16-Port 10/100Mbps
Desktop Fast Ethernet Switch
FSD-1604
User’s Manual
Table of Contents
1. Package Contents ............................................................. 3
2. Product Features............................................................... 4
2.1 Switch Front Panel ...................................................... 5
2.2 LED Indicators ............................................................ 5
2.3 Switch Rear Panel .......................................................5
2.4 Installing the FSD-1604 ............................................... 6
3.ProductSpecications .......................................................9
4. Customer Support .......................................................... 10
1. Package Contents
Check the contents of your package for following parts:
FSD-1604 x 1 DC 5V, 1A Power
Adapter x 1
If any of these are missing or damaged, please contact your
dealer immediately, if possible, retain the carton including the
original packing material, and use them against to repack the
product in case there is a need to return it to us for repair.
User’s Manual x 1
3
2. Product Features
RJ-45 Interface
16-Port 10/100Mbps Fast Ethernet ports l
Comply with IEEE 802.3 10Base-T, IEEE 802.3u 100Base-TX l
Switching
Hardware based 10/100Mbps Auto-Negotiation and Auto l
MDI/MDI-X
Features Store-and-Forwardmode with wire-speed ltering l
and forwarding rates
Flow control for Full Duplex operation and back pressure for l
Half Duplex operation
Integrates address look-up engine, supporting 8K absolute l
MAC addresses
2Mbit SRAM Packet Buffer l
Switch Fabric: 3.2Gbps, Switch Throughput: 2.38Mpps l
Automatic address learning and address aging l
Comply with CSMA/CD protocol l
Hardware
Plastic shape and Desktop size, wall mount designed l
LED indicators for system Power, per port Link / Act l
Supports to handle up to 1522bytes packet l
External DC 5V, 1A Power Adapter l
One power on/off button for energy saving l
FCC Class B, CE compliant l
4
2.1 Switch Front Panel
Power
2 4 6 8 10 12 14 16
1 3 5 7 9 11 13 15
ACTLNK
FSD-1604
16-Port 10/100Mbps Desktop Switch
1 61 41 21 08642
1 51 31 197531
Po w e r O N/ O F F
Figure 1-1 shows a front panel of FSD-1604.
Figure 1-1: FSD-1604 Front Panel
2.2 LED Indicators
FSD-1604
LED Color Function
PWR Green Lit: Power on.
Lit: indicate the link through that port is
LNK/ACT Green
successfully established at 10/100Mbps.
Blink: indicate that the Switch is actively
sending or receiving data over that port.
2.3 Switch Rear Panel
Figure 1-2 shows a rear panel of FSD-1604.
Figure 1-2: FSD-1604 Rear Panel
5
Power
Notice
1. The device is a power-required device, it
Note
Note
means, it will not work till it is powered. If
your networks should active all the time, please
consider using UPS (Uninterrupted Power
Supply) for your device. It will prevent you
from network data loss or network downtime.
2. In some area, installing a surge suppression
device may also help to protect your Switch
from being damaged by unregulated surge or
current to the Switch or the power adapter.
2.4 Installing the FSD-1604
This part describes how to install your FSD-1604 and make
connections to it. Please read the following topics and perform
the procedures in the order being presented.
This FSD-1604 does not need software configuration.
Desktop Installation
To install the FSD-1604 on desktop, simply follow the next
steps:
Step 1: Place the FSD-1604 on desktop near a DC power
source.
Step 2: Keep enough ventilation space between the FSD-1604
and the surrounding objects.
When choosing a location, please keep in mind
the environmental restrictions discussed in Product
Specifications.
6
Step 3: Connect your FSD-1604 to network devices.
PC/Laptop
xDSL/Cable Router
Internet
Power Adapter
RJ-45
RJ-45
Power
001101010
1614121 08642
151 31197531
Power ON/ OFF
A. Connect one end of a standard network cable to the
10/100 RJ-45 ports on the Back of the FSD-1604.
B. Connect the other end of the cable to the network
devices such as printer servers, workstations or
routers…etc.
Step 4: Supply power to the FSD-1604.
A. Connect one end of the power cable to the
FSD-1604.
B. Connect the 5V DC power adapter to a standard
wall outlet.
When the Switch receives power, the Power LED should remain
solid Green.
7
Wall Mount Installation
Note
RJ-45
UTP Cable
Power
Adapter
Step 1: Please nd the wallthatcan mount the FSD-1604.
Step 2: Install two screws on the wall.
Step 3: Hang the FSD-1604 on the screws from the wall.
Step 4: Repeat step 4 of Desktop Installation for supply power
to the FSD-1604.
Before wall mount installation, please consider the
material quality of wall, power socket location and
Ethernet cable length.
8
3. Product Specications
Model FSD-1604
HardwareSpecication
Network Connector 16-Port RJ-45 for 10/100Base-TX
LED Display
Switch Architecture Store and Forward switch architecture
MAC Address Table 8K MAC address table with Auto learning function
Switch Fabric 3.2Gbps
Switch Throughput 2.38Mpps
Maximum Packet Size 1522Bytes
Flow Control
Power Requirement DC 5V,1A Power Adapter
Power Consumption 2.7 Watts / 9.2BTU
Dimension (W x D x H) 200x 135 x 35 mm
Weight 369g
Standard Conformance
EMI Safety FCC Class B, CE
Operating environment 0 ~ 50 Degree C
Storage environment -10 ~ 70 Degree C
Operating Humidity 5 ~ 95%, Relative Humidity, non-condensing
Storage Humidity 5 ~ 95%, Relative Humidity, non-condensing
Standard Compliance
System: Power x1 (Green)
Per Port: LNK/ACT (Green)
Back pressure for Half-Duplex. IEEE 802.3x Pause
Frame for Full-Duplex
IEEE 802.3
IEEE 802.3u
IEEE 802.3x
Ethernet
Fast Ethernet
Flow Control
9
4. Customer Support
Thank you for purchase PLANET products. You can browse our
online FAQ resource at the PLANET web siterst to check if it
could solve you issue. If you need more support information,
please contact PLANET switch support team.
PLANET online FAQ :
http://www.planet.com.tw/en/support/faq.php?type=1
Switch support team mail address :
support_switch@planet.com.tw
Copyright © PLANET Technology Corp. 2012.
Contents subject to revision without prior notice.
PLANET is a registered trademark of PLANET Technology Corp. All other trademarks belong
to their respective owners.
10
EC Declaration of Conformity
For the following equipment:
*Type of Product: 16-Port 10/100Mbps Fast Ethernet Switch, Plastic
*Model Number: FSD-1604
* Produced by:
Manufacturer‘s Name : Planet Technology Corp.
Manufacturer‘s Address: 10F., No.96, Minquan Rd., Xindian Dist.,
New Taipei City 231, Taiwan (R.O.C.).
is herewith confirmed to comply with the requirements set out in the Council Directive on the
Approximation of the Laws of the Member States relating to Electromagnetic Compatibility
Directive on (2004/108/EC).
For the evaluation regarding the EMC, the following standards were applied:
EN 55022 (CLASS B: 2006 + A1:2007)
EN 61000-3-2 (2006 + A2: 2009)
EN 61000-3-3 (2008)
EN 55024 (1998 + A1: 2001 + A2:2003)
IEC 61000-4-2 (2008)
IEC 61000-4-3 (2006 + A1: 2007 + A2:2010)
IEC 61000-4-4 (2004 + A1: 2010)
IEC 61000-4-5 (2005)
IEC 61000-4-6 (2008)
IEC 61000-4-8 (2009)
IEC 61000-4-11 (2004)
Responsible for marking this declaration if the:
Manufacturer Authorized representative established within the EU
Authorized representative established within the EU (if applicable):
Company Name: Planet Technology Corp.
Company Address: 10F., No.96, Minquan Rd., Xindian Dist., New Taipei City 231, Taiwan
(R.O.C.)
Person responsible for making this declaration
Name, Surname Kent Kang
Position / Title : Product Manager
Taiwan
29, Feb., 2012
Place Date Legal Signature
PLANET TECHNOLOGY CORPORATION
e-mail: sales@planet.com.tw http://www.planet.com.tw
10F., No.96, Minquan Rd., Xindian Dist., New Taipei City, Taiwan , R.O.C. Tel:886-2-2219-9518 Fax:886-2-2219-9528
