Planar VMC49MXX4 Datasheet

The Planar VM Complete VMC49MMX4 video wall features four 49-inch LCD video wall displays in a 2x2 landscape configuration, with tiled bezel widths of 1.8 millimeters. With a diagonal video wall size of 97 inches, and 700-nit brightness, it is ideal for any retail store, hospitality setting, or corporate lobby. The Planar VM Complete VMC49MXX4 comes with the video wall displays, mounts and trim.

SPECIFICATION DETAIL

Planar VMC49MXX4

LCD Video Wall

Product Name VM Series Display Viewable Size Video Wall Dimensions

w/Handles (W x H x D) Video Wall Dimensions w/o

Handles (W x H x D) Video Wall Dimensions:

Notes

In the Bundle

VMC49MXX4 VM49MX-X 97" diagonal

84.6" x 47.8" x 4.0" (2151.2mm x 1211.6mm x 101.9mm)

84.6" x 47.8" x 3.6" (2151.2mm x 1211.6mm x 91.7mm)

Dimensions are estimates only. Please refer to the display and mount dimensional drawings and display spacing guidance as found in the Planar VM Series User Guide.

VM49MX-X display x4, 1.8m AC Power Cord (US) x4, 1.8m AC Power Cord (EU) x4, 1.8m DisplayPort cable x4, Remote control x4, IR Receiver x4, IR loop cable x4, RS-232 cable x4, RS-232 loop cable x4, alignment brackets, cable clips, Quick Start Guide, Handling Guide, VMT-MXL mount x4, trim pieces.

For more information, please visit www.planar.com
