Page 1
S3
For your child's safety
Read these instructions carefully
before use and keep them for
future reference.
Page 2
Congratulations on choosing
the ` S3!
Safety Warnings
Product Care
Configurations
Features
Instructions
Page 3
S3
Safety Warnings
S3
Safety Warnings
The S3 complies with requirements applicable in market of sale,
refer www.philandteds.com/certification
Read the instructions carefully before use and keep them
for future reference. Your child’s safety may be affected if
you do not follow these instructions.
WARNING
Never leave your child unattended in
the stroller.
WARNING
This vehicle is intended for children
from newborn to 6 years.
Maximum weight of 20lbs/9kg in the
newborn position.
Maximum weight of 44lbs/20kg in the
upright main seat.
Maximum weight of 33/lbs15kg in the
double kit.
WARNING
Always use the safety harness to
avoid serious injury from falling or
sliding out.
WARNING
Always secure all safety harness
straps. Child may slip into leg
openings and strangle.
WARNING
To prevent the stroller from becoming
unstable, do not place parcels or
accessory items anywhere except
in the storage basket and pockets
provided.
WARNING
The stroller may become unstable if
the recommended load is exceeded.
WARNING
Check that the stroller body or seat
unit attachment devices are correctly
engaged before use.
WARNING
Ensure that all locking devices are
engaged before use.
WARNING
Always unload your children on level
ground.
WARNING
The parking device shall be engaged
during the loading and unloading of
children.
WARNING
Make sure children are clear of any
moving parts if you adjust the stroller.
WARNING
Keep fingers clear of moving parts
when folding and unfolding the stroller.
Page 4
Product care
S3
S3
Product care
CLEANING & CARING
Check the S3 for cuts & bruises. If your product is damaged
in any way, or you’re not sure how to use it, please consult our
web support (www.philandteds.com/support) from where you
can access a local customer care team.
Caring for S3
Unlike children, your S3 likes to stay clean.
Brush dirt off frame and wheels regularly.•
Clean with non-abrasive household cleaner and a soft •
cloth.
Wash off sand and salt after visiting the beach.•
Always dry frame if wet.•
Fabrics can be sponge cleaned with warm water, using a •
mild natural soap.
Do not use detergents or bleach.•
Store in a well ventilated space, away from direct sunlight •
(which can harm and fade fabric), and moisture.
Improper care will void any warranties. Do not use the S3 •
if deterioration is detected or suspected.
The stroller should not be used near an open fire or •
exposed flame.
Excessive wear can reduce effectiveness and safety. Parts
may need lubrication. Inspect essential components for:
Fraying - especially webbing straps and safety harness. Wear
- locks, snap fasteners, tyres, plastic and moving parts. Safety locks must not be loose.
RIGHTS & REMEDIES
We want to give owners confidence in the quality of our
products. They are fully warranted against defects in materials
& workmanship for one year from the date of purchase.
What is the warranty? If we determine that the product has
a manufacturing fault we will repair it free of charge. If not
practical to repair it we will, at our discretion, replace the faulty
part in question*.
What if it’s outside the warranty terms? If the product fails
due to wear & tear, accident, neglect or negligence, or if it is
outside the 1 year warranty period, we will happily repair it for
a reasonable charge.
Who do I contact? If your product is less than a year old and
subject to a warranty claim please file one through the support
section of the ` website:
www.philandteds.com/support. If you are unsure if the product
is subject to a warranty claim, or it is outside the one year
warranty period, please consult our web support
(www.philandteds.com/support) from where you can access
a local customer care team. You will need to provide proof of
purchase. They will inform you of the next step.
Please register your product purchase through our online warranty
registration by visiting: www.philandteds.com/register
Who is covered? The original purchaser buying product from
an authorised dealer. Proof of purchase is required.
What is covered? Workmanship or materials that are deemed
faulty by `, providing the product has at all times
been used in normal conditions, used in accordance with the
instructions & been properly maintained.
What is not covered? Second hand product; modified product;
poorly maintained product; normal wear, fading & fabric cuts;
improper use or care: (by way of example) abnormal use; not
following instructions; excessive load; transport damage i.e.
airline or freight damage.
Customer costs within warranty The customer is responsible
for any inwards freight charge to return product to a `
representative for warranty & or service.
Customer costs outside warranty Where proof of purchase is
not provided or product is outside of the one year warranty
period, ` reserves the right to charge a service fee
and/or charge for parts replaced/repaired.
A return freight charge may apply.
Exclusions Any consequential loss or damage to any person
or property directly or indirectly as a result of using a `
product.
WORLDWIDE COVERAGE: If you file a warranty claim outside
of the country of purchase we reserve the right to charge
freight and/or service fees. * Consumers may have extra rights
in some countries or states.
Page 5
Configurations
S3
S3
Configurations
double kitmain seatnewborn
20lbs
max load
parcel tray
11lbs
max load
44lbs
max load
33lbs
max load
Page 6
S3
Features
S3
Features
01 Handle bar
02 Handle bar adjustor
03 Sunhood
04 Double kit
05 Grab bar
06 Frame lock
07 Harness
08 Parcel tray
09 Rear wheels
10 Front wheel
11 Recline straps
12 Foot brake
Accessories available
food tray
bottle holder
mesh cover
cup holder sleeping bag cocoon
hang bag
(sold separately)
Shop online
shop.philandteds.com
storm cover
Page 7
S3
Instructions
S3
Instructions
Out of the box
WARNING
Keep fingers clear of moving parts •
when folding and unfolding the stroller.
Ensure that all locking devices are •
engaged before use.
Page 8
S3
Instructions
S3
Instructions
BRAKE HUB
must face inside
How to put the mudguards and wheels on
4
4
Page 9
S3
Instructions
S3
Instructions
How to attach the sunhood and grab bar
How to use the harness
WARNING
Always use the safety harness to avoid •
serious injury from falling or sliding out.
Always secure all safety harness •
straps. Child may slip into leg openings
and strangle.
excess strap
inside shoulder pad
FOLD AND STORE
Page 10
S3
Instructions
S3
Instructions
How to change the height of the handle bar How to use the brake
WARNING
The parking device shall be engaged
during the loading and unloading of children.
Page 11
S3
Instructions
S3
Instructions
How to recline the main seat
WARNING
This vehicle is intended for children from newborn to 6 years•
Maximum weight of 20lbs/9kg in the newborn position.
Maximum weight of 44lbs/20kg in the upright main seat.
Maximum weight of 33lbs/15kg in the double kit.
The stroller may become unstable if the recommended load is exceeded. •
1
3
2
Follow these instructions in reverse to return the seat to an upright position.
Page 12
S3
Instructions
S3
Instructions
How to fold up the stroller
2
WARNING
Keep fingers clear of moving parts
when folding and unfolding the stroller.
1a 1b 1c
TWIST & PRESS
2
Page 13
S3
Instructions
S3
Instructions
WARNING
The stroller shall only be used for a •
maximum of 2 children.
Check that the stroller body or seat •
unit attachment devices are correctly
engaged before use.
The parking device shall be engaged •
during the loading and unloading of
children.
The stroller may become unstable if •
the recommended load is exceeded.
How to attach the double kit on the front
DK on front
33lbs
max load
2
Page 14
S3
Instructions
S3
Instructions
DK on rear
33lbs
max load
WARNING
Place heavier child in the main seat. •
Always unload your children on level •
ground.
How to attach the double kit on the rear
2
