Distance To Screen Distance (Meter/Inch)
1.5/60
2.0/79
3.0/119
5.0/197
7.0/276
8.0/315
10.0/394
Max. Screen Diagonal (Meter/Inch)
1.02/40
1.36/54
2.04/81
3.4/135
4.76/190
5.44/217
6.8/271
Min Screen. Diagonal (Meter/Inch) 0.94/
0.88/35
1.17/47
1.76/70
2.93/117
4.11/163
4.69/187
5.87/233
7020 Koll Center Pkwy . Suite #138 . Pleasanton . CA 94566 . U.S.A.
Phone: 925.426.9100 . Fax: 925.426.8200 . Website: www.pixainc.com
SPECIFICATIONS
Display Specification
• Display Technology: Signal 0.70" Ddr Dmd 1024 X 768.
• Brightness: Typical 1800 Ansi Lumen (4 Segment) / Typical 850 Ansi Lumen (6 Segment).
• Contrast Ratio: Typical 2200:1 (Full-On/Full-In).
• Horizontal Resolution: 480 Tv Lines (S-Video). (Depends On The Model).
• Image Size:Min 35" , Max 300" Diagonal.
• Audible Noise: Max. 32Dba When Eco Mode Is On.
System Specification
• System: Ntsc/Pal/Secam/Ntsc 4.43.
All-in-One DLP
Home Theatre Projector
Model No.
DHT-200
KEY FEATURES
• Signal 0.70" DDR DMD 1024 X 768 Display Technology.
• Image Size For Minimum 35" And Maximum 271"
Diagonal.
• Brightness: Zeiss 1800 ANSI Lumen.
• Contrast Ratio: 2200:1
• Build-In 6 In-One DSC Multiple Memory Card Reader.
• Integrated 2.1 Channel Wireless Speakers.
• Docking DVD Player
• Throw Distance: 1.5M - 10M.
• Focusing Range: 1.5 To 10.0 Meter (60" To 394"), Optimal 1.5 To 5.0 Meter (60" To 197").
• Color Wheel: 4 Segmentations Rgwb (7200Rpm) 6 Segmentations Rgbrgb (7200Rpm).
• Projection Lens: Zoom Ratio: 1.2:1 With F/2.8~3.1, 100% Offset.
• Lamp: 250W Lamp Life: 2000 Hours (Normal Mode) / 3500 Hours (Eco Mode).
• Digital Zoom: Max. X32 For Xga Mode.
• Keystone Correction: +/- 12 Degrees (Vertical).
• Picture Reverse Scan: Left/Right And Top/Bottom.
• Scanning Frequency: Automatic Frequency Control:
Horizontal: 15 - 82Khz.
Vertical: 50 - 85 Hz.
• Operating Temperature: 5 C To +35 C
• Safety Regulations: 1. EMC-FCC class B, CE Class B, CCC, UL.
2. Safety - cUL, TUV, Cb.
Connector Specification
• Computer: Sxga (Compression)/Xga/Svga/Vga/Mac.
• Computer Input: Vga-In / Dvi-In (Depends On The Model).
• Computer Output: Monitor Out (D-Sub 15 Pins). (Depends On The Models)
• Video: Component (Hdtv, Edtv) Input:
Rca Jack X3, Rca X1 (Composite),
Mini Din 4-Pin X1, Rca X2 (R, L-Mono).
• Audio Out: 3.5Mm Mini Jack X 1: Audio Out.
3.5Mm Mini Jack X 3: Audio 5.1 Channel Output.
• Built-In Speaker: 2W X 1.
• Wireless Speaker : Stereo 25W X 2.
Physical Characteristics
• DHT-200 Dimensions (Wxdxh): 374 X 290 X 92Mm (14.7" X 11.4" X 3.6").
• DHT-200 Net Weight: 4.5 Kg (10Lb).
• Wireless Speaker Dimension (Wxdxh): 170X180X270Mm (6.7"X7.1"X10.6").
• Wireless Speaker Weight: 8.35 Kg.
• Front Elevation / Maximum Tilt Angle: Up To 15 Degrees / 45 Degrees Up And Down.
• Power Supply:100 To 240V, 50 To 60 Hz.
• Power Consumption: 330 Watt
Updated: Feb 2004
