Phoenix Gold RX65CX User guide

Coaxial loudSpeaker Manual

Manuel de Coaxial

Models: RX4CX, RX46CX, RX5CX RX57CX, RX65CX, RX69CX

Features:

• LAMINATE-TREATED PAPER CONE -Advancedlaminatingprocessproducesexcellentsti󰘯nesstoweightratio,superiordampingqualities

• 19mm BALANCED DRIVE MYLAR TWEETER-Excellentreproductionofhighfrequencies

• POLYMIDE VOICE COIL FORMER-Hightemperaturelight-weightvoicecoilstructureforincreasedsensitivity

• TRIPLE-LAYER UV TREATED FOAM SURROUND-Premiumdesignforexcellentsensitivityandlongtermreliability

• RIGID POWDER COATED STEEL FRAME - Designed for precise motor alignment

Coaxial Speaker Owner’s Manual

BASIC INSTALLATION

SelectingtheplacementofyournewRXCoaxialspeakerscouldbeaseasyas
usingtheexistingfactorylocationsormayrequireyoutocreateanewlocation.
Speakerplacementinthedoor,dash,orreardeckisthemostcommon.See
yourlocalPhoenixGoldDealerforadditionallocationandmountingassistance.

DOORS/REARDECK

1.Manyvehiclesalreadyhavefactorylocations(Figure1)tohousethe“DROP
IN”featureoftheRXCoaxialspeakers.Ifnoexistinglocationsareavailable
orarenotused,checkthedesiredlocationforadequatecutoutareaand
anydepthobstructions.Makesuretoallowsu󰘲cientclearanceforwindow
tracks,structuralbraces,trunklidsprings,etc.

2.Assumingenoughareaanddepthisavailable,usetheprovidedtemplate
andtracethespeakercutoutandmountingholesontothesurfaceofthe
mountinglocation.

3.Ifthemountingsurfaceisnotstructurallystrongenoughtoaccommodate
screws,(i.e.plastic,cardboard)usetheprovidedspeedclipswhichwillact
asanutforthesuppliedscrews.

4.Alwaysprovidewaterprotection,ifnotsuppliedinthevehicle.Wesuggest
usingarainshieldorequivalent.Ifindoubt,pleasecontactyour
PhoenixGoldDealer.

SPEAKERINSTALLATIONWITHOUTGRILL

PhoenixGoldhasprovidedafoammountinggasket.Wheninstallingyour
newcomponentspeakersinafactorylocationmakesuretousethefoam
mountinggasketasshownin󰘰gure1.Forreversemountedspeakersplacethe
foamgasketinfrontofthespeaker.ThiswillensureanairtightsealforyourR
speakers.

Formorecustomapplications,orcaseswherethefactorygrillwillnotbeused,
ahighexcursionprotectivegrillhasbeenprovided.Wheninstallingyournew
componentspeakerswiththeprovidedRXgrilluse󰘰gure2.

Figure 2

Mountingthespeakerinacustomapplication.

Figure 1

Mountingthespeakerinafactorylocation.

SPECIFICATIONS: Duetocontinualproductimprovement,allspeci󰘰cationssubjecttochangewithoutnotice.

RX4CX RX46CX RX5CX RX57CX RX65CX RX69CX

RMSPowerHandling(watts) 40W 40W 40W 50W 50W 60W

PeakPowerHandling(watts) 80W 80W 80W 100W 100W 120W

Impedance(ohms) 4 4 4 4 4 4

CutOutDimension(mm)/in. (93)3.7 (143X88)5.6X3.5 (120)4.75 (188X131)7.4X5.2 (144)5.7 (221X154)8.7X6.1

MountingDepth(mm)/in. (50)2.0 (51.5)2.1 (55)2.2 (71)2.8 (64)2.5 (76)3.0

© 2013 Phoenix Gold • www.phoenixgold.com

Coaxial Speaker Owner’s Manual

Pour Les Modele: RX4CX, RX46CX, RX5CX, RX57CX, RX65CX, RX69CX

INSTALLATION DE BASE

Lasélectiondel’emplacementdevosnouveauxhaut-parleurscoaxiauxRX
peutêtreaussifacilequel’utilisationdesemplacementsdefabrication
oupeutnécessiterlacréationd’unnouvelemplacement.L’emplacementle
pluscourantestdanslesportes,letableaudebordouàl’arrièredupont.
ConsultezvotreconcessionnairePhoenixGoldpourunemplacementde
montagesupplémentaireetdel’assistance.

INSTALLATIONDESHAUT-PARLEURSPORTES/PLAGE

ARRIÈRE

1.Denombreuxvéhiculesontdéjàdesemplacementsd’usine(Figure1)

pourlafonctionnalité“DROPIN”delalignecoaxialRX.Siaucundes
emplacementsexistantsn’estdisponibleous’ilsnesontpasutilisés,
véri󰘰erl’emplacementdésirépourladécoupeadéquateetdesobstaclesen
profondeur.Assurez-vousdelaissersu󰘲sammentdedégagementpourles
pistesdelafenêtre,lesferruresstructurales,l’amortisseurarrière,etc

2.Ensupposantqu’ilyasu󰘲sammentdesurfaceetdeprofondeur,utiliser

lemodèlefournietretracerladécoupeduhaut-parleuretlestrousde

montage sur la surface de l’emplacement de montage

3.Silasurfacedemontagen’apasunestructuresu󰘲sammentsolidepour

accueillirlesvis,(parex.plastique,carton)utiliserlesclipsrapidesfournis
quiservirontd’écrouspourlesvisfournies

4.Toujoursassurerlaprotectionpourl’eau,siellen’estpasfourniedans

levéhicule.Nousvoussuggéronsd’utiliserunehoussedepluieou
l’équivalent.Encasdedoute,veuillezcontactervotrerevendeurPhoenix
Gold.

INSTALLATION DU HAUT PARLEUR SANS GRILLES

PhoenixGoldafourniunjointstatiquedemontageenmousse.Lorsde
l’installationdevosnouveauxhaut-parleurscoaxiauxdansuneusine,
assurez-vousd’utiliserlesjointsstatiquesdemontageenmoussecommele
montrela󰘰gure1.Pourleshaut-parleursmontésàl’envers,placezlejointen
mousseenfaceduhaut-parleur.Ceciassureraunjointétancheàl’airpour
voshaut-parleursRX.

INSTALLATION DU HAUT PARLEUR AVEC GRILLES

Pour plus d’applications sur mesure, ou des cas où la grille d’usine n’est pas

utilisée,unegrilledeprotectiondehautedéviationaétéfournie.Assurez­vousd’utiliserlejointencaoutchouca󰘰nd’obtenirunjointétancheàl’air.

Lorsdel’installationdevosnouveauxhaut-parleurscoaxiauxaveclagrilleRX
fournie,utilisezla󰘰gure2.

NB:Lesspéci󰘰cationssontsujettesàchangersanspréavisenraisonde
l’améliorationcontinuelleduproduit.

Figure 1

Figure 2

© 2013 Phoenix Gold • www.phoenixgold.com

PhoenixGold

A Division of AAMP of America™

1319056thCourt

Clearwater,Florida33760

P: 888-228-5560

[email protected]
www.phoenixgold.com

©2013AAMPofFlorida,Inc

DesignedandEngineeredintheUSA
