READ
`
KEEP FOR FUTURE REFERENCE
FOR YOUR CHILD'S SAFETY
THESE INSTRUCTIONS
BEFORE USE
CAREFULLY
™
Page 2
philandteds.com
Page 3
Congratulations on choosing
the sub4!
Product Care
Safety Warnings
Features
Instructions
Page 4
Product care
SUB4
GENERAL INSTRUCTIONS CLEANING & CARING
This document contains important information
and must be kept for future reference.
Please read thoroughly before commencing use
as incorrect use can be dangerous.
Please register your product purchase through our online warranty
registration by visiting: www.philandteds.com/register
This vehicle is intended for children from
6 months up to a maximum weight of
15kg/33lbs.
Maximum height - 100cm/39.4"
Check the sub4 for cuts & bruises. If your product is
damaged in any way, or you’re not sure how to use
it, please consult our web support (www.philandteds.
com/support) from where you can access a local
customer care team.
Caring for sub4
Unlike children, your sub4 likes to stay clean.
• Brush dirt off the frame and wheels regularly.
• Clean with a non-abrasive household cleaner and a
soft cloth.
• Wash off sand and salt after visiting the beach.
• Always dry the frame if wet.
• Fabrics can be sponge cleaned with warm water,
using a mild natural soap.
• Do not use detergents or bleach.
• Store in a well ventilated space, away from direct
sunlight (which can harm and fade fabric), and
moisture.
• Take care to avoid damage to the foam rubber,
which is not covered under warranty.
• Improper care will void any warranties. Do not use
the sub4 if deterioration is detected or suspected.
Page 5
SUB4
Product care
IMPORTANT IMPORTANT
• Always load/unload your children on level ground.
• Ensure the brake is engaged during the loading
and unloading of children.
• Care should be taken if the stroller is used on
stairs or escalators.
• Always use the safety strap.
• Excessive wear can reduce effectiveness and
safety. Parts may need lubrication. Inspect
essential components for:
Fraying - especially webbing straps and safety
harness.
Wear - locks, snap fasteners, tyres, plastic and
moving parts.
Safety - locks must not be loose.
Tyres & Tubes
• The valve is car-size. Manually inflate to 40psi
max. Releasing air delivers a softer ride, but
lower pressure reduces tread life.
• New inner tubes and tyres are generally
available from your dealer, cycle or specialist
wheel shops. Standard tyre kits can repair
punctures.
• A flat tyre can result from grit holding the valve
open. To check: inflate tyre, deflate rapidly, and
re-inflate.
• Tyres and tubes are not covered under
warranty. Do not over inflate. Tyre pressure is
affected by heat especially when inside parked
cars.
For rights & remedies, refer www.philandteds.com/warranty
Page 6
SUB4
Safety Warnings
The sub4 complies with requirements applicable in market
of sale, refer www.philandteds.com/certification
WARNINGS
Australia / New Zealand Safety Standard states:
To avoid injury or death:
• Always apply the brakes whenever the stroller
is stationary.
• Do not leave children unattended.
• Secure the child in the harness at all times.
• Do not carry extra children or bags on this
stroller.
• Make sure children are clear of any moving
parts if you adjust the stroller.
• Use the harness at all times.
• When not in use disconnect shoulder straps
from the waist buckle or strap as harness can
form loops that can lead to strangulation.
• It is unsafe to use accessories other than those
approved by the vehicle's manufacturer.
• Care should be taken if the stroller is used on
stairs or escalators.
• The stroller should not be used near an open
fire or exposed flame.
• This vehicle is intended for children up to a
maximum weight of 15kg/33lbs.
• This seat unit is not suitable for children under
6 months.
• Do not place more than 3kg/6.5lbs in the jet
pack.
WARNINGS
European Safety Guidelines state:
Read the instructions carefully before use and
keep them for future reference. Your child’s
safety may be affected if you do not follow these
instructions.
• This vehicle is intended for children from 6
months up to 3 years, or to a maximum weight
of 15kg/33lbs.
• It may be dangerous to leave your child
Page 7
SUB4
Safety Warnings
unattended.
• The stroller shall only be used for a maximum
of 1 child.
• Accessories or replacement parts that are not
approved by the manufacturer or distributor
should not be used.
• Any load attached to the handle affects the
stability of the stroller.
• Always use the crotch strap in combination
with the waist belt.
• Check that the stroller body or seat unit
attachment devices are correctly engaged
before use.
• Ensure that all locking devices (handles &
wheels) are engaged before use.
• Use a harness as soon as your child can sit
unaided.
• Do not place more than 3kg/6.5lbs in the jet
pack.
• The parking device should be engaged during
the loading and unloading of children.
• This seat unit is not suitable for children under
6 months.
WARNINGS
American Safety Guidelines state:
• Never leave your child unattended in the
stroller.
• Always use the safety harness to avoid serious
injury from falling or sliding out.
• To prevent the stroller from becoming unstable,
do not place parcels or accessory items
anywhere except in the storage pockets
provided. Do not hang items such as shopping
bags from the frame.
• Excessive weight may cause a hazardous
unstable condition to exist.
• The vehicle is intended for a maximum weight
of 15kg/33lbs.
• Do not place more than 3kg/6.5lbs in the jet
pack.
Page 8
SUB4
Features
01
02
03
04
07
06
01 Hand brake
02 Handle bar
03 Sunhood
04 Quick release fold levers
05 Rear wheels
06 Aerocore seat
07 Harness
08 Front wheel
05
08
Page 9
SUB4
Features
01 Frein poignèe au guidon
02 Guidon
03 Capote
04 Mècanisme pour le pliage
05 Roué arrière
06 Assise en matériau aerocore
07 Harnais
08 Roué avant
01 Hanbremse
02 Griff
03 Sonnenverdeck
04 Verschluss zum Einrasten
05 Hinterräder
06 Luftgepolstertes Sitzkissen
07 Gurt
08 Vorderräder
01 Freno de mano
02 Manubrio
03 Tapa sol
04 Seguro fácil de liberar
05 Llantas traseras
06 Asiento aerocore
07 Arnés
08 Llantas delanteras
01 Handrew
02 Duwstang
03 Zonnekap
04 Snelsluiting
05 Achterwielen
06 Aerocore zitkuip
07 Veiligheidsharnas
08 Voorwielen
Page 10
SUB4
Instructions
Page 11
SUB4
Instructions
Page 12
SUB4
Instructions
Page 13
SUB4
Instructions
Page 14
SUB4
Instructions
Page 15
SUB4
Instructions
Page 16
SUB4
Instructions
Page 17
SUB4
Instructions
Page 18
SUB4
Instructions
1
2
01
03a
02
03
04
Page 19
SUB4
Instructions
Page 20
SUB4
Instructions
Page 21
SUB4
Instructions
Page 22
SUB4
Instructions
01
02
Page 23
SUB4
Instructions
03
05
04
06
Page 24
SUB4
Instructions
Page 25
SUB4
Instructions
Page 26
