TAKE A TRIP TO SOMEWHERE NEW

NavGate units are all-in-one navigation and multimedia centres.
They are completely flexible when it comes to installation and can
be customised to suit your own taste. Integrate, find, connect, play
and, most importantly, have fun.

PERFECT-FIT NAVIGATION

With NavGate, there’s a custom-fit solution for any car and any driver. An extensive selection of installation set-ups
is available, for smooth and seamless integration in all types of cars.

Find the perfect fit for your car at www.pioneer.eu

FIND

At heart, Pioneer’s NavGate units are about fast and

precise navigation. All new NavGate models utilise extensive
European map data from TeleAtlas and come with a TMC receiver for
up-to-date traffic information.

CONNECT

Stay connected on the road with Bluetooth
built-in Bluetooth module from Parrot, so you can enjoy hands-free conversations on your mobile or iPhone
safely behind the wheel.

®

wireless technology. All new 2009 NavGate units feature a

PLAY

NavGate puts the fun back into driving. You now have the ability to turn
your car into a complete mobile entertainment centre. Mix and match
from a wide selection of multimedia formats, such as iPod, USB and SD,
to enjoy your favourite music and video files on the road.

To see the full NavGate line-up, pick up the 2009 NavGate catalogue or visit www.pioneer.eu

07NavGate

NAVIGATION THAT
FITS AROUND YOU

With NavGate Feeds, navigation is now customisable. This all-new PC application,
which can be downloaded via the Pioneer website (www.pioneer.eu), enhances your
driving experience with a range of interesting features.

MODIFY YOUR MAPS

With NavGate Feeds you can personalise the map content
on your NavGate unit. When you find interesting locations
on the internet, such as restaurants, hotels, sport clubs
and camping areas on Google Maps™ mapping service*,
you can transfer them to your NavGate unit via an SD
card or USB stick. These locations will then appear

as ‘Points Of Interest’ on your maps, in the form of
easy-to-read icons. NavGate Feeds can also link to
GeoRSS readers, so you can import locations from
geotagged images you find on the internet.

* Google Maps is a trademark of Google Inc.

DRIVE REPORT

See an overview of your journeys and the number of kilometres you’ve travelled. Using
the Drive Report feature of NavGate Feeds you can view trips you’ve made on a map,
to which you can add comments. Useful when you need to calculate your travel expenses.

ECO AND FUEL REPORT

NavGate Feeds now lets you see how economically
you have been driving. Eco Report gives you an evaluation
of your acceleration and brake data and also calculates
your CO
representation of this data on your PC. Fuel Report helps
you calculate how much fuel you have consumed for a
specific trip or period of time and gives you a graphical
representation of your mileage history.

emissions. You can then view a graphical

2

AV ADD-ONS

BACK-UP CAMERAS

When connected to a NavGate unit, AV headunit or colour
display with camera input, these back-up cameras give a
wide-angle view of what’s behind your car when in reverse.
Choose either the ND-BC2 or ND-BC20PA universal

ND-BC2 ND-BC20PA

UNIVERSAL BACK-UP CAMERA UNIVERSAL BACK-UP CAMERA WITH VISUAL DSP UNIT

LCD COLOUR DISPLAYS

Pioneer’s wide-screen colour LCD displays bring
brilliant entertainment to the rear seat. Both screens
have 2 AV inputs and 1 AV output. The AVD-W1100V
features a headphone jack, while the AVD-W7900

back-up camera. The ND-BC20PA features a visual
DSP unit, to eliminate the wide-angle distortion effect,
and ‘Parking Guidelines’, which make reverse parking
extremely easy.

features an IR headphone transmitter, for use with our
optional SE-IRM290 IR headphones. The AVD-W7900
also features a complementary headrest mounting
bezel, for easy installation.

AV D-W1100 V AVD-W7900

7-INCH WIDE-SCREEN QVGA COLOUR DISPLAY11-INCH WIDE-SCREEN VGA COLOUR DISPLAY

SE-IRM290

INFRA-RED HEADPHONES

MULTI-DVD PLAYER

XDV-P6

MULTI-DVD PLAYER WITH DOLBY DIGITAL/DTS DIGITAL OUTPUT

Boost your in-car experience with an in-dash 6-DVD/CD
changer and standalone DVD/CD player. The XDV-P6
handles DVD-Video, DVD-R/DVD-RW, VideoCD, CD/CD-R/
CD-RW, MP3 and WMA playback.

Remote con trol includ ed

09NavGate

Nothing beats the feeling of hearing your favourite tunes

on the open road. That’s why we designed our new range

of headunits with your music in mind. It’s your drive,

so you should be able to enjoy it just the way you want

to. There are solutions for any need, whether you’re

looking for a complete in-car multimedia experience

or just a convenient way to play your music collection

on the go. You are now in charge of your in-car enjoyment.

It’s time to take control.

TAKE

THE WHEEL

11HEADUNITS

ALL YOUR MUSIC
ALL YOUR VIDEOS
ALL THE TIME

With Pioneer, there’s no more saying goodbye to your music and videos when getting into your car. Our 2009 range of headunits
offers complete playback and connectivity options, so all of your favourite audio and video entertainment is available when
you really want it. SD, iPod, USB, Aux-in, DVD, CD, MP3, AAC, WMA, DivX: it’s all possible. And that’s only the beginning.
So, what are you waiting for? Get out there and set your music free.

SD CARD CONNECTIVITY

The DEH-P4100SD features an SD card slot, so you can take hours of music
on the road with just one SD or SDHC card. Easy.

iPod DIRECT CONTROL

With iPod direct control it takes just one easy connection to control your iPod directly from your
headunit’s front panel. Headunits are available for both iPod music and video playback.

USB CONNECTIVITY

AUDIO AND VIDEO PLAYBACK

The USB terminal lets you hook up a range of sources, such as a USB
stick with audio content or an MP3 player. All USB devices can
be controlled directly from the headunit, so you can search and select
tracks using the hard-key controls.

When it comes to playing your favourite audio and video formats, our new range of headunits
has got everything covered.

AUX-IN CONNECTION

All headunits in the new range feature an Aux-in
connection, which means you can connect a range

of portable devices and take even more of your music on the road.

13HEADUNITS

THE COMPLETE AV EXPERIENCE

DVD AV HEADUNITS

Get ready for the next era of in-car entertainment. Our 3 new DVD AV headunits are complete multimedia centres, offering
impressive connectivity, playback and expansion options. All models feature a large screen display and touch panel operation,
while their sleek designs give the finishing touch to any car dashboard. It’s time to take multimedia to a whole new level.

AVH-P4100DVD

DVD AV HEADUNIT

2009 AVH MODELS

If you’re looking to get a complete in-car entertainment system, our new
AVH models are the perfect solution. Thanks to their vast playback
and connectivity options, entertainment will never take the back seat.

AUDIO PLAYBACK

VIDEO PLAYBACK

Features a 7-inch slide-down touch screen

Optional remote control available

PERFECT INTEGRATION

A range of installation kits is available for Pioneer’s AVH models, so
you’ll always have the perfect fit for your dashboard*. You can further
integrate your AVH headunit with the colour customisation
feature. Select your button colour illumination from a multitude of
colours, to match your car’s colour scheme.

EXPAND

3 hi-volt RCA pre-outs (AVH-P4100DVD) ›

2 hi-volt RCA pre-outs (AVH-P5100DVD, AVH-P 3100DVD) ›

2 video inputs, 1 video output, 1 back-up camera input ›

IP-Bus connectivity for optional CD-BTB200 Bluetooth adapter, ›
multi-DVD player, TV tuner or digital signal processor

* Visit www.pioneer.eu to find the installation kit for your car

AVH-P5100DVD

BLUETOOTH

®

ADAPTER

READY

� �

AVH-P4100DVD

AVH-P3100DVD

�

AVH-P3100DVD

DVD AV HEADUNIT

EASY CONTROL OF YOUR MULTIMEDIA

Optional remote

control available

Features a 5.8-inch

touch screen

�*�**�

� �

� � �

� � �

� � �

� � �

� � �

� � �

� � �

� � �

�

� �

� � �

� � �

***

�

Song search Source menu

The AVH-P4100DVD and AVH-P3100DVD feature a user-friendly interface, making it simple to control
headunit functions on screen. With the easy-to-read layout, selecting tracks and AV sources, as well as
controlling multimedia functions, is now more convenient. For a personal touch, you can customise
background visuals with pre-installed images or your own photographs. There’s also the option of displaying
iPod album artwork, provided that your iPod has this feature.

SLIDE TOUCH

Slide touch is a handy new feature of
the AVH-P4100DVD and AVH-P3100DVD.
You can now perform certain functions, such as fast
forwarding and rewinding audio and video files,
simply by sliding your finger across the screen.

� � �

� � �

� � �

� �

� � �

� � �

� � �

� � �

* Via optional CD-IU205V cable

** Via optional CD-IU200V cable

*** Via optional CD-IU50V cable

The key features of each product
are indicated by means of icons
and logos. For an explanation of
these icons and logos, please see
pages 78-79.

For full features and specifications,
please visit www.pioneer.eu

15HEADUNITS

AVH-P5100DVD

DVD AV HEADUNIT

FULLY DETACHABLE FACEPLATE

For your peace of mind, the AVH-P5100DVD has a fully detachable face. Simply
unclip the faceplate to leave just a blank back panel in your car.

Optional remote control available

7-INCH FOLDAWAY SCREEN

At the touch of a button, the AVH-P5100DVD opens to reveal a
motorised 7-inch QVGA touch panel display. So, you get the benefit
of having a compact 1-DIN unit, without having to sacrifice on
screen size. And because it’s a touch panel, you can control
headunit features and functions directly on screen.

PERSONALISE YOUR SYSTEM

Thanks to colour customisation, you can perfectly integrate the
AVH-P5100DVD into your car’s interior. Choose from a selection of
colours for the button illumination and on-screen display.

BLUETOOTH

®

ADAPTER

READY

THE PERFECT BALANCE

DVH-P4100UB

The DVH-P4100UB offers the perfect mix of entertainment and flexibility. The unit’s playback capabilities
allow you to enjoy your favourite audio and video files, while its connectivity and expansion options
let you to attach a range of music sources and audio components. The DVH-P4100UB also comes with
an IR remote control for convenient and complete control over your in-car entertainment system.

DVH-P4100UB

�

�

*

�

�

�

�

�

�

�

�

�

�

�

�

DVH-P4100UB

DVD RDS TUNER

MUSIC AND VIDEO
WITH ONE CONNECTION

The DVH-P4100UB’s front USB terminal can
be used to connect either an iPod, iPhone
or USB device. The headunit supports both
iPod music and video playback.

Remote control included

DVD/CD slot hidden behind

the flap-style front panel

EXPAND YOUR SYSTEM

Want to build the perfect in-car environment for enjoying
your music and videos? The DVH-P4100UB features
2 RCA pre-outs, so you can expand your system with
extra amps, speakers and a subwoofer. There’s also
the option of adding one or more LCD colour displays,
to watch your videos in widescreen format.

�

�

�

�

�

* Via optional
CD-IU50V cable

The key features
of each product are
indicated by means
of icons and logos.
For an explanation
of these icons and
logos, please see
pages 78-79.

For full features
and specifications,
please visit
www.pioneer.eu

THE BEST MATCH

The DVH-P4100UB features colour customisation. Choose between red
and blue for the button illumination, to better match your headunit with
your dashboard.

17HEADUNITS

SMOOTH OPERATORS

BLUETOOTH CD TUNERS

Worried about picking up? With Pioneer’s new Bluetooth CD tuners, making those all-important calls has now become
stress-free. Integrated Parrot Bluetooth technology enables hands-free telephony and audio streaming, so you can make
calls with both hands on the wheel. User-friendly control of your contacts also makes it that much easier to talk on the road.
When the conversation’s over, enjoy your favourite music thanks to the wide connectivity and playback options.

Steering wheel remote

DEH-P8100BT

BLUETOOTH CD RDS TUNER

control included

MULTI-LANGUAGE INTERFACE*

* Available in English, French, German,
Italian, Spanish, Dutch and Russian
for the DEH-P7100BT and DEH-P8100BT

VOICE RECOGNITION

The DEH-P8100BT and DEH-P7100BT feature voice recognition
control. This means you can perform certain Bluetooth telephony
functions simply by speaking to your headunit*.

* Available in English, French, German, Italian, Spanish and Dutch

TWIN USB/iPod

The DEH-P8100BT features 2 rear USB terminals,
so you can simultaneously connect 2 iPod
models, 2 USB devices or a combination of both.

DEH-P7100BT

BLUETOOTH CD RDS TUNER

Optional steering wheel
remote control available

ULTIMATE SYSTEM EXPANSION

The DEH-P8100BT and DEH-P7100BT both have 3 hi-volt RCA
pre-outs, which means you can build a system that perfectly suits
your needs. If you like to tweak your audio, the 7-band graphic
equaliser lets you adjust equalisation levels to best match

the acoustics of your car.

DEH-P8100BT

DEH-P7100BT

DEH-6100BT

�

�

*

�

DEH-6100BT

BLUETOOTH CD RDS TUNER

EVERYTHING COVERED

The DEH-6100BT offers the complete package.
The built-in Bluetooth module allows hands-free
telephony and audio streaming, with Bluetooth
functions available in 3 languages: English, Spanish

2009 BLUETOOTH FEATURES

Optional steering wheel

remote control available

and Russian. The unit also has a front USB terminal
and front Aux-in terminal, so you can connect
a wide range of portable audio devices.

�**�**�

� �

� � �

� � �

� � �

� � �

� � �

� �

� �

� � �

� � �

� � �

� �

**

�

�

PARROT BLUETOOTH MODULE

Pioneer’s Bluetooth CD tuners now feature a Parrot
Bluetooth module. Parrot modules are compatible with
a wide range of mobile phones and can be updated
when new phones are launched.

AUDIO STREAMING

Thanks to their audio streaming profile, our Bluetooth CD tuners let you stream your favourite

songs from your mobile phone to your headunit. This music can then be controlled directly

from your headunit.

EXTERNAL MICROPHONES

All new Bluetooth models features external microphones that can be adjusted in all
directions to better pick up the driver’s voice. The DEH-P8100BT comes with a twin
microphone, which cuts out noise from the outside of the car by focusing on the area
surrounding the driver.

PHONEBOOK CAPABILITIES

Transfer your contacts to your Bluetooth headunit
using your mobile phone. These Bluetooth models
can store phonebooks from a maximum of
5 different phones. Each phonebook can hold a

maximum of 1000 entries, and 5 phone numbers and
genres can be stored for each independent entry.

�

� � �

� �

� � �

� � �

� � �

� �

� �

� �

� � �

� �

* Features 2 rear USB terminals

** Via optional CD-IU50 cable

The key features of each product
are indicated by means of icons
and logos. For an explanation
of these icons and logos,
please see pages 78-79.

For full features and specifications,
please visit www.pioneer.eu

Find out if your mobile phone is compatible at www.pioneer.eu

19HEADUNITS

DEH-P5100UB

CD RDS TUNER

MULTI-LANGUAGE SELECTIONHEAR THE DIFFERENCE

Card-type remote

control included

The DEH-P5100UB’s 7-band graphic equaliser lets you customise
equalisation levels to best match the acoustics of your car.
To compensate for outside noise, the Automatic Sound Leveliser
(ASL) uses signal processing to automatically and electronically
adjust the internal volume, so your music always sounds right.

BLUE OEL DISPLAY

Pioneer’s blue OEL (Organic Electro-Luminescent) display makes
taking charge of your music even easier. 3 lines of information make
it more convenient to search and select tracks from USB and iPod,
while the 192 x 48 resolution allows all information to be displayed clearly.

The DEH-P5100UB has a multi-language user interface, which
means you can view all information in your language of choice*.

* Available in English, French, German, Italian, Spanish, Dutch and Russian

BLUETOOTH

®

ADAPTER

READY

NEVER COMPROMISE

DEH-P5100UB

The DEH-P5100UB will be your perfect partner in achieving the ultimate in-car sound experience.
Its 3 hi-volt RCA pre-outs let you boost your audio performance with extra amps, speakers and subs.
A range of advanced audio features lets you adjust your music to suit your preferred musical tastes.
To top it off, the DEH-P5100UB can easily connect to your iPod and USB devices.

DEH-P5100UB

�

�

*

�

�

�

�

�

BUILD YOUR IDEAL SYSTEM

CD-BTB200 Bluetooth adapter

TS -A 170 CI

DEH -P51 00U B

(via optional CD-IU50)

iPod

(via optional CD-U50E)

USB device

TS -A 170 CI

�

�

�

�

�

�

�

�

�

�

�

�

�

�

�

TS -A 170 3I

TS-W308D2 (4 Ω mode)

Front RCA pre-out
Rear RCA pre-out
Subwoofer RCA pre-out
Front USB terminal
IP-Bus connection

(Bridged)

GM-640 0F

GM- 5400T

�

�

�

TS -A 170 3I

* Via optional
CD-IU50 cable

The key features
of each product are
indicated by means
of icons and logos.
For an explanation
of these icons and
logos, please see
pages 78-79.

For full features and
specifications, please
visit www.pioneer.eu

21HEADUNITS

CONNECT TO ALL YOUR MUSIC

MULTI-FORMAT CD TUNERS

Wherever your music is stored, you can now take it with you on the road. The DEH-P4100SD and DEH-P3100UB offer ultimate
connectivity options, so you can connect a range of portable audio sources and take all of your music along for the ride.
Both models also let you connect the CD-BTB200 Bluetooth adapter, so you can even enjoy streaming music from a mobile
phone. It’s time to get connected.

DEH-P4100SD

CD RDS TUNER

ALL YOUR MUSIC ON ONE SD CARD

Remove the front panel of the DEH- P4100SD to reveal the SD card slot

The DEH-P4100SD features Pioneer’s rotary commander, which
gives you easy control over all headunit features and functions. It
makes browsing through folders and files quick and easy, which is
convenient when you are playing music from one of the many
portable audio sources you can connect to the DEH-P4100SD.

Optional remote

control available

The DEH-P4100SD has an SD card slot discreetly hidden behind
its front panel. Simply insert one SD or SDHC card and enjoy
your entire music collection on the go. There’s no more worrying
about having to leave your entire CD collection or portable audio
player in your car. It’s the most convenient way to take your music
on the road.

EXPANSION FLEXIBILITYONE POINT OF CONTROL

Connect an amplifier and speakers to the 1 RCA pre-out, and run
a subwoofer directly from your headunit using direct sub drive.
You can also adjust your equalisation levels using the 3-band
parametric equaliser.

BLUETOOTH

®

ADAPTER

READY

DEH-P3100UB

CD RDS TUNER

Optional remote

control available

DEH-P4100SD

�

� �

�*�

� �

� �

� �

� �

� �

� �

� �

� �

� �

� �

� �

DEH-P3100UB

*

DIRECT iPod AND USB CONNECTION

The DEH-P3100UB’s front USB terminal is the one-stop port for connecting an iPod* or USB device**.
Without the need for any additional adapters, this is a quick and easy way to access you digital music
collection while you are driving.

* Use the optional CD-IU50 cable, specially made for in-car use

** Use the optional CD-U50E cable to safely connect while driving

iPod DIRECT CONTROL

COMPLETE INTEGRATION

� �

� �

� �

� �

� �

� �

� �

� �

� �

* Via optional CD- IU50 cable

The key features of each
product are indicated
by means of icons and
logos. For an explanation
of these icons and logos,
please see pages 78-79.

For full features
and specifications,
please visit ww w.pioneer.eu

With iPod direct control, it takes just one easy connection
to control your iPod directly from your headunit. Browse
through artists and playlists and select tracks with a simple

Thanks to the DEH-P3100UB’s OEM display output,
you can view information on your existing in-car display*.

* Find the correct adapter for your car at www.pioneer.eu

turn and click of the DEH-P3100UB’s rotary commander.

23HEADUNITS

YOUR MUSIC FIRST

HIGH POWER CD TUNERS

Simply want to enjoy your favourite music in your car in the best quality possible? With our new entry-level CD tuners,
the focus is back on your enjoyment. It takes just 3 ingredients: you, your music and your car. We’ll do the rest. Take a drive
with Pioneer. You’ll be surprised at the difference it makes.

DEH-2100UB/DEH-2120UB

CD RDS TUNER

The DEH-2120UB features green button illumination

FRONT USB CONNECTION

ADVANCED SOUND RETRIEVER

Original Sound

Response (dB)

Frequency (Hz) x10

Experience your compressed music like never before with
Pioneer’s Advanced Sound Retriever (ASR). While compressed
audio may be convenient, it can result in inferior sound quality.
The ASR restores harmonics that are lost during compression by
using compressed audio data to calculate the original harmonics
and enabling their recreation based on the calculation algorithm.

4

Compressed audio sound

The front USB terminal is the convenient way to play compressed
music on the road. For safe connection of USB devices while you are
driving, Pioneer offers the 50 cm long CD-U50E cable.

ASR restores the sound quality of the compressed

audio to the level of the original recording

Frequency (Hz) x10

Pioneer’s ASR adjusts frequency response and sound pressure,
especially in the high frequency and low frequency ranges to
revitalise the density and presence of the compressed signal.
The result? Improved sound quality with the staging, density and
feeling restored to the level of the original recording.

4

Frequency (Hz) x10

4

DEH-1100MP/DEH-1120MP/DEH-1100MPB

CD RDS TUNER

DEH-2100UB

DEH-2120UB

DEH-1100MP

�

� �

� �

� �

� �

� �

� �

� �

� �

�

DEH-1120MP

DEH-1100MPB

The DEH-1120MP features green button illumination

The DEH-1100MPB features a blue display

PLAY YOUR FAVOURITE FILES

Take your favourite music files on the road,
thanks to MP3, WMA and WAV playback.

BUILD UP YOUR SYSTEM

The 1 RCA pre-out lets you expand your sound system with an amplifier and speakers.

� �

� �

� �

The key features of each product are
indicated b y means of icons and logos.
For an explan ation of these icons and
logos, plea se see pages 78-79.

For full features and specifications,
please visit www.pioneer.eu

CONNECTION FLEXIBILITY

Connect a range of portable audio players
to the front Aux-in.

SAFETY FIRST

The steering wheel remote input allows you to have easy and safe control of your music. If your
car features an existing steering wheel remote control, you can hook your headunit up to that
remote via an optional adapter* and take control with both hands on the wheel.

* Find the correct a dapter for your car at www.pio neer.eu

25HEADUNITS

BLUETOOTH

®

ADAPTER

READY

ACCESSORIES

BLUETOOTH ADAPTER

CD-BTB200

Enjoy hands-free telephony and audio streaming in your car. With
the CD-BTB200, your headunit will automatically pick up your
Bluetooth-enabled* mobile phone’s signal, meaning you can have
a conversation while your phone is in your pocket or bag.

5.1 MULTI-CHANNEL
DIGITAL SIGNAL PROCESSOR

With a built-in Dolby Digital/DTS/

Dolby Pro Logic II decoder, the
DEQ-P6600 will wrap you in impressive 5.1-channel surround
sound – for DVD-Video and audio sources.

REMOTE CONTROLS

CD-R320

CARD-TYPE REMOTE CONTROL

The adapter also lets you play streaming audio from a Bluetooth-enabled
mobile phone or audio player.

* Find out whether your mobile phone is compatible at www.pioneer.eu

TV TUNER

GEX-P5700TVPDEQ-P6600

With the GEX-P5700TVP hideaway PAL TV tuner, you can enjoy
analogue television broadcasts in your car. So, even if you’re
running late, you’ll never have to miss your favourite shows.

CD-SR100

STEERING WHEEL REMOTE CONTROL

Remote controle included

The CD-R320 is an optional card-type remote
control for the DEH-P3100UB, DEH-P4100SD,
DEH-6100BT and DEH-P7100BT headunits.

CD-SR120

STEERING WHEEL REMOTE CONTROL WITH VOICE
RECOGNITION AND BLUETOOTH OPERATION

With the CD-SR120 you can operate Bluetooth
functions and activate voice recognition all from
your steering wheel. This is an optional remote
for the DEH-6100BT* and DEH-P7100BT.

* Voice recognition is not available for the DEH-6100BT

Operate the most frequently used audio functions
directly from your steering wheel. This is an optional
remote control for the DEH-P3100UB, DEH-P4100SD
and DEH-P5100UB.

CD-R55

REMOTE CONTROL

The CD-R55 is an optional remote for all AVH models
and gives you convenient control over headunit and
DVD functions.

CABLES FOR iPod MUSIC AND VIDEO PLAYBACK

Use one of these cables to easily connect your iPod to your headunit. Visit www.pioneer.eu for a detailed overview of iPod compatibility with
our headunits.

CD-IU50

iPod-TO-USB INTERFACE CABLE

Cable for music playback. Compatible with the DEH-P3100UB,
DEH-P4100SD, DEH-P5100UB, DEH-6100BT, DEH-P7100BT and
DEH-P8100BT.

CD-IU200V

iPod VIDEO CABLE

Cable for music and video playback. Compatible with the
AVH-P4100DVD.

USB CABLE

CD-IU50V

iPod VIDEO CABLE

Cable for music and video playback. Compatible with the
DVH-P4100UB and AVH-P3100DVD.

CD-IU205V

iPod VIDEO CABLE

Cable for music and video playback. Compatible with the
AVH-P5100DVD.

CD-U50E

USB EXTENSION CABLE

As connecting a USB device directly to a front USB terminal can
interfere with driving, Pioneer offers the CD-U50E USB extension
cable. This 50 cm cable lets you connect a USB device to your
headunit safely and is compatible with all Pioneer headunits that
feature a front USB terminal.

AUX CABLES

CD-V150M

MINI-JACK AV CABLE

The CD-V150M cable lets you connect a range of external
sources, such as portable audio and video players, to your
headunit’s Aux-in connection.

CD-RM10

MINI-JACK RCA AV CABLE

The CD-RM10 mini-jack cable can be used in combination with
a DVH or AVH headunit. Use the auxiliary input to connect an
external video device or portable audio player (e.g., digital stills
camera, camcorder, games console, portable AV player, music
player or music phone).

27HEADUNITS

Make

no excuses

What does it take to be a leader? The desire to achieve

greatness? The strength to push beyond the limits? Yes,

these are all important. But you get nowhere without

passion. If you are passionate about sound, we’ve got the

equipment you need to take your listening experience to

a new level. Whether you like it pure or you need it loud, let

us help you reach the goal of exhilarating audio perfection.

29AUDIO

IT’S ALL ABOUT YOU

PASSION

We have a passion for audio. It excites and enthrals us. Because it’s our passion, we want to share it. Our motivation
is to give you, our fellow audio lovers, products that let you get the best out of your music. Because nothing can move
you like a true audio experience. We’ve always said our goal is to “move the heart and touch the soul”. And that’s what real
audio does for us.

INSPIRATION

Creating better sound is about listening. Not just to the music,
but also to the people who value sound quality and performance
audio. We are deeply involved in the sound competition scene,
both for high quality sound and SPL. These events allow us to
test our best products in the most demanding environments, but
also give us the opportunity to share ideas with people who
really care about audio. This gives us the inspiration to push
forward, helping us break the boundaries of what is expected
from audio products and further fuelling our love of sound.

INNOVATION

Our design process is the bringing together of innovative ideas and
signature technologies. The aim is to give audio fans something they
don’t see everyday. Everything we do is with your music in mind.
Unique concepts, such as Open & Smooth™ technology and the

incorporation of basalt fibres in our speaker cones, have been
developed to truly enhance your listening experience. While unique
design principles, such as the Air Suspension System, have eased
installation, making quality audio accessible to more people.

HEAR THE DIFFERENCE

SUPERIOR SOUND

Good music needs to be heard in the best quality possible. That’s why we have created a range of audio
products that takes sound quality to new heights. Think of our TAD professional studio loudspeakers,
which are revered by sound engineers worldwide for delivering the pinnacle in sound reproduction.
We used the same sound philosophy when designing our in-car range. Our Optical Digital Reference system
and RS speaker series are the benchmark for in-car sound quality for pros on the car audio competition scene.
Utilising the most advanced technologies and quality materials, these high-end components deliver the purest
sound on the market.

When it comes to achieving superior sound, we have a complete range of product solutions, all delivering a sound
experience you won’t find anywhere else.

Want to experience superior sound? Go to pages 32-58

TIME TO STEP UP

PERFORMANCE AUDIO

Never compromise on performance. That’s the design philosophy behind our tuning products. Whether it’s for competing in the toughest Sound
Pressure Level competitions or showing off on the street, the best equipment is needed to make a lasting impression. We use the same
mentality when designing our Pro DJ equipment. Designed using input from professional DJs, who are required to give a top performance night
after night, this range of products offers the reliability and quality they stake their reputation on. Our tuning subwoofers have been designed
using feedback from professional SPL competitors. This input has helped us create a range of products that really gets to the heart of what
performance audio fans require.

If you’re looking for exhilarating audio, we’ve got something that’s right up your alley. Just check out our range of performance audio products
and don’t look back.

Want to put in a top performance? Go to pages 60-73

31AUDIO

A PASSION FOR
SUPERIOR SOUND

THE FIRST CHOICE FOR THOSE WHO CARE ABOUT MUSIC

Because the way your music sounds is important, we continually push ourselves to create products that can exceed the limits
of sound purity. Our Optical Digital Reference (ODR) system and Pioneer Reference Series (PRS) are testament to this fact.
You deserve the best for your music. That’s why, for audiophiles and audio enthusiasts alike, we have always been the first choice.

We’d like to introduce our very own team of audiophiles. Team Pioneer consists of the best car audio installers Europe has to offer.
As they regularly compete in the scene’s most demanding sound challenges, they require the best audio components available.
That’s where we come in. It’s the perfect partnership. While Team Pioneer competes using our audio components, we get valuable
insight into how our products perform on the biggest stage. Everything we learn goes into making our products more capable of handling
your music.

EUROPEAN NUMBER ONE

As far as high-quality sound competitions

go, the EMMA (European Mobile Media
Association) European Finals is where it really counts. Only open to
the top 2 cars from each nation, this competition pits the best
against the best. At the 2008 finals in Wels, Austria, Team Pioneer
was crowned with 6 European champions, 5 vice European
champions and also picked up 3 third-place finishes.

The winning team at the 2008 EMMA European Finals in Wels, Austria

A COMMITMENT
TO YOUR MUSIC

IT’S A PERSONAL THING

Just as a good song requires the perfect combination of elements – rhythm, melody, lyrics – creating your perfect in-car sound
system is about choosing the best components to suit your needs. Whether you‘re an audiophile who cares about reproducing
music in its purest form or an audio enthusiast looking to relive the experience of your favourite live performance, selecting
the best equipment for you is essential. We have conveniently grouped our superior sound products to help you find the
perfect solution.

SUPERIOR SOUND FOR AUDIOPHILES

You are passionate about creating perfect audio. You love piecing
together a range of separate components to find that perfect
symbiotic whole. You demand high-quality products that can take
your audio experience to the next level. Pioneer’s Optical

P34 Optical Digital Reference system

P36 RS speaker series

P38 High-end Pioneer Reference Series

P42 High-quality Pioneer Reference Series

SUPERIOR SOUND FOR AUDIO ENTHUSIASTS

You care about music. It’s part of your life. You know there is nothing
quite like listening to your favourite song or album on the road.
But is your car stereo really getting the best out of your music?
Pioneer offers a range of solutions to make high-quality audio

Digital Reference system and Pioneer Reference Series are
perfect for you. These systems have been built to aid even
the hardest-to-please audiophiles as they strive for perfect in-car
audio. Are you ready to take your passion to a new level?

attainable to you. Whether you are looking for pure and smooth sound
or simply an upgrade in quality from your original factory-installed
speakers, there’s something here for you.

P44 High-quality TS-E speaker series

P48 Space-saving solutions

P50 Easy installation solutions

P52 Custom-fit solutions

P56 Easy upgrade solutions

33AUDIO SUPERIOR SOUND

THE PUREST SOUND AROUND

OPTICAL DIGITAL REFERENCE (ODR) SYSTEM

Let us introduce the result of our search for perfect in-car sound: the Optical Digital Reference system. A masterpiece
of engineering, this system reproduces a sound so pure, you’ll feel like you’ve discovered music all over again.

RS-D7RII

SYSTEM CONTROL CD TUNER

THE PERFECT COMBINATION

The foundation of the ODR system is an optical digital connection between the CD tuner and amplifier, which guarantees the most
accurate transmission of the audio signal to the speakers. There’s no noise and no distortion, just perfect in-car sound.

RS-A9

DIGITAL POWER AMPLIFIER WITH INTEGRATED DSP

RS-A7

DIGITAL POWER AMPLIFIER

For full product specifications, please visit www.pioneer.eu

A WINNING COMBINATION

TEAM PIONEER AND ODR

It’s the perfect combination of high-quality products and installation expertise that makes
Team Pioneer so successful in high-quality sound competitions. These contests are all

about reproducing music as close to the original sound as possible. The goal is sound purity,
not to be the loudest or most powerful. It’s here that Team Pioneer has proven the ODR system and RS speakers to be top
of their class.

CONTINUED SUCCESS

In the three years since its inauguration, Team Pioneer has come to dominate the European competition circuit. In 2006, its first year of
competing, the team was already crowned with a vice European champion. In 2008, the team won close to 50 % of all entered competitions
and now boasts 19 national champions, 6 European champions and 5 vice European champions.

2007 RESULTS 2008 RESULTS

Overall results for 2007:

11 national champions ›
48 first-place cups ›
15 second-place cups ›
5 third-place cups ›
Podium places in 76 % of all entered competitions ›

2007 EMMA European Finals:

1 European Best of Show car ›
1 European Best of Sound title ›
2 European champions ›
5 vice European champions ›
1 third-place finish ›

2007 IASCA European Finals:

1 European Second-best of Sound award ›

Overall results for 2008:

19 national champions ›
98 first-place cups ›
42 second-place cups ›
20 third-place cups ›
Podium places in 79 % of all entered competitions ›

2008 EMMA European Finals:

6 European champions ›
5 vice European champions ›
3 third-place finishes ›

Follow the team at www.pioneer.eu/teampioneer

35AUDIO SUPERIOR SOUND

THE PINNACLE
OF SOUND REPRODUCTION

RS SPEAKER SERIES

The perfect accompaniment to the ODR system, RS speakers are the outcome of years of fine-tuning by Pioneer’s top engineers.
The results are simply astounding. Handcrafted by skilled technicians, they guarantee every sound your hear resonates with rich
texture. You think you know sound? You’ve heard nothing yet.

TS-SO1RSII

7.7 CM MIDRANGE

TS-M01RSII

17 CM MID-BASS DRIVER

For full product specifications, please visit www.pioneer.eu

TS-T01RSII

3.5 CM SUPER WIDE-RANGE TWEETER

UD-NO1RSIITS-W01RSII

2-WAY PASSIVE CROSSOVER NETWORK25 CM SUBWOOFER

THE CHOICE OF CHAMPIONS

ODR WINS AGAIN

While 20 07 and 2008 were t wo very successful years for Team Pioneer, one member in
particular stood out from the crowd. In 2007, Norway’s Ketil Skjei scooped up both the

Best of Sound and Best of Show awards at the EMMA European Finals, while in 2008
he became European champion in the EMMA Master 7 category. His award-winning BMW 728iL is fitted with 100 %
Pioneer products, including an ODR headunit and amplifiers and the full range of RS speakers.

THE FIRST CHOICE

It’s no coincidence that so many Team Pioneer members choose ODR and RS components for competing on the biggest stage. Using only
ODR and RS components for their car installs, Germany’s Dirk Wölfinger and Norway’s Anders Fleischer have enjoyed great success on
the European competition scene. Dirk Wölfinger is current European champion in the EMMA Master Unlimited category, while Anders
Fleischer is current European champion in the EMMA Advanced 5 category.

HOW YOU BENEFIT FROM THE TEAM’S SUCCESS

While Team Pioneer keeps winning, our engineers keep learning.
At Pioneer, we see the high-quality competition scene as a test
field for our products, a chance to see how they perform under the
hardest conditions. What we learn at the highest level is

transmitted to the whole Pioneer range. Whatever product we are
developing, we always apply the same winning mentality, to
ensure all of our products live up to the reputation of our high-end
audio components.

Follow the team at www.pioneer.eu/teampioneer

37AUDIO SUPERIOR SOUND

DISCOVER A NEW

SOUND EXPERIENCE

HIGH-END PIONEER REFERENCE SERIES (PRS)

By using the most advanced components and innovative technologies, this PRS system offers unsurpassed quality
and sophisticated designs. It’s time to get behind the wheel and take your music to a new level.

RS-P90

UNIVERSAL DIGITAL PREAMPLIFIER

AXM-P90RS

AUDIO MASTER UNIT

THE ULTIMATE FACTORY UPGRADE

If you have a factory-installed headunit that can’t be easily replaced,
the AXM-P90RS is the easiest way of achieving the highest-quality car
audio. With this unit you can create a full-blown sound system tailored

DEX-P90RS

COMPONENT CD RDS TUNER

Remote control included

specifically to your musical taste and car interior. For the perfect
combination, use the AXM-P90RS with the RS-P90
preamplifier, to realise the ideal sound field of your car.

universal digital

DEQ-P90

DIGITAL PREAMP/EQUALISER

THE SYSTEM OF CHOICE

The high-end PRS has a reputation for being the best high-end car entertainment system around. That’s because it remains to be the system
of choice for competitors on the high-quality sound circuit. And once you’ve experienced it, you’ll definitely hear why.

For full product specifications, please visit www.pioneer.eu

READ ALL ABOUT IT

“The PRS-A900 is top-notch. The efforts to

develop one of the most distortion-free and

at the same time most powerful amps in its
class have finally paid off. For those looking
for a high-end power amp to complete their
front system, it has just arrived.”

Car & hifi magazine (Germany)

PRS-A900

4-CHANNEL BRIDGEABLE POWER AMPLIFIER

4 x 100 W (4 Ω) /2 x 200 W (4 Ω) ma x.
4 x 50 W (4 Ω)/2 x 100 W (4 Ω b ridged) continuous outpu t power

PERFECT SYMMETRY

The PRS-A900’s left and right channel circuits have been positioned completely
symmetrically and are separated by a copper-coated T-shaped partition board. This
blocks out radiation noise from the power supply, resulting in minimum distortion
and maximum sound intensity and clarity. The PRS-A900 also has no crossover
function, which ensures the left and right channels are completely isolated. This
reduces noise and enhances the overall sound experience.

TOTAL VIBRATION CONTROL CONCEPT THE PERFECT BALANCE

Natural vibrations of a car can be transferred to

components inside an amplifier, affecting sound
quality. The PRS-A900’s patented sandwich construction keeps
power transistors firmly in place, reducing the effects of vibration,
while the H-shaped chassis absorbs the outer vibration.

installation based on the principles of symmetry and vibration
control. This installation helped him become the European
champion in the EMMA Multimedia Expert category in 2008.

Using 5 PRS-A900 amplifiers, Team Pioneer
member Viktor Ivanov has created a car

39AUDIO SUPERIOR SOUND

REACH A NEW
LEVEL OF SOUND

PRS HIGH-CLASS SPEAKERS

Pioneer’s PRS speakers are for those who really care about reproducing top-quality audio. The choice for serious
contenders on the high-quality sound competition scene, they literally wrap you in pure, powerful sound.

For full product specifications, please visit www.pioneer.eu

PRS HIGH-CLASS COMPONENT SPEAKERS

TS-T031PRS

2.8 CM TWEETER

TS-S101PRS

10 CM MID-HIGH RANGE DRIVER

TS-M171PRS

17 CM MID-BASS DRIVER

200 W MAX.

60 W MAX.

200 W MAX.

TS-C171PRS

17 CM SEPARATE 2-WAY SPEAKER SYSTEM

50 W nominal input power

WHAT THE PRESS HAD TO SAY

“In the autohifi audio test room, this Pioneer system excited

us with its powerful yet clean and punchy bass. This was
joined by pure strong vocals and a nearly seamless
crossover to the tweeter. This is the best system you
will find in this price range.”

“Only on rare occasions have we heard such distortion-free

sound. In this sense, these high-end car speakers
work perfectly.”

autohifi magazine (Germany)

200 W MAX.

PRS HIGH-CLASS SEPARATE COMPONENT SPEAKER SYSTEMS

TS-C131PRS

13 CM SEPARATE 2-WAY SPEAKER SYSTEM

30 W nominal in put power

150 W MAX.

INSTALLATION EXAMPLES

TS -M 171P RS TS-S101PRS and TS-T031PRS

41AUDIO SUPERIOR SOUND

PROVEN PERFORMERS

HIGH-QUALITY PIONEER REFERENCE SERIES

Regularly appearing on the high-quality sound competition circuit, this system is capable of producing a perfect performance,
time after time. Comprising a range of high-quality components, it’s the best in its class for true and natural sound.

DEH-P88RSII

COMPONENT CD RDS TUNER

A TOUCH OF CLASS

Using the DEH-P88RS and PRS-D410,

predecessors of the DEH-P88RSII and
PRS-D420, Germany’s Susanne Böhm has managed two
very successful years with Team Pioneer. In 2007 she was

Susanne’s VW Beetle was chosen as having the second-best car audio installation for 2008 by readers of 'autohifi' car audio magazine

Remote control included

In 2008, the DEH-P88RSII was the number one choice for high-end

tuners amongst the readers of German car audio magazine 'autohifi'

both German and European champion in the EMMA
Experienced 3 category, while in 2008 she became German
champion and vice European champion in the EMMA
Advanced 5 category.

PRS-D420

4-CHANNEL CLASS-FD AMPLIFIER

4 x 150 W (4 Ω) /2 x 600 W (4 Ω) ma x.
4 x 75 W (4 Ω) /4 x 150 W (2 Ω )/2 x 300 W (4 Ω ) continuous outp ut power

PRS-D220

2-CHANNEL CLASS-FD AMPLIFIER

2 x 300 W (4 Ω )/1 x 1200 W (4 Ω ) max.
2 x 150 W (4 Ω) /2 x 300 W (2 Ω) /1 x 600 W (4 Ω) con tinuous output power

For full product specifications, please visit www.pioneer.eu

A POWERFUL MATCH

If you’re looking for pure, powerful sound, Pioneer offers the perfect amplifier and subwoofer combination. The TS-W12PRS
subwoofer is equipped with a Voice Coil Cooling System (VCCS™), so the sound it produces stays natural. Perfect for
connecting a subwoofer, the PRS-D1200M can remain stable at a 1 ohm impedance level and features gold-plated terminals,
so there’s no power distortion.

v

TS-W12PRS PRS-D1200M

30 CM DUAL VOICE COIL SUBWOOFER

300 W nominal input pow er

1200 W MAX.

MONO-CHANNEL CLASS-D AMPLIFIER

1 x 800 W (4 Ω )/1 x 1200 W (1 Ω /2 Ω) max.
1 x 400 W ( 4 Ω)/1 x 600 W (2 Ω)/1 x 6 00 W (1 Ω) continuous outpu t power

AMP/SUB CONFIGURATION EXAMPLE

2 subwoofers (as 4 Ω mono)

PR S-D12 00M

POWER IN ACTION

8 Ω

TS- W12PRS

TS- W12PRS

8 Ω

The TS-W12PRS subwoofer features in
the installs of Team Pioneer members

Björn Rosenhauer and Pascal Seiler. Both Björn’s Opel Corsa

and Pascal’s BMW 120D contain two of these high-powered
PRS subwoofers, while Pascal’s installation also contains two
PRS-D1200M and two PRS-D420 amps.

43AUDIO SUPERIOR SOUND

DO YOUR EARS A FAVOUR

TS-E SPEAKER SERIES

Calling all audio enthusiasts. Do you want to hear your favourite music the
way it was supposed to be heard? Do you want to experience pure audio in

your car? Pioneer’s TS-E speakers are the best in their class for producing
powerful, high-quality audio. Utilising Open & Smooth ™ technology, they deliver open staging and smooth transitions to
ensure nothing but accurate, full-bodied sound.

A FAVOURITE OF THE PRESS

“Every wisp and breath transpired with a realism that

I’ve only experienced in systems in a much higher
price category”

“I felt a bit overwhelmed by the clarity which this

inexpensive set provided”

“Never have I experienced a set of speakers in this

price range that sound nearly as good as these”

“As far as I’m concerned, Pioneer nailed it”

Car Audio and Electronics magazine (USA)

“We’ve never heard such full-bodied sound from any

speakers for such low a price”

autohifi magazine (Germany)

In 2008, Pioneer’s TS-E170CI speakers were

the number one choice for readers of German

car audio magazine ‘autohifi’

For full product specifications, please visit www.pioneer.eu

SEPARATE COMPONENT SPEAKER SYSTEMS

TS-E170CI

17 CM SEPARATE 2-WAY SPEAKER SYSTEM

60 W nominal in put power

TS-E130CI

13 CM SEPARATE 2-WAY SPEAKER SYSTEM

35 W nominal in put power

260 W MAX.

180 W MAX.

45AUDIO SUPERIOR SOUND

THE SECRET BEHIND PURE SOUND

Open & Smooth™ technology is the result of years of interaction between Team Pioneer and our sound
engineers. What’s the concept? To create truly accurate sound, speakers should be able to reproduce
the ambience in which sounds originate. Think of a live stage performance. Stage size, the movement of

musicians, aural reflection: these are all details that bring sounds to life. Speakers incorporating Open
and Smooth™ technology can recreate this ambience. They produce a smoother, multidimensional sound, so you can really
experience your music as if you were at a live stage performance.

OPEN

Experience your music as though it were coming from a wide,
open stage right in front of your dashboard.

SMOOTH

Feel the smooth transition between sound frequencies,
giving a natural and dynamic flow to the music.

SOLID AS A ROCK

Volcanic basalt rock Basalt fibres Speaker cone with interwoven basalt and aramid fibres

TS-E speaker cones are reinforced with basalt fibre, for increased
strength and stability. The use of basalt in speaker cones is unique
to Pioneer and allows us to create speakers that deliver more
precise sound and better bass reproduction. To create these solid
speaker cones, pulverised volcanic basalt rock is melted down at
a temperature of over 1480°C and drawn into long, thin fibres.

For full product specifications, please visit www.pioneer.eu

These basalt fibres are interwoven with aramid fibres and are
placed into the mould just before the foamed IMPP™. As the
foamed IMPP™ hardens, it fuses to the fibres, creating a
one-piece cone. The result is a speaker that is lightweight,
super-strong, well-damped, stable in extreme temperatures and
environmentally friendly.

COAXIAL 2-WAY SPEAKERS

TS-E6902I

6" X 9" COAXIAL 2-WAY SPEAKERS

80 W nominal in put power

TS-E1702IS

17 CM COAXIAL 2-WAY SPEAKERS

60 W nominal in put power

TS-E1302I TS-E1002I

13 CM COAXIAL 2-WAY SPEAKERS

35 W nominal in put power

360 W MAX.

280 W MAX.

180 W MAX.

TS-E2002I

20 CM COAXIAL 2-WAY SPEAKERS

90 W nominal in put power

TS-E1702I

17 CM COAXIAL 2-WAY SPEAKERS

35 W nominal in put power

10 CM COAXIAL 2-WAY SPEAKERS

25 W nominal in put power

360 W MAX.

180 W MAX.

110 W MAX.

47AUDIO SUPERIOR SOUND

WHEN SIZE MATTERS

NO COMPROMISE ON PERFORMANCE

Want great sound without having to give up your whole car boot? Pioneer’s space-saving amps and shallow-type subwoofers
need less space, without compromising on power.

CLASS-D AMPLIFIERS

GM-D8400M

MONO-CHANNEL CLASS-D AMPLIFIER

1 x 600 W (4 Ω )/1 x 1200 W (2 Ω ) max.
1 x 300 W (4 Ω )/1 x 600 W (2 Ω ) continuous out put power

45 % OF THE SIZE,
100 % OF THE POWER

GM-D7400M

MONO-CHANNEL CLASS-D AMPLIFIER

1 x 400 W ( 4 Ω)/1 x 800 W (2 Ω) max.
1 x 200 W (4 Ω )/1 x 400 W ( 2 Ω) continuous output power

THE CLASS-D DIFFERENCE

Current vs. power

50

40

30

Current (A)

20

10

500 100 200 300 400 500

Power output (Watt - 4 Ω)

Class-D amplifiers overcome the inefficiencies of traditional Class-A and Class-AB amplifiers.
They transform very little power into heat, while a very large percentage of the power supply
(67 %) is transferred into the load. This results in a very compact amp that needs little input
power to produce very high output power.

Class - AB
Class - D

SPACE-SAVING DESIGN

A typical subwoofer uses a damper (spider) to control the woofer
cone’s excursion. The Air Suspension Excursion Control System,
formed by creating a sealed air space between the double cones,
effectively replaces the damper, providing excellent design and

For full product specifications, please visit www.pioneer.eu

performance characteristics. It provides superior compliance
linearity, regardless of volume input, for reproducing exceptionally
clear, low-distortion bass sound. This has also allowed enclosure
volumes to be reduced by 70 %.

SHALLOW-TYPE SUBWOOFERS

TS-SW3001S4

30 CM SHALLOW-TYPE 4  SINGLE VOICE COIL SUBWOOFER

400 W nominal input po wer

1500 W MAX.

TS-SW3001S2

30 CM SHALLOW-TYPE 2  SINGLE VOICE COIL SUBWOOFER

400 W nominal input po wer

TS-SW1041D

25 CM SHALLOW-TYPE 4  SINGLE VOICE COIL SUBWOOFER

250 W nominal input power

FLAT SUB, ROCK-SOLID BASS

Don’t be fooled by their flat design. Our shallow-type subs have
speaker cones reinforced with basalt fibres, which means they are
capable of producing a powerful and punchy bass sound.

CUSTOM ENCLOSURE BOXES

1500 W MAX.

1000 W MAX.

UD-SW125S

CUSTOM ENCLOSURE BOX FOR
TS-SW3001S4 AND TS-SW3001S2

Protection bars included

TS-SW841D

20 CM SHALLOW-TYPE 4  SINGLE VOICE COIL SUBWOOFER

120 W nominal in put power

Mounting depth:
30 cm sub: 8.1 cm
25 cm sub: 7.5 cm

500 W MAX.

UD-SW104S

CUSTOM ENCLOSURE BOX FOR TS-SW1041D

Protection bars included

UD-SW84S

CUSTOM ENCLOSURE BOX FOR TS-SW841D

Protection bars included

49AUDIO SUPERIOR SOUND

EASY INSTALLATION SOLUTIONS

THE SHORTEST ROUTE TO GREAT SOUND

High-quality sound need not come with all of the installation worries. With minimal installation time required, these products
offer the perfect audio upgrade in the quickest time possible.

Q-LEVEL SPEAKERS

If you drive a Renault, Peugeot, Citroën or Opel/Vauxhaull, achieving smooth

and accurate in-car sound is easier than you think. Q-level speakers can be
installed in your existing speaker locations; no modifications are required. The result is exceptionally high-quality in-car
sound, without any installation worries.

TS-Q172C

17 CM SEPARATE 2-WAY SPEAKER SYSTEM

50 W nominal input power

OPEL/VAUXHALL PERFECT-FIT

220 W MAX.

TS-Q171C TS-Q131C

17 CM SEPARATE 2-WAY SPEAKER SYSTEM

40 W nominal input power

CITROËN PEUGEOT PERFECT-FIT

200 W MAX.

13 CM SEPARATE 2-WAY SPEAKER SYSTEM

35 W nominal in put power

RENAULT PERFECT-FIT

NO MODIFICATIONS NECESSARY HEAR THE DIFFERENCE

Now anyone can become a car stereo installer. Pioneer’s Q-level
speakers are designed to fit perfectly into your car’s existing factory­installed speaker locations – no extra cutting or drilling is required.
All models also come complete with a quick installation guide.

Q-level separate component speakers combine a KEVLAR® brand
fibre woofer with a soft dome tweeter to make for low distortion,
high resolution and smooth response. While the woofer guarantees
a lively dimension, the soft dome tweeter adds natural overtones.
It’s an upgrade in sound quality that you’ll really notice in your music.

180 W MAX.

For full product specifications, please visit www.pioneer.eu

AMPLIFIED SUBWOOFER

TS-WX77A

DOUBLE 16 CM BACK-LOADED HORN ACTIVE SUBWOOFER

200 W MAX.

Standard wired remote control

RICH AND SPEEDY BASS SOUND

The symmetrical back loaded horn structure of the TS-WX77A
is driven by two 16 cm subs. This makes for a rich and speedy
bass sound that is unexpected from such a flat sub.

Only 8.2 cm high

ULTRA-FLAT AND SCRATCH RESISTANT

The TS-WX77A inside the boot of a Mini Cooper

Being only 8.2 cm high, the TS-WX77A won’t monopolise your car
boot. You can even put your luggage on top of it: the tough
polyurethane skin is anti-slip and anti-scratch.

51AUDIO SUPERIOR SOUND

CUSTOM-FIT SOLUTIONS

CUSTOM-FIT SPEAKERS

Want high-quality sound, but don’t want to spend too much time on installation? Our brand new custom-fit speakers
are the perfect solution. They can be matched to a specific make and model of car to ensure the best fit.

SEPARATE COMPONENT CUSTOM-FIT SPEAKER SYSTEMS

TS-170CI

17 CM SEPARATE 2-WAY SPEAKER SYSTEM

35 W nominal in put power

Easy Connector for: Chevrolet, Citroën, Daewoo, Fiat, ›

Hyundai, Kia, Opel, Peugeot, Renault, Toyota, Volkswagen

Tweeter adaptors included for: Citroën, Opel, ›

Peugeot and Volkswagen

170 W MAX.

TS-130CI

13 CM SEPARATE 2-WAY SPEAKER SYSTEM

25 W nominal in put power

Easy Connector for: Opel, Renault, Volkswagen ›
Tweeter adaptors included for: Renault ›

For full product specifications, please visit www.pioneer.eu

130 W MAX.

QUALITY YOU’LL NOTICE

BALANCED-DOME TWEETER

Pioneer’s new separate component and 2-way coaxial custom-fit
speakers now feature a 30 mm PEI balanced dome tweeter.
These tweeters produce highly vivid sound, so you’ll really
notice the difference in sound quality.

EASY CONNECTORS

As more and more cars have a specific connector

for their factory-installed speakers, upgrading your
sound system with new speakers can become complicated.
Although factory connectors can be cut and replaced with
universal connectors, this process is time consuming and

REINFORCED WOOFER CONE

The woofer cone of new custom-fit speakers is made from a
stronger material. This allows for more precision in the lower
bass tones and a better live experience.

you always risk making a wrong connection. To counter this,
we have developed the Easy Connector. These connectors are
made for specific car brands and make installation extremely
easy. Just plug them in, and off you go.

EASY CONNECTOR FOR 17 CM CUSTOM-FIT SPEAKERS

Type 1 Type 2 Type 3

2

car speaker

Easy C onnector

Fiat, Opel, Renault, Toyota Citroën, Peugeot Chevrolet/Daewoo, Hyundai, Kia, Opel

1

EASY CONNECTOR FOR 13 CM AND 10 CM CUSTOM-FIT SPEAKERS

Installing a universal speaker requires cutting the wire so it fits the speaker correctly. With custom-fit speakers, you can simply plug the Renault, Opel or Volkswagen

wire into the Easy Connector.

53AUDIO SUPERIOR SOUND

COAXIAL 2-WAY CUSTOM-FIT SPEAKERS

TS-1702I

17 CM COAXIAL 2-WAY SPEAKERS

35 W nominal in put power

Easy Connector for: Citroën, Hyundai, Kia, Opel, Peugeot, ›
Renault, Volkswagen

170 W MAX.

TS-1302I

13 CM COAXIAL 2-WAY SPEAKERS

25 W nominal in put power

Easy Connector for: Opel, Renault, Volkswagen ›

DUAL-CONE CUSTOM-FIT SPEAKERS

TS-1701I

17 CM DUAL-CONE SPEAKERS

35 W nominal in put power

Easy Connector for: Citroën, Hyundai, Kia, Opel, ›
Peugeot, Renault, Volkswagen

TS-1301I

13 CM DUAL-CONE SPEAKERS

25 W nominal in put power

130 W MAX.

170 W MAX.

130 W MAX.

TS-1002I

10 CM COAXIAL 2-WAY SPEAKERS

25 W nominal in put power

Easy Connector for: Opel, Renault, Volkswagen ›

TS-1001I

10 CM DUAL-CONE SPEAKERS

20 W nominal input power

120 W MAX.

110 W MAX.

Easy Connector for: Opel, Renault, Volkswagen ›

For full product specifications, please visit www.pioneer.eu

Easy Connector for: Opel, Renault, Volkswagen ›

AMPLIFIED SUBWOOFERS

Our amplified subwoofers are the perfect solution for people with limited time and limited space. With built-in MOSFET
amplifiers, they offer powerful bass sounds, without any of the installation worries.

TS-WX22A

20 CM SEALED AMPLIFIED SUBWOOFER

Standard wired remote control

150 W MAX.

TS -WX11A

12.8 CM X 20.8 CM OVAL CONE SEALED-TYPE AMPLIFIED SUBWOOFER

Standard wired remote control

150 W MAX.

Horizontal or vertical installation

Horizontal or vertical installation

55AUDIO SUPERIOR SOUND

EASY UPGRADE SOLUTIONS

TIME TO MAKE THE CHANGE

Not happy with the sound from your existing car speakers? Pioneer offers a selection first-stop solutions for upgrading your
car audio at an amazing price, making it easier than ever to take that first step to great in-car sound.

TS-G SPEAKERS

TS-G171C

17 CM SEPARATE 2-WAY SPEAKER SYSTEM

35 W nominal in put power

SEPARATE COMPONENT SPEAKER SYSTEMS

170 W MAX.

TS-G131C

13 CM SEPARATE 2-WAY SPEAKER SYSTEM

25 W nominal in put power

A NEW SOUND EXPERIENCE

For full product specifications, please visit www.pioneer.eu

130 W MAX.

Engineers with an ear for live and powerful sound have redesigned our TS-G speakers.
With an IMPP™ woofer cone, these speakers boast an outstanding tolerance to high
volume levels, extreme temperatures and humidity. Thanks to the combination of high-quality
components, TS-G speakers can turn your drive into a live sound experience.

COAXIAL 3-WAY SPEAKERS

TS-G1703I

17 CM COAXIAL 3-WAY SPEAKERS

35 W nominal in put power

180 W MAX.

TS-G1303I

13 CM COAXIAL 3-WAY SPEAKERS

25 W nominal in put power

TS-G1302I

13 CM COAXIAL 2-WAY SPEAKERS

25 W nominal in put power

140 W MAX.

COAXIAL 2-WAY SPEAKERS

130 W MAX.

TS-G1003I

10 CM COAXIAL 3-WAY SPEAKERS

25 W nominal in put power

TS-G1702I

17 CM COAXIAL 2-WAY SPEAKERS

35 W nominal in put power

TS-G1002I

10 CM COAXIAL 2-WAY SPEAKERS

25 W nominal in put power

130 W MAX.

170 W MAX.

120 W MAX.

DUAL-CONE SPEAKERS

TS-G1701I

17 CM DUAL-CONE SPEAKERS

35 W nominal in put power

TS-G1301I

13 CM DUAL-CONE SPEAKERS

25 W nominal in put power

170 W MAX.

130 W MAX.

TS-G1001I

10 CM DUAL-CONE SPEAKERS

20 W nominal input power

110 W MAX.

57AUDIO SUPERIOR SOUND

HIGH-GRADE CUSTOM-FIT SPEAKERS

TS-H1703

17 CM SEPARATE 2-WAY SPEAKER SYSTEM

50 W nominal input power

Easy Connector for: Alfa Romeo, Audi, BMW, Citroën, Fiat, ›
Ford, Lancia, Opel/Vauxhall, Peugeot, Renault, Rover, Seat,
Skoda, Volkswagen, Volvo

TS-H687

6" X 8" COAXIAL 3-WAY SPEAKERS

50 W nominal input power

Ford, Jaguar, Mazda › Daewoo/Chevrolet, Fiat, Lancia, Seat, Volkswagen ›

SURFACE MOUNT SPEAKERS

180 W MAX.

240 W MAX.

TS-H1303

13 CM SEPARATE 2-WAY SPEAKER SYSTEM

35 W nominal in put power

Easy Connector for: Alfa Romeo, BMW, Citroën, Hyundai, ›
Lada, Opel/Vauxhall, Peugeot, Renault, Rover, Volvo

TS-H467

4" X 6" COAXIAL 2-WAY SPEAKERS

25 W nominal in put power

130 W MAX.

110 W MAX.

TS-CX7

CENTRE SPEAKER FOR 5.1-CHANNEL SURROUND SOUND

20 W nominal input power

TWEETERS

TS-S15

TUNE-UP DOME TWEETERS

40 W nominal input power

For full product specifications, please visit www.pioneer.eu

60 W MAX.

120 W MAX.

TS-X150

3-WAY SPEAKERS

20 W nominal input power

TS-44

FULL-RANGE SPEAKERS

10 W nominal inpu t power

60 W MAX.

40 W MAX.

PIONEER ONLINE

Pi oneer ’s we bsi te h as be en redesig ned, so now yo u can br ows e the exte nsi ve li ne- up o f produc ts w ith ease. Go t o w ww.p ione er.e u
for audio entertainment news, extensive Pioneer product information and the latest Team Pioneer news, competition results
and videos. See you there.

MATCH PRODUCTS TO YOUR CAR

Now you can find the perfect products for your car online. Simply go to the car entertainment section of www.pioneer.eu and enter
the make, model and year of your car. You will then be given a selection of products that perfectly matches your specifications. It’s
that easy.

MATCH YOUR SUB AND AMP DOWNLOAD

Find the perfect amp to drive your subwoofer. When you select an
amp or subwoofer at www.pioneer.eu, you can click on the ‘related’
tab to see the best products to match your selection.

www.pioneer.eu is also the place to download the latest Pioneer
product brochures, product manuals and software and firmware
updates for your Pioneer equipment.

JOIN OUR QUEST FOR PERFECT IN-CAR SOUND

Join Team Pioneer in its pursuit for sonic perfection. Read
all about the team and its members, see the cars,watch videos

www.pioneer.eu/teampioneer

www.flickr.com/photos/teampioneer www.youtube.com/teampioneer www.myspace.com/teampioneer www.facebook.com

of the events and find out all the latest competition results.

59AUDIO SUPERIOR SOUND

THE #1 CHOICE
FOR PERFORMANCE AUDIO

POWER WHEN IT REALLY COUNTS

When the number of decibels matters, there should be no fooling around. Years of competing in the world’s most demanding
SPL competitions have helped us create the toughest and most reliable audio components you’re likely to find. You want
power? You’ve come to the right place.

THE WORLD’S BEST USE PIONEER

With the help of Pioneer, the USA’s Team Edge Audio became the first
ever team to win all 4 sanctioned SPL world finals in one year
(IASCA, USACi, dB Drag and MECA). The team has won 25 world
titles with Pioneer equipment.

Team Pioneer has a number of Sound Pressure Level specialists
in its ranks. They have gained success at both the national and
European levels.

YOU LIKE IT LOUD?

NO MORE COMPROMISES

Pure and powerful sound – that’s what our performance audio products are all about. So, whether it’s on the competition
scene or on the streets, you’ll have the power to give a performance you can rely on.

PRO SPL

Sound Pressure Level competitions are all about power and reliability. It’s
on this stage where audio products are put to the test; if the equipment
is not of the highest quality, it just won’t make the cut. That’s why Pioneer

P62 Professional competition-grade SPL subwoofers

P64 Competition-grade SPL amplifiers

P65 Competition-grade SPL subwoofers

STREET TUNING

Loud music belongs on the street, where everyone can hear it.
An impressive audio performance requires equipment with attitude.
Nothing has more attitude than Pioneer’s street tuning products.

is a top choice for pro SPL competitors. Our SPL amps and subs are
regular performers on the international stage for one simple reason:
rock-solid, reliable power.

Stylishly designed and full of power, our tuning subs, amps and
speakers are ready to carry your sound to new heights.

P66 a-Ccelerate subwoofers

P69 Bridgeable amplifiers

P70 a-Ccelerate free-air subwoofers

P71 a-Ccelerate speakers

61AUDIO PERFORMANCE AUDIO

THE PROS’ CHOICE

PROFESSIONAL COMPETITION-GRADE SPL SUBWOOFERS

Prepare to be blown away. Pioneer’s professional SPL
subwoofers take power to a whole new level. These subs
are the biggest on the block, regularly dominating

international SPL competitions. It’s time to hear what real power sounds like.

WELCOME TO THE 180 dB CLUB

In an outstanding achievement, Team Edge Audio member Scott Owens became the first person to break the 180 dB sound barrier in an
SPL competition. His record-breaking Ford F-250 was decked out with 13 Pioneer TS-W5102SPL subwoofers and 52 PRS-D5000SPL
amplifiers (predecessor of the PRS-D2000SPL). This achievement earned Scott a place in the very exclusive “180 dB club”.

SO, HOW LOUD IS 180 dB?

Want to know what it’s like to break the sound barrier? Below you will find an indication of just how loud Scott Owens’ audio system
sounded at 180 dB.

NORMAL CONVERSATION

MUSIC AT A ROCK CONC ERT JET ENGINE TAKING OFF THRESHOLD OF PAIN ROCKET ENGINE

60 dB 110 dB 120 dB 140 dB 180 dB

SCOT T OWENS’ FORD F-250

For full product specifications, please visit www.pioneer.eu

TS-W8102SPL

38 CM COMPETITION-GRADE SPL 2  DUAL VOICE COIL SUBWOOFER FOR PROFESSIONAL USE

300 0 W nominal input power

TS-W5102SPL

30 CM COMPETITION-GRADE SPL 2  DUAL VOICE COIL SUBWOOFER FOR PROFESSIONAL USE

250 0 W nominal input power

r

8000 W MAX.

6000 W MAX.

Turn the page for the perfect amps to power these champion subs…

63AUDIO PERFORMANCE AUDIO

POWER YOU CAN RELY ON

COMPETITION-GRADE SPL CLASS-D AMPLIFIERS

These pro amplifiers are just the thing to power our champion subs. Their stability at high pressure levels has allowed them to break
new records in SPL competitions and push beyond the 180 dB sound barrier. This is proven power of the highest magnitude.

PRS-D2000SPL

COMPETITION-GRADE SPL CLASS-D AMPLIFIER

1 x 400 0 W (1 Ω)/1 x 30 00 W (2 Ω)/1 x 1500 W (4 Ω) ma x.
1 x 200 0 W (1 Ω)/1 x 1500 W ( 2 Ω)/1 x 750 W ( 4 Ω) continuous ou tput power

PRS-D1200SPL

COMPETITION-GRADE SPL CLASS-D AMPLIFIER

1 x 2400 W (1 Ω)/1 x 2000 W ( 2 Ω)/1 x 1000 W (4 Ω) max.
1 x 1200 W (1 Ω )/1 x 1000 W (2 Ω )/1 x 500 W (4 Ω ) continuous output power

MULTI-AMPLIFIER SYNCHRONISATION SYSTEM (MASS)

Pioneer’s exclusive Multi-Amplifier Synchronisation System gives
you easy control over a multi-amp system. Adjustments that
are made to the ‘master’ amplifier are automatically made to all

A WINNING PERFORMANCE

other connected amplifiers. This makes controlling up to four amps
easier than ever before.

Using the PRS-D2000SPL amplifier to power his TS-W5102SPL monster sub, Team Pioneer member Lars Engel became German vice champion
in the ESPL Experienced 2 category at the German 2008 EMMA Finals.

For full product specifications, please visit www.pioneer.eu

A CLASS ABOVE

COMPETITION-GRADE SPL SUBWOOFERS

Based on pure power alone, these competition-grade
subs are simply the best in their class. When you factor
in a construction designed to exceed the expectations of
sound quality, you know you’re in for one truly deep
bass experience.

TS-W3002D4

30 CM COMPETITION-GRADE SPL 4  DUAL VOICE COIL SUBWOOFER

1000 W nominal input pow er

TS-W2501D4

25 CM COMPETITION-GRADE SPL 4  DUAL VOICE COIL SUBWOOFER

800 W nominal input pow er

3500 W MAX.

2500 W MAX.

SMALLER ENCLOSURE VOLUME

Thanks to the Air Suspension System, Pioneer’s

competition-grade subs can achieve a consistently
clear, powerful and wide-ranging bass response, from a much
smaller enclosure volume. This is possible because of a sealed
air pocket between the sub’s two cones. The pressure inside this
pocket creates an air suspension system, which requires less
enclosure space to control the speaker cone, allowing a drastic
reduction in enclosure volumes.

70 %
SMALLER ENCLOSURE

CUSTOM ENCLOSURE BOXES

UD-W302S UD-W252S

CUSTOM ENCLOSURE BOX FOR TS-W3002D4

CUSTOM ENCLOSURE BOX FOR TS-W2501D4

65AUDIO PERFORMANCE AUDIO

MAKE A STATEMENT

a-Ccelerate SUBWOOFERS

Pioneer’s a-Ccelerate subwoofers are the ultimate tool for street tuning.

These ‘Champion Series’ subs are pedigrees of Pioneer’s competition­grade SPL subs and incorporate high-class technology for an improved performance. So, with their powerful sound and edgy
good looks, they will undoubtedly impress anyone near.

'CHAMPION SERIES' SUBS

Competing in the toughest SPL competitions has
allowed us to improve our subs’ performance.
These improvements are passed down through
the whole subwoofer line-up. So you can always rely
on a championship performance.

1

INCREASED DURABILITY

2

3

1. Air pressure and mechanical stress 2. Mechanical stress 3. Heating stress

TS-W308D4 TS-W258D4

30 CM 4  DUAL VOICE COIL SUBWOOFER

400 W nominal input po wer

Our tests have shown the parts of a subwoofer that undergo the most stress at high sound pressure levels.

We have used this knowledge to create subwoofers that can sustain much higher sound pressure levels for

longer periods of time.

1400 W MAX.

25 CM 4  DUAL VOICE COIL SUBWOOFER

350 W nominal input power

1200 W MAX.

A KNOCKOUT PUNCH

The composite IMPP™ woofer cone of our a-Ccelerate subwoofers has been reinforced with basalt fibres, giving you a punchier and
more powerful bass sound.

For full product specifications, please visit www.pioneer.eu

OPTIMISE YOUR POWER

Unique for their price range, our a-Ccelerate 2 ohm dual voice coil subwoofers let you get more power from your amp.
For example, one double 2 ohm subwoofer gives you the option of having an impedance level of 1 ohm at your amplifier.
So, if your amp is stable at this level, you can lower the impedance to increase the power.

TS-W308D2

30 CM 2  DUAL VOICE COIL SUBWOOFER

400 W nominal input po wer

1400 W MAX.

TS-W258D2

25 CM 2  DUAL VOICE COIL SUBWOOFER

350 W nominal input power

1200 W MAX.

CUSTOM ENCLOSURE BOXES

UD-W301S

CUSTOM ENCLOSURE BOX FOR TS-W308D4 AND TS-W308D2

UD-W251S

CUSTOM ENCLOSURE BOX FOR TS-W258D4 AND TS-W258D2

SPOKE GRILLES

UD-G308 UD-G258

SPOKE GRILLE FOR TS-W3002D4,
TS-W308D4, TS-W308D2 AND TS-W308F

SPOKE GRILLE FOR TS-W2501D4, TS-W258D4,
TS-W258D2 AND TS-W258F

67AUDIO PERFORMANCE AUDIO

COMPLETE CONNECTION FLEXIBILITY

Discover the wide range of connection options with Pioneer’s Dual Voice Coil a-Ccelerate subwoofers. The double 2 Ohm and double
4 Ohm models offer a wide variety of set-up possibilities (8 Ohm, 4 Ohm, 2 Ohm or 1 Ohm) – provided there is correct power matching
between the sub and amp. With all common impedance loads covered, you’re free to build the system you’ve always wanted.

TS-W308D2

2 subwoofers (as 2 Ω mono)

GM-D8400M

2 subwoofers (as 4 Ω stereo)

GM-6400F

1 subwoofer (as 4 Ω mono) 1 subwoofer (as 8 Ω mono)

4 Ω 8 Ω

Covered

Covered

4 Ω 8 Ω

4 Ω

Covered

Covered

4 Ω

4 Ω 8Ω

Covered

2 subwoofers (as 4 Ω mono)

GM -D740 0M

2 subwoofers (as 2 Ω stereo)

GM- 5400T

TS-W258D4

2 Ω

2 Ω

GM-5400T in bridged mode

GM-D8400M

SINGLE-SIDED PUSH TERMINALS

All speaker terminals are located on one side of the subwoofer, for easy installation.

AMPLIFIED SUBWOOFERS

TS-WX20LPA

20 CM LINEAR POWER AMPLIFIED SUBWOOFER

TS-WX206A

20 CM BANDPASS AMPLIFIED SUBWOOFER

200 W MAX.

150 W MAX.

For full product specifications, please visit www.pioneer.eu

FOR THE PERFECT INSTALL

BRIDGEABLE AMPLIFIERS

Inspired by our competition level amplifiers, Pioneer’s bridgeable amplifiers are back, offering superb sound and complete
installation flexibility. Stylishly redesigned to match the a-Ccelerate subs, these amps will give that extra touch of class
to any system set-up.

GM-6400F

4-CHANNEL BRIDGEABLE AMPLIFIER

4 x 120 W (4 Ω) /2 x 300 W (4 Ω bridged) max.
4 x 60 W (4 Ω) /2 x 150 W (4 Ω bridged )/4 x 75 W (2 Ω) continuous output power

2-CHANNEL BRIDGEABLE AMPLIFIER

2 x 250 W (4 Ω )/1 x 760 W (4 Ω bridged) max.
2 x 125 W (4 Ω) /1 x 380 W (4 Ω bridged)/2 x 19 0 W (2 Ω) continuous output po wer

GM-3300TGM-5400T

2-CHANNEL BRIDGEABLE AMPLIFIER

2 x 120 W (4 Ω) /1 x 300 W (4 Ω bridge d) max.
2 x 60 W (4 Ω) /1 x 150 W (4 Ω bridged)/2 x 75 W ( 2 Ω) continuous ou tput power

69AUDIO PERFORMANCE AUDIO

DISCOVER THE SOUND
OF GREAT BASS

a-Ccelerate FREE-AIR SUBWOOFERS

Building your own car audio installation can be a challenge. Free-air

subwoofers make that challenge that little bit easier because they use
your car boot as the enclosure space. This means they offer complete installation flexibility, while still producing powerful
bass and low distortion – just as you’d expect from ‘Champion Series’ subs.

TS-W308F

30 CM FREE-AIR SUBWOOFER

300 W nominal input pow er

1000 W MAX.

TS-W258F

25 CM FREE-AIR SUBWOOFER

250 W nominal input power

IT’S TIME TO MAKE YOUR MARK

800 W MAX.

Ignite your passion for audio tuning by joining Team Pioneer
on its quest for perfect in-car sound. Go online to find out more
about the individual cars and installations, and see where the
inspiration takes you.

For full product specifications, please visit www.pioneer.eu

www.pioneer.eu/teampioneer

www.flickr.com/photos/teampioneer

www.youtube.com/teampioneer

www.myspace.com/teampioneer

www.facebook.com

IT’S ALL ABOUT ATTITUDE

a-Ccelerate SPEAKERS

Need some mean-looking speakers to complete your installation? Our a-Ccelerate speakers will give you that
urban edge. Reinforced with long aramid fibres, the strong woofer cone ensures powerful, punching bass.
Open & Smooth™ technology gives your music extra depth, so you can immerse yourself in pure sound.

6" X 9" COAXIAL SPEAKERS

TS-A6904I

6" X 9" COAXIAL 4-WAY SPEAKERS

80 W nominal in put power

TS-A6903I TS-A6902I

6" X 9" COAXIAL 3-WAY SPEAKERS

80 W nominal in put power

400 W MAX.

350 W MAX.

6" X 9" COAXIAL 2-WAY SPEAKERS

40 W nominal input power

260 W MAX.

71AUDIO PERFORMANCE AUDIO

SEPARATE COMPONENT SPEAKER SYSTEMS

TS-A170CI

17 CM SEPARATE 2-WAY SPEAKER SYSTEM

50 W nominal input power

TS-A130CI

13 CM SEPARATE 2-WAY SPEAKER SYSTEM

30 W nominal in put power

COAXIAL 3-WAY SPEAKERS

TS-A2503I

25 CM COAXIAL 3-WAY SPEAKERS

80 W nominal in put power

TS-A2003I TS-A1703I

20 CM COAXIAL 3-WAY SPEAKERS

80 W nominal in put power

190 W MAX.

420 W MAX.

400 W MAX.

17 CM COAXIAL 3-WAY SPEAKERS

50 W nominal input power

260 W MAX.

240 W MAX.

TS-A1303I

13 CM COAXIAL 3-WAY SPEAKERS

30 W nominal in put power

For full product specifications, please visit www.pioneer.eu

180 W MAX.

READY FOR SOME SERIOUS TUNING?

Pioneer has teamed up with the West Coast Customs crew for their new show

Street Customs Berlin. The show follows on from the popular Pimp My Ride and
Street Customs and shows the team as they set up a workshop in Berlin and

unleash their tuning talents on the streets of Europe. The first series will see
6 vehicles transformed into stunning show cars, as Ryan Friedlinghaus and
his team put their creativity into overdrive. All pimped cars will contain full
sound systems from Pioneer: amps, subs, speakers…the lot. The team opted
to use Pioneer because of our extensive range of high-quality components and
reputation in the tuning scene. It’s a great combination, with impressive results.
See for yourself.

Photographs by Hans Haas

73AUDIO PERFORMANCE AUDIO

AUDIO PRODUCT OVERVIEW

OPTICAL DIGITAL REFERENCE SYSTEM

RS-D7RII RS-A9 RS-A7 RS-P90 UD-N01RSII

SYST EM CONT ROL CD TUNE R DIGI TAL POWE R AMPLIF IER WITH

INTE GRATED DS P

DIGITA L POWER A MPLIFI ER UNI VERSA L DIGITAL PR EAMPL IFIER

2-WAY PASSI VE CROS SOVER NE TWOR K

TS -T01RS II TS-S01RSII TS-M 01RSII TS-W01RSII

3.5 CM SU PER WID E-RAN GE TWEE TER

7.7 CM MIDR ANGE 17 CM MID -BASS DRI VER

25 CM SU BWOOFE R

HIGH-END PIONEER REFERENCE SERIES

AXM-P90RSDEX-P90RS DEQ-P90 PRS-A900 TS-W12PRS

COMP ONENT CD RD S TUNER

TS-T031PRS TS-C171PRSTS-S101PRS TS-C131PRSTS-M171PRS

2.8 CM T WEET ER

DIGITA L PREAM P/EQUAL ISER

200 W MA X.

10 CM MID- HIGH RAN GE DRIVER

AUDIO M ASTER U NIT

60 W MA X.

17 CM MID- BASS DRI VER

4-C HANNEL B RIDGEAB LE
POW ER AMPLI FIER

4 x 100 W (4 Ω )/2 x 2 00 W (4 Ω) m ax.
4 x 50 W (4 Ω )/2 x 10 0 W (4 Ω brid ged) co ntinu ous
output power

200 W MA X.

17 CM SEPA RATE 2-WAY
SPE AKER SYS TEM

200 W MA X./ 50 W NOM .

30 CM DU AL VOICE CO IL
SUBWOOFER

13 CM SEPA RATE 2-WAY
SPE AKER SYS TEM

1200 W MA X./ 300 W NO M.

150 W MA X./3 0 W NOM.

HIGH-QUALITY PIONEER REFERENCE SERIES

DEH-P88RSII PRS-D1200M PRS-D420 PRS-D220

COMP ONENT CD RD S TUNER

MON O-C HAN NEL CL AS S-D A MPL IFIE R

1 x 800 W ( 4 Ω)/1 x 1 200 W (1 Ω /2 Ω) m ax.
1 x 400 W ( 4 Ω)/ 1 x 600 W (2 Ω )/1 x 6 00 W (1 Ω )
continuous output power

4-C HANNEL C LASS- FD AMPLI FIER

4 x 150 W (4 Ω )/2 x 6 00 W (4 Ω) m ax.
4 x 75 W (4 Ω )/4 x 150 W ( 2 Ω)/ 2 x 300 W (4 Ω )
continuous output power

2-CH ANNEL CL ASS-F D AMPLIF IER

2 x 300 W ( 4 Ω)/1 x 1 200 W (4 Ω ) max.
2 x 150 W (4 Ω )/2 x 3 00 W (2 Ω) /1 x 60 0 W (4 Ω)
continuous output power

AMPLIFIERS

PRS-D2000SPL PRS-D1200SPL GM-D8400M GM-D7400M GM-6400F

COMP ETITI ON-GRA DE SPL
CLA SS-D AMP LIFIER

1 x 400 0 W (1 Ω) /1 x 300 0 W (2 Ω) /
1 x 1500 W ( 4 Ω) max .
1 x 200 0 W (1 Ω)/ 1 x 150 0 W (2 Ω)/
1 x 750 W ( 4 Ω) con tinuou s outp ut powe r

COMP ETITI ON-GRA DE SPL
CLA SS-D AMP LIFIER

1 x 240 0 W (1 Ω)/ 1 x 200 0 W (2 Ω) /
1 x 1000 W ( 4 Ω) max .
1 x 1200 W ( 1 Ω)/ 1 x 1000 W ( 2 Ω)/
1 x 500 W ( 4 Ω) con tinuou s outp ut powe r

MON O-C HAN NEL CL AS S-D A MPL IFIE R

1 x 600 W ( 4 Ω)/1 x 1 200 W (2 Ω ) max .
1 x 300 W ( 4 Ω)/1 x 6 00 W (2 Ω )
continuous output power

MON O-C HAN NEL CL AS S-D A MPL IFIE R

1 x 400 W ( 4 Ω)/ 1 x 800 W (2 Ω ) max.
1 x 200 W ( 4 Ω)/1 x 4 00 W (2 Ω )
continuous output power

4-C HANNEL B RIDGEA BLE AMPL IFIER

4 x 120 W (4 Ω )/2 x 3 00 W (4 Ω b ridge d) ma x.
4 x 60 W (4 Ω )/2 x 15 0 W (4 Ω bri dged )/4 x 75 W ( 2 Ω)
continuous output power

GM-5400T GM-3300T

2-CH ANNEL BRI DGEABL E AMPLI FIER

2 x 250 W ( 4 Ω)/ 1 x 760 W ( 4 Ω bridg ed) ma x.
2 x 125 W (4 Ω )/1 x 3 80 W ( 4 Ω bridg ed) /2 x 19 0 W (2 Ω )
continuous output power

2-CH ANNEL BRI DGEABL E AMPLI FIER

2 x 120 W (4 Ω )/1 x 3 00 W (4 Ω b ridge d) ma x.
2 x 60 W (4 Ω )/1 x 15 0 W (4 Ω bri dged )/2 x 7 5 W (2 Ω)
continuous output power

SUBWOOFERS

38 CM C OMPETI TION-GR ADE SPL
2 Ω DUAL V OICE COIL S UBWOOFE R
FOR P ROFESSI ONAL USE

TS-W308D2

30 CM 2 Ω DU AL VOICE CO IL
SUBWOOFER

TS-SW3001S4

30 CM SH ALLOW-T YPE 4 Ω SING LE
VOIC E COIL SUBW OOFER

8000 W MAX./3000 W NOM.

1400 W MA X. /400 W NO M.

1500 W MA X./4 00 W NOM .

30 CM CO MPETI TION-GR ADE SPL
2 Ω DUAL V OICE COIL S UBWOOFE R
FOR P ROFESSI ONAL USE

TS-W258D4

25 CM 4 Ω DU AL VOICE CO IL
SUBWOOFER

TS-SW3001S2

30 CM SH ALLOW-T YPE 2 Ω SING LE
VOIC E COIL SUBW OOFER

6000 W M AX. /250 0 W NOM.

1200 W MA X./ 350 W NO M.

1500 W MA X./4 00 W NOM .

CUSTOM ENCLOSURE BOXES AND GRILLES

UD-SW104S

CUST OM ENCLOS URE BOX FOR
TS-SW1041D

Pro tection ba rs include d

UD-SW125S

CUST OM ENCLOS URE BOX FOR
TS-SW3001S4 AND TS-SW3001S2

Pro tection ba rs include d

UD-SW84S

CUST OM ENCLOS URE BOX FOR
TS-SW841D

Pro tection ba rs include d

30 CM CO MPETI TION-GR ADE SPL
4 Ω DUAL V OICE COIL S UBWOOFE R

TS-W258D2

25 CM 2 Ω DU AL VOICE CO IL
SUBWOOFER

TS-SW1041D

25 CM SH ALLOW-T YPE 4 Ω SING LE
VOIC E COIL SUBW OOFER

3500 W M AX. /1000 W NO M.

1200 W MA X./ 350 W NO M.

1000 W MA X./ 250 W NO M.

UD-W302S

CUST OM ENCLOS URE BOX FOR
TS-W3002D4

25 CM CO MPETI TION-GR ADE SPL
4 Ω DUAL V OICE COIL S UBWOOFE R

TS-W308F

30 CM F REE-AIR S UBWOOF ER

TS-SW841D

20 CM SH ALLOW-T YPE 4 Ω SING LE
VOIC E COIL SUBW OOFER

2500 W M AX. /800 W N OM.

1000 W MA X./ 300 W NO M.

500 W MA X./ 120 W NOM.

UD-W252S

CUST OM ENCLOS URE BOX FOR
TS-W2501D4

UD- W301S

CUST OM ENCLOS URE BOX FOR
TS-W308D4 AND TS-W308D2

UD- W251S

CUST OM ENCLOS URE BOX FOR
TS-W258D4 AND TS-W258D2

TS-W308D4TS-W8102SPL TS-W5102SPL TS-W3002D4 TS-W2501D4

30 CM 4 Ω DU AL VOICE C OIL
SUBWOOFER

TS-W258F

25 CM F REE-AIR S UBWOOFE R

1400 W MA X. /400 W NO M.

800 W MA X./ 250 W NO M.

UD-G308

SPOK E GRILLE F OR TS-W3 002D4,
TS-W308D4, TS-W308D2 AND TS-W308F

UD-G258

SPOK E GRILLE F OR TS-W2 501D4,
TS-W 258D4 , TS-W2 58D2 AN D TS-W25 8F

75AUDIO PRODUCT OVERVIEW

AMPLIFIED SUBWOOFERS

DOUB LE 16 CM BACK-L OADED
HORN A CTIVE SU BWOOFE R

SPEAKERS

TS-E SERIES

TS -E170C I

17 CM SEPA RATE 2-WAY
SPE AKER SYS TEM

TS-E1702I

17 CM COA XIAL 2-WAY SP EAKE RS

a-Ccelera te TS-A SERIES

260 W MA X./ 60 W NOM .

180 W MA X./3 5 W NOM.

200 W MA X.

20 CM LI NEAR PO WER
AMP LIFIED SU BWOOFE R

TS -E130 CI

13 CM SEPA RATE 2-WAY
SPE AKER SYS TEM

TS-E1302I

13 CM COA XIAL 2-WAY SP EAKER S

200 W MA X.

180 W MA X./3 5 W NOM.

180 W MA X./3 5 W NOM.

20 CM BA NDPASS
AMP LIFIED SU BWOOFE R

TS-E6902I

6" X 9" CO AXIAL 2 -WAY SPEAK ERS

TS -E1002 I

10 CM COA XIAL 2-WAY SP EAKE RS

150 W MA X.

360 W MA X./ 80 W NOM .

110 W MAX ./25 W N OM.

20 CM SE ALED
AMP LIFIED SU BWOOFE R

TS-E2002I

20 CM CO AXIA L 2-WAY SPEAK ERS

150 W MA X.

360 W MA X./ 90 W NOM .

TS -W X11ATS-WX77A TS-W X20LPA TS-WX206A TS-WX22 A

12.8 CM X 2 0.8 CM OVAL CO NE
SEA LED-TY PE AMP LIFIED S UBWOOF ER

TS-E1702IS

17 CM COA XIAL 2 -WAY SPEAK ERS

150 W MA X.

280 W MA X./ 60 W NOM .

TS -A170 CI

17 CM SEPA RATE 2-WAY
SPE AKER SYS TEM

TS-A2503I TS-A2003I TS-A1703I TS-A1303I

25 CM CO AXIA L 3-WAY SPEA KERS

260 W MA X./ 50 W NOM .

420 W MA X./ 80 W NOM.

TS -A130 CI

13 CM SEPA RATE 2-WAY
SPE AKER SYS TEM

20 CM CO AXIA L 3-WAY SPE AKERS

190 W MA X./3 0 W NOM.

400 W MA X. /80 W NOM .

TS-A6904I TS-A6903I

6" X 9" CO AXIAL 4 -WAY SPEA KERS

17 CM COA XIAL 3 -WAY SPEAKE RS

400 W MA X. /80 W NOM .

240 W MA X./ 50 W NOM.

6" X 9" CO AXIAL 3 -WAY SPEAK ERS

13 CM COA XIAL 3 -WAY SPE AKERS

350 W MA X./ 80 W NOM .

180 W MA X./3 0 W NOM.

TS-A6902I

6" X 9" CO AXIAL 2 -WAY SPEAK ERS

260 W MA X./4 0 W NOM.

TS-G SERIES

17 CM SEPA RATE 2-WAY
SPE AKER

SYSTEM

TS-G1702I TS-G1302I TS -G1002 I

17 CM COA XIAL 2-WAY SP EAKE RS

TS-G1001I

10 CM DUA L-CON E SPEAKE RS

170 W MA X./3 5 W NOM.

170 W MA X./3 5 W NOM.

110 W MAX ./20 W N OM.

TS -G131CTS -G171C TS-G1703I

13 CM SEPA RATE 2-WAY
SPE AKER SYS TEM

13 CM COA XIAL 2-WAY SP EAKER S

130 W MA X./2 5 W NOM.

130 W MA X./2 5 W NOM.

17 CM COA XIAL 3 -WAY SPEAKE RS

10 CM COA XIAL 2-WAY SP EAKE RS

CUSTOM-FIT SERIES

180 W MA X./3 5 W NOM.

120 W MA X./2 5 W NOM.

TS-G1303I

13 CM COA XIAL 3 -WAY SPE AKERS

TS-G1701I

17 CM DUA L-CON E SPEAKE RS

140 W MA X./ 25 W NOM.

170 W MA X./3 5 W NOM.

TS-G1003I

10 CM COA XIAL 3 -WAY SPEAKE RS

TS-G1301I

13 CM DUA L-CONE S PEAKE RS

130 W MA X./2 5 W NOM.

130 W MA X./2 5 W NOM.

TS -170 CI T S-13 0C I

17 CM SEPA RATE 2-WAY
SPE AKER SYS TEM

TS -170 1I

17 CM DUA L-CON E SPEAKE RS

TS -Q131C

13 CM SEPA RATE 2-WAY
SPE AKER SYS TEM

170 W MA X./3 5 W NOM.

170 W MA X./3 5 W NOM.

180 W MA X./3 5 W NOM.

13 CM SEPA RATE 2-WAY
SPE AKER SYS TEM

13 CM DUA L-CONE S PEAKE RS

TS-H1703

17 CM SEPA RATE 2-WAY
SPE AKER SYS TEM

SURFACE MOUNT SPEAK ERS AND TWE ETERS

130 W MA X./2 5 W NOM.

130 W MA X./2 5 W NOM.

180 W MA X./5 0 W NOM.

TS-1702I

17 CM COA XIAL 2-WAY SP EAKE RS

TS -100 1I

10 CM DUA L-CON E SPEAKE RS

TS-H1303

13 CM SEPA RATE 2-WAY
SPE AKER SYS TEM

170 W MA X./3 5 W NOM.

110 W MAX ./20 W N OM.

130 W MA X./3 5 W NOM.

TS-1302I

13 CM COA XIAL 2-WAY SP EAKER S

TS -Q172C

17 CM SEPA RATE 2-WAY
SPE AKER SYS TEM

TS-H687

6" X 8" CO AXIAL 3 -WAY SPEAK ERS

130 W MA X./2 5 W NOM.

220 W MA X./ 50 W NOM .

240 W MA X./ 50 W NOM.

TS -100 2I

10 CM COA XIAL 2-WAY SP EAKE RS

TS -Q171CTS -130 1I

17 CM SEPA RATE 2-WAY
SPE AKER SYS TEM

TS-H467

4" X 6" COA XIAL 2- WAY SPE AKERS

120 W MA X./2 5 W NOM.

200 W MA X./4 0 W NOM.

110 W MAX ./25 W N OM.

TS-CX7

CENT RE SPEA KER FOR

5.1-CHANNEL SURROUND SOUND

60 W MA X./2 0 W NOM.

TS -X150 TS-44 TS-S15

3-WAY SPE AKERS

60 W MA X./2 0 W NOM.

FUL L- RANGE SP EAKER S

40 W MA X./10 W N OM.

TUNE -UP DOME T WEETE RS

120 W MA X./4 0 W NOM.

For full product specifications, visit www.pioneer.eu

77AUDIO PRODUCT OVERVIEW

BLUETOOTH

®

ADAPTER

READY

GLOSSARY

Here you can find an explanation of all icons and logos used throughout this catalogue. It has been organised alphabetically
for your convenience.

1-LI NE 16-CH ARAC TER DISPL AY

To m ake it easy to read informa tion such a s radi o sta tion f requencie s, tr ack
title s and ar tist nam es, some Pioneer headunits have be en fitt ed with a 1-line
16-ch aracter display. This also f acilitate s brow sing t hrough the s ongs s tored
on a USB a udio playe r or US B stick o r throug h the co ntact li st on y our
Bluet ooth-ena bled mobile ph one.

3-B AND PARA METR IC EQUAL ISER (PEQ )

The 3-band e qualiser all ows you t o adjust t he equalis ation to match you r car’s
acous tics. To ease usage even further, 6 equaliser cur ves are p reset: Po werful,
Natur al, Vocal, Fl at, Custo m and Super B ass. 3 band s can be adju sted in
band -specific s teps from + 6 to -6, name ly EQ-L (low ), EQ-M (mid ) and EQ-H (hig h).

7-BA ND GRAP HIC EQUA LISER (GE Q)

With Pione er’s 7-b and g raphic equaliser, you can c ustomise the equalisa tion
levels t o best m atch the acou stics of your c ar. To ease usag e, 7 equaliser cur ves
are pr eset: Po werful, Na tural, Voc al, Flat, Cu stom 1, Cust om 2 and Sup er Bass.
7 bands (50 Hz , 12 5 Hz, 315 Hz, 800 Hz, 2 kHz , 5 kH z and 12.5 kHz) can be adju sted
in band-specific steps from +6 to -4, or -6, depending on which equaliser curve
is selec ted.

ADVA NCED AUDI O CODING (A AC)

AAC is s hort for Ad vanced Audio Coding and re fers t o an audio c ompressio n
techn ology stand ard used with MPEG 2 a nd MPEG 4. AAC provid es more ef ficient
audio en coding comp ression tha n other form ats like MP3, w hile deliverin g
qualit y comp arable to uncomp ressed CD audio. Pio neer units play bac k A AC files
enco ded by iTunes

AUT OMATIC SO UND LEV ELISER ( ASL)

Automatic Sound Leveliser technology electronically and automatically adjusts
volume a nd frequen cies to mask var ying degr ees of exte rior noise.

ADVA NCED SOUN D RETRI EVER (A SR)

Compressed audio such as MP3 may be convenient, but it can result in inferior
sound qu ality. Pionee r’s ASR restor es the quality of co mpressed au dio files such
as MP3 t o the level of t he original re cording.

AUX- IN TERMI NAL (FRO NT/RE AR)

Conne ct a range of e xternal de vices, suc h as portabl e audio or video p layers, to
your he adunit's Au x-in connec tion.

BLUE TOOTH

Units with this revolutio nary w ireless technolo gy com municate automa tically
with most Blue tooth-e nabled mob ile phones* and trea t the mobi le as a sou rce
devic e. Aft er set-u p of an individu al user iden tity, Bluetoot h wirele ss technolog y
ensures automatic data communication between the phone and the navigation
unit, w henever th e two devic es are within r ange of each o ther.

* Find out wheth er your mobile pho ne is compatible at www.pio neer.eu

BLUE TOOTH A DAPT ER READY

Headu nits that are Blue tooth adapt er ready can be ho oked up to the CD-B TB200
Bluet ooth ad apter so you can e njoy the fre edom of true wirel ess in- car
telep hony. This add-on sol ution makes sure you r headun it auto matically pick s up
your Bluet ooth-ena bled mobile phone’s signal. The CD-B TB200 also incor porates
the audio profile to en able au dio str eaming from a Bluet ooth-en abled m obile
phone o r portabl e audio player.

CD-R/RW

CD-R and CD- RW are Compact Disc recordable formats. CD- R is a “write once”
form at, w hich o nly all ows d ata t o be reco rded once. CD-RW is a re writable
form at allowing da ta to be recor ded multiple t imes.

CEL LULAR T ELEPH ONE AUTO M UTING

This f eature au tomaticall y reduces t he volume o f your sys tem when an
incoming call is detected or y ou dial an outgoing call on a cellular phone
installed in you r car.

®

.

COLOUR CUSTOMISATION

Colou r customisa tion lets yo u better in tegrate yo ur headunit i nto your dash board.
Sele ct fr om a var iety o f colou rs for t he but ton an d/or s creen i llumina tion. All 20 09
AVH mod els have RGB b utton illum ination, let ting you ch oose from a multitude o f
colour s, while the AVH-P5100DVD also has 5 different colours for the screen display.
The D VH-P410 0UB lets y ou swit ch betw een blue an d red for th e butto n illuminat ion.

COMP ACT DISC DI GITAL AUD IO

Comp act Disc digit al audio is a sta ndard digit al format fo r storing au dio on a CD.

COMP ACT DISC DI GITAL VI DEO

Comp act Disc digit al video is a st andard digi tal format f or storing v ideo on a CD.

DIRE CT SUB DRI VE

Direc t sub driv e is an easy so lution for love rs of booming bas s, which allows you
to hook u p a subwoofe r without th e need for an add itional ampli fier.

DivX

Using the DivX co dec, le ngthy video segments can be co mpressed into small
sizes w hile maintaini ng relative ly high visual qu ality.

DOLB Y DIGITAL

The current surrou nd sound qualit y encod ing sta ndard, D olby Dig ital pr ovides
in-c ar mov ie the atre s ound p erforman ce. T he fro nt lef t and right, centr e and
rear left and right speakers span frequencies from 20 Hz-20 kHz, and there is a
dedic ated subwo ofer channe l for addition al low freque ncy sound ef fects.

DOLB Y DIGITAL P RO LOGIC II

Dolby Di gital Pro Lo gic II reprod uces multi- channel sur round sound f rom a
varie ty of sound s ources to c reate the t hrill of 5.1-cha nnel surrou nd sound eve n
from 2- channel so urces.

DTS D IGITAL OU T

Units wi th DTS Digital Ou t are capa ble of reading and th en passing a DTS digit al
signal t o a receiver or p rocesso r containing a D TS decoder.

DTS D IGITAL SU RROUND

DTS Digi tal Surround is a 5.1-ch annel surrou nd sound forma t f or consumer
produ cts and pro vides 5.1 chann els of discret e digital audio .

DVD-R/DVD-RW

DV D- R an d D VD -R W ar e DV D r ec ord ab le f or mat s. DV D- R is a “w rit e o nce ” fo rm at ,
which only allo ws d ata to b e re corded once. DV D-RW is a r ewritabl e for mat
allowin g data to be re recorde d over existi ng data a give n number of tim es.

DVD-VIDEO

DVD g uarantee s second-t o-none p icture qua lity. The ul tra-shar p digital pi cture
and s urround sound bri ng impres sive cinem a into y our car. DV D is also packed
with us eful featur es, such as multi ple languages , sound tracks and su btitles and
suppo rt for variou s multi- channel audi o-encodi ng technolo gies such as DTS and
Dolby Di gital.

EAS Y CONNEC TOR

All custom-fi t spea kers ar e equip ped wit h a handy E asy C onnector, making it
easier t o cable them w ith the car’s s peaker conn ections.

HIGH PA SS FILTE R/LO W PASS FILT ER

A H igh Pas s Filt er is a filt er tha t pass es high freq uencies well, b ut at tenuate s (or
red uce s) fr eque ncie s low er th an an a djus tab le cu t-of f fr eque ncy. For e xamp le, w hen
yo u do n ot w ant low sou nds to pl ay f rom the tw eet er s or m id- ran ge s pe ake rs, tur n on
the HPF ( High Pa ss Filt er) on the t weeter s’ or mid-ran ge spea kers’ c hannels. Only
freq uencies higher than th e cut- off f requency are output ted fr om the twee ters o r
mid-range speakers.

A Low P ass F ilter is a filter that pass es lo w fre quencies well, but atten uates (or
reduc es) freque ncies highe r t han an adjust able cut-o ff frequ ency. For exa mple,
when y ou do not want h igh sounds t o play from th e subwoof er, turn on the L PF (Low
Pass Filt er) o n the subw oofer's chann el. O nly f requencie s low er t han t he cu t-off
freq uency are ou tputt ed from the s ubwoofer.

HI-VOLT PRE-OUT

By providing a str ong sign al with less n oise and more definition, the hi -volt
pre-outs reduce demand on an amplifier’s input circuit, so it can work with lower
gain set tings. Th is results in im proved so und quality a nd a wider dyn amic range.

iPod DIR ECT CONT ROL

Headu nits wit h iPod Di rect Con trol let you con trol your iPod dir ectly fr om your
headu nit. S imply h ook u p your iPod to your h eadunit using an op tional cable
and you’r e set.

iPod VID EO

Pione er's AVH and DVH he adunits suppor t playb ack of iPod Video. Check the
acce ssories (p age 27) to find t he correc t cable for your h eadunit.

MAD E FOR iPod

“Made fo r iP od” means that an elec tronic acces sory has been desi gned to
conne ct sp ecifically to iPod and h as be en cer tified by t he de veloper to m eet
Apple p erform ance stand ards.

MOSF ET 50 W X 4

The MO SFET 50 W p ower amp bo osts audio p erforma nce levels b y using
semic onductor techn ology. Char acterist ics such a s l ow lo ss, low au dio
disto rtion, e liminated switching distor tion and a wide power b and combi ne to
give MOSFET 50 W x 4 headu nits 50 W x 4 of sonic clarity, matching the bes t
component amplifiers.

MP3

Popul ar compr ession forma t that allow s large amo unts of audio files to be stored
on one CD-R /CD-R W d isc. MP3-c ompatible Pio neer players com e equipp ed with
large buff ering capabiliti es, wh ich me ans th ey are able to handle data rates
from 16 k bps and VBR Va riable Bit Rat e recordin g.

MULT I-LAN GUAGE USE R INTERF ACE

Selec t from up to 7 languages (E nglish, Fre nch, German , Italian, Sp anish, Dutc h
or Russ ian) to naviga te the headun it’s display men u in your langua ge of choice.

OEL DI SPLAY

Pi one er ’s O EL d is pla ys l et you vie w a ll in fo rm at ion cle ar ly. Two t y pes ar e av ail ab le.
Pione er’s blue OEL di splay sho ws thr ee lines of inf ormation at a resolutio n of
192 x 48 . You can also cus tomise the di splay with a v ariety of hi gh-qualit y stills
and m otion gra phics. Pio neer’s dot segment OEL displ ay shows informat ion on
two lin es of 16 charac ters and has w hite illuminat ion.

OEM DI SPLAY OU TPUT

The OEM display out put enables you to connect your headu nit t o you r car ’s
exist ing digital display *. Inform ation, such as radio freq uency and CD track
numbe r, is outp utted th rough the IP -Bus conne ction via an op tional inter face.

* Find the correct adapter for your car at www.pioneer.eu

OEM RE MOTE CO NTROL RE ADY

If your car features an existing steering wheel remote control, you can connect it
to your headunit and take full control via that remote control*. By using an optional
OEM r emote con trol adapt er, the head unit can be hard-wir ed direct ly to the c ar’s
origin al remote co ntrol sys tem via the m ini-jack inp ut at the ba ck of the hea dunit.
A simple, c onvenien t and safe fea ture that l ets you keep b oth hands on t he wheel.

* Find the correct adapter for your car at www.pioneer.eu

PARRO T

Parrot develops technologies for embedded noise-robust voice recognition and signal
proc essing, wit h applicatio ns in mobile com puting and m obile communi cations.
Parr ot is one of the few comp anies to develop the Blue tooth wirele ss technolog y
stac k, rather tha n rely on thir d party cod e. This ensures th at Pioneer’s Blue tooth
models h ave bett er maintainab ility throu ghout their l ife cycle.

RCA P RE-OUT S (1, 2, 3)

RCA pre-o uts e nable y ou to easily expan d your sound syst em. De pending on
whet her your headuni t comes with 1, 2 or 3 RCA pre-out s, you can cus tomise
your sound sys tem with separat e amp lifiers for the front speake rs, t he r ear
speak ers and/or a subwoofe r. The RCA pre- outs let yo u create t he exact s ound
you wan t, with the f ocus on compl ete flexibili ty.

ROTA RY COMMA NDER

You can c ontrol all of the headunit ’s function s wit h the rotar y co mmander
single dial. The rotary comman der works like a joyst ick, giving you speedy
cont rol over the hea dunit. R otate it lef t or right, pu sh it up, down, le ft or right
or p ress i t to na viga te joy stic k-st yle t hrou gh dif fere nt ra dio st atio ns or ac ces s
folder s and files.

SD

A Secur e Digital (SD) car d is a flash me mory stor age device, av ailable in a range
of memor y capacitie s, which ca n s tore a wide select ion of file form ats. Pioneer ’s
DEH- P4100SD headuni t fe atures an SD slot behind its front pan el, a llowing
music pla yback. Th e 2009 Nav Gate line-up f eatures ma ny models that al low SD
music and/or vid eo playb ack. SD c ards can also be u sed for updating NavGate
units v ia the NavGa te Feeds P C applicatio n.

SOUR CE LEVE L ADJUS TER (SL A)

The S ource Le vel Adjust er allows yo u to indepe ndently a djust the v olume rati o
bet ween all of the head unit’s sources (usin g t he FM volume level as a referenc e),
so the s tart-up vo lume betwe en sources w ill always be t he same.

TEL E ATLAS M APS

Tele Atlas p rovides map data for Pio neer’s navigatio n unit s. Wit h one of the
most c omprehens ive map datab ases in the wor ld, Tele Atlas enab les you to find
dest inations, gui des travelle rs with land marks and pr ovides acc urate data .

TRA FFIC ME SSAGE CH ANNEL ( TMC)

Keeps t he driver u pdated on c urrent tr affic eve nts and sugg ests alte rnative r outes.

USB

Unive rsal Serial Bu s ( USB) is an exter nal periphe ral interf ace standar d for
commu nication betw een Pione er units and e xternal perip herals ov er a
connection cable.

USB- IN (FRON T/REA R)

Using the inte grated front or rear USB -in t erminal, it takes only secon ds t o
expa nd your sy stem wit h a USB sti ck with au dio conten t or a USB audio playe r
and p lay your compress ed audio fi les. Con trolling t he device can be done fro m
the he adunit or via a re mote contr ol.

VOICE RECOGNITION

The DEH -P8100 BT an d DEH -P7100B T Blue tooth CD tune rs fe ature voice
reco gnition. This mean s you pe rform c ertain Bluetooth telepho ny funct ions by
using sp eech comma nds*.

* Available in English, French, German, Italian, Spanish and Dutch.

WAV

WAV files are used to store high-quality, uncompressed audio data of CD-quality.
This file format requires a huge amount of memory – roughly 10 MB per minute
of m usic. Co mpressed audio fil es such as MP3 and W MA req uire signi ficantly
less me mory, but re produce po orer qualit y sound.

WIN DOWS MEDI A AUDIO (W MA)

WMA is a music compres sion form at develo ped by t he Micros oft Cor poration .
It uses th e l atest coding te chnologie s t o c ompress an orig inal audio track ,
minimisin g file sizes whil e maintaining g ood audio qualit y.

RAD IO DATA SYST EM (RDS)

RDS at taches ad ditional (digi tal) infor mation along w ith FM bro adcasts.
This in formatio n is used by your R DS tuner for a w ide variet y of featur es:

- AF ( Alterna tive Fre quency) en sures tha t you can co ntinue list ening to yo ur
fav ouri te ra dio ch anne l wit hout any in terr upt ion. W hen y our c urre nt fr eque ncy i s
ne ar ly o ut o f re ac h, t he sys te m au to ma tic all y s wit ch es t o a f re qu enc y w ith be tt er
rece ption – with out you ever n oticing.

- PI (Pro gramme Identit y) S eek wi ll auto matically sear ch fo r a differe nt st ation
wit h the s ame pro gram ming, i f the tu ner ca n’t find a s uita ble sta tion o r rece ption
stat us become s bad.

- TA (Traf fic Announce ment) lets you rec eive traffi c annou ncements au tomatica lly,
no mat ter what s ource you ar e listening t o. Playba ck of any sour ce you’re
listen ing to at that m oment will be in terrupt ed.

- PT Y (Progr amme Type) allow s you to searc h quickly and ea sily for radio ch annels
that b roadcast w ithin a cer tain theme, s uch as News, We ather, Pop, Ro ck, etc.

WORK S WITH iP hone

“Wor ks with iPh one” means t hat an elec tronic acc essory h as been desi gned to
conne ct speci fically to iPhone a nd has be en cert ified by the develo per to m eet
Apple p erform ance stand ards.

GLOSSARY

79

PIONEER WORLD

Forget yesterday’s limits, this is tomorrow’s technology, Pioneer style.

So surround yourself with Pioneer – at work or play. You’ll come alive. We promise.

Audio & Video KURO Flat Screen TV DJ Products

F

or detailed information concerning Pioneer’s Environmental Policy, please visit the following site: www.pioneer.eu/environment

GREAT BRITAIN:

PION EER GB LI MITE D
Pion eer House, H ollybus h Hill, St oke Poges ,
Slou gh, Buckin ghamshir e SL2 4Q P
Tel.: + 44 (0) 1753 78 9 789
www.pioneer.co.uk

IRELAND:

AUDI O VISION I MPORT LT D
Acous tic Hous e, John F. Kenn edy Driv e, Naas Road, D ublin 12
Tel.: + 353 1 2 40 56 00
e-m ail: info @avi. ie
www.ie.pioneer.eu

ICELAND:

BR ÆDURNI R ORMSS ON HF
Lágm úli 8, P.O. Box 8 760, 1 28 Reyk javik
Tel.: + 354 5 5 32 80 0
e-mail: [e-mail]
www.ormsson.is

Windo ws Media, and the W indows lo go are tr ademarks, or regist ered tra demarks o f Microso ft Corp oration in the Unit ed State s and/or o ther coun tries. iP od is a re gistered t rademark of Apple, Inc.,
regis tered in the U.S. and othe r countrie s. “Made for i Pod” means t hat an elec tronic acc essory ha s been design ed to conne ct specific ally to iPod a nd has been ce rtified b y the develop er to meet A pple
perf ormance s tandards. A pple is not res ponsible for th e operatio n of this de vice or its co mpliance wit h safety an d regul atory sta ndards. Pio neer does not s ell iPods. iPho ne is a tradema rk of Apple, In c.
"Wor ks with iPho ne" means tha t an electro nic accesso ry has been d esigned to co nnect spec ifically to iP hone and has be en certifi ed by the dev eloper to mee t Apple per formance s tandards . ICEpower
is a regi stered tr ademark of B ang & Olufse n ICEpowe r a/s. DuPont and/or DU PO NT-TORAY CO., LTD . produce K EVLA R® bran d fibre. DuPo nt™ and KEV LAR® are tr ademarks a nd registe red tradem arks
of DuP ont or its af filiates and a re used unde r license by Pi oneer. SD Logo i s a trademar k. The Blue tooth word m ark and logo s are owned b y the Blueto oth SIG, Inc. a nd any use of su ch marks by P ioneer
is under lic ense. The Pa rrot Trademar ks appearin g on this docume nt are the sole and ex clusive prop erty of Par rot S.A. Div X and associat ed logos are tr ademarks of Di vX, Inc. and are u sed under licen se.
“DTS ” and "DT S Digital Out” ar e trademar ks of Digital The ater Syst ems, Inc. “Dolb y”, “Dolby D igital” and the “ double-D” s ymbol are reg istered tra demarks of Do lby Labora tories. Oth er trademar ks and
trad e names are tho se of their re spective o wners.

Reco rding equipme nt and copyr ight: Reco rding equipme nt should be use d only for law ful copying , and you a re advised to c heck caref ully what is law ful copying i n the co untry in whi ch you are makin g a
copy. C opy of copyr ight mater ial such as films or m usic is unlawf ul unless per mitted by a l egal except ion or consen ted to by the r ightowne rs.

MALTA:

DOR ELL TR ADING L IMITE D
Sta ndard Bldg s., C. De Br ockdorf f Stre et, Msid a, MSD- 02
Tel.: + 356 2 1 33 38 61
e-mail: [e-mail]
www.pioneer.com.mt

LATVIA:

BAL TIC MULT I MEDIA SI A
Vent spils Iela 5 0, LV-10 02 Riga
Tel.: + 371 7 610 111
e-mail: [e-mail]

ESTONIA:

DIGISOUND OÜ
Kanal i Tee 12 , 10112 Tallinn
Tel.: + 372 6 0 33 99 0 – Fax: + 372 60 3 3 997
e-m ail: info @digis ound.ee

MACEDONIA:

MA KPET ROL A. D. SKOPJE
Mit o Hadzivas ilev Jasmi n 4. MK, 10 00 Sko pje
Tel.: + 389 2 3 112 14 4 – Fax : [phone]
e-mail: contact @makpetrol.com.mk
www.mk.pioneer.eu

In-car AV/Navigation

®

PUBLISHED BY:

PIONEER EUROPE N.V. - HAVEN 1087, KEETBERGLAAN 1

B-9120 MELSELE, TEL.: [phone]

COPYRIGHT 2009 BY PIONEER EUROPE N.V. - ALL RIGHTS RESERVED

Disclaimer:

Feat ures and spe cificatio ns of the pro ducts desc ribed or illus trated in t his brochur e are correc t
at the time of prin ting but c ould change a s product ion change s might occ ur. This broc hure may
cont ain typogr aphical err ors and the colo urs of the depic ted produc ts may devia te slightly fr om
realit y. Co nsult y our Pi oneer dealer to ens ure th at ac tual f eatures and specific ations match
your requirem ents. T his broc hure may contain refere nces to produc ts that may o r will no t be
availa ble in your coun try.

WWW.PIONEER.EU

Your local Pioneer dealer: ›

09- C-CONS GUIDE-EN – P rinted in Be lgium. As a par t of Pioneer ’s commi tment to a cle aner enviro nment and the p rotectio n of the eart h, this cata logue has bee n printed on ch lorine-fr ee paper.
