User’s Manual of IGS-801M
Trademarks
Copyright © PLANET Technology Corp. 2015.
Contents are subject to revision without prior notice.
PLANET is a registered trademark of PLANET Technology Corp. All other trademarks belong to their respective owners.
Disclaimer
PLANET Technology does not warrant that the hardware will work properly in all environments and applications, and makes no
warranty and representation, either implied or expressed, with respect to the quality, performance, merchantability, or fitness for
a particular purpose. PLANET has made every effort to ensure that this User's Manual is accurate; PLANET disclaims liability
for any inaccuracies or omissions that may have occurred.
Information in this User's Manual is subject to change without notice and does not represent a commitment on the part of
PLANET. PLANET assumes no responsibility for any inaccuracies that may be contained in this User's Manual. PLANET makes
no commitment to update or keep current the information in this User's Manual, and reserves the right to make improvements to
this User's Manual and/or to the products described in this User's Manual, at any time without notice.
If you find information in this manual that is incorrect, misleading, or incomplete, we would appreciate your comments and
suggestions.
FCC Warning
This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to Part 15 of the FCC
Rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated
in a commercial environment. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and
used in accordance with the Instruction manual, may cause harmful interference to radio communications. Operation of this
equipment in a residential area is likely to cause harmful interference in which case the user will be required to correct the
interference at his own expense.
CE Mark Warning
This is a Class A product. In a domestic environment, this product may cause radio interference, in which case the user may be
required to take adequate measures.
Energy Saving Note of the Device
This power required device does not support Standby mode operation. For energy saving, please remove the power cable to
disconnect the device from the power circuit. In view of saving the energy and reducing the unnecessary power consumption, it
is strongly suggested to remove the power connection for the device if this device is not intended to be active.
WEEE Warning
To avoid the potential effects on the environment and human health as a result of the presence of hazardous
substances in electrical and electronic equipment, end users of electrical and electronic equipment should
understand the meaning of the crossed-out wheeled bin symbol. Do not dispose of WEEE as unsorted
municipal waste and have to collect such WEEE separately.
Revision
PLANET IGS-801M User's Manual
Model: IGS-801M
Revision: 2.0 (July, 2015)
Part No: EM-IGS-801M_v2.0
2
User’s Manual of IGS-801M
TABLE OF CONTENTS
1. INTRODUCTION.................................................................................................................. 10
1.1 Packet Contents .........................................................................................................................................10
1.2 Product Description................................................................................................................................... 11
1.3 How to Use This Manual............................................................................................................................12
1.4 Product Features........................................................................................................................................13
1.5 Product Specifications ..............................................................................................................................16
2. INSTALLATION ................................................................................................................... 19
2.1 Hardware Description ................................................................................................................................19
2.1.1 Switch Front Panel ..............................................................................................................................................19
2.1.2 LED Indications ...................................................................................................................................................20
2.1.3 Switch Upper Panel .............................................................................................................................................21
2.1.4 Wiring the Power Inputs.......................................................................................................................................21
2.1.5 Wiring the Fault Alarm Contact............................................................................................................................22
2.2 Mounting Installation .................................................................................................................................24
2.2.1 DIN-Rail Mounting ...............................................................................................................................................24
2.2.2 Wall Mount Plate Mounting..................................................................................................................................25
3. SWITCH MANAGEMENT .................................................................................................... 27
3.1 Requirements..............................................................................................................................................27
3.2 Management Access Overview.................................................................................................................28
3.3 Web Management.......................................................................................................................................29
3.4 SNMP-based Network Management.........................................................................................................30
3.5 PLANET Smart Discovery Utility ..............................................................................................................30
4. WEB CONFIGURATION...................................................................................................... 33
4.1 Main Web Page ...........................................................................................................................................36
4.1.1 Save Button .........................................................................................................................................................37
4.1.2 Configuration Manager ........................................................................................................................................38
4.1.2.1 Saving Configuration .................................................................................................................................39
4.2 System.........................................................................................................................................................40
3
User’s Manual of IGS-801M
4.2.1 System Information..............................................................................................................................................40
4.2.2 IP Configurations .................................................................................................................................................41
4.2.3 IPv6 Configuration ...............................................................................................................................................43
4.2.4 User Configuration...............................................................................................................................................45
4.2.5 Time Settings.......................................................................................................................................................46
4.2.5.1 System Time..............................................................................................................................................46
4.2.5.2 SNTP Server Settings ...............................................................................................................................49
4.2.6 Log Management.................................................................................................................................................50
4.2.6.1 Local Log...................................................................................................................................................50
4.2.6.2 Local Log...................................................................................................................................................51
4.2.6.3 Remote Syslog ..........................................................................................................................................52
4.2.6.4 Log Message .............................................................................................................................................54
4.2.7 SNMP Management ............................................................................................................................................56
4.2.7.1 SNMP Overview ........................................................................................................................................56
4.2.7.2 SNMP System Information ........................................................................................................................57
4.2.7.3 SNMP View ...............................................................................................................................................57
4.2.7.4 SNMP Access Group.................................................................................................................................59
4.2.7.5 SNMP Community .....................................................................................................................................61
4.2.7.6 SNMP User................................................................................................................................................62
4.2.7.7 SNMPv1, 2 Notification Recipients ............................................................................................................ 64
4.2.7.8 SNMPv3 Notification Recipients ................................................................................................................ 65
4.2.7.9 SNMP Engine ID .......................................................................................................................................66
4.2.7.10 SNMP Remote Engine ID........................................................................................................................67
4.3 Port Management .......................................................................................................................................69
4.3.1 Port Configuration................................................................................................................................................69
4.3.2 Port Counters ......................................................................................................................................................71
4.3.3 Bandwidth Utilization ...........................................................................................................................................76
4.3.4 Port Mirroring.......................................................................................................................................................77
4.3.5 Jumbo Frame ......................................................................................................................................................79
4.3.6 Port Error Disabled Configuration ........................................................................................................................80
4.3.7 Port Error Disabled ..............................................................................................................................................82
4.3.8 Protected Ports....................................................................................................................................................82
4.3.9 EEE .....................................................................................................................................................................85
4.4 Link Aggregation........................................................................................................................................87
4.4.1 LAG Setting .........................................................................................................................................................89
4.4.2 LAG Management ...............................................................................................................................................90
4.4.3 LAG Port Setting..................................................................................................................................................91
4.4.4 LACP Setting .......................................................................................................................................................93
4.4.5 LACP Port Setting................................................................................................................................................94
4
User’s Manual of IGS-801M
4.4.6 LAG Status ..........................................................................................................................................................95
4.5 VLAN............................................................................................................................................................98
4.5.1 VLAN Overview ...................................................................................................................................................98
4.5.2 IEEE 802.1Q VLAN .............................................................................................................................................99
4.5.3 Management VLAN ...........................................................................................................................................103
4.5.4 Create VLAN .....................................................................................................................................................104
4.5.5 Interface Settings...............................................................................................................................................105
4.5.6 Port to VLAN......................................................................................................................................................109
4.5.7 Port VLAN Membership ..................................................................................................................................... 110
4.5.8 Protocol VLAN Group Setting ............................................................................................................................ 111
4.5.9 Protocol VLAN Port Setting ...............................................................................................................................113
4.5.10 GVRP Setting ..................................................................................................................................................114
4.5.11 GVRP Port Setting........................................................................................................................................... 116
4.5.12 GVRP VLAN .................................................................................................................................................... 117
4.5.13 GVRP Statistics ...............................................................................................................................................118
4.5.14 VLAN setting example: ....................................................................................................................................120
4.5.14.1 Two separate 802.1Q VLANs ................................................................................................................120
4.5.14.2 VLAN Trunking between two 802.1Q aware switches ...........................................................................123
4.6 Spanning Tree Protocol ...........................................................................................................................126
4.6.1 Theory ...............................................................................................................................................................126
4.6.2 STP Global Settings ..........................................................................................................................................133
4.6.3 STP Port Setting................................................................................................................................................135
4.6.4 CIST Instance Setting........................................................................................................................................138
4.6.5 CIST Port Setting...............................................................................................................................................140
4.6.6 MST Instance Configuration ..............................................................................................................................142
4.6.7 MST Port Setting ...............................................................................................................................................144
4.6.8 STP Statistics ....................................................................................................................................................146
4.7 Multicast....................................................................................................................................................147
4.7.1 Properties ..........................................................................................................................................................147
4.7.2 IGMP Snooping .................................................................................................................................................148
4.7.2.1 IGMP Setting ...........................................................................................................................................152
4.7.2.2 IGMP Querier Setting ..............................................................................................................................154
4.7.2.3 IGMP Static Group...................................................................................................................................155
4.7.2.4 IGMP Group Table...................................................................................................................................156
4.7.2.5 IGMP Router Setting ...............................................................................................................................157
4.7.2.6 IGMP Router Table..................................................................................................................................158
4.7.2.7 IGMP Forward All ....................................................................................................................................159
4.7.3 IGMP Snooping Statics......................................................................................................................................160
4.7.4 MLD Snooping...................................................................................................................................................162
5
User’s Manual of IGS-801M
4.7.4.1 MLD Setting.............................................................................................................................................162
4.7.4.2 MLD Static Group ....................................................................................................................................164
4.7.4.3 MLD Group Table ....................................................................................................................................165
4.7.4.4 MLD Router Setting .................................................................................................................................165
4.7.4.5 MLD Router Table....................................................................................................................................167
4.7.4.6 MLD Forward All......................................................................................................................................168
4.7.5 MLD Snooping Statics .......................................................................................................................................169
4.7.6 Multicast Throttling Setting ................................................................................................................................171
4.7.7 Multicast Filter ...................................................................................................................................................172
4.7.7.1 Multicast Profile Setting ........................................................................................................................... 173
4.7.7.2 IGMP Filter Setting ..................................................................................................................................174
4.7.7.3 MLD Filter Setting....................................................................................................................................175
4.8 Quality of Service .....................................................................................................................................177
4.8.1 Understanding QoS ...........................................................................................................................................177
4.8.2 General..............................................................................................................................................................178
4.8.2.1 QoS Properties ........................................................................................................................................178
4.8.2.2 QoS Port Settings....................................................................................................................................179
4.8.2.3 Queue Settings........................................................................................................................................180
4.8.2.4 CoS Mapping...........................................................................................................................................181
4.8.2.5 DSCP Mapping........................................................................................................................................183
4.8.2.6 IP Precedence Mapping ..........................................................................................................................184
4.8.3 QoS Basic Mode................................................................................................................................................186
4.8.3.1 Global Settings ........................................................................................................................................186
4.8.3.2 Port Settings............................................................................................................................................187
4.8.4 Rate Limit ..........................................................................................................................................................188
4.8.4.1 Ingress Bandwidth Control ......................................................................................................................188
4.8.4.2 Egress Bandwidth Control .......................................................................................................................189
4.8.4.3 Egress Queue .........................................................................................................................................190
4.8.5 Voice VLAN .......................................................................................................................................................191
4.5.8.1 Introduction to Voice VLAN......................................................................................................................191
4.8.5.2 Properties ................................................................................................................................................191
4.8.5.3 Telephony OUI MAC Setting....................................................................................................................193
4.8.5.4 Telephony OUI Port Setting.....................................................................................................................195
4.9 Security .....................................................................................................................................................197
4.9.1 802.1X ...............................................................................................................................................................197
4.9.1.1 Understanding IEEE 802.1X Port-based Authentication..........................................................................198
4.9.1.2 802.1X Setting .........................................................................................................................................201
4.9.1.3 802.1X Port Setting .................................................................................................................................202
4.9.1.4 Guest VLAN Setting ................................................................................................................................204
6
User’s Manual of IGS-801M
4.9.1.5 Authenticated Host ..................................................................................................................................206
4.9.2 RADIUS Server .................................................................................................................................................207
4.9.3 TACACS+ Server...............................................................................................................................................210
4.9.4 AAA ...................................................................................................................................................................212
4.9.4.1 Login List .................................................................................................................................................213
4.9.4.2 Enable List...............................................................................................................................................214
4.9.5 Access ...............................................................................................................................................................215
4.9.5.1 Telnet.......................................................................................................................................................215
4.9.5.2 SSH .........................................................................................................................................................216
4.9.5.3 HTTP .......................................................................................................................................................218
4.9.5.4 HTTPs .....................................................................................................................................................219
4.9.6 Management Access Method ............................................................................................................................220
4.9.6.1 Profile Rules ............................................................................................................................................220
4.9.6.2 Access Rules ...........................................................................................................................................222
4.9.7 DHCP Snooping ................................................................................................................................................223
4.9.7.1 DHCP Snooping Overview ......................................................................................................................223
4.9.7.2 Global Setting ..........................................................................................................................................224
4.9.7.3 DHCP Snooping VLAN Setting................................................................................................................225
4.9.7.4 Port Setting..............................................................................................................................................227
4.9.7.5 Statistics ..................................................................................................................................................229
4.9.7.6 Database Agent.......................................................................................................................................230
4.9.7.7 Rate Limit ................................................................................................................................................232
4.9.7.8 Option82 Global Setting ..........................................................................................................................233
4.9.7.9 Option82 Port Setting ..............................................................................................................................234
4.9.7.10 Option82 Circuit-ID Setting ....................................................................................................................236
4.9.8 Dynamic ARP Inspection ...................................................................................................................................237
4.9.8.1 Global Setting ..........................................................................................................................................237
4.9.8.2 VLAN Setting...........................................................................................................................................238
4.9.8.3 Port Setting..............................................................................................................................................239
4.9.8.4 Statistics ..................................................................................................................................................241
4.9.8.5 Rate Limit ................................................................................................................................................242
4.9.9 IP Source Guard................................................................................................................................................243
4.9.9.1 Port Settings............................................................................................................................................244
4.9.9.2 Binding Table...........................................................................................................................................246
4.9.10 Port Security ....................................................................................................................................................247
4.9.11 DoS..................................................................................................................................................................249
4.9.11.1 Global DoS Setting ................................................................................................................................249
4.9.11.2 DoS Port Setting ....................................................................................................................................252
4.9.12 Storm Control...................................................................................................................................................253
4.9.12.1 Global Setting ........................................................................................................................................253
7
User’s Manual of IGS-801M
4.9.12.2 Port Setting............................................................................................................................................254
4.10 ACL ..........................................................................................................................................................256
4.10.1 MAC-based ACL..............................................................................................................................................257
4.10.2 MAC-based ACE .............................................................................................................................................258
4.10.3 IPv4-based ACL...............................................................................................................................................261
4.10.4 IPv4-based ACE ..............................................................................................................................................262
4.10.5 IPv6-based ACL...............................................................................................................................................267
4.10.6 IPv6-based ACE ..............................................................................................................................................268
4.10.7 ACL Binding .....................................................................................................................................................273
4.11 MAC Address Table................................................................................................................................274
4.11.1 Static MAC Setting...........................................................................................................................................275
4.11.2 MAC Filtering ...................................................................................................................................................276
4.11.3 Dynamic Address Setting.................................................................................................................................277
4.11.4 Dynamic Learned.............................................................................................................................................278
4.12 LLDP ........................................................................................................................................................280
4.12.1 Link Layer Discovery Protocol .........................................................................................................................280
4.12.2 LLDP Global Setting ........................................................................................................................................281
4.12.3 LLDP Port Setting............................................................................................................................................283
4.12.4 LLDP Local Device ..........................................................................................................................................286
4.12.5 LLDP Remove Device .....................................................................................................................................288
4.12.6 MED Network Policy ........................................................................................................................................289
4.12.7 MED Port Setting.............................................................................................................................................293
4.12.8 LLDP Overloading ...........................................................................................................................................295
4.12.9 LLDP Statistics.................................................................................................................................................297
4.13 Diagnostics .............................................................................................................................................299
4.13.1 Cable Diagnostics............................................................................................................................................299
4.13.2 Ping .................................................................................................................................................................301
4.13.3 Ping Test..........................................................................................................................................................301
4.13.4 IPv6 Ping Test..................................................................................................................................................302
4.13.5 Trace Router....................................................................................................................................................303
4.14 RMON.......................................................................................................................................................304
4.14.1 RMON Statistics ..............................................................................................................................................304
4.14.2 RMON Event ...................................................................................................................................................306
4.14.3 RMON Event Log ............................................................................................................................................307
4.14.4 RMON Alarm ...................................................................................................................................................308
4.14.5 RMON History .................................................................................................................................................311
4.14.6 RMON History Log ..........................................................................................................................................312
8
User’s Manual of IGS-801M
4.15 Maintenance............................................................................................................................................313
4.15.1 Factory Default ................................................................................................................................................313
4.15.2 Reboot Switch .................................................................................................................................................313
4.15.3 Backup Manager .............................................................................................................................................314
4.15.4 Upgrade Manager............................................................................................................................................314
4.15.5 Dual Image ......................................................................................................................................................316
5. SWITCH OPERATION ....................................................................................................... 318
5.1 Address Table...........................................................................................................................................318
5.2 Learning ....................................................................................................................................................318
5.3 Forwarding & Filtering .............................................................................................................................318
5.4 Store-and-Forward ...................................................................................................................................318
5.5 Auto-Negotiation ......................................................................................................................................319
6. TROUBLESHOOTING....................................................................................................... 320
APPENDIX A Switch's RJ45 Pin Assignments................................................................... 322
A.1 1000Mbps, 1000BASE-T..........................................................................................................................322
A.2 10/100Mbps, 10/100BASE-TX..................................................................................................................322
9
User’s Manual of IGS-801M
1. INTRODUCTION
Thank you for purchasing PLANET IGS-801M Industrial Managed Switch, which comes with multiple Gigabit Ethernet copper
connectibility and robust layer 2 and layer 4 features. The description of this model is shown below:
IGS-801M
“Industrial Managed Switch” is used as an alternative name in this user’s manual.
1.1 Packet Contents
8-Port 10/100/1000Mbps Managed Industrial Ethernet Switch
Open the box of the Industrial Managed Switch and carefully unpack it. The box should contain the following items:
Model Name
Item
The Managed Switch
Quick Installation Guide
DIN Rail Kit
Wall Mounting Kit
RJ45 Dust Caps
If any item is found missing or damaged, please contact your local reseller for replacement.
IGS-801M
■
■
■
■
8
10
User’s Manual of IGS-801M
1.2 Product Description
PLANET IGS-801M is an Industrial 8-Port Full Gigabit Managed Ethernet Switch specially designed to transmit reliable but
high-speed data in heavy industrial demanding environments. It provides 8-Port 10/100/1000BASE-T copper interfaces
delivered in an IP30 rugged strong case with redundant power system. Besides support for 16Gbps switch fabric to handle
extremely large amounts of video, voice and important data in a secure topology, the IGS-801M provides user-friendly but
advanced IPv6 / IPv4 management interfaces and abundant L2 / L4 switching functions. It is the best investment for industrial
business expanding or upgrading its network infrastructure.
Environmentally Hardened Design
With IP30 industrial case protection, the IGS-801M provides a high level of immunity against electromagnetic interference and
heavy electrical surges which are usually found on plant floors or in curb side traffic control cabinets. It also possesses an
integrated power supply source with wide range of voltages (12 to 48V DC or 24V AC) for worldwide high availability
applications requiring dual or backup power inputs. Being able to operate under the temperature range from -40 to 75 degrees C,
the IGS-801M can be placed in almost any difficult environment.
Robust Layer 2 Features
The IGS-801M can be programmed for advanced switch management functions such as dynamic port link aggregation, 802.1Q
VLAN and Q-in-Q VLAN, Multiple Spanning Tree Protocol (MSTP), loop and BPDU guard, IGMP snooping, and MLD
snooping. Via the link aggregation, the IGS-801M allows the operation of a high-speed trunk to combine with multiple ports,
and supports fail-over as well. Also, the Link Layer Discovery Protocol (LLDP) is the Layer 2 protocol included to help
discover basic information about neighboring devices on the local broadcast domain.
11
Loading...
