Pinnacle Systems Pro Tools HD User Manual

chapter 2
Pro Tools Keyboard Shortcuts for Windows

Conventions Used in This Guide

Digidesign guides use the following conven­tions to indicate menu choices and key com­mands:
:
Convention Action
File > Save Session Choose Save Session
from the File menu
Ctrl+N Hold down the Control
key and press the N key
Alt+“+/–” Hold down the Alt key
and press the “+” or “–” key (numeric keypad or QWERTY, as noted)
Ctrl-click Hold down the Control
key and click the mouse button
Right-click (Windows) Click with the right
mouse button
Windows Keyboard Shortcuts for Pro Tools 6.9
1

Global Keyboard Commands

Table 3. Global Keyboard Shortcuts for Windows Systems
Task Shortcut
Change all audio channel strips Alt+applicable function
Change all selected audio channel strips Alt+Shift+applicable function
Applicable functions: Automation mode • playlist enables • record, solo and mute enables
• record and solo safes • inserting plug-ins • I/O, bus, send assignment
• volume/peak indicator • extend selection • track heights • clear clip meter
Toggle item and set all others to same new state Alt-click on applicable item
Toggle item and set all others to opposite state Ctrl-click on applicable item
Applicable items: Tracks in Show/Hide Tracks List • Group enables/activation
• Automation Enable window • memory location parameters
Fine Tune (fine adjust mode) Ctrl-click on applicable fader/pot/breakpoint
Applicable functions: Plug-In parameter editing • fader movement • scrubbing
• automation data trimming (requires larger track view for highest resolution)
Select multiple contiguous items (tracks, regions, paths)
Applicable functions: Tracks (click Track names) • Regions in Regions List
Windows Keyboard Shortcuts for Pro Tools 6.9
2
Click to select first item, then Shift-click another to select all similar items between
• Paths in I/O Setup

Record and Playback

Table 4. Record and Playback Shortcuts for Windows Systems
Task Shortcut
Open New Track Dialog Ctrl+Shift+N (for more information, see “New Tracks
Dialog” on page 4)
Start record Ctrl+Spacebar (or F12)
Stop record Spacebar
Stop record and discard take Ctrl+”.” (period key)
Start/stop playback Spacebar
Half-speed record Ctrl+Shift+Spacebar
Half-speed playback Shift+Spacebar
Pause (pre-prime deck for instant playback and record)
Enable/disable online record Ctrl+Alt+Spacebar
Enable/disable online playback Ctrl+J, or Alt+Spacebar
Cycle through record modes (normal/Destruc­tive/Loop/TrackPunch/QuickPunch)
Loop playback toggle Start-click, or right mouse-click, on Transport Play
Record-safe track Ctrl-click on track Record Enable button
Solo-safe track Ctrl-click on track Solo button
TrackPunch Ctrl+Shift+T
QuickPunch Ctrl+Shift+P
Enter/Exit record during playback in QuickPunch Ctrl+Spacebar (or F12) or click Transport Record but-
Set and enable pre/post-roll time Alt-click with selector before/after selection
Disable pre/post-roll time Ctrl+K (or Alt-click within selection closer to
Start+Spacebar, or Alt-click on Transport Play button
Right mouse-click on Transport record button
button
ton
front/back)
Windows Keyboard Shortcuts for Pro Tools 6.9
3
Table 4. Record and Playback Shortcuts for Windows Systems
Task Shortcut
Scroll to selection start/end Left/Right Arrow keys (when selection exceeds win-
dow view)
Toggle Transport Master (Pro Tools/Machine/MMC) Ctrl+\
Back/Forward (move the playback location back­wards/forwards by the Back/Forward amount)
Back/Forward and Play (move the playback location backwards/forwards by Back/Forward amount and then begin playback)
Extend a selection backwards by the Back/Forward amount
Extend the selection backwards by the Back/For­ward amount and begin playback
Ctrl+Rewind/Fast-Forward (Transport)
Ctrl+Alt+Rewind
Shift+Ctrl+Rewind
Shift+Ctrl+Alt+Rewind

New Tracks Dialog

Table 5. New Tracks Dialog Shortcuts
Task Shortcut
Cycle through Track Type choices Control+Up/Down Arrow
Cycle through Track Format choices Control+Left/Right Arrow
Cycle through Track Timebase choices Control+Alt+Up/Down Arrow
Add or delete a Track Entry field Control+Plus/Minus (+/–)
Re-arrange Track Entry field (move up/down) Drag the Up/Down icon (at left of each Track Entry
row) to desired position
Windows Keyboard Shortcuts for Pro Tools 6.9
4

Auditioning

When Transport = Pro Tools
Table 6. Auditioning when Transport = Pro Tools
Task Shortcut
Play by pre-roll value up to selection start/end (or current location if no selection)
Play by post-roll value from selection start/end (or current cursor location if no selection)
Play by pre & post-roll value through selection start/end
Alt+Left/Right Arrow keys
Ctrl+Left/Right Arrow keys
Ctrl+Alt+Left/Right Arrow keys
When Transport = Machine/MMC
Table 7. Auditioning when Transport = Machine/MMC
Task Shortcut
Cue transport to selection start/end Ctrl+Left/Right Arrow keys
Cue transport with pre/post-roll to selection start/end
Alt+Left/Right Arrow keys

Scrub (Jog)/Shuttle

Table 8. Scrub (Jog)/Shuttle Shortcuts
Task Shortcut
Temporary scrub mode when using Selector right mouse click - drag
Extend selection while scrubbing Shift-click - drag w/ Scrubber, (also in temporary
scrub mode)
Shuttle Alt-click-drag w/ Scrubber, (also in temporary scrub
mode)
Shuttle Lock Start+number key 1–9 (5 = real-time, 9 = max)
Change direction during Shuttle +/– (for example, Start+number+minus key)
Windows Keyboard Shortcuts for Pro Tools 6.9
5
Table 8. Scrub (Jog)/Shuttle Shortcuts
Task Shortcut
Shuttle Lock stop 0 (press number key to resume shuttle)
Exit Shuttle Lock mode Spacebar or Esc

Numeric Keypad Modes

Numeric Keypad Modes
Task Shortcut
Transport Modes
MIDI Metronome On/Off 7
MIDI Count On/Off 8
Merge Record On/Off 9
Loop Playback 4
Loop Record 5
QuickPunch Record 6
Rewind 1
Fast Forward 2
Record 3
Play/Stop 0
Shuttle Modes (TDM Systems Only)
1 X Forward 6
1 X Rewind 4
4 X Forward 9
4 X Rewind 7
1/4 X Forward 3
Windows Keyboard Shortcuts for Pro Tools 6.9
6
Numeric Keypad Modes
Task Shortcut
1/4 X Rewind 1
1/2 X Forward 5-6
1/2 X Rewind 5-4
2 X Forward 8-9
2 X Backward 8-7
1/16 X Forward 2-3
1/16 X Backward 2-1
Loop Playback of Edit Selection 0
Note: Choose Classic, Transpor t or Shuttle mode in Preferences > Operations tab.
Edit Selection Definition and Navigation
Table 9. Edit Selection, Definition and Navigation Shortcuts
Task Shortcut
Locate cursor to next region-boundary/sync point Tab
Locate cursor to previous region boundary/sync point
Go to and select next region Start+Tab
Go to and select previous region Start+Ctrl+Tab
Go to Song Start Start+Enter
Extend selection to Song Start Shift+Start+Enter
Extend selection to next region-boundary Shift+Tab
Extend selection to previous region-boundary Ctrl+Shift+Tab
Extend selection to include next region Star t+Shift+Tab
Extend selection to include previous region Start+Shift+Ctrl+Tab
Ctrl+Tab
Windows Keyboard Shortcuts for Pro Tools 6.9
7
Table 9. Edit Selection, Definition and Navigation Shortcuts
Task Shortcut
Return to start of session Enter
Go to end of session Ctrl+Enter
Extend selection to start of session Shift+Enter
Extend selection to end of session Ctrl+Shift+Enter
Set selection start/end during playback Down/Up Arrow keys
Set selection start/end to incoming time code while stopped
Select entire region in Edit window Double-click with Selector
Select entire track in Edit window Triple-click with Selector, or single-click in track and
Extend cursor across all tracks and create selection Alt-click in Rulers
Extend cursor or selection across all tracks Enable “All” Edit group (! key) and Shift–click on any
Bring selected region to the front Alt+Shift+F
Send selected region to the back Alt+Shift+B
Down/Up Arrow keys
press Ctrl+A
other track

Select Edit Tools and Modes

Table 10. Select Edit Tools and Modes Shor tcuts
Task Shortcut
Shuffle F1
Slip F2
Spot F3
Grid F4
Zoomer F5, or Ctrl+1 on QWERTY keyboard
Windows Keyboard Shortcuts for Pro Tools 6.9
8
Table 10. Select Edit Tools and Modes Shor tcuts
Task Shortcut
Trimmer F6 or Ctrl +2 on QWERTY keyboard
Selector F7 or Ctrl+3 on QWERTY keyboard
Grabber F8 or Ctrl+4 on QWERTY keyboard
Scrubber F9 or Ctrl+5 on QWERTY keyboard
Pencil F10 or Ctrl+6 on QWERTY keyboard
SmartTool (F6 & F7) or (F7 & F8) or Ctrl+7 on QWERTY keyboard
Cycle through Edit modes ‘ key
Cycle through Edit tools center mouse click (on two-button systems, press
the left and right mouse button simultaneously)

Editing, Nudging and Trimming

(+/– Key Usage is on Numeric Keypad Only)
Table 11. Editing, Navigation and Trimming Shortcuts
Task Shortcut
Change Grid value Start+Alt+“+/–”
Change Nudge value Ctrl+Alt+“+/–”
Nudge selection or region right/left by Nudge value +/–
Nudge data within current region to right/left by Nudge value (keeps region start/end and moves underlying audio)
Nudge left selection boundary right/left by Nudge value
Nudge right selection boundary right/left by Nudge value
Nudge back/forward by next Nudge value See “Miscellaneous” on page 22
Trim left edge of region to right/left by Nudge value Alt+“+/–”
Start+“+/–”
Alt+Shift+“+/–”
Ctrl+Shift+“+/–”
Windows Keyboard Shortcuts for Pro Tools 6.9
9
