Philips X100 User Manual
Discover your phone
LCD display
Right soft key
Left soft key
Navigation key
Pick-up key
Microphone
Philips continuously strives to improve its products. Therefore,
Philips reserves the rights to revise this user guide or withdraw it
at any time without prior notice. Philips provides this user guide "as
is" and does not accept, except as required by the applicable law,
liability for any error, omission or discrepancy between this user
guide and the product described. The device is meant to be connected to GSM/GPRS networks.
1
OK key
Hang-up key/
Power on/off
Alphanumeric
keypad
Headset/Charger connector
Getting Started
Inserting the SIM card
1. Press on the back cover and slide the cover as shown. As
shown in the right picture, take out the battery.
2. Insert your SIM card. Please ensure that beveled corner facing
you and gold contact downwards.
3. As show, reinstall the battery and the back cover.
2
Charging the battery
Plug in the connector as
shown. Then plug the other
end into a power socket.
Insert a Micro-SD card (memory card)
Push down the card holder
and lift it up. Align your
micro-SD card with the slot.
Put it in place. Press down
the card holder and pull it
until it is locked.
To transfer files from your
PC, use a compatible card
reader.
Remove the SIM card
Press the slot to unlock the
SIM card. Slide the SIM card
and take them out.
3
How to...
Switch the phone on/
off
Unlock the keypad Press RUnlock, and then *.
Lock the keypad Long press *. To set an idle time
Long press).
span for the keypad to be locked, go to
LMenu > Settings > Security >Auto
keypad lock.
Make a call Enter the phone number using the key-
Answer a call When the phone rings, press (.
End a call Press ).
Access Contacts Press LMenu > Contacts on idle
Select text entry
methods
Access the main
menu
Quickly return to idle
when browsing
menus
Silent on/off Long press # on idle screen.
pad and press (.
screen. You can search for and edit a
contact, make a call or send a message.
Press # repeatedly.
Press LMenu on idle screen. Press +,
-, <, > to navigate through the menus.
Press LOK to select.
Press ).
4
Dual SIM settings On idle screen, press RGo to >Dual
Select ringtones and
adjust ring volume
Check call history Go to LMenu > Calls.
Browse the Internet Go to LMenu > Browser.
To receive push messages (specially format-
ted SMS messages that
contain a URL).
Play games Go to LMenu > Games.
STK Go to LMenu > Browser > STK1 or
Use calculator Go to LMenu > Tools > Calculator.
Access FM radio Plug the supplied earphone into your
Make a list of important things
SIM. Select SIM1 setup or SIM2 setup,
and then press LOK to edit operator/
Card name and choose alert for incoming callings and messages.
If you want to choose SIM1 or SIM2 as
primary SIM, select Primary SIM swap,
and then press LSwap.
Go to LMenu > Settings > User pro-
files. Select your desired profile. Go to
Edit to select your options. Press , to
activate the profile.
Go to LMenu > WAP > Settings > Ser-
vice message settings > Enable push. Press
LOK. To check push messages, go to
LMenu > WAP > Service inbox.
STK2 (depending on whether your SIM
card supports STK).
phone and go to LMenu > Multimedia
> FM radio.
Go to LMenu > Tools > To do list.
5
Select an image as the
wallpaper of your
phone
Select the duration of
backlight
Set a navigation key
as direct access to a
menu
Set PIN password
protection for your
SIM card
Set password protection for your phone
Restore factory
settings
Go to LMenu > Settings > Display >
Wallpaper.
(If you want to use a customized wallpaper from Micro SD card, you need to set
it again everytime you turn off the
phone.)
Go to LMenu > Settings > Display >
LCD backlight.
Go to LMenu > Settings > General >
Dedicated key. Press LEdit to change
current settings.
Go to LMenu > Settings > Security >
Change password > SIM PIN or SIM PIN2.
(The default PIN is provided by the network operator. )
Go to LMenu > Settings > Security >
Phone lock.
(The default phone lock password is
0000.)
Go to LMenu > Settings > Restore
factory settings.
6
Text entry
1. Press # repeatedly to select your desired inputs.
ABC/abc/Abc: for Smart English entry
ABC/abc/Abc: for multi-tap English entry
123: for numeric entry.
2. Press * to enter a symbol and punctuation.
3. Press 0 to enter a space.
Smart English input ( ABC/abc/Abc)
You need to press only once on the key corresponding to each letter needed to spell a word: keystrokes are analyzed and the word
suggested is displayed at the pop-up window.
Example: how to enter the word "home":
1. Press 4, 6, 6, 3.
The screen displays the first word of a list: Good.
2. Press > to scroll and select Home.
3. Press LSelect to confirm.
Multi-tap input (ABC/abc/Abc)
Press repeatedly on the key corresponding to each letter, until the
desired character appears.
Example: how to enter the word "home":
Press 4, 4 (GHI) 6, 6, 6 (MNO), 6 (MNO), 3,
3
(DEF).
7
Call settings
Speed dial
On the idle screen, you can call a preset speed dial number by long
pressing a numeric key (2 to 9). To assign a speed-dial
key to a contact, go to Settings > Call > Speed dial.
Handle multiple calls (network-dependent)
1. Go to Menu > Settings > Call
call divert.
2. Make a second call
During an active call, enter the number or select a contact, and
press (.
Answer a second call
During an active call, press (.
. Activate call waiting, and deactivate
Messages
Write and send SMS
1. Go to Menu > Messaging > SMS > Write message.
2. Write your message. To use templates, press LOptions > Use
templates.
3. To send the message, press ,.
If you want to choose a SIM to send the message, press
L
Options > Send(Primary SIM)/Send(Secondary SIM).
Read and reply to SMS
Go to Menu > Messaging > SMS > Inbox. Press , to read current
message, and LOptions > Reply to reply to current message.
8
