Let's get started!
MEET YOUR PHOTOBOXX
888-609-2285
www.photoboxx.me
© copyright 2017
RIBB O N
P APE R
P O W E R COR D
P H OTO B O XX HEAD
P RINT C AT C H
T OP S TAND
B OT T O M S TAND
B A S E
ASSEMBLING
01
Unpack the photoboxx equipment.
02
Connect the bottom stand to the base.
03
Connect the top stand to the bottom
stand.
PHOTOBOXX
Steps 1-19
04
Connect the photoboxx head to the
stand.
1
2
05
Remove print catch found above
the printer.
06
1
2
Attach the print catch to the front
slot.
07
1
2
Connect the power cable to the
Photoboxx and a power source.
ClipboardPageNumber
ESSENTIALS | PAGE
Front
4
08
Open front door and locate the tab
at the bottom of the printer.
09
Lift and pull to slide the printer
drawer open.
10
Pull blue lever.
11
Lift scrap box straight up and out.
12
Push roll of paper down to feed into
printer; stop when you hear the beeps.
13
Place scrap box back into the printer.
14
Close printer and slide printer
drawer closed.
15
Printer should print multiple blank
sheets of paper and then be ready to
print. If not, see page 10.
6
INSTRUCTION MANUAL
16
18
Close the front door.
Download the Socialdrip app from
the App Store on your mobile device.
Open the app and follow instructions
to configure the internet connectivity.
17
19
Light should be flashing green
indicating you need to connect to
WiFi or an Ethernet connection.
Start your event.
CONGRATULATIONS!
Now go tell the world to use your hashtag!
CONTINUE FOR MORE HELPFUL TIPS
ClipboardPageNumber
ESSENTIALS | PAGE
4
HELPFUL TIPS
• Connect to a fast and reliable wifi connection [at least 3 mbps].
• Always replace ribbon and paper together.
• Always empty the scrap box before transporting or shipping your photoboxx.
IF POSTS ARE NOT PRINTING...
• Make sure attendees' social media accounts are set to public. [Photoboxx doesn't print private posts to
protect users' privacy].
• Make sure that the printer is connected to internet, with at least 3 mbps speed.
• Make sure hashtag is spelled correctly.
• Make sure the post is not too old. Photoboxx will not print old posts, only new posts with the hashtag.
• Make sure printer doesn't have an error light [see diagram on next page].
PRINTER ERROR LIGHTS
TECH SUPPORT: 888-609-2285 ext. 2
Check out www.photoboxx.me/support for troubleshooting videos and tutorials.
10
REPLACING
RIBBON &
PAPER
Steps 1-15
01
Remove ribbon tray from top of printer.
02
Remove old ribbon from tray and
discard into trash.
03
Place new ribbon into tray. The roll will
fit securely into the notches of the tray.
04
Place ribbon tray back into printer.
05
Pull lever.
Always replace
paper and ribbon at
the same time.
06
Remove and empty scrap box.
07
Remove old paper roll from printer.
12
08
Remove black plastic end caps.
09
Discard of old paper roll.
10
Insert end caps into new roll of
paper with a push and twist.
There should be no
gaps between paper
roll and end caps.
11
Insert paper roll into printer [drop in].
12
Push roll of paper down to feed into
printer, stop when you hear the beeps.
13
Place scrap box back into printer.
14
Close printer door.
15
Printer should print multiple blank
sheets of paper and then be ready
to print. If not, see page 10.
14
