PicoScope® 4000 Series (A API)

PC Oscilloscopes

Programmer's Guide

ps4000apg.en-7

PicoScope 4000 Series (A API) Programmer's Guide Contents

Contents

1 Welcome ................................................................................................................................... 7

2 Introduction .............................................................................................................................. 8

1 License agreement ......................................................................................................................................................... 8

2 Trademarks ....................................................................................................................................................................... 8

3 System requirements ..................................................................................................................................................... 9

4 Installation instructions ................................................................................................................................................. 9

3 Programming with the ps4000a API .................................................................................. 10

1 Driver ................................................................................................................................................................................ 10

2 Voltage ranges ............................................................................................................................................................... 11

3 Channel selection .......................................................................................................................................................... 11

4 Triggering ........................................................................................................................................................................ 12

5 Downsampling ............................................................................................................................................................... 13

6 Sampling modes ............................................................................................................................................................ 14

1 Block mode ....................................................................................................................................................... 15

2 Rapid block mode ............................................................................................................................................ 16

3 Streaming mode .............................................................................................................................................. 21

4 Retrieving stored data .................................................................................................................................... 23

7 Timebases ...................................................................................................................................................................... 24

8 Combining several oscilloscopes ............................................................................................................................. 24

9 Handling PicoConnect probe interactions ............................................................................................................... 26

4 API functions ......................................................................................................................... 27

1 ps4000aChangePowerSource() – handle dual-port USB powering .................................................................. 28

2 ps4000aCloseUnit() – close a scope device ......................................................................................................... 30

3 ps4000aCurrentPowerSource() – read current power source ........................................................................... 31

4 ps4000aEnumerateUnits() – find out how many units are connected ............................................................ 32

5 ps4000aFlashLed() – flash the front-panel LED ................................................................................................... 33

6 ps4000aGetAnalogueOffset() – find the allowable analog offset range ....................................................... 34

7 ps4000aGetChannelInformation() – find out if extra ranges available ........................................................... 35

8 ps4000aGetCommonModeOverflow() – find out which channels have overflowed ................................... 36

9 ps4000aGetDeviceResolution() – query the ADC resolution ............................................................................. 37

10 ps4000aGetMaxDownSampleRatio() – find out downsampling ratio for data ........................................... 38

11 ps4000aGetMaxSegments() – get maximum number of memory segments ............................................ 39

12 ps4000aGetMinimumTimebaseStateless() – query shortest timebase ...................................................... 40

13 ps4000aGetNoOfCaptures() – get number of rapid block captures ............................................................. 41

14 ps4000aGetNoOfProcessedCaptures() – get number of downsampled rapid block captures ............. 42

15 ps4000aGetStreamingLatestValues() – get streaming data while scope is running ............................... 43

16 ps4000aGetTimebase() – find out what timebases are available ................................................................. 44

17 ps4000aGetTimebase2() – find out what timebases are available .............................................................. 45

18 ps4000aGetTriggerTimeOffset() – read trigger timing adjustments (32-bit) ............................................. 46

PicoScope 4000 Series (A API) Programmer's Guide Contents

19 ps4000aGetTriggerTimeOffset64() – read trigger timing adjustments (64-bit) ......................................... 48

20 ps4000aGetUnitInfo() – read information about scope device ...................................................................... 49

21 ps4000aGetValues() – retrieve block-mode data .............................................................................................. 50

22 ps4000aGetValuesAsync() – retrieve block or streaming data ..................................................................... 52

23 ps4000aGetValuesBulk() – retrieve more than one waveform at a time ..................................................... 53

24 ps4000aGetValuesOverlapped() – retrieve data in overlapping blocks ........................................................ 55

1 Using the GetValuesOverlapped functions ............................................................................................... 56

25 ps4000aGetValuesOverlappedBulk() – retrieve overlapping data from multiple segments ................... 57

26 ps4000aGetValuesTriggerTimeOffsetBulk() – get trigger timing adjustments (multiple) ...................... 58

27 ps4000aGetValuesTriggerTimeOffsetBulk64() – get trigger timing adjustments (multiple) ................. 60

28 ps4000aIsLedFlashing() – read status of LED ................................................................................................... 61

29 ps4000aIsReady() – poll the driver in block mode ............................................................................................. 62

30 ps4000aIsTriggerOrPulseWidthQualifierEnabled() – find out whether trigger is enabled ....................... 63

31 ps4000aMaximumValue() – get maximum allowed sample value ................................................................ 64

32 ps4000aMemorySegments() – divide scope memory into segments .......................................................... 65

33 ps4000aMinimumValue() – get minimum allowed sample value .................................................................. 66

34 ps4000aNoOfStreamingValues() – get number of samples in streaming mode ....................................... 67

35 ps4000aNearestSampleIntervalStateless() – find nearest available sampling interval .......................... 68

36 ps4000aOpenUnit() – open a scope device ......................................................................................................... 69

37 ps4000aOpenUnitAsync() – open a scope device without waiting ............................................................... 70

38 ps4000aOpenUnitAsyncWithResolution() – open a flexible-resolution scope ........................................... 71

39 ps4000aOpenUnitProgress() – check progress of OpenUnit() call ............................................................... 72

40 ps4000aOpenUnitWithResolution() – open a flexible-resolution scope ....................................................... 73

41 ps4000aPingUnit() – check that unit is responding ........................................................................................... 74

42 ps4000aQueryOutputEdgeDetect() – query special trigger mode ................................................................. 75

43 ps4000aRunBlock() – start block mode ............................................................................................................... 76

44 ps4000aRunStreaming() – start streaming mode .............................................................................................. 78

45 ps4000aSetBandwidthFilter() – enable the bandwidth limiter ........................................................................ 80

46 ps4000aSetCalibrationPins() – set up the CAL output pins ............................................................................. 81

47 ps4000aSetChannel() – set up input channels ................................................................................................... 82

48 ps4000aSetDataBuffer() – register data buffer with driver ............................................................................. 84

49 ps4000aSetDataBuffers() – register min/max data buffers with driver ...................................................... 85

50 ps4000aSetDeviceResolution() – set up a FlexRes scope .............................................................................. 86

51 ps4000aSetEts() – set up equivalent-time sampling (ETS) ............................................................................. 87

52 ps4000aSetEtsTimeBuffer() – set up 64-bit buffer for ETS time data ......................................................... 88

53 ps4000aSetEtsTimeBuffers() – set up 32-bit buffers for ETS time data .................................................... 89

54 ps4000aSetNoOfCaptures() – set number of rapid block captures .............................................................. 90

55 ps4000aSetOutputEdgeDetect() – set special trigger mode .......................................................................... 91

56 ps4000aSetProbeInteractionCallback() – register callback function for PicoConnect events .............. 92

57 ps4000aSetPulseWidthQualifierConditions() – set up pulse width triggering ............................................ 93

58 ps4000aSetPulseWidthQualifierProperties() – set up pulse width triggering ............................................ 94

59 ps4000aSetSigGenArbitrary() – set up arbitrary waveform generator .......................................................... 95

1 AWG index modes ........................................................................................................................................... 98

PicoScope 4000 Series (A API) Programmer's Guide Contents

2 Calculating deltaPhase .................................................................................................................................. 98

60 ps4000aSetSigGenBuiltIn() – set up function generator ............................................................................... 100

61 ps4000aSetSigGenPropertiesArbitrary() – set up arbitrary waveform generator .................................... 102

62 ps4000aSetSigGenPropertiesBuiltIn() – set up function generator ............................................................ 103

63 ps4000aSetSimpleTrigger() – set up level triggers only ................................................................................ 104

64 ps4000aSetTriggerChannelConditions() – specify which channels to trigger on ................................... 105

1 PS4000A_CONDITION structure ............................................................................................................... 106

65 ps4000aSetTriggerChannelDirections() – set up signal polarities for triggering ..................................... 107

1 PS4000A_DIRECTION structure ................................................................................................................ 108

66 ps4000aSetTriggerChannelProperties() – set up trigger thresholds .......................................................... 109

1 PS4000A_TRIGGER_CHANNEL_PROPERTIES structure .................................................................... 110

67 ps4000aSetTriggerDelay() – set up post-trigger delay ................................................................................... 112

68 ps4000aSigGenArbitraryMinMaxValues() – get AWG sample value limits ............................................... 113

69 ps4000aSigGenFrequencyToPhase() – get phase increment for signal generator ................................ 114

70 ps4000aSigGenSoftwareControl() – trigger the signal generator ................................................................ 115

71 ps4000aStop() – stop data capture ..................................................................................................................... 116

72 Callback functions ................................................................................................................................................... 117

1 ps4000aBlockReady() – receive notification when block-mode data ready ................................. 117

2 ps4000aDataReady() – indicate when post-collection data ready .................................................. 118

3 ps4000aProbeInteractions() – callback for PicoConnect probe events ........................................ 119

4 ps4000aStreamingReady() – indicate when streaming-mode data ready ..................................... 121

73 Wrapper functions .................................................................................................................................................... 122

1 Streaming mode ............................................................................................................................................ 122

2 Advanced triggers ......................................................................................................................................... 123

3 Probe interactions ......................................................................................................................................... 123

5 Reference ............................................................................................................................. 125

1 Driver status codes .................................................................................................................................................... 125

2 Enumerated types and constants ........................................................................................................................... 125

3 Numeric data types .................................................................................................................................................... 125

4 Glossary ........................................................................................................................................................................ 125

Index ......................................................................................................................................... 127

PicoScope 4000 Series (A API) Programmer's Guide

Welcome

1 Welcome

The PicoScope 4444, 4824 and 4000A Series of PC Oscilloscopes from Pico Technology are compact, high-resolution scope units designed to replace traditional benchtop oscilloscopes.

This Programmer's Guide explains how to use the ps4000a API, the Application Programming Interface for the PicoScope 4000 Series (A API) and PicoScope 4000A Series oscilloscopes. The ps4000a API supports the following models:

PicoScope 4444 4-channel differential oscilloscope (product web page)

PicoScope 4824 8-channel oscilloscope (product web page)

PicoScope 4224A 2-channel oscilloscope (product web page)

PicoScope 4424A 4-channel oscilloscope (product web page)

PicoScope 4824A 8-channel oscilloscope (product web page)

Other oscilloscopes in the PicoScope 4000 Series use an older API called ps4000. This is documented in the original PicoScope 4000 Series Programmer's Guide.

PicoScope 4000 Series (A API) Programmer's Guide

Introduction

2 Introduction

2.1 License agreement

The material contained in this release is licensed, not sold. Pico Technology Ltd grants a license to the person who installs this software, subject to the conditions listed below.

Access. The licensee agrees to allow access to this software only to persons who have been informed of these conditions and agree to abide by them.

Usage. The software in this release is for use only with Pico products or with data collected using Pico products.

documents, etc.) except the example programs. You may copy and distribute SDK files without restriction, as long as you do not remove any Pico Technology copyright statements. The example programs may be modified, copied and distributed for the purpose of developing programs to collect data using Pico products.

Liability. Pico Technology and its agents shall not be liable for any loss, damage or injury, howsoever caused, related to the use of Pico Technology equipment or software, unless excluded by statute.

Fitness for purpose. As no two applications are the same, Pico Technology cannot guarantee that its equipment or software is suitable for a given application. It is your responsibility, therefore, to ensure that the product is suitable for your application.

Mission-critical applications. This software is intended for use on a computer that may be running other software products. For this reason, one of the conditions of the license is that it excludes use in mission-critical applications, for example life support systems.

Viruses. This software was continuously monitored for viruses during production, but you are responsible for virus-checking the software once it is installed.

Support. If you are dissatisfied with the performance of this software, please contact our technical support staff, who will try to fix the problem within a reasonable time. If you are still dissatisfied, please return the product and software to your supplier within 14 days of purchase for a full refund.

Upgrades. We provide upgrades, free of charge, from our website at www.picotech.com. We reserve the right to charge for updates or replacements sent out on physical media.

2.2 Trademarks

Pico Technology, PicoScope and PicoConnect are trademarks of Pico Technology Ltd, registered in the United Kingdom and other countries.

PicoScope and Pico Technology are registered in the U.S. Patent and Trademark Office.

Windows, Excel and Visual Basic for Applications are registered trademarks or trademarks of Microsoft

Corporation in the USA and other countries. LabVIEW is a registered trademark of National Instruments Corporation. MATLAB is a registered trademark of The MathWorks, Inc.

PicoScope 4000 Series (A API) Programmer's Guide

Item

Specification

Operating system

Windows 7, 8.1 or 10 (32-bit and 64-bit versions) Linux and macOS, 64-bit versions only: see picotech.com/downloads for supported versions

Processor Memory Free disk space

As required by the operating system

Ports

USB 3.0 or USB 2.0 port(s)

Introduction

2.3 System requirements

To ensure that your PicoScope operates correctly, you must have a computer with at least the minimum system requirements to run one of the supported operating systems, as shown in the following table. The performance of the oscilloscope will be better with a more powerful PC, and will benefit from a multicore processor.

USB

The ps4000a driver offers three different methods of recording data, all of which support USB 2.0 and USB 3.0. The fastest transfer rates between the PC and the PicoScope device are achieved using USB 3.0.

2.4 Installation instructions

The PicoSDK installation process varies depending on your operating system. Software and installation instructions are available from picotech.com/downloads.

Windows users

Visit picotech.com/downloads, select your oscilloscope from the list and download the latest PicoSDK installer, choosing either the 32-bit or 64-bit version depending on your operating system and software development environment.

macOS users

If you have already installed PicoScope 6 Beta for macOS, you already have all the drivers installed. If not, visit

picotech.com/downloads, select your oscilloscope from the list and download and install the latest version.

Linux users

Visit Linux Software & Drivers for Oscilloscopes and Data Loggers for full instructions.

PicoScope 4000 Series (A API) Programmer's Guide

Programming with the ps4000a API

3 Programming with the ps4000a API

The ps4000a.dll dynamic link library in the lib subdirectory of your SDK installation allows you to program a

PicoScope 4000 Series (A API) oscilloscope using standard C function calls.

A typical program for capturing data consists of the following steps:

Open the scope unit.

Set up the input channels with the required voltage ranges and coupling mode.

Set up triggering.

Start capturing data. (See Sampling modes, where programming is discussed in more detail.)

Wait until the scope unit is ready.

Stop capturing data.

Copy data to a buffer.

Close the scope unit.

Numerous example programs are available on the "picotech" GitHub pages. These show how to use the functions of the driver software in each of the modes available.

3.1 Driver

Microsoft Windows

Your application will communicate with a PicoScope 4000 Series library called ps4000a.dll, which is supplied in 32-bit and 64-bit versions. The DLL exports the ps4000a function definitions in stdcall format, which is compatible with a wide range of programming languages.

ps4000a.dll driver depends on another DLL, picoipp.dll (which is supplied in 32-bit and 64-bit versions)

and a low-level driver called WinUsb.sys (or CyUsb3.sys on Windows 7). These are installed by PicoSDK and configured when you plug the oscilloscope into each USB port for the first time. Your application does not call these drivers directly.

Linux and macOS

Please see the Downloads section of picotech.com for instructions on downloading the drivers for these operating systems. The drivers use the cdecl calling convention. Linux libraries and dependencies are distributed via our package repositories. macOS libraries and dependencies are distributed with PicoScope 6 for

macOS.

PicoScope 4000 Series (A API) Programmer's Guide

Function

Reading

Voltage

decimal

hex

ps4000aMinimumValue()

–32 767

8001

minimum

N/A

0000

zero

ps4000aMaximumValue()

+32 767

7FFF

maximum

1. Call ps4000aSetChannel() with range set to

PS4000A_1V.

2. Apply a sine wave input of 500 mV amplitude to the oscilloscope.

3. Capture some data using the desired sampling mode.

4. The data will be encoded as shown opposite.

DC coupling:

The scope accepts all input frequencies from zero (DC) up to its maximum analog bandwidth.

AC coupling:

The scope accepts input frequencies from a few hertz up to its maximum analog bandwidth. The lower –3 dB cutoff frequency is about 1 Hz.

Programming with the ps4000a API

3.2 Voltage ranges

ps4000aSetChannel() allows you to set the voltage range of each input channel of the scope. The allowable

voltage ranges are described in the device data sheet. Each sample is normalized to 16 bits, and the minimum and maximum values returned to your application are given by ps4000aMinimumValue() and

ps4000aMaximumValue() as follows:

Example

3.3 Channel selection

You can switch each channel on and off, and set its coupling mode to either AC or DC, using the

ps4000aSetChannel() function.

PicoScope 4000 Series (A API) Programmer's Guide

Programming with the ps4000a API

3.4 Triggering

PicoScope 4000 Series PC Oscilloscopes can either start collecting data immediately, or be programmed to wait for a trigger event to occur. In both cases you need to use the PicoScope 4000 trigger functions:

ps4000aSetTriggerChannelConditions() – specifies which channels are included in the trigger

logic

ps4000aSetTriggerChannelDirections() – specifies the edge or threshold to be used for each

channel

ps4000aSetTriggerChannelProperties() – specifies threshold levels, level or window mode, and

global trigger timeout

ps4000aSetTriggerDelay() – defines post-trigger delay (optional)

Alternatively, the above functions can be run in a single operation by calling ps4000aSetSimpleTrigger().

A trigger event can occur when one of the input channels crosses a threshold voltage on either a rising or a falling edge. It is also possible to combine up to four inputs by defining multiple trigger conditions.

The driver supports these triggering methods:

Simple Edge

Advanced Edge

Windowing

Pulse width

Logic

Delay

Drop-out

Runt

The pulse width, delay and drop-out triggering methods additionally require the use of the pulse width qualifier functions:

ps4000aSetPulseWidthQualifierConditions()

ps4000aSetPulseWidthQualifierProperties()

PicoScope 4000 Series (A API) Programmer's Guide

Programming with the ps4000a API

3.5 Downsampling

The driver can optionally apply a data reduction, or downsampling, process before returning data to the application. Downsampling is done by firmware on the device and is generally faster than using the PC's own

processor. You instruct the driver to downsample by passing a downSampleRatioMode argument to one of the data-retrieval functions such as ps4000aGetValues(). You must also pass in an argument called

downSampleRatio: how many raw samples are to be combined into each processed sample.

Retrieving multiple types of downsampled data

You can optionally retrieve data using more than one downsampling mode with a single call to

ps4000aGetValues(). Set up a buffer for each downsampling mode by calling ps4000aSetDataBuffer(). Then, when calling ps4000aGetValues(), set downSampleRatioMode to

the bitwise OR of the required downsampling modes.

Retrieving both raw and downsampled data

You cannot retrieve raw data and downsampled data in a single operation. If you require both raw and downsampled data, first retrieve the downsampled data as described above and then continue as follows:

1. Call ps4000aStop().

2. Set up a data buffer for each channel using ps4000aSetDataBuffer() with the ratio mode set to

PS4000A_RATIO_MODE_NONE.

3. Call ps4000aGetValues() to retrieve the data.

Downsampling modes

The available downsampling modes are:

PS4000A_RATIO_MODE_NONE (0)

No downsampling is performed. The downSampleRatio parameter is ignored.

PS4000A_RATIO_MODE_AGGREGATE (1)

The aggregate method generates two buffers of data for every channel, one containing the minimum sample value for every block of downSampleRatio raw samples, and the other containing the maximum value.

PS4000A_RATIO_MODE_DECIMATE (2)

The decimate method returns the first sample in every block of downSampleRatio successive samples and discards all the other samples.

PS4000A_RATIO_MODE_AVERAGE (4)

The average method returns the sum of all the samples in each block of downSampleRatio samples, divided by the length of the block.

PS4000A_RATIO_MODE_DISTRIBUTION (8)

Reserved for future use.

PicoScope 4000 Series (A API) Programmer's Guide

Programming with the ps4000a API

3.6 Sampling modes

The PicoScope 4000 Series PC Oscilloscopes can run in various sampling modes.

Block mode. In this mode, the scope stores data in internal buffer memory and then transfers it to the PC.

When the data has been collected it is possible to examine the data, with an optional downsampling factor. The data is lost when a new run is started in the same segment, the settings are changed, or the scope is powered down.

Rapid block mode. This is a variant of block mode that allows you to capture more than one waveform at a

time with a minimum of delay between captures. You can use downsampling in this mode if you wish.

Streaming mode. In this mode, data is passed directly to the PC without being stored in the scope's internal

buffer memory. This enables long periods of slow data collection for chart recorder and data-logging applications. Streaming mode provides fast streaming at up to 160 MS/s with a USB 3.0 connection. Downsampling and triggering are supported in this mode.

Data callbacks

In all sampling modes, the driver returns data asynchronously using a callback. This is a call to one of the functions in your own application. When you request data from the scope, you pass to the driver a pointer to your callback function. When the driver has written the data to your buffer, it makes a callback (calls your function) to signal that the data is ready. The callback function then signals to the application that the data is available.

Because the callback is called asynchronously from the rest of your application, in a separate thread, you must ensure that it does not corrupt any global variables while it runs.

In block mode, you can alternatively poll the driver instead of using a callback.

Most of the callback functions have a PICO_STATUS parameter. The driver sends this value to the callback function to indicate the success or otherwise of the data capture.

Probe callback

The driver can be instructed to signal to your application whenever a probe connection event occurs. It does this using a callback to a function that you define. See Handling PicoConnect probe interactions.

PicoScope 4000 Series (A API) Programmer's Guide

Programming with the ps4000a API

3.6.1 Block mode

In block mode, the computer prompts a PicoScope 4000 Series PC Oscilloscope to collect a block of data into its internal memory. When the oscilloscope has collected the whole block, it signals that it is ready and then transfers the whole block to the computer's memory through the USB port.

Block size. The maximum number of values depends upon the size of the oscilloscope's memory. The memory buffer is shared between the enabled channels, so if two channels are enabled, each is allocated half the memory. These features are handled transparently by the driver. The block size also depends on the

number of memory segments in use (see ps4000aMemorySegments()).

Sampling rate. The maximum real-time sampling rate may depend on the number of channels enabled. See the data sheet for your scope model. You specify the sampling rate by passing a timebase number (see

Timebases) to ps4000aRunBlock().

Setup time. The driver normally performs a number of setup operations, which can take up to 50 milliseconds, before collecting each block of data. If you need to collect data with the minimum time interval between

blocks, use rapid block mode and avoid calling setup functions between calls to ps4000aRunBlock(),

ps4000aStop() and ps4000aGetValues().

Downsampling. When the data has been collected, you can set an optional downsampling factor and examine the data. Downsampling is the process of reducing the amount of data by combining adjacent samples using one of several algorithms. It is useful for zooming in and out of the data without having to repeatedly transfer the entire contents of the scope's buffer to the PC.

Memory segmentation. The scope's internal memory can be divided into segments so that you can capture several waveforms in succession. Configure this using ps4000aMemorySegments().

Data retention. The data is lost when a new run is started in the same segment, the number of segments is changed, or the scope is powered down.

3.6.1.1 Using block mode

This is the general procedure for reading and displaying data in block mode using a single memory segment:

1. Open the oscilloscope using ps4000aOpenUnit(). 1a. (PicoScope 4444 only) Register your probe interaction callback function using

ps4000aSetProbeInteractionCallback().

2. Select channel ranges and AC/DC coupling using ps4000aSetChannel().

3. Using ps4000aGetTimebase(), select timebases until the required nanoseconds per sample is located.

4. Use the trigger setup functions ps4000aSetTriggerChannelConditions(),

ps4000aSetTriggerChannelDirections(), ps4000aSetTriggerChannelProperties()

and ps4000aSetTriggerDelay() to set up the trigger if required.

5. Start the oscilloscope running using ps4000aRunBlock().

6. Wait until the oscilloscope is ready using the ps4000aBlockReady() callback.

7. Use ps4000aSetDataBuffer() to tell the driver where your memory buffer is. For greater efficiency when doing multiple captures, you can call this function outside the loop, after step 4.

8. Transfer the block of data from the oscilloscope using ps4000aGetValues().

9. Display the data.

10. Repeat steps 5 to 9.

11. Stop the oscilloscope using ps4000aStop().

12. Request new views of stored data using different downsampling parameters: see Retrieving stored data.

13. Close the device using ps4000aCloseUnit().

PicoScope 4000 Series (A API) Programmer's Guide

Note that if you use ps4000aGetValues() or ps4000aStop() before the oscilloscope is ready, no capture will be available and the driver will return PICO_NO_SAMPLES_AVAILABLE.

Programming with the ps4000a API

3.6.1.2 Asynchronous calls in block mode

ps4000aGetValues() function may take a long time to complete if a large amount of data is being collected.

To avoid hanging the calling thread, it is possible to call ps4000aGetValuesAsync() instead. This immediately returns control to the calling thread, which then has the option of waiting for the data or calling

ps4000aStop() to abort the operation.

3.6.2 Rapid block mode

In normal block mode, the PicoScope 4000 Series scopes collect one waveform at a time. You start the the device running, wait until all samples are collected by the device, and then download the data to the PC or start another run. There is a time overhead of tens of milliseconds associated with starting a run, causing a gap between waveforms. When you collect data from the device, there is another minimum time overhead which is most noticeable when using a small number of samples.

Rapid block mode allows you to sample several waveforms at a time with the minimum time between waveforms. On the PicoScope 4824, for example, it reduces the gap from milliseconds to about 2.5 µs.

3.6.2.1 Using rapid block mode

You can use rapid block mode with or without downsampling.

Without downsampling

1. Open the oscilloscope using ps4000aOpenUnit().

1a. (PicoScope 4444 only) Register your probe interaction callback function using

ps4000aSetProbeInteractionCallback().

2. Select channel ranges and AC/DC coupling using ps4000aSetChannel().

3. Set the number of memory segments equal to or greater than the number of captures required using

ps4000aMemorySegments(). Use ps4000aSetNoOfCaptures() before each run to specify the

number of waveforms to capture.

PicoScope 4000 Series (A API) Programmer's Guide

Programming with the ps4000a API

4. Using ps4000aGetTimebase(), select timebases until the required nanoseconds per sample is located. This will indicate the number of samples per channel available for each segment. If you know that the number of samples per segment will not exceed the limit, you can call this function after step 2.

5. Use the trigger setup functions ps4000aSetTriggerChannelConditions(),

ps4000aSetTriggerChannelDirections(), ps4000aSetTriggerChannelProperties()

and ps4000aSetTriggerDelay() to set up the trigger if required.

6. Start the oscilloscope running using ps4000aRunBlock(). You can call

ps4000aGetNoOfCaptures() while capturing is in progress to obtain a count of the number of

waveforms captured. Once all the waveforms have been captured, but ready is not complete, call

ps4000aGetNoOfProcessedCaptures() to obtain the number of captures processed on the PC.

7. Wait until the oscilloscope is ready using the ps4000aBlockReady() callback.

8. Use ps4000aSetDataBuffer() to tell the driver where your memory buffers are. Call the function once for each channel/segment combination for which you require data. For greater efficiency when doing multiple captures, you can call this function outside the loop, after step 5.

9. Transfer the blocks of data from the oscilloscope using ps4000aGetValuesBulk().

10. Retrieve the time offset for each data segment using

ps4000aGetValuesTriggerTimeOffsetBulk64().

11. Display the data.

12. Repeat steps 6 to 11 if necessary.

13. Stop the oscilloscope using ps4000aStop().

14. Close the device using ps4000aCloseUnit().

With downsampling

To use rapid block mode with downsampling (in aggregation mode), follow steps 1 to 7 above and then proceed as follows:

8a. Call ps4000aSetDataBuffers() to set up one pair of buffers for every waveform segment required. 9a. Call ps4000aGetValues() for each pair of buffers. 10a. Retrieve the time offset for each data segment using ps4000aGetTriggerTimeOffset64().

Continue from step 11 above.

PicoScope 4000 Series (A API) Programmer's Guide

Programming with the ps4000a API

3.6.2.2 Rapid block mode example 1: no aggregation

#define MAX_WAVEFORMS 100 #define MAX_SAMPLES 1000

Set up the device as usual:

Open the device

Channels

Trigger

Number of memory segments (this should be equal or more than the number of captures required)

// Set the number of waveforms to MAX_WAVEFORMS

ps4000aSetNoOfCaptures(handle, MAX_WAVEFORMS);

pParameter = false;

ps4000aRunBlock

(

handle, 0, // noOfPreTriggerSamples 10000, // noOfPostTriggerSamples 1, // timebase to be used &timeIndisposedMs, // calculated duration of capture 0, // segmentIndex lpReady, &pParameter

);

Get number of captures. Call ps4000aGetNoOfCaptures() to find out the number of captures taken by the device. This is particularly useful if a trigger is being used.

Comment: these variables have been set as an example and can be any valid value. pParameter will be set true by your callback function lpReady.

while (!pParameter) Sleep (0);

int16_t buffer[PS4000A_MAX_CHANNELS][MAX_WAVEFORMS][MAX_SAMPLES];

for (int32_t i = 0; i < 20; i++) {

for (int32_t c = PS4000A_CHANNEL_A; c <= PS4000A_CHANNEL_H; c++) {

ps4000aSetDataBuffer

(

handle, c, buffer[c][i], MAX_SAMPLES, i, PS4000A_RATIO_MODE_NONE

);

}

PicoScope 4000 Series (A API) Programmer's Guide

Programming with the ps4000a API

Comments: buffer has been created as a three-dimensional 16-bit integer array, which will contain 1000 samples as defined by MAX_SAMPLES. There are only 20 buffers set, but it is possible to set up to the number of captures you have requested.

ps4000aGetValuesBulk

(

handle, &noOfSamples, 10, // fromSegmentIndex 19, // toSegmentIndex 1, // downSampleRatio PS4000A_RATIO_MODE_NONE, // downSampleRatioMode overflow // indices 10 to 19 will be populated

)

Comments: the number of samples could be up to noOfPreTriggerSamples +

noOfPostTriggerSamples, the values set in ps4000aRunBlock(). The samples are always returned from

the first sample taken, unlike the ps4000aGetValues() function which allows the sample index to be set. This function does not support downsampling. The above segments start at 10 and finish at 19 inclusive. It is possible for the fromSegmentIndex to wrap around to the toSegementIndex, by setting the

fromSegmentIndex to 98 and the toSegmentIndex to 7.

ps4000aGetValuesTriggerTimeOffsetBulk64

(

handle, times, // indices 10 to 19 will be populated timeUnits, // indices 10 to 19 will be populated 10, // fromSegmentIndex, inclusive 19 // toSegmentIndex, inclusive

)

Comments: the above segments start at 10 and finish at 19 inclusive. It is possible for the fromSegmentIndex to wrap around to the toSegmentIndex, if the fromSegmentIndex is set to 98 and the toSegmentIndex

to 7.

PicoScope 4000 Series (A API) Programmer's Guide

Programming with the ps4000a API

3.6.2.3 Rapid block mode example 2: using aggregation

#define MAX_WAVEFORMS 100 #define MAX_SAMPLES 1000

Set up the device as usual:

Open the device

Channels

Trigger

Number of memory segments (this should be equal or more than the number of captures required)

// Set the number of waveforms to MAX_WAVEFORMS

ps4000aSetNoOfCaptures(handle, MAX_WAVEFORMS);

pParameter = false;

ps4000aRunBlock

(

handle, 0, // noOfPreTriggerSamples 1000000, // noOfPostTriggerSamples 1, // timebase to be used &timeIndisposedMs, // calculated duration of capture 1, // segmentIndex lpReady, &pParameter

);

Get number of captures. Call ps4000aGetNoOfCaptures() to find out the number of captures taken by the device. This is particularly useful if a trigger is being used.

Comments: the set-up for running the device is exactly the same whether or not you use downsampling when you retrieve the samples.

for (int32_t segment = 10; segment < 20; segment++) {

for (int32_t c = PS4000A_CHANNEL_A; c <= PS4000A_CHANNEL_H; c++) {

ps4000aSetDataBuffers

(

handle, c, bufferMax[c], bufferMin[c] MAX_SAMPLES, segment, downSampleRatioMode // set to RATIO_MODE_AGGREGATE

);

}

ps4000aGetValues

(

handle, 0,

PicoScope 4000 Series (A API) Programmer's Guide

&noOfSamples, // set to MAX_SAMPLES on entering 1000, downSampleRatioMode, // set to RATIO_MODE_AGGREGATE segment, overflow

);

ps4000aGetTriggerTimeOffset64

(

handle, &time, &timeUnits, segment

)

}

Comments: each waveform is retrieved one at a time from the driver, with an aggregation of 1000. Since only one waveform will be retrieved at a time, you only need to set up one pair of buffers: one for the maximum samples and one for the minimum samples. Again, the buffer sizes are 1000 samples.

Programming with the ps4000a API

3.6.3 Streaming mode

Streaming mode can capture data without the gaps that occur between blocks when using block mode. It can transfer data to the PC at speeds of up to 160 MS/s for the PicoScope 4824 and 4000A Series, or up to 100 MS/s for the PicoScope 4444, depending on the computer's performance. This makes it suitable for high-speed data

acquisition, allowing you to capture long data sets limited only by the computer's memory.

Downsampling

The driver returns downsampled readings while the device is streaming. If the downsampling ratio is set to 1, only one buffer is returned per channel. When the downsampling ratio is greater than 1 and aggregation mode is selected, two buffers (maximum and minimum) per channel are returned.

PicoScope 4000 Series (A API) Programmer's Guide

Programming with the ps4000a API

3.6.3.1 Using streaming mode

This is the general procedure for reading and displaying data in streaming mode:

1. Open the oscilloscope using ps4000aOpenUnit().

1a. (PicoScope 4444 only) Register your probe interaction callback function using

ps4000aSetProbeInteractionCallback().

2. Select channels, ranges and AC/DC coupling using ps4000aSetChannel().

3. Use the trigger setup functions

[1] [2] [3]

4. Call ps4000aSetDataBuffer() to tell the driver where your data buffer is.

5. Set up downsampling and start the oscilloscope running using ps4000aRunStreaming().

6. Call ps4000aGetStreamingLatestValues() to get data.

7. Process data returned to your application's function. This example is using autoStop, so after the driver

has received all the data points requested by the application, it stops the device streaming.

8. Call ps4000aStop(), even if autoStop is enabled.

9. Request new views of stored data using different downsampling parameters: see Retrieving stored data.

10 Close the device using ps4000aCloseUnit().

[4]

to set up the trigger if required.

PicoScope 4000 Series (A API) Programmer's Guide

Programming with the ps4000a API

3.6.4 Retrieving stored data

You can collect data from the ps4000a driver with a different downsampling factor when

ps4000aRunBlock() or ps4000aRunStreaming() has already been called and has successfully captured

all the data. Use ps4000aGetValuesAsync().

PicoScope 4000 Series (A API) Programmer's Guide

Timebase (n)

Sampling interval (tS)

= 2.5 ns x 2

Sampling frequency (fS)

= 400 MHz / (n+1)

0 *

2.5 ns

400 MHz

1 *

5 ns

200 MHz

2 *

10 ns

100 MHz

20 ns

50 MHz

= 20 ns x (n–2)

= 50 MHz / (n–2)

40 ns

25 MHz

...

232–1

~ 11 s

~ 93 mHz

Timebase (n)

Sampling interval (tS)

= 12.5 ns × (n+1)

Sampling frequency (fS)

= 80 MHz / (n+1)

12.5 ns

80 MHz

25 ns

40 MHz

...

232–1

~54 s

~18.6 mHz

Programming with the ps4000a API

3.7 Timebases

The ps4000a API allows you to select any of 232 different timebases created by dividing the oscilloscope's master sampling clock. The timebases allow slow enough sampling in block mode to overlap the streaming sample intervals, so that you can make a smooth transition between block mode and streaming mode. Calculate the timebase using ps4000aGetTimebase() or refer to the following tables:

PicoScope 4444

* 12-bit sampling mode only

PicoScope 4824 and 4000A Series

Notes

1. The maximum possible sampling rate may depend on the number of enabled channels and (for flexible-

resolution scopes) the selected ADC resolution. Refer to the data sheet for details.

2. In streaming mode, the maximum possible sampling rate may be limited by the speed of the USB interface.

3.8 Combining several oscilloscopes

It is possible to collect data using up to 64 PicoScope 4000 Series PC Oscilloscopes at the same time, depending on the capabilities of the PC. Each oscilloscope must be connected to a separate USB port.

ps4000aOpenUnit() returns a handle to an oscilloscope. All the other functions require this handle for

oscilloscope identification. For example, to collect data from two oscilloscopes at the same time:

CALLBACK ps4000aBlockReady(...) // Define callback function specific to application

handle1 = ps4000aOpenUnit() handle2 = ps4000aOpenUnit()

ps4000aSetChannel(handle1) // set up unit 1 ps4000aRunBlock(handle1)

ps4000aSetChannel(handle2) // set up unit 2 ps4000aRunBlock(handle2)

// Data will be stored in buffers

PicoScope 4000 Series (A API) Programmer's Guide

Programming with the ps4000a API

// and application will be notified using callback.

ready = FALSE while not ready

ready = handle1_ready ready &= handle2_ready

ps4000aCloseUnit(handle1) ps4000aCloseUnit(handle2)

Note: It is not possible to synchronize the collection of data between oscilloscopes that are being used in combination.

PicoScope 4000 Series (A API) Programmer's Guide

Applicability

PicoScope 4444 only

Note

In addition to ps4000aApi.h, you must also include PicoConnectProbes.h. This file contains definitions of enumerated types that describe the PicoConnect probes.

Programming with the ps4000a API

3.9 Handling PicoConnect probe interactions

The PicoScope 4444 has a PicoConnect™ intelligent probe interface. This interface supplies power to the probe as well as allowing the scope to configure and interrogate the probe. Your application can choose to be alerted whenever a probe is connected or disconnected, or when its status changes.

Probe interactions use a callback mechanism, available in C and similar languages. For languages that do not support callbacks, use the wrapper functions provided.

Procedure

1. Define your own function to receive probe interaction callbacks.

2. Call ps4000aOpenUnit() to obtain a device handle.

3. Call ps4000aSetProbeInteractionCallback() to register your probe interaction callback function.

4. Capture data using the desired sampling mode. See Sampling modes for details.

5. Call ps4000aCloseUnit() to release the device handle. The makes the scope device available to other

applications.

PicoScope 4000 Series (A API) Programmer's Guide

API functions

4 API functions

The ps4000a API exports the following functions for you to use in your own applications. All functions are C functions using the standard call naming convention (__stdcall). They are all exported with both decorated

and undecorated names.

PicoScope 4000 Series (A API) Programmer's Guide

Applicability

All modes

Arguments

handle, identifier for the scope device.

powerstate, the required state of the unit.

USB 3.0 devices

Set to one of:

PICO_POWER_SUPPLY_CONNECTED

– to use power from the external power supply

PICO_POWER_SUPPLY_NOT_CONNECTED

– to use power from the USB port

PICO_USB3_0_DEVICE_NON_USB3_0_PORT

– to use power from a non-USB 3.0 port

API functions

4.1 ps4000aChangePowerSource() – handle dual-port

USB powering

PICO_STATUS ps4000aChangePowerSource

(

int16_t handle, PICO_STATUS powerstate

)

This function selects the power supply mode.

Whenever the power supply mode is changed, all data and settings in the scope device are lost. You must then reconfigure the device before restarting capture.

PicoScope 4444 only

The PicoScope 4444 can use DC power from either a USB 2.0 or a USB 3.0 port. USB 3.0 might be needed if the probes connected draw enough supply current. If another function returns

PICO_PROBE_POWER_DC_POWER_SUPPLY_REQUIRED or PICO_PROBE_NOT_POWERED_WITH_DC_POWER_SUPPLY, you must call this function to change to the correct

power source.

The PicoScope 4444 returns PICO_POWER_SUPPLY_NOT_CONNECTED if the DC power supply is not connected.

All USB 3.0 devices (PicoScope 4824 and 4000A Series)

When the device is plugged into a non-USB 3.0 port, it requires a two-stage power-up sequence. You must call this function if any of the following conditions arises:

USB power is required.

The power supply is connected or disconnected during use.

A 2-channel USB 3.0 scope is plugged into a USB 2.0 port (indicated if any function returns the

PICO_USB3_0_DEVICE_NON_USB3_0_PORT status code).

If you receive the PICO_USB3_0_DEVICE_NON_USB3_0_PORT status code from one of the

ps4000aOpenUnit…() functions (ps4000aOpenUnit(), ps4000aOpenUnitWithResolution(),

ps4000aOpenUnitAsync() or ps4000aOpenUnitProgress()), you must then call

ps4000aChangePowerSource() to switch the device into non-USB 3.0-power mode.

Note. The PicoScope 4824 and 4000A Series have two power supply options:

1. To power them from a USB 3.0 port, use the USB 3.0 cable supplied.

2. To power them from a non-USB 3.0 port, use a double-headed USB 2.0 cable (available separately) and plug it

into two USB 2.0 ports on the host machine.

PicoScope 4000 Series (A API) Programmer's Guide

USB 2.0 devices

Set to one of:

PICO_PROBE_POWER_DC_POWER_SUPPLY_REQUIRED

– to use external DC power

PICO_PROBE_NOT_POWERED_WITH_DC_POWER_SUPPLY

– to use USB power

Returns

PICO_OK PICO_POWER_SUPPLY_REQUEST_INVALID PICO_INVALID_PARAMETER PICO_NOT_RESPONDING PICO_INVALID_HANDLE PICO_PROBE_POWER_DC_POWER_SUPPLY_REQUIRED PICO_PROBE_NOT_POWERED_WITH_DC_POWER_SUPPLY PICO_DRIVER_FUNCTION PICO_FPGA_FAIL PICO_INTERNAL_ERROR PICO_MEMORY PICO_NOT_RESPONDING PICO_PROBE_CONFIG_FAILURE PICO_RESOURCE_ERROR PICO_TIMEOUT PICO_RESOURCE_ERROR PICO_DEVICE_NOT_FUNCTIONING PICO_NOT_RESPONDING

API functions

PicoScope 4000 Series (A API) Programmer's Guide

Applicability

All modes

Arguments

handle, identifier for the scope device.

Returns

PICO_OK PICO_HANDLE_INVALID PICO_DRIVER_FUNCTION

API functions

4.2 ps4000aCloseUnit() – close a scope device

PICO_STATUS ps4000aCloseUnit

(

int16_t handle

)

This function disconnects the PicoScope device from the ps4000a driver. Once disconnected, the device can then be opened or enumerated by this or another application.

PicoScope 4000 Series (A API) Programmer's Guide

Applicability

PicoScope 4444 only

Arguments

handle, identifier for the scope device.

Returns

PICO_OK PICO_INVALID_HANDLE PICO_DRIVER_FUNCTION PICO_USB3_0_DEVICE_NON_USB3_0_PORT PICO_NOT_RESPONDING PICO_POWER_SUPPLY_CONNECTED PICO_POWER_SUPPLY_NOT_CONNECTED PICO_TIMEOUT PICO_RESOURCE_ERROR PICO_DEVICE_NOT_FUNCTIONING

API functions

4.3 ps4000aCurrentPowerSource() – read current power

source

PICO_STATUS ps4000aCurrentPowerSource

(

int16_t handle

)

This function returns the current power state of the device.

PicoScope 4824 and 4000A Series: There is no need to call this function as the device has only one possible state. Normally returns PICO_OK.

PicoScope 4444: Returns PICO_POWER_SUPPLY_NOT_CONNECTED if device is USB-powered; returns

PICO_POWER_SUPPLY_CONNECTED if DC power supply is connected.

PicoScope 4000 Series (A API) Programmer's Guide

Applicability

All modes

Arguments

* count, on exit, the number of scopes found. * serials, on exit, a list of serial numbers separated by commas and terminated by a final

null. Example: AQ005/139,VDR61/356,ZOR14/107

* serialLth, on entry, the length of the int8_t buffer pointed to by serials; on exit,

the length of the string written to serials.

Returns

PICO_OK PICO_BUSY PICO_NULL_PARAMETER PICO_FW_FAIL PICO_CONFIG_FAIL PICO_MEMORY_FAIL PICO_ANALOG_BOARD PICO_CONFIG_FAIL_AWG PICO_INITIALISE_FPGA PICO_INTERNAL_ERROR PICO_TIMEOUT PICO_RESOURCE_ERROR PICO_DEVICE_NOT_FUNCTIONING

API functions

4.4 ps4000aEnumerateUnits() – find out how many

units are connected

PICO_STATUS ps4000aEnumerateUnits

(

int16_t * count, int8_t * serials, int16_t * serialLth

)

This function counts the number of PicoScope 4000 Series (A API) units connected to the computer, and returns a list of serial numbers as a string. Note that this function will only detect devices that are not yet being controlled by an application.

PicoScope 4000 Series (A API) Programmer's Guide

Applicability

All modes

Arguments

handle, identifier for the scope device.

start, the action required:

< 0:flash the LED indefinitely.

0:stop the LED flashing.

> 0

flash the LED start times. If the LED is already flashing on entry to this function, the flash count will be reset to start.

Returns

PICO_OK PICO_HANDLE_INVALID PICO_BUSY PICO_DRIVER_FUNCTION PICO_MEMORY PICO_INTERNAL_ERROR PICO_POWER_SUPPLY_UNDERVOLTAGE PICO_NOT_RESPONDING PICO_POWER_SUPPLY_CONNECTED PICO_POWER_SUPPLY_NOT_CONNECTED PICO_TIMEOUT PICO_RESOURCE_ERROR PICO_DEVICE_NOT_FUNCTIONING

4.5 ps4000aFlashLed() – flash the front-panel LED

PICO_STATUS ps4000aFlashLed

(

int16_t handle, int16_t start

)

This function flashes the LED on the front of the scope without blocking the calling thread. Calls to

ps4000aRunStreaming() and ps4000aRunBlock() cancel any flashing started by this function.

API functions

PicoScope 4000 Series (A API) Programmer's Guide

Applicability

All modes

Arguments

handle, identifier for the scope device.

range, the voltage range to be used when gathering the min and max information.

coupling, the type of AC/DC coupling used.

* maximumVoltage, on exit, the maximum voltage allowed for the range. Pointer may be

NULL if not required.

* minimumVoltage, on exit, the minimum voltage allowed for the range. Pointer may be NULL if not required. If both maximumVoltage and minimumVoltage are NULL, the

driver returns PICO_NULL_PARAMETER.

Returns

PICO_OK PICO_INVALID_HANDLE PICO_DRIVER_FUNCTION PICO_INVALID_VOLTAGE_RANGE PICO_NULL_PARAMETER PICO_MEMORY PICO_INTERNAL_ERROR

API functions

4.6 ps4000aGetAnalogueOffset() – find the allowable

analog offset range

PICO_STATUS ps4000aGetAnalogueOffset

(

int16_t handle, PICO_CONNECT_PROBE_RANGE range, PS4000A_COUPLING coupling, float * maximumVoltage, float * minimumVoltage

)

This function is used to get the maximum and minimum allowable analog offset for a specific voltage range.

PicoScope 4000 Series (A API) Programmer's Guide

Applicability

Reserved for future expansion

Arguments

handle, identifier for the scope device.

info, the type of information required. The only value supported is:

PS4000A_CI_RANGES, returns the extra ranges available

probe, not used, must be set to 0.

* ranges, on exit, an array populated with available ranges for the given value of info.

May be NULL. See ps4000aSetChannel() for possible values.

* length, on entry: the length of the ranges array; on exit: the number of elements written

to ranges or, if ranges is NULL, the number of elements that would have been written.

channels, the channel for which the information is required. See

ps4000aSetChannel() for possible values.

Returns

PICO_OK PICO_INVALID_HANDLE PICO_INVALID_PARAMETER

API functions

4.7 ps4000aGetChannelInformation() – find out if extra

ranges available

PICO_STATUS ps4000aGetChannelInformation

(

int16_t handle, PS4000A_CHANNEL_INFO info, int32_t probe, int32_t * ranges, int32_t * length, int32_t channels

)

This function queries which extra ranges are available on a scope device.

PicoScope 4000 Series (A API) Programmer's Guide

Applicability

PicoScope 4444 only

Arguments

handle, identifier for the scope device.

overflow, a set of flags that indicate whether a common-mode overflow has occurred on

any of the channels. It is a bit pattern with bit 0 denoting Channel A.

Returns

PICO_OK PICO_INVALID_HANDLE PICO_INVALID_PARAMETER PICO_DRIVER_FUNCTION PICO_NOT_SUPPORTED_BY_THIS_DEVICE PICO_BUSY PICO_MEMORY_FAIL PICO_INTERNAL_ERROR PICO_TIMEOUT PICO_RESOURCE_ERROR PICO_DEVICE_NOT_FUNCTIONING

API functions

4.8 ps4000aGetCommonModeOverflow() – find out

which channels have overflowed

PICO_STATUS ps4000aGetCommonModeOverflow

(

int16_t handle, uint16_t * overflow

)

On each channel of a differential oscilloscope, both the positive and negative differential input voltages must remain within the specified limits to avoid measurement errors. These limits are independent of the differential voltage limit, which is the maximum voltage difference allowed between the two inputs.

This function queries whether any channel has exceeded the common mode voltage limit.

PicoScope 4000 Series (A API) Programmer's Guide

Applicability

PicoScope 4444 only

Arguments

handle, the handle of the required device

* resolution, returns the resolution of the device. Values are defined by

PS4000A_DEVICE_RESOLUTION.

Returns

PICO_OK PICO_INVALID_HANDLE PICO_DRIVER_FUNCTION PICO_NULL_PARAMETER

API functions

4.9 ps4000aGetDeviceResolution() – query the ADC

resolution

PICO_STATUS ps4000aGetDeviceResolution

(

int16_t handle,

PS4000A_DEVICE_RESOLUTION * resolution

)

This function retrieves the ADC resolution that is in use on the specified device.

PicoScope 4000 Series (A API) Programmer's Guide

Applicability

All modes

Arguments

handle, identifier for the scope device.

noOfUnaggregatedSamples, the number of raw samples to be used to calculate the

maximum downsampling ratio.

* maxDownSampleRatio, on exit, the maximum possible downsampling ratio.

downSampleRatioMode, see Downsampling.

segmentIndex, the memory segment where the data is stored.

Returns

PICO_OK PICO_INVALID_HANDLE PICO_NO_SAMPLES_AVAILABLE PICO_NULL_PARAMETER PICO_INVALID_PARAMETER PICO_SEGMENT_OUT_OF_RANGE PICO_TOO_MANY_SAMPLES PICO_DRIVER_FUNCTION PICO_NOT_USED PICO_BUSY

API functions

4.10 ps4000aGetMaxDownSampleRatio() – find out

downsampling ratio for data

PICO_STATUS ps4000aGetMaxDownSampleRatio

(

int16_t handle, uint32_t noOfUnaggregatedSamples, uint32_t * maxDownSampleRatio, PS4000A_RATIO_MODE downSampleRatioMode, uint32_t segmentIndex

)

This function returns the maximum downsampling ratio that can be used for a given number of samples.

PicoScope 4000 Series (A API) Programmer's Guide

Applicability

All modes

Arguments

handle, identifier for the scope device.

* maxSegments, on exit, the maximum possible number of memory segments. This

information can also be found in the data sheet for the device.

Returns

PICO_OK PICO_DRIVER_FUNCTION PICO_INVALID_HANDLE PICO_NULL_PARAMETER

API functions

4.11 ps4000aGetMaxSegments() – get maximum number

of memory segments

PICO_STATUS ps4000aGetMaxSegments

(

int16_t handle, uint32_t * maxSegments

)

This function retrieves the maximum number of memory segments allowed by the device.

PicoScope 4000 Series (A API) Programmer's Guide

Applicability

Arguments

handle, identifier for the scope device.

enabledChannelOrPortFlags, a bit field (using bitwise-OR if necessary) indicating

which channels are enabled:

PS4000A_CHANNEL_A_FLAGS = 1 PS4000A_CHANNEL_B_FLAGS = 2 PS4000A_CHANNEL_C_FLAGS = 4 PS4000A_CHANNEL_D_FLAGS = 8 PS4000A_CHANNEL_E_FLAGS = 16 PS4000A_CHANNEL_F_FLAGS = 32 PS4000A_CHANNEL_G_FLAGS = 64 PS4000A_CHANNEL_H_FLAGS = 128

* timebase, on exit: the timebase number of the shortest possible timebase under the

specified conditions.

* timeInterval, on exit: the sample interval, in seconds, corresponding to the timebase value.

resolution, the desired resolution mode.

Returns

See picoStatus.h.

API functions

4.12 ps4000aGetMinimumTimebaseStateless() – query

shortest timebase

PICO_STATUS ps4000aGetMinimumTimebaseStateless

(

int16_t handle, PS4000A_CHANNEL_FLAGS enabledChannelOrPortFlags, uint32_t * timebase, double * timeInterval, PS4000A_DEVICE_RESOLUTION resolution

)

This function obtains details of the shortest (fastest) timebase available on the specified device with the specified combination of enabled channels and resolution. It does not change any settings on the device.

PicoScope 4000 Series (A API) Programmer's Guide

Applicability

Rapid block mode

Arguments

handle, identifier for the scope device.

* nCaptures, on exit, the number of waveforms captured.

Returns

PICO_OK PICO_INVALID_HANDLE PICO_INVALID_PARAMETER PICO_DRIVER_FUNCTION PICO_NO_SAMPLES_AVAILABLE PICO_NOT_USED_IN_THIS_CAPTURE_MODE PICO_MEMORY_FAIL PICO_INTERNAL_ERROR PICO_TIMEOUT PICO_RESOURCE_ERROR PICO_DEVICE_NOT_FUNCTIONING PICO_NOT_RESPONDING

API functions

4.13 ps4000aGetNoOfCaptures() – get number of rapid

block captures

PICO_STATUS ps4000aGetNoOfCaptures

(

int16_t handle, uint32_t * nCaptures

)

This function gets the number of captures collected in one run of rapid block mode. You can call it during device capture, after collection has completed or after interrupting waveform collection by calling ps4000aStop().

PicoScope 4000 Series (A API) Programmer's Guide

Applicability

Rapid block mode

Arguments

handle, identifier for the scope device.

* nProcessedCaptures, on exit, the number of waveforms captured and processed.

Returns

PICO_OK PICO_INVALID_HANDLE PICO_INVALID_PARAMETER PICO_DRIVER_FUNCTION PICO_NULL_PARAMETER PICO_NOT_USED_IN_THIS_CAPTURE_MODE

API functions

4.14 ps4000aGetNoOfProcessedCaptures() – get number

of downsampled rapid block captures

PICO_STATUS ps4000aGetNoOfProcessedCaptures

(

int16_t handle, uint32_t * nProcessedCaptures

)

This function gets the number of captures collected and processed in one run of rapid block mode. It enables your application to start processing captured data while the driver is still transferring later captures from the device to the computer.

The function returns the number of captures the driver has processed since you called ps4000aRunBlock(). It is for use in rapid block mode, alongside ps4000aGetValuesOverlappedBulk(), when the driver is set to transfer data from the device automatically as soon as the ps4000aRunBlock() function is called. You can call ps4000aGetNoOfProcessedCaptures() during device capture, after collection has completed or after interrupting waveform collection by calling ps4000aStop().

The returned value (nProcessedCaptures) can then be used to iterate through the number of segments using

ps4000aGetValues(), or in a single call to ps4000aGetValuesBulk(), where it is used to calculate the

toSegmentIndex parameter.

When capture is stopped

If nProcessedCaptures = 0, you will also need to call ps4000aGetNoOfCaptures(), in order to determine how many waveform segments were captured, before calling ps4000aGetValues() or

ps4000aGetValuesBulk().

PicoScope 4000 Series (A API) Programmer's Guide

Applicability

Streaming mode only

Arguments

handle, identifier for the scope device.

lpPs4000Ready, a pointer to your ps4000aStreamingReady() callback function that

will return the latest downsampled values.

pParameter, a void pointer that will be passed to the ps4000aStreamingReady()

callback function.

Returns

PICO_OK PICO_INVALID_HANDLE PICO_NO_SAMPLES_AVAILABLE PICO_INVALID_CALL PICO_BUSY PICO_NOT_RESPONDING PICO_DRIVER_FUNCTION PICO_USB3_0_DEVICE_NON_USB3_0_PORT PICO_NOT_RESPONDING PICO_POWER_SUPPLY_UNDERVOLTAGE PICO_POWER_SUPPLY_CONNECTED PICO_POWER_SUPPLY_NOT_CONNECTED PICO_STREAMING_FAILED

4.15 ps4000aGetStreamingLatestValues() – get

streaming data while scope is running

PICO_STATUS ps4000aGetStreamingLatestValues

(

int16_t handle, ps4000aStreamingReady lpPs4000Ready, void * pParameter

)

This function is used to collect the next block of values while streaming is running. You must call

ps4000aRunStreaming() beforehand to set up streaming.

API functions

PicoScope 4000 Series (A API) Programmer's Guide

Applicability

All modes

Arguments

handle, identifier for the scope device.

timebase, a code between 0 and 232–1 that specifies the sampling interval (see

Timebases).

noSamples, the number of samples required.

* timeIntervalNanoseconds, on exit, the time interval between readings at the

selected timebase. If a null pointer is passed, nothing will be written here. * maxSamples, on exit, the maximum number of samples available. The scope allocates a

certain amount of memory for internal overheads and this may vary depending on the number of segments, number of channels enabled, and the timebase chosen. If this pointer is null, nothing will be written here.

segmentIndex, the number of the memory segment to use.

Returns

PICO_OK PICO_INVALID_HANDLE PICO_TOO_MANY_SAMPLES PICO_INVALID_CHANNEL PICO_INVALID_TIMEBASE PICO_INVALID_PARAMETER PICO_DRIVER_FUNCTION PICO_SEGMENT_OUT_OF_RANGE PICO_INVALID_TIMEBASE

API functions

4.16 ps4000aGetTimebase() – find out what timebases

are available

PICO_STATUS ps4000aGetTimebase

(

int16_t handle, uint32_t timebase, int32_t noSamples, int32_t * timeIntervalNanoseconds, int32_t * maxSamples uint32_t segmentIndex

)

This function discovers which timebases are available on the oscilloscope. Set up the channels using

ps4000aSetChannel() first.

PicoScope 4000 Series (A API) Programmer's Guide

Applicability

All modes

Arguments

handle, timebase, noSamples, see ps4000aGetTimebase().

* timeIntervalNanoseconds, on exit, the time interval between samples at the

selected timebase. If a null pointer is passed, nothing will be written here.

maxSamples, segmentIndex, see ps4000aGetTimebase().

Returns

See ps4000aGetTimebase().

API functions

4.17 ps4000aGetTimebase2() – find out what timebases

are available

PICO_STATUS ps4000aGetTimebase2

(

int16_t handle, uint32_t timebase, int32_t noSamples, float * timeIntervalNanoseconds, int32_t * maxSamples, uint32_t segmentIndex

)

This function is similar to ps4000aGetTimebase() except that it allows sub-nanosecond time sampling intervals.

PicoScope 4000 Series (A API) Programmer's Guide

API functions

4.18 ps4000aGetTriggerTimeOffset() – read trigger

timing adjustments (32-bit)

PICO_STATUS ps4000aGetTriggerTimeOffset

(

int16_t handle, uint32_t * timeUpper, uint32_t * timeLower, PS4000A_TIME_UNITS * timeUnits, uint32_t segmentIndex

)

This function gets the trigger time offset for waveforms in block mode or rapid block mode. The trigger time offset is an adjustment value used for correcting jitter in the waveform, and is intended mainly for applications that wish to display the waveform with reduced jitter. The offset is zero if the waveform crosses the threshold at the trigger sampling instant, or a positive or negative value if jitter correction is required. The value should be added to the nominal trigger time to get the corrected trigger time.

Call this function after data has been captured or when data has been retrieved from a previous capture.

This function is provided for use in programming environments that do not support 64-bit integers. Another version of this function, ps4000aGetTriggerTimeOffset64(), is available that returns the time as a single 64-bit value.

PicoScope 4000 Series (A API) Programmer's Guide

Applicability

Block mode and rapid block mode

Arguments

handle, identifier for the scope device.

* timeUpper, on exit, the upper 32 bits of the time at which the trigger point occurred.

* timeLower, on exit, the lower 32 bits of the time at which the trigger point occurred.

* timeUnits, on exit, the time units in which * timeUpper and * timeLower are

measured. The allowable values are:

PS4000A_FS PS4000A_PS PS4000A_NS PS4000A_US PS4000A_MS PS4000A_S

segmentIndex, the number of the memory segment for which the information is required.

Returns

PICO_OK PICO_INVALID_HANDLE PICO_DEVICE_SAMPLING PICO_SEGMENT_OUT_OF_RANGE PICO_NULL_PARAMETER PICO_NO_SAMPLES_AVAILABLE PICO_DRIVER_FUNCTION PICO_NOT_USED_IN_THIS_CAPTURE_MODE PICO_TRIGGER_ERROR PICO_FW_FAIL PICO_TIMEOUT PICO_RESOURCE_ERROR PICO_DEVICE_NOT_FUNCTIONING PICO_NOT_RESPONDING PICO_MEMORY_FAIL PICO_INTERNAL_ERROR

API functions

PicoScope 4000 Series (A API) Programmer's Guide

Applicability

Block mode and rapid block mode

Arguments

handle, identifier for the scope device.

* time, on exit, the time at which the trigger point occurred.

* timeUnits, on exit, the time units in which time is measured. See

ps4000aGetTriggerTimeOffset().

segmentIndex, the number of the memory segment for which the information is required.

Returns

API functions

4.19 ps4000aGetTriggerTimeOffset64() – read trigger

timing adjustments (64-bit)

PICO_STATUS ps4000aGetTriggerTimeOffset64

(

int16_t handle, int64_t * time, PS4000A_TIME_UNITS * timeUnits, uint32_t segmentIndex

)

This function gets the trigger time offset for a waveform. It is equivalent to

ps4000aGetTriggerTimeOffset() except that the time offset is returned as a single 64-bit value instead

of two 32-bit values.

PicoScope 4000 Series (A API) Programmer's Guide

Applicability

All modes

Arguments

handle, identifier for the device. If handle is invalid, the error code from the last unit that

failed to open is returned.

string, the character string buffer in the calling function where the unit information string

(selected with info) will be stored. If a null pointer is passed, only requiredSize is returned.

stringLength, the size of the character string buffer.

* requiredSize, on exit, the required character string buffer size.

info, an enumerated type specifying what information is required from the driver. Values

are listed below.

Returns

PICO_OK PICO_INVALID_HANDLE PICO_NULL_PARAMETER PICO_INVALID_INFO PICO_INFO_UNAVAILABLE PICO_DRIVER_FUNCTION

PICO_INFO constant

Example

0: PICO_DRIVER_VERSION, version number of ps4000a DLL

1.0.4.56

1: PICO_USB_VERSION, type of USB connection to device: 1.1, 2.0 or 3.0

3.0

2: PICO_HARDWARE_VERSION, hardware version of device

3: PICO_VARIANT_INFO, variant number of device

4824

4: PICO_BATCH_AND_SERIAL, batch and serial number of device

KJ087/0006

5: PICO_CAL_DATE, calibration date of device

11Nov13

6: PICO_KERNEL_VERSION, version of kernel driver

1.0

7: PICO_DIGITAL_HARDWARE_VERSION, version of digital board

8: PICO_ANALOGUE_HARDWARE_VERSION, version of analog board

9: PICO_FIRMWARE_VERSION_1

1.4.0.0

10: PICO_FIRMWARE_VERSION_2

0.9.15.0

API functions

4.20 ps4000aGetUnitInfo() – read information about

scope device

PICO_STATUS ps4000aGetUnitInfo

(

int16_t handle, int8_t * string, int16_t stringLength, int16_t * requiredSize, PICO_INFO info

)

This function writes information about the specified scope device to a character string. If the device fails to open, only the driver version and error code are available to explain why the last open unit call failed.

PicoScope 4000 Series (A API) Programmer's Guide

API functions

4.21 ps4000aGetValues() – retrieve block-mode data

PICO_STATUS ps4000aGetValues

(

int16_t handle, uint32_t startIndex, uint32_t * noOfSamples, uint32_t downSampleRatio, PS4000A_RATIO_MODE downSampleRatioMode, uint32_t segmentIndex, int16_t * overflow

)

This function retrieves block-mode data, either with or without downsampling, starting at the specified sample number. It is used to get the stored data from the scope after data collection has stopped, and store it in a user

buffer previously passed to ps4000aSetDataBuffer() or ps4000aSetDataBuffers(). It blocks the calling function while retrieving data.

If multiple channels are enabled, a single call to this function is sufficient to retrieve data for all channels.

Note that if you are using block mode and call this function before the oscilloscope is ready, no capture will be available and the driver will return PICO_NO_SAMPLES_AVAILABLE.

PicoScope 4000 Series (A API) Programmer's Guide

Applicability

Block mode and rapid block mode

Arguments

handle, identifier for the scope device.

startIndex, a zero-based index that indicates the start point for data collection. It is

measured in sample intervals from the start of the buffer.

* noOfSamples, on entry, the number of samples requested; on exit, the number of

samples actually retrieved.

downSampleRatio, the downsampling factor that will be applied to the raw data. Multiple

downsampling modes can be bitwise-ORed together, but the downSampleRatio must be the same for all modes.

downSampleRatioMode, whether to use downsampling to reduce the amount of data.

See Downsampling.

segmentIndex, the zero-based number of the memory segment where the data is stored.

* overflow, on exit, a set of flags that indicate whether an overvoltage has occurred on

any of the channels. It is a bit pattern, with bit 0 corresponding to Channel A.

Returns

PICO_OK PICO_INVALID_HANDLE PICO_NO_SAMPLES_AVAILABLE PICO_DEVICE_SAMPLING PICO_NULL_PARAMETER PICO_SEGMENT_OUT_OF_RANGE PICO_INVALID_PARAMETER PICO_TOO_MANY_SAMPLES PICO_DATA_NOT_AVAILABLE PICO_STARTINDEX_INVALID PICO_INVALID_SAMPLERATIO PICO_INVALID_CALL PICO_NOT_RESPONDING PICO_MEMORY PICO_DRIVER_FUNCTION PICO_USB3_0_DEVICE_NON_USB3_0_PORT PICO_NOT_RESPONDING PICO_POWER_SUPPLY_UNDERVOLTAGE PICO_POWER_SUPPLY_CONNECTED PICO_POWER_SUPPLY_NOT_CONNECTED PICO_BUFFERS_NOT_SET PICO_INVALID_PARAMETER PICO_INVALID_SAMPLERATIO PICO_ETS_NOT_RUNNING PICO_MEMORY_FAIL PICO_INTERNAL_ERROR PICO_RESOURCE_ERROR

API functions

PicoScope 4000 Series (A API) Programmer's Guide

Applicability

Block mode and streaming mode

Arguments

handle, identifier for the scope device.

startIndex, noOfSamples, downSampleRatio, downSampleRatioMode, segmentIndex, see ps4000aGetValues().

* lpDataReady, the ps4000aStreamingReady() function that is called when the

data is ready.

pParameter, a void pointer that will be passed to the ps4000aStreamingReady()

callback function. The data type depends on the design of the callback function, which is determined by the application programmer.

Returns

PICO_OK PICO_INVALID_HANDLE PICO_NO_SAMPLES_AVAILABLE PICO_DEVICE_SAMPLING – streaming only PICO_NULL_PARAMETER PICO_STARTINDEX_INVALID PICO_SEGMENT_OUT_OF_RANGE PICO_INVALID_PARAMETER PICO_DATA_NOT_AVAILABLE PICO_INVALID_SAMPLERATIO PICO_INVALID_CALL PICO_DRIVER_FUNCTION PICO_USB3_0_DEVICE_NON_USB3_0_PORT PICO_NOT_RESPONDING PICO_POWER_SUPPLY_UNDERVOLTAGE PICO_POWER_SUPPLY_CONNECTED PICO_POWER_SUPPLY_NOT_CONNECTED PICO_BUFFERS_NOT_SET PICO_INTERNAL_ERROR PICO_MEMORY

API functions

4.22 ps4000aGetValuesAsync() – retrieve block or

streaming data

PICO_STATUS ps4000aGetValuesAsync

(

int16_t handle, uint32_t startIndex, uint32_t noOfSamples, uint32_t downSampleRatio, PS4000A_RATIO_MODE downSampleRatioMode, uint32_t segmentIndex, void * lpDataReady, void * pParameter

)

This function returns data, either with or without downsampling, starting at the specified sample number. It can be used in block mode to retrieve data from the device, using a callback so as not to block the calling function. It can also be used in streaming mode to retrieve data from the driver, but in this case it blocks the calling function.

PicoScope 4000 Series (A API) Programmer's Guide

API functions

4.23 ps4000aGetValuesBulk() – retrieve more than one

waveform at a time

PICO_STATUS ps4000aGetValuesBulk

(

int16_t handle, uint32_t * noOfSamples, uint32_t fromSegmentIndex, uint32_t toSegmentIndex, unit32_t downSampleRatio, PS4000A_RATIO_MODE downSampleRatioMode, int16_t * overflow

)

This function allows more than one waveform to be retrieved at a time in rapid block mode. The waveforms must have been collected sequentially and in the same run.

If multiple channels are enabled, a single call to this function is sufficient to retrieve data for all channels.

PicoScope 4000 Series (A API) Programmer's Guide

Applicability

Rapid block mode

Arguments

handle, identifier for the scope device.

* noOfSamples, on entry, the number of samples required; on exit, the actual number

retrieved. The number of samples retrieved will not be more than the number requested. The data retrieved always starts with the first sample captured.

fromSegmentIndex, the first segment from which waveforms should be retrieved.

toSegmentIndex, the last segment from which waveforms should be retrieved.

downSampleRatio, downSampleRatioMode, see Downsampling.

* overflow, an array of at least as many integers as the number of waveforms to be

retrieved. Each segment index has a separate overflow element, with overflow[0] containing the fromSegmentIndex and the last index the toSegmentIndex. Each element in the array is a bit field as described under ps4000aGetValues().

Returns

PICO_OK PICO_INVALID_HANDLE PICO_INVALID_PARAMETER PICO_SEGMENT_OUT_OF_RANGE PICO_NO_SAMPLES_AVAILABLE PICO_STARTINDEX_INVALID PICO_NOT_RESPONDING PICO_DRIVER_FUNCTION PICO_USB3_0_DEVICE_NON_USB3_0_PORT PICO_NOT_RESPONDING PICO_POWER_SUPPLY_UNDERVOLTAGE PICO_POWER_SUPPLY_CONNECTED PICO_POWER_SUPPLY_NOT_CONNECTED PICO_NO_CAPTURES_AVAILABLE PICO_NOT_USED_IN_THIS_CAPTURE_MODE PICO_CAPTURING_DATA PICO_INVALID_SAMPLERATIO

API functions

PicoScope 4000 Series (A API) Programmer's Guide

Applicability

Block mode

Arguments

handle, startIndex, * noOfSamples, downSampleRatio, downSampleRatioMode, segmentIndex: see ps4000aGetValues()

* overflow: see ps4000aGetValuesBulk()

Returns

PICO_OK PICO_POWER_SUPPLY_CONNECTED PICO_POWER_SUPPLY_NOT_CONNECTED PICO_INVALID_HANDLE PICO_INVALID_PARAMETER PICO_DRIVER_FUNCTION PICO_USB3_0_DEVICE_NON_USB3_0_PORT PICO_NOT_RESPONDING PICO_POWER_SUPPLY_UNDERVOLTAGE

API functions

4.24 ps4000aGetValuesOverlapped() – retrieve data in

overlapping blocks

PICO_STATUS ps4000aGetValuesOverlapped

(

int16_t handle, uint32_t startIndex, uint32_t * noOfSamples, uint32_t downSampleRatio, PS4000A_RATIO_MODE downSampleRatioMode, uint32_t segmentIndex, int16_t * overflow

)

This function allows you to make a deferred data-collection request in block mode. The request will be executed, and the arguments validated, when you call ps4000aRunBlock(). The advantage of this function is that the driver makes contact with the scope only once, when you call ps4000aRunBlock(), compared with the two contacts that occur when you use the conventional ps4000aRunBlock(), ps4000aGetValues() calling sequence. This slightly reduces the dead time between successive captures in block mode.

After calling ps4000aRunBlock(), you can optionally use ps4000aGetValues() to request further copies of the data. This might be required if you wish to display the data with different data reduction settings.

If multiple channels are enabled, a single call to this function is sufficient to retrieve data for all channels.

PicoScope 4000 Series (A API) Programmer's Guide

API functions

4.24.1 Using the GetValuesOverlapped functions

This procedure is similar to that described in Using block mode, with differences shown in italics:

1. Open the oscilloscope using ps4000aOpenUnit().

2. Select channel ranges and AC/DC coupling using ps4000aSetChannel().

3. Using ps4000aGetTimebase(), select timebases until the required nanoseconds per sample is located.

4. Use the trigger setup functions ps4000aSetTriggerChannelDirections() and

ps4000aSetTriggerChannelProperties() to set up the trigger if required.

4a. Use ps4000aSetDataBuffer() to tell the driver where your memory buffer is. 4b. Set up the transfer of the block of data from the oscilloscope using ps4000aGetValuesOverlapped().

5. Start the oscilloscope running using ps4000aRunBlock().

6. Wait until the oscilloscope is ready using the ps4000aBlockReady() callback (or poll using

ps4000aIsReady()).

7. (not needed)

8. (not needed)

9. Display the data.

10. Repeat steps 5 to 9 if needed.

11. Stop the oscilloscope using ps4000aStop().

12. Request new views of stored data using different downsampling parameters: see Retrieving stored data.

13. Close the device using ps4000aCloseUnit().

A similar procedure can be used with rapid block mode using ps4000aGetValuesOverlappedBulk().

PicoScope 4000 Series (A API) Programmer's Guide

Applicability

Rapid block mode

Arguments

handle, startIndex, * noOfSamples, downSampleRatio, downSampleRatioMode: see ps4000aGetValues()

fromSegmentIndex, toSegmentIndex, * overflow, see ps4000aGetValuesBulk()

Returns

4.25 ps4000aGetValuesOverlappedBulk() – retrieve

overlapping data from multiple segments

PICO_STATUS ps4000aGetValuesOverlappedBulk

(

int16_t handle, uint32_t startIndex, uint32_t * noOfSamples, uint32_t downSampleRatio, PS4000A_RATIO_MODE downSampleRatioMode, uint32_t fromSegmentIndex, uint32_t toSegmentIndex, int16_t * overflow

)

This function requests data from multiple segments in rapid block mode. It is similar to calling

ps4000aGetValuesOverlapped() multiple times, but more efficient.

API functions

PicoScope 4000 Series (A API) Programmer's Guide

Applicability

Rapid block mode

Arguments

handle, identifier for the scope device.

* timesUpper, an array of integers. On exit, the most significant 32 bits of the time offset

for each requested segment index. times[0] will hold the fromSegmentIndex time offset and the last times index will hold the toSegmentIndex time offset. The array must

be long enough to hold the number of requested times.

* timesLower, an array of integers. On exit, the least significant 32 bits of the time offset

for each requested segment index. times[0] will hold the fromSegmentIndex time offset and the last times index will hold the toSegmentIndex time offset. The array size

must be long enough to hold the number of requested times.

* timeUnits, an array of integers. The array must be long enough to hold the number of

requested times. On exit, timeUnits[0] will contain the time unit for

fromSegmentIndex and the last element will contain the time unit for toSegmentIndex.

Refer to ps4000aGetTriggerTimeOffset() for specific figures.

fromSegmentIndex, the first segment for which the time offset is required.

toSegmentIndex, the last segment for which the time offset is required. If toSegmentIndex is less than fromSegmentIndex then the driver will wrap around from

the last segment to the first.

API functions

4.26 ps4000aGetValuesTriggerTimeOffsetBulk() – get

trigger timing adjustments (multiple)

PICO_STATUS ps4000aGetValuesTriggerTimeOffsetBulk

(

int16_t handle, uint32_t * timesUpper, uint32_t * timesLower, PS4000A_TIME_UNITS * timeUnits, uint32_t fromSegmentIndex, uint32_t toSegmentIndex

)

This function retrieves the trigger time offset for multiple waveforms obtained in block mode or rapid block mode. It is a more efficient alternative to calling ps4000aGetTriggerTimeOffset() once for each waveform required. See ps4000aGetTriggerTimeOffset() for an explanation of trigger time offsets.

This function is provided for use in programming environments that do not support 64-bit integers. If your programming environment does support 64-bit integers, it is easier to use

ps4000aGetValuesTriggerTimeOffsetBulk64().

PicoScope 4000 Series (A API) Programmer's Guide

Returns

PICO_OK PICO_POWER_SUPPLY_CONNECTED PICO_POWER_SUPPLY_NOT_CONNECTED PICO_INVALID_HANDLE PICO_NOT_USED_IN_THIS_CAPTURE_MODE PICO_NOT_RESPONDING PICO_NULL_PARAMETER PICO_DEVICE_SAMPLING PICO_SEGMENT_OUT_OF_RANGE PICO_NO_SAMPLES_AVAILABLE PICO_DRIVER_FUNCTION

API functions

PicoScope 4000 Series (A API) Programmer's Guide

Applicability

Rapid block mode

Arguments

handle, identifier for the scope device.

* times, an array of integers. On exit, this will hold the time offset for each requested

segment index. times[0] will hold the time offset for fromSegmentIndex, and the last

times index will hold the time offset for toSegmentIndex. The array must be long enough

to hold the number of times requested.

* timeUnits, an array of integers long enough to hold the number of requested times. timeUnits[0] will contain the time unit for fromSegmentIndex, and the last element

will contain the toSegmentIndex. Refer to ps4000aGetTriggerTimeOffset64() for specific figures.

fromSegmentIndex, the first segment for which the time offset is required. The results for

this segment will be placed in times[0] and timeUnits[0].

toSegmentIndex, the last segment for which the time offset is required. The results for

this segment will be placed in the last elements of the times and timeUnits arrays. If

toSegmentIndex is less than fromSegmentIndex, then the driver will wrap around from

the last segment to the first.

Returns

API functions

4.27 ps4000aGetValuesTriggerTimeOffsetBulk64() – get

trigger timing adjustments (multiple)

PICO_STATUS ps4000aGetValuesTriggerTimeOffsetBulk64

(

int16_t handle, int64_t * times, PS4000A_TIME_UNITS * timeUnits, uint32_t fromSegmentIndex, uint32_t toSegmentIndex

)

This function is equivalent to ps4000aGetValuesTriggerTimeOffsetBulk() but retrieves the trigger time offsets as 64-bit values instead of pairs of 32-bit values.

PicoScope 4000 Series (A API) Programmer's Guide

Applicability

All modes

Arguments

handle, identifier for the scope device.

status, returns a flag indicating the status of the LED:

<> 0 : flashing 0 : not flashing

Returns

PICO_OK PICO_HANDLE_INVALID PICO_NULL_PARAMETER PICO_DRIVER_FUNCTION PICO_NOT_SUPPORTED_BY_THIS_DEVICE PICO_NOT_USED

4.28 ps4000aIsLedFlashing() – read status of LED

PICO_STATUS ps4000aIsLedFlashing

(

int16_t handle, int16_t * status

)

This function reports whether or not the LED is flashing.

API functions

PicoScope 4000 Series (A API) Programmer's Guide

Applicability

Block mode

Arguments

handle, identifier for the scope device.

ready, on exit, indicates the state of the collection. If zero, the device is still collecting. If

non-zero, the device has finished collecting and ps4000aGetValues() can be used to retrieve the data.

Returns

PICO_OK PICO_INVALID_HANDLE PICO_DRIVER_FUNCTION PICO_NULL_PARAMETER PICO_NO_SAMPLES_AVAILABLE PICO_CANCELLED PICO_NOT_RESPONDING

API functions

4.29 ps4000aIsReady() – poll the driver in block mode

PICO_STATUS ps4000aIsReady

(

int16_t handle, int16_t * ready

)

This function may be used instead of a callback function to receive data from ps4000aRunBlock(). To use this method, pass a NULL pointer as the lpReady argument to ps4000aRunBlock(). You must then poll the

driver to see if it has finished collecting the requested samples.

PicoScope 4000 Series (A API) Programmer's Guide

Applicability

Call after setting up the trigger, and just before calling either ps4000aRunBlock() or

ps4000aRunStreaming().

Arguments

handle, identifier for the scope device.

* triggerEnabled, on exit, indicates whether the trigger will successfully be set when

ps4000aRunBlock() or ps4000aRunStreaming() is called. A non-zero value indicates

that the trigger is set, otherwise the trigger is not set.

* pulseWidthQualifierEnabled, on exit, indicates whether the pulse width qualifier

will successfully be set when ps4000aRunBlock() or ps4000aRunStreaming() is called. A non-zero value indicates that the pulse width qualifier is set, otherwise the pulse width qualifier is not set.

Returns

PICO_OK PICO_INVALID_HANDLE PICO_NULL_PARAMETER PICO_DRIVER_FUNCTION

API functions

4.30 ps4000aIsTriggerOrPulseWidthQualifierEnabled() –

find out whether trigger is enabled

PICO_STATUS ps4000aIsTriggerOrPulseWidthQualifierEnabled

(

int16_t handle, int16_t * triggerEnabled, int16_t * pulseWidthQualifierEnabled

)

This function discovers whether a trigger, or pulse width triggering, is enabled.

PicoScope 4000 Series (A API) Programmer's Guide

Applicability

All modes

Arguments

handle, identifier for the scope device.

* value, on exit, the maximum value.

Returns

PICO_OK PICO_INVALID_HANDLE PICO_DRIVER_FUNCTION PICO_NULL_PARAMETER

API functions

4.31 ps4000aMaximumValue() – get maximum allowed

sample value

PICO_STATUS ps4000aMaximumValue

(

int16_t handle, int16_t * value

)

This function returns the maximum possible sample value in the current operating mode.

PicoScope 4000 Series (A API) Programmer's Guide

Applicability

Block mode, rapid block mode

Arguments

handle, identifier for the scope device.

nSegments, the number of segments to be used, from 1 to the number returned by

ps4000aGetMaxSegments().

* nMaxSamples, on exit, the number of samples that are available in each segment. This

is the total number over all channels, so if more than one channel is in use, the number of samples available to each channel is nMaxSamples divided by 2 (for 2 channels) or 4 (for 3 or 4 channels) or 8 (for 5 to 8 channels).

Returns

PICO_OK PICO_USER_CALLBACK PICO_INVALID_HANDLE PICO_TOO_MANY_SEGMENTS PICO_DRIVER_FUNCTION PICO_MEMORY_FAIL

API functions

4.32 ps4000aMemorySegments() – divide scope memory

into segments

PICO_STATUS ps4000aMemorySegments

(

int16_t handle, uint32_t nSegments, int32_t * nMaxSamples

)

This function sets the number of memory segments that the scope device will use.

By default, each capture fills the scope device's available memory. This function allows you to divide the memory into a number of segments so that the scope can store several captures sequentially. The number of segments defaults to 1 when the scope device is opened.

PicoScope 4000 Series (A API) Programmer's Guide

Applicability

All modes

Arguments

handle, identifier for the scope device.

* value, on exit, the minimum value.

Returns

PICO_OK PICO_INVALID_HANDLE PICO_DRIVER_FUNCTION PICO_NULL_PARAMETER

API functions

4.33 ps4000aMinimumValue() – get minimum allowed

sample value

PICO_STATUS ps4000aMinimumValue

(

int16_t handle, int16_t * value

)

This function returns the minimum possible sample value in the current operating mode.

PicoScope 4000 Series (A API) Programmer's Guide

Applicability

Streaming mode.

Arguments

handle, identifier for the scope device.

* noOfValues, on exit, the number of samples.

Returns

PICO_OK PICO_INVALID_HANDLE PICO_NULL_PARAMETER PICO_NO_SAMPLES_AVAILABLE PICO_NOT_USED PICO_BUSY PICO_DRIVER_FUNCTION

API functions

4.34 ps4000aNoOfStreamingValues() – get number of

samples in streaming mode

PICO_STATUS ps4000aNoOfStreamingValues

(

int16_t handle, uint32_t * noOfValues

)

This function returns the number of raw samples available after data collection in streaming mode. Call it after

ps4000aStop().

PicoScope 4000 Series (A API) Programmer's Guide

Applicability

Arguments

handle, identifier for the scope device.

enabledChannelOrPortFlags, the proposed combination of enabled channels. Use

the bitwise-OR of the relevant PS4000A_CHANNEL_FLAGS values – see

ps4000aGetMinimumTimebaseStateless().

timeIntervalRequested, the proposed sampling interval, in seconds.

resolution, the proposed resolution.

useEts, the proposed state of ETS:

0 = ETS off 1 = ETS on

* timebase, on exit, the timebase that will result in a sampling interval as close as

possible to timeIntervalRequested.

* timeIntervalAvailable, on exit, the sampling interval corresponding to timebase.

Returns

See PicoStatus.h.

API functions

4.35 ps4000aNearestSampleIntervalStateless() – find

nearest available sampling interval

PICO_STATUS ps4000aNearestSampleIntervalStateless

(

int16_t handle, PS4000A_CHANNEL_FLAGS enabledChannelOrPortFlags, double timeIntervalRequested, PS4000A_DEVICE_RESOLUTION resolution, uint16_t useEts, uint32_t * timebase, double * timeIntervalAvailable

)

This function queries the nearest available sampling interval given a desired sampling interval and a device configuration. It does not change the configuration of the device.

PicoScope 4000 Series (A API) Programmer's Guide

Applicability

All devices

Arguments

handle, on exit, an identifier for the device:

–1 : if the unit fails to open, 0 : if no unit is found or > 0 : if successful (value is handle of the device opened)

handle must be used in all subsequent calls to API functions to identify this scope device.

* serial, on entry, an empty string, a serial number string or NULL; on exit, a null-

terminated string containing the device's serial number. If serial is NULL, the function opens the first scope found; otherwise, it tries to open the scope that matches the string.

Returns

PICO_OK PICO_OS_NOT_SUPPORTED PICO_OPEN_OPERATION_IN_PROGRESS PICO_EEPROM_CORRUPT PICO_KERNEL_DRIVER_TOO_OLD PICO_FW_FAIL PICO_MAX_UNITS_OPENED PICO_NOT_FOUND PICO_NOT_RESPONDING PICO_USB3_0_DEVICE_NON_USB3_0_PORT PICO_RESOURCE_ERROR PICO_MEMORY_FAIL PICO_HARDWARE_VERSION_NOT_SUPPORTED PICO_MEMORY_FAIL PICO_INTERNAL_ERROR PICO_POWER_SUPPLY_NOT_CONNECTED PICO_TIMEOUT PICO_DEVICE_NOT_FUNCTIONING PICO_NOT_USED PICO_FPGA_FAIL

API functions

4.36 ps4000aOpenUnit() – open a scope device

PICO_STATUS ps4000aOpenUnit

(

int16_t * handle, int8_t * serial

)

This function opens a scope device. The maximum number of units that can be opened is determined by the operating system, the kernel driver and the PC's hardware.

PicoScope 4824 and 4000A Series only: If the function returns PICO_USB3_0_DEVICE_NON_USB3_0_PORT, the application must call ps4000aChangePowerSource() to complete the two-stage power-up sequence for a USB 2.0 port (or USB 3.0 port with USB 2.0 cable). Returns PICO_OK if connected to a USB 3.0 port.

PicoScope 4444 only: If the function returns PICO_POWER_SUPPLY_NOT_CONNECTED, the application must call ps4000aChangePowerSource() to complete the two-stage power-up sequence for a USB 2.0 or USB 3.0 port. Returns PICO_POWER_SUPPLY_CONNECTED if a power supply is connected.

PicoScope 4444 only: This function opens the device with the lowest available resolution. To open the device with a different resolution, use ps4000aOpenUnitWithResolution().

PicoScope 4000 Series (A API) Programmer's Guide

Applicability

All devices

Arguments

* status, on exit, indicates:

0 if there is already an open operation in progress 1 if the open operation is initiated

* serial, on exit, a null-terminated string containing the device's serial number.

Returns

PICO_OK PICO_OPEN_OPERATION_IN_PROGRESS PICO_USB3_0_DEVICE_NON_USB3_0_PORT PICO_OPERATION_FAILED PICO_OS_NOT_SUPPORTED PICO_EEPROM_CORRUPT PICO_KERNEL_DRIVER_TOO_OLD PICO_FW_FAIL PICO_MAX_UNITS_OPENED PICO_NOT_FOUND PICO_NOT_RESPONDING PICO_RESOURCE_ERROR PICO_MEMORY_FAIL PICO_HARDWARE_VERSION_NOT_SUPPORTED PICO_MEMORY_FAIL PICO_INTERNAL_ERROR PICO_POWER_SUPPLY_NOT_CONNECTED PICO_TIMEOUT PICO_DEVICE_NOT_FUNCTIONING PICO_NOT_USED PICO_FPGA_FAIL

API functions

4.37 ps4000aOpenUnitAsync() – open a scope device

without waiting

PICO_STATUS ps4000aOpenUnitAsync

(

int16_t * status, int8_t * serial

)

This function opens a scope device without blocking the calling thread. You can find out when it has finished by periodically calling ps4000aOpenUnitProgress() until that function returns a non-zero value.

PicoScope 4000 Series (A API) Programmer's Guide

Applicability

All devices

Arguments

* status, * serial, see ps4000aOpenUnitAsync(). resolution, see ps4000aOpenUnitWithResolution(). If the device has fixed ADC

resolution, this argument is ignored.

Returns

API functions

4.38 ps4000aOpenUnitAsyncWithResolution() – open a

flexible-resolution scope

PICO_STATUS ps4000aOpenUnitAsyncWithResolution

(

int16_t * status, int8_t * serial, PS4000A_DEVICE_RESOLUTION resolution

)

This function is similar to ps4000aOpenUnitAsync() but also sets the ADC resolution for scope devices that have flexible resolution.

PicoScope 4000 Series (A API) Programmer's Guide

Applicability

Use after ps4000aOpenUnitAsync()

Arguments

* handle, on exit, the device identifier. –1 if the unit fails to open, 0 if no unit is found or a

non-zero handle to the device. This handle is valid only if the function returns PICO_OK.

* progressPercent, on exit, the percentage progress. 100% implies that the open

operation is complete.

* complete, on exit, set to 1 when the open operation has finished

Returns

PICO_OK PICO_NULL_PARAMETER PICO_OPERATION_FAILED PICO_USB3_0_DEVICE_NON_USB3_0_PORT PICO_OPEN_OPERATION_IN_PROGRESS PICO_OS_NOT_SUPPORTED PICO_EEPROM_CORRUPT PICO_KERNEL_DRIVER_TOO_OLD PICO_FW_FAIL PICO_MAX_UNITS_OPENED PICO_NOT_FOUND PICO_NOT_RESPONDING PICO_RESOURCE_ERROR PICO_MEMORY_FAIL PICO_HARDWARE_VERSION_NOT_SUPPORTED PICO_MEMORY_FAIL PICO_INTERNAL_ERROR PICO_POWER_SUPPLY_NOT_CONNECTED PICO_TIMEOUT PICO_DEVICE_NOT_FUNCTIONING PICO_NOT_USED PICO_FPGA_FAIL

API functions

4.39 ps4000aOpenUnitProgress() – check progress of

OpenUnit() call

PICO_STATUS ps4000aOpenUnitProgress

( int16_t * handle, int16_t * progressPercent, int16_t * complete )

This function checks on the progress of ps4000aOpenUnitAsync(). For status codes related to USB 2.0 powering, see ps4000aOpenUnit().

PicoScope 4444: returns PICO_POWER_SUPPLY_NOT_CONNECTED on completion if no power supply is connected; returns PICO_OK if a power supply is connected.

PicoScope 4824 and 4000A Series: returns PICO_USB3_0_DEVICE_NON_USB3_0_PORT if connected to a USB 2.0 port, or to any type of port through a USB 2.0 cable. Returns PICO_OK if connected to a USB 3.0 port.

PicoScope 4000 Series (A API) Programmer's Guide

Applicability

All devices

Arguments

handle, see ps4000aOpenUnit() * serial, see ps4000aOpenUnit()

resolution, an enumerated value of type PS4000A_DEVICE_RESOLUTION indicating

the number of bits of ADC resolution required from the scope device. If the device has fixed ADC resolution, this argument is ignored.

Returns

API functions

4.40 ps4000aOpenUnitWithResolution() – open a

flexible-resolution scope

PICO_STATUS ps4000aOpenUnitWithResolution

(

int16_t * handle, int8_t * serial, PS4000A_DEVICE_RESOLUTION resolution

)

This function is similar to ps4000aOpenUnit() but additionally sets the hardware ADC resolution of a flexible- resolution device.

PicoScope 4000 Series (A API) Programmer's Guide

Applicability

All modes

Arguments

handle, identifier for the scope device.

Returns

PICO_OK PICO_INVALID_HANDLE PICO_DRIVER_FUNCTION PICO_BUSY PICO_NOT_RESPONDING PICO_INTERNAL_ERROR PICO_TIMEOUT PICO_RESOURCE_ERROR PICO_DEVICE_NOT_FUNCTIONING PICO_USB3_0_DEVICE_NON_USB3_0_PORT PICO_POWER_SUPPLY_UNDERVOLTAGE PICO_POWER_SUPPLY_CONNECTED PICO_POWER_SUPPLY_NOT_CONNECTED

API functions

4.41 ps4000aPingUnit() – check that unit is responding

PICO_STATUS ps4000aPingUnit

(

int16_t handle

)

This function can be used to check that the already opened device is still connected to the USB port and communication is successful.

PicoScope 4000 Series (A API) Programmer's Guide

Applicability

Level and window trigger types

Arguments

handle, identifier for the scope device.

state, on exit, the value of the edge-detect flag:

0 : do not wait for a signal transition <> 0 : wait for a signal transition (default)

Returns

PICO_OK PICO_INVALID_HANDLE PICO_DRIVER_FUNCTION PICO_NULL_PARAMETER PICO_NOT_SUPPORTED_BY_THIS_DEVICE

API functions

4.42 ps4000aQueryOutputEdgeDetect() – query special

trigger mode

PICO_STATUS ps4000aQueryOutputEdgeDetect

(

int16_t handle, int16_t * state

)

This function obtains the state of the edge-detect flag, which is described in

ps4000aSetOutputEdgeDetect().

PicoScope 4000 Series (A API) Programmer's Guide

Applicability

Block mode and rapid block mode

Arguments

handle, identifier for the scope device.

noOfPreTriggerSamples, the number of samples to return before the trigger event. If no

trigger has been set, then this argument is added to noOfPostTriggerSamples to give the maximum number of data points (samples) to collect.

noOfPostTriggerSamples, the number of samples to return after the trigger event. If no

trigger event has been set, then this argument is added to noOfPreTriggerSamples to give the maximum number of data points to collect. If a trigger condition has been set, this specifies the number of data points to collect after a trigger has fired, and the number of data points to be collected is:

noOfPreTriggerSamples + noOfPostTriggerSamples

timebase, a number in the range 0 to 232–1. See the guide to calculating timebase values.

* timeIndisposedMs, on exit, the time, in milliseconds, that the scope will spend

collecting samples. This does not include any auto trigger timeout. If this pointer is null, nothing will be written here.

segmentIndex, zero-based, specifies which memory segment to use.

lpReady, a pointer to the ps4000aBlockReady() callback that the driver will call when

the data has been collected. To use the ps4000aIsReady() polling method instead of a callback function, set this pointer to NULL.

* pParameter, a void pointer that is passed to the ps4000aBlockReady() callback

function. The callback can use the pointer to return arbitrary data to your application.

Returns

PICO_OK PICO_INVALID_HANDLE PICO_USER_CALLBACK PICO_SEGMENT_OUT_OF_RANGE

API functions

4.43 ps4000aRunBlock() – start block mode

PICO_STATUS ps4000aRunBlock

(

int16_t handle, int32_t noOfPreTriggerSamples, int32_t noOfPostTriggerSamples, uint32_t timebase, int32_t * timeIndisposedMs, uint32_t segmentIndex,

ps4000aBlockReady lpReady,

void * pParameter

)

This function starts collecting data in block mode. For a step-by-step guide to this process, see Using block

mode.

The number of samples is determined by noOfPreTriggerSamples and noOfPostTriggerSamples (see below for details). The total number of samples must not be more than the memory depth of the segment referred to by segmentIndex.

PicoScope 4000 Series (A API) Programmer's Guide

PICO_INVALID_CHANNEL PICO_INVALID_TRIGGER_CHANNEL PICO_INVALID_CONDITION_CHANNEL PICO_TOO_MANY_SAMPLES PICO_INVALID_TIMEBASE PICO_NOT_RESPONDING PICO_CONFIG_FAIL PICO_INVALID_PARAMETER PICO_NOT_RESPONDING PICO_TRIGGER_ERROR PICO_NOT_USED_IN_THIS_CAPTURE_MODE PICO_TRIGGER_WITHIN_PRE_NOT_ALLOWED_WITH_DELAY PICO_INVALID_NUMBER_CHANNELS_FOR_RESOLUTION PICO_NOT_ENOUGH_SEGMENTS PICO_NO_TRIGGER_ENABLED_FOR_TRIGGER_IN_PRE_TRIG PICO_MEMORY_FAIL PICO_INTERNAL_ERROR PICO_TIMEOUT PICO_RESOURCE_ERROR PICO_DEVICE_NOT_FUNCTIONING PICO_USB3_0_DEVICE_NON_USB3_0_PORT PICO_POWER_SUPPLY_UNDERVOLTAGE PICO_POWER_SUPPLY_CONNECTED PICO_POWER_SUPPLY_NOT_CONNECTED PICO_WARNING_PROBE_CHANNEL_OUT_OF_SYNC

API functions

PicoScope 4000 Series (A API) Programmer's Guide

Applicability

Streaming mode only

Arguments

handle, identifier for the scope device.

* sampleInterval, on entry, the requested time interval between data points on entry; on

exit, the actual time interval assigned.

sampleIntervalTimeUnits, the unit of time that the sampleInterval is set to. See

ps4000aGetTriggerTimeOffset() for values.

maxPreTriggerSamples, the maximum number of raw samples before a trigger event

for each enabled channel.

maxPostTriggerSamples, the maximum number of raw samples after a trigger event for

each enabled channel.

autoStop, a flag to specify if the streaming should stop when all of maxPreTriggerSamples + maxPostTriggerSamples have been taken.

downSampleRatio, the number of raw values to each downsampled value.

downSampleRatioMode, the type of data reduction to use.

overviewBufferSize, the size of the overview buffers (the buffers passed by the

application to the driver). The size must be less than or equal to the bufferLth value passed to ps4000aSetDataBuffer().

API functions

4.44 ps4000aRunStreaming() – start streaming mode

PICO_STATUS ps4000aRunStreaming

(

int16_t handle, uint32_t * sampleInterval, PS4000A_TIME_UNITS sampleIntervalTimeUnits, uint32_t maxPreTriggerSamples, uint32_t maxPostTriggerSamples, int16_t autoStop, uint32_t downSampleRatio, PS4000A_RATIO_MODE downSampleRatioMode, uint32_t overviewBufferSize

)

This function tells the oscilloscope to start collecting data in streaming mode. When data has been collected from the device it is downsampled and the values returned to the application. Call

ps4000aGetStreamingLatestValues() to retrieve the data. See Using streaming mode for a step-by-step

guide to this process. This function always starts collecting data immediately, regardless of the trigger settings. Whether a trigger is set

or not, the total number of samples stored in the driver is always maxPreTriggerSamples +

maxPostTriggerSamples. If autoStop is false, the scope will collect data continuously, using the buffer as

a first-in first-out (FIFO) memory.

PicoScope 4000 Series (A API) Programmer's Guide

Returns

PICO_OK PICO_INVALID_HANDLE PICO_USER_CALLBACK PICO_NULL_PARAMETER PICO_INVALID_PARAMETER PICO_STREAMING_FAILED PICO_NOT_RESPONDING PICO_TRIGGER_ERROR PICO_INVALID_SAMPLE_INTERVAL PICO_INVALID_BUFFER PICO_USB3_0_DEVICE_NON_USB3_0_PORT PICO_POWER_SUPPLY_UNDERVOLTAGE PICO_POWER_SUPPLY_CONNECTED PICO_POWER_SUPPLY_NOT_CONNECTED PICO_TIMEOUT PICO_RESOURCE_ERROR PICO_DEVICE_NOT_FUNCTIONING PICO_NOT_USED_IN_THIS_CAPTURE_MODE PICO_INVALID_NUMBER_CHANNELS_FOR_RESOLUTION PICO_INTERNAL_ERROR PICO_MEMORY PICO_WARNING_PROBE_CHANNEL_OUT_OF_SYNC

API functions

PicoScope 4000 Series (A API) Programmer's Guide

Applicability

PicoScope 4444 only

Arguments

handle, identifier for the scope device.

channel, an enumerated type in the following range:

PS4000A_CHANNEL_A … PS4000A_CHANNEL_D

bandwidth, the required cutoff frequency of the filter. See ps4000aApi.h for allowable

values.

Returns

PICO_OK PICO_USER_CALLBACK PICO_INVALID_HANDLE PICO_INVALID_CHANNEL PICO_NOT_USED (if the device does not have a bandwidth limiter) PICO_BUSY PICO_ARGUMENT_OUT_OF_RANGE PICO_INVALID_BANDWIDTH

4.45 ps4000aSetBandwidthFilter() – enable the

bandwidth limiter

PICO_STATUS ps4000aSetBandwidthFilter

(

int16_t handle, PS4000A_CHANNEL channel, PS4000A_BANDWIDTH_LIMITER bandwidth

)

This function sets up the bandwidth limiter filter, if one is available on the selected device.

API functions

PicoScope 4000 Series (A API) Programmer's Guide

Applicability

PicoScope 4444 only

Arguments

handle, identifier for the scope device.

pinStates, the desired state of the CAL pins:

PS4000A_CAL_PINS_OFF (0)

0 volts on both pins

PS4000A_GND_SIGNAL (1)

0 volts on CAL – pin, test signal on CAL + pin

PS4000A_SIGNAL_SIGNAL (2)

same test signal on both pins

waveType, as defined in ps4000aApi.h. Only the following types are allowed:

PS4000A_SINE PS4000A_SQUARE PS4000A_DC_VOLTAGE

frequency, the signal repetition frequency in hertz. Range [100, 10 000] for PS4000A_SQUARE, [100, 100 000] for PS4000A_SINE. Value ignored for PS4000A_DC_VOLTAGE.

amplitude, the signal amplitude in microvolts. Range [0, 8 000 000]. Value ignored for PS4000A_DC_VOLTAGE.

offset, the signal offset in microvolts. Range [–4 000 000, +4 000 000]. If offset is

zero, the signal range is [0 V, amplitude]. If the total of offset ± amplitude exceeds the range [–4 000 000, +4 000 000], the output will be clipped.

Returns

PICO_OK PICO_INVALID_HANDLE PICO_DRIVER_FUNCTION PICO_NOT_SUPPORTED_BY_THIS_DEVICE PICO_CAL_PINS_WAVETYPE PICO_TIMEOUT PICO_RESOURCE_ERROR PICO_DEVICE_NOT_FUNCTIONING PICO_NOT_RESPONDING

API functions

4.46 ps4000aSetCalibrationPins() – set up the CAL

output pins

PICO_STATUS ps4000aSetCalibrationPins

(

int16_t handle, PS4000A_PIN_STATES pinStates, PS4000A_WAVE_TYPE waveType, double frequency, uint32_t amplitude, uint32_t offset

)

This function sets up the CAL pins on the back of the PicoScope 4444 differential oscilloscope. These pins can generate test signals for use when compensating scope probes.

PicoScope 4000 Series (A API) Programmer's Guide

Applicability

All modes

Arguments

handle, identifier for the scope device.

channel, the channel to be configured. The allowable values are:

PS4000A_CHANNEL_A … PS4000A_CHANNEL_B (PicoScope 4224A) PS4000A_CHANNEL_A … PS4000A_CHANNEL_D (PicoScope 4424A and 4444) PS4000A_CHANNEL_A … PS4000A_CHANNEL_H (PicoScope 4824A and 4824)

enabled, specifies if the channel is active (TRUE) or inactive (FALSE).

type, specifies the coupling mode: DC (TRUE) or AC (FALSE).

range, specifies the measuring range. This is defined differently depending on the

oscilloscope.

PicoScope 4444: the measuring ranges are defined in PicoConnectProbes.h. Refer to the PICO_CONNECT_PROBE_RANGE enumeration (ps4000aProbeInteractions()) for the list, which is specific to each probe. PicoScope 4824: Measuring ranges 0 to 13, defined ps4000aApi.h, are shown in the

table below.

analogOffset, an offset, in volts, to be added to the input signal before it reaches the

input amplifier and digitizer. See the device data sheet for the allowable range.

Returns

PICO_OK PICO_USER_CALLBACK PICO_INVALID_HANDLE PICO_INVALID_CHANNEL PICO_INVALID_VOLTAGE_RANGE PICO_DRIVER_FUNCTION PICO_INVALID_COUPLING PICO_INVALID_ANALOGUE_OFFSET PICO_WARNING_PROBE_CHANNEL_OUT_OF_SYNC

Indicates that the channel configuration is not applicable to the PicoConnect probe in use. Check the most recent probe notification (received via callback) and apply a range appropriate to your probe.

PICO_PROBE_NOT_POWERED_WITH_DC_POWER_SUPPLY PICO_PROBE_POWER_DC_POWER_SUPPLY_REQUIRED

4.47 ps4000aSetChannel() – set up input channels

PICO_STATUS ps4000aSetChannel

(

int16_t handle, PS4000A_CHANNEL channel, int16_t enabled, PS4000A_COUPLING type, PICO_CONNECT_PROBE_RANGE range, float analogOffset

)

This function sets up the characteristics of the specified input channel.

API functions

PicoScope 4000 Series (A API) Programmer's Guide

range

Voltage range

PICO_X1_PROBE_10MV

±10 mV

PICO_X1_PROBE_20MV

±20 mV

PICO_X1_PROBE_50MV

±50 mV

PICO_X1_PROBE_100MV

±100 mV

PICO_X1_PROBE_200MV

±200 mV

PICO_X1_PROBE_500MV

±500 mV

PICO_X1_PROBE_1V

±1 V

PICO_X1_PROBE_2V

±2 V

PICO_X1_PROBE_5V

±5 V

PICO_X1_PROBE_10V

±10 V

PICO_X1_PROBE_20V

±20 V

PICO_X1_PROBE_50V

±50 V

PICO_X1_PROBE_100V

±100 V

PICO_X1_PROBE_200V

±200 V

API functions

PicoScope 4000 Series (A API) Programmer's Guide

Applicability

All sampling modes.

Non-aggregated data only. For aggregated data, use ps4000aSetDataBuffers().

Arguments

handle, identifier for the scope device.

channel, the channel for which you want to set the buffers. See ps4000aSetChannel()

for allowable values.

* buffer, a buffer to receive the data values. Each value is a 16-bit ADC count scaled

according to the selected voltage range.

bufferLth, the size of the buffer array.

segmentIndex, the number of the memory segment to be retrieved.

mode, the type of data reduction to use. See Downsampling for options.

Returns

PICO_OK PICO_INVALID_HANDLE PICO_INVALID_CHANNEL PICO_DRIVER_FUNCTION PICO_RATIO_MODE_NOT_SUPPORTED PICO_INVALID_PARAMETER

API functions

4.48 ps4000aSetDataBuffer() – register data buffer with

driver

PICO_STATUS ps4000aSetDataBuffer

(

int16_t handle, PS4000A_CHANNEL channel, int16_t * buffer, int32_t bufferLth, uint32_t segmentIndex, PS4000A_RATIO_MODE mode

)

This function registers your data buffer, for non-aggregated data, with the ps4000a driver. You need to allocate the buffer before calling this function.

PicoScope 4000 Series (A API) Programmer's Guide

Applicability

All sampling modes. All downsampling modes. For non-aggregated data, the simpler

ps4000aSetDataBuffer() can be used instead.

Arguments

handle, identifier for the scope device.

channel, the channel for which you want to set the buffers. See ps4000aSetChannel()

for allowable values.

* bufferMax, a user-allocated buffer to receive the maximum data values in aggregation

mode, or the non-aggregated values otherwise. Each value is a 16-bit ADC count scaled according to the selected voltage range.

* bufferMin, a user-allocated buffer to receive the minimum data values in aggregation

mode. Not normally used in other modes, but you can direct the driver to write non-aggregated values to this buffer by setting bufferMax to NULL. To enable aggregation, the downsampling ratio and mode must be set appropriately when calling one of the

ps4000aGetValues...() functions.

bufferLth, specifies the size of the bufferMax and bufferMin arrays.

segmentIndex, the number of the memory segment to be retrieved.

mode, the type of downsampling to use. See Downsampling.

Returns

PICO_OK PICO_INVALID_HANDLE PICO_INVALID_CHANNEL PICO_DRIVER_FUNCTION PICO_RATIO_MODE_NOT_SUPPORTED PICO_INVALID_PARAMETER

API functions

4.49 ps4000aSetDataBuffers() – register min/max data

buffers with driver

PICO_STATUS ps4000aSetDataBuffers

(

int16_t handle, PS4000A_CHANNEL channel, int16_t * bufferMax, int16_t * bufferMin, int32_t bufferLth, uint32_t segmentIndex, PS4000A_RATIO_MODE mode

)

This function registers your data buffers, for receiving aggregated data, with the ps4000a driver. You need to allocate memory for the buffers before calling this function.

PicoScope 4000 Series (A API) Programmer's Guide

Applicability

PicoScope 4444 only

Arguments

handle, identifier for the scope device.

resolution, determines the resolution of the device when opened. This is chosen from

the available values of PS4000A_DEVICE_RESOLUTION. If resolution is out of range the device will return PICO_INVALID_DEVICE_RESOLUTION.

Returns

PICO_OK PICO_INVALID_DEVICE_RESOLUTION PICO_OS_NOT_SUPPORTED PICO_OPEN_OPERATION_IN_PROGRESS PICO_EEPROM_CORRUPT PICO_KERNEL_DRIVER_TOO_OLD PICO_FPGA_FAIL PICO_MEMORY_CLOCK_FREQUENCY PICO_FW_FAIL PICO_MAX_UNITS_OPENED PICO_NOT_FOUND (if the specified unit was not found) PICO_NOT_RESPONDING PICO_MEMORY_FAIL PICO_ANALOG_BOARD PICO_CONFIG_FAIL_AWG PICO_INITIALISE_FPGA PICO_POWER_SUPPLY_NOT_CONNECTED PICO_USB3_0_DEVICE_NON_USB3_0_PORT PICO_POWER_SUPPLY_UNDERVOLTAGE PICO_POWER_SUPPLY_CONNECTED PICO_TIMEOUT PICO_RESOURCE_ERROR PICO_DEVICE_NOT_FUNCTIONING

API functions

4.50 ps4000aSetDeviceResolution() – set up a FlexRes

scope

PICO_STATUS ps4000aSetDeviceResolution

(

int16_t handle,

PS4000A_DEVICE_RESOLUTION resolution

)

This function sets the ADC resolution. Increasing the resolution affects other properties such as the maximum sampling rate and analog bandwidth. When the resolution is changed, any data captured that has not been saved

will be lost. If ps4000aSetChannel() is not called, ps4000aRunBlock() and ps4000aRunStreaming() may fail.

PicoScope 4000 Series (A API) Programmer's Guide

Applicability

Not implemented

Arguments

handle, identifier for the scope device.

Returns

PICO_ETS_NOT_SUPPORTED PICO_DRIVER_FUNCTION PICO_INVALID_HANDLE

API functions

4.51 ps4000aSetEts() – set up equivalent-time sampling

(ETS)

PICO_STATUS ps4000aSetEts

(

int16_t handle, PS4000A_ETS_MODE mode, int16_t etsCycles, int16_t etsInterleave, int32_t * sampleTimePicoseconds

)

This function is reserved for future use.

PicoScope 4000 Series (A API) Programmer's Guide

Applicability

Not implemented

Arguments

handle, identifier for the scope device.

Returns

PICO_ETS_NOT_SUPPORTED PICO_DRIVER_FUNCTION PICO_INVALID_HANDLE

API functions

4.52 ps4000aSetEtsTimeBuffer() – set up 64-bit buffer for

ETS time data

PICO_STATUS ps4000aSetEtsTimeBuffer

(

int16_t handle, int64_t * buffer, int32_t bufferLth

)

Reserved for future use.

PicoScope 4000 Series (A API) Programmer's Guide

Applicability

Not implemented

Arguments

handle, identifier for the scope device.

Returns

PICO_ETS_NOT_SUPPORTED PICO_DRIVER_FUNCTION PICO_INVALID_HANDLE

API functions

4.53 ps4000aSetEtsTimeBuffers() – set up 32-bit buffers

for ETS time data

PICO_STATUS ps4000aSetEtsTimeBuffers

(

int16_t handle, uint32_t * timeUpper, uint32_t * timeLower, int32_t bufferLth

)

This function is reserved for future use.

PicoScope 4000 Series (A API) Programmer's Guide

Applicability

Rapid block mode

Arguments

handle, identifier for the scope device.

nCaptures, the number of waveforms to be captured in one run.

Returns

PICO_OK PICO_INVALID_HANDLE PICO_INVALID_PARAMETER PICO_DRIVER_FUNCTION PICO_MEMORY_FAIL PICO_INTERNAL_ERROR

API functions

4.54 ps4000aSetNoOfCaptures() – set number of rapid

block captures

PICO_STATUS ps4000aSetNoOfCaptures

(

int16_t handle, uint32_t nCaptures

)

This function sets the number of captures to be collected in one run of rapid block mode. If you do not call this function before a run, the driver will capture one waveform.

PicoScope 4000 Series (A API) Programmer's Guide

Applicability

Level and window trigger types

Arguments

handle, identifier for the scope device. state, a flag that specifies the trigger behavior:

0 : do not wait for a signal transition <> 0 : wait for a signal transition (default)

Returns

PICO_OK PICO_INVALID_HANDLE PICO_DRIVER_FUNCTION

API functions

4.55 ps4000aSetOutputEdgeDetect() – set special trigger

mode

PICO_STATUS ps4000aSetOutputEdgeDetect

(

int16_t handle, int16_t state

)

This function tells the device whether or not to wait for an edge on the trigger input when one of the 'level' or 'window' trigger types is in use. By default the device waits for an edge on the trigger input before firing the trigger. If you switch off edge detect mode, the device will trigger continually for as long as the trigger input remains in the specified state.

You can query the state of this flag by calling ps4000aQueryOutputEdgeDetect().

PicoScope 4000 Series (A API) Programmer's Guide

Applicability

PicoScope 4444 only

Arguments

handle, identifier for the scope device.

callback, a pointer to your callback function.

Returns

PICO_OK

API functions

4.56 ps4000aSetProbeInteractionCallback() – register

callback function for PicoConnect events

PICO_STATUS ps4000aSetProbeInteractionCallback

(

int16_t handle, ps4000aProbeInteractions callback

)

This function registers your ps4000aProbeInteractions() callback function with the ps4000a driver. The driver will then call your function whenever a PicoConnect™ probe is plugged into, or unplugged from, a PicoScope 4444 device, or if the power consumption of the connected probes exceeds the power available. See Handling

PicoConnect probe interactions for more information on this process.

You should call this function as soon as the device has been successfully opened and before any call to

ps4000aSetChannel().

PicoScope 4000 Series (A API) Programmer's Guide

Applicability

All modes

Arguments

handle, identifier for the scope device.

* conditions: see ps4000aSetTriggerChannelConditions() nConditions: see ps4000aSetTriggerChannelConditions() info: see ps4000aSetTriggerChannelConditions()

Returns

PICO_OK PICO_INVALID_HANDLE PICO_USER_CALLBACK PICO_CONDITIONS PICO_PULSE_WIDTH_QUALIFIER PICO_DRIVER_FUNCTION PICO_INVALID_CONDITION_INFO PICO_INVALID_PARAMETER PICO_DUPLICATE_CONDITION_SOURCE PICO_MEMORY_FAIL PICO_INTERNAL_ERROR PICO_TOO_MANY_CHANNELS_IN_USE

API functions

4.57 ps4000aSetPulseWidthQualifierConditions() – set

up pulse width triggering

PICO_STATUS ps4000aSetPulseWidthQualifierConditions

(

int16_t handle,

PS4000A_CONDITION * conditions,

int16_t nConditions, PS4000A_CONDITIONS_INFO info

)

This function sets up the conditions for pulse width qualification, which is used with either threshold triggering, level triggering or window triggering to produce time-qualified triggers. Each call to this function creates a pulse

width qualifier equal to the logical AND of the elements of the conditions array. Calling this function multiple times creates the logical OR of multiple AND operations. This AND-OR logic allows you to create any possible Boolean function of the scope's inputs.

To cease ORing pulse width qualifier conditions and start again with a new set, call with

info = PS4000A_CLEAR.

Other settings of the pulse width qualifier are configured by calling

ps4000aSetPulseWidthQualifierProperties().

Note: The oscilloscope contains a single pulse-width counter. It is possible to include multiple channels in a pulse-width qualifier but the same pulse-width counter will apply to all of them. The counter starts when your selected trigger condition occurs, and the scope then triggers if the trigger condition ends after a time that satisfies the pulse-width condition.

PicoScope 4000 Series (A API) Programmer's Guide

Applicability

All modes

Arguments

handle, identifier for the scope device.

direction, the direction of the signal required for the trigger to fire. See

PS4000A_DIRECTION for allowable values. This is also the direction that resets and starts

the counter.

lower, the lower limit of the pulse width counter, in samples.

upper, the upper limit of the pulse width counter, in samples. This parameter is used only

when the type is set to PW_TYPE_IN_RANGE or PW_TYPE_OUT_OF_RANGE.

type, the pulse width type, one of these constants:

PW_TYPE_NONE (do not use the pulse width qualifier) PW_TYPE_LESS_THAN (pulse width less than lower) PW_TYPE_GREATER_THAN (pulse width greater than lower) PW_TYPE_IN_RANGE (pulse width between lower and upper) PW_TYPE_OUT_OF_RANGE (pulse width not between lower and upper)

Returns

PICO_OK PICO_INVALID_HANDLE PICO_USER_CALLBACK PICO_CONDITIONS PICO_PULSE_WIDTH_QUALIFIER PICO_DRIVER_FUNCTION PICO_MEMORY_FAIL PICO_INTERNAL_ERROR

API functions

4.58 ps4000aSetPulseWidthQualifierProperties() – set up

pulse width triggering

PICO_STATUS ps4000aSetPulseWidthQualifierProperties

(

int16_t handle, PS4000A_THRESHOLD_DIRECTION direction, uint32_t lower, uint32_t upper, PS4000A_PULSE_WIDTH_TYPE type

)

This function configures the general properties of the pulse width qualifier.

PicoScope 4000 Series (A API) Programmer's Guide

Applicability

All modes. PicoScope 4824 and 4000A Series only.

Arguments

handle, identifier for the scope device.

offsetVoltage, the voltage offset, in microvolts, to be applied to the waveform.

pkToPk, the peak-to-peak voltage, in microvolts, of the waveform signal.

startDeltaPhase, the initial value added to the phase counter as the generator begins to step through the

waveform buffer. Call ps4000aSigGenFrequencyToPhase() to calculate this.

4.59 ps4000aSetSigGenArbitrary() – set up arbitrary

waveform generator

PICO_STATUS ps4000aSetSigGenArbitrary

(

int16_t handle, int32_t offsetVoltage, // see note 1 uint32_t pkToPk, // see note 1 uint32_t startDeltaPhase, uint32_t stopDeltaPhase, uint32_t deltaPhaseIncrement, uint32_t dwellCount, int16_t * arbitraryWaveform, // see note 1 int32_t arbitraryWaveformSize, // see note 1 PS4000A_SWEEP_TYPE sweepType, PS4000A_EXTRA_OPERATIONS operation, // see note 1 PS4000A_INDEX_MODE indexMode, uint32_t shots, uint32_t sweeps, PS4000A_SIGGEN_TRIG_TYPE triggerType, PS4000A_SIGGEN_TRIG_SOURCE triggerSource, int16_t extInThreshold

)

API functions

This function programs the signal generator to produce an arbitrary waveform.

The arbitrary waveform generator (AWG) uses direct digital synthesis (DDS). It maintains a 32-bit phase accumulator that indicates the present location in the waveform. The top bits of the phase accumulator are used as an index into a buffer containing the arbitrary waveform. The remaining bits act as the fractional part of the index, enabling high-resolution control of output frequency and allowing the generation of lower frequencies.

Note 1: in general, this function can be called with new arguments while waiting for a trigger; the exceptions are the arguments noted above, which must be unchanged on subsequent calls, otherwise the function will return

PICO_BUSY.

Note 2: call this function before starting data acquisition, even if the signal generator will be triggered during data collection.

Note 3: for more information about using this function, read the article Triggering a PicoScope signal generator

using the PicoScope API functions.

PicoScope 4000 Series (A API) Programmer's Guide

stopDeltaPhase, the final value added to the phase counter before the generator restarts or reverses the

sweep. If required, call ps4000aSigGenFrequencyToPhase() to calculate it. When frequency sweeping is not required, set equal to startDeltaPhase.

deltaPhaseIncrement, the amount added to the delta phase value every time the dwellCount period

expires. This determines the amount by which the generator sweeps the output frequency in each dwell period. When frequency sweeping is not required, set to zero.

dwellCount, the time, in multiples of dacPeriod, between successive additions of deltaPhaseIncrement to the delta phase counter. This determines the rate at which the generator sweeps

the output frequency. Minimum allowable values are as follows:

PicoScope 4824:

MIN_DWELL_COUNT

* arbitraryWaveform, a buffer that holds the waveform pattern as a set of samples equally spaced in

time. Call ps4000aSigGenArbitraryMinMaxValues() to obtain the range of allowable values, or use these constants:

PicoScope 4824:

[–32768, 32767]

arbitraryWaveformSize, the size of the arbitrary waveform buffer, in samples. Call

ps4000aSigGenArbitraryMinMaxValues() to obtain the range of allowable values, or use these

constants:

PicoScope 4824:

PS4000A_MIN_SIG_GEN_BUFFER_SIZE (10) PS4000A_MAX_SIG_GEN_BUFFER_SIZE (16384)

sweepType, determines whether the startDeltaPhase is swept up to the stopDeltaPhase, or down to

it, or repeatedly up and down. Use one of the following values: UP, DOWN, UPDOWN, DOWNUP.

operation, configures the white noise/PRBS (pseudo-random binary sequence) generator:

PS4000A_ES_OFF:

White noise/PRBS output disabled. The waveform is defined by the other arguments.

PS4000A_WHITENOISE:

The signal generator produces white noise and ignores all settings except

offsetVoltage and pkTopk.

PS4000A_PRBS:

The signal generator produces a PRBS.

indexMode, specifies how the signal will be formed from the arbitrary waveform data. SINGLE, DUAL and QUAD index modes are possible (see AWG index modes).

shots, the number of cycles of the waveform to be produced after a trigger event. If this is set to a non-zero

value [1, MAX_SWEEPS_SHOTS], then sweeps must be set to zero.

sweeps, the number of times to sweep the frequency after a trigger event, according to sweepType. If this is

set to a non-zero value [1, MAX_SWEEPS_SHOTS], then shots must be set to zero.

triggerType, the type of trigger that will be applied to the signal generator:

PS4000A_SIGGEN_RISING:

rising edge

PS4000A_SIGGEN_FALLING:

falling edge

PS4000A_SIGGEN_GATE_HIGH:

high level

PS4000A_SIGGEN_GATE_LOW:

low level

triggerSource, the source that will trigger the signal generator:

PS4000A_SIGGEN_NONE:

no trigger (free-running)

PS4000A_SIGGEN_SCOPE_TRIG:

the selected oscilloscope channel (see

ps4000aSetSimpleTrigger())

PS4000A_SIGGEN_SOFT_TRIG:

a software trigger (see ps4000aSigGenSoftwareControl())

API functions

PicoScope 4000 Series (A API) Programmer's Guide

If a trigger source other than PS4000A_SIGGEN_NONE is specified, then either shots or sweeps, but not both, must be set to a non-zero value.

extInThreshold, not used

Returns

PICO_INVALID_HANDLE PICO_DRIVER_FUNCTION PICO_NO_SIGNAL_GENERATOR PICO_USB3_0_DEVICE_NON_USB3_0_PORT PICO_MEMORY_FAIL PICO_INTERNAL_ERROR PICO_SIG_GEN_PARAM PICO_NULL_PARAMETER PICO_SIGGEN_OFFSET_VOLTAGE PICO_SIGGEN_PK_TO_PK PICO_SIGGEN_OUTPUT_OVER_VOLTAGE PICO_SHOTS_SWEEPS_WARNING PICO_BUSY PICO_TIMEOUT PICO_RESOURCE_ERROR PICO_DEVICE_NOT_FUNCTIONING PICO_NOT_RESPONDING

API functions

PicoScope 4000 Series (A API) Programmer's Guide

SINGLE mode. The generator outputs the raw contents

of the buffer repeatedly. This mode is the only one that can generate asymmetrical waveforms. You can also use this mode for symmetrical waveforms, but the dual and quad modes make more efficient use of the buffer memory.

DUAL mode. The generator outputs the contents of the

buffer from beginning to end, and then does a second pass in the reverse direction through the buffer. This allows you to specify only the first half of a waveform with twofold symmetry, such as a Gaussian function, and let the generator fill in the other half.

QUAD mode. The generator outputs the contents of the

buffer, then on its second pass through the buffer outputs the same data in reverse order as in dual mode. On the third and fourth passes it does the same but with a negative version of the data. This allows you to specify only the first quarter of a waveform with fourfold symmetry, such as a sine wave, and let the generator fill in the other three quarters.

outputFrequency

repetition rate of the complete arbitrary waveform

dacFrequency

update rate of AWG DAC (see table below)

deltaPhase

calculated from startDeltaPhase and deltaPhaseIncrement

phaseAccumulatorSize

maximum count of phase accumulator (see table below)

awgBufferSize

maximum AWG buffer size (see table below)

arbitraryWaveformSize

length in samples of the user-defined waveform

API functions

4.59.1 AWG index modes

The arbitrary waveform generator supports SINGLE, DUAL and QUAD index modes to make the best use of the waveform buffer.

4.59.2 Calculating deltaPhase

The arbitrary waveform generator steps through the waveform by adding a deltaPhase value between 1 and phaseAccumulatorSize-1 to the phase accumulator every dacPeriod (1/dacFrequency). If deltaPhase is constant, the generator produces a waveform at a constant frequency that can be calculated as follows:

where:

You can call ps4000aSigGenFrequencyToPhase() to calculate deltaPhase.

PicoScope 4000 Series (A API) Programmer's Guide

Parameter

PicoScope 4824 and 4000A Series

dacFrequency

80 MHz

dacPeriod (= 1/dacFrequency)

12.5 ns

phaseAccumulatorSize

4 294 967 296 (232)

awgBufferSize

16 384 (214)

API functions

It is also possible to sweep the frequency by continually modifying the deltaPhase. This is done by setting up a deltaPhaseIncrement that the oscilloscope adds to the deltaPhase at specified intervals.

PicoScope 4000 Series (A API) Programmer's Guide

Applicability

All modes. PicoScope 4824 and 4000A Series only.

Arguments

handle, identifier for the scope device.

offsetVoltage, the voltage offset, in microvolts, to be applied to the waveform.

pkToPk, the peak-to-peak voltage, in microvolts, of the waveform signal.

4.60 ps4000aSetSigGenBuiltIn() – set up function

generator

PICO_STATUS ps4000aSetSigGenBuiltIn

(

int16_t handle, int32_t offsetVoltage, // see note 1 uint32_t pkToPk, // see note 1 PS4000A_WAVE_TYPE waveType, // see note 1 double startFrequency, double stopFrequency, double increment, double dwellTime, PS4000A_SWEEP_TYPE sweepType, PS4000A_EXTRA_OPERATIONS operation, // see note 1 uint32_t shots, uint32_t sweeps, PS4000A_SIGGEN_TRIG_TYPE triggerType, PS4000A_SIGGEN_TRIG_SOURCE triggerSource, int16_t extInThreshold

)

API functions

This function sets up the signal generator to produce a signal from a list of built-in waveforms. If different start and stop frequencies are specified, the oscilloscope will sweep either up, down or up and down.

Note 1: in general, this function can be called with new arguments while waiting for a trigger; the exceptions are the arguments offsetVoltage, pkToPk, arbitraryWaveform, arbitraryWaveformSize and

operation, which must be unchanged on subsequent calls, otherwise the function will return a PICO_BUSY

status code. Note 2: call this function before starting data acquisition, even if the signal generator will be triggered during data

collection. Note 3: for more information about using this function, read the article Triggering a PicoScope signal generator

using the PicoScope API functions.

PICO PS 4224A Instructions

Specifications and Main Features

Frequently Asked Questions

User Manual

Welcome

Introduction

2.1 License agreement

2.2 Trademarks

2.3 System requirements

2.4 Installation instructions

Programming with the ps4000a API

3.1 Driver

3.2 Voltage ranges

3.3 Channel selection

3.4 Triggering

3.5 Downsampling

3.6 Sampling modes

3.6.1 Block mode

3.6.1.1 Using block mode

3.6.1.2 Asynchronous calls in block mode

Rapid block mode allows you to sample several waveforms at a time with the minimum time between waveforms. On the PicoScope 4824, for example, it reduces the gap from milliseconds to about 2.5 µs.

3.6.2.1 Using rapid block mode

3.6.2.2 Rapid block mode example 1: no aggregation

3.6.2.3 Rapid block mode example 2: using aggregation

3.6.3 Streaming mode

3.6.3.1 Using streaming mode

3.6.4 Retrieving stored data

3.7 Timebases

3.8 Combining several oscilloscopes

3.9 Handling PicoConnect probe interactions

API functions

4.2 ps4000aCloseUnit() – close a scope device

4.5 ps4000aFlashLed() – flash the front-panel LED

4.21 ps4000aGetValues() – retrieve block-mode data

4.24.1 Using the GetValuesOverlapped functions

4.28 ps4000aIsLedFlashing() – read status of LED

4.29 ps4000aIsReady() – poll the driver in block mode

4.36 ps4000aOpenUnit() – open a scope device

4.41 ps4000aPingUnit() – check that unit is responding

4.43 ps4000aRunBlock() – start block mode

4.44 ps4000aRunStreaming() – start streaming mode

4.47 ps4000aSetChannel() – set up input channels

4.59.1 AWG index modes

4.59.2 Calculating deltaPhase
