General
Lighting
Outdoor
Signage
Circline and Signage
Circline Fluorescent Ballasts
Standard electromagnetic core and coil construction continues to provide reliable 60Hz operation and economy over a wide variety of lighting system applications.
No. of
Lamp Type Input
Lamps
1 FC8T9 120 RLQS-122-TP-W 25 0.75 0.53 1 1
1 FC16T9 120 RLCS-140-TP-W 28 0.50 0.44 1 1
2 FC8T9 & FC12T9 120 RS-2232-TP-W 46 0.70 0.40 1 Each
2 FC12T9 & FC16T9 120 RS-3240-TP-W 56 0.60 0.76 1 Each
Volts
Sign Ballasts for T12/HO Fluorescent Lamps
With a mere three ballasts covering over 200 different uorescent lamp combinations, Philips Advance signPRO® electronic ballasts for T12/HO rapid start uorescent lamps offer
a convenient, reliable, and energy-saving alternative to conventional magnetic ballasts. Delivering energy savings of up to 20% when compared to magnetic ballasts, our signPRO
electronic sign ballasts run a total of 1 to 6 lamps and operate 4 to 48 feet of total lamp footage.
No. of
Lamp Type Input
Lamps
1-2 T12/HO 120
1-2 T12/HO 120
2-4 T12/HO 120
2-4 T12/HO 120
2-4 T12/HO 120
2-4 T12/HO 120
4-6 T12/HO 120
4-6 T12/HO 120
4-6 T12/HO 120
Volts
Philips Advance Model Input
Type Philips Advance Model Input
Electronic
Magnetic
Electronic
Magnetic
Magnetic
Magnetic
Electronic
Magnetic
Magnetic
ASB-0416-12-E 175 0.73 1.46 -20 4 feet 16 feet
ASB-0412-12-BL-TP 175 0.89 1.48 -20 4 feet 12 feet
ASB-1232-24-E 350 0.73 2.95 -20 12 feet 32 feet
ASB-0620-24-BL-TP 304 0.90 2.56 -20 6 feet 20 feet
ASB-1224-24-BL-TP 312 0.84 2.70 -20 12 feet 24 feet
ASB-2040-24-BL-TP 472 0.80 4.00 -20 20 feet 40 feet
ASB-2048-46-E 490 0.73 4.17 -20 20 feet 48 feet
ASB-1240-46-BL-TP 462 0.78 3.90 -20 12 feet 40 feet
ASB-2448-46-BL-TP 604 0.86 5.19 -20 24 feet 48 feet
Power
(Watts)
Ballast
Factor
Power
(Watts)
Line
Current
Ballast
Factor
Rapid Start Lamps Operated
FC6T9 FC8T9 FC12T9 FC16T9 FC8T9 &
Line
Current
Min. Start
Temp. (F)
Total T12/HO Lamp Footage Operated
Min. Max.
FC12T9
FC12T9 &
FC16T9
Philips Advance
signPRO T12/HO ballast
Lighting Electronics Product Reference 2010 11
