CONTROLLE R
ATR111
User Manual
1
ORDERING CODES
Ordering codes model ATR111
ATR111- xx x
Power supply
AD
12…24Vac ± 10% 50/60Hz
12…35Vdc
B
230 Vac ± 10% 50/60 Hz
2
TECHNICAL DATA
Main features
Displays 3 digits (0,56 inches)
+ 1 Leds (Out1)
Operating temperature 0-40°C - humidity 35..95uR%
Sealing Front panel IP65 (with gasket) /
Box IP30 / Terminal blocks IP20
Material ABS UL94V2 self- exstinguish
Weight Approx. 100 gr.
Hardware data
Analog input AN1
Software configurable
Thermocouples K, J, S, R
PT100, NI100, PT500,
PT1000, PTC 1000 ohm ,
NTC 10Kohm
Tolerance 25°C
0.5 % ± 1 digit for
thermocouples and
RTD
Cold junction
0.2°c/°c of ambient
temperature
Outputs
1
Relay or SSR:
OUT1 :10A resistive on AD codes,
8A resistive with internal transformer
SSR : 8 Volt 20mA for version B
15 Volt 30mA for version AD (alim. 12Vac)
30 Volt 30mA for version AD (alim. 24Vac)
Software data
Control algorithm On/OFF with hysteresis or P.I.D. with Autotuning
Data protection Configuration password, quick programming by
Memory card
3
WIRING DIAGRAM ATR111
PIXSYS
PIXSYSPIXSYS
PIXSYS
ATR111-AD
ATR111-ADATR111-AD
ATR111-AD
10A 230V
Resistive
3/4HP
Q1
PT C/NTC
-
+
Tc
+V DC
SSR
1 2 3 4
5 6 7 8 9
10 11 12
-
+
I
V/I
+
-
PT /NI 100 /1K
2 wir e 4 /20m A
Po wer
Memo ry1
-
+
12...35V...
12/24V
~
PT C/NTC
-
+
Tc
+V DC
SSR
1 2 3 4
5 6 7 8 9
10 11 12
-
+
I
V/I
+
-
PT /NI 100 /1K
2 wir e 4 /20mA
Po we r
Memory1
230 V
~
8A 230V
Resistive
1/2HP
Q1
PIXSYS
PIXSYSPIXSYS
PIXSYS
ATR111- B
ATR111- BATR111- B
ATR111- B
4
DISPLAYS AND KEYS
Visualize setpoint (ex. programmed temperature):
press once for SET1 (Led Out1 flashes),
In configuration mode press with arrow
keys to modify value of visualized parameter.
Display normally shows
process value (ex. measured temperature),
but can also visualize setpoints or value of
entering data
S
E
T
F
N
C
OUT 1
OUT 2
ATR111
L1
PIXSYS
Visualize set, increase set
or scroll parameters
(whith fast advancement)
Visualize set, decrease set,
scroll parameters.
(whith fast advancement)
