Thank you for buying this Pioneer product.
Please read through these operating instructions so that you will know how to operate your model properly. After
you have finished reading the instructions, put them in a safe place for future reference.
IMPORTANT
CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN
The lightning flash with arrowhead symbol,
within an equilateral triangle, is intended to
alert the user to the presence of uninsulated
"dangerous voltage" within the product's
enclosure that may be of sufficient
magnitude to constitute a risk of electric
shock to persons.
CAUTION:
TO PREVENT THE RISK OF ELECTRIC
SHOCK, DO NOT REMOVE COVER (OR
BACK). NO USER-SERVICEABLE PARTS
INSIDE. REFER SERVICING TO QUALIFIED
SERVICE PERSONNEL.
WARNING
This equipment is not waterproof. To prevent a fire
or shock hazard, do not place any container filed
with liquid near this equipment (such as a vase or
flower pot) or expose it to dripping, splashing, rain
or moisture.
D3-4-2-1-3_A_En
Operating Environment
Operating environment temperature and humidity:
+5 ºC to +35 ºC (+41 ºF to +95 ºF); less than 85 %RH
(cooling vents not blocked)
Do not install this unit in a poorly ventilated area, or in
locations exposed to high humidity or direct sunlight (or
strong artificial light)
This product complies with the Low Voltage Directive
(73/23/EEC, amended by 93/68/EEC), EMC Directives
(89/336/EEC, amended by 92/31/EEC and
93/68/EEC).
D3-4-2-1-7c_A_En
D3-4-2-1-9a_En
The exclamation point within an equilateral
triangle is intended to alert the user to the
presence of important operating and
maintenance (servicing) instructions in the
literature accompanying the appliance.
D3-4-2-1-1_En-A
WARNING
Before plugging in for the first time, read the following
section carefully.
The voltage of the available power supply differs
according to country or region. Be sure that the
power supply voltage of the area where this unit
will be used meets the required voltage (e.g., 230V
or 120V) written on the rear panel.
D3-4-2-1-4_A_En
WARNING
To prevent a fire hazard, do not place any naked
flame sources (such as a lighted candle) on the
equipment.
D3-4-2-1-7a_A_En
CAUTION
This product is a class 1 laser product, but this
product contains a laser diode higher than Class 1.
To ensure continued safety, do not remove any covers
or attempt to gain access to the inside of the product.
Refer all servicing to qualified personnel.
The following caution label appears on your unit.
Location:
top of the unit
CAUTION
ATTENTION
ADVARSEL
VARNING
VORSICHT
PRECAUCI” N
VARO!
CLASS 3B VISIBLE AND INVISIBLE LASER RADI ATION WHEN OPEN, AVOID EXPOSURE TO THE BEAM.
RADIATIONS LASER VISIBLES ET INVISIBLES DE CLASSE 3B QUAND OUVERT. …VITEZ TOUT EXPOSITION AU FAISCEAU.
KLASSE 3B SYNLIG OG USYNLIG LASERSTR ≈LING VED ≈BNING. UNDG≈ UDS∆ TTELSE FOR STR≈LING.
KLASS 3B SYNLIG OCH OSYNLIG LASERSTR≈LNING Nƒ R DENNA DEL ƒR ÷PPNAD. UNDVIK A TT U TSƒ T TA DIG F÷R STR≈LEN.
BEI GE÷FFNETER ABDECKUNG IST SICHT BARE UND UN SIC HTBARE LASERSTRAHLUNG DER KLASSE 3B IM GERƒTEINNEREN VORHANDEN.
NICHT DEM LASERSTRAHL AUSSETZEN!
CUANDO SE ABRE HAY RADIACI”N L¡ SER DE CLASE 3B VISIBLE E I NV IS IB LE . E V IT E LA EXPOSICI” N A LOS RAYOS L¡ SER.
AVATTAESSA OLET ALTTIINA NƒKYVƒLLE JA NƒKYMƒTT÷ MƒLLE LUOKAN 3B LASERSƒTEILYLLE. ƒ Lƒ KATSO SƒTEESEEN.
VRW2262 - A
D3-4-2-1-8_B_En
If the AC plug of this unit does not match the AC
outlet you want to use, the plug must be removed
and appropriate one fitted. Replacement and
mounting of an AC plug on the power supply cord of
this unit should be performed only by qualified
service personnel. If connected to an AC outlet, the
cut-off plug can cause severe electrical shock. Make
sure it is properly disposed of after removal.
The equipment should be disconnected by removing
the mains plug from the wall socket when left
unused for a long period of time (for example, when
on vacation).
D3-4-2-2-1a_A_En
CAUTION
The STANDBY/ON switch on this unit will not
completely shut off all power from the AC outlet.
Since the power cord serves as the main disconnect
device for the unit, you will need to unplug it from
the AC outlet to shut down all power. Therefore,
make sure the unit has been installed so that the
power cord can be easily unplugged from the AC
outlet in case of an accident. To avoid fire hazard,
the power cord should also be unplugged from the
AC outlet when left unused for a long period of time
(for example, when on vacation).
POWER-CORD CAUTION
Handle the power cord by the plug. Do not pull out the
plug by tugging the cord and never touch the power
cord when your hands are wet as this could cause a
short circuit or electric shock. Do not place the unit, a
piece of furniture, etc., on the power cord, or pinch the
cord. Never make a knot in the cord or tie it with other
cords. The power cords should be routed such that they
are not likely to be stepped on. A damaged power cord
can cause a fire or give you an electrical shock. Check
the power cord once in a while. When you find it
damaged, ask your nearest PIONEER authorized
service center or your dealer for a replacement.
S002_En
VENTILATION CAUTION (Receiver subwoofer)
When installing this unit, make sure to leave space
around the unit for ventilation to improve heat
radiation (at least 5 cm at top, 5 cm at rear, and 5
cm at each side).
VENTILATION CAUTION (DVD Recorder)
When installing this unit, make sure to leave space
around the unit for ventilation to improve heat
radiation (at least 10 cm at top, 10 cm at rear, and
10 cm at each side).
WARNING
Slots and openings in the cabinet are provided for
ventilation to ensure reliable operation of the
product, and to protect it from overheating. To
prevent fire hazard, the openings should never be
blocked or covered with items (such as newspapers,
table-cloths, curtains) or by operating the
equipment on thick carpet or a bed.
5 cm
5 cm
Receiver subwooferDVD Recorder
5 cm
10 cm
This product is for general household purposes. Any
failure due to use for other than household purposes
(such as long-term use for business purposes in a
restaurant or use in a car or ship) and which
requires repair will be charged for even during the
warranty period.
D3-4-2-1-7b_A_En
10 cm
10 cm
K041_En
English
If you want to dispose this product, do not mix it with general household waste. There is a separate collection system for used
electronic products in accordance with legislation that requires proper treatment, recovery and recycling.
Private households in the 25 member states of the EU, in Switzerland and Norway may return their used electronic products free of charge to
designated collection facilities or to a retailer (if you purchase a similar new one).
For countries not mentioned above, please contact your local authorities for the correct method of disposal.
By doing so you will ensure that your disposed product undergoes the necessary treatment, recovery and recycling and thus prevent potential
negative effects on the environment and human health.
• Speakers (front x2, surround x2, center x1) (page 12)
• Speaker cables x5 (page 11)
• Non-skid pads (large) x4 (page 6, 7)
• Non-skid pads (small) x20 (page 6, 7)
• Speaker stands x2 (page 7)
• Screws (for speaker stands) x2 (page 7)
Speakers (S–ST606) box:
• Speakers (front x2, surround x2, center x1) (page 12)
• Speaker cables x5 (page 11)
• Non-skid pads (large) x4 (page 5)
• Non-skid pads (large) x16 (page 5)
• Non-skid pads (small) x4 (page 5)
• Speaker stand bases x 4 (page 5)
• Screws (for bases) x 12 (page 5)
15
18
Speaker Setup Guide
Chapter 2
Speaker Setup Guide
Safety precautions when setting up
When assembling the speakers, lay them down flat on
their side to avoid accidents or injury. Make sure to use a
stable surface when assembling, setting up, and placing
the speakers.
Home theater sound setup
(RCS-606H)
• This is a standard multichannel surround sound
speaker setup for optimal 5.1 channel home theater
sound.
Front
left
Center
Receiver subwoofer
Front
right
2 Attach the smaller non-skid pads to the base of
the center speaker. The large non-skid pads are for
the front and surround speakers, and the receiver
subwoofer (as shown).
Use the adhesive side of the pads to attach them to the
base (flat surface) of each speaker.
English
Rear
Front
Surround
left
1 Attach the speaker stand bases to the stems
using the screws provided.
Once you have aligned the stem and base, secure with
the small screws at the points shown below. Note that
the speaker should face in the direction of the base of the
isosceles triangle (outlined below).
Listening position
Surround
right
Non-skid pads
(small) x 4
Non-skid pads
(large) x 16
Non-skid pads
(large) x 4
Center speaker
Front and
surround
speakers
Receiver
subwoofer
5
En
Speaker Setup Guide
3 Secure each of the front and surround speakers
using the metal catch provided.
Screw two picture hooks or similar into the wall behind
the speaker. Pass a chain or cord around the hooks and
through the metal catch so that the speaker is stabilized
(make sure to test that it supports the weight of the
speaker).
After installing, make sure the speaker is securely fixed.
Chain or cord
Home theater sound setup
(RCS-404H/RCS-505H)
Depending on the size and characteristics of your room,
you can place your speakers in one of two ways using this
system.
Standard surround setup
This is a standard multichannel surround sound speaker
setup for optimal 5.1 channel home theater sound.
Metal catch
Caution
• The metal catch is not a mounting fixture, and the
speaker should not be hung directly from the wall
using this catch. Always use a chain or cord when
stabilizing the speaker.
• Pioneer disclaims all responsibility for any losses or
damage resulting from improper assembly,
installation, insufficient strength of the installation
materials, misuse, or natural disasters.
4 Connect the speaker system.
Refer to Connecting up to connect the speakers properly.
After connecting everything, place the speakers as
shown in the diagram above for optimal surround sound.
Front
left
Center
Surround
left
Listening position
Front
right
Receiver subwoofer
Surround
right
1 Attach the smaller non-skid pads to the base of
each of the front, surround and center speakers. The
four large non-skid pads are for the receiver
subwoofer (as shown).
Use the adhesive side of the pads to attach them to the
base (flat surface) of each speaker.
Front and surround speakers
Non-skid pads
(small) x 20
6
En
After placing the speakers, run the Auto MCACC setup
(page 23) to complete your surround sound setup.
Non-skid pads
(large) x 4
Center speaker
Receiver
subwoofer
Speaker Setup Guide
2 Connect the speaker system.
Refer to Connecting up to connect the speakers properly.
After connecting everything, place the speakers as
shown in the diagram (left) for optimal surround sound.
After placing the speakers, run the Auto MCACC setup
(page 23) to complete your surround sound setup.
3 Make sure the Front Surround mode is switched
off.
See the operating instructions for more on using Front
Surround.
Front surround setup
This setup is ideal when rear surround speaker
placement isn't possible or you want to avoid running
long speaker cables in your listening area. Use this setup
together with the Front Surround modes in page 26 to
take advantage of wall and ceiling reflections for a very
realistic surround effect.
Front right
Surround
right
Receiver
subwoofer
Surround left
Front left
Center
Front speakers
Non-skid pads
(small) x 20
Non-skid pads
(large) x 4
Speaker stands
Center speaker
Receiver
subwoofer
2 Attach the surround speakers to the speaker
stands.
For each speaker, line up the spurs on the stand with the
holes on the back of the speaker and insert, then secure
the speaker to the stand with the screw provided.
English
Listening position
1 Attach the smaller non-skid pads to the base of
the front and center speakers and to the speaker
stands. The four large non-skid pads are for the
receiver subwoofer (as shown).
Use the adhesive side of the pads to attach them to the
base (flat surface) of each speaker or stand.
3 Connect the speaker system.
Refer to Connecting up to connect the speakers properly.
After connecting everything, place the speakers as
shown in the diagram (left) for optimal surround sound
(the surround speakers are next to the front speakers).
7
En
Speaker Setup Guide
4 Turn the speakers as shown, following the guide
marks for optimal Front Surround.
If you have selected FRTMOVIE (Front Surround Movie)
or FRTMUSIC (Front Surround Music), turn each
surround speaker so that the guide markers on the stand
base are lined up horizontally in the direction the
listening position (see below). With EXTPOWER (Extra
Power), the surround speakers should point in the same
direction as the front speakers (see below).
See Using Front Surround on page 26 for more
information.
Wall mounting the speakers
(RCS-404H/RCS-505H)
In addition to the center speaker, the front and surround
speakers also have holes for wall mounting. However, if
you are using the Front Surround setup described on the
previous page, do not wall mount the surround speakers.
5 mm
10 mm
5 mm to 7 mm
FRTMOVIE / FRTMUSIC
After placing the speakers, run the Auto MCACC setup
(page 23) to complete your surround sound setup.
Caution
• Please don’t attach the surround speakers to the wall
for Front surround setup.
EXTPOWER
Wall mounting the center speaker
The center speaker has a mounting hole which can be
used to mount the speaker on the wall.
5 mm
10 mm
Before mounting
• Remember that the speaker system is heavy and that
its weight could cause the screws to work loose, or
the wall material to fail to support it, resulting in the
speaker falling. Make sure that the wall you intend to
mount the speakers on is strong enough to support
them. Do not mount on plywood or soft surface walls.
• Mounting screws are not supplied. Use screws
suitable for the wall material and support the weight
of the speaker.
Caution
• If you are unsure of the qualities and strength of the
wall, consult a professional for advice.
• Pioneer is not responsible for any accidents or
damage that result from improper installation.
Additional notes on speaker placement
• Install the main front left and right speakers at an
equal distance from the TV.
• RCS-404H/505H only: For optimum effect, install the
surround speakers slightly above ear level.
• Install the center speaker above or below the TV so
that the sound of the center channel is localized at
the TV screen.
8
En
5 mm to 7 mm
Precautions:
• When installing the center speaker on top of the TV,
be sure to secure it with tape or some other suitable
means. Otherwise, the speaker may fall from the TV
due to external shocks such as earthquakes,
endangering those nearby or damaging the speaker.
Speaker Setup Guide
• The front (L/R), center and surround (L/R) speakers
supplied with this system are magnetically shielded.
However, depending on the installation location,
color distortion may occur if the speaker is installed
extremely close to the screen of a television set. If this
happens, turn the power switch of the television set
OFF, and turn it ON after 15 min to 30 min. If the
problem persists, place the speaker system away
from the television set.
• The receiver subwoofer is not magnetically shielded
and so should not be placed near a TV or monitor.
Magnetic storage media (such as floppy discs and
tape or video cassettes) should also not be kept close
to the receiver subwoofer.
• RCS-606H only: Do not attach the front, surround
speakers and receiver subwoofer to the wall or
ceiling. They may fall off and cause injury.
• RCS-404H/505H only: Do not attach the receiver
subwoofer to the wall or ceiling. They may fall off and
cause injury.
• For safety, make sure that there is no exposed bare
speaker wire outside of the speaker terminals.
• Do not connect any speakers other than those
supplied to this system.
• Do not connect the supplied speakers with any other
amplifier. This may result in malfunction or fire.
English
En
9
Connecting up
Chapter 3
Connecting up
Basic connections
Important
• When connecting this system or changing connections, be sure to switch power off and disconnect the power
cord from the wall socket.
After completing all connections, connect the power cords to the wall socket.
Receiver subwoofer (SX-SW606/SX-SW404)
FM antenna
AM loop antenna
3
SYSTEM CONNECTOR
USE ONLY WITH
DISPLAY UNIT
Control cable
CONTROL
OUT
AC IN
MCACC
SETUP MIC
SPEAKERS
SURROUND
SUB WOOFER
RL
CENTER
FRONT
RL
ab
CONTROL IN
ANTENNA
FM
UNBALAMLOOP ANTENNA75Ω
AUDIO INPUT
DIGITAL
DVD/DVR 1
DVD/DVR 2
(COAXIAL)
(OPTICAL)
Coaxial cable
(OPTICAL)
4
Display unit
DIGITAL
ANALOG
L
R
AC I
N
AV 1 (RGB) – TVAV 2 (INPUT 1/DECODER)
DIGITAL
CONTROL
OUT
COAXIAL IN
Y
P
B
OUTPUT
LR
P
R
COMPONENT
G-LINK
VIDEO OUT
VIDEOAUDIO
IN
OUT
S-VIDEO
ANTENNA
DVD Recorder
1
(DVR-640H-AV/
DVR-440H-AV)
2
Display cable
10
En
Connecting up
1 Connect the DVD recorder to the receiver
subwoofer.
a. Plug the control cable into the CONTROL OUT jack
on the rear of the receiver subwoofer.
Plug the other end of the cable into the CONTROL IN
jack on the rear of the DVD recorder.
b. Plug the coaxial cable into the DIGITAL AUDIO
INPUT (DVD/DVR 1) jack on the rear of the receiver
subwoofer.
Plug the other end of the cable into the COAXIAL DIGITAL OUT jack on the rear of the DVD recorder.
Note that unless the control cable is
connected, you can’t use the remote
control with the DVD recorder.
2 Connect the display unit to the receiver
subwoofer.
• Plug the L-shaped end of the display cable into the
connector on the rear of the display unit.
Plug the other end of the display cable into SYSTEM
CONNECTOR jack on the receiver subwoofer.
3 Assemble the AM loop antenna.
abc
4 Connect the AM and FM antennas
1
.
a. Connect one wire of the AM loop antenna to each AM
2
antenna terminal
.
For each terminal, press down on the tab to open;
insert the wire, then release to secure.
1
2
b. Push the FM antenna
FM antenna socket.
5 Connect each speaker.
• Each speaker cable has a color-coded connector at
one end and two wires at the other end.
• Twist and pull off the protective shields on each wire.
3
plug onto the center pin of the
Color-coded wire
(Connect to speaker)
Color-coded connector
(Connect to rear panel)
English
a. Bend the stand in the direction indicated by the
arrow.
b. Clip the loop onto the stand.
wired with the color-coded label (model label), then
insert the colored wire into the red (+) side and the
other wire into the black (–) side.
c. If you want to fix to a wall or other surface, perform
step b after first securing the stand with screws.
It is recommended that you determine the reception
strength before securing the stand with the screws.
Note
1• Keep antenna cables away from other cables, the display unit, receiver subwoofer and DVD recorder.
• If reception with the supplied antenna is poor, see Improving poor FM reception and Improving poor AM sound on page 29 or Connecting external antennas on page 34.
2• Don’t let it come into contact with metal objects and avoid placing near computers, television sets or other electrical appliances.
• The signal earth () is designed to reduce noise that occurs when an antenna is connected. It is not an electrical safety earth.
• If radio reception is poor, you may be able improve it by re-inserting each antenna wire into the opposite terminal.
• For best reception, do not untwist the AM loop antenna wires or wrap them around the loop antenna.
3• To ensure optimum reception, make sure the FM antenna is fully extended and not coiled or hanging at the rear of the unit.
• Connect the wires to the speaker. Match the colored
11
En
Connecting up
Receiver subwoofer (SX-SW404)
MCACC
SETUP MIC
6
CONTROL
OUT
SUB WOOFER
CENTER
SPEAKERS
SURROUND
RL
RL
SYSTEM CONNECTOR
USE ONLY WITH
DISPLAY UNIT
AC IN
8
Receiver subwoofer (SX-SW606)
FRONT
CONTROL IN
5
DVD/DVR 1
ANTENNA
FM
UNBAL
DIGITAL
DVD/DVR 2
AUDIO INPUT
AM
LOOP ANTENNA75Ω
ANALOG
OPTICAL
To AC outlet
Surround right
(Gray)
L
R
Front right
Listening position
Center (Green)
(Red)
Surround left
(Blue)
Front left
(White)
12
En
SYSTEM CONNECTOR
USE ONLY WITH
DISPLAY UNIT
8
CONTROL IN
MCACC
SETUP MIC
CONTROL
SPEAKERS
65
OUT
AC IN
SUB WOOFER
CENTER
SURROUND
RL
FRONT
RL
ANTENNA
FM
UNBAL
DVD/DVR 2
DVD/DVR 1
To AC outlet
DIGITAL
AUDIO INPUT
OPTICAL
Surround right
(Gray)
AM
LOOP ANTENNA75Ω
ANALOG
L
R
Listening position
Surround left
(Blue)
Center (Green)
Front right
(Red)
Front left
(White)
Connecting up
• Connect the other end to the color-coded speaker
terminals on the rear of the receiver subwoofer. Make
sure to insert completely.
The small lug at the wire-end of the speaker plug
should face up or down depending on whether it’s
being plugged into one of the upper or lower speaker
terminals. Please make sure to connect correctly.
Upper terminalLower terminal
6 Connect the subwoofer cable.
• Just below the subwoofer speaker, to the left of
center, you should see the subwoofer connecting
cable. Plug this into the SUBWOOFER SPEAKER
terminal.
Caution
• These speaker terminals carry HAZARDOUS LIVE
voltage. To prevent the risk of electric shock when
connecting or disconnecting the speaker cables,
disconnect the power cord before touching any
uninsulated parts.
• Do not connect any speakers other than those
supplied to this system.
• Do not connect the supplied speakers to any
amplifier other than the one supplied with this
system. Connection to any other amplifier may result
in malfunction or fire.
7 Connect the DVD recorder to your TV.
1
• Connect the VIDEO OUTPUT jack to a video input on
your TV.
Use the yellow jack of the supplied audio/video cable
for the video connection.
• Connect the AUDIO OUTPUT jacks to the
corresponding audio inputs on your TV.
Use the red and white jacks of the supplied audio/
video cable for the audio connection. Make sure you
match the left and right outputs with their
corresponding inputs for correct stereo sound.
8 Connect the power cord.
2
• Connect the power cords to AC inlets on the receiver
subwoofer and DVD recorder.
Connect the power cords to a wall socket.
English
7
Audio/video cable
(red/white/yellow)
DVD Recorder
(DVR-640H-AV/DVR-440H-AV)
AV 1 (RGB) – TVAV 2 (INPUT 1/DECODER)
AC I
N
DIGITAL
OUT
COAXIAL IN
CONTROL
G-LINK
COMPONENT
VIDEO OUT
Y
B
P
OUTPUT
LR
P
R
VIDEOAUDIO
S-VIDEO
8
To AC outlet
Note
1 Other types of video connection are possible. See page 51-page 54 for more information.
2• Do not use any power cord other than the one supplied with this system.
• Do not use the supplied power cord for any purpose other than connecting to this system.
AUDIO IN
VIDEO IN
TV
IN
OUT
ANTENNA
RF antenna
cable
Antenna/cable TV
wall outlet
ANTENNA IN
RF antenna
cable
ANTENNA IN
ANTENNA
OUT
13
En
Connecting up
Using this system for TV audio
If your TV has a stereo audio output you can connect it to
this system and enjoy surround TV sound.
AUDIO INPUT
CONTROL
SYSTEM CONNECTOR
USE ONLY WITH
DISPLAY UNIT
SPEAKERS
OUT
SURROUND
SUB WOOFER
RL
CENTER
RL
AC IN
1 Connect the AUDIO OUTPUT jacks on your TV to
the ANALOG AUDIO INPUT jacks on the receiver
subwoofer.
Use the red/white stereo audio cable (not supplied) for
this connection. Make sure you match the left and right
outputs with their corresponding inputs for correct
stereo sound.
• You can use the ANALOG AUDIO INPUT jacks for
any analog source you want, such as a tape deck, etc.
DIGITAL
DVD/DVR 2
ANALOG
OPTICAL
L
R
DVD/DVR 1
FRONT
1
AUDIO
OUTPUT
TV
14
En
Remote control
Chapter 4
Remote control
RECORDER
1
3
5
6
9
12
13
15
17
19
22
27
29
HDD/DVD
PAUSEPLAYSTOP
REC
TOP MENU
DISC
NAVIGATOR
CM
BACK
PAUS E
LIVE TVRETURN
PREV
AUDIO
/ /
SET UP
123
/ST–/ST+
456
MCACC
78
SURROUND
SLEEP
INPUT
TV CONTROL
MAIN SUB
Important
• Functions printed in green on the remote control are
accessed by switching the MAIN/SUB switch to SUB.
1 RECORDER
Press to switch the recorder on or into standby.
2 RECEIVER
Press to switch the receiver subwoofer on or into
standby.
RECEIVER
AUDIO IN
HELP
HOME MENU
CHANNEL
+
ENTER
CHANNEL
–
TIMER REC REC MODE
SR
+
/TUNE+
/TUNE–
TEST TONE VIDEO IN
9
0
CLEAR
++
VOLUME DISPLAY
––
OPEN
OPEN
SOUND
RETRIEVER
INFO
GUIDE
PLAY MODE
ONE TOUCH COPY
MENU
JUKE BOX
RDS DISP
AXD7442
FM/AM
STOP REC
NEXTVOLUME
SUBTITLE ANGLE
ENTER
ADVANCED SOUND TV/DVD
CHANNEL
CM
SKIP
2
4
7
8
10
11
14
16
18
20
21
23
24
25
26
28
3 Input select buttons
HDD/DVD (page 78)
Press to select the hard disk (HDD) or DVD for
recording or playback. The receiver subwoofer’s
audio input is also switched to DVD/DVR1.
1
FM/AM (page 29)
Press to select the built-in radio tuner.
AUDIO IN (page 34)
Press repeatedly to select one of the receiver
subwoofer’s audio inputs (DVD/DVR1, DVD/DVR2,
DIGITAL or ANALOG).
4 SOUND RETRIEVER
Press to restore CD quality sound to compressed audio
sources (page 27).
5 Playback controls (page 86)
PAUSE
Press to pause playback or recording.
PLAY
Press to start playback.
STOP
Press to stop playback.
6 Recording controls (page 78)
REC
Press to start recording. Press repeatedly to set the
recording time in blocks of 30 mins.
When the red action button is visible in a GUIDE
Plus+™ screen, use for One-Button-Record.
STOP REC
Press to stop recording.
7 INFO
Press to see additional information for the highlighted
item in GUIDE Plus+™.
8 HELP
Press for help on how to use the current GUI screen.
9 DISC NAVIGATOR (page 89, 96) / TOP MENU
(page 87)
Press to display the Disc Navigator screen, or the top
menu if a DVD-Video or finalized DVD-R/RW (Video) disc
is loaded.
English
Note
1 If the recorder is set to remote mode 2 or 3, the receiver subwoofer’s audio input will not be switched. See also Remote Control Mode on
page 134.
15
En
Remote control
10 GUIDE
Press to display the GUIDE Plus+™ screen; press again
to exit.
11 HOME MENU
Press to display the Home Menu, from which you can
navigate many the functions of the system.
12 /// (cursor buttons) and ENTER
Use to navigate all DVD recorder on-screen displays.
Press ENTER to select the currently highlighted
option.
CHANNEL +/– (page 77)
Press to change the channel of the built-in TV tuner.
CM BACK (commercial back)
Press repeatedly to skip progressively backward
through the audio or video playing.
CM SKIP (commercial skip)
Press repeatedly to skip progressively forward
through the audio or video playing.
13 PAUSE LIVE TV (page 79)
Press to start recording the current TV channel, but with
playback paused, effectively pausing the broadcast.
14 RETURN
Press to go back one level in the on-screen menu or
display.
15 PREV / NEXT
Press to skip to the previous or next title/chapter/track/
folder; or to display the previous or next menu page.
When GUIDE Plus+™ is displayed, use to display the
previous/next page.
16 VOLUME +/–
Use to adjust the volume.
17 GUIDE Plus+™ Action buttons and DVD playback
function buttons
When in the GUIDE Plus+™ system, these buttons
act as the Red, Green, Yellow and Blue Action
buttons (the functions of these buttons change
according to the GUIDE Plus+™ Area). (page 64)
AUDIO (page 77, 94)
Press to change the audio language or channel.
(When the recorder is stopped, press to change the
tuner audio.)
SUBTITLE (page 93)
Press to display/change the subtitles included in
multilingual DVD-Video discs.
ANGLE (page 94)
Press to switch camera angles on discs with multiangle scenes.
PLAY MODE (page 91)
Press to change the play mode (search, repeat,
program play, etc.)
18 TIMER REC (page 65)
Press to set a timer recording from the GUIDE Plus+™
system.
19 / (page 91)
Press to start reverse or forward scanning. Press
again to change the speed.
/, / (page 91)
While paused, press and hold to start slow-motion
playback. Press repeatedly to change the playback
speed.
While paused, press to advance a single frame in
either direction.
When GUIDE Plus+™ is displayed, use to display the
previous/next day.
20 REC MODE (page 77)
Press repeatedly to change the recording mode (picture
quality).
21 ONE TOUCH COPY (page 106)
Press to start One Touch Copy of the currently playing
title to DVD or the HDD.
22 Number buttons
Use the number buttons for track/chapter/title
selection; channel selection, and so on.
/// (cursor buttons) and ENTER
Use to control receiver functions.
SETUP
Use to access the menu system for surround sound
setup, tuner settings and so on (page 23, 29, 30, 31,
37).
SR+
Use to setup the SR+ features and to select the SR+
mode (page 36).
MCACC
Starts the Auto MCACC setup (page 23).
TEST TONE
Use to output the test tone (for speaker setup)
(page 32).
SURROUND
Use to select a Surround mode (page 25).
SLEEP
Press to set the sleep timer (page 37).
ADVANCED
Use to select a Pioneer original surround mode
(page 26).
16
En
Remote control
SOUND (page 27)
Press to access the sound menu, from which you can
adjust bass and treble, etc.
CLEAR
Press to clear an entry and start again.
23 MENU (page 87)
Press to display the disc menu if a DVD-Video, finalized
DVD-R/-RW or finalized DVD+R/+RW disc is loaded.
When in the GUIDE Plus+™ system, use to jump directly
to the Menu bar.
24 VIDEO IN (page 82)
Press to change the DVD recorder input for recording
and playback.
25 TV/DVD
Press to switch between ‘TV mode’, in which you get the
picture and sound from the TV’s tuner, and ‘DVD mode’,
in which you get picture and sound from the system’s
tuner (or an external input).
26 JUKEBOX (page 113)
Press to display the Jukebox screen of the DVD recorder,
from where you can copy music to the HDD for playback.
27 TV CONTROL (page 136)
After setting up, use these controls to control your TV.
28 DISPLAY (page 95)
Displays/changes the on-screen information
displays.
RDS DISP
Changes RDS displays (page 30).
29
MAIN/SUB
Change from MAIN to SUB to access the green
functions/commands on the remote.
Using the remote control
Please keep in mind the following when using the remote
control:
• Make sure that there are no obstacles between the
remote and the remote sensor on the unit.
• Remote operation may become unreliable if strong
sunlight or fluorescent light is shining on the unit’s
remote sensor.
• Remote controllers for different devices can interfere
with each other. Avoid using remotes for other
equipment located close to this unit.
• Replace the batteries when you notice a fall off in the
operating range of the remote.
• When the batteries run down or you change the
batteries, the remote control mode is reset to
Recorder 1. See Remote Control Mode on page 134.
• Use within the operating range in front of the remote
control sensor on the display unit, as shown.
30
30
7m
Putting the batteries in the remote
control
1 Open the battery compartment cover on the
back of the remote control.
2 Insert two AA/R6 batteries into the battery
compartment following the indications (,) inside
the compartment.
3 Close the cover.
Caution
Incorrect use of batteries can result in hazards such
as leakage and bursting. Please observe the
following:
• Don’t mix new and old batteries together.
• Don’t use different kinds of battery together—
although they may look similar, different batteries
may have different voltages.
• Make sure that the plus and minus ends of each
battery match the indications in the battery
compartment.
• Remove batteries from equipment that isn’t going to
be used for a month or more.
• When disposing of used batteries, please comply
with governmental regulations or environmental
public instruction’s rules that apply in your country or
area.
WARNING
• Do not use or store batteries in direct sunlight or
other excessively hot place, such as inside a car or
near a heater. This can cause batteries to leak,
overheat, explode or catch fire. It can also reduce the
life or performance of batteries.
English
17
En
Before you start
Chapter 5
Before you start
Switching on
The DVD recorder and receiver subwoofer have separate power switches. The power switch for the receiver subwoofer
is located on the display unit.
Remote control
RECORDER
HDD/DVD
TOP MENU
NAVIGATOR
BACK
PREV
SURROUND
RECEIVER
PAUSE PLAY STOP
REC
DISC
CM
PAUSE
LIVE TVRETURN
AUDIO
/ /
SET UP
123
/ST–/ST
456
MCACC
78
SLEEP
INPUT
AUDIO IN
FM/AM
STOP REC
HELP
HOME MENU
CHANNEL
+
ENTER
CHANNEL
–
NEXT VOLUME
SUBTITLE ANGLE
TIMER REC REC MODE
+
ONE TOUCH COPY
/TUNE
+
SR
ENTER
+
/TUNE
–
TEST TONE VIDEO IN
9
ADVANCED SOUND TV/DVD
0
CLEAR
++
CHANNEL
VOLUME DISPLAY
––
TV CONTROL
SOUND
RETRIEVER
INFO
GUIDE
CM
SKIP
PLAY MODE
MENU
JUKE BOX
RDS DISP
STANDBY/ON
Display unit
– VOLUME + AUDIO INPUT SURROUND
18
En
OPEN/CLOSE
STANDBY/ON
USB
The table below shows what needs to be switched on for
various system functions:
Function
Display unit
DVD
recorder
DVD playbackOnOn
CD playbackOnOn
HDD playbackOnOn
RadioOnOff
Timer recordingOffOn
DVD Recorder (DVR-640H-AV)
HDD/DVD
S-VIDEODV INVIDEO L AUDIO R
(MONO)
INPUT
REC
COPY
ONE
STOP
TOUCH
CH
+–
REC
Setting up
After connecting and installing the DVD recorder and
receiver subwoofer, complete the steps below to set the
system up for use.
DVD recorder
• Set the date and time, TV channel tuning and the type
of TV in the Setup Navigator (page 59).
Receiver subwoofer
• Switch off the display demo mode (page 23).
• Complete the Auto MCACC setup to optimize the
surround sound (page 23).
Before you start
Basic operation
This manual is split into to parts, one covering using the
receiver subwoofer, the other using the DVD recorder.
Below are some common operations and where to find
them explained in this manual.
Watching a DVD
Remember that when using the remote to control the
DVD recorder, you should point the remote towards the
display unit, not the recorder itself.
RECORDER
HDD/DVD
PAUS EPLAYSTOP
STOP REC
REC
TOP MENU
DISC
NAVIGATOR
CM
BACK
PAUS E
LIVE TV
PREV
AUDIO
SUBTITLE ANGLE
/ /
SET UPSR
1 Switch on the display unit (receiver subwoofer).
2 Switch on the DVD recorder.
3 Switch on your TV.
Turn on your TV and make sure that it is set to the correct
video input.
4 Press HDD/DVD.
5 Press OPEN/CLOSE on the DVD recorder to
open the disc tray.
6 Load a disc.
Load a disc with the label side facing up, using the disc
tray guide to align the disc (if you’re loading a doublesided DVD disc, load it with the side you want to play
face-down).
RECEIVER
AUDIO IN
FM/AM
RETRIEVER
HELP
HOME MENU
GUIDE
CHANNEL
+
ENTER
RETURN
CHANNEL
–
NEXTVOLUME
PLAY MODE
TIMER REC REC MODE
+
ONE TOUCH COPY
/TUNE
+
SOUND
INFO
CM
SKIP
7 Press (play) to start playback.
Press to stop playback.
You can resume playback from the same
point by pressing . (Press again to
cancel the resume function.)
Pauses playback, or restarts playback
when paused.
Press to start scanning. Press repeatedly
to increase the scanning speed.
See Basic playback on page 86 for more on playing discs.
8 Adjust the volume.
9 Adjust the sound using the surround effects
See Listening to your system on page 25 for details.
Listening to a CD
1 Switch on the display unit (receiver subwoofer).
2 Switch on the DVD recorder.
3 Press HDD/DVD.
4 Load a CD and start playback (page 88).
5 Adjust the volume.
6 Adjust the sound using the surround effects
(page 25).
Watching a title recorded on the HDD
1 Switch on the display unit (receiver subwoofer).
2 Switch on the DVD recorder.
3 Switch on your TV.
4 Press HDD/DVD.
5 Start playback of the HDD title (page 87).
6 Adjust the volume.
7 Adjust the sound using the surround effects
(page 25).
Listening to the radio
1 Switch on the display unit (receiver subwoofer).
2 Tune to a station (page 29).
3 Adjust the volume.
4 Adjust the sound using the surround effects
(page 25).
Lights when one of the Front Surround listening
modes is selected (page 26).
SURR.
Lights when one of the Advanced Surround listening
modes is selected (page 26).
3SOUND
Lights when Sound Retriever is active (page 27).
4Tuner indicators
received in auto stereo mode.
(RCS-404H/505H only)
– Lights when a broadcast is being received.
– Lights when a stereo FM broadcast is being
– Lights when FM mono reception is selected.
– VOLUME + AUDIO INPUT SURROUND
4 AUDIO INPUT (page 34)
Press repeatedly to select one of the external audio
inputs (DVD/DVR1, DVD/DVR2, DIGITAL or ANALOG).
5 SURROUND
Use to select a Surround mode (page 25).
6 IR remote sensor (page 17)
kHz
MHz
6
– Lights when in one of the RDS display or search
modes.
5kHz / MHz
Indicates the frequency unit shown in the character
display (kHz for AM, MHz for FM).
6Character display
7
Lights when sleep timer is active (page 37).
82 PL II
Lights during Dolby Pro Logic II decoding (page 25).
92 D
Lights during playback of a Dolby Digital source
(page 25).
54
22
En
Getting started
MCACC
SURROUND
ADVANCED SOUND TV/DVD
SLEEP
INPUT CHANNEL VOLUME DISPLAY
CLEAR
JUKE BOX
TEST TONE VIDEO IN
SR
+
ONE TOUCH COPY
MENU
/TUNE
+
/ /
TIMER REC REC MODE
/TUNE
–
/ST
–
/ST
+
123
456
78
0
++
9
0
02
Chapter 2
Getting started
Important
• To access green functions on the remote, move the
slider switch from MAIN to SUB.
System demo setting
Switches the automatic demo feature on or off (this
starts when you plug in for the first time).
SURROUND
AUDIO
SUBTITLE ANGLE
/ /
SETUP
123
/ST
–
456
MCACC
789
TIMER REC REC MODE
/TUNE
+
ENTER
/TUNE
–
TEST TONE VIDEO IN
+
SR
/ST
PLAY MODE
ONE TOUCH COPY
MENU
+
1 Switch the system into standby.
2 Press SETUP.
3 Use the / buttons to select DEMO from the
menu, then press ENTER.
4 Use the / buttons to select a setting, then
press ENTER.
Select from:
• DEMO ON – Switches the demo display on.
• DEMO OFF – Switches the demo display off and the
system into standby.
ADVANCED SOUND TV/DVD
0
SLEEP
++
INPUT
CHANNEL
––
TV CONTROL
MAIN SUB
CLEAR
JUKE BOX
VOLUME DISPLAY
RDS DISP
AXD7442
Using the Auto MCACC setup for
optimal surround sound
The Multichannel Acoustic Calibration (MCACC) system
measures the acoustic characteristics of your listening
area, taking into account ambient noise, and testing for
channel delay and channel level. After you have set up
the microphone provided, the system uses the
information from a series of test tones to optimize the
speaker settings and equalization (Acoustic Calibration
EQ) for your particular room.
Important
• The test tones used for Auto MCACC setup are loud;
however, do not turn the volume down during setup
as this may result in a sub-optimal setup.
• Make sure the microphone and speakers are not
moved during the MCACC setup.
RECORDER
HDD/DVD
PAUS EPLAYSTOP
REC
TOP MENU
FM/AM
STOP REC
AUDIO IN
RECEIVER
SOUND
RETRIEVER
INFOHELP
1 Connect the microphone to the MCACC SETUP
MIC jack on the rear panel.
MCACC
SETUP MIC
CONTROL
SPEAKERS
SYSTEM CONNECTOR
OUT
SUB WOOFER
RL
USE ONLY WITH
DISPLAY UNIT
CENTER
RL
AC IN
1
CLEAR
SLEEP
INPUT
MAIN SUB
ANTENNA
CONTROL IN
FM
UNBALAMLOOP ANTENNA
75Ω
AUDIO INPUT
DIGITAL
DIGITAL
DVD/DVR 1
DVD/DVR 2
SURROUND
FRONT
ANALOG
(OPTICAL)
(COAXIAL)
(OPTICAL)
L
R
++
CHANNEL
––
TV CONTROL
JUKE BOX
VOLUME DISPLAY
RDS DISP
AXD7442
English
2 Place the microphone at your normal listening
position.
Place the mic horizontally about ear level at your normal
listening position using a table or chair.
Make sure there are no obstacles between the speakers
and the microphone.
Note
1 You only need to use the Auto MCACC setup once (unless you change the placement of your speakers or your room layout).
23
En
02
Getting started
3 If the receiver subwoofer is off, press
RECEIVER to turn the power on.
4 Press MCACC.
Try to be as quiet as possible after pressing MCACC. The
volume increases automatically and the system outputs
a series of test tones.
• To cancel Auto MCACC setup before it has finished,
press MCACC. The unit will continue to use the
previous settings.
• If the ambient noise level is too high, NOISY blinks in
the display for five seconds. To exit and check the
noise levels
ENTER when RETRY shows in the display.
• If you see an ERR MIC or ERR SP message in the
display, there may be a problem with your mic or the
speaker connections. To try again, press ENTER
when you see RETRY
When the MCACC setup is complete, the volume level
returns to normal, COMPLETE
Acoustic Calibration EQ is activated.
1
, press MCACC, or to try again, press
2
3
shows in the display, and
4
24
En
Note
1• If the room environment is not optimal for the Auto MCACC setup (too much ambient noise, echo off the walls, obstacles blocking the speakers from
the microphone) the final settings may be incorrect. Check for household appliances (air conditioner, fridge, fan, etc.), that may be affecting the environment and switch them off if necessary.
• Some older TVs may interfere with the operation of the mic. If this seems to be happening, switch off the TV during Auto MCACC setup.
2 If this doesn’t work, press MCACC, turn off the power, and check the problem indicated by the ERR message, then try the Auto MCACC setup again.
3 If COMPLETE doesn’t appear, it is likely an error occurred during the setup. Please check all connections and try again.
4 See Listening with Acoustic Calibration EQ on page 27 to switch on/off Acoustic Calibration EQ.
Listening to your system
MCACC
TESTTONEVIDEOIN
/TUNE
MCACC
TESTTONEVIDEOIN
/TUNE
03
Chapter 3
Listening to your system
Important
• To access green functions on the remote, move the
slider switch from MAIN to SUB.
Auto listening mode
The Auto listening mode is the simplest way to listen to
any source as it was mastered: the output from the
speakers mirrors the channels in the source material.
RCS-404H/RCS-505H only: If you set up the system for
Front surround (page 7), the Front Surround modes will
give the best results (see Using Front Surround on
page 26).
78
SURROUND
SLEEP
INPUT
MAIN SUB
9
ADVANCED SOUND TV/DVD
0
CLEAR
JUKE BOX
++
CHANNEL
VOLUME DISPLAY
––
TV CONTROL
RDS DISP
AXD7442
•Press SURROUND to select the AUTO listening
mode.
If the source is Dolby Digital or DTS, the front panel 2 D
or DTS indicator lights.
• You can also use the SURROUND button on the
display unit to change the listening mode.
Listening in surround sound
You can listen to stereo or multichannel sources in
surround sound. Surround sound is generated from
stereo sources using one of the Dolby Pro Logic
decoding modes.
RCS-404H/RCS-505H only: If you set up the system for
Front surround (page 7), the Front Surround modes will
give the best results (see Using Front Surround on
page 26).
78
SURROUND
SLEEP
INPUT
MAIN SUB
9
ADVANCED SOUND TV/DVD
0
CLEAR
JUKE BOX
++
CHANNEL
VOLUME DISPLAY
––
TV CONTROL
RDS DISP
AXD7442
•Press SURROUND repeatedly to select a listening
mode.
• You can also use the SURROUND button on the
display unit to change the listening mode.
The choices that appear in the display will vary according
to the type of source that’s playing.
If the source is Dolby Digital or DTS, the front panel 2 D
or DTS indicator lights.
• AUTO – Auto listening mode (see above)
• DOLBY PL (Dolby Pro Logic) – 4.1 channel surround
sound for use with any two-channel source
• MOVIE (Dolby Pro Logic II Movie) – 5.1 channel
surround sound, especially suited to movie sources,
for use with any two-channel source
• MUSIC (Dolby Pro Logic II Music) – 5.1 channel
surround sound, especially suited to music sources,
for use with any two-channel source; see Dolby Pro Logic II Music settings below
• STEREO – See Listening in stereo on page 26
Dolby Pro Logic II Music settings
When listening in Dolby Pro Logic II Music mode (see
above), there are three settings you can adjust: Center
Width, Dimension, and Panorama.
SET UP
MCACC
SLEEPCLEAR
1 With Dolby Pro Logic II Music mode active, press
SOUND.
2 Use / to select C WIDTH, DIMEN. or
PANORAMA then press ENTER.
• C WIDTH (Center Width): Provides a better blend of
the front speakers by spreading the center channel
between the front right and left speakers, making it
sound wider (higher settings) or narrower (lower
settings)
• DIMEN. (Dimension): Adjusts the depth of the
surround sound balance from front to back, making
the sound more distant (minus settings), or more
forward (positive settings)
123
/ST
456
78
SR+ONE TOUCH COPY
/TUNE
+
ENTER
–
/ST
+
/TUNE
–
TEST TONE VIDEO IN
9
ADVANCED SOUND TV/DVD
0
MENU
JUKE BOX
INPUT
TV CONTROL
MAIN SUB
++
CHANNEL
VOLUME DISPLAY
––
English
RDS DISP
AXD7442
25
En
03
78
9
SURROUND
ADVANCED SOUND TV/DVD
SLEEP
INPUT
MAIN SUB
CHANNEL
TV CONTROL
RDS DISP
AXD7442
VOLUME DISPLAY
CLEAR
JUKE BOX
78
0
++
––
9
MCACC
SURROUND
ADVANCED SOUND TV/DVD
SLEEP
INPUT
MAIN SUB
CHANNEL
TV CONTROL
RDS DISP
AXD7442
VOLUME DISPLAY
CLEAR
JUKE BOX
TEST TONEVIDEO IN
/TUNE
78
0
++
––
9
Listening to your system
• PANORAMA: Extends the front stereo image to
include the surround speakers for a ‘wraparound’
effect.
3 Use / to adjust the setting then press ENTER
to confirm.
Using Front Surround
RCS-404H/RCS-505H only
The Front Surround modes are effective when you are
using the Front surround speaker setup as described on
page 7. The surround speakers should be placed beside
the front speakers and oriented either towards the walls,
or straight ahead, depending on which mode you are
using (see below).
SURROUND
ADVANCED SOUND TV/DVD
0
SLEEP
INPUT
MAIN SUB
•Press ADVANCED to select a Front Surround
mode.
Press repeatedly to select FRTMOVIE, FRTMUSIC or
EXTPOWER.
• If you have selected FRTMOVIE (Front Surround
Movie) or FRTMUSIC (Front Surround Music), turn
each surround speaker so that the guide markers on
the stand base are lined up horizontally in the
direction the listening position (see below). With
EXTPOWER (Extra Power), the surround speakers
should point in the same direction as the front
speakers (see below).
++
CHANNEL
––
TV CONTROL
CLEAR
JUKE BOX
VOLUME DISPLAY
RDS DISP
AXD7442
RCS-404H/RCS-505H only: If you set up the system for
Front surround (page 7), the Front Surround modes will
give the best results (see Using Front Surround above).
•Press ADVANCED to select an Advanced
Surround mode.
Press repeatedly to select:
• ADVMOVIE – Suitable for movies
• ADVMUSIC – Suitable for music
• EXPANDED – Wide sound field
• TV SURR. – Surround sound for mono or stereo TV
broadcasts
• SPORTS – Suitable for sports programming
• GAME – Suitable for TV game units
• VIRTUAL – A virtual surround effect using just the
subwoofer and front speakers.
• 5 STEREO – Powerful surround sound for stereo
music sources
Listening in stereo
You can listen to any source—stereo or multichannel—in
stereo. When playing a multichannel source, all
channels are downmixed to the front left/right speakers
and the subwoofer.
26
En
FRTMOVIE / FRTMUSIC
Using Advanced Surround
The Advanced Surround effects can be used with any
multichannel or stereo source for a variety of additional
surround sound effects.
EXTPOWER
•Press SURROUND repeatedly until STEREO shows
in the display.
• You can also use the SURROUND button on the
display unit to change the listening mode.
Listening to your system
03
Using the Sound Retriever
When audio data is removed during the MP3 or WMA
compression process, sound quality often suffers from
an uneven sound image. The Sound Retriever feature
employs new DSP technology that helps bring CD quality
sound back to compressed 2-channel audio by restoring
sound pressure and smoothing jagged artifacts left over
after compression.
Tip
• This feature is effective when used together with the
Jukebox function of the DVD recorder.
RECORDER
HDD/DVD
PAUSEPLAYSTOP
FM/AM
AUDIO IN
RECEIVER
SOUND
RETRIEVER
•While listening to a stereo source, press SOUND
RETRIEVER .
Press repeatedly to switch between:
• RTRV ON — Switches the Sound Retriever on.
• RTRV OFF — Switches the Sound Retriever off.
Listening with Acoustic Calibration
EQ
You can listen to sources using the Acoustic Calibration
EQ set in Using the Auto MCACC setup for optimal surround sound on page 23.
/ /
SET UP
MCACC
SURROUND
SLEEP
INPUT
1 Press SOUND.
2 Use the / buttons to select MCACC EQ then
press ENTER.
TIMER REC REC MODE
123
456
78
MAIN SUB
SR
+
ENTER
TEST TONE VIDEO IN
9
ADVANCED SOUND TV/DVD
0
CLEAR
++
CHANNEL
VOLUME DISPLAY
––
TV CONTROL
ONE TOUCH COPY
MENU
JUKE BOX
RDS DISP
AXD7442
3 Use the / buttons to switch EQ ON or EQ OFF
then press ENTER to confirm.
• On the EQ OFF setting, equalization is set to off and
speaker settings (channel delay and channel level)
remains as it is set.
• Acoustic Calibration EQ is set to on automatically
after Auto MCACC setup is used.
Enhancing dialogue
The Dialogue Enhancement feature is designed to make
the dialogue stand out from other background sounds in
a TV or movie sound track.
1 Press SOUND.
2 Use the / buttons to select DIALOGUE then
press ENTER.
3 Use the / buttons to select the amount
dialogue enhancement then press ENTER to confirm.
Select between OFF, MID or MAX.
Using Quiet and Midnight listening
modes
The Quiet listening feature reduces excessive bass or
treble in a sound source.
The Midnight listening feature allows you to hear
effective surround sound of movies at low volume levels.
1 Press SOUND.
2 Use the / buttons to select TONE then press
ENTER.
3 Use the / buttons to select QUIET or
MIDNIGHT then press ENTER to confirm.
• To cancel the Quiet or Midnight listening modes,
select BASS/TRE.
Adjusting the bass and treble
Use the bass and treble controls to adjust the overall
tone.
1 Press SOUND.
2 Use the / buttons to select TONE then press
ENTER.
3 Use the / buttons to select BASS/TRE then
press ENTER.
• Selecting BASS/TRE cancels the Quiet and Midnight
listening modes. These modes cannot be used at the
same time.
4 Use the / buttons to select BASS or TREBLE;
use the / buttons to adjust the sound then press
ENTER to confirm.
English
27
En
03
Listening to your system
Boosting the bass level
There are two bass modes you can use to enhance the
bass in a source.
1 Press SOUND.
2 Use the / buttons to select BASSMODE then
press ENTER.
3 Use the / buttons to select the sound then
press ENTER to confirm.
Select between OFF, MUSIC or CINEMA.
28
En
Listening to the radio
04
Chapter 4
Listening to the radio
Important
• To access green functions on the remote, move the
slider switch from MAIN to SUB.
Listening to the radio
The tuner can receive both FM and AM broadcasts, and
lets you memorize your favorite stations so you don’t have
to manually tune in every time you want to listen.
RECORDER
HDD/DVD
FM/AM
PAUS EP LAYSTOP
REC
STOP REC
TOP MENU
DISC
NAVIGATOR
CM
BACK
PAUSE
LIVE TV
PREV
NEXTVOLUME
AUDIO
SUBTITLE ANGLE
/ /
SET UP
123
/ST
–
456
MCACC
78
SURROUND
ADVANCED SOUND TV/DVD
SLEEP
INPUT
CHANNEL
TV CONTROL
MAIN SUB
1Press
FM/AM
to switch to the tuner, then press
repeatedly to select the FM or AM band.
The display shows the band and frequency.
2Tune to a frequency.
There are three tuning modes—manual, auto, and highspeed:
AUDIO IN
HELP
HOME MENU
CHANNEL
+
ENTER
CHANNEL
–
TIMER REC REC MODE
+
/TUNE
+
SR
ENTER
/ST
/TUNE
–
TEST TONE VIDEO IN
9
0
CLEAR
++
VOLUME DISPLAY
––
SOUND
RETRIEVER
INFO
GUIDE
RETURN
PLAY MODE
ONE TOUCH COPY
MENU
+
JUKE BOX
AXD7442
CM
SKIP
• Manual tuning: Press TUNE +/– repeatedly to
change the displayed frequency.
• Auto tuning: Press and hold TUNE +/– until the
frequency display starts to move, then release. The
tuner will stop on the next station it finds. Repeat to
keep searching.
• High-speed tuning: Press and hold TUNE +/– until
the frequency display starts to move rapidly. Keep the
button held down until you reach the frequency you
want. If necessary, fine tune the frequency using the
manual tuning method.
Improving poor FM reception
If you’re listening to an FM station in stereo but the
reception is weak, you can improve the sound quality by
switching to mono.
1Tune to an FM radio station then press
2Use the
press
ENTER
3Use the
press
ENTER
The mono indicator () lights when the tuner is in mono
reception mode.
Select FM AUTO above to switch back to auto-stereo
mode (the stereo indicator () lights when receiving a
stereo broadcast).
Improving poor AM sound
The simplest way to improve the sound quality of AM
radio is to make sure that the TV in the room is switched
off. Also try changing the position and direction of the
AM loop antenna.
Changing the noise cut mode
If you find that the sound quality is bad even after trying
the above, you may be able to improve it using a different
noise cut mode. Just choose the one that sounds best.
1 Tune to an AM radio station then press SETUP.
2
Use the
press ENTER.
3
Use the
(1, 2 or 3) then press ENTER.
/
buttons to choose FM MODE then
.
/
buttons to select
FM MONO
.
/
/
buttons
buttons
to choose NOISECUT then
to select a Noise cut mode
SETUP
then
English
.
29
En
04
SET UP
MCACC
ADVANCED SOUND TV/DVD
SLEEP
INPUT
MAIN SUB
CHANNEL
TV CONTROL
RDS DISP
AXD7442
VOLUME DISPLAY
CLEAR
JUKE BOX
TEST TONE VIDEO IN
SR
+
ONE TOUCH COPY
MENU
/TUNE
+
ENTER
/TUNE
–
/ST
–
/ST
+
123
456
78
0
++
––
9
ENTER
456
Listening to the radio
30
En
Memorizing stations
You can save up to 30 station presets so that you always
have easy access to your favorite stations without having
to tune in manually each time.
Displaying RDS information
You can display the different types of RDS information
available.
2
1Tune to an AM or FM radio station.
For the FM band, select mono or auto-stereo reception as
necessary. This setting is saved along with the preset.
2Press
3Use the
press
4Use the
you want then press
SETUP
ENTER
.
/
buttons to choose ST.MEM. then
.
/
buttons to select the station preset
ENTER
.
Listening to station presets
1Make sure the tuner function is selected.
2Use the
ST +/–
buttons to select a station preset.
•Press
RDS DISP
for RDS information.
Each press changes the display as follows:
• Radio Text (RT) – Messages sent by the radio station.
For example, a talk radio station may provide a phone
number as RT.
Using RDS
Radio Data System (RDS) is a system used by most FM
radio stations to provide listeners with various kinds of
information—the name of the station and the kind of
show they’re broadcasting, for example.
One feature of RDS is that you can search by type of
program. For example, you can search for a station that’s
• Program Service Name (PS) – The name of the radio
station.
• Program Type (PTY) – This indicates the kind of
program currently being broadcast.
• SEARCH – PTY search (see below)
• Current tuner frequency
broadcasting a show with the program type, JAZZ.
You can search the following program types:
NEWS – News
AFFAIRS – Current Affairs
INFO
– General Information
SPORT – Sport
EDUCATE – Educational
DRAMA – Radio plays, etc.
CULTURE – National or regional
culture, theater, etc.
SCIENCE – Science and
technology
VARIED – Usually talk-based
material, such as quiz shows or
interviews.
POP M – Pop music
ROCK M – Rock music
EASY M – Easy listening
LIGHT M – ‘Light’ classical music
CLASSICS – ‘Serious’ classical
music
OTHER M – Music not fitting
above categories
WEATHER – Weather reports
Note
1 In addition, there are three other program types, TEST, ALARM, and NO TYPE. ALARM and TEST are used for emergency announcements. You can’t
search for these, but the tuner will switch automatically to this RDS broadcast signal. NO TYPE appears when a program type cannot be found.
2• If any noise is picked up while displaying the RT scroll, some characters may be displayed incorrectly.
• If you see NO DATA in the RT display, it means no RT data is sent from the broadcast station. The display will automatically switch to the PS data
display (if no PS data, the frequency is displayed).
• In the PTY display, NO DATA or NO TYPE may be shown. In this case, the PS display is shown after a few seconds.
3 RDS is only possible in the FM band.
FINANCE – Stock market reports,
commerce, trading, etc.
CHILDREN – Programs for
children
SOCIAL – Social affairs
RELIGION – Programs
concerning religion
PHONE IN – Public expressing
their views by phone
TRAVEL – Holiday-type travel
rather than traffic
announcements
LEISURE – Leisure interests and
hobbies
JAZZ – Jazz
COUNTRY
NATION M – Popular music in a
language other than English
OLDIES – Popular music from the
’50s and ’60s
FOLK M – Folk music
DOCUMENT
1
– Country music
– Documentary
Searching for RDS programs
You can search for a program type listed above.
1Press the
2Press
FM/AM
RDS DISP
button for the FM band.
repeatedly until SEARCH appears in
the display.
3Use the
/
buttons to select the program type
you want to hear.
4Press
ENTER
to start the search.
The system searches the station presets for a match. If it
finds one, searching stops for 5 sec.
5If you want to keep listening to the station, press
ENTER
within the 5 seconds.
If you don’t press ENTER, searching resumes.
3
Loading...
+ 122 hidden pages
You need points to download manuals.
1 point = 1 manual.
You can buy points or you can get point for every manual you upload.
