Philips VR285 User Manual
2 head mono VCR
• On-Screen Display
• One-Button
automatic installation including automatic time
download and correction
• ShowView™/VideoPlus™– the easiest way to programme a Timer
• Digital Studio Picture Control for an excellent picture quality
• Laser-Cut Video Heads – the maximum precision for the ultimate
recording quality
• Automatic time used indication
• Easy-to-read big VCR Display
2 head mono VCR
VR285
2 head mono VCR
VR285
ShowView and VideoPlus are Trademarks of Gemstar Development Group
Subject to modification without notice
Product Information
Reception
•
Tuning: PLL, CH - FREQ entry, 99 presets
• Tuning/Install Features: Automatic Search, Manual Search/Store
• Automatic Time/Date Download: PDC,Text (Time)
User Interface
•
OSD Menu Languages: Dutch, English,French, German, Italian,
Spanish, Swedish
•
Picture Improvement System: Digital Studio Picture Control,
Edge Noise Canceller
•
Audio Recording System: Linear
•
Audio Recording Level: Automatic
Programming
•
Number of Events: 6 / month
•
Programming Mode: OTR,Remote
•
Record Control & Transmitter Identification: PDC,VPS
•
Programming System: Daily / Weekly
•
Automatic Sat. Recording: From EXT2
Tape Deck
•
Number of Video / FM Audio/Erase Heads: 2/0/0
•
Play:+1x, -1x
•
Playback Features: Still, Multiple Search Speeds,Variable Slow
Motion Speed
•
Index Search: Next / Previous index search
•
Tape Length Recognition: Automatic
•
Tape Counter: Linear relative, Linear time used
•
Automatic Functions at Tape End: Rewind after Play – Eject after Record
•
Winding /Rewinding Time (E180): 100 sec.
•
Head Cleaning Mode: Automatic,Manual
Connectors Rear
•
EXT1: Black, Euro CVBS In & Out
•
EXT2: Blue, Euro CVBS In & Out,Euro Decoder, RGB loop through
•
Antenna In & Out: 75 Ohms (IECtype
)
•
Mains Connector: Standard (IECtype
)
General
•
Voltage / Frequency: 198-264 V/50Hz
•
Backup Presets: 1yr
•
Backup Clock,Timer Events & Calendar: 7hrs
•
Power Cons.in Play/Std-By/ Low Power Std-By: 12.5W / 9.5W /<6W
•
Remote Control: RT182
•
Equipment Supplied: Antenna cable, Mains cord, Batteries
•
Set Size – W x D x H (mm): 380 x 260 x 93
•
Packaging – W x D x H (mm): 450 x 382 x 180
•
Weight including / excluding package in kg: 5.5 /3.6
/02 /05 /07 /13 /39 /58
Full (UHF+VHF)Tuner x UHF only x x x x
TV System Off Air PAL B/G PAL I PAL I PAL B/G PAL B/G-I, SECAM
PALB/G-D/K,SECAM
B/G-L/L’ B/G-D/K
Follow TV, Direct Record - - - - Yes Yes
Programming System ShowView™ VideoPlus™ VideoPlus™ ShowView™ ShowView™ ShowView™
Record/Playback Std PAL PAL PAL PAL PAL-SEC-MESEC PAL-MESEC
Record Speed SP SP / LP SP / LP SP SP SP
Modulator System PAL G PAL I PAL I PAL G - PAL G/K
Modulator Range Ch 21 - 55 Ch 21 - 55 Ch 21 - 55 Ch 21 - 55 - Ch 21 - 55
Modulator Feature - Auto Seek Auto Seek - - Modulator Preadjustment Ch 36 Ch 35 Ch 35 Ch 36 - Ch 36
Delivery Menu Language English English English English French English
Remote RT182 / 101 101 101 101 104 101
Product Highlights
• Digital Studio Picture Control
Thanks to a digital Noise-Reduction Circuit,you are sure to obtain the best
picture quality with any kind of tape.
• Automatic Time Download
At the first installation, your VCR will automatically download the time. Your
VCR will be the clock reference in your home, as the time is readjusted every
day. You don’t even have to worry anymore about changing from summer to
winter time!
• TURBO DRIVE
Enjoy the ease of use and the comfort of one of the fastest VCR decks in
the world.
• Automatic Head Cleaning
Clean heads ensure an optimum picture quality. Each time you put a tape in
your VCR,the heads will be cleaned automatically.
