Philips TX100001 User Manual

AT&T IR U-verse

TV Remote Control

User Guide

Installing Batteries

The remote control requires two
AA size (1.5V) Alkaline batteries to
work.

Tips: replace the batteries every nine
months for optimum performance.

1. On the back of the remote con­trol, press the battery cover tab
forward, lift and remove the bat­tery cover.

2. Insert two (2) AA-size batteries,
matching the + and – symbols
with the battery pictures.

3. Put the battery cover back on
and test the remote control by
pressing the AT&T key. The AT&T
key should light up to indicate
that batteries are inserted prop­erly.

4. Re-pairing to TX Transmitter unit
is required upon battery replace­ment on the remote control and
vice visa. Battery placement is
simple, remove the battery lid on
the TX Transmitter unit and insert
the coin cell battery provided in
the battery slot. Next, replace
battery lid on the TX Transmitter
Unit.

5. Refer to item 7 – RF Pairing with
Transmitter on this user manual
for full instruction.

Controlling Other
Devices

In order to control other devices with
your U-Verse TV Remote Control, you
need to tell the remote control what
types of devices you have. Section 1
guides you through the steps need­ed to do this. When you complete
Section 1, the volume and channels
will always work on the U-verse TV
Receiver no matter what mode you
are in. If you want to change this or
allow the POWER key to affect multi­ple devices then you can also follow
the steps in Section 2. If you’d like
to reset any of the settings then you
can go to Sections 3 and 4.

1. Programming the

remote to control other
devices

To use the U-verse TV remote con­trol for your other devices, you will
need to program one or more of the
TV, DVD or AUX buttons at the top of
the remote control. There are two
ways to do this. If your device is list­ed in the Manufacture Code List at
the end of this Manual, you can use
section A. If your device is not listed,
you will need to use section B.

Note:
The AUX button may be programmed

to operate a VCR, Home Theater In A
Box (HTIB), Receiver or Amplifier.

A. Manually

Use the following steps to program
the TV, DVD or AUX mode keys:

1. Power on the device you want to
program

2. Locate the 4-digit set-up code
for the device you want to pro­gram from the Manufacture
Code List in this manual. If your
device is not listed you will need
to use section B on “Using the
Automatic Search”. If there are
multiple codes listed for your
device, you may need to repeat
steps 2 through 7 to find the cor­rect one.

3. Press and hold the appropriate
mode key you want to assign to
this device (TV, DVD or AUX) on
the remote control

4. While holding the mode key,
press the OK key

5. Release both the mode key and
the OK key

– All the mode keys should flash

twice

– You’ll now have 10 seconds to

start step 6

6. Enter the appropriate 4-digit set­up code for your device (from
the Manufacture Code List) by
pressing the number keys (0-9)
on the remote control

– If the mode key flashes three

times, then a correct code has
been entered.

– If the mode key gives a long

flash, then an invalid code has
been entered. Start over at step

3.

– If all the mode keys give a long

flash, then the remote control
has timed-out. Start over at step
3

7. Point the remote control at the
programmed device and press
the power key once

– The device should turn off

– If it does not turn off, repeat

steps 2 through 6 trying each
code for your brand until you
find the correct code

8. Repeat steps 1 through 7 to pro­gram another device.

Note: If you are interrupted while you
are programming, the remote con­trol may time-out before you com­plete the code set-up and you will
need to start over. This is indicated
by a red flash of the mode keys.

Now that your devices are pro­grammed, you can press the appro­priate mode key on the remote con­trol to work with the selected device.
To use the remote control for your
U-verse TV Receiver again, press the
AT&T mode key.

Combination Devices Note: If you
have an integrated or combination
unit, such as a TV/DVD unit, each
component of the unit needs to be
programmed separately. In the Man­ufacture Code List for these devices
there will be codes for all compo­nents of the combination unit. They
can be distinguished as follows:

- TV codes start with a “1”

- DVD codes start with a “2”

- AUX codes start with a “3”

For some combination devices, the
original remote control may be re­quired to switch between the com­ponents.

B. Using the Automatic
Search

You can search the remote control
memory for your 4 digit manufacture
device code. You will need to use
this function if the code for your de-

vice is not listed in the Manufacture
Code List.

1. Turn on the device you wish to
program

2. Point the remote control at the
device

3. Press and hold the appropriate
mode key you want to assign to
this device (TV, DVD or AUX) on
the remote control

4. While holding the mode key,
press the OK key

5. Release both the mode key and
the OK key

– All the mode keys should flash

twice

– You’ll now have 10 seconds to

start step 6

6. Enter 922 by pressing the number
keys on the remote control

– The selected mode key will

flash twice indicating correct en­try

7. For TV or DVD modes press and
release the PLAY key

– For AUX searching only, press

and release the PLAY key then
press

1 for VCR

2 for Receiver/Tuner

3 for Amplifier

4 for Home Theater In A Box

(HTIB)

– The AUX mode keys will flash

twice indicating correct entry

8. Now press the FF button multi­ple times until the device turns
off

9. Press the ENTER key (bottom
right) to save the code on the
remote control

10. Check to make sure the code
works by pressing the mode key,
then the power button, to turn
the device back on. If this does
not work, start again at step 2.

11. Now that your devices are pro­grammed, you can press the
appropriate mode key on the
remote control to work with
the selected device. To use the
remote control for your AT&T U­verse TV Receiver again, press
the AT&T mode key.

Note:
– If any other key is pressed except
PLAY, ENTER, POWER, EXIT, REW, FF,
or number keys 1 to 4, the selected
mode key will give a long red flash
(error message) and the remote
control will return to normal opera­tion and you will need to start over.

– If you are interrupted while you
are programming, the remote con­trol may time-out before you com­plete the code set-up and you will
need to start over. This is indicated
by a red flash of the mode keys.

2. Setting up your

Volume, Channel and
Power Options

The default for your power, vol­ume and channel controls send the
codes to the U-verse TV receiver no
matter what mode you are in. Thus,
in DVD mode, the volume still con­trols the U-verse TV receiver, etc. If
you would like to change this, follow
these instructions:

A. Volume Control Set-Up
Options

The volume commands are always
sent to the U-verse TV receiver un­til the TV mode key is programmed.
Then the volume commands are
sent to the TV from all mode keys.
If you’d like the volume commands
to still be sent to just one device,
but that it be a different device (for
example a home theater setup) then
follow the instructions in Section I.
If you’d like the volume commands
sent to different devices depending
on which mode you are in then go
to Section II.

I. Volume Always Controls the
same Device

1. Press and hold the AT&T key on
the remote control

2. While holding the AT&T mode
key, press the OK key

3. Release both the AT&T key and
the OK key

– All the mode keys will flash

twice indicating programming
mode

4. Enter 955 by pressing the number
keys on the remote control

– The AT&T key will flash twice

indicating correct entry

5. Press the mode key that you
want to always receive the vol­ume commands

– The selected mode key will

flash three times indicating suc­cessful assignment and return to
normal operations

The volume commands will now go
to the selected device no matter
what mode you are in.

II. Volume Control Depends on
Device Selected

The volume setting can also be re­configured to independently control
the volume associated with each de­vice. (e.g. In AUX mode the receiver
controls the audio; In TV mode the
TV controls the audio)

1. Press and hold the AT&T key on
the remote control

2. While holding the AT&T mode
key, press the OK key

3. Release both the AT&T key and
the OK key

– All the mode keys will flash

twice indicating programming
mode

4. Enter 955 by pressing the number
keys on the remote control

– The AT&T key will flash twice

indicating correct entry

5. Press the ENTER key

– The AT&T key will flash three

times indicating successful as­signment and returns to normal
operations

B. Channel Selection Set-Up
Option

By default the remote control will
always send channel commands to
the U-verse TV receiver no matter
what mode you are in. This will pre­vent accidental TV channel changes
while in TV, DVD or AUX modes.

There are two ways you can change
this: I) Have channel commands al­ways go to a single device other
than the U-verse TV receiver; II) Have
channel commands go to different
devices when in different modes
(e.g., When in TV mode the chan­nel commands go to the TV, when in
DVD mode the channel commands
go to the DVD player, etc.). See the
appropriate section for each.

I. Channel Always Controls the
Same Device

1. Press and hold the AT&T key on
the remote control

2. While holding the AT&T mode key,
press the OK key

3. Release both the AT&T key and
the OK key

– All the mode keys will flash

twice indicating programming
mode

4. Enter 966 by pressing the number
keys on the remote control

– The AT&T key will flash twice

indicating correct entry

5. Press the mode key that you
wish the channel commands to
always go to

– The selected mode key will

flash three times indicating suc­cess and return to normal opera­tions.

The channel commands will now
go to the selected device no matter
what mode you are in.

II. Channel Control Depends
on Device Selected

1. Press and hold the AT&T key on
the remote control

2. While holding the AT&T mode key,
press the OK key

3. Release both the AT&T key and
the OK key

– All the mode keys will flash

twice indicating programming
mode

4. Enter 966 by pressing the number
keys on the remote control

– The AT&T key will flash twice

indicating correct entry

5. Press the Enter key

– The AT&T key will flash three

times indicating successful as­signment and return to normal
operations.

If you press any key other than the
mode keys or ENTER, the AT&T key
will give a long red flash and the
remote control will return to normal
operation. Should the remote con­trol time-out before you complete
the procedure you will need to start
over.

C. Power Control Set-Up
Options

By default, the POWER key only
powers on or places your U-verse TV
receiver in stand-by mode. Once you
have programmed the TV mode key,
the TV and U-verse TV receiver will
both be powered on/off simultane­ously. You also have the option to
turn on/off TV, DVD and AUX mode
devices individually by pressing the
applicable mode key then the POW­ER key.

I. To Have Multiple Devices
Power Off with the Power Key

If you would like other devices to be
powered on/off simultaneously with
the POWER key, then follow these
instructions for the additional de­vices (for a total of 4).

1. Press and hold the AT&T key on
the remote control

2. While holding the AT&T mode
key, press the OK key

3. Release both the AT&T key and
the OK key

– All the mode keys will flash

twice indicating programming
mode

4. Enter 977 by pressing the number
keys on the remote control

– The AT&T key will flash twice

indicating correct entry

5. Press the AT&T key on the re­mote control

– The AT&T key will flash twice

indicating correct entry

6. Press the TV key on the remote
control

– The TV key will flash twice indi-

cating correct entry

7. Press each additional mode key
that you wish to include such as
the DVD key or AUX key

– Each selected mode key will

flash twice indicating correct en­try

8. Press the ENTER key to com­plete

– The last mode key selected will

flash three times indicating suc­cessful assignment and return to
normal operations

Note:
If any key is pressed except the
mode keys and ENTER, the AT&T key
will give a long red flash and the re­mote control will return to normal
operation. Should the remote con­trol time-out before you complete
the procedure you will need to start
over.

If the devices that you have pro­grammed to turn ON/OFF at the
same time get out of sync so that
some turn ON and others turn OFF,
you will need to manually turn OFF
the out of sync devices and then
press the POWER key to turn them

all back ON. It is important to point
the remote directly toward the de­vices for this to work properly.

To change the number of devices
controlled by the POWER key, you
must start at Step 1 and continue
until all desired devices have been
programmed.

3. Changing and
Removing Codes

A. Mode Deactivation

To deactivate a mode key, follow
these steps:

1. Press and hold the mode key
(TV, DVD or AUX) that you’d like
to deactivate on the remote con­trol

2. Without releasing the chosen
mode key, press and hold the OK
key simultaneously

3. Release both the mode key and
the OK key

– All the mode keys should flash

twice

4. Enter the appropriate 4-digit
code from the list below de­pending on the mode you are
deactivating:

– TV: 1254

– DVD: 2254

– AUX: 3254

– The mode key will flash three

times indicating correct entry
and return to normal operation

– When an invalid code is en-

tered, the selected mode key will
give a long flash to indicate that
you have not entered the code
correctly

– Should the remote control

time-out before you complete
the set-up, you will need to start
over

B. Reassigning Your Mode
Keys To Another Device

The TV, DVD and AUX keys are already
set up to control specific devices:

TV key: TV & HDTV

DVD key: DVD

AUX key: VCR, Home Theater

In A Box (HTIB), Receivers and
Amplifiers

You may change these mode keys
to operate another type of device.
To do this, you must copy an existing
mode key to the one you would like
to change. For example, you have
two DVD players and you’d like to
use the AUX key for one of them. You
would begin by programming one of
the DVD players into the DVD mode
key and then copy that to the AUX
mode key. Then you reprogram the
original DVD mode key to the other
DVD player. Before beginning these
steps, program the device you’d like
to copy by following the steps in
Section 1. Then use the steps below
to copy the codes.

1. Press and hold the AT&T key on
the remote control

2. Without releasing the AT&T key,
press and hold the OK key simul­taneously

3. Release both the AT&T key and
the OK key

– All the mode keys will flash

twice indicating programming
mode

4. Enter 944 by pressing the number
keys on the remote control

– All the mode keys will flash

twice indicating correct entry

5. Press the mode key (i.e., TV, DVD
or AUX) you would like to copy
the codes FROM (See above)

– The selected mode key will

flash once

6. Press the mode key you would
like to copy the codes TO

– The selected mode key will

flash three times indicating suc­cessful reassignment and return
to normal operations

Once you copy the mode key, you
will have both keys with the same
program code. Now reprogram the
original mode key with a new code
for a second device.

Note:
If any other key is pressed except
the mode keys the AT&T key will give
a long red flash and the remote con­trol will return to normal operation.
Should the remote control time-out
before you complete the procedure
you will need to start over.

4. Resetting to Factory
Defaults

A. Resetting the Remote
Control to Factory Default
Settings:

1. Press and hold the AT&T key on
the remote control.

2. Without releasing the AT&T key,
press and hold the OK key.

3. Release both the AT&T key and
the OK key

– All four mode keys will flash

twice to indicate programming
mode.

4. Enter programming code 900 by
pressing the number keys on the
remote control.

– The AT&T key will flash three

times indicating you have suc­cessfully entered the code and
the remote has been reset to the
default settings

Note:
If any other key is pressed except the
number keys, the AT&T key will give
a long red flash and the remote con­trol will return to normal operation.
Should the remote control time-out
before you complete the procedure
you will need to start over.

B. Resetting the Volume,
Channel and Power
Programming:

1. Press and hold the AT&T key on
the remote control.

2. Without releasing the AT&T key,
press and hold the OK key.

3. Release both the AT&T key and
the OK key

– All four mode keys will flash

twice to indicate programming
mode

4. Enter programming code 902 by
pressing the number keys on the
remote control.

– The AT&T key will flash three

times indicating you have suc­cessfully entered the code to re­set Volume, Channel and Power
to the defaults and the remote
will return to normal operation

Note:
If any other key is pressed except the
number keys, the AT&T key will give
a long red flash and the remote con­trol will return to normal operation.
Should the remote control time-out
before you complete the procedure
you will need to start over.

5. Learning the remote

to control other devices

In cases where devices are not listed
in the Manufacture Code List in this
manual or certain keys are not avail­able, but you have the original re­mote control on hand, you can learn
the codes from the original remote
control into the desired keys of this
U-verse remote control.

To learn the desired IR codes from
the original remote, follow these
steps:

1. Get ready the original remote
control to be learnt

2. Press and hold the mode key (i.e.
TV, DVD or AUX) where you want
the codes to be learned.

3. Without releasing the selected
mode key, press and hold the
MENU key simultaneously.

4. Release both the mode key and
the MENU key

− All the mode keys will flash
twice indicating programming
mode

5. Enter 988 by pressing the number
keys on the remote control

− The selected mode key will
flash twice indicating correct en­try

6. Press the key on this U-verse re­mote control that you want the
codes to be learnt to (TV, DVD
and AUX keys are mode keys and
so not available for learning)

− The selected mode key will
flash twice indicating correct en­try

7. Point the original remote control
directly opposite to this U-verse
remote control.

8. Press and hold the key on the
original remote control where
the code is to be learnt

− The original remote control
transmits code to this U-verse
remote control. Upon comple­tion this U-verse remote con­trol, selected mode key will flash
three times indicating successful
learning.

9. Release the key on the original
remote control

10. Repeat steps 6-9 for learning
more codes.

11.Press any of the mode key (i.e.
AT&T, TV, DVD or AUX) to return
to normal operations

− The selected mode key will flash

three times and return to normal op­erations

Note:

− If no code is received from original

remote within the 30 seconds, then
all the selected mode keys will give
a long red flash (error message) and
this U-verse remote control will re­turn to normal operations. You will
need to start over.

− If codes from original remote are

poorly received, or battery is weak,
or learns memory is full, then only
the single selected mode key will
give a long red flash (error message)
and this U-verse remote control will
return to normal operations. You will
need to start over after replacing
batteries or erasing some existing
learn codes.

6. Resetting of Learning

Codes

A. Resetting of Individual
Learning Codes

To erase individual learn codes, fol­low these steps:

1. Press and hold the mode key (i.e.
TV, DVD or AUX) which you want
to erase learn codes

2. Without releasing the selected
mode key, press and hold the
MENU key simultaneously

3. Release both the mode key and
the MENU key

− All the mode keys will flash
twice indicating programming
mode

4. Enter 904 by pressing the number
keys on the remote control

− The selected mode key will
flash twice indicating correct en­try

5. Press the key that you want to
erase the learn codes

− The selected mode key will
flash three times indicating suc­cessful resetting

6. Repeat step 5 for erasing other
learning codes

7. Press any of the mode key (i.e.
AT&T, TV, DVD or AUX) to return
to normal operations

− The selected mode key will
flash three times and return to
normal operations

Note:

− If the battery power is weak during

resetting mode, the selected mode
key will give a long flash (error mes-

sage), the learn codes will not be
erased and you will need to replace
new batteries and start over.

B. Resetting of All Learning
Codes within TV, DVD or AUX
mode

To erase all learn codes in selected
mode TV, DVD or AUX, follow these
steps:

1. Press and hold the mode key (i.e.
TV, DVD or AUX) which you want
to erase learn codes

2. Without releasing the selected
mode key, press and hold the
MENU key simultaneously

3. Release both the mode key and
the MENU key

− All the mode keys will flash
twice indicating programming
mode

4. Enter 905 by pressing the number
keys on the remote control

− The selected mode key will
flash three times indicating suc­cessful erasing of all learn codes
under the selected mode and
the remote control will return to
normal operations

Note:

− If the battery power is weak during

resetting mode, the selected mode
key will give a long flash (error mes­sage), the learn codes will not be
erased and you will need to replace
new batteries and start over

C. Resetting of All Learning
Codes in All Modes

To erase all learn codes, follow these
steps:

1. Press and hold the AT&T mode
key on the remote control

2. Without releasing the AT&T mode
key, press and hold the MENU
key simultaneously

3. Release both the AT&T mode key
and the MENU key

− All the mode keys will flash
twice indicating programming
mode

4. Enter 906 by pressing the number
keys on the remote control

− The AT&T mode key will flash
three times indicating success­ful erasing of all learn codes and
the remote control will return to
normal operations

Note:

− If the battery power is weak during

resetting mode, the selected mode
key will give a long flash (error mes­sage), the learn codes will not be
erased and you will need to replace
new batteries and start over

7. RF Pairing with

Transmitter

By default this remote recognises RF
signal from all similar RF transmit­ters. However you can set this re­mote control to recognize RF signal
only from its dedicated transmitter
by performing this function:

1. Remove the battery lid from
the Transmitter and get ready a
sharp object (such as a pencil)

2. Place the remote control near
the RF transmitter

3. Press and hold the AT&T key on
the remote control

4. Without releasing the AT&T mode
key, press and hold the MENU
key simultaneously

5. Release both the AT&T mode key
and the MENU key

− All the mode keys will flash
twice indicating programming
mode

6. Enter 990 by pressing the number
keys on the remote control

− The AT&T mode key will flash
twice indicating correct entry

7. Press and release the OK key on
the remote control to start RF
pairing

8. Use the sharp object to press
and release the tiny Pairing key
on the RF transmitter

− The AT&T mode key will flash
three times indicating successful
RF pairing

Note:

− If the batteries are removed from

the remote control, the pairing with
the Transmitter will be lost, and the
remote will respond to RF signals
from all similar RF transmitters. You
will need to pair them again.

− If the battery is removed from

the Transmitter, the pairing with
the remote control will be lost, and
the remote will not respond to any
transmitter. You will need to pair the
Transmitter with the remote again.

8. Backlight Control Set

Up Option

By default the Backlight is set to Off.
You can turn the Backlight on or off
by performing this function.

1. Press and hold the AT&T key on
the remote control

2. Without releasing the AT&T mode
key, press and hold the MENU
key simultaneously

3. Release both the AT&T mode key
and the MENU key

− All the mode keys will flash
twice indicating programming
mode

4. Enter 991 by pressing the number
keys on the remote control

− The AT&T mode key will flash
three times indicating successful
toggling the Backlight enabling/
disabling control.

Note:

− The Backlight is turned off upon

factory default settings and you will
need to perform this function to turn
the Backlight on again.

FCC ID:RCSTX100001

Federal Communication

Commission Interference

Statement

This equipment has been tested and
found to comply with the limits for
a Class B digital device, pursuant to
Part 15 of the FCC Rules. These limits
are designed to provide reasonable
protection against harmful interference
in a residential installation. This
equipment generates, uses and can
radiate radio frequency energy and, if
not installed and used in accordance
with the instructions, may cause harmful
interference to radio communications.
However, there is no guarantee that
interference will not occur in a particular
installation. If this equipment does
cause harmful interference to radio
or television reception, which can be
determined by turning the equipment
off and on, the user is encouraged to
try to correct the interference by one of
the following measures:

- Reorient or relocate the receiving
antenna.

- Increase the separation between the
equipment and receiver.

- Connect the equipment into an
outlet on a circuit different from that
to which the receiver is connected.

- Consult the dealer or an experienced
radio/TV technician for help.

FCC Caution: Any changes or
modifications not expressly approved
by the party responsible for compliance
could void the user’s authority to
operate this equipment.

This device complies with Part 15 of the
FCC Rules. Operation is subject to the
following two conditions: (1) This device
may not cause harmful interference,
and (2) this device must accept
any interference received, including
interference that may cause undesired
operation.

This transmitter must not be co-located
or operating in conjunction with any
other antenna or transmitter.

AT&T RC1534819 (12 Jun 2008).ind1 1 6/12/2008 1:36:47 PM

LG 1005, 1396, 1397, 1398

1399, 1402, 1403, 1404

1405
Lloyd’s 1384
Loewe 1053
Logik 1001
Luxman 1004
LXI 1000, 1004, 1045, 1053

1058, 1068, 1075
Maganvox 1260, 1302, 1321
Magnavox 1004, 1007, 1018, 1053

1056, 1057, 1059, 1060

1083, 1110, 1147, 1228

1300, 1301, 1326, 1339

1365, 1366, 1371, 1384

1387
Magnin 1380
Majestic 1001
Marantz 1004, 1051, 1053
Media Center

1408
Megatron 1004, 1051
Memorex 1001, 1004, 1005, 1022

1045

MGA 1004, 1005, 1018, 1021

1047, 1061, 1062, 1380

Midland 1049, 1068, 1097, 1098

1160
Minutz 1048
Mitsubishi 1004, 1005, 1018, 1021

1047, 1061, 1062, 1081

1381
Montgomery Ward

1001
Motorola 1003, 1099
MTC 1004, 1005, 1073
Multitech 1036
NAD 1004, 1058, 1075, 1085
NEC 1003, 1004, 1005
Net-Tv 1040
Olevia 1420
Nikko 1004, 1015
Norcent 1217, 1320
NTC 1015
Onwa 1036
Optimus 1085
Optonica 1064, 1099
Orion 1023, 1033, 1107, 1382

1383

Panasonic 1003, 1010, 1049, 1053

1096, 1123, 1152, 1231
1289, 1292, 1295, 1303

1304, 1305, 1306, 1385
Penney 1380, 1385
Philco 1003, 1004, 1005, 1007

1011, 1018, 1053, 1056

1057, 1059
Philips 1003, 1004, 1007, 1011

1017, 1018, 1053, 1056

1057, 1059, 1060, 1063

1110, 1126, 1129, 1148

1155, 1238, 1263, 1264

1265, 1290, 1291, 1307

1308, 1309, 1337, 1389
Philips Magnavox

1260, 1264, 1265, 1266
Pilot 1097
Pioneer 1004, 1085, 1102
Polaroid 1285, 1458
Portland 1004, 1005, 1015, 1097
Price Club 1073
Prima 1113
Prism 1049
Proscan 1000, 1008, 1068, 1108
Proton 1004, 1011
Pulsar 1160
Pulser 1004
Quasar 1003, 1039, 1049, 1096

1165, 1166, 1385

Radio Shack

1000, 1045, 1098, 1384

Radio Shack/Realistic

1004, 1011, 1036, 1045

1064, 1097, 1098

RCA 1000, 1003, 1004, 1005

1008, 1018, 1049, 1065
1066, 1067, 1068, 1069
1070, 1071, 1082, 1102
1104, 1106, 1108, 1115
1151, 1162, 1167, 1168
1268, 1269, 1270, 1271
1310, 1355, 1359, 1361
1370, 1373, 1379, 1380

1381, 1385, 1386
Runco 1160
Sampo 1004, 1097, 1098, 1120
Samsung 1004, 1005, 1011, 1014

1018, 1019, 1072, 1073

1074, 1097, 1098, 1156

1161, 1297, 1323, 1360

1363, 1364
Sansui 1023, 1107, 1122, 1273

1382, 1383, 1384
Sanyo 1045, 1062, 1095, 1103

1380
Scotch 1004
Scott 1004, 1011, 1033, 1036

1044
Sears 1000, 1004, 1012, 1018

1044, 1045, 1047, 1055

1058, 1068, 1075, 1076
1103, 1105, 1384

Sharp 1004, 1009, 1011, 1025

1064, 1077, 1078, 1097
1099, 1153, 1157, 1274
1298, 1311, 1312, 1362

1375, 1378
Shogun 1004
Signature 1001
Simpson 1007
Sony 1002, 1109, 1137, 1201

1202, 1249, 1272, 1275

1276, 1277, 1278, 1317

1356, 1374, 1384, 1388
Soundesign 1004, 1007, 1036, 1044
Squareview 1105
SSS 1036
Starlite 1036
Supre-Macy 1100
Supreme 1002
Sylvania 1004, 1007, 1018, 1027

1056, 1057, 1059, 1060

1124, 1145, 1150, 1153

1279, 1296, 1387, 1464
Symphonic 1024, 1031, 1036, 1105

1280, 1384
Tandy 1099
Tashiko 1058
Tatung 1003
Technics 1049
Techwood 1004, 1049
Teknika 1001, 1004, 1005, 1007

1012, 1015, 1036, 1044

1060, 1073, 1096, 1097

1111
Tera 1004, 1011
Thomas 1384
TMK 1004
Toshiba 1006, 1045, 1058, 1073

1079, 1093, 1116, 1154

1158, 1159, 1175, 1252

1267, 1281, 1282, 1283

1284, 1286, 1293, 1294

1313, 1315, 1319, 1338

1364, 1377
Totevision 1097
Universal 1048, 1063
Victor 1055
Vidtech 1004, 1005
Viking 1100
Wards 1000, 1001, 1004, 1005

1031, 1044, 1048, 1053

1056, 1057, 1059, 1060

1063, 1064, 1118
White Westinghouse

1013
Yamaha 1004, 1005, 1018,
Zenith 1001, 1089, 1118, 1125

1161, 1287, 1357, 1382

1383, 1384

HDTV

Acer 1041, 1192
Akai 1427, 1432
Apex 1088
Astar 1434
Audiovox 1455
Axion 1459
Benq 1136
Coby 1460
Daewoo 1135
Dell 1141, 1142, 1146, 1394

1395, 1409
Element 1431
Emerson 1468
Emprex 1438
Epson 1422, 1451
Fujitsu 1029
Gateway 1038, 1449
Hewlett Packard

1419, 1444, 1445, 1452

Hitachi 1030, 1132, 1133, 1134

1191, 1208, 1209, 1210

1211, 1212, 1226, 1322

1324, 1328, 1344, 1447
HP 1419, 1445, 1452,
Ilo 1412, 1435, 1436
InFocus 1450
Initial 1457
Insignia 1437
JVC 1130, 1131, 1227
LG 1343, 1346, 1396
Magnavox 1329, 1358, 1372, 1414
Maxent 1424
Mintek 1457
Mitsubishi 1032, 1213, 1229, 1230

1448
NEC 1193, 1423
NET-TV 1040
Olevia 1406, 1418, 1421, 1462
Panasonic 1140, 1169, 1170, 1194

1233, 1234, 1331, 1336

1410, 1417, 1442, 1466
Philips 1126, 1129, 1236, 1237

1239, 1261, 1334, 1351

1390, 1411
Pioneer 1035, 1195, 1240, 1335

1469, 1470

3086, 3087
RCA 1151, 2077, 3106
Samsung 1297, 2214, 3148
Sharp 1153, 1378, 2086, 2292

3100, 3200
Sylvania 1027, 1124, 1296, 2064

2078, 2213, 3088, 3105

3147
Toshiba 1154, 1158, 1338, 2093

2094, 2094, 3098, 3099

3149

TV-VCR-TUNER COMBO

Panasonic 1303, 1303, 1304, 3110

3155, 3156, 3157, 5109

5111
Philips 1309, 3161, 5112

TV-VCR-DVD-TUNER
COMBO

Panasonic 1292, 1295, 2211, 2212

3145, 3146, 5107, 5108

TV-RECEVIER

Philips 1390, 5138
Polaroid 1393, 5141

DVD

Aiwa 2026, 2131
Akai 2378
Amphion MediaWorks

2342
AMW 2342
Apex 2001, 2056, 2057, 2061

2095, 2098, 2229, 2250
2316, 2322, 2330

Apex Digital 2261, 2262, 2263, 2266

2269, 2291
Apple 2383
Arrgo 2325
Astar 2354
Audiovox 2132, 2373, 2388
Axion 2379
Bang & Olufsen

2324, 2370
Blaupunkt 2136, 2322
BOSE 2215
BOSE 2122, 2130, 2215
BOSS 2336
Broksonic 2053, 2072, 2284
CambridgeSoundWorks

2395
Cinevision 2152, 2195
Clarion 2100
Classic 2101, 2391
Coby 2380, 2387
Curtis 2387
CyberHome 2083, 2325
Cytron 2374
Daewoo 2058, 2062, 2137, 2138

2190

Denon 2040, 2110, 2133, 2216

2247, 2253, 2317
Desay 2344
DiamondVision

2382
Disney 2321
Durabrand 2326
Eclipse 2335
Emerson 2002, 2059, 2073, 2321

2327, 2392
ESA 2327, 2394
Fisher 2112, 2134, 2255
Funai 2002, 2321, 2327
Gateway 2346
GE 2041, 2079, 2118, 2261

2272, 2319, 2322,
Go Video 2046, 2124, 2127, 2129

2230, 2239, 2249, 2346
GPX 2114, 2390
Greenhill 2322
Grundig 2320
Harman Kardon

2125

Hitachi 2000, 2027, 2126, 2173

2240
Ilo 2375
Initial 2322, 2381
Insignia 2327, 2369, 2394
Irradio 2149, 2150
JVC 2017, 2028, 2047, 2090

2096, 2097, 2115, 2166

2204, 2206, 2217, 2218

2232, 2242, 2265, 2277

2283, 2359, 2360, 2361

2362, 2364, 2365, 2366

2367
Kenwood 2142, 2148
KLH 2322
Konka 2029, 2030, 2376
Koss 2060, 2200
Lasonic 2081
Lenoxx 2326
LG 2297, 2303, 2339, 2352

2363, 2368, 2371
Liteon 2346, 2353
Magnavox 2002, 2018, 2033, 2089

2237, 2241, 2245, 2259

2270, 2293, 2318, 2320

2321, 2327

Marantz 2143, 2320
Memorex 2003
Microsoft 2319
Mintek 2004, 2322, 2381
Mitsubishi 2019, 2123, 2145, 2147
NAD 2059, 2139
Nakamichi 2116
Nesa 2322
Nexxtech 2140, 2256, 2328
Norcent 2005, 2117
Onkyo 2006, 2219, 2220, 2318
Oppo 2323
Oritron 2009
Panasonic 2031, 2066, 2075, 2076

2104, 2105, 2106, 2111
2151, 2153, 2154, 2155
2167, 2179, 2188, 2198
2207, 2211, 2212, 2221
2228, 2248, 2258, 2268
2300, 2318, 2384, 2385
2386, 2398, 2399

Philips 2018, 2032, 2033, 2045

2051, 2091, 2109, 2156
2157, 2158, 2159, 2169
2208, 2209, 2222, 2243
2259, 2260, 2264, 2282
2285, 2302, 2304, 2318
2320, 2321, 2404

Pioneer 2008, 2021, 2160, 2164

2191, 2223, 2224, 2267

2310, 2337, 2400
Polaroid 2007, 2377, 2409
Polk Audio 2320
Presidian 2321
Proscan 2010, 2118, 2144, 2205

2319
Qwestar 2009
RCA 2010, 2048, 2055, 2063

2077, 2099, 2107, 2118

2161, 2165, 2172, 2177

2181, 2261, 2275, 2281

2287, 2289, 2319, 2322

2331
Sampo 2119
Samsung 2012, 2049, 2074, 2085

2102, 2175, 2186, 2196

2214, 2233, 2246, 2274

2279, 2286, 2290, 2294

2295, 2299, 2311, 2314

2333, 2340, 2347, 2351
Sansui 2071
Sanyo 2034, 2050, 2120, 2393
Sensory Science

2346

Sharp 2013, 2015, 2044, 2082

2086, 2170, 2174, 2292

2321, 2396
Sherwood 2121, 2397
Sony 2014, 2020, 2022, 2065

2067, 2068, 2069, 2070

2087, 2103, 2108, 2113

2162, 2171, 2176, 2178

2182, 2187, 2189, 2192

2193, 2201, 2202, 2203

2226, 2238, 2244, 2251

2257, 2273, 2278, 2280

2288, 2296, 2298, 2305

2306, 2307, 2309, 2313

2315, 2329, 2332, 2338

2355, 2356, 2357, 2405

2406, 2407
Sungale 2343
Sylvania 2002, 2064, 2078, 2092

2194, 2213, 2321, 2327

2408
Symphonic 2321
Techwood 2141
Toshiba 2023, 2025, 2037, 2038

2040, 2041, 2054, 2080

2084, 2088, 2093, 2094

2168, 2180, 2183, 2184

2185, 2197, 2210, 2227

2231, 2235, 2259, 2271

2276, 2284, 2301, 2318

2334, 2341
Toshiba 2135, 2312, 2348, 2349

2350, 2358, 2401, 2402

2403
Trutech 2345
Urban Concepts

2318
Venturer 2011
Westinghouse

2372
Xbox 2319
Yamaha 2106, 2146, 2163, 2320

2389

Zenith 2039, 2052, 2128, 2199

2234, 2236, 2252, 2308
2318

DVD-VCR COMBO

Apex 2229, 3189
Broksonic 2072, 3082
CineVision 2230, 3242
Daewoo 2062, 3076
Emerson 2073, 3083
Go Video 2046, 2127, 2129, 2129

2230, 2239, 3066, 3109

3110, 3188, 3193, 3221
Hitachi 2126, 2173, 3117, 3169
Insignia 2369, 3239
JVC 2047, 2097, 2166, 2166

2232, 2359, 2360, 2361
2362, 2364, 2365, 2366
2367, 3067, 3118, 3170
3171, 3194, 3228, 3229
3230, 3231, 3234, 3235

3236, 3237
LG 2363, 2368, 3233, 3238
Magnavox 2237, 3190
Panasonic 2066, 2167, 2228, 3078

3172, 3191
Philips 2051, 2169, 3071, 3173
Polaroid 2007, 3111
RCA 2048, 2165, 2172, 3068

3174, 3175
Samsung 2049, 2074, 2085, 2233

2290, 2311, 2311, 3069

3084, 3101, 3184, 3214

3218, 3232
Sanyo 2050, 3070
Sharp 2170, 2174, 3176, 3177
Sony 2065, 2067, 2067, 2171

2238, 2244, 2244, 2355

2356, 2357, 3085, 3104

3178, 3179, 3187, 3192

3224, 3225, 3226, 3240
Toshiba 2080, 2080, 2084, 2168

2235, 2312, 2358, 3102

3103, 3180, 3185, 3219

3227, 3241
Zenith 2052, 2128, 2234, 2236

3072, 3119, 3186, 3186

VCR

ABS 3223
Admiral 3001
Adventura 3021
Aiwa 3021
Akai 3003, 3055, 3058
Alienware 3223
Apex 3189
Audio Dynamics

3005, 3006

Bang & Olufsen

3222

Bell & Howell

3007
Broksonic 3081, 3082, 3202, 3213
Candle 3011, 3013, 3014
Carver 3036
CineVision 3242
Citizen 3011, 3013, 3014
Colortyme 3005
Curtis Mathes

3000, 3005, 3014, 3212

CyberPower

3223

Cyperpower

3223

Daewoo 3011, 3013, 3021, 3076

3120, 3150
DBX 3005, 3006
Dell 3223
Dimensia 3000
DIRECTV 3246
Dish Network

3247, 3248
Dishpro 3247
Dynatech 3021
Echostar 3247, 3248
Electrohome

3023
Emerson 3003, 3011, 3021, 3023

3038, 3083, 3202, 3202
Expressvu 3247
Fisher 3007, 3029, 3030
Fuji 3058
Funai 3002, 3021
Garrard 3021
Gateway 3223
GE 3000, 3059, 3090, 3201

3203, 3212
Go Video 3066, 3073, 3109, 3110

3188, 3193, 3221
GOI 3247
Goldstar 3005, 3014
Gradiente 3021
Harley Davidson

3021

Harman Kardon

3005

Headquarter

3007

Hewlett Packard

3223

Hitachi 3052, 3055, 3059, 3117

3169
HNS 3243
Howard Computers

3223
HP 3223
HTS 3247
Hughes 3246, 3250
Humax 3246
Hush 3223
iBUYPOWER

3223
Insignia 3239
JC Penney 3005, 3006, 3007, 3030

3036, 3052
Jensen 3055
JVC 3005, 3006, 3007, 3014

3055, 3060, 3067, 3118

3121, 3122, 3123, 3124

3125, 3126, 3127, 3151

3170, 3171, 3194, 3205

3228, 3229, 3230, 3231

3234, 3235, 3236, 3237

3247, 3248, 3250
Kenwood 3005, 3006, 3007, 3014

3055, 3060
LG 3233, 3238
Linksys 3223
Lloyd’s 3021

Maganvox 3154, 3181
Magnavox 3036, 3037, 3051, 3061

3128, 3152, 3153, 3183

3190, 3206, 3211
Magnin 3201
Marantz 3005, 3006, 3007, 3014

3036
Media Center PC

3223

Memorex 3001, 3004, 3007, 3021

3051
MGA 3023, 3038, 3201
Microsoft 3223
Mind 3223
Minolta 3052
Mitsubishi 3023, 3038, 3039, 3060

3108, 3203
Montgomery Ward

3001
Motorola 3001
Multitech 3021
NEC 3005, 3006, 3007, 3014

3055, 3060

Niveus Media

3223
Northgate 3223
Optimus 3001
Optonica 3047
Orion 3004, 3202, 3213
Panasonic 3053, 3062, 3063, 3077

3078, 3079, 3086, 3087
3107, 3129, 3130, 3131
3132, 3133, 3134, 3145
3146, 3155, 3156, 3157
3158, 3159, 3172, 3191

3197, 3207, 3212, 3253
Penney 3201, 3212
Pentax 3052, 3059
Pentex Research

3014
Philco 3036, 3037
Philips 3036, 3047, 3061, 3071

3135, 3160, 3161, 3173
3208, 3216, 3243, 3244
3246, 3250, 3251

Philips Magnavox

3135
Pioneer 3006, 3060
Polaroid 3111
Portland 3013
Proscan 3000
Pulsar 3051
Quarter 3007
Quartz 3007
Quasar 3062, 3091, 3092, 3212
Radio Shack

3001, 3047

Radio Shack/Realistic

3007, 3021, 3023, 3029

3047

RCA 3000, 3003, 3040, 3041

3042, 3052, 3059, 3062
3068, 3075, 3093, 3094
3106, 3136, 3162, 3174
3175, 3199, 3201, 3203
3206, 3212, 3243, 3249
3250

Realistic 3001, 3007, 3011, 3021

3023, 3029, 3047
ReplayTV 3252
Ricavision 3223
Ricoh 3064
Runco 3051
Samsung 3011, 3069, 3084, 3089

3101, 3148, 3184, 3214

3215, 3218, 3232, 3243
Sanky 3001, 3051
Sansui 3004, 3006, 3055, 3060

3202, 3211, 3213
Sanyo 3007, 3070, 3201
Scott 3011, 3038
Sears 3007, 3029, 3030, 3052

3211
Sharp 3001, 3013, 3023, 3047

3080, 3100, 3137, 3163

3164, 3176, 3177, 3200
Shintom 3048, 3058
Signature 3001
Singer 3064
Sony 3048, 3049, 3058, 3085

3104, 3138, 3139, 3140

3178, 3179, 3187, 3192

3195, 3209, 3211, 3217

3223, 3224, 3225, 3226

3240, 3245
Stack 3223
Stack 9 3223
STS 3052
Sylvania 3021, 3036, 3037, 3038

3061, 3088, 3095, 3105

3147
Symphonic 3002, 3021
Systemax 3223
Tagar Systems

3223
Tandy 3007
Tatung 3055
Teac 3021, 3042, 3055
Technics 3053
Teknika 3021, 3050
Thomas 3211
Tivo 3074, 3244, 3245, 3246

3249, 3250

Toshiba 3011, 3029, 3030, 3038

3096, 3098, 3099, 3102
3103, 3141, 3142, 3149
3165, 3166, 3167, 3168
3180, 3182, 3185, 3210

3219, 3220, 3223, 3227

3241
Touch 3223
Vector Research

3005, 3006, 3011
Victor 3006
Video Concepts

3005, 3006, 3011
Viewsonic 3223
Voodoo 3223
Wards 3001, 3011, 3021, 3023

3047, 3052

White Westinghouse

3002
XR-1000 3021
Yamaha 3005, 3006, 3007, 3014

3055
Zenith 3048, 3051, 3058, 3064

3072, 3097, 3119, 3143

3144, 3186, 3196, 3198

3202, 3204, 3211, 3213
ZT Group 3223

HTIB

Apex 2316, 4049
Audiovox 2388, 4053
BOSE 2130, 2215, 4000, 4000
CambridgeSoundWorks

2395, 4060
Classic 2391, 4055
Coby 2387, 4052
Curtis 2387, 4056
Denon 2216, 4012
Emerson 2392, 4057
GPX 2390, 4055
Insignia 2394, 4059
JBL 2043, 4001
JVC 2035, 2217, 2218, 2283

4002, 4013, 4014, 4028
Koss 2060, 2200, 4003, 4015
LG 2303, 4041
Magnavox 2293, 4035
Onkyo 2024, 2219, 2220, 4004

4016, 4017
Panasonic 2104, 2221, 2300, 2384

2385, 2386, 4005, 4018

4030, 4038, 4050, 4050

4051
Philips 2036, 2222, 2282, 2304

4006, 4019, 4027, 4039

4042
Pioneer 2016, 2223, 2224, 4007

4020, 4021, 4029
RCA 2042, 2161, 2281, 4008

4008, 4026
Samsung 2294, 2295, 2299, 2314

4033, 4033, 4036, 4047
Sanyo 2393, 4058
Sharp 2396, 4061
Sherwood 2397, 4062
Sony 2108, 2113, 2225, 2226

2278, 2288, 2296, 2305

2306, 2307, 2315, 4009

4010, 4022, 4023, 4024

4031, 4032, 4034, 4043

4044, 4045, 4046, 4048
Toshiba 2227, 4025, 4040
Venturer 2011, 4011
Yamaha 2389, 4054
Zenith 4037

REC-TUN

ADC 5144
Aiwa 5000, 5001, 5002, 5004

5005, 5006, 5034, 5143
Akai 5083
Audiotronic 5145
Audiovox 5152
Bang & Olufsen

5151
BOSE 5007
Capetronic 5144
Carver 5000, 5143, 5145
Denon 5008, 5035, 5036, 5037

5038, 5039, 5040, 5041
5042, 5043, 5044, 5045
5046, 5047, 5048, 5049
5050, 5051, 5052, 5053

5054, 5114, 5124
Eclipse 5149
Gradiente 5153
Harman/Kardon

5000, 5009, 5055, 5056

5142, 5143
JBL 5009
JVC 5010, 5057, 5058, 5059

5116
Kenwood 5011, 5012, 5013, 5060

5061, 5062, 5063, 5064

5065, 5066, 5067, 5068

5123, 5127, 5128, 5132

5148
Linn 5000, 5143
Magnavox 5000, 5143, 5144, 5145
Marantz 5000, 5069, 5143, 5145
Mitsubishi 5070, 5071, 5072
Onkyo 5018, 5073, 5074, 5075

5076, 5077, 5078, 5079

5080, 5081, 5082, 5084

Polaroid 1262, 1391, 1392, 1393

1396, 1431, 1440
Proscan 1000
Protron 1430
Proview 1407
RCA 1143, 1196, 1241, 1242
Sampo 1038, 1243
Samsung 1019, 1171, 1172, 1173

1174, 1175, 1197, 1198

1199, 1200, 1245, 1246

1325, 1327, 1352, 1354

1443
Sceptre 1467
Scott 1428
Sharp 1138, 1176, 1177, 1214

1244, 1247, 1248, 1348

1350, 1415, 1416
Sony 1037, 1128, 1137, 1178

1215, 1216, 1218, 1219

1220, 1221, 1250, 1251

1316, 1318, 1330, 1347

1413
SVA 1446
Sylvania 1046, 1465
Syntax 1418
Syntax-Brillian

1418
Tatung 1426
Toshiba 1127, 1179, 1203, 1204

1222, 1223, 1332, 1340

1341, 1345, 1353
Trutech 1425
Viewsonic 1038, 1149, 1180, 1181

1182, 1183, 1184, 1185

1186, 1187, 1188, 1189

1190, 1205, 1206, 1441
Viore 1435
Vizio 1429, 1433, 1439
Westinghouse

1454

Zenith 1020, 1139, 1207, 1253

1255, 1333, 1342, 1349

TV-DVD COMBO

Akai 1427, 2378
Apex 1163, 2095
Axion 1459, 2379
Bang & Olufsen

1453, 2370
Broksonic 1114, 2053
Coby 1460, 2380
Cytron 1456, 2374
DiamondVision

1461, 2382
Hitachi 1226, 2240
Ilo 1457, 2375
Initial 1457, 2381
JVC 1288, 2206
LG 1255, 2371
Mintek 1457, 2381
Panasonic 1289, 2207
Philips 1290, 1291, 1337, 2208

2209, 2243
Polaroid 1440, 1458, 2377, 2409
RCA 1115, 1162, 1379, 2063

2099, 2289
Sansui 1122, 2071
Sylvania 1150, 1464, 2092, 2408
Toshiba 1116, 1293, 1294, 1345

2054, 2210, 2210, 2231
Westinghouse

1454, 2372

TV-DVD-TUNER COMBO

Audiovox 1455, 2373, 5152

TV-VCR COMBO

Broksonic 1121, 1382, 1383, 3081

3202, 3213
Daewoo 1298, 3150
Emerson 1382, 1383, 3202, 3213
GE 1164, 1380, 1381, 3090

3201, 3203
JVC 1299, 3151
Maganvox 1302, 1321, 3154, 3181
Magnavox 1300, 1301, 3152, 3153
Magnin 1380, 3201
MGA 1380, 3201
Mitsubishi 1381, 3203
Orion 1382, 1383, 3202, 3213
Panasonic 1305, 1306, 3158, 3159
Penney 1380, 3201
Philips 1307, 1308, 3152, 3160
Quasar 1165, 1166, 3091, 3092
RCA 1167, 1168, 1310, 1380

1381, 3093, 3094, 3162

3201, 3203
Samsung 1161, 3089
Sansui 1382, 1383, 3202, 3213
Sanyo 1380, 3201
Sharp 1311, 1312, 3163, 3164
Sylvania 1145, 3095
Toshiba 1006, 1006, 1267, 1313

1315, 1319, 3096, 3165

3166, 3167, 3168, 3182
Zenith 1118, 1382, 1383, 3097

3202, 3213

TV-DVD-VCR COMBO

Magnavox 1339, 2241, 3183,
Panasonic 1123, 1152, 2075, 2076

Manufacture Code List

TV

Abex 1098
Admiral 1001, 1099
Advent 1005, 1053, 1110, 1113
Adventura 1100
Aiko 1015
Aiwa 1034
Akai 1002, 1427
Alleron 1044
Amtron 1036
Anam National

1003, 1036
AOC 1004, 1005
Apex 1111, 1119, 1163, 1256
Audiovox 1036
Bang & Olufsen

1453
Belcor 1004
Bell & Howell

1001, 1045
Benq 1042
Bradford 1036
Broksonic 1114, 1121, 1382, 1383
Brokwood 1004
Candle 1004, 1007, 1100
Celebrity 1002
Citizen 1004, 1007, 1015, 1036

1073, 1097, 1100
Colortyme 1004
Concerto 1004
Contec/Cony

1011, 1012, 1036
Craig 1036
Crosley 1000, 1053
Crown 1036, 1053
CTX 1257
Curtis Mathes

1000, 1004, 1014, 1045

1073, 1097, 1385
CXC 1036
Cytron 1456
Daewoo 1004, 1005, 1013, 1015

1016, 1097, 1106, 1258

1362, 1368, 1369
Daytron 1004, 1097
DiamondVision

1461
Dimensia 1000
Dumont 1160
Durabrand 1259
Dynatech 1004
Electroband 1002
Electrohome

1002, 1003, 1004, 1018

1021

Emerson 1004, 1011, 1013, 1025

1028, 1031, 1033, 1036
1044, 1045, 1080, 1097
1101, 1102, 1107, 1382

1383
Envision 1004
Fisher 1043, 1045, 1047, 1103
Fujitsu 1029, 1044
Funai 1036, 1044, 1384
Futuretec 1036
Gateway 1038
GE 1000, 1003, 1004, 1008

1021, 1048, 1049, 1063

1068, 1094, 1144, 1164

1224, 1367, 1380, 1381

1385, 1386
Gibralter 1160
Goldstar 1004, 1005, 1011, 1018

1050, 1090, 1091, 1097

1098, 1400, 1401
Grunpy 1036, 1044
Hallmark 1004
Harley Davidson

1384
Harvard 1036
Hisense 1112
Hitachi 1004, 1011, 1012, 1051

1052, 1084, 1085, 1086

1087, 1102, 1225, 1384
HP 1408
Ilo 1457
IMA 1036
Infinity 1053
Janeil 1100
JBL 1053
JC Penney 1000, 1004, 1005, 1007

1012, 1021, 1048, 1049

1058, 1063, 1068, 1072

1073, 1075, 1097, 1098
JCB 1002
Jensen 1004, 1232, 1285, 1314

1376
JVC 1011, 1012, 1026, 1049

1052, 1054, 1055, 1080

1092, 1117, 1131, 1235

1288, 1299
Kawasho 1002, 1004
Kenwood 1004, 1018
Kloss Novabeam

1036, 1056, 1057, 1100

KTV 1036, 1097, 1101

5085, 5086, 5087, 5130

5131, 5140
Optimus 5144
Panasonic 5019, 5020, 5107, 5108

5109, 5110, 5111, 5115

5126
Philips 5000, 5112, 5138, 5143

5145, 5154
Pioneer 5021, 5022, 5088, 5089

5090, 5091, 5092, 5093

5094, 5119, 5120, 5144

5147
Polaroid 5141
Polk Audio 5143
RCA 5024, 5025, 5026, 5137

5144
Rotel 5150
Samsung 5139
Sansui 5000, 5143
Sherwood 5027
Sony 5017, 5023, 5028, 5029

5030, 5031, 5032, 5033

5095, 5096, 5097, 5113

5117, 5121, 5125, 5129

5133, 5134, 5136, 5146
Technics 5016, 5019, 5020, 5098
5099, 5100, 5101, 5115
5122, 5126
Thorens 5145
Wards 5000, 5021, 5143
Yamaha 5003, 5014, 5015, 5021

5102, 5103, 5104, 5105

5106, 5118, 5135

AMPLIFIER

Adcom 6055
Aiwa 6003, 6020
Carver 6002
Citizen 6026
Curtis Mathes

6046
Denon 6014, 6039, 6057
Fisher 6002
GE 6028, 6045
Goldstar 6016, 6021
Harman/Kardon

6047

Harmon/Kardon

6013
Hitachi 6034
JBL 6050
JVC 6018, 6024, 6041
Kenwood 6015, 6022
Left Coast 6047
Magnavox 6035
Marantz 6000, 6047, 6058
Nakamichi 6012
NEC 6033, 6048
Onkyo 6005, 6006, 6017, 6054

6056
Optimus 6008, 6046
Panasonic 6001, 6040
Parasound 6059
Philips 6047
Pioneer 6004, 6009, 6010, 6023

6036, 6046, 6051
Polk Audio 6047
Proton 6035
Quasar 6001
RCA 6025, 6046
Sharp 6029, 6030, 6031, 6032
Sherwood 6011
Shure 6048
Sony 6020, 6042, 6044, 6049
Soundesign 6045
Teac 6019
Technic 6001
Technics 6001, 6040
Toshiba 6027
Victor 6024
Wards 6045
Yamaha 6007, 6037, 6038, 6043

6052, 6053

AT&T RC1534819 (12 Jun 2008).ind2 2 6/12/2008 1:36:48 PM
