Philips TV-DVD User Manual

14” TV-DVD

My Cool Entertainment Box!

DVD integration comes to small screen TV.This cool 14”TV comes with a built-in DVD/CD/MP3 player and 2 mono sound speakers. Ideal choice for movie entertainment because it can playback DVD picture on stereo sound.

Enhanced video performance

• Black Hibri picture tube gives good colour reproduction on small screen

Multi-purpose convenience

• Integrated CD/DVD/MP3 player that plays practically any disc format

• Picture CD playback digital still pictures

Intuitive control, feeling your needs

• Smart picture and smart sound provide personalized settings

• The perfect TV remote with all main TV control functions

14PT6107

14” TV-DVD 14PT6107

Technical specifications


• Screen Size : 14” (37 cm)

• Visible screen size : 34 cm

• Picture Tube : Black Hibri

• Sharpness Control

Sound

• Sound Power : 5 W RMS 10 W Music Power

• Mono Sound

• Stereo Playback for DVD

• 2 On Board Speakers

Ease of Use Installation

• 100 Preset channels

• Autostore

• Manual store

• Fine tuning

• Sorting

Ease of Use Utilisation

• Remote Control : RCLE016

• Smart Picture : Soft, Natural,

Control Rich,Multimedia, Personal

• 16:9 Compress

• Parental Control

• Smart Sound : Movie, Speech, Music,

Control Personal

• Sleep Timer

Connections

Front

• Headphone jack 3.5 mm out

Side

• Video CVBS in

• Audio ( cinch RCA) in

• Euro A/V connector Ext1

(RGB in, CVBS in/out)

• Digital out (coaxial)

• Stereo Audio out (cinch) Constant Level

Information

• 1 Page Teletext

• Program Information Line

DVD Playe r

• Playback DVD/Video CD/CD Audio/MP3/ CD-R/CD-RW/DVD-R/DVD-RW

• Picture CD Playback

• Still Picture

• Zoom 2/3/4

• Favourite Track Selection

• Parental Control and Disc Lock

Reception

• Tuning System : PLL digital tuning

• Tuner : VHF, UHF, S-Channel,

Hyperband

• Aerial Input : 75 ohm Coaxial

• TV System : See table

• Video Playback : NTSC 4.43/3.58

Miscellaneous

• Mains : AC 90-276 V, 50/60 Hz

• Power Consumption: 50 W Normal Operation

<3 W stand by

• Set Weight : 9.8 Kg

• Weight Incl. : 12.5 Kg Packaging

• Set Dimension : 384 x 384 x 392 mm (WxDxH)

• Box Dimension : 460 x 460 x 470 mm (WxDxH)

• TV Colour : Silver Shadow (10811)

Product highlights

Black Hibri

Tv tube technology used for all Philips 14” tv's giving good colour reproduction on the smaller sets.

Smart Picture

Smart Picture provides the optimum picture settings for color, brightness, saturation, contrast, sharpness, etc. to enhance your overall viewing experience at all times.

On Board CD/DVD/MP3 Player

Just press play on the integrated TV-DVD remote control and the Philips TV-DVD plays it all; DVD-Video discs,Video CDs, Super Video CDs, Audio CDs, Home recorded CDs and MP3 CDs.

Picture CD Playback

A Picture CD contains digital still pictures in JPEG format. Most Philips DVD players and recorders support playback of Picture CDs & home created discs as well as ones from photo shops.

1 page Teletext

The teletext provide a rich variety of information, which includes TV guide.

Sleeptimer

The Sleeptimer automatically turns the TV off at a preset time of up to 240 minutes from the time the feature is activated. Sleeptimer settings are programmed in 15, 30, and 60-minute increments.

Front / Side Connections

Digital cameras and video games can be connected quickly and easily to video or stereo AV inputs. Connect your headphones (optional) for convenient private listening.

version

14PT6107 /00

14PT6107

PAL PAL PAL SECAM SECAM SECAM

/01

/05

/58

transmission system stand supplied

BG DK I BG DK LL’

in the box

Predecessor : 14PT6107

Chassis : PT90B

Introduction :Year 2003

Date of issue 2004-01-15

Specifications subject to change without notice.
