Pico Mixer User Manual

PICO

MIXER

Thank you for purchasing Erica Synths Pico Series module!

With Pico Series we challenged ourselves – can we make ANY
superior functionality synth module 3HP wide and affordable?

Erica Pico Mixer is simple 3 channel DC coupled mixer
intended to mix AUDIO SIGNALS AND CV SIGNALS
in order to obtain complex modulations.
Also it may serve as CV AND AUDIO attenuator.

3 inputs
Diode protection against overvoltage

FEATURESTECHNICAL SPECS

Mixer gain 1
Power consumption +4mA, -4mA
Module width 3HP
Module depth 35mm

PICO

MIXER

MIXER

Adjust CV OR AUDIO input levels
for each channel

IN1 LVL

IN2 LVL

IN3 LVL

IN1

IN2

IN3

OUT

PICO

Patch CV OR AUDIO signals here

This is mixer output
