Phoenix SmartFlash RF46 User Manual

SmartFlash RF46

DIGITAL MACRO RING FLASH

Main controlling unit

> Mounted on camera

hots hoe

Translucent

Light Diffuser

Ring Tube

Auto
Confinnation
Indicator

Lens Securing Ring

On/Off Switch

Test Button

MAIN FEATURES

Guide Number: 46ft

Automatic TTL flash exposure control

IGBT fast recycling circuitry

Flash exposure compensation control'
Auto exposure confirmation

Multiple mounting threads
Suitable for macro, scientific, medical or hobby photography

.

Camera body dependent features

PRECAUTIONS

Before you start to operate the macro ring flash, please read the
following caution to prevent possible damages.

1. Do not attempt to use this macro ring flash unit on other brands
of cameras other than the dedicated mounting of which it is

intended for.

2. Any attempt to dismantle the main controlling unit and ring light
attachment will result in possible electric shocks or burns. If the

outer casing of any parts is faulty, please return to the authorized
dealer for repairs by authorized personnel.

3. Do not attempt to trigger the flash close to eyes.

4. To maintain the optimize performance of the macro ring flash,

do not fire the flash continuously for more than 10 times.After
continuous firing, allow lhe flash to rest for 5 minutes before
continuing.

5. When the flash unit is not used for more than 2 weeks, remove

all batteries to prevent battery leakage.

6. Try to charge fully and fire the flash several times in a month to
ensure that the electronic circuitry as well as the capacitor is
kept in a tip-top condition.

7. During battery replacement, replace all 4 batteries of the same

type at the same time.

8. Flash unit should be kept dry at all times as it is not either
waterproof or weatherproof. Often it impractical to repairl
replace components damaged by water.

9. Care must be taken as this flash unit is a precise equipment.

Any accident knocks or drop may result in permanent damage
to the circuitry and components which may not be feasible to

undergo repairs.

10. Always store the flash unit in a cool dry place, away from heat

or direct sunlight. Never store the flash in a drawer or cup-
board containing naphthalene or camphor (moth balls) as these
will have a negative effects on the circuitry of the flash unit.

11. Do not use a thinner, benzene or other cleaning agents to

remove dirt or fingerprint from the unit. Use a soft, moistened
cloth instead.
