Pigtronix Keymaster User Manual

Pigtronixtm

Keymaster

User’s Guide

All contents © Absara Audio LLC 2010

Index:

Welcome…………………………………………………………

Anatomy of the Keymaster……………………………..…….

Notes. …………………………………………………………….

Limited Warranty……………………………………….…….…

Safety Precautions………………………….,.…………….…..

Welcome!

Thank you for entering the realm of Pigtronix. The Keymaster you now
possess is a universal analog signal converter that will allow you to
interface any audio source with instrument level “guitar” pedals and
return your signal back to the proper impedance on its way back out of
this crafty little box. The ability to run the loops in series or blend them in
parallel will lead to new sonic possibilities using the gear you already own.

As the name entails, Keymaster is designed to function in many situations:

On a pedal board it is a dual, true-bypass looper, giving you access to two
preset signal chains of pedals. Furthermore, you can mix the channels,
allowing for blended distortions with a crossfade via expression pedal and
out-of-this-world modulation combinations. The gain sections also serve as
line driver / pre-amp stages for your instrument.

In the studio, the Keymaster provides producers with a simple and
effective solution for ReAmp applications. The Keymaster converts
balanced, line level signals from the mixing desk to effects friendly levels
and then returns the signal back to balanced output or buffered ¼”
outputs for a guitar amp

For Stage Vocalists, DJs, Rappers, Beat Box and Horn the Keymaster finally
gives convenient on-stage access to the tools that guitarists use to define
their sound. Keymaster is the ideal solution for anyone who uses a mic on
stage, acting as a hub for getting your tone into effects and right back to
XLR for the soundman or to your own amp.
