Pioneer KEX-M8306ZT, KEX-M8206ZT Service Manual

ORDER NO.

CRT2545

PUB. NO. CRT2545

AUDIO SYSTEM

HEAD UNIT

Manufactured for TOYOTA

by PIONEER CORPORATION

VEHICLE DESTINATION PRODUCED AFTER TOYOTA PART No. ID No. PIONEER MODEL No.

LEXUS LX470 U.S.A., CANADA August 2000 86120-60390 P1720 KEX-M8206ZT/UC

LEXUS LX470 U.S.A., CANADA August 2000 86120-60390 P1720 KEX-M8206ZT-91/UC

LEXUS LX470 U.S.A., CANADA August 2000 86120-60280 P1722 KEX-M8306ZT/UC

LEXUS LX470 U.S.A., CANADA August 2000 86120-60280 P1722 KEX-M8306ZT-91/UC

LX470

2

KEX-M8206ZT,M8206ZT-91,M8306ZT,M8306ZT-91

- Dolby noise reduction manufactured under license from Dolby Laboratories Licensing Corporation.

"Dolby" and the double-D symbol are trademarks of Dolby Laboratories Licensing Corporation.

- These models do not provide the test mode for CD changers.

- KEX-M8206ZT/UC and KEX-M8306ZT/UC have adopted AVC-LAN.

KEX-M8206ZT/UC

- Supplementary model is identical to the original except for the addition of following items.

Description Part No.

KEX-M8206ZT-91/UC KEX-M8306ZT-91/UC

Polyethylene Bag CEG1106 CEG1106

Carton CHA1721 CHA1721

Contain Box CHL4139 CHL4140

Cover CEG1045 CEG1045

KEX-M8306ZT/UC

ID No.P1720

ID No.P1722

- This service manual should be used together with the following manual(s):

Model Order No. Mech. Module Remarks

CX-631 CRT1640 2L Cassette Mech. Module:Mech.Description

CONTENTS

1. SAFETY INFORMATION ............................................3

2. EXPLODED VIEWS AND PARTS LIST.......................4

3. BLOCK DIAGRAM AND SCHEMATIC DIAGRAM .....8

4. PCB CONNECTION DIAGRAM ................................30

5. ELECTRICAL PARTS LIST ........................................44

6. ADJUSTMENT..........................................................55

7. GENERAL INFORMATION .......................................60

7.1 DIAGNOSIS .......................................................60

7.1.1 DISASSEMBLY ........................................60

7.1.2 CONNECTOR FUNCTION DESCRIPTION ..61

7.1.3 TROUBLESHOOTING................................62

7.2 IC ........................................................................64

7.3 EXPLANATION ..................................................69

7.3.1 SYSTEM BLOCK DIAGRAM ...................69

7.3.2 OPERATIONAL FLOW CHART ................70

8. OPERATIONS AND SPECIFICATIONS.....................71

3

KEX-M8206ZT,M8206ZT-91,M8306ZT,M8306ZT-91

1. SAFETY INFORMATION

This service manual is intended for qualified service technicians; it is not meant for the casual do-it-yourselfer.

Qualified technicians have the necessary test equipment and tools, and have been trained to properly and safely repair

complex products such as those covered by this manual.

Improperly performed repairs can adversely affect the safety and reliability of the product and may void the warranty.

If you are not qualified to perform the repair of this product properly and safely, you should not risk trying to do so

and refer the repair to a qualified service technician.

4

KEX-M8206ZT,M8206ZT-91,M8306ZT,M8306ZT-91

3

1

1

1

5

15

45

7

17

11

12

10

43

44

42

6

43

18

9

19

16

7

8

8

13

14

8

8

4

2

2

20

27

21

30

31

21

21

21

21

50

46

46

36

41

37

35

49

49

43

23

26

39

40

24

26

43

33

34

32

22

38

25

33

34

32

48

47

29

28

2. EXPLODED VIEWS AND PARTS LIST

2.1 EXTERIOR

5

KEX-M8206ZT,M8206ZT-91,M8306ZT,M8306ZT-91

Mark No. Description Part No.

Mark No. Description Part No.

1 Screw BMZ26P050FMC
2 Screw BMZ30P050FMC
3 Case CNB2590
4 Insulator CNM6654
5 Cushion CNM6934

6 Main Unit(KEX-M8206ZT) CWM7093

Main Unit(KEX-M8306ZT) CWM7096
7 Screw BMZ30P080FMC
8 Screw BPZ30P060FSN
9 Terminal(CN202) CKF1059

10 Terminal(CN303) CKF1059
11 Connector(CN302) CKM1065
12 Connector(CN301) CKM1322
13 Plug(CN651) CKS3542
14 Connector(CN701) CKS3568

15 Antenna Jack(CN201) CKX1024
16 Holder CNC8711
17 Holder CNC8712
18 FM/AM Tuner Unit CWE1611
19 Holder CNC6774

20 Chassis Unit CXB5297
21 Screw BPZ26P100FMC
22 Button(EJECT) CAC6642
23 Button(CH,PROG,DISC) CAC6771
24 Button(SEEK,TRACK) CAC6772

25 Button(TRAF) CAC6557
26 Lighting Conductor CNV6144
27 Rubber CNV6145
28 Lighting Conductor CNV6500
29 Holder CNV6502

30 Keyboard Unit CWM7103
31 Socket(CN901) CKS3555
32 Knob Assy CXB5296

* 33 Knob CAA1500

34 Spring CBL-108

35 Button(AM) CAC5252
36 Button(TAPE) CAC5254
37 Button(FM) CAC5253
38 Grille Unit(KEX-M8206ZT)CXB6091

Grille Unit(KEX-M8306ZT)CXB6092

39 Door(KEX-M8206ZT) CAT2133

Door(KEX-M8306ZT) CAT2135
40 Spring CBH1371
41 Button(DISC) CAC6186
42

Cassette Mechanism ModuleEXK3885

43 Screw IMS26P050FMC
44 Transistor(Q331) 2SB1185
45 Transistor(Q521) 2SB1185
46 Shield CNC9047
47 Holder CNV6503

48 Lighting Conductor CNV6501
49 Holder Unit CXB2765
50 Lighting Conductor CNV6143

-

EXTERIOR SECTION PARTS LIST

NOTE:

- Parts marked by “*” are generally unavailable because they are not in our Master Spare Parts List.

- Screws adjacent to ∇ mark on the product are used for disassembly.

6

KEX-M8206ZT,M8206ZT-91,M8306ZT,M8306ZT-91

2.3 CASSETTE MECHANISM MODULE

7

KEX-M8206ZT,M8206ZT-91,M8306ZT,M8306ZT-91

1 Screw BSZ20P040FMC
2 Washer CBF1037
3 Washer CBF1038
4 Washer CBG1003
5 Deck Unit EWM1027

6 Screw(M2x5) EBA1028
7 Screw(M2x2.5) EBA1037
8 Spring EBH1531
9 Spring EBH1589

10 Connector(CN251) CKS3540

11 Spring EBH1515
12 Spring EBH1587
13 Spring EBH1517
14 Spring EBH1518
15 Spring EBH1519

16 Spring EBH1537
17 Cord EDD1027
18 Photo-interrupter

(EGN2,3) EGN1006

19 Photo-interrupter(EGN1) EGN1005
20 Roller ENR1031

21 Shaft ELA1362
22 Roller ELA1348
23 Arm ENC1490
24 Arm ENC1397
25 Guide ENC1519

26 Holder ENC1516
27 Lever ENC1448
28 Arm ENC1488
29 Roller ENR1023
30 Belt ENT1027

31 Gear ENV1347
32 Collar ENV1508
33 Gear ENV1350
34 Flywheel ENV1500
35 Worm Gear ENV1439

36 Worm Wheel ENV1440
37 Gear ENR1037
38 Lever ENV1533
39 Arm ENV1525
40 Gathering PCB ENX1037

41 Gathering PCB ENX1060
42 Switch(S1)(S2) ESG1004
43 Motor Unit(M2)(SUB) EXA1382
44 Chassis Unit EXA1559
45 Tube ENM1039

46 Roller ENR1027
47 Reel Unit EXA1560
48 Head Base Unit EXA1434
49 Lever Unit EXA1578
50 Gear Unit EXA1545

51 Frame Unit EXA1476
52 Lever Unit EXA1439
53 Head Assy(HD1) EXA1594
54 Motor Unit(M1)(MAIN) EXA1499
55 Washer HBF-179

56 Screw JGZ20P025FNI
57 Spring EBH1545
58 Washer YE20FUC
59 Pinch Roller Unit EXA1533
60 Pinch Roller Unit EXA1532

61 Capacitor(C1) CEAL4R7M35

Mark No. Description Part No. Mark No. Description Part No.

- CASSETTE MECHANISM MODULE SECTION PARTS LIST

8

KEX-M8206ZT,M8206ZT-91,M8306ZT,M8306ZT-91

A

1

234

B

C

D

12

34

Q203

Q3

L2 D5

L4 D7

25

26

Q201

AM RF

AM
OSC

FM
OSC

D231

CF52

CF51

T31

Q31

CF232

CF230

23

25

PA4026A

IC1

CF53

L52

PA4024A

IC2

DIVER

IC202

LA1061M

AM

CN201

SUB
ANT

MAIN

ANT

FIX

COMP

FMTV

AMTV

VCO

AMIFC

FMB

AMB

TUNB

19 20

17

15 21

14

13

11

6

2

IC201

PM2007A

PLL

XIN

XOUT

PDI
PCK
PDO
PCE

29

25

COMP

9

5
4

IC204

PM4006B

11

12

IC205
NJM2903M

RDS DECODER

CN251

CN252

CN253

IC251

HA12216F

TAPE EQUALIZER

MECHANISM DRIVER

IC351

PA2020A

Q271

B.U

BU

M

SUB

MOTOR

M

MAIN

MOTOR

10

+B

TAPE-L

MTL

MTL

VR301

VREF

6

22

14

17

2

51

53

17

7

18

19

5

2

NR

Q351
Q352

1

9

8

STBY

LOAD

LOAD

SWITCH

MODE
SENSE

FWD

SENSE

REV

SENSE

1

4

5

4

3

20

FWD

LcH

REV
LcH

23

8

1

64

23

8

1

64

41

910

34

63836

32

14 15 17 19

30

31

28

47

1

2

19

40 7

43

Lch

FMSL

AMSL

STO/AMDET

ST

COMP

FMSD

PNS

S-80736AN-D0

IC703

2

1

RESET

VDD

Q528

Q530

Q531

Q205

HA12181FP

IC203

AM NOISE

CANCELLER

3AM-L

9

16

Q703

MUTE

Q705

MUTE

FM-L

AM-L

BU

CN701

4

3

20

19 2

65

20

18

2

3

1

57K

25

57K

13

15

12

RESET

Q706

88

TAPEMUTE

AUD+B

TAPE-L

Q201

SL

51

DSSILL

XIN

XOUT

SYSTEM CONT

IC601

PDI
PCK
PDO
PCE

1

5,6

13

ST

SD

SL

SD

95

90

ST

89

38

37

A

MAIN UNIT

FM/AM TUNER UNIT

B

C

DECK UNIT

D

PCB UNIT

E

REEL PCB

7

9

18

10

3

PD5579A

SWITCH

70µs

3. BLOCK DIAGRAM AND SCHEMATIC DIAGRAM

3.1 BLOCK DIAGRAM(KEX-M8206ZT)
