR PACKETS
RECEIVED AND SENT BY CPU ....................................................................................74-1
74.1 CLEAR CPU-RX-STAT PROTOCOL ....................................................................................................... 74-1
74.2 CPU-RX-RATELIMIT PROTOCOL .......................................................................................................... 74-1
74.3 CPU-RX-RATELIMIT TOTAL ................................................................................................................. 74-2
74.4 DEBUG DRIVER ................................................................................................................................ 74-3
74.5 SHOW CPU-RX PROTOCOL ................................................................................................................ 74-3
CHAPTER 75 COMMANDS FOR MPLS ........................................................................75-4
75.1 MPLS EGRESS -TTL ........................................................................................................................... 75-4
75.2 MPLS ENABLE .................................................................................................................................. 75-5
75.3 MPLS INGRESS-TTL .......................................................................................................................... 75-5
75.4 SHOW MPLS ..................................................................................................................................... 75-6
75.5 SHOW MPLS ENABLE ........................................................................................................................ 75-7
75.6 SHOW MPLS FORWARDING-TABLE ..................................................................................................... 75-7
75.7 SHOW MPLS FTN-TABLE BRIEF .......................................................................................................... 75-8
75.8 SHOW MPLS FTN-TABLE DETA IL ......................................................................................................... 75-8
75.9 SHOW MPLS ILM-TABLE .................................................................................................................. 75-10
75.10 SHOW MPLS VRF-TABLE ............................................................................................................... 75-11
CHAPTER 76 LDP .........................................................................................................76-1
76.1 ADVERTISEMENT-MODE .................................................................................................................... 76-1
76.2 CLEAR LDP ADJACENCY ................................................................................................................... 76-1
76.3 CLEAR LDP SESSION ........................................................................................................................ 76-2
76.4 CLEAR LDP STATISTICS ..................................................................................................................... 76-2
76.5 CONTROL-MODE .............................................................................................................................. 76-3
76.6 DEBUG LDP ALL ............................................................................................................................... 76-4
76.7 DEBUG LDP DSM .............................................................................................................................. 76-4
76.8 DEBUG LDP ERROR .......................................................................................................................... 76-5
76.9 DEBUG LDP EVENTS ......................................................................................................................... 76-5
76.10 DEBUG LDP FSM ............................................................................................................................. 76-6
76.11 DEBUG LDP HEXDUMP .................................................................................................................... 76-6
76.12 DEBUG LDP NSM ............................................................................................................................ 76-7
76.13 DEBUG LDP PACKET ....................................................................................................................... 76-7
76.14 DEBUG LDP TIMER .......................................................................................................................... 76-8
76.15 DEBUG LDP TSM ............................................................................................................................. 76-8
76.16 DEBUG LDP USM ............................................................................................................................ 76-9
1-47
XGS3 Command Guide
76.17 LDP {ENABLE|DISABLE} .................................................................................................................. 76-9
76.18 GLOBAL-MERGE-CAPABILITY ........................................................................................................ 76-10
76.19 HELLO-INTERVAL ......................................................................................................................... 76-11
76.20 HOLD-TIME .................................................................................................................................. 76-11
76.21 IMPORT-BGP-ROUTES ................................................................................................................... 76-12
76.22 KEEPALIVE-INTERVAL ................................................................................................................... 76-13
76.23 KEEPALIVE-TIMEOUT .................................................................................................................... 76-13
76.24 LABEL-RETENTION-MODE ............................................................................................................. 76-14
76.25 LABEL-SWITCHING ....................................................................................................................... 76-15
76.26 LDP ADVERTISEMENT-MODE .......................................................................................................... 76-16
76.27 LDP HELLO-INTERVAL ................................................................................................................... 76-16
76.28 LDP HOLD-TIME ............................................................................................................................ 76-17
76.29 LDP KEEPALIVE-INTERVAL ............................................................................................................ 76-18
76.30 LDP KEEPALIVE-TIMEOUT .............................................................................................................. 76-19
76.31 LDP LABEL-RETENTION-MODE....................................................................................................... 76-19
76.32 LDP MULTICAST-HELLOS ............................................................................................................... 76-20
76.33 LDP TARGETED-PEER-HELLO-INTERVAL ......................................................................................... 76-21
76.34 LDP TARGETED-PEER-HOLD-TIME .................................................................................................. 76-21
76.35 LOOP-DETECTION ........................................................................................................................ 76-22
76.36 LOOP-DETECTION-COUNT ............................................................................................................. 76-23
76.37 MULTICAST-HELLOS ..................................................................................................................... 76-23
76.38 PROPAG ATE-RELEASE .................................................................................................................. 76-24
76.39 REQUEST-RETRY .......................................................................................................................... 76-24
76.40 REQUEST-RETRY-TIMEOUT ............................................................................................................ 76-25
76.41 ROUTER LDP ................................................................................................................................ 76-26
76.42 ROUTER-ID .................................................................................................................................. 76-26
76.43 SHOW LDP ................................................................................................................................... 76-27
76.44 SHOW LDP ADJACENCY ................................................................................................................ 76-29
76.45 SHOW LDP DOWNSTREAM ............................................................................................................. 76-29
76.46 SHOW LDP FEC ............................................................................................................................ 76-30
76.47 SHOW LDP INTERFACE .................................................................................................................. 76-31
76.48 SHOW LDP LSP ............................................................................................................................. 76-31
76.49 SHOW LDP SESSION ..................................................................................................................... 76-32
76.50 SHOW LDP STATISTICS .................................................................................................................. 76-32
76.51 SHOW LDP TARGETED-PEERS ....................................................................................................... 76-33
76.52 SHOW LDP UPSTREAM .................................................................................................................. 76-34
76.53 SHOW MPLS LDP DISCOVERY ........................................................................................................ 76-34
76.54 SHOW MPLS LDP FEC .................................................................................................................... 76-35
76.55 SHOW MPLS LDP NEIGHBOR .......................................................................................................... 76-35
1-48
XGS3 Command Guide
76.56 SHOW MPLS LDP PARAMETER ....................................................................................................... 76-36
76.57 SHOW MPLS LDP SES SI O N ............................................................................................................ 76-38
76.58 TARGETED-HELLO-ACCEPT ........................................................................................................... 76-38
76.59 TARGETED-PEER .......................................................................................................................... 76-39
76.60 TARGETED-PEER-HELLO-INTERVAL ............................................................................................... 76-39
76.61 TARGETED-PEER-HOLD-TIME ........................................................................................................ 76-40
76.62 TRANSPORT-ADDRESS ................................................................................................................. 76-41
CHAPTER 77 MPLS VPN ..............................................................................................77-1
77.1 ADDRESS-FA MILY IPV4 ...................................................................................................................... 77-1
77.2 ADDRESS-FA MILY VPNV4 .................................................................................................................. 77-1
77.3 AGGREGATE-ADDRESS ..................................................................................................................... 77-2
77.4 CLEAR IP BGP .................................................................................................................................. 77-2
77.5 DEBUG BGP MPLS ............................................................................................................................ 77-3
77.6 DEBUG BGP UPDATE ......................................................................................................................... 77-4
77.7 DESCRIPTION ................................................................................................................................... 77-4
77.8 IMPORT MAP .................................................................................................................................... 77-5
77.9 IP ROUTE ......................................................................................................................................... 77-5
77.10 IP ROUTE VRF ................................................................................................................................ 77-6
77.11 IP VRF............................................................................................................................................ 77-7
77.12 IP VRF FORWARDING VRFNAME ....................................................................................................... 77-7
77.13 MPLS PROXY LOOPBACK-GROUP .................................................................................................... 77-8
77.14 NEIGHBOR REMOTE-AS ................................................................................................................... 77-9
77.15 NEIGHBOR AS-OVERRIDE .............................................................................................................. 77-10
77.16 NEIGHBOR SOO ............................................................................................................................ 77-10
77.17 RD .............................................................................................................................................. 77-11
77.18 ROUTE-TARGET ............................................................................................................................ 77-12
77.19 SHOW IP BGP VPNV4 .................................................................................................................... 77-13
77.20 SHOW IP ROUTE VRF..................................................................................................................... 77-14
77.21 SHOW IP VRF ............................................................................................................................... 77-14
1-49
XGS3 Command Guide
Chapter 1 Commands for Basic Switch
Configuration

1.1 Commands for Basic Conf igur a tion

1.1.1 Authentication line login

Command:
authentication line {console | sty | web} login {local | radius | tacacs} No authentication line {console | sty | web} login
Function:
Configure VTY (login with Telnet and SSH), Web and Console, so as to select the priority of the authentication mode for the login user. The no form command restores the default authenticati on mode .
Default:
No configuration is enabled for the console login method by default. Local authentication is enabled for the VTY and Web login method by default.
Command Mode:
Global Mode.
Usage Guide:
The authentication method for Console, VTY and Web login can be configured respectively. And authentication method can be any one or combination of Local, RADIUS or TACCACS. When login method is configuration in combination, the preference goes from left to right. If the users have passed the authentication method, authentication method of lower preferences will be ignored. To be mentioned, if the user receives correspond protocol’s answer whether refuse or incept, it will not attempt the next authentication method (Exception: if the local authentication method failed, it will attempt the next authentication method); it will attempt the next authentication method if it receives nothing. And AAA function RADIUS server should be configured before the RADIUS configuration method can be used. And TACACS server should be configured before the TACACS configuration method can be used.
The authentication line console login c ommand is exclusive with the login command. The authentication line console login command configures the switch to use the Console login method. And the login command makes the Console login to use the passwords configured by the password command for authentication. If local authentication is configured while no local users are configured, users will be able to login the switch via the Console method.
Example:
To configure the Telnet and ssh login method to use RADIUS authentication method.
1-50
XGS3 Command Guide
Switch(config)# authenticat ion line vty login lo cal radi us
Relative Command:
aaa enable, radius-server authentication host, tacacs-server authentication host, tacacs-server key

1.1.2 banner

Command:
banner motd <LINE> no banner motd
Function:
This command is used to configure the information displayed when the login authentication of a telnet or console user is successful, the no command configures that the information is not displayed when the authentication is successful.
Parameters: .
<LINE>: The information displayed when the authentication is successful, length limit from 1 to 100 characters.
Command Mode:
Global Mode.
Default:
Do not show the information when the authentication is successful.
Example:
Switch(config)#banner motd Welc ome

1.1.3 boot img

Command:
boot img <img-file-url>｛primary | backup｝
Function:
Configure the first and second img files used in the next boot of the main control boardcard.
Parameters: .
primary means to configure the first IMG file, backup means to configure the second IMG file, <img-file-url> is the full path of the booting IMG file, the format of which is as follows:
1. The file path comprises of two parts: device prefix used as the root directory (flash:/) and the file name. No space is allowed in each part or between two parts.
2. The suffix of all file names should be .img.
3. The length of the full file path should be no longer than 128 characters, while the file name no longer than 80 characters.
1-51
XGS3 Command Guide
Command Mode:
Admin Mode.
Default:
The factory original configuration only specifies the first booting IMG file, the nos.img file in the FLASH, without the second one.
Example:
1. Set flash:/nos.img as the second booting IMG file used in the next booting of the system.
Switch#boot img flash:/nos.im g backup
2. Set flash:/5.4.128.0_nos.img as the first booting IMG file used in the next booting of the system.
Switch#boot img flash:/5.4.128.0_nos.img primary

1.1.4 boot startup-config

Command:
boot startup-config { NULL | <file-url> }
Function:
Configure the CGF file used in the next booting of the main control boardcard.
Parameters:
The NULL keyword means to use the factory original configuration as the next booting configuration. Setting the he CGF file used in the next booting as NULL equals to implementing “set default” and “write”. <file-url> is t he f ull path of CGF file used in the next booting.
1. The file path compri se s of two parts: device prefix used as th e root dir e ctory ( fl ash :/) an d th e fil e name. No space
is allowed in each part or between two parts.
2. The suffix of all file names should be .cfg.
3. The length of the full file path should be no longer than 128 characters, while the file name no longer than 80
characters.
Command Mode:
Admin Mode.
Default Settings:
None.
Example:
1. Set flash:/ startup.cfg as the booting CFG file used in the next booting of the system.
Switch# boot startup-configflash:/ startup.cfg
2. Set flash:/ test-trunk.cfg as the booting CFG file used in the next booting of the system.
Switch#boot startup-config flash:/ test-trunk.cfg
1-52
XGS3 Command Guide

1.1.5 clock set

Command:
clock set <HH:MM:SS> <YYYY.MM.DD>
Function:
Set system date and time.
Parameter:
<HH:MM:SS>is the current time, and the valid scope for HH is 0 to 23, MM and SS 0 to 59; <YYYY.MM.DD> is t he current year, month and date, and the valid scope for YYYY is 1970~2038, MON meaning month, and DD between 1 to 31.
Command mode:
Admin Mode.
Default:
upon first time start-up, it is defaulted to 2006.1.1 0: 0: 0.
Usage guide:
The switch can not continue timing with power off, hence the current date and time must be first set at environments where exact time is required.
Example:
To set the switch current date and time to 2002.8.1 23: 0: 0:
Switch#clock set 23:0:0 2002.8.1
Relative Command:
show clock

1.1.6 config

Command:
config [terminal]
Function:
Enter Global Mode from Admin Mode.
Parameter:
[terminal] indicates terminal configuration.
Command mode:
Admin Mode
Example:
Switch#config
1-53
XGS3 Command Guide
Switch>

1.1.7 debug ssh-server

Command:
debug ssh-server no debug ssh-server
Function:
Display SSH server debugging information; the “no debug ssh-server” command stops displaying SSH server debugging information.
Default:
This function is disabled by default.
Command mode:
Admin Mode.

1.1.8 disable

Command:
disable
Function:
Disable admin mode.
Command mode:
Admin Mode.
Example:
Switch#disable

1.1.9 enable

Command:
enable
Function:
Use enable command to enter Admin Mode from User Mode.
Command mode:
User Mode/ Admin Mode.
Usage Guide:
To prevent unauthorized access of non-admin user, user authentication is required (i.e. Admin user password is required) when entering Admin Mode from User Mode. If the correct Admin user password is entered, Admin Mode access is granted; if 3 consecutive entry of Admin user password are all wrong, it remains in the User Mode. Set the Admin user password under Global Mode with “enable password” command.
1-54
XGS3 Command Guide
Switch#
Example:
Switch>enable

1.1.10 enable password

Command:
enable passw ord [0|7] <password> no enable password
Function:
Configure the password used for enter Admin Mode from the User Mode, The “no enable password” command deletes this passwo rd.
Parameter:
password is the password for the user. If input option 0 on password setting, the password is not encrypted; if input option 7, the password is encrypted.
Command mode:
Global Mode
Default:
This password is empty by system default
Usage Guide:
Configure this password to prevent unauthorized entering Admin Mode. It is recommended to set the password at the initial switch configuration. Also, it is recommended to exit Admin Mode with “exit” command when the administrator needs to leave the terminal for a long time.

1.1.11 end

Command:
end
Function:
Quit current mode and return to Admin mode when not at User Mode/ Admin Mode.
Command mode:
Except User Mode/ Admin Mode
Example:
Quit VLAN mode and return to Admin mode.
Switch(config-vlan1)#end Switch#
1-55
XGS3 Command Guide

1.1.12 exec-timeout

Command:
exec-timeout <minutes> [<seconds>] no exec-timeout
Function:
Configure the timeout of exiting admin mode. The “no exec-timeout” command restores the default value.
Parameters:
<minute> is the time value shown in minute and ranges between 0~35791.
<seconds> is the time value shown in seconds and ranges between 0~59.
Command mode:
Global mode
Default:
Default timeout is 10 minutes.
Usage guide:
To secure the switch, as well to prevent mal ic iou s a ctio ns f rom unauthorized u ser, the time will be count from the last configuration the admin had m ade, an d the sy st em w ill exit the admin mode at due time. It is required to enter admin code and password to enter the admin mode again. The timeout timer will be disabled when the timeout is set to 0.
Example:
Set the admin mode timeout value to 6 minutes
Switch(config)#exec-timeout 6
Set the admin mode timeout value to 5 minutes, 30 seconds
Switch(config)#exec-timeout 5 3 0

1.1.13 exit

Command:
exit
Function:
Quit current mode and return to it’s previous mode.
Command mode:
All Modes
Usage Guide:
This command is to quit current mode and return to it’s previous mode.
Example:
Quit global mode to it’s previous mode
Switch#exit
1-56
XGS3 Command Guide
Switch#

1.1.14 help

Command:
help
Function:
Output brief description of the command interpreter help system.
Command mode:
All configuration modes.
Usage Guide:
An instant online help provided by the switch. Help command displays information about the whole help system, including complete help and part ial help. T he user can type in ? any time to get online help.
Example:
switch(config)#help
PLANETOS CLI provides advanced help feature. When you need help, anytime at the command line please press '?'. If nothing matches, the he lp list w ill b e empty and you mu st backup until entering a '?' shows the availab le option s. Two styles of help are provided:
1. Full help is available when you are ready to enter acommand argument (e.g. 'show ?') and describes each possible argument.
2. Partial help is provided when an abbreviated argument is entered and you want to know what arguments match the input (e.g. 'show ve?'.)

1.1.15 hostname

Command:
hostname <hostname> no hostname
Function:
Set the prompt in the switch command line interface. The no operation cancels the configuration.
Parameter:
<hostname> is the string for the prompt, up to 30 characters are allowed.
Command mode:
Global Mode
Default:
The default prompt is relatived with the switch.
1-57
XGS3 Command Guide
Test(config)#
Usage Guide:
With this command, the user can set the CLI prompt of the switch according to their own requirements.
Example:
Set the prompt to “Test”.
Switch(config)#hostname Test

1.1.16 ip host

Command:
ip host <hostname> <ip_addr> no ip host {<hostname>|all}
Function:
Set the mapping relationship between the host and IP address; the “no ip host” parameter of this command will delete the mapping.
Parameter:
<hostname> is the host name, up to 15 characters are allowed; <ip_addr> is the corresponding IP address for the host name, takes a dot decimal format;
all is all of the host name.
Command mode:
Global Mode
Usage Guide:
Set the association between host and IP address, which can be used in commands like “ping <host>“.
Example:
Set IP address of a host with the hostname of “beijing” to 200.121.1.1.
Switch(config)#ip host beijing 200.121.1.1
Command related:
telnet, ping, traceroute

1.1.17 ipv6 host

Command:
ipv6 host <hostname> <ipv6_addr> no ipv6 host {<hostname>|all}
Function:
Configure the mapping relationship between the IPv6 address and the host; the “no ipv6 host <hostname>” command deletes this mapping relationship.
Parameter:
1-58
XGS3 Command Guide
<hostname> is the name of the host, containing max 15 characters; <ipv6_addr> is the IPv6 address corresponding to the host name.
<all> is all the host address.
Command Mode:
Global Mode
Usage Guide:
Configure a fixed corresponding relationship between the host and the IPv6 address, applicable in commands such as “traceroute6 <host>”, etc.
Example:
Set the IPv6 address of the host named beijing to 2001:1:2:3::1
Switch(config)#ipv6 host beijing 2001:1:2:3::1
Command related:
ping6,traceroute6

1.1.18 ip http server

Command:
ip http server no ip http server
Function:
Enable Web configuration; the “no ip http server” command disables Web configuration
Command mode:
Global mode
Usage guide:
Web configuation is for supplying a interface configured with HTTP for the user, which is straight and visual, esay to understand.
Example:
Enable Web Server function and enable Web configurations.
Switch(config)#ip http server

1.1.19 language

Command:
language {chinese | english}
Function:
Set the language for displaying the help information.
Parameter:
1-59
XGS3 Command Guide
chinese for Chinese display; english for English display.
Command mode:
Admin and Config Mode.
Default:
The default setting is English display.
Usage Guide:
Switch provides help information in two languages, the user can select the language according to their preference. After the system restart, the help information display will revert to English.

1.1.20 login

Command:
login no login
Function:
login enable password authentication, no login command cancels the login configuration.
Command mode:
Global mode
Default:
No login by default
Usage guide:
By using this command, users have to enter the password set by password command to enter normal user mode with console; no login cancels this restriction.
Example:
Enable password
Switch(config)#login

1.1.21 password

Command:
password [0|7] <password> no password
Function:
Configure the pas sw or d us ed f or ent er n or ma l u ser mo de on the console. The “no password” command delete s this password.
Parameter:
1-60
XGS3 Command Guide
Switch(config)#login
password is the configured code. Encryption will be performed by entering 8.
Command mode:
Global mode
Default:
This password is empty by system default
Usage guide:
When both this password and login command are configured, users have to enter the password set by password command to enter normal user mode on console.
Example:
Switch(config)#password 0 test

1.1.22 reload

Command:
reload
Function:
Warm reset the switch.
Command mode:
Admin Mode.
Usage Guide:
The user can use this command to restart the switch without power off.

1.1.23 service password-encryption

Command:
service password-encryption no service password-encryption
Function:
Encrypt system password. T he “no serv ice password-encryption” command cancels the encryption.
Command mode:
Global Mode
Default:
No service password-encryption by system default
Usage guide:
The current unencrypted passwords as well as the coming passwords configured by password, enable password and username command will be encrypted by executed this command. no service password-encryption cancels this function however encrypted passwords remain unchanged.
1-61
XGS3 Command Guide
Example:
Encrypt system passwords
Switch(config)#service password-encryption

1.1.24 service terminal-length

Command:
service terminal-length <0-512> no service terminal-length
Function:
Configure the columns of characters displayed in each screen on terminal (vty). The “no service terminal-length” command cancels the screen shifting operation.
Parameter:
Columns of characters displayed on each screen of vty, ranging between 0-512.
Command mode:
Global Mode
Usage guide:
Configure the columns of characters displayed on each screen of the terminal. The columns of characters displayed on each screen on the telent.ssh client and the Console will be following this config urati on.
Example:
Set the number of vty threads to 20.
Switch(config)#service t erminal-length 20

1.1.25 sysContact

Command:
sysContact <LINE> no sysContact
Function:
Set the factory contact mode, the “no sysContact” command reset the switch to factory settings.
Parameter:
<LINE> is the prompt character string, range from 0 to 255 characters.
Command mode:
Global Mode
Default:
The factory settings.
Usage guide:
1-62
The user can set the factory contact mode bases the fact instance.
Example:
Set the factory contact mode to test.
Switch(config)#sysContact test

1.1.26 sysLocation

Command:
sysLocation <LINE> no sysLocation
Function:
Set the factory address, the “no sysLocation” command reset the switch to factory settings.
Parameter:
<LINE> is the prompt character string, range from 0 to 255 characters.
XGS3 Command Guide
Command mode:
Global Mode
Default:
The factory settings.
Usage guide:
The user can set the factory address bases the fact instance.
Example:
Set the factory address to test.
Switch(config)#sysLocation test

1.1.27 set default

Command:
set default
Function:
Reset the switch to factory settings.
Command mode:
Admin Mode.
Usage Guide:
Reset the switch to factory settings. That is to say, all configurations made by the user to the switch will disappear.
When the switch is restarted, the prompt will be the same as when the switch was powered on for the first time.
Note:
After the command, “write” command must be executed to save the operation. The switch will reset to factory
1-63
settings after restart.
Switch#reload
Example:
Switch#set default
Are you sure? [Y/N] = y
Switch#write

1.1.28 setup

Command:
setup
Function:
Enter the Setup Mode of the switch.
XGS3 Command Guide
Command mode:
Admin Mode.
Usage Guide:
Switch provides a Setup Mode, in which the user can configure IP addre ss es, etc.

1.1.29 show clock

Command:
show clock
Function:
Display the curre nt syst e m cl o ck.
Command mode:
Admin and Configuration Mode.
Usage Guide:
If the system clock is inaccurate, user can adjust the time by examining the system date and clock.
Example:
Switch#show clock Current time is TUE AUG 22 11：00：01 2002
Command related:
clock set
1-64
XGS3 Command Guide
From running CPU IDLE: 89%
The memory total 128 MB, free 58914872 bytes, usage is 56.10%

1.1.30 show cpu usage

Command:
show cpu usage [<slotno>]
Function:
Show CPU usage rate.
Command mode:
Admin and Configuration Mode.
Usage Guide:
Check the current usage of CPU r esource by show cpu usage command. Only the chassis switch uses slotno parameter which is used to show the CPU usage rate of the card on specified slot, if there is no parameter, the default is current card.
Example:
Show the current usage rate of CPU.
Switch#show cpu usage Last 5 second CPU IDLE: 87% Last 30 second CPU IDLE: 89% Last 5 minute CPU IDLE: 89%
Command related:
clock set

1.1.31 show memory usage

Command:
show memory usage [<slotno>]
Function:
Show memory usage rate.
Command mode:
Admin and Configuration Mode.
Usage Guide:
Check the current usage of memory resource by show memory usage command. Only the chassis switch uses slotno parameter w hic h is us ed to show the memory usage rate of card o n t he specified slot, if th er e is n o parameter, the default is current card.
Example:
Show the current usage rate of the memory.
Switch#show memory usage
1-65

1.1.32 show privilege

Current privilege level is 15
Command:
show privilege
Function:
Show privilege of the current users.
Command mode:
All configuration modes
Example:
Show privilege of the current user.
Switch(Config)#show privilege

1.1.33 show temperature

XGS3 Command Guide
Command:
show temperature
Function:
Display the current temputerature of the switch CPU.
Command mode:
All mode.
Usage Guide:
This command is used to monitor the temperature of the switch CPU.
Example:
Display the current temperature of the switch CPU.
Switch(Config)#show temperature Temperature: 47.0625 ℃

1.1.34 show tech-support

Command:
show tech-support [no-more]
Function:
Display the operational information and the task status of the switch. The technique specialist use this command to diagnose whether the switch operate normally.
Parameter:
no-more: Display the operational information and the task status of the switch directly, do not connect the user by
1-66
“more”. Command mode:
Admin and Configuration Mode.
Usage Guide:
This command is used to collect the relative information when the switch operat ion is malfuncti oned.
Example:
Switch#show tech-support

1.1.35 show version

Command:
show version
Function:
Display the version information of the switch.
XGS3 Command Guide
Command mode:
Admin and Configuration Mode.
Usage Guide:
this command is used to show the v er si on in form at i on of t he s witch, including the hardw are v er sio n an d the sof tware version information.
Example:
Switch#show version

1.1.36 username

Command:
username <username> [privilege <privilege>] [password <0|7> <password>] no username <username>
Function:
Configure local login username and password along with its privilege level.
Parameter:
<username> is the name of the user. <privilege> is the maximum privilege level of the commands that the user is able to execute, its value is limited
between 1 and 15, and 1 by default. <password> is the password for the user. If input option 7 on password setting, the password is encrypted; if input option 0, the password is not processed.
Command Mode:
Global Mode.
1-67
XGS3 Command Guide
Usage Guide:
There are two available choices for the preferences of the registered commands in the switch. They are 1 and 15. Preference of 1 is for the commands of the normal user configuration mode. Preference of 15 is for the commands registered in modes other than the normal user configuration modes. 16 local users at most can be configured through this command, and the maximum length of the password should be no less than 32.
Notice:
The user can log in user and priority after the command configures, before issuing the command authentication line console login local, it should be made sure that at one user has be configured as preference level of 15, in order to login the switch and ma ke con figurat ion change s in pr ivileg ed mod e and gl obal m ode. If ther e are no conf igured local users with preference level of 15, while only Local authentication is configured for the Console login method, the switch can be login without any authentication. When using the HTTP method to login the switch, only users with preference level of 15 can login the switch, users with preference level other than 15 will be denied.
Example:
Configure an administrator account named admin, with the preference level as 15. And configure two normal accounts with its preference level as 1. Then enable local authentication method. Above all the configurations, only the admin user is able to login the switch in privileged mode through Telnet or Console login method, user1 a nd user 2 ca n only log in the switch in normal user mode through the telnet and console login method. For HTTP login method, only the admin user can pass the authentication configuration, user1 and user2 will be denied.
Switch(config)#username admin privilege 15 password 0 admin Switch(config)# username user1 privilege 1 password 7 user1 Switch(config)# username user2 password 0 user2 Switch(config)# authenticat ion line con so le logi n local

1.1.37 web language

Command:
web language {chinese | english}
Function:
Set the language for displaying the HTTP Server information.
Parameter:
chinese for Chinese display; english for English display.
Command mode:
Admin Mode
Default:
The default setting is English display.
Usage Guide:
1-68
XGS3 Command Guide
The user can select the language according to their preference.

1.1.38 write

Command:
write
Function:
Save the currently configured p aram eters to the Flash memory.
Command mode:
Admin Mode.
Usage Guide:
After a set of configuration with desired functions, the setting should be saved to the Flash memory, so that the system can revert to the saved configuration automatically in the case of accidentally powered off or power failure. This is the equivalent to the copy running-config startup-config command.

1.2 Commands for Telnet

1.2.1 authentication ip access-class

Command:
authentication ip access-class {<num-std>|<name>} no authentication ip access-class
Function:
Binding standard IP ACL protocol to login with Telnet/SSH/Web; the no form command will cancel the binding ACL.
Parameters:
<num-std> is the access-class number for standard numeric ACL, ranging between 1-99; <name> is the access-class name for standard ACL, the character string length is ranging between 1-32.
Default:
The binding ACL to Telnet/SSH/Web function is closed by default.
Command Mode:
Global Mode.
Example:
Binding standard IP ACL protocol to access-class 1.
Switch(config)#authentication ip access-class 1 in

1.2.2 authentication ipv6 access-class

1-69
XGS3 Command Guide
Command:
authentication ipv6 access-class {<num-std>|<name>} no authentication ipv6 access-class
Function:
Binding standard IPv6 ACL protocol to login with Telnet/SSH/Web; the no form command will cancel the binding ACL.
Parameters:
<num-std> is the access-class number for standard numeric ACL, ranging between 500-599; <name> is the access-class name for standard ACL, the character string length is ranging between 1-32.
Default:
The binding ACL to Telnet/SSH/Web function is closed by default.
Command Mode:
Global Mode.
Example:
Binding standard IP ACL protocol to access-class 500.
Switch(config)#authenti cat ion i pv 6 acces s-class 500

1.2.3 authentication line login

Command:
authentication line {console | vty | web} login {local | radius | tacacs} no authentication line {console | vty | web} login
Function:
Configure VTY (login with Telnet and SSH), Web and Console, so as to select the priority of the authentication mode for the login user. The no form command restores the default authenti cation mode.
Default:
No configuration is enabled for the console login method by default. Local authentication is enabled for the VTY and Web login method by default.
Command Mode:
Global Mode.
Usage Guide:
The authentication method for Console, VTY and Web login can be configured respectively. And authentication method can be any one or combination of Local, RADIUS or TACACS. When login method is configuration in combination, the preference goes from left to right. If the users have passed the authentication method, authentication method of lower preferences will be ignored. To be mentioned, if the user receives correspond protocol’s answer whether refuse or incept, it will not attempt the next authentication method (Except io n: i f the l ocal authentication method failed, it will attempt the next authentication method); it will attempt the next authentication method if it receives nothing. And AAA function RADIUS server should be configured before the RADIUS configuration method can be used. And TACACS server should be configured before the TACACS configuration
1-70
XGS3 Command Guide
method can be used. The authentication line console login command is exclusive with the “login” command. The authentication line console login command c onfigures the sw itch to us e the Console login method. And the login command makes the Console login to use the passwords configured by the password command for authentication. If local authentication is configured while no local users are configured, users will be able to login the switch via the Console method.
Example:
Configure the remote login authentication mode to radius.
Switch(config)#authentication login r adi us
Relative Command:
aaa enable, radius-server authentication host

1.2.4 authentication securityip

Command:
authentication securityip <ip no authentication securityip <ip-addr>
Function:
To configure the trusted IP address for Telnet and HTTP login method. The no form of this command will remove the trusted IP address configuration.
Parameters:
<ip-addr> is the trusted IP address of the client in dotted decimal format which can login the switch.
Default:
No trusted IP address is configured by default.
Command Mode:
Global Mode.
Usage Guide:
IP address of the client which can login the switch is not restricted before the trusted IP address is not configured. After the trusted IP address is configured, only clients with trusted IP addre ss es are able to login the switch. Up to 32 trusted IP addresses can be configured in the switch.
Example:
To configure 192.168.1.21 as the trusted IP address.
Switch(config)# authenticat ion sec urity ip 192.168.1.21

1.2.5 authentication securityipv6

Command:
1-71
XGS3 Command Guide
authentication securityipv6 <ipv6-addr> no authentication securityipv6 <ipv6-addr>
Function:
To configure the trusted IPv6 address for Telnet and HTTP login method. The no form of this command will remove the specified configuration.
Parameters:
<ipv6-addr> is the trusted IPv6 address which can login the switch.
Default:
No trusted IPv6 addresses are configured by default.
Command Mode:
Global Mode.
Usage Guide:
IPv6 address of the client which can login the switch is not restricted before the trusted IPv6 address is not configured. After the trusted IPv6 address is configu red, only clients with trust ed IPv 6 addresses are able to login the switch. Up to 32 trusted IPv6 addresses can be configured in the switch.
Example:
Configure the secure IPv6 address is 2001:da8:123:1::1.
Switch(config)# authenticat ion sec urity ipv 6 2001:da8:123:1::1

1.2.6 authorization

Command:
uthorization line {console | vty | web} exec {local | radius | tacacs} no authorization line {console | vty | web} exec
Function:
Configure VTY (login with Telnet an d SS H), Web and Console, so as to select the priority of the authorization mode for the login user. The no form command restores the default authorization mode.
Default:
There is no authorization mode.
Command Mode:
Global Mode.
Usage Guide:
The authorization method for Console, VTY and Web login can be configured respectively. And authorization method can be any one or combination of Local, RADIUS or TACACS. When login method is configuration in combination, the preference goes from left to right. If the users have passed the authorization method, authorization method of lower preferences will be ignored. To be mentioned, if the user receives corresponding protocol’s answer whether refuse or incept, it will not attempt the next authorization method; it will attempt the next authorization method if it receives nothing. And AAA function RADIUS server should be configured before the RADIUS configuration method
1-72
XGS3 Command Guide
can be used. And TACACS server should be configured before the TACACS configuration method can be used. The local users adopt username command permission while authorization command is not configured, the users login the switch via RADIUS/TACACS method and works under common mode.
Example:
Configure the telnet authentication mode to RADIUS.
Switch(config)#authorization line vty exec radius

1.2.7 terminal length

Command:
terminal length <0-512> terminal no length
Function:
Set columns of characters displayed in each screen on terminal; the “terminal no length” cancels the screen switching operation and display content once in all.
Parameter:
Columns of characters displayed in each screen, ranging between 0-512 (0 refers to non-stop display).
Command mode:
Admin Mode.
Default:
Default columns is 25.
Usage guide:
Set length of characters displayed in each screen on terminal, so that the-More-message will be shown when displayed information exceeds the screen. Press any key to show information in next screen. Default length is 25.
Example:
Configure treads in each display to 20.
Switch#terminal length 20

1.2.8 terminal monitor

Command:
terminal monitor terminal no monitor
Function:
Copy debugging messages to current display terminal; the “terminal no monitor” command restores to the default value.
Command mode:
1-73
XGS3 Command Guide
Admin Mode.
Usage guide:
Configures whether the current debugging messages is displayed on this terminal. If this command is configured on telnet or SSH clients, debug messages will be sent to that client. The debug message is displayed on console by default.
Example:
Switch#terminal monitor

1.2.9 telnet

Command:
telnet {<ip-addr> | <ipv6-addr> | host <hostname>} [<port>]
Function:
Log on the remote host by Telnet
Parameter:
<ip-addr> is the IP address of the remote host, shown in dotted decimal notation;
<ipv6-addr> is the IPv6 address of the remote host;
<hostname> is the name of the remote host, containing max 30 characters;
<port> is the port number, ranging between 0~65535.
Command Mode:
Admin Mode.
Usage Guide:
This command is used when the switch is applied as Telnet client, for logging on remote host to configure. When a switch is applied as a Telnet client, it can only establish one TCP connection with the remote host. To connect to another remote host, the current TCP connection must be disconnected with a hotkey “CTRL+ \”. To telnet a host name, mapping relationship between the host name and the IP/IPv6 address should be previously configured. For required commands please refer to ip host and ipv6 host. In case a host corresponds to both an IPv4 and an IPv6 addresses, the IPv6 should be preferred when telneting this host name.
Example:
The switch Telnets to a remote host whose IP address is 20.1.1.1.
Switch#telnet 20.1.1.1 23 Connecting Host 20.1.1.1 Port 23 Service port is 23 Connected to 20.1.1.1 login:123 password:*** XGS3>
1-74
XGS3 Command Guide

1.2.10 telnet server enable

Command:
telnet server enable no telnet server enable
Function:
Enable the Telnet server functi on in the switch: the “no tel net serv er enable” command disa bles the Telnet function in the switch.
Default:
Telnet server function is enabled by default.
Command mode:
Global Mode
Usage Guide:
This command is available in Console only. The administrator can use this command to enable or disable the Telnet client to login to the switch.
Example:
Disable the Telnet server function in the switch.
Switch(config)#no telnet server enable

1.2.11 telnet-server max-connection

Command:
telnet-server max-connection {<max-connection-number> | default}
Function:
Configure the max connection number supported by the Telnet service of the switch.
Parameters:
<max-connection-number>: the max connection number supported by the Telnet service, ranging from 5 to 16.
The default option will restore the default configuration.
Default:
The system default value of the max connection number is 5.
Command Mode:
Global Mode
Usage Guide:
None.
Example:
Set the max connection number supported by the Telnet service as 10.
Switch(config)#telnet-server max-connection 10
1-75
XGS3 Command Guide

1.2.12 ssh-server authentication-retries

Command:
ssh-server authentication-retries <authentication-retries> no ssh-server authentication-retries
Function:
Configure the number of times for retrying SSH authentication; the “no ssh-server authentication-retries” command restores the default number of times for retrying SSH authentication.
Parameter:
<authentication-retries > is the number of times for retrying authentication; valid range is 1 to 10.
Command mode:
Global Mode
Default:
The number of times for retrying SSH authentication is 3 by default.
Example:
Set the number of times for retrying SSH authentication to 5.
Switch(config)#ssh-server authentication-retries 5

1.2.13 ssh-server enable

Command:
ssh-server enable no ssh-server enable
Function:
Enable SSH function on the switch; the “no ssh-server enable” command disables SSH function.
Command mode:
Global Mode
Default:
SSH function is disabled by default.
Usage Guide:
In order that the SSH client can log on the switch, the users need to configure the SSH user and enable SSH function on the switch.
Example:
Enable SSH function on the switch.
Switch(config)#ssh-server enable

1.2.14 ssh-server host-key create rsa

1-76
XGS3 Command Guide
Command:
ssh-server host-key create rsa [modulus < modulus >]
Function:
Generate new RSA host key .
Parameter:
modulus is the modulus which is used to compute the host key; valid range is 768 to 2048. The default value is
1024.
Command mode:
Global Mode
Default:
The system uses the key generated when the ssh-server is started at the first time.
Usage Guide:
This command is used to generate the new host key. When SSH client logs on the server, the new host key is used for authentication. After the new host key is generated and “write” command is used to save the configuration, the system uses this key for authentication all the time. Because it takes quite a long time to compute the new key and some clients are not compatible with the key generated by the modulus 2048, it is recommended to use the key which is generated by the default modulus 1024.
Example:
Generate new host key.
Switch(config)#ssh-server host-key create rsa

1.2.15 ssh-server max-connection

Command:
ssh-server max-connection { <max-connection-number>|default}
Function:
Configure the max connection number supported by the SSH service of the switch.
Parameters:
<max-connection-number>: the max connection number supported by the SSH service, ranging from 5 to 16. The
default option will restore the defaul t configuration.
Default:
The system default value of the max connection number is 5.
Command Mode:
Global Mode
Usage Guide:
None.
Example:
Set the max connection number supported by the SSH service as 10.
1-77
XGS3 Command Guide
ssh-server login user number 2
Switch(config)#ssh-server max-connection 10

1.2.16 ssh-server timeout

Command:
ssh-server timeout <timeout> no ssh-server timeout
Function:
Configure timeout value for SSH authentication; the “no ssh-server timeout” command restores the default timeout value for SSH authentication.
Parameter:
<timeout> is timeout value; valid range is 10 to 600 seconds.
Command mode:
Global Mode
Default:
SSH authentication timeout is 180 seconds by default.
Example:
Set SSH authentication timeout to 240 seconds.
Switch(config)#ssh-server timeout 240

1.2.17 show ssh-server

Command:
show ssh-server
Function:
Display SSH state and users which log on currently.
Command mode:
Admin Mode.
Example:
Switch#show ssh-server ssh server is enabled ssh-server timeout 180s ssh-server authentication-retries 3 ssh-server max-connection number 6
1-78
XGS3 Command Guide
aa
Telnet user a login from 192.168.1.20

1.2.18 show telnet login

Command:
show telnet login
Function:
Display the information of th e Telnet client which currently establishes a Telnet connection with the switch.
Command mode:
Admin and Configuration Mode.
Usage Guide:
Check the Telnet client messages connected through Telnet with the switch.
Example:
Switch #show telnet login Authenticate login by local Login user:

1.2.19 who

Command:
who
Command mode:
All configuration modes
Example:
Show the current login users with vty.
Switch #who

1.3 Commands for Configuring Switch IP

1.3.1 interface vlan

Command:
interface vlan <vlan-id> no interface vlan <vlan-id>
Function:
Enter the VLAN interface configuration mode; the no operation of this command will delete the existing VLAN interface.
1-79
XGS3 Command Guide
Switch(Config-if-Vlan1)#
Switch(config)#
Parameters:
<vlan-id> is the VLAN ID of an existing VLAN, ranging from 1 to 4094.
Command Mode:
Global Configuration Mode.
Usage Guide:
Users should first make sure the existence of a VLAN before configuring it. Us er “exit” command to quit the VLAN interface configuration mode back to the globa l confi guration mode.
Example:
Enter the VLAN interface configuration mode of VLAN1.
Switch(config)#interfac e vlan 1

1.3.2 ip address

Command:
ip address <ip-address> <mask> [secondary] no ip address [<ip-address> <mask>] [secondary]
Function:
Set the IP address and mask for the specified VLAN interface; the “no ip address <ip address> <mask> [secondary]” command deletes the specified IP address setting.
Parameter:
<ip-address> is the IP address in dot decimal format; <mask> is the subnet mask in dot decimal format;
[secondary] indicates the IP configured is a secondary IP address.
Default:
No IP address is configured upon switch shipment.
Command mode:
VLAN Interface Mode
Usage Guide:
A VLAN interface must be created first before the user can assign an IP address to the switch.
Example:
Set 10.1.128.1/24 as the IP address of VLAN1 interface.
Switch(config)#interface vlan 1 Switch(Config-if-Vlan1)#ip address 10.1.128.1 255.255.255.0 Switch(Config-if-Vlan1)#exit
Relative Command:
ip bootp-client enable, ip dhcp-client enable
1-80
XGS3 Command Guide

1.3.3 ipv6 address

Command:
ipv6 address <ipv6address | prefix-length> [eui-64] no ipv6 address <ipv6address | prefix-length> [eui-64]
Function:
Configure aggregatable global unicast address, site-local address and link-local address for the interface.
Parameters:
<ipv6address> is the prefix of an IPV6 address; <prefix-length>is the length of the prefix of an IPV6 address, ranging from 3 to 128; eui-64 means that the eui64 interface id of the interface will automatically create an IPV6 address.
Command Mode:
Interface Configuration Mode.
Default
None.
Usage Guide:
The prefix of an IPV6 address should not be a multicast address, or other kinds of IPV6 addresses with specific usage. Different layer-three VLAN interfaces are forbidden to share a same address prefix. As for any global unicast address, the prefix should be limited in the range from 2001:: to 3fff ::,with a length no shorter than 3. And the prefix length of a site-local address or a link-local address should not be shorter than 10.
Examples:
Configure an IPV6 address at the layer-three interface of VLAN1: set the prefix as 2001:3f:ed8::99, the length of which is 64.
Switch(Config-if-Vlan1)#ipv6 address 2001:3f:ed8::99/64

1.3.4 ip bootp-client enable

Command:
ip bootp-client enable no ip bootp-client enable
Function:
Enable the switch to be a BootP Client and obtain IP address and gateway address through BootP negotiation; the “no ip bootp-client enable” command disables the BootP Client function and releases the IP address obtained in BootP.
Default:
BootP client function is disabled by default.
Command mode:
VLAN Interface Mode
1-81
XGS3 Command Guide
Switch(config)#
Switch(config)#
Usage Guide:
Obtaining IP address through BootP, Manual configuration and DHCP are mutually exclusive, enabling any two methods for obtaining IP address is not allowed. Note: To obtain IP address via BootP, a DHCP server or a BootP server is required in the network.
Example:
Get IP address through BootP.
Switch(config)#interface vlan 1 Switch(Config-if-Vlan1)#ip bootp-client enable Switch (Config-if-Vlan1)#exit
Relative command:
ip address, ip dhcp-client enable

1.3.5 ip dhcp-client enable

Command:
ip dhcp-client enable no ip dhcp-client enable
Function:
Enables the switch to be a DHCP client and obtain IP address and gateway address through DHCP negotiation; the “no ip dhcp-client enable” command disables the DHCP client function and releases the IP address obtained in DHCP. Note: To obtain IP address via DHCP, a DHCP server is required in the network.
Default:
the DHCP client function is disabled by default.
Command mode:
VLAN Interface Mode
Usage Guide:
Obtaining IP address by DHCP, Manual configuration and BootP are mutually exclusive, enabling any 2 methods for obtaining an IP address is not allowed.
Example:
Getting an IP address through DHCP.
Switch(config)#interfac e vlan 1 Switch(Config-if-Vlan1)#ip dhcp-client enable Switch(Config-if-Vlan1)#exit
1-82
XGS3 Command Guide

1.4 Commands for SNMP

1.4.1 debug snmp mib

Command:
debug snmp mib no debug snmp mib
Function:
Enable the SNMP mib debugging; the "no debug snmp mib” command disables the debugging.
Command Mode:
Admin Mode.
Usage Guide:
When user encounters problems in applying SNMP, the SNMP debugging is available to locate the problem causes.
Example:
Switch#debug snmp mib

1.4.2 debug snmp kernel

Command:
debug snmp kernel no debug snmp kernel
Function:
Enable the SNMP kernel debugging; the “no debug snmp kernel” command disables the debugging function.
Command Mode:
Admin Mode.
Usage Guide:
When user encounters problems in applying SNMP, the SNMP debugging is available to locate the problem causes.
Example:
Switch#debug snmp kernel

1.4.3 rmon enable

Command:
rmon enable no rmon enable
Function:
1-83
Enable RMON; the “no rmon enable” command disables RMON.
Private MIB OID:1.3.6.1.4.1.6339
Command mode:
Global Mode
Default:
RMON is disabled by default.
Example:
Enable RMON.
Switch(config)#rmon enable
Disable RMON.
Switch(config)#no rmon enabl e

1.4.4 show private-mib oid

Command:
XGS3 Command Guide
show private-mib oid
Function:
Show the original oid of the private mib.
Command mode:
Admin and configuration mode.
Usage Guide:
Check the beginning oid of the private mib by show private-mib oid command.
Example:
Show the original oid of the private mib.
Switch#show private-mib oid

1.4.5 show snmp

Command:
show snmp
Function:
Display all SNMP counter information.
Command mode:
Admin and Configuration Mode.
Example:
Switch#show snmp
1-84
0 SNMP packets input
0 SNMP trap PDUs
snmp packets input
Total number of SNMP packet inputs.
unknown community name
Number of community name error packets.
Number of permission for community name error packets.
encoding errors
Number of encoding error packets.
number of requested variable
Number of variables requested by NMS.
number of altered variables
Number of variables set by NMS.
get-request PDUs
Number of packets received by “get” requests.
Number of packets received by “getnext” requests.
set-request PDUs
Number of packets received by “set” requests.
snmp packets output
Total number of SNMP packet outputs.
too big errors
Number of “Too_ big” error SNMP packets.
maximum packet siz e
Maximum length of SNMP packets.
MIB objects.
0 Bad SNMP version errors 0 Unknown community name
0 Illegal operat i on for com mun ity name supp lie d 0 Encoding errors 0 Number of requested variables 0 Number of altered variables 0 Get-request PDUs 0 Get-next PDUs 0 Set-request PDUs 0 SNMP packets output 0 Too big errors (Max packet size 1500) 0 No such name errors 0 Bad values errors 0 General errors
XGS3 Command Guide
0 Get-response PDUs
Displayed information Explanation
bad snmp version errors Number of version information error packets.
illegal operation for community name supplied
get-next PDUs
no such name errors Number of packets requesting for non-existent
1-85
bad values errors
Number of “Bad_values” error SNMP packets.
general errors
Number of “General_error s” er r or SN MP packets.
response PDUs
Number of response packets s ent.
trap PDUs
Number of Trap p ac kets sent.
SNMP engineID:3138633303f1276c Engine Boots is:1
Displayed Information
Explanation
SNMP engineID
Engine number
Engine Boots
Engine boot counts
Notify View:one
Displayed Information
Explanation

1.4.6 show snmp engineid

Command:
show snmp engineid
Function:
Display the engine ID commands.
Command Mode:
Admin and Configuration Mode.
Example:
XGS3 Command Guide
Switch#show snmp engineid

1.4.7 show snmp group

Command:
show snmp group
Function:
Display the group information comman ds.
Command Mode:
Admin and Configuration Mode.
Example:
Switch#show snmp group
Group Name:initial Security Level:noAuthnoPriv Read View:one Write View:<no writeview specified>
1-86
Group Name
Group name
Security level
Security level
Read View
Read view name
Write View
Write view name
Notify View
Notify view name
<no writeview specified>
No view name specified by the user
Security IP Information:
Displayed information
Description
Community string
Community string
Community access
Community access permission
Trap-rec-address
IP address which is used to receive Trap.

1.4.8 show snmp mib

Command:
show snmp mib
Function:
Display all MIB supported by the switch.
Command Mode:
XGS3 Command Guide
Admin and Configuration Mode.

1.4.9 show snmp status

Command:
show snmp status
Function:
Display SNMP configuration information.
Command mode:
Admin and Configuration Mode.
Example:
Switch#show snmp status
Trap enable RMON enable Community Information: V1/V2c T rap Host Infor mat ion: V3 Trap Host Infor mat ion:
1-87
Trap enable
Enable or disable to send Trap.
SecurityIP
IP address of the NMS which is allowed to access Agent
Row status:active
Displayed Information
Explanation
User name
User name
Engine ID
Engine ID
Priv Protocol
Employed encryption algorithm
Auth Protocol
Employed identification algorithm
Row status
User state
View Name:readview 1. -Included active

1.4.10 show snmp user

Command:
show snmp user
Function:
Display the user information command s.
Command Mode:
Admin and Configuration Mode.
Example:
Switch#show snmp user
XGS3 Command Guide
User name: initialsha Engine ID: 1234567890 Auth Protocol:MD5 Priv Protocol:DES-CBC

1.4.11 show snmp view

Command:
show snmp view
Function:
Display the view information commands.
Command Mode:
Admin and Configuration Mode.
Example:
Switch#show snmp view
1-88
1.3. Excluded active
Displayed Information
Explanation
View Name
View name
1.and1.3.
OID number
Included
The view includes sub trees rooted by this OID
The view does not include sub trees rooted by this OID
active
State
Excluded

1.4.12 snmp-server community

Command:
snmp-server community {ro | rw} <string> [access {<num-std>|<name>}] [ipv6-access {<ipv6-num-std>|<ipv6-name>}] [read <read-view-name>] [write <write-view-name>]
XGS3 Command Guide
no snmp-server community <string> [access {<num-std>|<name>}] [ipv6-access {<ipv6-num-std>|<ipv6-name>}]
Function:
Configure the community string for the switch; the “no snmp-server community <string> [access {<num-std>|<name>}] [ipv6-access {<ipv6-num-std> |<ipv6-name>}] “command deletes the configured
community string.
Parameter:
<string> is the community string set;
ro | rw is the specified access mode to MIB, ro for read-only and rw for read-write.
<num-std> is the access-class number for standard numeric ACL, ranging between 1-99; <name> is the access-class name for standard ACL, the character string length is ranging between 1-32; <ipv6-num-std> is the access-class number for standard numeric IPv6 ACL, ranging between 500-599; <name> is the access-class name for standard IPv6 ACL, the character string length is ranging between 1-32. <read-view-name> is the name of readable view which includes 1-32 charact ers . <write-view-name> is the name of writable view which includes 1-32 characters.
Command mode:
Global Mode
Usage Guide:
The switch supports up to 4 community strings. It can realize the access-control for specifically community view by binding the community name to specifically readable view or writable view.
Example:
Add a community string named “private” with read-write permission.
Switch(config)#snmp-server community rw private
1-89
Add a community string named “public” with read-only permission.
Switch(config)#snmp-server community ro public
Modify the read-write community string named “private” to read-only.
Switch(config)#snmp-server community ro private
Delete community string “private”.
Switch(config)#no snmp-server community private
Bind the read-only community str in g “public” to readable view “pviewr”.
Switch(config)#snmp-server community ro public read pviewr
Bind the read-write community string “private” to readable view “pviewr” and writable view “pvieww”.
Switch(config)#snmp-server community rw private read pviewr write pvieww

1.4.13 snmp-server enable

XGS3 Command Guide
Command:
snmp-server enable no snmp-server enable
Function:
Enable the SNMP proxy server function on the switch. The “no snmp-server enable” command disables the SNMP proxy server function
Command mode:
Global mode
Default:
SNMP proxy server function is disabled by system default.
Usage guide:
To perform configuration management o n th e switch with netw ork mana ge sof t w ar e, t he S N MP proxy server function
has to be enabled with this command.
Example:
Enable the SNMP proxy server function on the swit ch.
Switch(config)#snmp-server enable

1.4.14 snmp-server enable traps

Command:
snmp-server enable traps no snmp-server enable traps
1-90
XGS3 Command Guide
Function:
Enable the switch to sen d Trap message; the “no snmp-serv er enabl e t raps” command disables the switch to se nd Trap message.
Command mode:
Global Mode
Default:
Forbid to send Trap message.
Usage Guide:
When Trap me ss age i s e nab led, if Down/Up in d ev ice ports or of system oc curs , the device will sen d Trap messages to NMS that receives Trap messages.
Example:
Enable to send Trap mes sage s.
Switch(config)#snmp-server enable traps
Disable to send Trap me ssa ge s.
Switch(config)#no snmp-server enable traps

1.4.15 snmp-server engineid

Command:
snmp-server engineid <engine-string> no snmp-server engineid
Function:
Configure the engine ID; the “no" form of this command restores to the default engine ID.
Command Mode:
Global mode
Parameter:
<engine-string> is the engine ID shown in 1-32 digit hex characters.
Default:
Default value is the company ID plus local MAC address.
Usage Guide:
None
Example:
Set current engine ID to A6 66 88999 F
Switch(config)#snmp-ser ver engineid A66688999F
Restore the default engine ID
Switch(config)#no snmp-server engineid
1-91
XGS3 Command Guide

1.4.16 snmp-server group

Command:
snmp-server group <group-string> {NoauthNopriv | AuthNopriv | AuthPriv} [[read <read-string>] [write <write-string>] [notify <notify-string>]] [access {<num-std>|<name>}] [ipv6-access {<ipv6-num-std>|<ipv6-name>}] no snmp-server group <group-string> {NoauthNopriv | AuthNopriv | AuthPriv} [access {<num-std>|<name>}] [ipv6-access {<ipv6-num-std>|<ipv6-name>}]
Function:
This command is used to configure a new group; the “no” form of this command deletes this group.
Command Mode:
Global Mode
Parameter:
<group-string> group name which includes 1-32 characters NoauthNopriv Applies the non recognizing and non encrypting safety level AuthNopriv Applies the recognizing but non encrypting safety level AuthPriv Applies the recognizing and encrypting safety level read-string Name of readable view which includes 1-32 characters write-string Name of writable view which includes 1-32 characters notify-string Name of trappable view which includes 1-32 ch aract ers
<num-std> is the access-class number for standard numeric ACL, ranging between 1-99; <name> is the access-class name for standard ACL, the character string length is ranging between 1-32; <ipv6-num-std> is the access-class number for standard numeric IPv6 ACL, ranging between 500-599; <name> is the access-class name for standard IPv6 ACL, the character string length is ranging between 1-32.
Usage Guide:
There is a default view “v1defaultviewname” in the system. It is recommended to use this view as the view name of
the notification. If the read or write view name is empty, corresponding operation will be disabled.
Example:
Create a group CompanyGroup, with the safety level of recognizing andencrypting, the read viewname isreadview,
and the writing is disabled.
Switch (config)#snmp-server group CompanyGroup AuthPriv read readview
deletet group
Switch (config)#no snmp-server group CompanyGroup AuthPriv

1.4.17 snmp-server host

Command:
snmp-server host { <host-ipv4-address> | <host-ipv6-address> } {v1 | v2c | {v3 {NoauthNopriv | AuthNopriv |
1-92
XGS3 Command Guide
AuthPriv}}} <user-string>
no snmp-server host { <host-ipv4-address> | <host-ipv6-address> } {v1 | v2c | {v3 {NoauthNopriv |
AuthNopriv | AuthPriv}}} <user-string>
Function:
As for the v1/v2c versi ons th is com mand conf igure s the IPv4 or IPv6 address and Trap community character string of
the network manage station receiving the SNMP Trap message. And for v3 version, this command is used for
receiving the network manage st ation IPv4 or IPv6 address and the T r ap user name and saf ety lev el; the “no” form o f
this command cancels this IPv4 or IPv6 address.
Command Mode:
Global Mode.
Parameter:
<host-ipv4-addr> | <host-ipv6-addr> is the IP address of the NMS managing station which receives Trap message.
v1 | v2c | v3 i s the version number when sending the trap. NoauthNopriv | AuthNopriv | AuthPriv is the safety level v3 trap is applied, which may be non encrypted and non
authentication, non encrypted and authentication, encrypted and authentication. <user-string> i s the community character string applied when sending the Trap message at v1/v2, and will be the user name at v3.
Usage Guide:
The Community character string configured in this command is the default community string of the RMON event
group. If the RMON event group has no community character string configured, the community character string
configured in this command w ill be appl ied w hen sendin g the Trap of RMON, and if the community character string i s
configured, its configuration will be applied when sending the RMON trap. This command allows configuration the
IPv4 or IPv6 address of the network manage station receiving the SNMP Trap message, but configure the version
number as v1 and v2c of the IPv4 and IPv6 address are less than 8 in all.
Example:
Configure an IP address to receive Trap
Switch(config)#snmp-server host 1.1.1.5 v1 usertrap
Delete a Trap receiv in g IPv6 address
Switch(config)#no snmp-server host 2001:1:2:3::1 v1 usertrap

1.4.18 snmp-server securityip

Command:
snmp-server securityip {<ipv4-address> | <ipv6-address>} no snmp-server securityip {<ipv4-address> | <ipv6-address>}
Function:
Configure to permit to access security IPv4 or IPv6 address of the switch NMS administration station; the no
1-93
XGS3 Command Guide
command deletes configured security IPv4 or IPv6 address.
Command Mode:
Global Mode.
Parameter:
<ipv4-address> is NMS security IPv4 address, point separated decimal format. <ipv6-address> is NMS security IPv6 address, colon separated hex format.
Usage Guide:
It is only the consistency between NMS administration station IPv4 or IPv6 address and security IPv4 or IPv6
address configured by the command, so it send SNMP packet could be processed by switch, the c ommand only
applies to SNMP. Allows configuration the IPv4 or IPv6 address of the network manage station receiving the SNMP
Trap message, but the IP addresses are less than 6 in all.
Example:
Configure security IP address of NMS administration station
Switch(config)#snmp-server securityip 1.1.1.5
Delete security IPv6 address
Switch(config)#no snmp-server securityip 2001::1

1.4.19 snmp-server securityip

Command:
snmp-server securityip {enable | disable}
Function:
Enable/disable the safety IP address authentication on NMS manage station.
Command Mode:
Global Mode
Default:
Enable the safety IP address authentication function.
Example:
Disable the safety IP address authentication function.
Switch(config)#snmp-server securityip disable

1.4.20 snmp-server trap-source

Command:
snmp-server trap-source {<ipv4-address> | <ipv6-address>}
no snmp-server trap-source {<ipv4-address> | <ipv6-address>}
1-94
XGS3 Command Guide
Function:
Set the source IPv4 or IPv6 address which is used to send trap packet, the no command deletes the configuration.
Command Mode:
Global Mode
Parameter:
<ipv4-address>: IPv4 address is used to send trap packet in dotted decimal notation
<ipv6-address>: IPv6 address is used to send trap packet in colon hexadecimal.
Usage Guide:
If there is no configuration, select the source address according to the interface address sent by actual trap packet,
when configure the IP address, adopt the configured source address as the source address of trap packet.
Example:
Set the IP address which is used to send trap packet.
Switch(config)# snmp-server trap-source 1.1.1.5
Delete the configured source address which is used to send IPv6 trap packet.
Switch(config)# no snmp-server trap-source 2001::1

1.4.21 snmp-server user

Command:
snmp-server user <use-string> <group-string> [{authPriv | authNoPriv} auth {md5 | sha} <word>] [access
{<num-std>|<name>}] [ipv6-access {<ipv6-num-std>|<ipv6-name>}]
no snmp-server user <user-string> [access {<num-std>|<name>}] [ipv6-access
{<ipv6-num-std>|<ipv6-name>}]
Function:
Add a new user to an SNMP group; the "no” form of this command deletes this user.
Command Mode:
Global Mode.
Parameter:
<user-string> is the user name containing 1-32 characters.
<group-string> is the name of the group the user belongs to, containing 1-32 characters.
authPriv use DES for the packet encryption. authNoPriv not use DES for the packet encryption. auth perform packet authentication. md5 packet authentication using HMAC MD5 algorithm. sha packet authentication using HMAC SHA algorithm.
<word > user password, containing 8-32 character. <num-std> is the access-class number for standard numeric ACL, ranging between 1-99;
1-95
XGS3 Command Guide
<name> is the access-class name for standard ACL, the character string length is ranging between 1-32; <ipv6-num-std> is the access-class number for standard numeric IPv6 ACL, ranging between 500-599; <name> is the access-class name for standard IPv6 ACL, the character string length is ranging between 1-32.
Usage Guide:
If the encryption and a ut he nti c ation is not selected, the defau lt s et tin gs will be no encryption and no authentication. If
the encryption is selected, the authentication must be done. When deleting a user, if correct username and incorrect
group name is inputted, the user can still be deleted.
Example:
Add a new user tester in the UserGroup with an encryption safety level and HMAC md5 for authentication, the
password is hellohello
Switch (config)#snmp-server user tester UserGroup authPriv auth md5 hellohello
deletes an User
Switch (config)#no snmp-server user tester

1.4.22 snmp-server view

Command:
snmp-server view <view-string> <oid-string> {include | exclude}
no snmp-server view <view-string> [ <oid-string> ]
Function:
This command is used to create or renew the view information; the “no" form of this command deletes the view
information.
Command Mode:
Global Mode.
Parameter:
<view-string> view name, contain ing 1-32 characters.
<oid-string>is OID number or corresponding node name, containing 1-255 characters.
include | exclude, include/exclude this OID.
Usage Guide:
The command supports not only the input using the character string of the variable OID as parameter. But also
supports the input using the node name of the parameter.
Example:
Create a view, the name is readview, including iso node but not including the iso.3 node
Switch (config)#snmp-server view readview iso include Switch (config)#snmp-server view readview iso.3 exclude
Delete the view
1-96
XGS3 Command Guide
Keywords
Source or destination addresses
running-config
Running configuration fil es
startup-config
Startup configuration files
nos.img
System files
nos.rom
System startup files
Switch (config)#no snmp-server view readview

1.5 Commands for Sw itch Upgrad e

1.5.1 copy（FTP）

Command:
copy <source-url> <destination-url> [ascii | binary]
Function:
Download files to the FTP client.
Parameter:
<source-url> is the location of the source files or directories to be copied;
<destination-url> is the destinatio n addres s to which the files or dir ectorie s to be c opied; forms of <source-url> and
<destination-url> vary depending on different locations of the files or directories.
ascii indicates the ASCII standard will be adopted;
binary indicates that the bin ary system w ill be adopted in the file transmission （def ault tr ansmi ssion method）.When
URL represents an FTP address, its form should be:
ftp://<username>:<password>@{<ipaddress>|<ipv6address>|<hostname> }/<filename>,amongst <username> is the
FTP user name,<password> is the FTP user passwor d,<ipaddress>|<ipv6address> is the IPv4 or IPv6 address of
the FTP server/client,<hostname> is the name of the host mapping with the IPv6 address,it does not support the file
download and upload with hosts mapping with IPv4 addresses,<filename> is the name of the FTP upload/download
file.
Special keywords of the filename
Command Mode:
Admin Mode.
Usage Guide:
This command supports command line hints, namely if the user can enter commands in following forms: copy <filename> ftp:// or copy ftp:// <filename> and press Enter, following hints will be provided by the system：
ftp server ip/ipv6 address [x.x.x.x]/[x:x::x:x] > ftp username> ftp password>
1-97
XGS3 Command Guide
Keywords
Source or destination addresses
running-config
Running configuration files
startup-config
Startup configuration files
ftp filename> Requesting for FTP server address, user name, password and file name
Examples:
(1) Save images in the FLA SH to the FTP server of 10.1.1.1, FTP server userna me is Switch, password is s uperuser
Switch#copy nos.img ftp://Switch:superuser@10.1.1.1/nos.img
(2) Obtain system file nos.img from the FTP server 10.1.1.1, the username is Switch, password is superuser
Switch#copy ftp://Switch:superuser@10.1.1.1/nos.img nos.img
(3) Save images in the FLASH to the FTP server of 2004:1:2:3::6
Switch#copy nos.img ftp://username:password@2004:1:2:3::6/ nos.img
(4) Obtain system file nos.img from the FTP server 2004:1:2:3::6
Switch#copy ftp:// userna me:password@2004:1:2:3:: 6/nos.img nos.img
(5) Save the running configuration files
Switch#copy running-config startup-config
Relevant Command:
Write

1.5.2 copy（TFTP）

Command:
copy <source-url> <destination-url> [ascii | binary]
Function:
Download files to the TFTP client.
Parameter:
<source-url> is the location of the source files or directories to be copied;
<destination-url> is the destinatio n addres s to w hich the files or di rect ories to be copi ed; forms of <source-url> and
<destination-url> vary depending on different locations of the files or directories.
ascii indicates the ASCII standard will be adopted;
binary indicates that the bin ary system w ill be adopted in the file tran smissio n（default transmission method）.When
URL represents an TFTP address, its form should be: tftp://{<ipaddress>|<ipv6address>|<hostname>}/<filename>,
amongst <ipaddress>| <ipv6address> is the IPv4 or IPv6 address of the TFTP server/client, <hostname> is the
name of the host mapping with the IPv6 address, it does not support the file download and upload with hosts
mapping with IPv4 addresses,<filename> is the name of the TFTP upload/download file.
Special keyword of the filename
1-98
XGS3 Command Guide
nos.img
System files
nos.rom
System startup files
Command Mode:
Admin Mode.
Usage Guide:
This command supports command line hints, namely if the user can enter commands in following forms: copy <filename> tftp:// or copy tftp:// <filename> and press Enter, following hints will be provided by the system: tftp server ip/ipv6 address[x.x.x.x]/[x:x::x:x]> tftp filename> Requesting for TFTP server address, file name
Example:
(1) Save images in the FLASH to the TFTP server of 10.1.1.1
Switch#copy nos.img tftp://10.1.1.1/nos.img
(2) Obtain system file nos.img from the TFTP server 10.1.1.1
Switch#copy tftp://10. 1 .1.1 / no s .img no s.i mg
(3) Save images in the FLASH to the TFTP server of 2004:1:2:3::6
Switch#copy nos.img tftp:// 2004:1:2:3::6/ nos.img
(4) Obtain system file nos.img from the TFTP server 2004:1:2:3::6
Switch#copy tftp:// 2004:1:2:3::6/nos.img nos.img
(5) Save the running configuration files
Switch#copy running-config startup-config
Relevant Command:
Write

1.5.3 ftp-dir

Command:
ftp-dir <ftp-server-url>
Function:
Browse the file list on the FTP server.
Parameter:
The form of <ftp-server-url> is： ftp://<username>:<password>@{ <ipv4address> | <ipv6address> }, amongst
<username> is the FTP user name, <password> is the FTP user password, { <ipv4address> | <ipv6address> } is the
IPv4 or IPv6 address of the FTP server.
Command Mode:
Admin Mode
1-99
XGS3 Command Guide
Example:
Browse the list of the files on the server with the FTP client, the username is “Switch”, the password is “superuser”
Switch#ftp-dir ftp://Switch:superuser @10.1.1.1.

1.5.4 ftp-ser ver enable

Command:
ftp-server enable
no ftp-server enable
Function:
Start FTP server, the “no ftp-server enable” command shuts down FTP server and prevents FTP user from logging
in.
Default:
FTP server is not started by default.
Command mode:
Global Mode
Usage Guide:
When FTP server function is enabled, the switch can still perform ftp client functions. FTP server is not started by
default.
Example:
enable FTP server service.
Switch#config Switch(config)# ftp-server enable
Relative command:
ip ftp

1.5.5 ftp-ser ver timeout

Command:
ftp-server timeout <seconds>
Function:
Set data connection idle time.
Parameter:
<seconds> is the idle time threshold (in seconds) for FTP connection, the valid range is 5 to 3600.
Default:
The system default is 600 seconds.
Command mode:
1-100
