Equipment Report

Electronically reprinted from February 2007

Pioneer S-2EX Loudspeaker

Bridging the divide

Neil Gader

y offering qualities we typically associate with audiophile

speakers as well as those from the pro-monitor world, Pioneer’s EX Series bridges the divide between two distinct listening cultures. It combines a recording-studio ethic, rigorous construction quality, and most signiﬁcantly, technology plucked directly from the playbook at Pioneer’s pro-audio “skunkworks,” the highly regarded TAD (Technical Audio Device) division.

Though TAD’s ﬁrst home-audio effort, 2003’s M-1 speaker, was critically acclaimed, its $40,000 tag priced most of us out. The more down-to-earth EX Series was designed and built at Pioneer’s Speaker Design Center in Paris by a team comprised of TAD and Pioneer engineers. Andrew Jones, the chief designer of the M-1, served as sound advisor, and the EX Series also received feedback from sound engineers at London’s legendary AIR Studios.

The $6000 S-2EX is a three-way, stand-mount compact in a bass-reﬂex enclosure. The bafﬂe has a gentle curve in it, as well as a backward slope, that serves to time-align the transducers at the listening position. Weighing in at over sixty pounds, the cabinet is bolstered by multiple layers of laminated MDF, ranging in thickness from 30mm to 100mm; the side panels are curvilinear to reduce internal standing waves. With its massive internal bracing, the enclosure’s resemblance to a ship’s

hull is striking.

As with the TAD M-1, a concentric

driver uniﬁes the tweeter and

midrange transducers. Although

it’s a dead ringer for the M-

To subscribe to the absolute sound, call 888-475-5991 (US), 760-745-2809 (outside US) or visit www.theabsolutesound.com. $42 for six issues in the US; $45 Canada, $75 outside

For more information on reprints from the absolute sound, contact Wright’s Reprints at 877-652-5295.

Pioneer S-2EX Loudspeaker

1’s driver, the EX midrange cone is magnesium rather than the M-I’s far more expensive beryllium. In either case, break-up modes don’t appear until well into the ultra-sonic range. The beryllium tweeter, however, is pure TAD, and TAD technology informs the bass cone, as well. Here the diaphragm is of one-piece construction (as opposed to the more commonly found separate center-cap), which Pioneer feels adds greater rigidity while pushing resonances outside of the cone’s audible frequency range. Finally, the huge 65mm voice coil has been engineered for extreme power handling and dynamic headroom.

Sonically, the S-2EX isn’t hobbled by the usual constraints of a compact speaker. It may sit on a stand, but it speaks with the voice of a three-way through and through. As its highpowered studio-monitor bloodline implies, the S-2EX is designed to play at prodigiously loud levels that would harelip any number of sophisticates

Specs & Pricing

PIONEER ELECTRONICS

P.O. Box 1540 Long Beach, California 90810 (800) 421-1404 pioneerelectronics.com

Type: Stand-mounted, bass-reﬂex

loudspeaker

Driver complement: 1.4" concentric tweeter,

5.5" concentric midrange, 7.12" woofer

Frequency response: 34Hz–100kHz Sensitivity: 86.5dB Impedance: 6 ohms Dimensions: 11.5" x 22.25" x 16.75" Weight: 62 lbs. Price: $6000

ASSOCIATED EQUIPMENT

Sota Cosmos Series III turntable; SME V pick-up arm; Shure V15VxMR cartridge; MBL 1531, Simaudio Moon Supernova, and Sony DVP-9000ES digital players; Plinius 9200 and MBL 7008 integrated amps; Tara Labs Omega, Nordost Baldur, Kimber Kable BiFocal XL; Wireworld Silver Electra & Kimber Palladian power cords; Richard Gray line conditioners; Sound Fusion Turntable stand

from the high end. Orchestral scale is remarkable for a speaker of this dimension; symphonies spring to life, with the walls of the venue seeming to breathe like a bellows.

The S-2EX doesn’t subdue dynamics, either. Concert grand pianos are not submissive instruments—at close range the energy and transient attack from any nine-footer will churn your insides. In this regard, the only other speaker of this size that compares is another compact three-way, the MBL

121.

In terms of tonal balance, this is one of the more neutral speakers I’ve heard in some time. Its midrange seems spot on; its treble is highly extended if a little dry at its limits; and bass response extends deep into the midbass with perceivable reserves below 40Hz. Its upper bass and lower mids (the bugaboos of compact speakers) never seem to run short. Cabinet resonances and port anomalies are so low that you quickly forget this is a bass-reﬂex design. There is also a sensation of weight in

the mids that deepens the presence of male and female singers. Both jazz singer Claire Martin, from Linn’s Too Damn Hot, and a cappella specialist Laurel Massé, on Feather and Bone [Premonition], exhibited good body and chest resonance.

The S-2EX communicates a precision sound geared to resolving details at all levels, micro and macro. Even familiar recordings take on a greater complexity and a physicality bordering on the tactile. Like any great speaker, its character is mostly determined by the recording. The downside is that bad recordings are not enhanced by syrupy colorations— the S-2EX exposes every blemish, as if illuminating them in high deﬁnition. The upside of such resolution is that the best recordings have never sounded better. Even familiar chestnuts seemed completely refreshed, as if I’d unknowingly acquired a newly remastered version. From the opening bars of Järvi and the Cincinnati Orchestra’s reading of Bartók’s Concerto for Orchestra [Telarc], each

February 2007 The Absolute Sound
