PST 1,3/ 8-LV-5,0
Order No.: 1704547
The figure shows a 10-position version of the product
http://eshop.phoenixcontact.net/phoenix/treeViewClick.do?UID=1704547
Extract from the online
catalog
Header, Nominal current: 14 A, Nom. voltage: 250 V, Pitch: 5 mm,
Number of positions: 8, Color: black, Assembly: Soldering
Commercial data
EAN 4017918995126
Pack 100 pcs.
Customs tariff 85366990
Weight/Piece 0.002996 KG
Catalog page information Page 477 (CC-2009)
Technical data
Product notes
WEEE/RoHS-compliant since:
07/02/2007
http://
www.download.phoenixcontact.com
Please note that the data given
here has been taken from the
online catalog. For comprehensive
information and data, please refer
to the user documentation. The
General Terms and Conditions of
Use apply to Internet downloads.
Dimensions / positions
Length 10.8 mm
Pitch 5 mm
Dimension a 35 mm
Number of positions 8
Pin dimensions 1,3 mm
PHOENIX CONTACT GmbH & Co. KG Page 1 / 4
http://www.phoenixcontact.com Mar 18, 2010
PST 1,3/ 8-LV-5,0 Order No.: 1704547
http://eshop.phoenixcontact.net/phoenix/treeViewClick.do?UID=1704547
Hole diameter 1.5 mm
Technical data
Insulating material group IIIb
Rated surge voltage (III/3) 4 kV
Rated surge voltage (III/2) 4 kV
Rated surge voltage (II/2) 4 kV
Rated voltage (III/2) 400 V
Rated voltage (II/2) 400 V
Connection in acc. with standard EN-VDE
Nominal current I
Nominal voltage U
N
N
13.5 A (depends on the plug used)
250 V
Maximum load current 13.5 A (depends on the plug used)
Insulating material PA
Inflammability class acc. to UL 94 V0
Certificates / Approvals
Certification CUL, UL
CUL
Nominal voltage U
Nominal current I
N
N
300 V
10 A
UL
Nominal voltage U
Nominal current I
N
N
300 V
10 A
PHOENIX CONTACT GmbH & Co. KG Page 2 / 4
http://www.phoenixcontact.com Mar 18, 2010
PST 1,3/ 8-LV-5,0 Order No.: 1704547
http://eshop.phoenixcontact.net/phoenix/treeViewClick.do?UID=1704547
Diagrams/Drawings
Drilling plan/solder pad geometry
Dimensioned drawing
PHOENIX CONTACT GmbH & Co. KG Page 3 / 4
http://www.phoenixcontact.com Mar 18, 2010
PST 1,3/ 8-LV-5,0 Order No.: 1704547
http://eshop.phoenixcontact.net/phoenix/treeViewClick.do?UID=1704547
Address
PHOENIX CONTACT GmbH & Co. KG
Flachsmarktstr. 8
32825 Blomberg,Germany
Phone +49 5235 3 00
Fax +49 5235 3 41200
http://www.phoenixcontact.com
© 2010 Phoenix Contact
Technical modifications reserved;
