IGS-624HPT
Industrial 4-Port 10/100/1000T 802.3at PoE+
w/ 2-Port 100/1000X SFP Ethernet Switch
Physical Port
• 4-port 10/100/1000Base-T RJ-45 with IEEE 802.3af /
802.3at PoE Injector
• 2-port SFP slot interface, SFP supports 1000Base-X
and 100Base-FX transceiver via DIP switch congured
Power over Ethernet
Long Distance High Power PoE and Gigabit Data Extension Solution
The PLANET IGS-624HPT is an Industrial Gigabit 802.3at PoE+ Switch providing non-blocking
wire-speed performance and great flexibility for Gigabit Ethernet extension in harsh
industrial environment. It provides 4-port 10/100/1000Base-T copper with 802.3af/at PoE
injector and 2 extra 100/1000Base-X SFP fiber optic interfaces delivered in an IP30
rugged strong case with redundant power system. The IGS-624HPT is well suited for
applications in deploying surveillance system, and securing control and wireless service
in climatically demanding environments with wide temperature range from -40 to 75
degrees C.
High Power PoE for Security and Public Service Applications
To fulfill the demand of High Power PoE for network applications, the IGS-624HPT
provides 4 10/100/1000Mbps ports featuring both IEEE 802.3af and IEEE 802.3at Power
over Ethernet Plus (PoE+) that combine up to 30-watt of power output and data per port
over one Cat.5E / 6 Ethernet cable. With totally 120-watt PoE output capability on the
whole system, the IGS-624HPT is designed specically to satisfy the growing demand of
higher power consuming network PD (powered devices) such as PTZ (Pan, Tilt & Zoom) /
Speed Dome network cameras, multi-channel (802.11a / b / g / n) outdoor wireless LAN
access points and other PoE network devices by providing double PoE power, rather
than the current conventional 802.3af PoE.
PTZ
Camera
Thin Client
Video
Phone
30.8W
WiMAX
AP/CPE
Door
Phone
Power Upgrade
15.4W
• Complies with IEEE 802.3af / IEEE 802.3at Power
over Ethernet Plus End-Span PSE
• Up to 4 IEEE 802.3af / 802.3at devices powered
• Supports PoE Power up to 30.8 watts for each PoE port
• Provides DC 52V power over RJ-45 Ethernet cable to
PD with Ethernet port
• Auto-detects EEE 802.3af/at equipment and protects
devices from being damaged by incorrect installation
• Remote power feeding up to 100m
Layer 2 Features
• Supports Auto-Negotiation and 10/100Mbps half / full
duplex and 1000Mbps full duplex mode
• Prevents packet loss with back pressure (half-duplex)
and IEEE 802.3x PAUSE frame ow control
(full-duplex)
• Automatic address learning and address aging
Industrial Case / Installation
• IP30 aluminum metal case protection
• Dual SFP Ports Auto Link Redundant Mode Support
• DIN Rail and Wall Mount Design
• 48V DC redundant power with polarity reverse protect
function and connective removable terminal block for
master and slave power
• Supports EFT protection 6000 VDC for power line
• Supports 6000 VDC Ethernet ESD protection
• -40 to 75 degrees C operating temperature
IP Phone
IP Camera
Wireless
AP/Router
1
IGS-624HPT
Intelligent LED Indicator for Real-time PoE Usage
The IGS-624HPT helps users to monitor current status of PoE power usage easily and efficiently by its advanced LED indication. Called “PoE Power
Usage”, the front panel of the Industrial Gigabit PoE+ Switch has four orange LEDs indicating 30W, 60W, 90W and 120W of PoE power usage.
Convenient and Reliable Power System
To facilitate the 802.3at High Power PoE usage with the commonly used 48V DC power input in transportation and industrial-level applications, the IGS-
624HPT adopts 48V DC to 52V DC power boost technology to solve power source issue which is not required for special power supplies to achieve the
level of High Power PoE+ output. To enhance the operation reliability and exibility, the IGS-624HPT is equipped with two DC power input connectors for
redundant power supply installation.
48V DC Power Input
1000Base-SX/LX
Fiber Optic
802.3af/802.3at
PoE Compliant PD Device
52V DC PoE+
10/100/1000Base-T
48V DC to 52V DC PoE+ Power Boost
2
IGS-624HPT
High Power Budget for PoE Extension
With 30-watt PoE output capability, the IGS-624HPT can extend much longer distance by using PLANET PoE Extender for powering up the IEEE 802.3af
PoE PD devices which can be installed over more than 100 meters away. By daisy-chaining multiple PLANET PoE Extenders, it offers the great exibility of
doubling, tripling or quadrupling the distance of PoE network.
Because of heavy consumption, power isn’t enough for powering
100
meters
802.3af PoE Camera
802.3af PSE
100
meters
100
meters
PoE Extender PoE Extender
(15.4W per port)
Though consumption is heavy, there’s still enough power for powering
100
meters
PoE Extender PoE Extender
IGS-624HPT
802.3at PSE (30W per port)
100
meters
100
meters
802.3af PoE Camera
Environmentally Hardened Design
The IGS-624HPT is equipped with the rugged IP30 metal case for easy deployment in heavy Industrial demanding environments. With IP30 industrial case
protection, the IGS-624HPT provides a high level of immunity against electromagnetic interference and heavy electrical surges which are usually found on
plant oors or in curb side trafc control cabinets. Being able to operate under the temperature range from -40 to 75 degrees C, the IGS-624HPT can be
placed in almost any difcult environment. The IGS-624HPT also allows either DIN rail or wall mounting for efcient use of cabinet space.
Fiber-Optical Link Capability Extend the Range of Network Deployment
The two SFP slots are compatible with 100Base-FX or 1000Base-SX / LX / WDM through SFP (Small Form Factor Pluggable) ber-optic transceivers. The
ber optical uplink capability guarantees the throughput to all nodes hooked into the network and the Gigabit Ethernet distance can be extended from 550
meters (Multi-Mode ber cable) up to 10/20/30/40/50/70/120 kilometers (Single-Mode ber or WDM ber).
3
Outdoor
PoE IP Camera
Ethernet up to
100 meters
1000
PoE
PoE
Extending Ethernet Distance
Outdoor
PoE IP Camera
Outdoor
PoE IP Camera
PoE
Ethernet up to
100 meters
PoE
Outdoor
PoE IP Camera
IGS-624HPT
Network Video
Recorder
IGS-624HPT
Fiber Optic Cable
up to 120km
1000 1000
IGS-624HPT
Fiber Optic Cable
up to 120km
Gigabit Fiber Switch
240km
1000
1000BASE-SX/LX Fiber-optic
PoE
1000BASE-T UTP with PoE
Adjustable 6-Port Switch Mode or 4 + 2 Fiber Redundant Mode
Via the built-in DIP switch, the IGS-624HPT can be configured as 6-port Ethernet switch or 4+2 fiber redundant mode. With the 6-port switch mode, the
IGS-624HPT can operate in Store-and-Forward mechanism with high performance; on the other hand, when in the 4+2 ber redundant mode, it provides
rapid ber redundancy of link for highly critical Ethernet applications. The redundant mode also supports auto-recovering function. If the destination port of
a packet is link down, it will forward the packet to the other port of the backup pair.
Site to Site Fiber Link Redundancy — IP Surveillance
Primary Link
Ordinary Switch
1000Base-X Fiber
(Forwarding)
1000
Redundant Link
1000Base-X Fiber
(Block)
1000
IGS-624HPT
Redundant
Industrial Switch
PoE
PoE
PoE
10/100/1000Base-T UTP
PoE
Surveillance Center
Location A
PoE IP Camera
Location B
1000
PoE
PoE
1000Base-SX/LX Fiber-optic
100Base-TX UTP with PoE
1000Base-T UTP
1000Base-T UTP with PoE
4
IGS-624HPT
Application
Hardened Environment Application
The IGS-624HPT Industrial PoE+ Switch offers full port Gigabit speed. It provides very high reliability and security features to make sure the continuous
operation in harsh environments such as control cabinet of transportation, factory, outdoor and places where extreme low or high temperatures can be
experienced. Moreover, the IGS-624HPT is also compatible with 100Mbps and 1000Mbps SFP transceivers to provide a strong, stable long-distance
connection and exible industrial networking deployment.
PoE IP Camera
PoE
IGS-624HPT
Weather Station
PoE
PoE IP Camera
70km 40km
Fiber
Switch
10001000
1000
Desert
PoE IP Camera
PoE PoE
IGS-624HPT
PoE IP Camera
PoE PoE
120km
IGS-624HPT
Steel FactoryData Center
1000
PoE
1000Base-SX/LX Fiber-optic
1000Base-T UTP with PoE
Redundancy Application
The IGS-624HPT Industrial Gigabit PoE+ Switch provides rapid ber redundancy of link for highly critical Ethernet applications. The redundant-mode supports
auto-recover function. If the destination port of a packet is link down, it forwards the packet to the other port of the backup pair.
Link Path Redundant to Critical Network Service
PoE
Security Machine
PoE
ATM Server
PoE
PoE IP Camera
1000Base-SX/LX Fiber-optic
100Base-TX UTP with PoE
1000Base-T UTP
1000Base-T UTP with PoE
Data Server
Gigabit Switch
Backup Switch
1000
Primary Link
1000Base-X Fiber
(Forwarding)
1000
Redundant Link
1000Base-X Fiber
(Block)
IGS-624HPT
Redundant
Industrial Switch
1000
PoE
PoE
5
Specications
IGS-624HPT
Model
Hardware Specications
Copper Ports
SFP / mini-GBIC Slots
DIP Switch
Connector
Alarm
LED
ESD Protection 6KV DC
EFT Protection 6KV DC
Enclosure IP30 aluminum metal case
Installation DIN rail kit and wall mount ear
Dimensions (W x D x H) 152 x 107x 72 mm
Weight 1539g
Power Requirements
Power Consumption / Dissipation
Power over Ethernet
PoE Standard IEEE 802.3af / IEEE 802.3at Power over Ethernet / PSE
PoE Power Supply Type End-Span
Power Pin Assignment 1/2(+), 3/6(-)
PoE Power Output
Max. number of Class 4 PD 4
Switch Specication
Switch Processing Scheme Store-and-Forward
Address Table 1K entries
Flow Control
Switch Fabric 12Gbps
Throughput (packet per second) 8.93Mpps@64bytes
Maximum Transmit Unit 9216 bytes
Speed
Standards Conformance
Standards Compliance
IGS-624HPT
4 x 10/100/1000Base-T RJ-45 TP
Auto-MDI/MDI-X, Auto-Negotiation
2 x SFP inter faces
Supports 1000Base- SX/LX and 100Base-FX SFP transceivers
DIP-1: SFP Port 5 1000Base-X (default) / 100Base-FX
DIP-2: SFP Port 6 1000Base-X (default)/ 100Base-FX
DIP-3: Switch mode / Fiber Redundant mode
Removable 6-pin terminal block
Pin 1/2 for Power 1; Pin 3/4 for fault alarm; Pin 5/6 for Power 2
Provides one relay output for power fail
Alarm Relay current carry ability: 1A @ DC 24V
3 x LED for System and Power:
Green: DC Power 1
Green: DC Power 2
Green: Power Fault
2 x LED for Per Copper Port (Port-1~Por t-4):
Green: 1000 LNK/ACT, Orange:100 LNK/ACT
Orange: PoE In-use
1 x LED for Per mini-GBIC interface (Port- 5 and Port-6)
Green: LNK/ACT
4 x LED for PoE Power Usage (W)
Orange: 30, 60, 90 and 120W
48V DC, 5A max.
Redundant power with polarity reverse protection function
15.1 watts / 52 BTU (Full loading without PoE function)
135.1 watts / 461 BTU (Full loading with PoE function)
Per port 52V DC, 275mA. Max. 15.4 watts (IEEE 802.3af)
Per port 52V DC, 535m A. Max. 30 watts (IEEE 802.3at)
Back pressure for half duplex
IEEE 802.3x Pause Frame for full duplex
SX/L X: 2000Mbps (full -duplex)
FX: 200Mbps (full -duplex)
TP: 10/20Mbps, 100/200Mbps, 2000Mbps
IEEE 802.3 Ethernet / 10Base-T
IEEE 802.3u Fast Ethernet / 100Base -TX
IEEE 802.3ab Gigabit Ethernet / 1000Base-T
IEEE 802.3z Gigabit Ethernet / 1000Base- SX/L X
IEEE 802.3x Full-Duplex Flow Control
IEEE 802.3at High Power over Ethernet
IEEE 802.3af Power over Ethernet
6
IGS-624HPT
36.55
30
Regulation Compliance
Stability Testing
Environment
Temperature
Humidity
Dimensions
FCC Part 15 Class A, CE
IEC60068 -2-32(Free fall)
IEC60068-2-27(Shock)
IEC60068-2-6(Vibration)
Operating: -40 ~75 degrees C
Storage: -40~75 degrees C
Operating: 5~95% (Non-condensing)
Storage: 5~95% (Non-condensing)
33.38
V1- V1+
V2- V2+
1A@24V
PWR1
PWR2
Fault
Input DC 48V
9.2
RedundantSwitch
Fiber Mode
1000
100
Port 6
Port 5
SFP
LNK/
ACT
1 2 3
ON
1000
100
P1 P2 FAULT
6
Industrial
18
50
18
40
28
1000
100
LNK/ACT
PoE In-Use
4
3
PoE Power
Usage (W)
2
1
IGS-624HPT
72
120
90
60
30
802.3at PoE+ Gigabit Switch
23 78
25.2
152
136
130
23.6
66
�3.5-4
107
66
60
40
SFP
5
LNK/
ACT
R2
7
Ordering Information
IGS- 624HPT Industr ial 4-Port 10/100/100 0T 802.3at PoE+ w/ 2-Port 100/1000X SFP Ethernet Switch
Related PoE Products
IGS-624HPT
ICA-2200
ICA-2500 5 Mega- Pixel PoE Box IP Camera
ICA-3250V Full HD Outdoor IR PoE IP Camera
ICA-3350V 3 Mega-Pixel Vari-Focal Bullet IR IP Camera
ICA- 4200V Full HD 20M IR Vari- Focal Dome IP Camera
ICA-5350V 3 Mega-Pixel Vandalproof IR IP Camera
ICA-8350 3 Mega- Pixel Vandalproof Fisheye IP Camera
ICA -HM101 2 Mega- Pixel PoE Cube IP Camera
ICA -H M126 H.264 Full HD Box IP Camera
ICA -H M127 3 Mega-Pixel H.264 Box IP Camera
ICA -H M132 H.264 2 Mega-Pixel 20M IR Vari-Focal Dome IP Camera
ICA -H M136 H.264 2 Mega-Pixel 20M IR Vandalproof Dome IP Camera
ICA -H M312 2 Mega-Pixel 25M IR Outdoor Bullet PoE IP Camera
ICA -HM316 2 Mega -Pixel Outdoor IR PoE IP Camera
IC A- HM 351 2 Mega-Pixel 35M IR Outdoor Box PoE IP Camera
ICA-HM620 2 Mega-Pixel PoE Plus Speed Dome Internet Camera
POE-152S IEEE 802.3af Power over Ethernet Split ter
POE-162 S IEEE 802.3at Gigabit High Power over Ethernet Splitter
PO E-E101 IEEE 802.3af Power over Ethernet Extender
POE-E201 IEEE 802.3at Power over Ethernet Extender
WNAP-C3220 802.11n Wireless Ceiling Mount PoE Access Point
WN AP- 1120P E 802.11n Wireless Access Point with PoE
WNAP-6350 2.4GHz 3 00Mbps 802.11n Wireless Outdoor PoE Access Point
WNAP-7350
Full HD PoE Box IP Camera
5GHz 30 0Mbps 802.11a/n Wireless Outdoor PoE Access Point
Related DIN-Rail Power Supply
PWR-240-48 240W 48V DC Industrial DIN Rail Power Supply (-10~ 60 degrees C)
SFP Module List
Fast Ethernet Transceiver (100Base-X SFP)
Model Speed (Mbps)
MFB-FX 100 LC Multi Mode 2km 1310n m 0 ~ 60OC
MFB-F20 100 LC Single Mode 20km 1310nm 0 ~ 60
MFB-F40 100 LC Single Mode 40km 1310 nm 0 ~ 60
MFB-F60 100 LC Single Mode 60km 1310nm 0 ~ 6 0
MFB- F120 100 LC Single Mode 120km 1550nm 0 ~ 60
MFB-TFX 10 0 LC Multi Mode 2km 1310 nm - 40 ~ 75
MFB-TF20 100 LC Single Mode 20km 1550nm -40 ~ 75
Connector
Interface
Fiber Mode Distance Wavelength (nm) Operating Temp.
O
C
O
C
O
C
O
C
O
C
O
C
8
Fast Ethernet Transceiver (100Base-X SFP)
IGS-624HPT
Model Speed (Mbps)
Connector
Interface
Fiber Mode Distance Wavelength (TX)
Wavelength
(RX)
Operating Temp.
MFB-FA20 100 WDM(LC) Single Mode 20km 1310nm 1550nm 0 ~ 60OC
MFB-FB20 100 WDM(LC) Single Mode 20km 1550nm 1310 nm 0 ~ 60
MFB-TFA20 100 WDM(LC) Single Mode 20km 1310nm 1550nm -40 ~ 75
MFB-TFB20 100 WDM(LC) Single Mode 20km 1550nm 1310nm -40 ~ 75
MFB-TFA40 10 0 WDM(LC) Single Mode 40km 1310n m 1550nm - 40 ~ 75
MFB-TFB40 100 WDM(LC) Single Mode 40km 1550nm 1310nm - 40 ~ 75
Gigabit Ethernet Transceiver (1000Base-X SFP)
Model Speed (Mbps)
MGB-GT 1000 Copper -- 100m -- 0 ~ 60OC
MGB-SX 1000 LC Multi Mode 550m 850nm 0 ~ 60
MGB-SX2 1000 LC Multi Mode 2km 1310nm 0 ~ 60
MGB-LX 1000 LC Single Mode 10km 1310nm 0 ~ 60
MGB-L30 1000 LC Single Mode 30km 1310 nm 0 ~ 60
MGB-L40 1000 LC Single Mode 40km 1550nm 0 ~ 60
MGB-L50 1000 LC Single Mode 50km 1550nm 0 ~ 6 0
MGB -L70 1000 LC Single Mode 70km 1550nm 0 ~ 60
MGB -L120 1000 LC Single Mode 120km 1550nm 0 ~ 60
MG B-TSX 1000 LC Multi Mode 550m 850nm -40 ~ 75
MGB-TLX 1000 LC Single Mode 10 km 1310nm - 40 ~ 75
MGB-TL30 1000 LC Single Mode 30km 1310n m -40 ~ 75
MG B-T L50 1000 LC Single Mode 50km 1550nm -40 ~ 75
Connector
Interface
Fiber Mode Distance Wavelength (nm) Wavelength
O
C
O
C
O
C
O
C
O
C
O
C
O
C
O
C
O
C
O
C
O
C
O
C
O
C
O
C
O
C
O
C
O
C
Gigabit Ethernet Transceiver (1000Base-BX, Single Fiber Bi-Directional SFP)
Model Speed (Mbps)
Connector
Interface
Fiber Mode Distance Wavelength (TX) Wavelength (RX)
MG B -L A10 1000 WDM(LC) Single Mode 10km 1310 nm 1550nm 0 ~ 60OC
MGB-LB10 1000 WDM(LC) Single Mode 10km 1550nm 1310nm 0 ~ 60
MGB-LA20 1000 WDM(LC) Single Mode 20km 1310nm 1550nm 0 ~ 60
MGB- LB20 1000 WDM(LC) Single Mode 20km 1550nm 1310nm 0 ~ 60
MGB-LA40 1000 WDM(LC) Single Mode 40km 1310nm 1550nm 0 ~ 60
MGB-LB40 1000 WDM(LC) Single Mode 40km 1550nm 1310nm 0 ~ 60
MGB-L A60 1000 WDM(LC) Single Mode 60km 1310nm 1550nm 0 ~ 60
MGB-LB60 1000 WDM(LC) Single Mode 60km 1550nm 1310nm 0 ~ 60
MG B -TL A10 1000 WDM(LC) Single Mode 10km 1310nm 1550nm -40 ~ 75
MG B-T LB10 1000 WDM(LC) Single Mode 10k m 1550nm 1310nm -40 ~ 75
MG B-T LA 20 1000 WDM(LC) Single Mode 20km 1310nm 1550nm -40 ~ 75
MG B-T LB2 0 1000 WDM(LC) Single Mode 20km 1550nm 1310 nm -40 ~ 75
MGB-TLA40 1000 WDM(LC) Single Mode 40km 1310nm 1550nm -40 ~ 75
MGB-TLB40 1000 WDM(LC) Single Mode 40km 1550nm 1310nm -40 ~ 75
MG B-T LA60 1000 WDM(LC) Single Mode 60km 1310nm 1550nm - 40 ~ 75
MG B-T LB6 0 1000 WDM(LC) Single Mode 60km 1550nm 1310nm - 40 ~ 75
Operating
Temp.
O
C
O
C
O
C
O
C
O
C
O
C
O
C
O
C
O
C
O
C
O
C
O
C
O
C
O
C
O
C
PLANET Technology Corporation
11F., No.96, Minquan Rd., Xindian Dist., New Taipei City
231, Taiwan (R.O.C.)
Tel: 886-2-2219-9518 Fax: 886-2-2219-9528
Email: sales@planet.com.tw www.planet.com.tw
IGS-624HPT
PLANET reserves the right to change specications without prior notice. All brand names and trademarks are property of
their respective owners. Copyright © 2013 PLANET Technology Corp. All rights reserved.
9
Loading...
