Planar VMC49MXX9 Datasheet

The Planar VM Complete VMC49MXX9 video wall features nine 49-inch LCD video wall displays in a 3x3 landscape configuration, with tiled bezel widths of 1.8 millimeters. With a diagonal video wall size of 146 inches, and 700-nit brightness, it is ideal for any retail store, hospitality setting, or corporate lobby. The Planar VM Complete VMC49MXX9 comes with the video wall displays, mounts and trim.

SPECIFICATION DETAIL

Planar VMC49MXX9

LCD Video Wall

Product Name VM Series Display Viewable Size Video Wall Dimensions

w/Handles (W x H x D) Video Wall Dimensions w/o

Handles (W x H x D) Video Wall Dimensions:

Notes

In the Bundle

VMC49MXX9 VM49MX-X 146" diagonal

126.9" x 71.7" x 4.0" (3226.8mm x 1817.4mm x 101.9mm)

126.9" x 71.7" x 3.6" (3226.8mm x 1817.4mm x 91.7mm)

Dimensions are estimates only. Please refer to the display and mount dimensional drawings and display spacing guidance as found in the Planar VM Series User Guide.

VM49MX-X display x9, 1.8m AC Power Cord (US) x9, 1.8m AC Power Cord (EU) x9, 1.8m DisplayPort cable x9, Remote control x9, IR Receiver x9, IR loop cable x9, RS-232 cable x9, RS-232 loop cable x9, alignment brackets, cable clips, Quick Start Guide, Handling Guide, VMT-MXL mount x9, trim pieces.

For more information, please visit www.planar.com
