Phonak inspiro V3, Roger inspiro, Roger inspiro SoundField, inspiro Premium, inspiro SoundField Service Manual
...
Service Manual
inspiro V3 and higher
File:
Page: 1 of 20 Number of local copies:
Date of print:
Contact:
This document is produced and reserved for Phonak service centers and for trained authorized service departments exclusively
technical.support@phonakcom.com
Electrostatic discharge sensitive devices
Take ESD precautionary measures whenever handling electronic devices
Uncontrolled copy if printed
000.000.004.342.pdf
Version: 1.00
Version 2.10
Written: 2011-08-25 BeH
Approved: 2011-09-19 MkB
Released: 2011-09-22 OlJ
Products and Models
inspiro is a teacher microphone which transmits the speech of a talker wirelessly to FM receiver, Roger receivers and SoundField speakers.
Roger inspiro Roger inspiro SoundField
inspiro Premium
inspiro SoundField inspiro Classic
File:
Title:
000.000.004.342.pdf
Service Manual inspiro V3 and higher
Version: 2.10
Page: 2/20
Table of Contents
Description Page
Products and models 01
Table of contents 02
General information
- Equipment and materials 03
- Product information 03
- Firmware version and compatibility 04
Diagnostics guideline
- Visual inspection all models 05
- Functional inspection all models 06
- Listening Inspection Roger inspiro 07
- Listening Inspection inspiro Premium and inspiro Classic 08
- Listening Inspection inspiro SoundField 09
Exploded views and spare part lists
- Explosion inspiro V3 10
- Spare part list Roger inspiro 11
- Spare part list inspiro Premium 12
- Spare part list inspiro Classic 13
Accessories
- Accessories inspiro V3 14
Repair instructions
- Disassembly 15/16
- Replace the display 16/17
- Assembly 17-19
- Serial number sticker 19
Revision history 20
File:
Title:
000.000.004.342.pdf
Service Manual inspiro V3 and higher
Version: 2.10
Page: 3/20
General Information
Equipment and Materials
Category Description Part no. / Download
Service tools Torx screwdriver 026-0272
Standard flat screwdriver
Software FM SuccessWare 4.6.3 or
Phonak DigiWare 1.1
Testing devices Roger X service reference receiver 052-3227-D01
Roger inspiro service reference transmitter 052-3175
MLxi 052-0067-87*40
MLx Audio Checker 052-3177
Audio cable 1m 052-0359
DigiMaster X (for inspiro SoundField only) 052-3180
Documentation Service manual http://extranet.sonova.com/001/default.aspx
Datasheets & user guide http://www.phonakpro.com
Phonak DigiWare 1.1 http://phonak-resource.com/digiware/web/
Product Information
inspiro with SW version V4.0
inspiro with SW verison V4.0 is the first Roger capable inspiro. This version is required to transmit to Roger receivers.
A inspiro with version 3.0 can be upgraded to version 4.0
inspiro with SW version V3.x
inspiro with SW version V3 comes with a new PCB, a bigger battery and new housing parts.
inspiro with SW version V3.x offers several improvements: compared to V1.x or 2.x
- Better battery status and charging indicator
- Direct acces to SoundField pairing as shortcut or through the menu
- Customization of soft keys
- Brighter display
- Longer battery life
- Better mechanic fixation of the knob on the backside for the clip
File:
Title:
Service Manual inspiro V3 and higher
General Information
Firmware Version and Compatibility
000.000.004.342.pdf
Version: 2.10
Page: 4/20
Education systems
compatibility matrix
Type and FW version Mode
FM
inspiro 2.3
inspiro SoundField 2.3
inspiro Premium V3.x
inspiro SoundField V3.x
Roger inspiro V4.x
Roger inspiro SoundField V4.x
FM+SF
SF
SF only
FM
FM+SF
SF
SF only
Roger+FM
Roger
SF only
MultiTalker Network
inspiro/ DynaMic 2.2 or lower
inspiro/DynaMic 2.3
inspiro 3.x
DynaMic 3.x
insiro audioHub 1.x
Note 1
Note 1
Note 3 Note 4 Note 5
Receivers
Roger inspiro 4.x
Roger DynaMic 4.x
Roger AudioHub 4.x
FM receiver
Roger receivers 4.x
DigiMaster V2.x
Roger DigiMaster V4.x
Note 2
Note 2
Note 2
Note 6
Acc
Roger WallPilot
Note 1: upgrade secondary transmitter to V2.3
Note 2: upgrade inspiro to V4.0
Note 3: upgrade secondary inspiro to V2.3 and downgrade Roger inspiro to V3.0
Note 4: downgrade Roger inspiro to V3.0
Note 5: upgrade secondary transmitter to V4.0
Note 6: upgrade DigiMaster to V4.0
Important note:
inspiro with FW 1.x or 2.x CANNOT be upgraded to V3.x or V4.x because of the differences in hardware.
File:
Title:
000.000.004.342.pdf
Service Manual inspiro V3 and higher
Diagnostics Guideline
Visual inspection all models
Version: 2.10
Page: 5/20
Housing
OK ?
Printing on keys OK?
Clip OK? Replace clip
Unwind the microphone cable.
Replace housing
No
Replace top housing
No
No
Microphone cable/
adaptor cable ok?
No
Remove clip and bottom plate.
Connector of microphone ok? Replace Microphone/ adaptor cable
No
Replace Microphone/ adaptor cable
File:
Title:
000.000.004.342.pdf
Service Manual inspiro V3 and higher
Diagnostics Guideline
Functional Inspection all models
Switch on inspiro
Version: 2.10
Page: 6/20
Content on display visible?
Connect inspiro a charger
inspiro indicates
charging, OK?
Press all keys,
function ok?
Plug in a charger and charge for 15min
No
Content on display visible?
On/ off switch OK?
Check USB connection
No
No
Replace SRM inspiro
Replace top housing shell
Replace SRM inspiro
- Reset inspiro
- Replace display
No
No
Replace SRM inspiro
- Replace top housing shell
- Replace on/off switch
Replace SRM inspiro
