StealthTouch-M5 Touchcomputer
compact, fanless, and versatile
StealthTouch-M5 is a 15" All-in-one touchcomputer powered by Intel
Pentium-M technology. Its versatile design allows you to customize the M5
to meet your application requirements and budget. The M5's versatility
makes it an ideal choice for applications in food service, retail,
manufacturing, healthcare, and self-service kiosk.
When configured as fanless and diskless thin client, the M5 will reduce
grease and dust intakes. It also has the power to run demanding
applications in Windows XP or Vista.
M5's benefits:
+ Rugged and slim design.
+ Choice of Resistive touch, Intellitouch, or InfraRed.
+ Blazing network, 10/100/1000BaseT. Wireless (WiFi) optional.
+ 4 Serial, 6 USB ports.
+ PoweredUSB to power up receipt printer, credit card terminal.
+ Integrated magnetic stripe reader and biometric fingerprint reader.
+ 2nd display port for advertisement on LCD or Plasma display.
Specifications
Display 15" LCD, Active matrix TFT, 1024x768
Touchscreen Option Resistive, Intellitouch SAW, InfraRed
Processor Intel Celeron-M 1GHz, upto Pentium-M 2GHz
Memory 512MB, upto 2GB DDR2
Video Memory upto 128MB (shared)
Storage Hard Drive, Solid-state Disk, or Compact Flash
CD/DVD Internal (optional)
Operating System XP Prof, WePOS, XP embedded, CE.NET, Linux
Network/Ethernet 10/100/1000 BaseT
WiFi (wireless) RF 802.11 (optional)
Serial Port 4
USB 2.0 6 : 4 Standard, 2 powered +12V, 1 powered +24V
Parallel Port 1
Cashdrawer Port 2 (Epson emulation, 24V)
CF Slot 1 (optional)
Speakers 2 Watts, Stereo (optional)
Mounting Options Wall or Pole mount, VESA 75mm
Security Lock Bolted (4mm screw), or Kensington MicroSaver
Bezel Color Dark grey
Dimensions (with Base) Width: 14.63" (380mm)
Height: 14.37" (373mm)
Depth: 10.37" (269mm), Wallmount: 3.3" (85mm)
Weight 22 lbs / 10 kgs (Wallmount: 10 lbs / 4.6 kgs)
Operating Temperature
Operating Humidity 20% to 80%
Power Supply External, 120W, AC 100-240V
Agency Approvals FCC A, CE, UL
Add-ons Magnetic stripe or Barcode slot reader
o
0
C to 40o C
Fingerprint /Biometric reader (DigitalPersona)
Rear customer display or 10" LCD
Barcode scanner (omni-directional)
Proximity RFID reader
Barcode scanner
VESA mount
Rear display
Dual view
