CHAPTER 1

The LCD Monitor

Unpacking

After you unpack your LCD monitor, make sure the following items are included in
the box and in good condition:

Standard Items

• PE150M LCD monitor

• VGA Cable With 15-Pin D-Sub VGA Connector (Male)

• Power cord

• User’s Manual

• CD Manual

• Landing Strip

• 1.5M Stereo Jack audio cable

If you find that any of these items are missing or appear damaged, contact your
dealer immediately. Do not throw away the packing material or shipping carton
in case you need to ship or store the LCD monitor in the future.

1

Identifying Components

The LCD Monitor — Front View

Figure 1-1: The LCD Monitor Front View

1. Power-On Indicator

This LED indicator stays lit when the power is on and blinks
when the LCD monitor is in power saving mode.

2. Monitor Stand

3. LCD Screen

The LCD monitor screen is a 15-inch TFT 1024 x 768 screen.

4. LCD Monitor Control Panel

Refer to Chapter 2 for details.

2

The LCD Monitor — Rear View

Figure 1-2: LCD Monitor Rear View

1. Audio Line-in (optional)

2. AC Power Jack

3. VGA Cable With 15-Pin D-Sub VGA Connector (Male)

4. VESA interface: It can be mounted to VESA arm. (75mm pitch)

Adjusting the Tilting Angle

The LCD monitor’s angle settings range from -5° to 25°. See Figure 1-3.

Figure 1-3: Tilting the Monitor

3

Raising Your Monitor to an Upright Position and
Adjusting Monitor Angle

4
