Copyright 2014 by PLANET Technology Corp. All rights reserved. No part of this publication may be
reproduced, transmitted, transcribed, stored in a retrieval system, or translated into any language or
computer language, in any form or by any means, electronic, mechanical, magnetic, optical, chemical,
manual or otherwise, without the prior written permission of PLANET.
PLANET makes no representations or warranties, either expressed or implied, with respect to the
contents hereof and specifically disclaims any warranties, merchantability or fitness for any particular
purpose. Any software described in this manual is sold or licensed "as is". Should the programs prove
defective following their purchase, the buyer (and not PLANET, its distributor, or its dealer) assumes
the entire cost of all necessary servicing, repair, and any incidental or consequential damages resulting
from any defect in the software. Further, PLANET reserves the right to revise this publication and to
make changes from time to time in the contents hereof without obligation to notify any person of such
revision or changes.
All brand and product names mentioned in this manual are trademarks and/or registered trademarks of
their respective holders.
Federal Communication Commission Interference Statement
This equipment has been tested and found to comply with the limits for a Class B digital
device, pursuant to Part 15 of FCC Rules. These limits are designed to provide reasonable
protection against harmful interference in a residential installation. This equipment
generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance
with the instructions, may cause harmful interference to radio communications. However, there is no
guarantee that interference will not occur in a particular installation. If this equipment does cause
harmful interference to radio or television reception, which can be determined by turning the equipment
off and on, the user is encouraged to try to correct the interference by one or more of the following
measures:
1.
Reorient or relocate the receiving antenna.
2. Increase the separation between the equipment and receiver.
3. Connect the equipment into an outlet on a circuit different from that to which the receiver is
connected.
4. Consult the dealer or an experienced radio technician for help.
FCC Caution
To assure continued compliance, use only shielded interface cables when connecting to computer or
peripheral devices. Any changes or modifications not expressly approved by the party responsible
for compliance could void the user’s authority to operate the equipment.
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two
conditions:
(1) This device may not cause harmful interference
(2) This device must accept any interference received, including interference that may cause undesired
operation.
Any changes or modifications not expressly approved by the party responsible for compliance could
void the user’s authority to operate the equipment.
I
Federal Communication Commission (FCC) Radiation Exposure Statement
This equipment complies with FCC radiation exposure set forth for an uncontrolled environment. In
order to avoid the possibility of exceeding the FCC radio frequency exposure limits, human proximity
to the antenna shall not be less than 20 cm (8 inches) during normal operation.
R&TTE Compliance Statement
This equipment complies with all the requirements of DIRECTIVE 1999/5/CE OF THE EUROPEAN
PARLIAMENT AND THE COUNCIL OF 9 March 1999 on radio equipment and telecommunication
terminal equipment and the mutual recognition of their conformity (R&TTE). The R&TTE Directive
repeals and replaces in the directive 98/13/EEC (Telecommunications Terminal Equipment and
Satellite Earth Station Equipment) as of April 8, 2000.
Safety
This equipment is designed with the utmost care for the safety of those who install and use it.
However, special attention must be paid to the dangers of electric shock and static electricity when
working with electrical equipment. All guidelines of this and of the computer manufacture must
therefore be allowed at all times to ensure the safe use of the equipment.
National Restrictions
This device is intended for home and office use in all EU countries (and other countries following the EU
directive 1999/5/EC) without any limitation except for the countries mentioned below:
Country Restriction Reasons/remarks
Bulgaria None
Outdoor use; limited to 10
France
Italy None
Luxembourg None
Norway Implemented
Russian
Federation
mW e.i.r.p. within the band
2454-2483.5 MHz
None Only for indoor applications
General authorization required for outdoor use and
public service
Military Radiolocation use. Refarming of the 2.4 GHz
band has been ongoing in recent years to allow current
relaxed regulation. Full implementation planned 2012
If used outside of own premises, general authorization is
required
General authorization required for network and service
supply(not for spectrum)
This subsection does not apply for the geographical area
within a radius of 20 km from the centre of Ny-Ålesund
Note: Please don’t use the product outdoors in France.
WEEE regulation
To avoid the potential effects on the environment and human health as a result of the
presence of hazardous substances in electrical and electronic equipment, end users of
electrical and electronic equipment should understand the meaning of the crossed-out
wheeled bin symbol. Do not dispose of WEEE as unsorted municipal waste and have to
collect such WEEE separately.
II
Revision
User Manual of PLANET 1750Mbps 802.11ac Dual Band Wall Mount Wireless Access Point
EAP-SIM/MAC Authentication)
Wireless MAC address filtering, up to 256 entries
Supports WPS (Wi-Fi Protected Setup)
Enable/ Disable SSID Broadcast
WMM (Wi-Fi Multimedia), Max. Associated Station Number
Multiple SSIDs: up to 16 at 2.4GHz and 16 at 5GHz
Wireless Isolation: Enable it to isolate each connected wireless client
from communicating with each other
WLAN L2 isolation (AP mode)
Provides wireless statistics
Tx power control adjustment by %: 10%, 25%, 50%, 75%, 90%, 100%
Auto-channel: Automatically selecting lease congested channel
Wired: 253
2.4GHz Wireless: 50
5GHz Wireless: 50
LAN
System Management
Built-in DHCP server supporting static IP address distribution
Supports UPnP
Supports 802.1Q VLAN, SSID and Ethernet port-based tag/untag
VID from 1~4094
Web-based (HTTP/HTTPS) management interface
SNMP v1,v2c,v3
SNTP synchronization
Firmware upgrade via WEB, USB and FTP
Supports scheduling reboot
Supports Smart Discovery Utility*
Local RADIUS: Radius server built-in with 256 accounts support
-10-
User Manual of WDAP-1750AC
Standards Conformance
IEEE 802.11ac (draft 2.0, 3T3R, up to 1300Mbps)
IEEE 802.11n (3T3R, up to 450Mbps)
IEEE 802.11g
IEEE 802.11b
Please follow the instructions below to connect WDAP-1750AC to the existing network devices and your
computers.
2.1 Product Outlook
Dimensions: (W x D x H)
182 x 30 x 182 mm
Weight :
470g
Figure 2-1 WDAP-1750AC
-12-
2.1.1 Panel Layout
Figure 2-2 shows the hardware interface of the WDAP-1750AC.
Hardware Interface
User Manual of WDAP-1750AC
2.1.2 Hardware Description
Port definition
Object Description
12V DC
LAN1
(PoE In)
LAN2
(PoE Out)
USB
Eject
Console
12V DC port to connect the power adapter
LAN port with IEEE 802.3at Power over Ethernet (PoE) to power on the device.
LAN port with IEEE 802.3af Power over Ethernet (PoE) OUT to supply power to
the POE IP-CAM.
USB Port for system log
Eject an attached USB device
Connect a management console
Figure 2-2 WDAP-1750AC Panel Layout
Reset
WPS
Power On/Off
To restore to the factory default setting, press and hold the Reset Button over 7
seconds, and then release it.
Wi-Fi Protected Setup (WPS) button
Switch the access point on/off
-13-
LED definition
LED STATUS FUNCTION
User Manual of WDAP-1750AC
Off
Blue
The access point is off.
The access point is on.
Amber The access point is starting up.
Flashing Amber
The access point cannot establish a connection to the network.
The access point is experiencing a problem of starting up. The
Flashing Amber and Blue
access point will restart.
-14-
User Manual of WDAP-1750AC
Chapter 3. Connecting to the AP
3.1 System Requirements
Broadband Internet Access Service (Cable/xDSL/Ethernet connection)
One IEEE 802.3at PoE switch (supply power to the WDAP-1750AC)
PCs with a working Ethernet Adapter and an Ethernet cable with RJ45 connectors
PCs running Windows 98/ME, NT4.0, 2000/XP, Windows Vista / Win 7, MAC OS 9 or later, Linux,
UNIX or other platforms are compatible with TCP/IP protocols
1. The AP in the following instructions refers to PLANET WDAP-1750AC.
2. It is recommended to use Internet Explore 7.0 or above to access the AP.
3.2 Installing the AP
Before installing the AP, make sure your PoE switch is connected to the Internet through the broadband service
successfully at this moment. If there is any problem, please contact your local ISP. After that, please install the
AP according to the following steps. Don't forget to pull out the power plug and keep your hands dry.
Step 1. Attach the two magnetic wall-mount strips to your wall using the included screws, as shown below..
Figure 3-1 WDAP-1750AC Installation Diagram 1
-15-
User Manual of WDAP-1750AC
Step 2. Fasten the antennas to the antenna connectors. And you can bend the antennas to fit your actual
needs.
Figure 3-2 WDAP-1750AC Installation Diagram 2
Step 3. Method A - Power socket nearby
Connect he power adapter to the access point’s 12V DC port and plug the power adapter into a power
source.
Method B – Hard to find the power socket
Plug the RJ45 Ethernet cable into the PoE port of the WDAP-1750AC and the other end of Ethernet
cable into the PoE switch.
Method A - Power socket nearby
-16-
Method B - Hard to find the power socket
Figure 3-3 WDAP-1750AC Installation Diagram 3
User Manual of WDAP-1750AC
-17-
User Manual of WDAP-1750AC
Chapter 4. Quick Installation Guide
This chapter will show you how to configure the basic functions of your AP within minutes.
A computer with wired Ethernet connection to the Wireless AP is required for the first-time
configuration.
4.1 Manual Network Setup - TCP/IP Configuration
The default IP address of the WDAP-1750AC is 192.168.1.253. And the default Subnet Mask is 255.255.255.0.
These values can be changed as you want. In this guide, we use all the default values for description.
Connect the WDAP-1750AC with your PC by an Ethernet cable plugging in LAN port on one side and in LAN
port of PC on the other side. Please power on the WDAP-1750AC by PoE switch through the PoE port.
In the following sections, we’ll introduce how to install and configure the TCP/IP correctly in Windows 7. And the
procedures in other operating systems are similar. First, make sure your Ethernet Adapter is working, and refer
to the Ethernet adapter manual if needed.
4.1.1 Configuring the IP Address Manually
Summary:
Set up the TCP/IP Protocol for your PC.
Configure the network parameters. The IP address is 192.168.1.xxx (if the default IP address of the
WDAP-1750AC is 192.168.1.253, and the DSL router is 192.168.1.254, the "xxx" can be configured to
any number from 1 to 252), Subnet Mask is 255.255.255.0.
1 Select Use the following IP address radio button, and then configure the IP address of the PC.
2 For example, as the default IP address of the WDAP-1750AC is 192.168.1.253 and the DSL router is
192.168.1.254, you may choose from 192.168.1.1 to 192.168.1.252.
-18-
User Manual of WDAP-1750AC
Figure 4-1 TCP/IP Setting
Now click OK to save your settings.
Now, you can run the ping command in the command prompt to verify the network connection between your
PC and the AP. The following example is in Windows 7 OS. Please follow the steps below:
1. Click on Start > Run.
2. Type “cmd” in the Search box.
Figure 4-2 Windo
-19-
ws Start Menu
User Manual of WDAP-1750AC
3. Open a command prompt, type ping 192.168.1.253 and then press Enter.
If the result displayed is similar to Figure 4-3, it means the connection between your PC and the AP
has been established well.
Figure 4-3 Successful Result of Ping Command
If the result displayed is similar to Figure 4-4, it means the connection between your PC and the AP
has failed.
Figure 4-4 Failed Result of Ping Command
If the address is 0.0.0.0, check your adapter installation, security settings, and the settings on your AP. Some
firewall software programs may block a DHCP request on newly installed adapters.
-20-
