Pioneer S-1EX User Manual

EX Speaker Series
S-1EX S-2EX S-7EX
S-W1EX
1975
TAD (Pioneer’s Technical Audio Device department) develops the TAD Pro Audio monitoring drivers. They are acknowledged as ‘‘best of the best’’ in the professional audio industry.
2005
The EX Series is born. A fl agship model for Pioneer’s speaker systems around the world, this speaker collection uses many of the technical specifi cations of the highly acclaimed TAD-M1. The EX Series showcases Pioneer’s knowledge and ability to create a premium speaker system with incredible design and astonishing sound quality.
The Evolution of Sublime Sound
1937
2
In the year of our foundation, Pioneer brings the A-8 dynamic speaker to the market. The clear vision we had then — to bring a new level of sound quality to a wider public — is still true today as we continue to aim ever higher.
1997
2000
Pioneer Electronics Technology established its speaker design group in California to create advanced speaker designs for the North America market.
Pioneer’s SDC (Speaker Design Center) is established in Paris in order to stay up-to-date with European trends and new technologies. A cosmopolitan team designs and develops Pioneer speakers based on the results of market research.
2003
2004
Derived from the legacy technology of TAD Pro Audio speakers, the TAD-M1 takes home audio reproduction to new levels. Considered to be one of the best speaker systems in the world, this speaker is recognized by audio purists for its remarkable clarity, detail, imaging and dynamics.
Pioneer initiates the EX project: to create a new high-end speaker system for worldwide markets.
3
Speaking of Excellence
Pioneer has been breaking the boundaries of fi rst-class entertainment for decades. Through the years, we have grown, fl ourished and changed with our customers and their aspirations, earning ourselves a top-ranked spot among the classics. It all began with the design and production of dynamic speakers. For this unique speaker collection, Pioneer has returned to its origins. The experience and expertise built up through the years culminates in the creation of our masterpiece, the EX Speaker Series. The superb, natural sound and accuracy of these premium speakers ensures that they are the absolute pinnacle of true sound quality. Designed by the world’s leading experts, skillfully crafted from the highest quality materials and passing rigorous sound testing with ease, the EX Series provides a superlative sound experience. Every step of the design process has been meticulously undertaken to ensure that the prestigious EX Series really does deserve its status. Turn the page, and embark on a journey to discover how this exquisite speaker collection came into existence.
Eight Steps to Excellence
10
11
12
13
14
Tweeter/Midrange Driver
4
Bass Driver
6
Perfect Time Alignment Design
8
Enclosure
Acoustic Balance Drive
Credentials
AIR Studios
Line-Up
4
5
Witness the Creation of Superior Audio
The fi rst step in the painstaking development of Pioneer’s premium speaker series is the creation of an outstanding concentric tweeter/midrange speaker driver. Cutting-edge TAD technologies allow the driver to reproduce exceptionally accurate audio. Every element has been crafted using only the highest-quality materials, ensuring that all frequencies of this wide-range driver are always precise and laser-sharp, boasting extraordinary liveliness and delicacy. Add in the Neodymium magnet’s tremendous strength and the result is fl uent and consistent sound at a superior level of true-to-life detail, ideal for DVD-Audio and SACD reproduction. Sit back, close your eyes and be swept up in a world of sonic perfection. Open your eyes and you’ll see that ideal sound is so much more than just a dream — it can be your reality.
TAD driver: CST-6001
*TAD (Technical Audio Devices)
TAD Speaker Design Coherent Source TransducerBeryllium Tweeter Diaphragm
Only the very best speaker components were considered for Pioneer’s new
audio masterpiece: the EX Series. So it’s no surprise that TAD (Technical Audio Devices) speaker engineering is incorporated into these reference-class drivers. They were crafted with extreme precision by TAD experts, and adhere to their rigorous standards. TAD professional studio monitoring loudspeakers are the fi rst choice in recording studios across the globe. They have set a standard for audio excellence and reliability, as recognized by many world-famous performers and professional sound engineers. The legacy began 30 years ago, and now TAD speakers can be found wherever the highest sound quality is required: studio monitors, concert hall speakers, cinema audio systems and more.
tweeters ideal for reproducing the high frequencies of DVD­Audio and SACD, up to 100 kHz. These revolutionary audio formats recreate sound as it actually exists in the real world, with all its original artistic qualities intact.
The tweeter diaphragm is composed of Beryllium metal, which is extremely light and rigid. This has resulted in an ultra­strong tweeter diaphragm with perfectly solid piston performance. It precisely reproduces the audio signal; limited distortion or resonance is added to the audio performance. This pure and solid performing diaphragm makes Beryllium
To ensure that all sound — direct and refl ected — arrives at the listening position with identical timbre, the EX Series employs TAD’s exclusive CST (Coherent Source Transducer) driver technology. The Beryllium tweeter is
mounted in the center of the magnesium midrange driver, allowing the sound directivity to be precisely controlled at all frequencies. The resulting aligned sound delivery is extremely smooth and coherent. Unlike conventional drivers, the problems with phase and off-axis frequency response have been totally eradicated.
Give Deeper Meaning to Sound
The next element to be developed is the EX Series’ meticulously designed bass driver. Also packed with TAD technology and fi rst-class components, it guarantees superior sound performance, even at very low frequencies. The extremely rigid and solid cone structure creates more stable and uniform cone movement, as well as enhanced damping properties. Unnecessary reaction and resonance are signifi cantly reduced by the specially designed basket frame. The ultra-strong Neodymium magnet and large voice coil let you effortlessly achieve a smooth response and a fl uid in line transition to the higher frequency drivers. But a perfect listening experience is about more than the highest quality materials and technologies. It involves your own passions and beliefs, your reactions to the sounds that surround you. Pioneer’s EX Series amplifi es those passions and provides the most exquisite platform from which to create a new world of special moments.
TAD driver: TL-0701
*TAD (Technical Audio Devices)
One-piece Cone and Center Cap
Conventional speaker cones have a separate center cap, to make it easier to attach the cone to the voice coil. However, this design weakens the cone’s mechanical integrity. The unique one-piece construction of the cone and
center cap that was created for the EX Series’ bass driver, combined with the improved rigidity of the aramid fi ber structure, produces a much stiffer and more rigid construction. Unwanted cone resonances are pushed beyond the bass driver’s operating range, allowing the cone to accurately pass the coil movement on to the air and signifi cantly improve the accuracy of sound reproduction.
6
65 mm Voice Coil
Typical bass drivers have relatively small voice coils, which at high power levels, mean reduced power handling ability and loss of effi ciency. At a huge 65 mm, the voice
coil of the EX Series has considerably greater power handling capability, producing outstanding dynamics, even at high sound levels.
“Air-flow Designed” Basket Frame
The tweeter/midrange and bass drivers of the EX Series feature novel “air-fl ow designed” basket frames and magnetic circuits that allow for unrestricted airfl ow behind the cone and around the voice coil. Even at very high power levels, it prevents sound distortion, offering simply pure and accurate sonic pleasure.
7
8
The Science of Sensation
9
In our eternal quest to offer you unrivalled sound perfection, we have taken innovative design further than ever before. In sound perception, every element must be considered. Even the slightest detail can make a world of difference. With an ideal system, all sounds produced by the loudspeakers arrive at the listeners’ ears simultaneously. If that doesn’t happen, the feeling of truly aligned performance is lost. The effect is even worse in multi-channel systems, where the impression of being immersed in the performance space disappears. Pioneer has developed the perfect answer: Perfect Time Alignment Design. This revolutionary 5-channel solution takes you as close to the sensation of sound perfection as you will ever get.
Coherent Source Transducer
When tweeters and midrange speaker drivers are mounted on a traditional fl at baffl e, the acoustic centers of the drivers are not aligned. The center of the midrange driver is positioned behind the baffl e and the center of the tweeter is placed in the baffl e’s plane. Some manufacturers try to resolve this problem with a stepped baffl e, however this results in unacceptable diffraction and coloring of the sound. TAD cleverly opted to mount the tweeter in the center of the midrange cone, which not only optimizes sound propagation in all directions, but also guarantees time alignment of the drivers.
Slant Layout Enclosure
Enclosures have a backwards slant of eight degrees. This brings the speaker’s center gravity of the speaker directly over the center of the base of the speaker. This positioning ensures stability of the cabinet and freedom from the effects of speaker vibrations. In combination with the Precisions Curves, perfect time alignments of the drivers and at the listening position is guaranteed.
Precision Curve
In traditional speaker systems, several speaker drivers are aligned on a fl at front baffl e. Because the sounds from each driver reach the listener from different distances, this composition inevitably leads to a small degree of confusion in the overall sound. With Pioneer’s EX Series, a revolutionary baffl e with a precise curved surface has been realized to solve this problem. This is the “precision curve.” By positioning the speaker drivers on a three-meter radius sphere centered on the listener, the time it takes for the sound to reach the listener’s ears from each of the drivers is precisely adjusted.
0RECISIONCURVE
INM
IN
M
Solid, Strong, Superb
With the tweeter/midrange and bass drivers perfected, an equally ingenious enclosure must be created to provide them with a stable base. The EX Series’ cabinets are crafted from multiple layers of laminated MDF, ranging from a minimum of 30 mm up to a generous 100 mm, to ensure that they remain inert. Along with the curved baffl e and radius edges, these enclosures help create an amazingly realistic stage with exceptional clarity and focus. For a striking appearance, these audiophile-quality speaker systems deserve a fi tting fi nish. The beautiful, trendy, dark wood gives a high-quality fi nish to the EX Series, which is befi ttingly called the “highest echelon.”
10
ABD
Vertical standing waves are a phenomenon that occurs in
nearly all speaker enclosures. Responsible for uneven,
boomy or sucked out bass response, vertical standing
waves generated inside tall fl oor-standing cabinets are
extremely diffi cult to control. But not for Pioneer. We
have developed unique acoustic simulation technology,
ABD (Acoustic Balance Drive), which allows us
to calculate the infl uence of the cabinet’s vertical
standing waves on the speaker frequency response,
taking into account bass drivers and port locations.
Using this software, the port and bass drivers of
the EX Series are placed in the best position
to cut this infl uence to a minimum. This new
technology allows the fi rst vertical standing
wave to be totally canceled and the infl uence
of the second one to be signifi cantly reduced.
The result is precise and dynamic bass with
no low midrange coloration.
11
Acoustic Balance Drive (ABD)
Acoustic Balance Drive (ABD)
dB SPLdB SPL
100
100
95
95
90
90
85
85
80
80
75
75
70
70
65
65
60
60
10 100 1000 10000 10 100 1000 10000
10 100 1000 10000 10 100 1000 10000
General Floor-Standing Speaker Floor-Standing Speaker with ABD Technology
General Floor-Standing Speaker Floor-Standing Speaker with ABD Technology
Axis Frequency Response
Axis Frequency Response
dB SPLdB SPL
100
100
95
95
90
90
85
85
80
80
75
75
70
70
65
65
60
60
Canceled Standing Wave
Canceled Standing Wave
HzHz
HzHz
Solid Credentials
The fl agship EX Series has been created by a talented network of high-end audio specialists consisting of only the very best TAD and Pioneer engineers from around the world. They have each added their individual expertise to co-create this fi rst-class model of audio excellence. In addition, Andrew Jones, chief engineer of the TAD-M1, acted as sound advisor to ensure the success of this ambitious project. Pioneer’s EX Series was conceived with the aim of creating true sound perfection to fulfi ll the desires of
Andrew Jones and the TAD-M1
used in the renowned TAD-M1 — widely considered to be one of the premier speaker systems available. You will certainly hear the difference when you listen to SACD and DVD-Audio discs. This superlative speaker collection reproduces today’s advanced reproduction formats with fl awless precision.
audiophiles with the most discerning of taste. That’s why these premium speakers call not only on the expertise of TAD engineers but comprise many of the technical elements
12
Revolutionary Phase Control
Not only has the latest technology that we have explained above been used in the design of the EX Series, but the latest results of Pioneer’s unique research into audio sound reproduction are also being actively used. This is the revolutionary “phase control” technology.
“Phase control” technology is the concept of managing the time and phase response of the speakers, amplifi ers and software to realize the dramatic high-quality sound during multi-channel sound reproduction. The most advanced concepts of phase control have been introduced to the EX Series. All the systems use the same CST and woofer drivers, which along with the crossover allows for perfect matching of the phase characteristics of all the speakers. Additionally S­W1EX subwoofer has a low pass fi lter (LPF) bypass function installed. In combination with the appropriate receiver, the phase response of the complete multi-channel system can be optimized for uncompromising surround sound reproduction.
13
The Mark of Excellence
The EX Series has undergone rigorous acoustic testing at AIR Studios in London, one of the world’s leading recording studios, and therefore meets its strict studio replay standards. Some of the most talented AIR Studios sound engineers contributed an unquestionable amount of know-how to fi ne-tune the EX Series. So they can replicate a professional studio sound environment in your home, with ideally controlled acoustics. Sir George Martin, the legendary Beatles producer and an Academy Award-nominated composer, founded AIR Studios in 1969. AIR Studios is now a state-of-the-art recording complex with matchless facilities for fi lm scoring, rock, pop, classical and orchestral work, video game sound design, post-production and live events.
This “phase control” trademark is attached to products designed for phase characteristic matching recording to reproduction, based on the phase control technology concept developed by the Pioneer Corporation.
AIR Studios and the AIR Studios logo are registered trademarks of AIR Studios, Inc.
S-1EX Floorstander S-2EX Compact Monitor
S-1EX
(Speakers are sold separately)
Features
• 1-3/8 in. (3.5 cm) Beryllium tweeter / 5-1/2 in. (14 cm) Magnesium midrange
• CST driver
• 7-1/16 in. (18 cm) Aramid / Carbon composite shell woofer
• Large Neodymium magnet
• Magnetically shielded-design
• Aerodynamic frame and magnetic circuits
• Perfect time-alignment design
• Precision curve
• Round enclosure
• Slant-layout enclosure
• ABD technology
• Phase-control design
• Unleaded solder
• 3-way speaker system
Specifi cations
Frequency Range: 28 - 100,000 Hz Nominal Impedance: 6 Ω Maximum Power (Input): 200 W Dimensions (W x H x D): 16-5/8 x 50-1/2 x 24 in. 422 x 1283 x 609 mm Weight: 145 lbs. 8oz.
66.0 kg Accessory: Grille, 4 Spikes
S-2EX
(Speakers are sold separately)
Features
• 1-3/8 in. (3.5 cm) Beryllium tweeter / 5-1/2 in. (14 cm) Magnesium midrange
• CST driver
• 7-1/16 in. (18 cm) Aramid / Carbon composite shell woofer
• Large Neodymium magnet
• Magnetically shielded-design
• Aerodynamic frame and magnetic circuits
• Perfect time-alignment design
• Precision curve
• Round enclosure
• Phase-control design
• Unleaded solder
• 3-way speaker system
Specifi cations
Frequency Range: 34 - 100,000 Hz Nominal Impedance: 6 Ω Maximum Power (Input): 200 W Dimensions (W x H x D): 11-7/16 x 22-1/4 x 16-3/4 in. 291 x 565 x 425 mm Weight: 61 lbs. 12oz.
28.0 kg
Accessory: Grille, 4 Spikes
1414
Angle view
Front view
Angle view
(Shown with option speaker stand CP-2EX)
Front view
1515
S-7EX Center Channel
(Shown with option speaker stand CP-7EX)
S-7EX
Features
• 1-3/8 in. (3.5 cm) Beryllium tweeter / 5-1/2 in. (14 cm) Magnesium midrange
• CST driver
• 7-1/16 in. (18 cm) Aramid / Carbon composite shell woofer
• Large Neodymium magnet
• Magnetically shielded-design
• Aerodynamic frame and magnetic circuits
• Perfect time-alignment design
• Precision curve
• Round enclosure
• Vertical twin method
• Phase-control design
• Unleaded solder
• 3-way speaker system
Specifi cations
Frequency Range: 34 - 100,000 Hz Nominal Impedance: 6 Ω Maximum Power (Input): 200 W Dimensions (W x H x D): 32-5/16 x 11-7/16 x 16-3/4 in. 820 x 291 x 425 mm Weight: 86 lbs.
39.0 kg Accessory: Grille, 4 Spikes, Base for Center Speaker
S-W1EX Powered Subwoofer
S-W1EX
Features
• Silent mount technology structure, to prevent unnecessary vibrations.
• Large 12 in. (30 cm) diametre woofer driver
• Large 12 in. (30 cm) diametre passive radiator
• Phase-control design
• Solid round enclosure
• Unleaded solder
Specifi cations
Frequency Range: 24 - 4,000 Hz (Set to BYPASS) Power output (RMS): 250 W / 4 Ω (100Hz) Dimensions (W x H x D): 16-15/16 x 18-14/16 x 16-15/16 in. 430 x 480 x 430 mm Weight: 75 lbs. 14 oz.
34.5 kg Accessory: 4 Bases, 4 Spikes, Power Supply cord, Ground cord
PIONEER ELECTRONICS (USA) INC.
P.O. Box 1540, Long Beach, California 90810
TO CONTACT US:
For Dealer Referrals or Product Information
1(800) PIONEER
For Service Companies or Customer Service
1(800) 421-1404
PIONEER ELECTRONICS OF CANADA, INC.
300 Allstate Parkway, Markham, ON, L3R 0P2
Phone: 1-877-283-5901
Our customer service representatives do not have access to information regarding dealer credit or sales information.
Disclaimer: Features and specifi cations of the products described or illustrated in this catalogue are correct at the time of printing but could change as production changes might occur. This catalogue may contain typographical errors and the colors of the depicted products may deviate slightly from reality. Consult your Pioneer dealer to ensure that actual features and specifi cations match your requirements. This catalogue may contain references to products that may or will not be available in your country.
Published by Pioneer Corporation. Copyright © 2005 Pioneer Corporation. All rights reserved. Note: Specifi cations and design are subject to modifi cation without notice. Printed on Recycled Paper.
For more information, call or write to:
Technical Specifications
Specifications
Enclosure:
Speakers (Tweeter):
Speakers (Midrange):
Speakers (Bass):
Frequency Range: 28 — 100,000 Hz 34 — 100,000 Hz 34 — 100,000 Hz
Sensitivity (2.83 V/1 m): 89.5 dB SPL 86.5 dB SPL 89.5 dB SPL
Nominal Impedance: 6 Ω 6 Ω 6 Ω ———
Maximum Power (Input) : 200 W 200 W 200 W
Power output (RMS) : 250W / 4 Ω (100 Hz)
Cross-over Frequencies :
Dimensions (W x H x D):
Weight:
Power Requirements /
Consumption
Finishes:
Grille:
S-1EX
3-way vented box system
Front-vented bass refl ex
Floor-standing type
Concentric driver:
1-3/8 in. (3.5 cm) Beryllium dome
Concentric driver:
5-1/2 in. (14 cm) Magnesium cone
7-1/16 in. (18 cm) Aramid cone (x2)
400 Hz
2 kHz
16-5/8 x 50-1/2 x 24 in.
422 x 1283 x 609 mm
145 lbs. 8 oz.
66.0 kg
120 V, 60 Hz / 56 W, 90 VA
Cabinet: Real wood veneer
Dark Teak wood
(satin fi nish)
Black cloth
S-2EX
3-way vented box system
Front-vented bass refl ex
Bookshelf type
Concentric driver:
1-3/8 in. (3.5 cm) Beryllium dome
Concentric driver:
5-1/2 in. (14 cm) Magnesium cone
7-1/16 in. (18 cm) Aramid cone
400 Hz
2 kHz
11-7/16 x 22-1/4 x 16-3/4 in.
291 x 565 x 425 mm
61 lbs. 12 oz.
28.0 kg
Cabinet: Real wood veneer
Dark Teak wood
(satin fi nish)
Black cloth
S-7EX
3-way vented box system
Front-vented bass refl ex
Center speaker type
Concentric driver:
1-3/8 in. (3.5 cm) Beryllium dome
Concentric driver:
5-1/2 in. (14 cm) Magnesium cone
7-1/16 in. (18 cm) Aramid cone (x2)
400 Hz
2 kHz
32-5/16 x 11-7/16 x 16-3/4 in.
820 x 291 x 425 mm
86 lbs.
39.0 kg
Cabinet: Real wood veneer
Dark Teak wood
(satin fi nish)
Black cloth
S-W1EX
Powered subwoofer
Passive radiator
Floor-standing type
12 in. (30 cm) Aramid cone +
12 in. (30 cm) Aramid cone
passive radiator
25 — 4,000 Hz
(Set to BYPASS)
50 — 150 Hz
(Continuously variable)
16-15/16 x 18-14/16 x 16-15/16 in.
430 x 480 x 430 mm
75 lbs. 14 oz.
34.5 kg
Cabinet: MDF with Real
wood veneer
Dark Teak wood
(satin fi nish)
Black cloth
CP-2EX
Speaker stand for S-2EX
——
——
——
15-3/4 x 23-3/4 x 20-3/16 in.
400 x 604 x 513 mm
(without decoupling spikes)
39 lbs. 4 oz.
17.8 kg
Stand: Black Plywood
(satin fi nish)
Decoupling Spikes: Silver
CP-7EX
Speaker stand for S-7EX
19-5/8 x 12-3/16 x 16-1/4 in.
498 x 310 x 412 mm
(without decoupling spikes)
30 lbs. 14 oz.
14.0 kg
Stand: Black Plywood
(satin fi nish)
Decoupling Spikes: Silver
