016-660
TABLE OF CONTENTS
Features ...............................................................................2
Introduction ........................................................................... 3
Advantages of temporal artery (T.A.) temperature ...............4
Safety precautions ................................................................ 5
Important notes.....................................................................6
Appearance, conguration and menu functions ................... 7
• Choosing the temperature unit of measure
• Audio alert set-up
• Choice of default display mode:
body or surface temperature
• How to calibrate the thermometer
• Audio ON/OFF
• Exiting the setting mode
Data memory ........................................................................ 12
Direct selection buttons ........................................................ 13
Changing batteries ...............................................................13
How to measure temperature ............................................... 14
Specications .......................................................................15
Troubleshooting .................................................................... 16
1
FEATURES
•
Non-contact thermometer
•
Instant readings (1 second)
•
Professional accuracy and reliability
•
Easy to use
•
Multi-usage: body, surface and air
•
Programmable alerts
•
3 languages + silent mode for taking temperature
when child is sleeping
•
Large backlit screen for nighttime readings
•
3 colour fever alerts
•
Audio alerts signal peak temperature and fever
•
Stores last 32 temperature readings
•
Displays in °C or °F
•
Auto shut-off conserves battery
•
Longevity: 40,000 readings
•
2 year warranty
•
2 AA batteries included
2
INTRODUCTION
Congratulations, you now own the ProScanTM Non-Contact
Infrared Thermometer, our latest infrared technology.
This innovative technology allows temporal artery (T.A.) temperature to be taken at a distance of about 3 cm - 5 cm away
from the forehead. It has been demonstrated that this method
of T.A. temperature reading is more precise than the tympanic
thermometry and better tolerated than rectal thermometry
This means accurate, reliable and safe readings in an instant.
As with any thermometer, it is essential to use the ProScan
Non-Contact properly to ensure accurate temperatures.
Please read these instructions carefully before using
this product and keep the instructions and your
ProScanTM thermometer in a safe place.
1
Greenes D, Fleisher G. Accuracy of a Noninvasive Temporal Artery Thermometer
for Use in Infants, Arch Pediatr Adolesc Med 2001; 155:376.
2
Allegaert, Casteels, van Gorp, Bogaert, Tympanic, infrared skin, and temporal
artery scan thermometers compared with rectal measurement in children:
a real-life assessment. Curr Ther Res Clin Exp. 2014 May 8;76:34-8. doi:
10.1016/j.curtheres.2013.11.005.eCollection 2014.
1,2
.
TM
3
ADVANTAGES OF TEMPORAL ARTERY (T.A.)
TEMPERATURE
The ProScanTM Non-Contact thermometer has been designed
to produce an instant forehead temperature reading without
any contact with the temporal artery. As this artery is quite
close to the surface of the forehead skin, it allows precise
reading of temperature. This artery is linked to the heart by
the carotid artery which is directly linked to the aorta. It forms
part of the main trunk of arterial system. The efciency, speed
and comfort of taking a temperature from this area make it
ideal compared to other temperature reading methods.
4
SAFETY PRECAUTIONS
• This device may be used for professional purposes or for
personal home use. It must only be used for the purposes
described in this instruction manual.
• This device must only be used in an ambient temperature range
of between 10°C and 40°C. Do not expose this thermometer
to extreme temperature conditions of > 50°C or < -20°C.
• This device must always be kept in a clean, dry place.
• Do not drop the thermometer. Protect it from severe impact
and shock.
• Do not expose the thermometer to sunlight or to water.
• Do not use this device in relative humidity higher than 85%.
• The protective glass over the lens is the most fragile part of
the thermometer. Do not touch the glass with your ngers.
• Clean the glass with a cotton swab lightly moistened with
95% alcohol. Never use abrasive cleaning agents.
• Never use rechargeable batteries.
• Remove the batteries when thermometer is not used for
an extended period of time to conserve battery life.
• Infrared thermometers should not be used on children under
2 years of age. For older children infrared thermometers
should not be used to manage important health concerns.
• Use of this thermometer is not intended as a substitute for
consultation with your healthcare professional.
• Infrared thermometers should not be used shortly
after exercise, bathing or coming indoors.
• Do not disassemble to thermometer. Do not attempt to repair
this device yourself. Should a problem occur, please contact
A.M.G. Medical Customer Service.
• This thermometer should only be used under the supervision
of an adult.
• Keep batteries out of reach of children.
5
IMPORTANT NOTES
• This thermometer is calibrated and ready to use.
• The reliability of the reading cannot be guaranteed if the
body temperature is measured over any part of the body
that is not the forehead temporal region.
• Body temperature increases by 0.5°C between 6:00 AM
and 3:00 PM.
• Women have a temperature that is higher, on average, by
around 0.2°C. Their temperature also varies in accordance
with their ovarian cycle. It rises by 0.5°C in the second half
of the cycle and at the early stages of pregnancy.
• When sitting, body temperature is lower by about 0.3°C
to 0.4°C then when standing.
Age Range Normal body Fever High Fever Application
Temperature Used
24 - 36 months* 35.9°C - 38.0°C 38.1°C - 39.0°C > 39.0°C Rectal
(96.6°F - 100.5°F) (100.6°F - 102.2°F) (> 102.2°F)
> 3 years* 35.4°C - 37.7°C 37.8°C - 39.4°C ≥ 39.5°C Rectal
(95.7°F - 99.9°F) (100.0°F - 103.0°F) (≥ 103.1°F)
11 - 65 years** 35.9°C - 37.6°C ≥ 37.7°C Rectal
(96.6°F - 99.7°F) (≥ 99.8°F)
> 65 years** 35.8°C - 37.5°C ≥ 37.6°C Rectal
(96.4°F - 99.5°F) (≥ 99.6°F)
*Herzog L, Phillips S. Addressing Concerns About Fever.
Clinical Pediatrics. 2011; 50(#5) 383-390.
** Private eld study, for information purposes only.
6
APPEARANCE, CONFIGURATION
AND MENU FUNCTIONS
Choosing the Temperature Unit of Measure
Note: ProScanTM Non-Contact default is °C.
1. Press on the ‟ PROG. ” button
for 3 seconds, the screen
displays F1.
2. Select ‟ - ” for °C or ‟ + ” for °F.
3. Conrm by pressing on the
‟ PROG. ” button.
7
Audio Alert Set-up
Note: The audio alert threshold default value is 38°C (100.4°F) and is for body
and surface temperature only. If the audio alerts threshold default settings are
changed, only the audio alerts will be pertinent, not the colour alerts.
1. Press on the ‟ PROG. ” button
for 3 seconds, the screen
displays F1.
2. Press once more on the
‟ PROG. ” button to get F2.
3. Select ‟ + ” to increase
the threshold by 0.1°C
(0.1°F), ‟ - ” to reduce it
by 0.1°C (0.1°F).
4. Conrm by pressing on the
‟ PROG. ” button.
8
Choice of Default Display Mode:
Body or Surface Temperature
Note: The ProScanTM Non-Contact default is set to BODY mode.
1. Press on the ‟ PROG. ” button
for 3 seconds, the screen
displays F1.
x 2
2. Press on the ‟ PROG. ” button
twice to get F3.
3. Select 0 by pressing on the ‟ - ”
button to choose the BODY
TEMP mode as default.
Select 1 by pressing on the ‟ + ”
button to choose the SURFACE
TEMP mode as the default.
4. Conrm by pressing on the
‟ PROG. ” button.
9
How to Calibrate the Thermometer
Note: The Non-Contact ProScanTM default is 0.0°C as the thermometer is already
calibrated at the factory. You can calibrate your thermometer, but we recommend
not to modify this setting.
1. Press on the ‟ PROG. ” button
for 3 seconds, the screen
displays F1.
x 3
2. Press on the ‟ PROG. ” button
three times to get F4.
3. Select ‟ + ” to increase the
difference by 0.1°C (0.1°F),
‟ - ” to reduce it by 0.1°C (0.1°F).
4. Conrm by pressing on the
‟ PROG. ” button.
Note: If in doubt, do not modify this setting.
Each time there is a signicant change in the ambient temperature due to
a change in environment, allow the ProScanTM Non-Contact to adapt to
the new ambient temperature for at least 15 minutes before using it.
10
Audio ON/OFF
Note: ProScanTM Non-Contact default is set to 1 (ON).
1. Press on the ‟ PROG. ” button
for 3 seconds, the screen
displays F1.
2. Press four times on the ‟ PROG. ”
button to get F5.
3. Select 0 by pressing on the ‟ - ”
button to power off the default
audio feature.
Select 1 by pressing on the ‟ + ”
button to power on the audio
as your default.
4. Conrm by pressing on the
‟ PROG. ” button.
Exiting the setting mode
Press on the ‟ PROG. ” button until
the screen turns off.
x 4
11
DATA MEMORY
1. To display the last temperature
reading, press simultaneously
on the ‟ - ” and ‟ + ” button.
2. To switch to the previous reading,
press on the ‟ + ” button.
3. Press on the button ‟ - ”
for review.
Note: The number indicated when changing
from one reading to another corresponds to
the number of readings.
4. To exit data memory, press the
measure key. The ProScanTM
Non-Contact backlight
turns off in 5 seconds and
the product will turn off
in 30 seconds.
Measure
key
12
DIRECT SELECTION BUTTONS
1. The ProScanTM Non-Contact has been specially designed
to take the body temperature of a human being by using
the ‟ BODY/CORPS ” function.
2. You can also use the ProScanTM Non-Contact to measure
the temperature of an object, food (baby food, etc.) or
liquid (bath water, milk bottle, etc.) by selecting the
‟ SURFACE ” button.
3. By pressing the ‟ AIR ” button, you will obtain the
temperature of the room.
4. By pressing the ‟ FR. ENG. ESP. ” button, you can change
the language from French to English to Spanish, or turn off
the language function.
The default language setting is English.
CHANGING BATTERIES
1. When the LCD screen displays
‟ Battery ”, the battery needs
to be replaced.
2. Open the lid and change the batteries,
ensuring that they are aligned properly
as indicated inside the battery
compartment. A mistake with this
could cause damage to the device
and compromise the guarantee
of your ProScanTM Non-Contact
Infrared Thermometer.
3. Never use rechargeable batteries.
Battery
compartment
13
HOW TO MEASURE TEMPERATURE
Note: If the thermometer has been stored at a very low or very high temperature,
allow the unit to adjust to room temperature for at least 15 minutes before using
the device. Wait at least 5 seconds between consecutive readings.
1. Before taking temperature readings, make sure to avoid
any drafts like air conditioning, etc.
2. Push back hair and wipe away any perspiration
from the forehead temporal region.
3. Press the thermometer’s measure key to turn of the device.
4. Aim at the forehead, over the
right temporal region, from a
distance of about 3 cm - 5 cm,
press the thermometer’s measure
key and the temperature will
be instantly displayed.
If the temperature reading is 38°C (100.4°F) or higher,
you will hear 5 beeps and the LCD backlight colour will
turn red which means that you have a high fever.
If the temperature reading is between 37.4°C - 37.9°C
(99.3°F - 100.2°F), you will hear 1 beep and the LCD
backlight colour will turn orange which means that you
have a low fever.
Otherwise, you will hear 1 beep and the LCD backlight
colour will display a green light which means no fever.
Note: If the audio alerts threshold default setting is changed, only the audio alerts
will be pertinent, not the colour alerts.
5. Allow a 3 - 5 second intervals between two readings.
6. The device will automatically shut-off after 30 seconds.
* It is not recommended to drink, eat, smoke, shower or be physically active
before/while taking a temperature reading. Please wait for at least 15 minutes
prior to taking a measurement following any of the above listed items.
14
SPECIFICATIONS
Normal
using condition
Batteries
Unit size 16 cm x 10 cm x 4 cm (6.3” x 4” x 1.6”)
Unit weight 131 g (without batteries)
Measuring range
Precision
Consumption
Measuring distance
Automatic shut-off 30 seconds
Longevity 40 000 readings
Warranty 2 years
Note: The manufacturer reserves the right to alter the specifications of the product
without prior notification.
• Ambient temperature: 10°C-40°C(50°F-104°F)
• Relative humidity: ≤ 85%
2 x AA alkaline batteries
Note: In body mode, there are 3 backlight colours:
- Green: ≤ 37.3°C (99.1°F), means normal temperature
- Orange: 37.4°C - 37.9°C (99.3°F - 100.2°F)
means low fever
- Red: ≥38°C (100.4°F), means high fever
• In Body mode: 32°C ~ 42.9°C
(89.6°F ~ 109.2°F)
• In Surface mode: 0°C - 60°C
(32°F - 140°F)
• In Air mode: 0°C - 40°C (32°F - 104°F)
Note: The ProScanTM Non-Contact Infrared
Thermometer can take temperature readings below
32°C or above 42.9°C (89.6°F - 109.2°F) but precision
is not guaranteed outside of this range.
• 32.0°C - 34.9°C (89.6°F - 94.8°F)
± 0.3°C (± 0.6°F)
• 35.0°C - 42.0°C (95°F - 107.6°F)
± 0.2°C (± 0.4°F)
• 42.1°C - 42.9°C (107.8°F - 109.2°F)
± 0.3°C (± 0.6°F)
≤ 450 mW
3 cm - 5 cm (1.2” - 2”)
15
TROUBLESHOOTING
Note: If you have one of the following problems while using your thermometer,
please refer to this guide to help resolve the problem. If the problem persists and
the product is still under warranty, please contact A.M.G. Medical’s Customer
Service Team at 1-800-363-2381 between 8:30 AM and 5:00 PM EST.
Problems
Green backlit
screen reads
‟ Lo ”.
Red backlit
screen shows
‟ Hi ”.
Comments
• The measured
temperature is less
than 32°C (89.6°F)
in Body mode.
• The measured
temperature is
less than 0°C (32°F)
in Surface or
Air mode.
• The measured
temperature is
superior to 42.9°C
(109.2°F) in
Body mode.
• The measured
temperature is
superior to 60°C
(140°F) in
Surface mode.
• The measured
temperature is
superior to 40°C
(104°F) in Air mode.
Instructions
1. Turn the unit off for 15 - 60
seconds and then turn on
again.
2. Retake temperature
using proper technique
(3 cm - 5 cm (1.2” - 2”))
and proper settings (Body,
Surface, Air Mode).
3. Ensure normal room
temperature: 10°C - 40°C
(50°F - 104°F).
4. Ensure there is no hair or
perspiration hampering the
reading if you are taking
body temperature.
5. Ensure there are no air
drafts or dramatic change
in ambient temperature
hampering the reading.
6. If the thermometer still
reads ‟ Lo ”, this indicates
that the patient has a low
body temperature. It could
also mean that surface or
air temperature is low.
If it reads ‟ Hi ”, this
indicates that the patient
has a high body
temperature. It could also
mean that surface or air
temperature is high.
16
Manufactured and printed in China for:
Fabriqué et imprimé en Chine pour :
A.M.G. Medical Inc.
Montreal, QC H4T 1V5 – 1-800-363-2381
Distributed in the USA by:
Distribué aux É.-U. par :
AMG Medical, Inc.
West Chazy, NY 12992 – 1-888-412-4994
www.amgphysiologic.com
Rev2 0718
P/N 911-016660
Loading...
