TFT LCD
Earpiece
Right soft key
Hang-up and
Power key
Alphanumeric
keypad
Left soft key
Navigation
and , keys
Pick-up key
Microphone
Charger and
USB port
Your phone
Philips continuously strives to improve its products. Due to software upgrading, some contents in this user guide
may be different from your product.Philips reserves the rights to revise this user guide or withdraw it at any
time without prior notice. Please take your product as standard.
Home screen
Status Bar
Shortcuts
SIM setting shortcuts
and notifications
Clock Display
Your phone’s home screen consists of the following
areas:
Keys
Learn about the main keys.
Key Definition Function
Dial Make or answer a call.
(
Confirm Select or confirm a option.
,
)
Hang-up/
Power/
Exit
End a call;
Hold to turn on/off the phone;
Return to idle screen.
L
R
Left soft
key
Right soft
key
Select the options on the
screen.
Select the options on the
screen.
Shortcut menu
The shortcut on home screen can open the
applications tab you often used.
Select shortcut menu:
1
Go to Menu>Settings>General>Shortcut >
Change to enter shortcut list.
2
Tap Select/Cancel to change shortcut menu.
3
Press L to confirm setting.
Stylus
While the first time you turn on the phone, you are
asked to do calibration for the stylus. Thus, strokes
or taps by the stylus will be precisely displayed on
the screen. (Or go to
calibration
).
Settings> General>Pen
Your phone 1
Icons & symbols
Learn about the icons and symbols on the screen.
Icons Definition Function
Silent
Vibration
only
Battery
SMS
MMS
Wap
message
Missed call
Call diverts
Bluetooth
Bluetooth
headset
2 Your phone
Your phone will not ring
when receiving a call.
Your phone will vibrate when
receiving a call.
The bars indicate the battery
level.
You have a new message.
You have a new multimedia
message.
You have received a Wap
push message.
You have missed a call.
All your incoming voice calls
are being forwarded to a
number.
Bluetooth is activated.
The Bluetooth headset is
connected.
Headset
Alarm
Roaming
Home zone
GSM
network
Blacklist
Profile
Memory
card
The headset is plugged into
the phone.
The alarm clock is activated.
Displayed when your phone
is registered to a network
other than your own
(especially when you’re
abroad).
A zone designated by your
network operator. Contact
your service provider for
details.
your phone is connected to a
GSM network.The more bars
are shown the better the
reception is.
Indicates that blacklist feature
is activated.
General mode is activated.
The memory card is in use.
Table of contents
Getting started . . . . . . . . . . . . . . . . . . . . . . . . . 4
Insert SIM card and Charge the battery. . . . . . . 4
Insert a Micro SD card (Memory card) . . . . . . . 6
Connect to your PC . . . . . . . . . . . . . . . . . . . . . . 6
Customize your phone . . . . . . . . . . . . . . . . . . . . 7
Basic function . . . . . . . . . . . . . . . . . . . . . . . . . .8
Use basic call functions . . . . . . . . . . . . . . . . . . . . 8
Receive and send messages. . . . . . . . . . . . . . . . . 9
Enter text . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
Manage your phonebook . . . . . . . . . . . . . . . . . 11
MultiMedia. . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
Media player . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
Camera . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
Video recorder . . . . . . . . . . . . . . . . . . . . . . . . . 15
FM radio . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
Business applications . . . . . . . . . . . . . . . . . . . 17
Manage your calendar . . . . . . . . . . . . . . . . . . . . 17
Alarm . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
Bluetooth. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
Read E-books . . . . . . . . . . . . . . . . . . . . . . . . . . 18
File management . . . . . . . . . . . . . . . . . . . . . . . . 19
Use blacklist . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
Check world clock . . . . . . . . . . . . . . . . . . . . . . 20
Calculator . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
Currency converter . . . . . . . . . . . . . . . . . . . . .20
Web applications & Java . . . . . . . . . . . . . . . . . 21
Browser . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
Java applications . . . . . . . . . . . . . . . . . . . . . . . . . 21
Settings. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
SIM setting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
Display setting . . . . . . . . . . . . . . . . . . . . . . . . . .22
General setting . . . . . . . . . . . . . . . . . . . . . . . . . 22
Sound setting . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
Call options . . . . . . . . . . . . . . . . . . . . . . . . . . . .24
Connectivity. . . . . . . . . . . . . . . . . . . . . . . . . . . . 24
Safety & Precaution . . . . . . . . . . . . . . . . . . . . .25
Precaution . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25
Tips . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26
Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . 26
Trademark Declaration. . . . . . . . . . . . . . . . . . . 27
Specific Absorption Rate Information . . . . . . . . 28
Limited warranty . . . . . . . . . . . . . . . . . . . . . . . . 28
Declaration of Conformity . . . . . . . . . . . . . . . .30
Tips & tricks. . . . . . . . . . . . . . . . . . . . . . . . . . .31
Table of contents 3
Getting started
Congratulations on your purchase and welcome to
Philips!
To get the most of your product and enjoy all
Philips has to offer, register your product at:
www. philips. com/welcome
More details about your product, please access:
www.philips.com/support
Note: Please read the safety instructions in the "Safety &
Precaution" section before use.
1
Remove the back cover.
Insert SIM card and Charge the
2
Take out the battery.
battery
Learn about installing SIM card and charging the
battery for the first use.
Insert SIM card
Follow the steps below to insert your SIM card.
Remember to turn off your mobile phone before
removing the back cover.
4 Getting started
3
Insert SIM1/SIM2.
4
Install the battery.
5
Replace the back cover.
Charge the battery
A new battery is partially charged. The battery icon
in the upper-right corner shows the battery level of
charging status.
Getting started 5
Note:
•
You can user the phone while it is charging.
•
Keeping the charger plugged to the mobile phone when
the battery is fully charged will not damage the battery.
The only way to turn off the charger is to unplug it, so it
is advisable to use an easily accessible power socket.
•
If you do not intend to use your phone for several days,
we recommend that you remove the battery.
•
If a fully charged battery left unused, it will lost its charge
over time.
•
If a battey is being used for the first time or the battery
has not been used for a prolonged period, it may take
longer time to recharge.
Insert a Micro SD card (Memory card)
You can expand the memory of your phone by
adding a micro-SD card.
1
Align your micro-SD card with the slot. Put it in
place.
2
To remove the micro-SD card, press the card to
release it.
6 Getting started
Connect to your PC
Data communication software (Mobile Phone
Tools) offers instant sychronization between your
phone and your computer. You can use the
software for the data synchronization between your
phone and PC, like phonebook, calendar, SMS
messages, and audio/video/picture files.
Install MobilePhoneTools on your PC
1
Insert the supplied Data communication
software into the CD drive.
2
Run the autorun.exe program.
3
Make selections as prompted, and installation
starts automatically.
Connecting your Phone to the PC
1
Connect your phone to the PC by using
supplied USB cable or through the Bluetooth.
2
When using the USB cable for connection,
select
COM port on your phone.
3
On your PC, double click the MobilePhoneTools
icon, then the connected icon is displayed.
Customize your phone
Customize your phone to match your preferences.
Set clock
1
On the home screen, go to Menu>Settings>
General>Time & date.
2
Select Set time/Set date: Enter the digits or
long press navigation key
+ or - until you reach
the desired digits.
SIM settings
1
Check that your phone is turned on. Enter the
PIN code if required.
2
Go to Settings>SIM settings>Dual SIM >SIM
card1/SIM card 2 settings
Name your SIM card, and activate it or not.
3
Select SIM1 or SIM2 to be the primary card.
,
Note:
•
The PIN code is preconfigured and communicated to
you by your network operator or retailer.
•
If you enter an incorrect PIN code three times in
succession, your SIM card will be blocked. To unblock it,
you must request the PUK code from your operator.
•
If you enter an incorrect PUK code ten times in
succession, the SIM card will be locked permanently.
When this happens, please contact your network
operator or retailer.
Profiles
The profiles are defined for several scenes.They
consist of the settings for ringtones, volume, and
others. With preset profiles, you can easily adjust
the settings as desired.
1
Go to Profiles, press ,Activate to activate
the profile.
2
Press Lto modify ringtones, volume and
others.
To activate
Meeting mode, long press # on
the home screen.
Note: If you select Flight mode, you disable the connection
between your phone and your mobile phone network.
Getting started 7
Basic function
Use basic call functions
Learn to make or answer a call and use basic call
functions.
Make a call
1
Enter the phone number.
2
Press ( to dial the number.
3
Press ) to hang up.
Note: For international calls, long press 0 to enter the
"+" sign for the international prefix.
Answer and end a call
1
Press ( to answer the call (Press the
navigation key + or - to adjust the volume).
2
Press , to select H-Free mode.
3
Press ) to hang up.
Note: You can use the supplied headset to answer or end a
call.
8 Basic function
Make a conference call
If network applicable, you can handle two or more
calls, or make a conference call.
1
During a call, enter a phone number, and then
press
(
number is dialled.
2
The first call is put on hold at this time.
3
You can press , to toggle between 2 calls.
4
To end the call, select Options>End or End all.
to dial the number. The second
Use speed dial
On the idle screen, you can call a number by long
pressing a numeric key.
To assign a contact to a speed-dial key:
1
Select Settings > General > Speed dial
2
Choose a numeric key.
3
Press , to add a number.
Make an emergency call
Without a SIM card in phone, you can press R to make
the emergency call.
In Europe, the standard emergency number is 112;
in the UK, it is 999.
Receive and send messages
You can use the Messaging menu to send text
message, multimedia message and E-mails.
Send a SMS message
1
Select Menu>Messaging>SMS>Create SMS.
2
Write your text message.
3
Press , to send the message.
Send a MMS message
1
Select Menu>Messaging>MMS>Create MMS.
2
Enter the contact number (To), a copy (Cc), a
blind copy (
3
Edit contents, and press LOptions to add
multimedia contents (photo, audio, video,
attachment or bookmark text).
4
Press , to send the Multimedia message.
Bcc) and subject.
Note: Copyright protected pictures and sound cannot be
sent by MMS.
Send an E-mail
1
Go to E-mail > Email accounts > Options >
New account. After setting up a new account,
press
, to activate it.
2
Go to Write Email, enter the address (To), a
copy (
Cc), a blind copy (Bcc), subject and
attachment.
3
Edit the E-mail contents.
4
Press L to send the E-mail.
Note: Consult your mail service provider for the mail
server configuration.
Receive E-mails
Select E-mail>Send and receive, you can receive
E-mails from the Internet.
To receive E-mails automatically:
1
Go to E-mail > Email accounts > Options >
Edit > Advance settings.
2
In Account settings, select your desired time
span.Your mail box will be checked automatically
after each time span.
Basic function 9
Enter text
Your mobile phone supports a number of text entry
methods, including T9 input, English input, numeric
input and symbol input.
Keys:
Keys/Virtual
keypad
#
*
Function
/ Use virtual keypad or stylus to enter
text.
Select a input method.
Long press to switch T9 English input
on or off.
*/ Enter symbols and punctuations.
0/ Insert a space.
Change to a new line.
Note: Depending on the language you select for your
phone, the supported input methods may vary.
10 Basic function
Introduction of input methods:
Input method Function
English input Press the keys that are marked
®
T9
predictive
text input
Numeric input Press the numeric key to enter a
with the letter you wish to enter.
Press once to get the first letter
on the key, press twice quickly to
get the second letter and so on
until the letter you want is
displayed on the screen.
You need to press only once on
the key corresponding to each
letter needed to spell a word:
keystrokes input are analyzed
and the word suggested by T9
is displayed at the pop-up
window.
number.
®
Pinyin input Input pinyin and select a
Stroke input Press the keys corresponding to
character.
the required strokes according
to sequence to get the desired
character. The stroke input
method classifies a Chinese
character into 5 basic strokes:
(horizontal, vertical, left falling
stroke, right falling stroke and
over-down) as well as a special
stroke. When the stroke you
need does not correspond to the
5 basic strokes, replace it with
the special strokes.
Manage your phonebook
Learn about basic phonebook function.
Add a new contact
Method one:
1
On the idle screen, enter a number, select a
location. (
2
To SIM1/To SIM2/To phone/).
Save the number, and add details as desired.
3
Press L to finish saving.
Method two:
1
Go to Contacts>View contacts.
2
Press L to enter options, and add a new
contact.
Note: For contacts on the smart phonebook, you can add
detailed information, like home number, office number,
contact pictures and ringtones.
Search for a contact
1
Go to Contacts>View contacts.
2
There are four phonebooks above the list: all,
phone, SIM1 and SIM2.
3
Select a desired phonebook.
4
Enter the first few letters of the name in the
search bar. (For example “Don Remly” enter
DR)
5
Select the contact from the list.
Basic function 11
Manage your contacts
You can copy or move contacts between the SIM
card and phone, or delete contacts. Go to
Contacts>View contacts or Advanced, select the
desired option.
1
Set group:
You can group your contacts as different groups.
For different groups, you can use different ringtones
for identification, and send messages to a group.
2
Add contacts to a group:
-
Select Contacts>View groups, enter a group.
-
In Caller groupss, press ,to add members
for the group.
Back-up your contacts
You can save the important contacts as .vcf files in
your phone or memory card.
Back up contact information:
1
In Contacts>View contacts, select your
desired contact.
2
Press LOptions>Send contact>Save as file
>Phone or Memory card, select a folder.
12 Basic function
3
Enter a file name, and press , to finish backing
up the file.
Restore contact information:
1
Go to My files, find the back-up file.
2
Press LOptions>Use to restore the contact
to your desired phonebook.
Special numbers
You can keep a list of useful numbers on your
phone, such as own numbers, service numbers,
voicemail and emergency numbers.
Function
My numbers
Emergency
Voice mail
Service
numbers
Definition
Edit the phone number and name.
Edit your emergency phone number.
Set your voice mail server number,
as well as retrieve your voice mails.
Consult the network operator for
the account information.
On the idle screen, long press
dial the voice mail number.
Contact your network operator for
more information.
1 to
MultiMedia
Media player
Save ARM, AAC, MIDI,WAV and AAC+ music files
under the
Audio folder on your phone and memory
card.
Play music
1
Go to Music>Music player>Tracks, select
your desired song in the folder.
2
Using the following keys to control playback:
Function Definition
,/ Pause and resume playback.
,/
Stop playback.
</ Select previous track.
>/ Select next track.
Press navigation key
adjust volume.
R Return to the previous menu.
)
Go to the home screen.
+ or - to
Player settings
Go to Music player>Settings:
•
Music source: Play audio files from your phone
or memory card.
•
Play in background: Continue to play music
after exiting the music player.
•
Equaliser: Select music style suitable to your
songs.
•
Repeat: Repeat one (play current file
repeatedly);
folder repeatedly).
•
Shuffle: Play music files in the folder randomly.
•
Refresh list: Refresh all songs in your list.
To turn off the music player on the idle screen
Press
Note: When listening to music, adjust the volume to a
moderate level. Continuous exposure to high volume may
impair your hearing.
Repeat all (play all the files in the
), and then press ,.
MultiMedia 13
Camera
Learn about camera function. Let you take photos
as desired by using your phone.
Take a photo
1
Go to Menu>Camera, select camera mode.
2
Aim the lens at the subject.
-
Press navigation key < or > to zoom in or
zoom out.
3
Press , to take a photo.
4
Press R to exit.
All the photos taken are saved to
or Memory>Pictures.
My files>Phone
View photos
Go to View picture,
1
View photos: press navigation key < or > to
select a photo.
2
Zoom in/out photos: press navigation key + or
- to zoom in or out a photo. After zooming in a
photo, press the navigation key
slide the screen.
3
Rotate photos: press L to rotate a photo.
14 MultiMedia
+, -,
<
or > to
Camera settings
While using the camera, pressLto select settings:
Icon Option Function
View picture
Image size
Quality
Timer
Continuous
shot
mode
Scenes
Storage
Effects
EV
View the photos you have
taken.
Select image size.
Set image quality.
Select a time span for auto
photographing.
Set to take photos
continuously.
Switch the picture mode.
Select a scene to take a
photo.
Select default storage
location.
Add special effects to the
photos.
Select a exposure value.
Shutter
Banding
Restore
Note: To zoom in or out a photo, please ensure that the
photo is taken in a size equal to or greater than 640x480.
Adjust the shutter sound.
Select a band to avoid the
impacts on photos caused
by flickers from lighting
sources.
Restore to default settings.
Video recorder
Learn about video recorder function. Let you
record a video clip as desired by using your phone.
Record a video
1
Go to Menu>Camera, select video recorder
mode.
2
Aim the lens at the subject.
3
Press , to record a video clip.
4
Press R to exit.
All the videos recorded are saved to
files
>Phone or Memory>Videos.
My
Play a video clip
Go to View videos,
1
Press , start or pause playing a video clip.
2
Press navigation key + or - fast rewind or
forward.
3
Press navigation key < or > to adjust volume.
4
PressRexit.
Video recorder settings
While using the video recorder, pressLto select
settings:
Icon Option Function
View videos
Other setting, see Camera settings on page 14.
Note: To send a video clip via E-mail, the file size should
equal to smaller than 100K.
View the videos you have
recorded.
MultiMedia 15
FM radio
Lear about listening to radio programs by using a FM
radio.
Listen to a radio station
1
Plug the supplied headset into your phone.
2
Go to Music>FM radio, press L
Options>Auto preset. It starts scanning
automatically and save the available channels.
3
Press the navigation key < or > to select a
station.
4
Press , to turn off FM radio.
FM radio settings
Go to LOptions>Settings:
•
Background play: Continue playback after exit
FM radio.
•
Loud speaker: Listen to radio through the
speaker.
•
Auto search: Turn on/Turn off auto search.
•
RDS: Activate RDS services (depend on the
radio station service).
16 MultiMedia
When you are listening to a RDS station, your
phone displays the following details: station name,
program type (for example, News, Sports and Info),
and frequency.
To turn off the FM radio on the home screen
Press
), and then press ,.
Record radio programs
You can record a radio program when listen to it.
1
Go to LOptions>Record.
2
Press , to start recording, and then press L
to stop recording.
3
Press , to save the file.
The files recorded are saved to
Memory>Audio.
My files>Phone or
Business applications
Manage your calendar
You can create your to-do list and make a plan on
your calendar.
Create your to-do list
1
Go to Tools>Calendar select a date, and then
press
LOptions>Add event.
2
Edit reminder settings.
3
Press L to save the task.
4
To change your to-do list, select the task, and
then press
LOptions to edit the task.。
Check your to-do list
You can check your to-do list in weekly or monthly
view. Go to
your to-do list.
Tools>Calendar, press , to check
Check the calendar
Go to Tools>Calendar, you can check the
calendar.
Alarm
Learn about how to set and use an alarm. You can
set up to five alarms.
Set an alarm
1
Go to Tools>Alarm.
2
Select an alarm, press , to edit the alarm.
3
Press L to finish setting the alarm.
Turn off an alarm
1
Go to Tools>Alarm.
2
Select the alarm you want to turn off.
3
Press the navigation key < or >
to select
Off
.
Stop an alarm
When the alarm rings,
•
Select Stop: The alarm stops.
•
Select Snooze: The alarm will sound again after
the set
Snooze (mins) interval.
Business applications 17
Bluetooth
Your phone can connect to a compatible Bluetooth
device for exchanging data.
Connect to a Bluetooth device
1
Go to Bluetooth>Power, turn on the
Bluetooth function.
2
Select Find devices, a list of available Bluetooth
devices appears.
3
Select the device you wish to connect.
4
Enter your Bluetooth password to start pairing
(0000 by default).The pairing is made if your
pairing request is accepted by the other part.
Send files via Bluetooth
1
Go to My files, select the file you want to send.
2
Press LOptions>Send>To Bluetooth.
3
Select a device.
4
Press , to start send the file.
Receive files via Bluetooth
1
Go to Bluetooth>Setting>Visibility, make
your phone visible to other Bluetooth devices.
2
Enter the password and accept the request.
18 Business applications
3
Press , to start receiving the file. The files
received are saved to
Memory>Others.
Note: If you do not use the Bluetooth feature for some
time, you should deactivate it in order to conserve battery
power.
My files>Phone or
Read E-books
You can read E-books (.txt file) on your phone.
Start reading an E-book
1
Go to Tools>Text reader.
2
Select the .txt file you wish to read.
3
Press , to start reading.
Go to
Options>Global settings>Encoding, select
the encoding suitable to your language.
Reading setup
Go to Options, you can setup the following:
•
Find: Find specific words in the file.
•
Jump to: Jump to the parts you desired.
•
Add bookmark: Add current page to
bookmark.
•
Go to bookmark: Read the page saved as
bookmark.
•
Delete bookmark: Delete the page saved as
bookmark.
•
Settings: Set font size, scroll screen
automatically or read E-book on full screen.
File management
Learn about how to use and manage your files and
folders.
Use your files
1
Set a photo as contact picture or wallpaper:
-
Open My files>Pictures, select a photo.
-
Press LOptions>As phonebook or Set as
wallpaper
2
Set an audio file as ringtone:
-
-
Note: To set photos you have taken as contact picture,
select Wallpaper in Image size.
.
Select an audio file.
Press LOptions>Set as ringtone.
Share your files
You can share your photos, audio or video files with
others via MMS, E-mail or Bluetooth.
1
Select your desired photos, audio or video files.
2
Press LOptions>Send.
Note: To send files via E-mail, the file size should smaller
300K.
Manage your files
You can copy, move or delete a file in a folder.
1
Open a folder, press LOptions>Select
multiple
>Select all or Select one by one,enter
multiple selection list.
2
Press , Select or Cancel.
3
Go to Options to finish copying, moving or
deleting.
Use blacklist
Learn about how to set the blacklist, you can reject
the incoming calls or messages from those
included in the blacklist.
Business applications 19
Activate blacklist
1
Go to Tools>Black list>Mode.
2
Press the navigation key < or > to activate
blacklist function.
Add a phone number to blacklist
1
Go to Black list>Black List numbers.
2
Edit the blacklist, add contacts by entering a
phone number or select a contact from
phonebook.
Check world clock
You can display two clocks on the home screen,
one showing your local time and one the time of
your destination.
Set world clock
Select Tools>World clock,
1
In Local settings/Foreign settings, press the
navigation key < or > to select a city.
2
Press LOptions to turn on/off Daylight
saving
.
3
In Switch local/foreign, switch clock.
20 Business applications
Note: Alarms, reminders, programmed events are time
zone independent.
Calculator
Use the numeric keys to calculate on the phone.
Currency converter
1
Go to Tools>Currency converter, enter the
rate.
2
Enter the sum of money in Local. Press L to
confirm.
Note: The result of the calculator is indicative only.
Web applications & Java
Browser
You can use this function to browse the Internet.
Consult your network operator for the service
subscription, data account information, and WAP
settings.
Access web sites
1
Go to Browser.
2
Select Enter address, enter your desired
websites.
3
Press , to access the website.
Set homepage
1
Go to Browser, browse a website.
2
Select Options, save current website as
Homepage. You can set the websites you
usually used as homepage.
Add bookmarks
1
Go to Browser, browse a website.
2
Select Options, add current website to
Bookmarks. You can add your favorite websites
to bookmarks.
Java applications
Learn about how to use Java applications and play
games. Your phone is preloaded with some Java
games and applications.
Install Java games
1
Connect your phone to a PC via supplied USB
cable.
2
Save .jar file to My files>Others.
3
Install the Java games.
Play Java games
1
Go to Fun>Java.
2
Select a game from the list.
3
Press , to start playing the game.
Web applications & Java 21
Settings
SIM setting
Function
Dual SIM
SIM card1/
SIMcard2 settings
Primary settings The default SIM card is SIM1.
Ask when
power on
Definition
Change SIM card slot settings.
Set SIM card name.
Select Active mode to receive calls or
messages from a SIM card.
You are provided services by primary SIM by
default.
You can select SIM1 or SIM2 as primary card.
Display SIM setting screen or not
while power on the phone.
Display setting
Function
Wallpaper
Themes
Backlight
level
22 Settings
Definition
Select an image as the wall paper of
your phone.
Define the theme for your phone.
Select the brightness of backlight.
Backlight
duration
Greeting
Select the duration of backlight.
Select whether to show greetings
when your phone is turned on.
General setting
Function
Language
Time&date
Speed dial
Pen
calibration
Security setup This menu allows you to use
PIN protection Set PIN or PIN2 password protection for
Change PIN/PIN2 Change your PIN and PIN2 passwords as
Definition
Select a language for your phone.
Set the clock of the phone.
Call a contact by long pressing a
numeric key.
See “Stylus” on page 1.
passwords to protect your SIM
card, phone, and information
stored on the phone.
your SIM card. (The PIN or PIN2 are
provided by the network operator.)
desired.
Phone lock Set password protection for your phone.
Safeguard Set password protection for the information
Shortcut
Dedicated
key
Default
storage
You are required to enter the password
each time you turn on the phone (1122 by
default).
stored on your phone.
Set shortcut menu.
Set a navigation key as direct access
to a menu.
Select the default storage location
for your files: phone or memory
card.
Memory
status
Check the memory occupancy of
information of different memory
storage.
Active slide
Auto screen
lock
Factory
setting
Active slide answer on.
Set an idle time span for the screen
to be locked automatically.
Restore your phone settings to the
default values. You need to enter
your phone lock password
.
default)
(1122 by
Sound setting
Function
Alert type
Ringtones
Ring volume
Key sound
Slide sound
Tap vibration
Shutter
sound
Battery low
Definition
Select alert types.
Select a ringtone for incoming calls
and messages.
Adjust the volume of rings.
Select whether the key sounds
when pressed.
Select whether the slide sounds
when opened or closed.
Select whether there is
accompanying vibration for each
tap.
Select shutter sounds for your
camera.
Select whether a warning tone is
emitted when the battery level is
low.
Settings 23
Call options
Function
Headset
answer
Any key
answer
Call time
reminder
Call services
Call divert
Call barring
Auto redial
Fixed dial
24 Settings
Definition
Use headset to answer an incoming
call.
Answer an incoming call by
pressing any keys (except
Get reminded after the call time
span once or repeatedly.
)).
Set call services.
Divert incoming calls to your voice
mailbox or another phone number.
Set limits to your incoming and
outgoing calls.
Keep redialing the number that fails
to go through.
Restrict your outgoing calls to
certain numbers (PIN2 code
required).
Connectivity
Function
Network
settings
Network
selection
Preferences Select your preferred network.
Bowser
Connections
Java settings
Java audio Set the volume level.
Java vibration Turn the vibration on or off.
Select SIM Select the SIM card.
Java SIM1/SIM2
Profile
Heap size Display allowed maximum size for Java
Definition
Set network settings for your
phone.
Select the network for your phone (service
subscription dependent). Automatic is
recommended.
See “Browser” on page 21.
The menu allows you to define the
Internet access profiles of your
phone. Consult your network
operator for details.
Set Java settings for your phone.
Select a Java network (service subscriptiondependent).
memory.
Safety & Precaution
Precaution
Keep your phone away from small children
Keep your phone and all accessories out of the reach of small
children. Small parts may cause choking or serious injury if
swallowed.
Radio Waves
Your phone transmits/receives radio waves in the GSM frequency
(900/1800MHz).
Check with the vehicle manufa cturer that electronic equipment
used in your vehicle will not be affected by radio energy.
Your cellular telephone complies with all applica ble safety standards
and the Radio Equipment and Telecommunications Terminal
Equipment Directive 1999/5/EC.
Switch off your phone...
Turn off the phone when in an aircraft.The use of mobile phones in
an aircraft may be dangerous for the operation of the aircraft,
disrupt the mobile phones network and may be illegal.
In hospitals, clinics, other health care centers and anywhere else where
you may be in the close vicinity of medical equipment.
In areas with a potentially explosive atmosphere (e.g. petrol stations
and also areas where the air contains dust particles, such as metal
powders).In a vehicle tran sporting flammable products or a vehicle
powered by liquefied petroleum gas (LPG).In quarries or other areas
where blasting operations are in progress.
Your mobile phone and your car
Avoid using your phone while driving and obey all regulations that
restrict the use of mobile phones while driving. Use hands free
accessories to increase your safety when possible. Ensure that your
phone and car kit do not block any air ba gs or other security devices
fitted in your car.
Handle your phone carefully and sensibly
For the optimal and satisfactory operation of the phone you are recommended to use the phone in the normal operating position.
•
Do not expose your phone to extreme temperatures.
•
Do not immerse the phone in any liquid; if your p hone is damp,
switch it off, remove the battery and let them dry for 24hrs before
using them again.
•
To clean the phone, wipe it with a soft cloth.
Protect batteries from damage
You should only use Philips Authentic Accessories, as the use of
any other accessories may dama ge your phone and may be
dangerous, and will make all guarantees for your Phili ps phone null and
void. The use of an unspecified type of battery may also cause an
explosion.
Make sure damaged parts are re placed immediately by a qualifi ed
technician and that they are replaced with genuine Philips replacement
parts.
•
Your phone is powered by a re chargeable battery.
•
Use specified charger only.
•
Do not incinerate.
•
Do not deform or open the battery.
•
Do not allow metal object s (such as keys in your pock et) to short
circuit the battery contacts.
•
Avoid exposure to excessive heat (>60° C or 140° F), moisture or
caustic environment s.
Environm ental care
Remember to observe the local regulations regarding the disposal
of the packaging materials, exhausted batteries and old phone and
please promote their recycling.Philips has marked the battery and
packaging with standard symbols designed to promote the recycling and
appropriate disposal of your eventual waste.
:The labelled packaging material is recyclable.
:A financial contributio n has been made to the associated national
packaging recovery and recycling system.
:The plastic material is recyclable (also identifies the type of plastic).
Safety & Precaution 25
WEEE Marking in the DFU: “Information to the Consumer”
Disposal of your old product
Your product is designed and manufactured with high quality materials
and components, which can be recycled and reused.
When this crossed-out wheeled bin symbol is attached to a
product it means the product is covered by the European
Directive 2002/96/EC
Please inform yourself about the local separate collection system
for electrical and el ectronic products.
Please act according to your local r ules and do not dispose of your old
products with your normal household waste. The correct disposal of
your old product will help prevent potential negative consequences for
the environment and human health.
This device may contain commodities, tech nology or software subject to
export laws and regulations from the US and other countries. Diversion
contrary to law is prohibited.
Tips
Pacema kers
If you have a pacemaker:
•
Always keep the phone more than 15 cm from yo ur pacemaker
when the phone is switched on, in order to avoid potential
interference.
•
Do not carry the phone in a breast pocket.
•
Use the ear opposite to the pacemaker to minimize the potential
interference.
•
Switch off your phone if you suspect that interference is taking place.
Hearing aids
If you are a user of a hearing aid, consult your physician and hearing aid
manufacturer to learn whet her your particular device is sus ceptible to
cellular phone interference.
EN 60950 Norm
In hot weather or after prolonged exposure to the sun (e.g., behind a
window or a windscreen), the temperature of your phone's casin g might
increase. Be very careful in this case when picking up your phone and also
avoid using it with an ambient temperature over 40° C.
26 Safety & Precaution
How to prolong the battery life of your phone
To have your mobile phone function properly, sufficient battery power
is important. For the power-saving purpose, do the following, if
applicable:
•
Turn off the Bluetooth function of your phone.
•
Set the backlight level and duration of your phone to a low value.
•
Turn on the auto keypad lock, turn off the key sounds, tap vibration,
or vibration alerts.
•
Turn off your phone if there is no coverage. Otherwise, the phone
will keep searching for network, and drain your battery power.
Troubleshooting
The phone does not switch on
Remove/reinstall the battery. Then charge the phone until the battery
icon stops scrolling. Unplug the charger and try to switch the mobile on.
The display shows BLOCKED when you switch on the phone
Somebody tried to use your phone but didn’t know the PIN code nor
the unblocking code (PUK). Contact your service provider.
The display shows IMSI failure
This problem is related to your subscription. Contac t your operator.
Your phone doesn’t return to idle screen
Long press the hang-up key or switch off the phone, check that the SIM
card and the battery are install ed correctly and switch it on agai n.
The network symbol is not displayed
The network connection is lost. Either you are in a radio shadow (in a
tunnel or between tall buildings) or you are outside the network
coverage area. Try from another place, try to reconnect to the network
(especially when abroad), check that the antenna is in place if your mobile
has an external antenna, or contact your network operator for
assistance/information.
The display doesn’t respond (or the display responds slowly) to
key pre sses
The display responds more slowly at very low temperatures. This is
normal and does not affect the operation of the phone. Take the phone
to a warmer place and try again. In other cases please contact your
phone supplier.
Your battery seems to over heat
You might be using a charger that was not intended for use with your
phone. Make sure you always use the Philips authentic accessory shipped
with your phone.
Your phone doesn’t display the phone numbers of incoming
calls
This feature is network and subscription dependent. If the network
doesn’t send the caller’s number, the phone will display Call 1 or
Withheld instead. Contact your operator for detailed information on
this subject.
You can’t send text messages
Some networks don’t allow m essage exchanges with oth er networks.
First check that you have entered the numb er of your SMS centre, or
contact your operator for detailed information on this subject.
You can’t receive and/or store JPEG pictures
A picture may not be accepted by your mobile phone if it is t oo large, if
its name is too long, or if it doesn’t have the correct file format.
You feel that you have missed some calls
Check your call divert options.
When charging, the battery icon shows no bar and t he outline
is flashing
Only charge the battery in an environment where the temperature does
not go below 0°C (32°F) or above 50°C (113°F).
In other cases please contact your phone supplier.
The display shows SIM failure
Check that the SIM card has been inserted correctly. If the problem
persists, your SIM card may be damaged. Contact your operator.
When attempting to use a feature in the menu, the display
shows NOT ALLOWED
Some features are network dependent. They are only available,
therefore, if the network or your subscription supports them. Contact
your operator for detailed information on this subject.
The display shows INSERT YOUR SIM CARD
Check that the SIM card has been inserted correctly. If the problem
persists, your SIM card may be damaged. Contact your operator.
The autonomy of your phone seems lower than indicated on
the user guide
The autonomy is linked to your settings (e.g., ringer volume, backlight
duration) and the features you use. To increase the autonomy, and
whenever possible, you must deactivate features you do not use.
Your phone doesn’t work well in your car
A car contains many metallic parts that absorb electromagnetic waves
which can affect the phone’s performance. A car kit is available to
provide you with an external antenna and enables you to make and
receive phone calls without handling the handset.
Notes: Check with the local authorities whether or not you are allowed
to use the phone while driving.
Your phone is not charging
If the battery is completely flat, it might take several minutes of precharge (up to 5 minutes in some cases) before the charging icon is
displayed on the screen.
The picture captured with the phone camera is not clear
Make sure that the camera lens on both sides is clean.
Trademark Declaration
®
T9
T9® is a registered trademark of Nuance
Communications, Inc..
JAVA JAVA is a trademark of Sun Microsystems, Inc.
Bluetooth™ Bluetooth™ is a trade-mark owned by
telefonaktiebolaget L M Ericsson, Sweden and licensed
to Philips.
Philips PHILIPS and PHILIPS’ Shield Emblem are register ed
trademarks of Koninklijke Philips Electronics N.V.
manufactured by Shenzhen Sang Fei Consumer
Communications Co., Ltd. under license from
Koninklijke Philips Electronics N.V..
Safety & Precaution 27
Specific Absorption Rate Information
International standards
THIS MOBILE PHONE MEETS THE INTERNATIONAL
RECOMMENDATIONS FOR EXPOSURE TO RADIO WAVES
Your mobile phone is a radio transmitter and receiver. It is designed and
manufactured not to exceed the limits for exposure to radio frequency
(RF) energy defined by the international standards. These
recommendations have been established by the International
Commission on Non-Ionizing Radiation Protection (ICNIRP) and, the
Institute of Electrical and Electronics Engineers (IEEE) that forecast a
substantial safety margin for assuring the protection of all persons,
regardless of age and health.
The exposure recommendations for mobile phones use a measurement
unit known as the Specific Absorption Rate (SAR). The SAR limit
recommended by the ICNIRP for the mobile phones used by the general
public is
2.0W/kg averaged over ten grams of tissue and, is 1,6W/kg
averaged over one gram of tissue
Tests for SAR have been conducted using recommended operating
positions with the mobile phone transmitting at its highest certified
power level in all tested frequency bands. Although the SAR is
determined at the highest certified power level, the actual SAR levels of
the mobile phone while operating are generally below the maximum SAR
value. This is because the phone is designed to operate at multip le power
levels so as to use only the power required to reach the network. In
general, the closer you are to a base station antenna, the lower the
power output.
While there may be differences between the SAR levels of various
phones and at various positions, they all meet the international
protection standards for exposure to radio waves.
The highest SAR value for this Xenium X510 model phone
when tested for compliance against the standard was 0.503 W/
kg for ICNIRP recommendation.
For limiting the radio waves exposure, it is recommended to reduce the
mobile phone call duration or to use a headset. The purpose of those
precautions is to take the mobile phone away from t he head and the
body.
28 Safety & Precaution
by IEEE Std 1528 for the head.
Limited warranty
1
What Does This Limited Warranty Cover?
Philips warrants to the original retail purchaser (“Consumer” or “You”)
that this Philips cellular product and all accessories origin ally provided by
Philips in the sales package (“Product”) are free from defects in materials,
design and workmanship under normal use in accordance with the
operating instructions and pursuant to the following terms and
conditions. This limited warranty extends only to the Consumer for
Products purchased and used in the original country of purchase. The
limited warranty is valid only in Philips’ intended coun try of sales of the
product.
2.
How Long is The Limited Warranty Period?
The limited warranty period for the Product extends for ONE (1) YEAR
from the date of purchase of the Product, documented by valid proof of
purchase. The limited warranty for original Philips rechargeable battery
extends for six (6) mo nths from the date of pu rchase.
3.
What Will Philips Do if The Product is Not Free From Material
Defects in Materials and Workmanship During The Limited
Warr anty Pe riod?
During the limited warranty period, Philips or its authorized serv ice
representative will, at its option either repair or replace, without char ge
for parts or labour, a materially defective Product with new or
refurbished parts or Product and return such repaired or replaced
Product to the Consumer in working condition. Philips will retain
defective parts, modules or equipment.
Repaired or replaced Product will be covered by this limited warranty
for the balance of the original limited warranty period or ninety (90) days
from the date of repair or replacement whichever is longer. Repair or
replacement of Product, at Philips’ option is your exclusive remedy.
4.
What is Not Covered By This Limited Warranty?
This limited warranty does not cover:
a) Product that has been subjected to misuse, accident, shipping or other
physical damage, improper installation, abnormal operation h andling,
neglect, inundation, fire, water or other liquid intrusion; or
b) Product that has been damaged due to repair, alteration, or
modification by anyone not authorized by Philips; or
c) Product that has reception or operation problems caused by signal
conditions, network reliability or cable or antenna systems; or
d) Product defects or problems caused by uses with non-Philips products
or accessories; or
e) Product which warranty/quality stickers, product serial number or
electronic serial number has been removed, altered or rendered illegible;
or
f) Product purchased, used, serviced, or shipped for repair from outside
the original country of purchase, or used for commercial or institutional
purposes (including bu t not limited to Products us ed for rental
purposes); or
g) Product returned without valid proof of purchase or which proof of
purchase has been altered or is illegible.
h)Normal wear and tear or Force Majeure.
5.
How Do You Get Warranty Service?
a) Return the Product to an authorized service center of Philips. You may
contact the local Philips office for the location of the nearest authorized
service center.
b)The SIM card must be removed from the Product before it is given to
Philips. Philips assumes no liability for damaged or loss of the SIM card or
the data contained therein.
c)If the Product failure is not covered by this limited warranty, or this
limited warranty is inapplicable, void or invalid due to any terms and
conditions stated herein, the Consumer will be charged for the cost of
repair or replacement of the Product and all other related cost incurred
in repairing or replacing the Product.
d) IMPORTANT - you are required to return the Product together with
a valid proof of purchase which must identify the point of purchase, da te
of purchase, Product model and Product serial number clearly.
6.
Other Limitation: This Warranty is The Entire Agreement.
EXCEPT FOR THE EXPRESS WARRANTIES SET FORTH ABOVE AND
THOSE IMPLIED BY LAW AND WHICH CANNOT BE EXCLUDED
OR MODIFIED BY AGREEMENT, PHILIPS PROVIDES NO OTHER
WARRANTY WHETHER EXPRESS OR IMPLIED (WHETH ER BY
STATUTE, UNDER THE OPERATION OF LAW OR OTHERWI SE)
AND SPECIALLY DISCLAIMS ANY WARRANTY OF SATISFA CTORY
QUALITY MERCHANTABILITY OR FITNESS FOR A PARTICULAR
PURPOSE.
PHILIPS’ TOTAL LIABILITY FOR DAMAGES RELATING TO OR
ARISING OUT OF THE PURCHASE OR USE OF THE PRODUCT,
REGARDLESS OF THE TYPE OR CAUSE OF SUCH DAMAGE OR THE
FORM OR CHARACTERISATION OF THE CLAIM ASSERTED (E.G.
CONTRACT OR TOPIT), SHALL NOT EXCEED THE ORIGINAL
PURCHASE PRICE PAID FOR THE PRODUC T.
HOWEVER IN NO EVENT SHALL PHILIPS BE LIABLE FOR ANY
PUNITIVE, SPECIAL, INCIDENTAL, INDIRECT OR
CONSEQUENTIAL DAMAGES (INCLUDING BUT NOT LIMITED TO
THE LOSS OF USE, LOSS OF TIME, INCONVENIENCE, COMMERIAL
LOSS, LOST PROFITS, LOST BUSINESS OPPORTUNITIES, COST OF
SUBSTITUTION OF GOODS OR SERVICES, INVESTMENTS,
DAMAGE TO GOODWILL OR REPUTATION, OR L OSS OF DATA
AND CLAIMS BY THIRD PARTIES) RESULTING FROM PURCHASE
OR USE OF THE PRODUCT, TO THE FULLEST EXTENT ALLOWED
BY LAW, WHETHER OR NOT PHILIPS HAS BEEN ADVISED OF T HE
POSSIBILTY OF SUCH DAMAGES. THESE LIMITATIONS SHALL
APPLY NOTWITHSTANDING THE FAILURE OF THE ESSENTIAL
PURPOSE OF ANY LIMITED REMEDY.
This limited warranty represents the complete and exclusive agreement
between the Consumer and Philips with respect to this cellular Product
and it supercedes all prior agreements between the parties, oral or
written, and all other commun ications between the parti es relating to
the subject matter of this limited warranty. No carrier, retailer, agent,
dealer, employee, thereof, or employee of Philips is authorized to make
modifications to this limited warranty and you should not rely on any
such representation.
This limited warranty does not affect the Consumer’s statutory rights
under applicable national laws in force.
Safety & Precaution 29
Declaration of Conformity
We,
Shenzhen Sang Fei Consumer
Communications Co., Ltd.
11 Science and Technology Road,
Shenzhen Hi-tech Industrial Park,
Nanshan District, Shen zhen 518057
China
declare under our sole responsibility that the product
Xenium X510
Philips GSM/GPRS 900/1800
TAC number: 35190704
to which this declaration relates, is in conformity with the follow ing
Standards:
SAFETY : EN 60950-1:2006+A11:2009
HEALTH: EN 50360:2001
EN 62209-1:2006
EMC: ETSI EN301 489-1 v1.8.1
ETSI EN 301 489-7 v1.3.1
ETSI EN 301 489-17 v1.3.2
SPECTRUM: ETSI EN 301 511 v9.0.2
ETSI EN 300 328 v1.7.1
We hereby declare that all essential radio test suites have been carried
out and that the above named product is in conformity to all the essential
requirements of Directive 1999/5/EC.
The conformity assessment procedure referred to in Article 10 and detailed in Annex IV of Directive 1999/5/EC has been followed with the involvement of the following Notified Body:
TÜV RHEINLAND PRODUCT SAFETY GMBH
Am Grauen Stein 51105 Köln
Germany
Identification mar k: CE 0197
July 19, 2010
30 Safety & Precaution
Tips & tricks
Optimizing your Philips Xenium battery performance
Here are some steps to help you optimize your Philips
Xenium’s battery performance.
How to optimize the standby and talk time of your phone?
•
Always ensure that your phone profile is
appropriately set to meet your actual usage. Profile
setting significantly impacts the phone’s battery
performance. In general, Outdoor Mode is the most
power-draining setting while Silent Mode consumes
the least amount of power.
•
If you’re using a Xenium phone with a dual SIM
feature, try to activate the 2 SIM cards only when
absolutely necessary. If you are in a country with
single coverage, deactivate the non-covered SIM to
prolong battery usage.
•
If you’re not using applications like Bluetooth, WIFI,
GPS and JAVA, turn them off. And be sure to lock
your phone to prevent accidental pressing of the
keys with the auto-lock feature.
•
Adjust the intensity and duration of your display
screen’s backlight to low or medium level and for
the shortest duration. In general, the lower the
backlight level and the shorter the duration, the
more power you will save.
•
Avoid using or placing your phone near magnetic
objects (eg. a radio or television) or on metal
surfaces, which will impact the network connection
and ultimately drain power from your battery.
How to extend your battery’s life?
•
Full charging and full running down of your battery
will extend its life. Charge the battery once the lowbattery warning comes on.
•
Temperature will impact battery usage. Over time,
heat will degrade your battery’s performance. Keep
your phone out of the sun or a hot car. If in low
temperature, place your phone in a warmer place
(eg. your pocket), as battery capacity decreases as
the temperature drops.
•
Always use authentic accessories as they enable
your battery to perform at its peak. Non-authentic
accessories (eg. chargers) can damage your battery
and even your phone.
Tips & tricks 31
Loading...
