1. Installation of Hardware
1. In order to be prepared for emergencies, completely cut off the power
connected to PC and auxiliary connection devices.
2. Open the PC case. Every manufacturer has the different shape and type
of PC cases.
3. Connect the RakerDV IEEE 1394 board on PCI slot.
Tighten up the screw to fix the bracket of board.
PCI Bus Slot
DV Board
4. Reassemble the PC case.
2. Installation of IEEE-1394 Driver
2.1 Installation of Driver for Windows 98 / 98SE / 2000 / ME
1. Turn on the PC power. When Windows is started, the new hardware is
automatically detected and the wizard dialogue to add new hardware is
displayed. Click “Next” button.
2. After selecting “Search the most adequate driver (recommended)”, click
“Next” button.
3. Windows will detect the location where the newly added hardware
driver is. Choose “CD-ROM Drive” and insert Windows CD-ROM. Then
click “Next” button.
4. Now installation of the selected driver is ready. Click “Next” button.
5. Copy the driver to be installed into PC.
6. Installation of IEEE-1394 driver is complete. Click “Finish” button.
2.2 How to Confirm the Installation of Driver for Windows’ 98 / 98SE /ME/
2000
Whether the IEEE-1394 driver is properly installed can be confirmed as
follows:
1. Click “Start-Setting(S)-Control Panel(C)” on the Window Taskbar.
2. Double click the system icon.
When the system preference dialogue appears, press “Device
Manager” tap, and double click “PCI OHCI Compatible IEEE 1394 Host
Controller” in “1394 Bus Controller” head.
3. If you confirm “Device is properly running.”, the installation of IEEE1394 Driver is perfectly done.
3. Installation of GreenEye camera Device Driver
For Windows 98/ 98SE / ME / 2000
l
Warning : Do not install GreenEye camera Driver to the computer already has
any other IEEE1394 PC camera Device Driver installed. GreenEye camera will
not be functional properly.
l
We recommend uninstallation of USB Camera Driver if it has been installed
before installation of GreenEye camera Deviece Driver.
1) Without connecting PC camera to PC, insert Drive CD into your CD-ROM
drive.
2) Then run “
3) Click "Next" on "Welcome to the InstallShield Wizard..." dialogue.
4) Click "Yes" on "License Agreement" dialogue.
5) Click "Next" on "Choose Destination Location" dialogue.
6) Click "Next" on "Select Program Folder" dialogue.
7) DC Connect 2.0 is copied to your PC.
8) After set-up, Click "Yes - Finish". Then the PC is restarted
automatically.
Note :
For Windows ME, a warning message may appears while installing, then
just click 'OK'.
DCConnect_21.exe".
And click "OK".
4. How to Confirm the Installation of Driver for Windows 98SE
/ ME
Whether the PC camera driver is properly installed can be confirmed as
follows:
1. Connect the PC camera to IEEE 1394 board
2. Click Start-Setting(S)-Control Panel(C) on the Window Taskbar.
3. Double click the system icon.
When the
and double click
head.
4. If you confirm ‘Device is properly running’, the installation of PC camera
System Properties
'TI DC1-680-1394Digital Camera'
Driver is perfectly done.
dialogue appears, press
Device Manager
in 'Imaging devices'
tap,
5. How to Confirm the Installation of Driver for Windows 2000
Whether the PC camera driver is properly installed can be confirmed as
follows:
1. Connect the PC camera to IEEE 1394 board
2. Click Start-Setting(S)-Control Panel(C) on the Window Taskbar.
3. Double click the system icon.
When the System Properties dialogue appears, press 'Hardware' tap, and
click 'Device Manager'. Then double click 'TI DC1-680-1394Digital
Camera'.
4. If you confirm ‘Device is properly running’, the installation of PC camera
Driver is perfectly done.
6. Viewing
After installation of DV board and DCconnect, connect the camera to the PC.
Click ' Start - Program(P) - DCconnect AmCap(camera)'
Then, a small AMCAP window will be appear.
To adjust the window size(640x480) and frame rate (30f/s),
click 'Option- Video Capture Pin... ' on the menu bar. Then select 'Y411' on
'Color Space/Compression' , Out put Size
Then click ‘apply’.
as 640x480 and
Frame Rate
as 30.
THIS DEVICE COMPLIES WITH PART 15 OF THE FCC RULES. OPERATION IS
SUBJECT TO THE FOLLOWING TWO CONDITIONS: (1) THIS DEVICE MAY NOT
CAUSE HARMFUL INTERFERENCE, AND (2) THIS DEVICE MUST ACCEPT ANY
INTERFERENCE RECEIVED, INCLUDING INTERFERENCE THAT MAY CAUSE
UNDESIRED OPERATION.
FCC RF INTERFERENCE STATEMENT
NOTE :
This equipment has been tested and found to comply with the limits for a
Class B digital device, pursuant to Part 15 of the FCC Rules. These limits
are designed to provide reasonable protection against harmful interference
in a residential installation.
This equipment generates, uses and can radiate radio frequency energy and,
if not installed and used in accordance with the instructions, may cause
harmful interference to radio communications. However, there is no
guarantee that interference will not occur in a particular installation.
If this equipment does cause harmful interference to radio or television
reception which can be determined by turning the equipment off and on,
the user is encouraged to try to correct the interference by one or more of
the following measures.
- Reorient or relocate the receiving antenna.
- Increase the separation between the equipment and receiver.
- Connect the equipment into an outlet on a circuit different from that to
which the receiver is connected.
- Consult the dealer or an experienced radio, TV technical for help.
- Only shielded interface cable should be used.
Finally, any changes or modifications to the equipment by the user not
expressly approved by the grantee or manufacturer could void the users
authority to operate such equipment,
