Page 1
Celestial Space
Porcelain Tile
Sizes Sizes and Finishes
24 x 48
24 x 24
Field Tile
Nominal (in) Actual (mm) Thickness (mm) Finish
3 x 6 72 x 147 10.5 Unpolished
3 x 6 Picket 72 x 146 10.5 Unpolished
6 x 24 147 x 597 10.5 Unpolished
2.5 x 12 Chevron Right 64 x 305 10.5 Unpolished
2.5 x 12 Chevron Left 64 x 305 10.5 Unpolished
12 x 12 297 x 297 10.5 Unpolished
12 x 24 297 x 597 10.5 Unpolished
24 x 24 597 x 597 10.5 Unpolished
24 x 48 597 x 1219 10.5 Unpolished
A 3mm grout joint is recommended.
Mosaics
Nominal (in) Actual (mm) Thickness (mm) Grout Joint (mm) Finish
3 x 3 Hexagon 276 x 296 10.5 3.5 Unpolished
2 x 2 Square 298 x 298 10.5 3 Unpolished
Herringbone 295 x 341 10.5 2.5 Unpolished
Coordinating Trim
Nominal (in) Actual (mm) Thickness (mm)
4 x 24 Single Bullnose 96 x 597 10.5 Unpolished
2 x 12 Cove Base 45 x 297 10
Finish
Unpolished
12 x 24
6 x 24
12 x 12
3 x 6
3 x 3
Hex Mosaics
Mesh mo unted on a
276mm x 29 6mm
sheet (coverage
area 0.71 s f)
2.5 x 12
Chevron Left
and Right
3 x 6 Picket
2 x 2
Mosaics
Mesh mo unted on a
298m m x 298mm
sheet (coverage are a
0.97 sf)
Herringbone
Mosaic
Mesh mounted on a
295mm x 341mm sheet
(Coverage area 0.9 sf)
2 x 12 Cove Base4 x 24 Single B ullnose
Product Performance
Breaking Streng th >500 lbf ASTM C648
Bond Strength >200 psi ASTM C482
Chemical Resistance Class A ASTM C650
Frost Resistance Unaffected ASTM C1026
Water Absorption <0.20% ASTM C373
Scratch Hardness 7 Mohs Scale
UPS
Wet Dynamic Coefficient of Friction Range
Unpolished 0.42 - 0.52 Ac uTest
sm
Shade & Texture Index
Celestial Space has a shade variation of V2.
V2 V3 V4V1
V1 Uniform appearance
V2 Slight Variation
V3 Moderate Variation
V4 Substantial Variation
This porcelain tile product is produced with a V2 variation. Expect that the amount of
color and texture on each piece may vary slightly. Inspect the product upon delivery and
for best results, blend tile from several cartons during installation.
Recommended Uses
Celestial Space is recommended for interior floors, walls, counter tops and exterior walls
in both residential and commercial applications. If an offset pattern is required for
tiles 18 inches or longer, PIXL recommends an offset of not greater than 33%.
Information listed here is subject to change. Please refer to pixltile.com for the latest, most
accurate information.
E-Mail: [email protected] Web: pixltile.com
Page 2
Celestial Space
Porcelain Tile
Celestial Space
Heavenly marble makes an elegant – and
durable – statement when reinterpreted in
porcelain tile. With no chance of etching,
staining, or natural coloration variances, this
divine white marble look is out of this world.
Features and Benefits
• Customize designs with three mesh-mounted
mosaic designs including 2x2 square,
herringbone, and 3x3 hexagons
• Finish your project in grand style with cove base
and bullnose trim along with on-trend chevrons
• Made in the USA
Easy-Clean Surface
This PIXL porcelain tile includes a proprietary
surface finish that imparts a subtle glow,
enhancing the color of the tile and allowing
many stains and scuff marks to be easily wiped
off the surface. This extraordinary finish helps
keep your living areas looking their best.
Both photos: Shower Walls: Celestial Space, 12 x 12. Shower Floor: Celestial Space, Herringbone Mosaic
E-Mail: [email protected] Web: pixltile.com
