Planar UR9851 Specifications

The Planar® UltraRes™ UR9851 is an 98" Ultra HD
(3840 x 2160) professional LCD display with best-in­class image and color quality for native 4K and
upscaled content. The 500 nit 98" display supports
multi-source viewing, 4K @ 60Hz, HDCP 2.2
compliance and portrait orientation. Planar UltraRes
Series displays offer superior performance with
exceptional 4K clarity and advanced processing ideal
for applications ranging from collaborative meeting
spaces to high impact digital signage.

SPECIFICATION DETAIL

Planar UltraRes UR9851

4K LCD Display

Product Name
Display Resolution
Screen Size
Aspect Ratio
Display Active Area
Cabinet Dimensions (W x H

x D)
Dimensions, including wall

mount
Bezel Width
Brightness (typ)
Response Time (typ)
Frame Rate
Contrast Ratio (typ)
Viewing Angle (typ)

UR9851
Ultra HD (3840 x 2160)
98 in. (diagonal)
16:9

85.0” (2159mm) x 47.8” (1214mm)

86.7" x 49.5" x 3.6" (2203mm x 1258mm x 93mm)

86.7" x 49.5" x 3.6" (2203mm x 1258mm x 93mm)

0.9" (22mm)
500 nits
8 ms
120Hz
1300:1
178°

Color Gamut
Display Color
Modes

Pixel Pitch
Weight
Weight (Shipping)

72% NTSC
>1 billion colors. Full 10 bit data path
1x 3840x2160 @ 24/25/30/60Hz, 4x 1920x1080 @ 24/25/30/50/60Hz; 2x

1920x2160 @ 60Hz; 480p, 576p, 720p @ 50/60 Hz; 1080p @ 24/25/30/50/60Hz;
1080i @ 50/60 Hz

0.562mm
255 lb (115 kg)
TBD

Backlight

LED

Line Voltage
Power Consumption (typ)
Operating Temperature

Humidity
Approvals
External Connections

Audio Output
Multi-Source Views
Display Control
Speakers
Orientation
Mounting
Fanless

100-240V; 50/60Hz
410W
0° to +35°C (32° to 95°F) at up to 1500m, 0° to +30°C (32° to 86°F) at up to

3000m
20 - 85% RH (non-condensing)

FCC Class A, CE, cTUVus, CCC
DisplayPort 1.2 x 1, HDMI 2.0 x 2 (HDCP 2.2), HDMI 1.4 x 2, OPS x 1, OPS USB

2.0 x 2, OPS USB 3.0 X 1
PC Line Out, S/PDIF

PiP, Dual, Triple, Quad
IR, RS-232, LAN, Keypad, Mobile app
10W x 2 built-in
Landscape/Portrait
Planar Profile Mounting System or VESA: 600 x 400 mm
Yes

HD format
Display Technology
Options / Features

Warranty
Planar Part Number
UPC

4K UHD 2160p
Direct-lit LED LCD
MediaPlex Plus Processing, Scheduling, Presets, Redundant power supply, TAA

compliant
3 years Advance Exchange

997-7960-00
8 10689 00261 1

For more information, please visit www.planar.com

Specifications are subject to change without notice.
Specification Report Date: 11/30/2017
© Copyright 2017 Planar Systems, Inc. All rights reserved
