Planar PL2410W User Manual
PL2410W
LCD Monitor
USER'S GUIDE
www.planar.com
Content
Operation Instructions...................................................................................................................................................1
Safety Precautions...........................................................................................................................................................2
First Setup...........................................................................................................................................................................3
Front View of the Product ............................................................................................................................................4
Rear View of the Product ..............................................................................................................................................5
Quick Installation .............................................................................................................................................................6
Basic Operation.................................................................................................................................................................7
Advanced Operation—OSD Menu............................................................................................................................9
Supporting Timing Modes ........................................................................................................................................12
Technical Information................................................................................................................................................. 13
Wall-mount instruction .............................................................................................................................................. 14
Care and Maintenance................................................................................................................................................ 15
Troubleshooting............................................................................................................................................................ 15
Product Registration and Technical Support..................................................................................................... 16
Operation Instructions
Thank you for purchasing this TFT LCD Monitor, a high-resolution multi-scan color TFT LCD
Monitor.
Please read this guide thoroughly before installation.
FCC RADIO FREQUENCY INTERFERENCE STATEMENT
WARNING: (FOR FCC CERTIFIED MODELS)
This
TFT LCD Monitor
device, pursuant to part 15 of the FCC Rules. These limits are designed to provide proper
protection against harmful interference to a residential installation. This
generates, uses, and can radiate radio frequency energy. Harmful interference to radio
communication may be led as a result if it‘s not properly installed and used. However, there is no
guarantee that interference will not occur in a particular installation. If this
cause serious interference to radio or television reception, resetting the
determine it. Moreover, users are encouraged to correct interference by doing one or more of
the following:
Reorient or relocate the receiving antenna.
Move the
Connect the
receiver is connected.
Consult your local dealer or an qualified technician.
FCC Warning:
To assure a continued FCC compliance, a user must use a grounded power supply cord and the
provided shielded video interface cable with bonded ferrite cores. Also, any unauthorized
changes or modifications to this
device.
Note: If necessary, shielded interface cables and AC power cord must be used to meet the
emission level limits.
Important Recycle Instruction:
has been tested and found compliant with the limits for a Class B digital
TFT LCD Monitor
TFT LCD Monitor
TFT LCD Monitor
TFT LCD Monitor
TFT LCD Monitor
and the receiver further away from each other.
into an outlet on a circuit different from that to which the
TFT LCD Monitor
would void the user‘s authority to operate this
does
may
Lamp(s) inside this product contain mercury. This product may contain other
electronic waste that can be hazardous if not disposed of properly. Recycle or dispose in
accordance with local, state, or federal Laws. For more information, contact the Electronic
Industries Alliance at WWW.EIAE.ORG. For lamp specific disposal information check
WWW.LAMPRECYCLE.ORG
According to WEEE regulation, this TFT LCD Monitor can't be handled as normal trash in Europe
when it is out of usage. Please refer to the recycle information from our website to handle it.
.
1
Safety Precautions
This
TFT LCD Monitor
is manufactured and tested on a ground principle that a user’s safety
comes first. However, improper use or installation may result danger to the TFT LCD Monitor as
well as to the user. Carefully go over the following WARNINGS before installation and keep this
guide handy.
WARNINGS:
This TFT LCD Monitor should be operated only at the correct power sources indicated on the
label on the rear end of the TFT LCD Monitor. If you’re unsure of the power supply in your
residence, consult your local dealer or power company.
Do not try to repair the TFT LCD Monitor yourself as it contains no user-serviceable parts. The
TFT LCD Monitor should only be repaired by a qualified technician.
Do not remove the TFT LCD Monitor cabinet. There is high-voltage parts inside that may
cause electric shock to human bodies, even when the power cord is disconnected .
Stop using the TFT LCD Monitor if the cabinet is damaged. Have it checked by a service
technician.
Put your TFT LCD Monitor only in a clean, dry environment. Unplug the TFT LCD Monitor
immediately if gets wet and consult your service technician.
Always unplug the
TFT LCD Monitor
before cleaning it. Clean the cabinet with a clean, dry
cloth. Apply non-ammonia based cleaner onto the cloth, not directly onto the glass screen.
Keep the
TFT LCD Monitor
away from magnetic objects, motors, TV sets, and transformer.
Do not place heavy objects on the cable or power cord.
For pluggable equipment, the socket-outlet shall be installed near the equipment and shall
be easily accessible.
2
First Setup
Congratulations on your purchase of this high performance TFT LCD monitor.
This TFT LCD Monitor comes with the following accessories :
LCD Monitor User's Guide
Power Cable Base
VGA Cable (15 pin)
Install the stand base
1. Lay the
from being scratched, put a piece of soft cloth on the table on which the screen will be set.
2. Unpack the base, one hand hold the monitor, the other hand attach the base to the stand.
3. Stand the
TFT LCD Monitor
TFT LCD Monitor
flat on a table with the LCD screen face down. To prevent the monitor
up.
Uninstall the stand base
1. Lay the
Monitor
be set.
2. Hold the monitor down with one hand. With the other hand, use two fingers to press the
hooks down as directed below.
3. Remove the base from the stand.
TFT LCD Monitor
from being scratched, put a piece of soft cloth on the table on which the screen will
flat on a table with the LCD screen face down. To prevent the
TFT LCD
3
Front View of the Product
①
②
③
④
⑤
⑥
OSD Turn On/ Off
Contrast/Brightness Setting/Scroll Down/Adjust Decrease
Preset Mode/ Scroll UP/ Adjust Increase
Input select/ Confirm Selection
Power On/ Off
LED Indicator
① ②③④
⑤⑥
4
