Planar LC1913R Drawing

022-1059-00 REV A

8

NOTES:

1. SHEET METAL HOUSING IS EG PLATED.

2. SOLID MODEL AVAILABLE UPON REQUEST.

3. PART IS RoHS COMPLIANT.

1.6

PHOTO &
THERMAL
SENSOR

7

56

4

3

REVISIONS

ZONE REV. DESCRIPTION DATE APPROVED

A INITIAL RELEASE 08/03/07 RD

12

DD

SCALE: 1/3

DETAIL C

SCALE 1 : 1

C

±5

123

202.0

404.0

380.3
ACTIVE AREA

376.3

DISPLAY

BEZEL

12X M4X.7

MOUNTING HOLES

(THREAD DEPTH

8mm MAX)

81.4 MAX

78.4
12X 38.4

4X M4X.7

MOUNTING HOLES

100.0

COOLING FAN
WARNING: DO NOT
RESTRICT AIRFLOW

C

163.2

C

327.5

DISPLAY

305.1
BEZEL

301.1

ACTIVE

AREA

PHOTO &
THERMAL

SENSOR

7.0

217.02X

267.02X

25.02X

100.0

BB

54

200 58

GND

PIN 4

PIN 1

AUDIO IN

VGA

DVI POWER

A

B

DETAIL B

SCALE 1 : 1

AUDIO OUT

S-VIDEO

COMPOSITE

VIDEO

8

7

6

DIMMING
CONTROL

FAN KIT POWER

5

12V

PIN 6

PIN 1

DETAIL A

SCALE 1 : 1

THIS DRAWING CONTAINS INFOR MATION PROPRIETARY T O PLANAR SYSTEMS, INC., ANY R EPRODUCTION IN PART OR WHOLE WITHOUT THE WRITT EN PERMISSION OF PLANAR SYSTEMS
IS PROHIBITED. THIS DRAWING IS SUPPLIED FOR INFORMATION, IDENTIFICAT ION, ENGINEERING, EVALUATION, A ND/OR INSPECTION PURPOSES ONLY AND MAY NOT BE USED AS BASIS
FOR THE MANUFACTURING OF PRO DUCTS OR THE FURNISHING OF SERVIC ES TO PLANAR SYSTEMS OR TO A NY THIRD PARTY UNLESS AUTHOR IZED IN WRITING BY PLANAR SYST EMS.

34

UNLESS OTHERWISE SPECIFIED
DIMENSIONS ARE IN MILLIMETERS.

TOLERANCES:

.XX= .25

1

X=

.5 ANGLES=

DIMENSIONING AND TOLERANCING PER

ASME Y14.5M-1994

THIRD ANGLE PROJECTION

ENGR BY

DRAWN BY

R.DAVENPORT

CHECKED BY

USED ON

1.X=

MATERIAL

FINISH

-

­06/14/07

-

-

NA

NA

TITLE

DWG,SPEC,MECH O/L LC1913R

PART NUMBER

SIZE

D

997-3360-00LF

SCALE

1:2

DRAWING NO.

076-0627-00

DO NOT SCALE

PLANAR SYSTEMS, INC.
1195 NW COMPTON DRIVE
BEAVERTON, OR 97006 USA

SHEET

1 OF 1

REV

A

12

AA
