Revision
User’s Manual for PLANET VoIP Analog Telephone Adapter:
Model: ATA
Status .................................................................................................................................................. 35
Call W aiting........................................................................................................................................46
Switch the Default Proxy ...................................................................................................................46
Auto Update firmware by manual (Keypad)......................................................................................47
Appendix C Frequently Asked Questions List ........................................................................................48
Appendix D ATA Specifications................................................................................................................49
- 5 -
Chapter 1
1
1
Introduction
Overview
Based on years of VoIP manufacturing experiences, PLANET Technology VoIP total solutions are
known for advanced implementation of standards based telephony with mass deployment capability.
Cost-effective, easy-to-install and simple-to-use, the PLANET ATA-150/ATA-150S VoIP Phone Adapter
(“ATA” in the following term) converts standard telephones to IP-based networks. The servi ce providers
and enterprises can offer users traditional and enhan ced th e telephony commu nication se rvi ces via the
existing broadband connection to the Internet or corporation network.
With the ATA, home users and companies are able to save the installation cost and extend their past
investments in telephones, conference and speakerphones. The ATA equipped with two telephony
interfaces, users may register to different SIP proxy servers, IP PBX and establish up to 2 concurrent
VoIP calls for more flexibility in the voice communications. ATA can be the bridge between the
traditional analog telephones to IP network with an extremely affordable investment.
Product Features
• Feature-rich telephone service over home Internet / Intranet connection
• Up to 2 concurrent VoIP calls
• Cost-effective, easy-to-use solution for Analog Telephone Adapter
• Call Waiting / Hold / Resume / Transfer / Forward /
• 3-Way Conference / Caller ID Generation
• VAD / CNG / Dynamic Jitter Buffer
• SNMP v1/v2, TR-069 and Auto Provision
- 6 -
Package Content
The contents of your product should contain the following items:
VoIP Telephone Adapter
Power adapter
Quick Installation Guide
User’s Manual CD
RJ-11 cable x 1
Physical Details
The following figure illustrates the each panel of SIP ATA.
ATA-150: SIP Analog Telephone Adapter (1 x RJ-45, 1 x RJ-11)
ATA-150S: 2-Port FXS SIP Analog Telephone Adapter (1 x RJ-45, 2 x RJ-11)
Front Panel of ATA-150
Left / Right Panel of ATA-150
- 7 -
Front Panel of ATA-150S
Left / Right Panel of ATA-150S
Physical Interface & Button
Pressing 1 second to reboot machine.
1 RESET
Pressing 5 seconds to reset to the factory default setting
2 12V DC
3 LAN
4 Phone
Machine default IP is http://192.168.0.1
Í
Note
- 8 -
button on rear panel over 5 seconds will reset the VoIP Phone
Adapter to factory default value. (Except speed dial and
call forward settings)
12V DC Power input outlet
RJ-45 connector, for Internet access, connected directly to
Switch/Hub through straight CAT-5 cable.
RJ-11 connector, connected directly to the analog phone.
. Press RESET
LED Display of ATA-150
PWR
LNK/ACT
Phone
LED Display of ATA-150S
PWR
LNK/ACT
RING1
RING2
Power is supplied to the device.
OFF: the device is disconnected to LAN.
ON: the device is connected to LAN.
OFF: the phone is idle.
ON: the phone is in use (off-hook).
Blinking: the phone is ringing.
Power is supplied to the device.
OFF: the device is disconnected to LAN.
ON: the device is connected to LAN.
OFF: the phone is idle.
ON: the phone is in use (off-hook).
Blinking: the phone is ringing.
OFF: the phone is idle.
ON: the phone is in use (off-hook).
Blinking: the phone is ringing.
- 9 -
Chapter 2
2
Preparations & Installation
Physical Installation Requirement
This chapter illustrates basic installation of ATA analog Phone Adapter (“ATA” in the following term)
• Network cables. Use standard 10/100Base-TX network (UTP) cables with RJ-45 connectors.
• TCP/IP protocol must be installed on all PCs.
For Internet Access, an Internet Access account with an ISP, and either of a DSL or Cable modem
Administration Interface
PLANET ATA provides GUI (Web based, Graphical User Interface) and utility for machine management
and administration.
Utility quickly search access
Using for soft utility to search SIP ATA from current network. The utility not only easy-to-use and
provides user more convenience for configuration access, at the some time If you forget this IP address
can also found that via the utility.
Copy this utility tool in your laptop or desktop computer first. And, this utility tool can only be executed in
Windows series of operating systems.
Click the icon for windows desktop to start searching ATA in the network.
Select “Refresh” and you will get the results as above choose the device you want to configuration,
click this IP address of ATA and press the “Connect to Device” button to browse the web page.
- 10 -
Web configuration access
You will connect to SIP ATA via your web browser automatically. ATA will prompt for logon username /
password, please enter: admin / 123 to continue machine administration.
ATA will prompt for logon username/password, please enter: admin / 123 to continue machine
administration.
The default IP address of ATA is 192.168.0.1. You also could open your web browser, and insert
http://192.168.0.1 in the address bar of your web browser to logon ATA web con f iguration page.
To start ATA web configuration, you must have one of these web browsers installed on computer for
management
•
Microsoft Internet Explorer 6.00 or higher with Java support
Please locate your PC in the same network segment
Í
Note
(192.168.0.x) of ATA. If you’re not familiar with TCP/IP,
please refer to related chapter on user’s manual CD or
consult your network administrator for proper network
configurations.
Keypad commands
The ATA series phone adapters support telephone key pad configurations, please connect analog
telephone set and refer to the following table for machine network configurations.
IVR Menu Choice Machine operation Parameter(s) Notes
#111#
#112xxx*xxx*xxx*
xxx#
- 11 -
Set DHCP client None
Use the * (star) key
Setup Static IP Address
when entering a decimal
ATA will change to DHCP
Client
DHCP will be disabled and
system will change to the
point. Static IP type.
#113xxx*xxx*xxx*
xxx#
#114xxx*xxx*xxx*
xxx#
#115xxx*xxx*xxx*
xxx#
#190#
#195#
Use the * (star) key
Set Network Mask
Set Gateway IP Address
Set Primary DNS Server
Unlock None
Save Network Settings None
when entering a decimal
point.
Use the * (star) key
when entering a decimal
point.
Use the * (star) key
when entering a decimal
point.
Must set Static IP first.
Must set Static IP first.
Must set Static IP first.
Must unlock the protect
function before carry out
the firmware update
(#160#).
Must save network
settings after set up
network settings via
keypad.
The system will be reset to
#198#
Factory Reset None
factory default value and
reboot automatically.
Following keypad commands can be used to display the network settings enabled on ATA via voice
prompt.
IVR Menu Choice Machine operation Notes
#120#
#121#
#122#
#123#
Check IP Address
Check network connection Type
Check the Phone Number
Check Network Mask
IVR will announce the current IP address of
the A T A.
IVR will announce if DHCP in enabled or
disabled.
IVR will announce current enabled VoIP
number.
IVR will announce the current network mask
of the ATA.
#124#
#125#
#128#
Check Gateway IP Address
Check DNS Server Setting
Check Firmware Version
IVR will announce the current gateway IP
address of the ATA.
IVR will announce the current setting in the
DNS field.
IVR will announce the version of the
firmware running on the ATA.
- 12 -
Following keypad commands can be used to set up the main function .
IVR Menu Choice Machine operation Parameter(s) Notes
01: G.711 u-Law, 02:
#130+first
priority codec
#133#
#134#
#138#
#139#
#140+Forward
type+Forward
Phone Number#
G.711 a-Law, 03: G.729,
04: G.723 6.3K, 05:
Set First Priority Codec
Set Speaker Voice Gain 00~31, 32: Mute
Set Mic Voice Gain 00~31, 32: Mute
Enable call waiting None Enable Call waiting
Disable call waiting None Disable C all waiting
You can set the codec you
want to the first priority.
For example: #13001#
Set G.711 u-Law to the first
priority codec
For example: #13305#
Mic Voice: 5
For example: #13410#
Mic Voice: 10
For example: #1401101#
Immediate Forward to 101
#141#
#150#
#160#
Disable Forward SettingsNone
For example: #1501#
Select Default Realm 0: Realm 1, 1: Realm 2
Set Default Proxy to Realm 2
Update firmware
Must unlock the protect
Update firmware None
function (#190#) before carry
out the firmware update.
- 13 -
Chapter 3
3
TCP/IP Settings
Configuring and monitoring your ATA from web browser
The ATA integrates a web-based graphical user interface that can cover most co nfigurations and
machine status monitoring. Via standard web browser, you can configure and check machine status
from anywhere around the world.
Overview on the web interface of ATA
With web graphical user interface, you may have:
More comprehensive setting feels than traditional command line interface.
Provides user input data fields, check boxes, and for changing machine configuration setting s
Displays machine running configuration
To start ATA web configuration, you must have one of these web browsers installed on comput er for
management
Microsoft Internet Explorer 6.00 or higher with Java support
Manipulation of ATA via web browser
Log on ATA via web browser
After TCP/IP configuration s on your P C, you may now open your web b rowser, and input
http://192.168.0.1
Enter the IP address of the ATA which
by default is 192.168.0.1
Phone Adapter will prompt for logon username/password: admin / 123
to logon Phone Adapter web co nfiguration page.
ATA login prompt screen
- 14 -
When users login the web page, users can see the Phone Adapter system information like firmware
version, company…etc in this main page.
VoIP Phone Adatper main page
LAN IP address configuration via web configuration interface
This page is used to configure the parameters for Internet network which connects to the LAN port of
your ATA. Here you may change the access method to static IP, DHCP, PPPoE or PPTP by click the
item value of LAN Access type.
- 15 -
Loading...
+ 35 hidden pages
You need points to download manuals.
1 point = 1 manual.
You can buy points or you can get point for every manual you upload.
