PHITS Y-101A
PHONEMA
Material
Thick
Description
Esvacel HD1000
6 mm
With a density of 1000 kg/m3,
this material increases the
consistency of the box and
block the bass to 300 Hz.
Esvapur AG150
20 mm
It is an agglomerate of
different foams that absorbs
frequencies between 100 and
4000 Hz. It avoids the
resonance of the table.
Basotect by Basf
100 mm
This cellular foam eliminates
internal resonances and
absorbs the frequencies
between 2 and 10 kHz.
Speaker’s improvements
Improve the acoustic tightness
Reduce the internal reverb
Increase the mass of the speaker
PHITS is a kit developed by Phonema to improve the communication speakers. Thanks to the combination
of different densities materials, a more rigid box is achieved and reverberation is eliminated in more than 47
dB. The result is a pure, clear and more intelligible sound.
PHITS installs easily, without modifying the original speaker. The acoustic panels perfectly fit inside the
speaker.
Specifications
Benefits
Phits Y-101A is a new model designed for the
Yaesu speaker SP-20.
All plates have been modified with the combination
of Esvacel HD1000 and Esvapur AG150. In
addition, the Basotect foam by Basf was added to
offer a better result.
The absence of acoustic criteria in the development
of the SP-20 speakers gets resolved with Phits Y-
101A It’s set up can be done in a few minutes and
only a screwdriver is required. The process is fully
reversible since no glue is used at all.
Phits Y-101A gives Yaesu speaker a clearer
sound with a frequency response cleaner without
internal reverberations. SSB and CW signals
appear sharper and listening is much more
pleasant.
Components
Plates: Esvacel HD1000 + Esvapur AG150
Cube: Basotect by Basf
Packaging
Phits Y-101A is delivered in a 31 x 22 x 10,5 cm
cardboard box, carefully wrapped in tissue paper.
In addition to the Phits plates, both a detailed
installation manual and a sticker to identify the
speaker has been improved are also included.
Weight: 1,7 Kg / 1,98 lb
