Always there to help you
Question?
Contact
Philips
Register your product and get support at
www.philips.com/welcome
XL300
XL305
User manual
Contents
1 Important safety instructions 3
2 Your phone 4
What is in the box 4
Overview of the phone 5
Overview of the base station 6
Display icons 6
3 Get started 8
Connect the base station 8
Install the handset 8
Congure your phone (country
dependent) 9
Change the remote access PIN/passcode 10
Charge the handset 10
Check the battery level 10
What is standby mode? 10
Check the signal strength 11
Switch the handset on or off 11
4 Calls 12
Make a call 12
Answer a call 12
End a call 13
Turn the speaker on or off 13
Adjust the earpiece/speaker volume 13
Make a second call 13
Answer a second call 13
Switch between two calls 14
Make a conference call with the
external callers 14
5 Intercom and conference calls 15
Make a call to another handset 15
Transfer a call 15
Make a conference call 15
6 Text and numbers 17
Enter text and numbers 17
7 Phonebook 18
View the phonebook 18
Search a record 18
Call from the phonebook 18
Add a record 18
Edit a record 19
Delete a record 19
Delete all records 19
8 Call log 20
Call list type 20
View the call records 20
Save a call record to the phonebook 20
Return a call 20
Delete a call record 21
Delete all call records 21
9 Redial list 22
View the redial records 22
Redial a call 22
Save a redial record to the phonebook 22
Delete a redial record 22
Delete all redial records 22
10 Phone settings 23
Sound settings 23
ECO mode 24
ECO+ mode 24
Set the backlight of the LCD screen 24
Set the date and time 25
Set the display language 25
11 Telephone answering machine 26
Turn the answering machine on or off 26
Set the answering machine language 26
Set the answer mode 26
Announcements 27
Incoming messages 27
Set the ring delay 28
Call screening 29
Remote access 29
12 Services 31
1EN
Call list type 31
Auto conference 31
Auto prex 31
Network type 31
Select the recall duration 32
Dial mode 32
Auto clock 32
Register additional handsets 32
Unregister handsets 33
Restore default settings 33
13 Technical data 34
14 Notice 35
Declaration of conformity 35
Use GAP standard compliance 35
Compliance with EMF 35
Disposal of your old product and
batteries 35
15 Frequently asked questions 37
16 Index 38
17 Appendix 40
Text and number input tables 40
2 EN
1 Important safety
instructions
Power requirements
• This product requires an electrical supply
of 100-240 volts AC. In case of power
failure, the communication can be lost.
• The voltage on the network is classied
as TNV-3 (Telecommunication Network
Voltages), as dened in the standard EN
60950.
• Handsfree activation could suddenly increase the
volume in the earpiece to a very high level: make sure
the handset is not too close to your ear.
• This equipment is not designed to make emergency
calls when the power fails. An alternative has to be
made available to allow emergency calls.
• Do not allow the product to come into contact with
liquids.
• Do not use any cleaning agents containing alcohol,
ammonia, benzene, or abrasives as these may harm
the set.
• Do not expose the phone to excessive heat caused by
heating equipment or direct sunlight.
• Do not drop your phone or allow objects to fall on
your phone.
• Active mobile phones in the vicinity may cause
interference.
Warning
• The Electrical network is classied as hazardous. The
only way to power down the charger is to unplug the
power supply from the electrical outlet. Ensure that the
electrical outlet is always easily accessible.
To avoid damage or malfunction
Caution
• Use only the power supply listed in the user
instructions.
• Use only the batteries listed in the user instructions.
• Risk of explosion if battery is replaced by an incorrect
type.
• Dispose of used batteries according to the instructions.
• Do not dispose of batteries in re.
• Always use the cables provided with the product.
• Do not allow the charging contacts or the battery to
come into contact with metal objects.
• Do not let small metal objects come into contact with
the product. This can deteriorate audio quality and
damage the product.
• Metallic objects may be retained if placed near or on
the handset receiver.
• Do not use the product in places where there are
explosive hazards.
• Do not open the handset, base station or charger as
you could be exposed to high voltages.
• For pluggable equipment, the socket-outlet shall
be installed near the equipment and shall be easily
accessible.
About operating and storage temperatures
• Operate in a place where temperature is
always between 0°C to +40°C (up to 90%
relative humidity).
• Store in a place where temperature is
always between -20°C and +45°C (up to
95% relative humidity).
• Battery life may be shorter in low
temperature conditions.
3EN
2 Your phone
Congratulations on your purchase and welcome
to Philips!
To fully benet from the support that Philips
offers, register your product at www.philips.
com/welcome.
What is in the box
Base station (XL300)
Base station (XL305)
Power adapter**
Line cord*
Guarantee
User manual
Handset**
Charger**
4 EN
4XLFNVWDUWJXLGH
Quick start guide
Note
• * In some countries, you have to connect the line
adapter to the line cord, then plug the line cord to the
telephone socket.
• ** In multi-handset packs, there are additional handsets
and chargers and power adapters.
Overview of the phone
l
k
j
i
a Earpiece
b M1/M2/M3
Save the call records as direct keys for
quick dial.
c /
• End the call.
• Exit the menu/operation.
• Cancel operation.
• Press and hold to switch the handset
on or off.
• Press to delete individual text or digit.
Press and hold to remove all text.
d /MENU /
• Access the main menu in standby
mode.
a
b
c
d
e
f
g
h
m
n
o
• Scroll up/down on the menu.
• Move the cursor left and right during
text editing.
e
Access the redial list and call log in standby
mode.
f
• Turn the speaker phone on/off.
• Make and receive calls through the
speaker.
g #R
Recall key (this feature is network
dependent).
h Microphone
i
• Press and hold to make an intercom
call (for multi-handset versions only).
• Set the dial mode (pulse mode or
temporary tone mode).
j
• Press to add a space during text
editing.
• Press and hold to enter a pause when
editing the contact's number.
k
Access the phonebook in standby mode.
l /OK
• Conrm selection.
• Enter the options menu.
m +/-
Adjust the volume.
n Loudspeaker
o Battery door
5EN
Overview of the base station
XL300
g
• Play messages.
• Stop messages playback.
Display icons
a
• Press to nd handsets.
• Press and hold to enter the registration
mode.
XL305
a Speaker
b
Turn the answering machine on/off.
c
• Press to nd handsets
• Press and hold to enter the registration
mode
d
• Delete the current playback message.
• Press and hold to delete all old
messages.
e /
Decrease/increase the speaker volume.
f /
Skip backward/forward during playback.
a
a
b
c
d
e
f
g
In standby mode, the icons shown on the main
screen tell you what features are available on
your handset.
Icon Descriptions
When the handset is off the base
station/charger, the bars indicate the
battery level (from full to low).
When the handset is on the base
station/charger, the bars keep scrolling
until charging is complete.
The empty battery icon ashes and you
hear an alert tone.
The battery is low and needs recharging.
The number of bar indicates the
connection status between the handset
and base station. The more bars are
shown, the better the signal or the
connection is.
It remains steadily on when browsing
incoming calls in the call log.
It indicates an outgoing call in the redial
list.
It ashes when there is a new missed call
or when browsing unread missed calls
in call log.
It remains steadily on when browsing
missed calls in call log.
It ashes when receiving incoming call. It
remains steadily on during a call.
The ringer is off.
Answering machine: it ashes when
there is a new message or when the
memory is full. It is displayed when the
telephone answering machine is turned
on.
6 EN
It ashes when there is a new voice
message.
It remains steadily on when the voice
messages are already viewed in the call
log.
The icon is not shown when there is no
voice message.
It is displayed when you scroll up/down a
/
list/increase and decrease the volume.
There are more digits on the right. Press
to read.
There are more digits on the left. Press
/MENU to read.
7EN
3 Get started
Caution
• Make sure that you have read the safety instructions in
the 'Important safety instructions' section before you
connect and install your handset.
Connect the base station
Warning
• Risk of product damage! Ensure that the power supply
voltage corresponds to the voltage printed on the back
or the underside of the phone.
• Use only the supplied power adapter to charge the
batteries.
Note
• If you subscribe to the digital subscriber line (DSL) high
speed internet service through your telephone line,
ensure you install a DSL lter between the telephone
line cord and the power socket. The lter prevents
noise and caller ID problems caused by the DSL
interference. For more information on the DSL lters,
contact your DSL service provider.
• The type plate is located on the bottom of the base
station.
1 Connect each end of the power adapter
to:
• the DC input jack at the back of the
base station;
• the power socket on the wall.
2 Connect each end of the line cord to:
• the telephone socket at the back of
the base station;
• the telephone socket on the wall.
3 Connect each end of the power adapter
to (for multi handset version only):
• the DC input jack at the bottom of the
extra handset charger.
• the power socket on the wall.
Install the handset
The batteries are pre-installed in the handset.
Pull the battery tape off from the batter y door
before charging.
8 EN
Note
• The country/language setting option is countr y
dependent. If no welcome message is displayed, it
means the country/language setting is preset for your
country. Then you can set the date and time.
Caution
• Risk of explosion! Keep batteries away from heat,
sunshine or re. Never discard batteries in re.
• Use only the supplied batteries.
• Risk of decreased battery life! Never mix different
brands or types of batteries.
Note
• Charge the batteries for 8 hours before rst use.
• If the handset becomes warm when the batteries are
being charged, it is normal.
Warning
• Check the battery polarity when inser ting in the
battery compar tment. Incorrect polarity may damage
the product.
Congure your phone
(country dependent)
When using your phone for the rst time, you
see a welcome message.
Set the country/language
Select your country/language, then press
/OK to conrm.
» The country/language setting is saved.
To re-set the language, see the following steps.
1 Select /MENU / > [PHONE SETUP]
> [LANGUAGE], then press /OK to
conrm.
2 Select a language, then press /OK to
conrm.
» The setting is saved.
Set the date and time
Tip
• To set the date and time later, press / to skip
this setting.
1 Press /MENU / .
2 Select [PHONE SETUP] > [DATE/TIME],
then press /OK to conrm.
3 Press the numeric buttons to enter the
date, then press /OK to conrm.
» The time setting menu is displayed on
the handset.
4 Press the numeric buttons to enter the
time.
• If the time is in 12-hour format, press
/MENU / to select [AM] or
[PM] (Country dependent).
5 Press /OK to conrm.
9EN
Change the remote access
PIN/passcode
Note
• The default answering machine remote access PIN/
passcode is 0000 and it is important to change it to
ensure the security.
• This feature is available only for XL305.
1 Press /MENU / in standby mode to
access the main menu.
2 Select [ANSW MACHINE] > [REMOTE
ACC.] > [CHANGE PIN], then press
/OK to conrm.
3 Enter the old PIN, then press /OK to
conrm.
4 Enter the new PIN code, then press
/OK to conrm.
5 Enter the new PIN code again, then press
/OK to conrm.
» The setting is saved.
Charge the handset
Place the handset on the base station to
charge the handset. When the handset is
placed correctly on the base station, you hear
a docking tone (see 'Set the docking tone' on
page 23).
» The handset starts charging.
Check the battery level
The battery icon displays the current battery
level.
When the handset is off the base
station/charger, the bars indicate
the battery level (full, medium and
low).
When the handset is on the base
station/charger, the bars ash until
charging completes.
The empty battery icon ashes.
The battery is low and needs
recharging.
The handset turns off if the batteries are empty.
If you are on the phone, you hear warning
tones when the batteries are almost empty. The
call gets disconnected after the warning.
Note
• Charge the batteries for 8 hours before rst use.
• If the handset becomes warm when the batteries are
being charged, it is normal.
Your phone is now ready to use.
10 EN
What is standby mode?
Your phone is in standby mode when it is idle.
The time and handset number are displayed on
the standby screen.
Check the signal strength
The number of bars indicates
the connection status between
the handset and base station. The
more bars are shown, the better
the connection is.
• Make sure the handset is linked to the base
station before you make or receive calls
and carry out the phone functions and
features.
• If you hear warning tones when you are
on the phone, the handset is almost out
of battery or the handset is out of range.
Charge the battery or move the handset
nearer to the base station.
Switch the handset on or off
Press and hold / to switch the handset
on or off.
11EN
4 Calls
Note
• When the power fails, the phone cannot access
emergency services.
Tip
• Check the signal strength before you make a call or
when you are in a call.
Make a call
You can make a call in these ways:
• Normal call
• Predial call
• Call through the direct keys
You can also make a call from the redial list (see
'Redial a call' on page 22), phonebook list (see
'Call from the phonebook' on page 18) and call
log (see 'Return a call' on page 20).
Normal call
1 Press /OK or .
2 Dial the phone number.
» The number is dialed out.
» The duration of your current call is
displayed.
Predial call
1 Dial the phone number
• To erase a digit, press / .
• To erase all digits, press and hold
/ .
• To enter a pause, press and hold .
2 Press /OK or to dial out the call.
Call through the direct key
You can make a quick call from the record pre-
saved in the direct key in different ways:
• Press M1, M2 or M3 in standby mode, then
press /OK or to dial out the number.
• Press /OK or to get the dial tone
rst, then press M1, M2 or M3 to dial out
the number.
• Press and hold M1, M2 or M3 in standby
mode to dial out the number.
Tip
• For information of how to set the direct keys, see the
next section.
Set the direct keys
1 Enter the number, press and hold M1, M2
or M3, then press /OK to conrm.
2 Enter/edit the name, then press /OK to
conrm.
» The direct key is set.
Note
• If there is already a record saved in the direct key, you
need to conrm whether you want to replace the old
record with the new one.
• For multiple handset versions, the same direct key
records saved in the base station are shared among
different handsets.
Note
• The call timer displays the talk time of your current call.
• If you hear warning tones, the phone is almost out of
battery or out of range . Charge the battery or move
the phone close to the base station.
Answer a call
When the phone rings, you can select from the
following options:
• press /OK or to answer the call.
12 EN
• press / to turn off the ringer of this
call.
Warning
• When the handset rings or when the handsfree is
activated, keep the handset away from your ear to
avoid ear damage.
Note
• If you have subscribed for a caller ID service with
the service provider, you will see the caller number
displayed on the handset. If the number is saved in the
phonebook, the name will be displayed.
• To view the complete name or number display of an
incoming call, press /MENU / .
Make a second call
Note
• This service is network dependent.
Tip
• When there is a missed call, a notication message
appears.
End a call
You can end a call in these ways:
• Press / ;
• Place the handset to the base station
or charging cradle.
Turn the speaker on or off
Press .
Adjust the earpiece/speaker
volume
Press +/- on the left side of the handset to
increase/decrease the volume during a call.
» The earpiece/speaker volume is
adjusted and the phone is back to the
call screen.
1 Press and hold #R during a call.
» The rst call is put on hold.
2 Dial the second number.
» The number displayed on the screen is
dialed out.
Answer a second call
Note
• This service is network dependent.
When there is a periodical beep to notify you
of an incoming call, you can answer the call in
these ways:
1 Press and hold #R and then press to
answer the call.
» The rst call is put on hold, and you
are now connected to the second call.
2 Press and hold #R and then press to
end the current call and answer the rst
call.
13EN
Switch between two calls
1 Press and hold #R and then press .
» The current call is put on hold, and you
are now connected to the other call.
Note
• This feature is country dependent.
Make a conference call with
the external callers
Note
• This service is network and countr y dependent. Check
with the service provider for additional charges.
When you are connected to two calls, press
/OK, then .
» The two calls are combined and a
conference call is established.
14 EN
5 Intercom and
conference calls
Switch between calls
Press and hold to switch between the
outside call and the intercom call.
An intercom call is a call to another handset
that shares the same base station. A conference
call involves a conversation between you,
another handset user and the outside callers.
Make a call to another
handset
Note
• If the base station only has 2 registered handsets, press
and hold to make a call to another handset.
1 Press and hold .
» The handsets available for intercom are
displayed.
2 Select a handset number, then press
/OK to conrm.
» The selected handset rings.
3 Press /OK on the selected handset.
» The intercom is established.
4 Press / to cancel or end the
intercom call.
Transfer a call
Note
• If the base station only has 2 registered handsets, press
and hold to transfer a call to another handset.
1 Press and hold during a call.
» The handsets available for intercom are
displayed.
2 Select a handset number, then press
/OK to conrm.
3 Press / when the other side answers
your call.
» The call is now transferred to the
selected handset.
Make a conference call
A 3-way conference call is between you,
another handset user and the outside callers. It
requires two handsets to share the same base
station.
While you are on the phone
You can go from one handset to another during
a call:
1 Press and hold .
» The current caller is put on hold.
2 Select a handset number, then press
/OK to conrm.
» Wait for the other side to answer your
call.
During an external call
1 Press and hold to initiate an internal call.
» The external caller is put on hold.
» For multi-handset versions, The
handsets available for intercom are
displayed. Then go to step 2.
» For two-handset versions, the other
handset rings. Then go to step 3.
2 Select or enter a handset number, then
press /OK to conrm.
» The selected handset rings.
3 Press /OK on the selected handset.
15EN
» The intercom is established.
4 Press /OK.
» You are now in a 3-way conference
call with an external call and a selected
handset.
5 Press / to end the conference call.
Note
• Press /OK to join an ongoing conference with
another handset if [SERVICES]>[CONFERENCE] is
set to [AUTO].
During the conference call
• Press and hold to put the external call
on hold and go back to the internal call.
» The external call is put on hold.
• Press /OK to establish the conference
call again.
Note
• If a handset hangs up during the conference call, the
other handset remains connected to the external call.
16 EN
6 Text and
numbers
You can enter text and numbers for handset
name, phonebook records, and other menu
items.
Enter text and numbers
1 Press once or several times on the
alphanumeric key to enter the selected
character.
2 Press / to delete a character. Press
and hold / to delete all characters.
Press /MENU / to move the cursor
left and right.
3 Press to add a space.
Note
• For information on key mapping of characters and
numbers, see the chapter 'Appendix' in the user
manual online.
17EN
7 Phonebook
This phone has a phonebook that stores up to
50 records. You can access the phonebook from
the handset. Each record can have a name up
to 16 characters long and a number up to 24
digits long.
There are 2 direct access memories (keys
and ). Depending on your country, keys
and are preset to the voice mail number
and information service number of your service
provider respectively. When you press and hold
on the key in standby mode , the saved phone
number is dialed automatically.
View the phonebook
Note
• You can view the phonebook on one handset only
each time.
Enter the rst character of a contact
1 Press or press /MENU / , then
select [PHONEBOOK] > [VIEW] to
access the phonebook list.
2 Press the alphanumerical key that matches
the character.
» The rst record that starts with this
character is displayed.
Call from the phonebook
1 Press or press /MENU / , then
select [PHONEBOOK] > [VIEW] to
access the phonebook list.
2 Select a contact in the phonebook list.
3 Press /OK to make the call.
Add a record
1 Press or press /MENU / , then
select [PHONEBOOK] > [VIEW] to
access the phonebook list.
2 Select a contact and press /OK to view
the available information.
Search a record
You can search the phonebook records in these
ways:
• Scroll the contact list.
• Enter the rst character of the contact.
Scroll the contact list
1 Press or press /MENU / , then
select [PHONEBOOK] > [VIEW] to
access the phonebook list.
2 Press /MENU / to scroll through the
phonebook list.
18 EN
Note
• If your phonebook memory is full, the handset displays
a notication message. Delete some records to add
new ones.
1 Press /MENU / in standby mode to
access the main menu.
2 Select [PHONEBOOK] > [ADD NEW],
then press /OK to conrm.
3 Enter the name, then press /OK to
conrm.
4 Enter the number, then press /OK to
conrm
» Your new record is saved.
Tip
• Press and hold to insert a pause.
Note
• The phonebook overwrites the old number with the
new number.
Tip
• Press once or several times on the alphanumeric key to
enter the selected character.
• Press / to delete the character. Press
/MENU / to move the cursor left and right.
Edit a record
1 Press /MENU / in standby mode to
access the main menu.
2 Select [PHONEBOOK] > [EDIT], then
press /OK to conrm.
3 Select a contact, then press /OK to
conrm.
4 Edit the name, then press /OK to
conrm.
5 Edit the number, then press /OK to
conrm.
» The record is saved.
Delete all records
1 Press /MENU / in standby mode to
access the main menu.
2 Select [PHONEBOOK] > [DELETE ALL],
press /OK to conrm.
» A conrmation request is displayed on
the handset.
3 Press /OK to conrm.
» All records (except the 2 direct access
memory records) are deleted.
Delete a record
1 Press /MENU / in standby mode to
access the main menu.
2 Select [PHONEBOOK] > [DELETE], then
press /OK to conrm.
3 Select a contact, then press /OK to
conrm.
» A conrmation request is displayed on
the handset.
4 Press /OK to conrm.
» The record is deleted.
19EN
8 Call log
3 Select an option, then press /OK to
conrm.
The call log stores the call history of all missed
or received calls. The incoming call history
includes the name and number of the caller,
call time and date. This feature is available if you
have registered to the caller ID service with
your service provider.
Your phone can store up to 50 call records. The
call log icon on the handset ashes to remind
you of any unanswered calls. If the caller allows
the display of his identity, you can view his
name or number. The call records are displayed
in chronological order with the most recent
received call at the top of the list.
Note
• Make sure that the number in the call list is valid before
you can call back directly from the call list.
The icons shown on the screen tell you
whether they are missed/received calls.
Icons Description
It remains steadily on when browsing
incoming calls in the call log.
It ashes when there is a new missed
call.
It remains steadily on when browsing
the unread missed calls in call log.
Call list type
You can set if you can see all calls or missed
calls from the call log.
View the call records
1 Press /MENU / in standby mode to
access the main menu.
2 Select [CALL LOG] > [MISSED CALLS]
to view missed calls or [ALL INCOMING]
to view all calls, then press /OK to
conrm.
» The call log is displayed.
3 Select a record, then press /OK
and select [VIEW] for more available
information.
Save a call record to the
phonebook
1 Press /MENU / in standby mode.
2 Select [CALL LOG] > [MISSED CALLS]
to view missed calls or [ALL INCOMING]
to view all calls, then press /OK to
conrm.
» The call log is displayed.
3 Select a record, then press /OK to
conrm.
4 Select [SAVE NUMBER], then press
/OK to conrm.
5 Enter and edit the name, then press
/OK to conrm.
6 Enter and edit the number, then press
/OK to conrm.
» The record is saved.
Select the call list type
1 Press /MENU / in standby mode to
access the main menu.
2 Select [SERVICES] > [CALL LISTS], then
press /OK to conrm.
20 EN
Return a call
1 Press in standby mode.
2 Select [MISSED CALLS] to view missed
calls or [ALL INCOMING] to view all calls,
then press /OK to conrm..
» The call log is displayed.
3 Select a record on the list.
4 Press /OK to make the call.
Delete a call record
1 Press /MENU / in standby mode.
2 Select [CALL LOG] > [MISSED CALLS]
to view missed calls or [ALL INCOMING]
to view all calls, then press /OK to
conrm.
» The call log is displayed.
3 Select a record, then press /OK to
conrm.
4 Select [DELETE], then press /OK to
conrm
» A conrmation request is displayed on
the handset.
5 Press /OK to conrm.
» The record is deleted.
Delete all call records
1 Press /MENU / in standby mode.
2 Select [CALL LOG] > [MISSED CALLS]
to view missed calls or [ALL INCOMING]
to view all calls, then press /OK to
conrm.
» The call log is displayed.
3 Press /OK to enter the options menu.
4 Select [DELETE ALL], then press /OK
to conrm
» A conrmation request is displayed on
the handset.
5 Press /OK to conrm.
» All records are deleted.
21EN
9 Redial list
The redial list stores the call history of dialed
calls. It includes the names and/or numbers you
have called. This phone can store up to 20 redial
records.
View the redial records
1 Press in standby mode.
2 Select [REDIAL], then press /OK to
conrm.
» The list of dialed calls is displayed.
Redial a call
1 Press in standby mode.
2 Select [REDIAL], then press /OK to
conrm.
» The list of dialed calls is displayed.
3 Select a record, then press /OK.
» The number is dialed out.
Save a redial record to the
phonebook
1 Press /MENU / in standby mode.
2 Select [CALL LOG] > [REDIAL], then
press /OK to conrm.
» The list of dialed calls is displayed.
3 Select a record, then press /OK to
conrm.
4 Select [SAVE NUMBER], then press
/OK to conrm.
5 Enter and edit the name, then press
/OK to conrm.
6 Enter and edit the number, then press
/OK to conrm.
» The record is saved.
Delete a redial record
1 Press /MENU / in standby mode.
2 Select [CALL LOG] > [REDIAL], then
press /OK to conrm.
» The list of dialed calls is displayed.
3 Select a record, then press /OK to
conrm.
4 Select [DELETE], then press /OK to
conrm.
» A conrmation request is displayed on
the handset.
5 Press /OK to conrm.
» The record is deleted.
Delete all redial records
1 Press /MENU / in standby mode.
2 Select [CALL LOG] > [REDIAL], then
press /OK to conrm.
» The list of dialed calls is displayed.
3 Press /OK to enter the options menu.
4 Select [DELETE ALL], then press /OK
to conrm.
» A conrmation request is displayed on
the handset.
5 Press /OK to conrm.
» All records are deleted.
22 EN
10 Phone settings
You can customize the settings to make it your
own phone.
Sound settings
Set the handset's ringtone volume
You can select among 5 ringtone volume levels
or [OFF].
1 Press /MENU / in standby mode to
access the main menu.
2 Select [PHONE SETUP] >[SOUNDS] >
[RING VOLUME], then press /OK to
conrm.
3 Select a volume level, then press /OK to
conrm.
» The setting is saved.
Set the handset's ringtone
You can select from 10 ringtones.
1 Press /MENU / in standby mode to
access the main menu.
2 Select [PHONE SETUP] > [SOUNDS]
> [RING TONES], then press /OK to
conrm.
3 Select a ringtone, then press /OK to
conrm.
» The setting is saved.
Set the key tone
Key tone is the sound made when you press a
key on the handset.
1 Press /MENU / in standby mode to
access the main menu.
2 Select [PHONE SETUP] > [SOUNDS]
> [KEY TONE], then press /OK to
conrm.
3 Select [ON]/[OFF], then press /OK to
conrm.
» The setting is saved.
Set the docking tone
Docking tone is the sound made when you
place the handset on the base station or
charger.
1 Press /MENU / in standby mode to
access the main menu.
2 Select [PHONE SETUP] > [SOUNDS] >
[DOCKING TONE], then press /OK to
conrm.
3 Select [ON]/[OFF], then press /OK to
conrm.
» The setting is saved.
Set the battery tone
Battery tone is the sound made when the
battery is low and needs recharging.
1 Press /MENU / in standby mode to
access the main menu.
2 Select [PHONE SETUP] > [SOUNDS] >
[BATTERY TONE], then press /OK to
conrm.
3 Select [ON]/[OFF], then press /OK to
conrm.
» The setting is saved.
Set the hearing aid compatibility
(according to the standard
ETS300381)
This feature enables the phone to couple with
the hearing aid device to amplify the sound and
reduce noise interference.
1 Press /MENU / in standby mode to
access the main menu.
2 Select [PHONE SETUP] > [SOUNDS]
> [HEARING AID], then press /OK to
conrm.
23EN
3 Select [ON]/[OFF], then press /OK to
conrm.
» The setting is saved.
ECO mode
The ECO mode reduces the transmission
power of the handset and base station when
you are on a call or when the phone is in
standby mode.
1 Press /MENU / in standby mode to
access the main menu.
2 Select [PHONE SETUP] > [ECO], then
press /MENU to conrm.
3 Select [ON]/[OFF], and press /OK to
conrm.
» The setting is saved.
» is displayed in standby mode.
Note
• When ECO mode is set to [ON], the connection
range between the handset and the base station can
be reduced.
Note
• Make sure that all the handsets registered to the base
station are XL300/XL305 in order to have the ECO+
feature functioning properly.
• When ECO+ is activated, the standby time is reduced.
This is because in ECO+ mode the base station is not
transmitting any signal in standby mode; therefore the
handset needs to “listen” more frequently for signals
from the base station to detect incoming calls or other
requests from the base station. The time it takes for the
handset to access features like call setup, call log, paging,
and phonebook browsing is also delayed. The handset
will not alert you to link loss in case of power loss or
moving out of range.
The following table shows you the current
status of the handset screen with different ECO
mode and ECO+ mode settings.
ECO mode/
ECO+ mode
[OFF]/[OFF] ECO and ECO+ are off.
[OFF]/[ON] ECO+ is displayed only after
[ON]/[OFF] ECO is displayed.
[ON]/[ON] ECO is displayed and
Handset icon display
the ECO+ mode is activated
during standby mode .
changed to ECO+ when the
ECO+ mode is activated in
standby mode.
ECO+ mode
When the ECO+ mode is activated, it
eliminates the transmission power of the
handset and base station in standby mode.
1 Press /MENU / in standby mode to
access the main menu.
2 Select [PHONE SETUP] >[ECO+], then
press /OK to conrm.
3 Select [ON]/[OFF], and press /OK to
conrm.
» The setting is saved.
24 EN
Set the backlight of the LCD
screen
You can set the backlight of the LCD screen
and keypad ashing on or off when the phone
rings.
1 Press /MENU / in standby mode to
access the main menu.
2 Select [PHONE SETUP] > [VISUAL
ALERT], then press /OK to conrm.
3 Select [FLASHING ON]/[FLASHING
OFF], then press /OK to conrm.
» The setting is saved.
Set the date and time
For information, see 'Set the date and time' in
the Get started section.
Set the display language
Note
• This feature only applies to models with multiple-
language support.
• Languages available vary from country to country.
1 Press /MENU / in standby mode to
access the main menu.
2 Select [PHONE SETUP] > [LANGUAGE],
then press /OK to conrm.
3 Select a language, then press /OK to
conrm.
» The setting is saved.
25EN
11 Telephone
answering
machine
Note
• Available only for XL305.
Your phone includes a telephone answering
machine that records unanswered calls when
it is on. You can access the answering machine
remotely and change the settings through the
answering machine menu on the handset.
The button on the base station lights up
when the answer machine is on.
Turn the answering machine
on or off
You can turn the answering machine on or off
through the base station or the handset.
3 Select [ANSWER ONLY]/[RECORD
ALSO]/[OFF], then press /OK to
conrm.
» The setting is saved.
Set the answering machine
language
Note
• This feature only applies to models with multiple-
language support.
The answering machine language is the language
for the announcements.
1 Press /MENU / in standby mode to
access the main menu.
2 Select [ANSW MACHINE] >
[LANGUAGE], then press /OK to
conrm.
3 Select a language, then press /OK to
conrm.
» The setting is saved.
Through the base
Press to turn the answering machine on or
off in standby mode.
Note
• When the answering machine is switched on, it answers
incoming calls after a certain number of rings based on
the ring delay setting.
Through the handset
1 Press /MENU / in standby mode to
access the main menu.
2 Select [ANSW MACHINE] > [VOICE
ANSWER], then press /OK to conrm.
26 EN
Set the answer mode
You can set the answering machine and
select if the callers can leave messages. Select
[RECORD ALSO]if you allow the callers to
leave messages. Select [ANSWER ONLY] if you
forbid the callers to leave messages.
1 Press /MENU / in standby mode to
access the main menu.
2 Select [ANSW MACHINE] > [VOICE
ANSWER], then press /OK to conrm.
3 Select an answer mode, then press /OK
to conrm.
» The setting is saved.
Note
• If the memory is full, the answering machine switches to
[ANSWER ONLY] mode automatically.
3 Select [ANSWER ONLY] or [RECORD
ALSO], then press /OK to conrm.
4 Select [PLAY], then press /OK to
conrm.
» You can listen to the current
announcement.
Announcements
The announcement is the message your caller
hears when the answering machine picks up
the call. The answering machine has 2 prerecorded announcements: [RECORD ALSO]
and [ANSWER ONLY].
Record an announcement
The maximum length of the announcement you
can record is 3 minutes. The newly recorded
announcement automatically replaces the old
one.
1 Press /MENU / in standby mode to
access the main menu.
2 Select [ANSW MACHINE] >
[ANNOUNCEMENT], then press /OK
to conrm.
3 Select [ANSWER ONLY] or [RECORD
ALSO], then press /OK to conrm.
4 Select [RECORD], then press /OK to
conrm.
5 Start recording close to the microphone
after the beep.
6 Press /OK to stop recording or the
recording stops after 3 minutes.
» You can listen to the newly recorded
announcement on the handset.
Listen to the announcement
1 Press /MENU / in standby mode to
access the main menu.
2 Select [ANSW MACHINE] >
[ANNOUNCEMENT], then press
/MENU to conrm.
Note
• You can no longer listen to the announcement when
you pick up an incoming call.
Restore the default announcement
1 Press /MENU / in standby mode to
access the main menu.
2 Select [ANSW MACHINE] >
[ANNOUNCEMENT], then press /OK
to conrm.
3 Select [RECORD ALSO]or [ANSWER
ONLY], then press /OK to conrm.
4 Select [USE DEFAULT], then press /OK
to conrm.
» The handset displays a conrmation
request.
5 Press /OK to conrm.
» The default announcement is restored
Incoming messages
Each message can be up to 3 minutes long.
When you receive new messages, the new
message indicator ashes on the answering
machine and the handset displays a notication
message.
Note
• If you pick up the phone when the caller leaves a
message, the recording stops and you can talk to the
caller directly.
27EN
Note
• If the memory is full, the answering machine switches to
[ANSWER ONLY] automatically. Delete old messages
to receive new ones.
Listen to the incoming messages
You can listen to the incoming messages in the
sequence they are recorded.
From the base
• To start/Stop listening, press .
• To adjust the volume, press / .
• To play the previous message/replay the
current message, press .
• To play the next message, press .
• To delete the current message, press .
Note
• No deleted messages can be recovered.
From the handset
1 Press /MENU / in standby mode to
access the main menu.
2 Select [ANSW MACHINE] > [PLAY],
then press /OK to conrm.
» New messages start playing. Old
messages start playing if there is no
new message.
• Press / to stop listening.
• Press /OK to enter the options menu.
• Press +/- on the left side of the handset to
increase/decrease the volume.
Delete an incoming message
From the base
Press when you listen to the message.
» The current message is deleted.
From the handset
1 When you listen to the message, press
/OK to enter the options menu.
2 Select [DELETE], then press /OK to
conrm.
» The current message is deleted.
Delete all old incoming messages
From the base
Press and hold in standby mode.
» All old messages are permanently
deleted.
From the handset
1 Press /MENU / in standby mode to
access the main menu.
2 Select [ANSW MACHINE] > [DELETE
ALL], then press /OK to conrm.
» The handset displays a conrmation
request.
3 Press /OK to conrm.
» All old messages are permanently
deleted.
Note
• You can delete the read messages only. No deleted
messages can be recovered.
Set the ring delay
You can set the number of times the phone
rings before the answering machine picks up
the call.
1 Press /MENU / in standby mode to
access the main menu.
2 Select [ANSW MACHINE] > [RING
DELAY], then press /OK to conrm.
3 Select a new setting, then press /OK to
conrm.
» The setting is saved.
Note
• Make sure that the answering machine is switched on
before this feature can be applied.
28 EN
Tip
• When you access the answering machine remotely,
you are recommended to set the ring delay to [TOLL
SAVER] mode. This is a cost effective way to manage
your messages. When there are new messages, the
answering machine picks up the call after 3 rings; When
there is no messages, it picks up the call after 5 rings.
Call screening
2 Select [ANSW MACHINE] > [REMOTE
ACC.] > [CHANGE PIN], then press
/OK to conrm.
3 Enter the old PIN, then press /OK to
conrm.
4 Enter the new PIN code, then press
/OK to conrm.
5 Enter the new PIN code again, then press
/OK to conrm.
» The setting is saved.
You can hear the caller while he is leaving a
message. Press /OK to answer the call.
Remote access
You can operate your answering machine when
you are away from home. Simply make a call to
your phone with a touch tone phone and enter
your 4-digit PIN code.
Note
• The remote access PIN code is the same as your
system PIN. The preset PIN is 0000.
Activate/deactivate the remote access
You can allow or block remote access to the
answering machine.
1 Press /MENU / in standby mode to
access the main menu.
2 Select [ANSW MACHINE] > [REMOTE
ACC.], then press /OK to conrm.
3 Select [ACTIVATE]/[DEACTIVATE], then
press /OK to conrm.
» The setting is saved.
Change the PIN code
1 Press /MENU / in standby mode to
access the main menu.
Access the answering machine
remotely
1 Make a call to your home number with a
touch tone phone.
2 Enter # when you hear the announcement.
3 Enter your PIN code.
» You now have access to your
answering machine, and you can now
listen to the new messages.
Note
• You have 2 chances to enter the correct PIN code
before your phone hangs up.
4 Press a key to carr y out a function. See the
Remote access commands table below for
a list of available functions.
Note
• When there is no message, the phone hangs up
automatically if no key is pressed for 8 seconds.
Remote access commands
Key Function
1 Repeat the current or listen to the
previous message.
2 Listen to messages.
3 Skip to the next message.
6 Delete the current message.
29EN
7 Switch the answering machine on.
(not available when you listen to the
messages).
8 Stop listening to the message.
9 Switch the answering machine off.
(not available when you listen to the
messages).
Behavior of the LED display on the
base station
The table below shows you the current status
with different LED display behavior on the base
station.
LED
display
Steady on • There is no new message and
Flashing • There is a new message and the
Flashing
(Fast)
Message status
the memory is not full.
• The handset is switched on.
• Enter the paging mode
memory is not full.
• There is an incoming call.
• Recording an incoming message/announcement.
• Message playback.
• Remote access/listen to messages from the handset.
• There is no new message and
the memory is full.
• Enter the registration mode
30 EN
12 Services
The phone supports a number of features that
help you handle and manage the calls.
Call list type
You can set whether you can view all incoming
calls or missed calls from this menu.
set in the menu. For example, you set 604 as
the detect number and 1250 as the prex.
When you have dialed out a number such as
6043338888, your phone changes the number
to 12503338888 when it dials out.
Note
• The maximum length of a detect number is 10 digits.
The maximum length of an auto prex number is 10
digits.
Select the call list type
1 Press /MENU / in standby mode to
access the main menu.
2 Select [SERVICES] > [CALL LISTS], then
press /OK to conrm.
3 Select an option, then press /OK to
conrm.
Auto conference
To join an external call with another handset,
press /OK.
Activate/Deactivate auto conference
1 Press /MENU / in standby mode to
access the main menu.
2 Select [SERVICES] > [CONFERENCE],
then press /OK to conrm.
3 Select [AUTO]/[OFF], then press /OK
to conrm.
» The setting is saved.
Set auto prex
1 Press /MENU / in standby mode to
access the main menu.
2 Select [SERVICES] > [AUTO PREFIX] >
[DETECT DIGIT], then press /OK to
conrm.
3 Enter the detect number, then press
/OK to conrm.
4 Select [PREFIX], then press /OK to
conrm.
5 Enter the prex number, then press /OK
to conrm.
» The setting is saved.
Note
• This is a country dependent feature.
• To enter a pause, press and hold .
• If the prex number is set and the detect number is left
empty, the prex number is added to all outgoing calls.
• The feature is unavailable if the dialed number starts
with * and #.
Network type
Auto prex
This feature checks and formats your outgoing
call number before it is dialed out. The prex
number can replace the detect number you
Note
• This is a country dependent feature. It only applies to
models with network type support.
31EN
1 Press /MENU / in standby mode to
access the main menu.
2 Select [SERVICES] > [NETWORK TYPE],
then press /OK.
3 Select a network type, then press /OK.
» The setting is saved.
Select the recall duration
Make sure that the recall time is set correctly
before you can answer a second call. In normal
case, the phone is already preset for the recall
duration. You can select among 3 options:
[SHORT], [MEDIUM] and [LONG]. The
number of available options varies with different
countries. For details, consult your service
provider.
1 Press /MENU / in standby mode to
access the main menu.
2 Select [SERVICES] > [RECALL TIME],
then press /OK to conrm.
3 Select an option, then press /OK to
conrm.
» The setting is saved.
Dial mode
Note
• This feature only applies to models that support both
tone and pulse dial.
2 Select [SERVICES] > [DIAL MODE], then
press /OK to conrm.
3 Select a dial mode, then press /OK to
conrm.
» The setting is saved.
Note
• If your phone is in pulse dial mode, press * during a call
for temporary tone mode. Digits entered for this call
are then sent out as tone signals.
Auto clock
Note
• This service is network dependent.
• Make sure you have subscribed to the caller ID service
before you use this feature.
It synchronizes the date and time on your
phone with the public switched telephone
network (PSTN) automatically. For the date to
be synchronized, make sure the current year is
set.
1 Press /MENU / in standby mode to
access the main menu.
2 Select [SERVICES] > [AUTO CLOCK],
then press /OK to conrm.
3 Select [ON]/[OFF]. Press /OK.
» The setting is saved. .
Dial mode is the telephone signal used in your
country. The phone suppor ts tone (DTMF) and
pulse (rotary) dial. Consult the service provider
for detailed information.
Set the dial mode
1 Press /MENU / in standby mode to
access the main menu.
32 EN
Register additional handsets
You can register additional handsets to the base
station. The base station can register up to 4
handsets.
1 Press and hold on the base station for
5 seconds.
2 Press /MENU / in standby mode to
access the main menu.
3 Select [SERVICES] > [REGISTER], then
press /OK to conrm.
4 Enter the system PIN. Press / to
make corrections. Then press /OK to
conrm the PIN.
Tip
• The handset number displays beside the handset name
in standby mode.
Note
• For models with an answering machine, you hear a
conrmation beep.
» Registration is complete in less than 2
minutes. The base automatically assigns
a handset number to the handset.
Note
• If the PIN is incorrect or no base is found within a
certain period, your handset displays a notication
message. Repeat the above procedure if registration
fails.
Note
• The preset PIN is 0000. No change can be made on it.
Unregister handsets
If two handsets share the same base station, you
can unregister a handset with another handset.
1 Press /MENU / in standby mode to
access the main menu.
2 Select [SERVICES] > [UNREGISTER],
then press /OK to conrm.
3 Enter the system PIN. (The preset PIN
is 0000). Press / to remove the
number.
4 Select the handset number to be
unregistered.
5 Press /OK to conrm.
» The handset is unregistered.
Restore default settings
You can reset your phone settings to the
original factory settings.
1 Press /MENU / in standby mode to
access the main menu.
2 Select [SERVICES] > [RESET], then press
/OK to conrm.
» A conrmation request is displayed on
the handset.
3 Press /OK to conrm.
» All settings are reset.
33EN
13 Technical data
General specication and features
• Talk time: 16 hours
• Standby time: 250 hours
• Range indoor: 50 meters
• Range outdoor: 300 meters
• Phonebook list with 50 entries
• Redial list with 20 entries
• Call log with 50 entries
• Answering machine with up to 30 minutes
recording time
• Caller identication standard support: FSK,
DTMF
Battery
• Philips: 2 x AAA Ni-MH 1.2V 550 mAh
rechargeable batteries
Power adapter
Base and charger
• Philips, S003IB0600040 input: 100-240V,
50-60Hz 0.15A, output: 6 V 400 mA
• Philips, SSW-1920UK-2 input: 100-240Vac,
50-60Hz 0.2A, output 6 V 500 mA
Power consumption
• Power consumption in idle mode: around
0.70 W (XL300), 0.75 W (XL305)
Weight and dimensions (XL300)
• Handset: 167 grams
• 178.62 x 54.08 x 31.3 mm (H x W x D)
• Base: 127 grams
• 46.95 x 120 x 109.57 mm (H x W x D)
• Charger: 69 grams
• 42.7 x 91.48 x 87.35 mm (H x W x D)
Weight and dimensions (XL305)
• Handset: 167 grams
• 178.62 x 54.08 x 31.3 mm (H x W x D)
• Base: 161 grams
• 46.95 x 120 x 109.57 mm (H x W x D)
• Charger: 69 grams
• 42.7 x 91.48 x 87.35 mm (H x W x D)
34 EN
14 Notice
Declaration of conformity
Hereby Philips Consumer Lifestyle, declares
that the XL300/XL305 is in compliance with
the essential requirements and other relevant
provisions of Directive 1999/5/EC. You can nd
the Declaration of Conformity on www.p4c.
philips.com.
This product has been designed, tested and
manufactured according the European R&TTE
directive 1999/5/EC.
Use GAP standard
compliance
general have the ability to emit and receive
electromagnetic signals.
One of Philips’ leading Business Principles is to
take all necessary health and safety measures
for our products, to comply with all applicable
legal requirements and to stay well within
the EMF standards applicable at the time of
producing the products.
Philips is committed to develop, produce and
market products that cause no adverse health
effects. Philips conrms that if its products are
handled properly for their intended use, they
are safe to use according to scientic evidence
available today.
Philips plays an active role in the development
of international EMF and safety standards,
enabling Philips to anticipate further
developments in standardization for early
integration in its products.
The GAP standard guarantees that all DECT™
GAP handsets and base stations comply with
a minimum operating standard irrespective of
their make. The handset and base station are
GAP compliant, which means they guarantee
the minimum functions: register a handset,
take the line, make a call and receive a call. The
advanced features may not be available if you
use them with other makes. To register and use
this handset with a GAP compliant base station
of different make, rst follow the procedure
described in the manufacturer's instructions,
then follow the procedure described in this
manual for registering a handset. To register a
handset from different make to the base station,
put the base station in registration mode, then
follow the procedure described in the handset
manufacturer's instructions.
Compliance with EMF
Koninklijke Philips Electronics N.V. manufactures
and sells many products targeted at consumers,
which, like any electronic apparatus, in
Disposal of your old product
and batteries
Your product is designed and manufactured
with high quality materials and components,
which can be recycled and reused.
When this crossed-out wheeled bin symbol is
attached to a product it means that the product
is covered by the European Directive 2002/96/
EC. Please inform yourself about the local
separate collection system for electrical and
electronic products.
Please act according to your local rules and
do not dispose of your old products with your
normal household waste.
Correct disposal of your old product helps to
prevent potential negative consequences for the
environment and human health.
35EN
Your product contains batteries covered by the
European Directive 2006/66/EC, which cannot
be disposed with normal household waste.
Please inform yourself about the local rules
on separate collection of batteries because
correct disposal helps to prevent negative
consequences for the environmental and
human health.
When this logo is attached to a product, it
means a nancial contribution has been paid to
the associated national recovery and recycling
system.
Environmental information
All unnecessary packaging has been omitted.
We have tried to make the packaging easy to
separate into three materials: cardboard (box),
polystyrene foam (buffer) and polyethylene
(bags, protective foam sheet.)
Your system consists of materials which can
be recycled and reused if disassembled by
a specialized company. Please observe the
local regulations regarding the disposal of
packaging materials, exhausted batteries and old
equipment.
36 EN
15 Frequently
asked questions
No signal bar is displayed on the screen.
• The handset is out of range. Move it closer
to the base station.
• If the handset displays [UNREGISTERED],
register your handset.
Tip
• For further information, see the chapter 'Services',
section 'Register additional handsets'.
• Make sure the handset is placed properly
on the charger. The battery icon animates
when charging.
• Make sure the docking tone setting is
turned on. When the handset is placed
correctly on the charger, you can hear a
docking tone.
• The charging contacts are dirty. Disconnect
the power supply rst and clean the
contacts with a damp cloth.
• Batteries are defective. Purchase new ones
from your dealer.
No display
• Make sure the batteries are charged.
• Make sure there is power and the phone is
connected.
If I fail to register the additional handsets to
the base station, what do I do?
Your base memory is full. Unregister the unused
handsets and try again.
No dialing tone
• Check your phone connections.
• The handset is out of range. Move it closer
to the base station.
No docking tone
• The handset is not placed properly on the
base station/charger.
• The charging contacts are dirty. Disconnect
the power supply rst and clean the
contacts with a damp cloth.
I cannot change the settings of my voice mail,
what do I do?
The voice mail service is managed by your
service provider but not the phone itself.
Contact your service provider to change the
settings.
The handset on the charger does not charge.
• Make sure the batteries are inserted
correctly.
Bad audio (crackles, echo, etc.)
• The handset is nearly out of range. Move it
closer to the base station.
• The phone receives interference from the
nearby electrical appliances. Move the base
station away from them.
• The phone is at a location with thick walls.
Move the base away from them.
The handset does not ring.
Make sure the handset ringtone is turned on.
The caller ID does not display.
• The service is not activated. Check with
your service provider.
• The caller's information is withheld or
unavailable.
Note
• If the above solutions do not help, disconnect the
power supply from both the handset and base station.
Try again after 1 minute.
37EN
16 Index
F
nd handsets/paging 6
A
additional handsets 32
Adjust volume 13
announcements 27
answer a call 12
answering machine 26
answering machine language 26
auto clock 32
auto conference 31
auto prex 31
B
base station
installation 8
overview 6
battery 8, 10, 34
C
call list type 20
call log 20
call screening 29
caller ID 12, 20
calling 12
charging 10
conference call 14, 15, 31
contacts 18
G
GAP 35
H
hearing aid compatibility 23
I
incoming message 27
intercom 15
L
language setting
answering machine 26
handset 9, 25
LED behavior 30
listen to messages 28
M
missed calls 20, 20
N
network type 31
D
date setting 9, 32
default settings 33
delete messages 28
display icons 6
disposal 35
E
ECO mode 24
ECO+ mode 24
38 EN
O
on or off 26
P
phone settings 23
phonebook 18, 20, 22
PIN
answering machine 10, 29
power adapter 34
R
recall time 32
redial 22
register/unregister 32, 33
remote access to the answering machine 29
ring delay 28
S
safety 3
save a number 20
signal strength 11
sounds
battery tone 23
docking 23
keytone 23
ringtone 23
speaker phone 13
T
text entry 17, 40
time setting 9, 32
transfer call 15
troubleshooting/FAQ 37
two calls/call on hold 14
39EN
17 Appendix
Text and number input tables
key Characters (for English/Latin)
0 space 0
1 - 1
2 A B C 2
3 D E F 3
4 G H I 4
5 J K L 5
6 M N O 6
7 P Q R S 7
8 T U V 8
9 W X Y Z 9
* * ? / \ ( )
# # ' , - &
40 EN
41EN
0168
Specifications are subject to change without notice
© 2013 Koninklijke Philips Electronics N.V.
All rights reserved.
UM_XL30x_90 _EN_V1.0
WK13041
Loading...
