Over Ear
8000 Series8000 Series
PH802
User manual
Register your product and get support at
www.philips.com/support
Contents
1 Important safety instructions 2
Hearing Safety 2
General information 2
2 Your Bluetooth over-ear
headphones 3
What's in the box 3
Other devices 3
Overview of your Bluetooth
wireless headset 4
3 Get started 5
Charge the battery 5
Pair the headphones with your
mobile phone 5
4 Use your headphones 6
Connect the headphones to a
Bluetooth device 6
Manage your calls and music 6
5 Technical data 8
6 Notice 9
Declaration of conformity 9
Disposal of your old product
and battery 9
Remove the integrated battery 9
Compliance with EMF 9
Environmental information 10
Notice of compliance 10
7 Trademarks 11
7 Frequently asked questions 12
1 Important
General information
safety
instructions
Hearing Safety
Danger
To avoid hearing damage, limit the time you
use headphones at high volume and set the
volume to a safe level. The louder the
volume, the shorter the safe listening time is.
Be sure to observe the following guidelines when using your headset.
• Listen at reasonable volumes for
reasonable periods of time.
• Be careful not to adjust the volume
continuously upwards as your
hearing adapts.
• Do not turn up the volume so high
that you can't hear what's around
you.
• You should use caution or temporarily discontinue use in potentially
hazardous situations.
• Excessive sound pressure from
earphones and headphones can
cause hearing loss.
• Using headphones with both ears
covered while driving is not recommended and may be illegal in some
areas while driving.
• For your safety, avoid distractions
from music or phone calls while in
trac or other potentially dangerous
environments.
To avoid damage or malfunction:
Caution
Do not expose headphones to excessive heat
Do not drop your headphones.
Headphones shall not be exposed to dripping
or splashing.
Do not allow your headphones to be
submerged in water.
Do not use any cleaning agents containing
alcohol, ammonia, benzene, or abrasives.
If cleaning is required use a soft doth, if
necessary dampened with a minimum amount
of water or diluted mild soap, to clean the
product.
The integrated battery shall not be exposed to
excessive heat such as sunshine, re or the
like.
Danger of explosion if battery is incorrectly
replaced. Replace only with the same or
equivalent type.
About operating and storage
temperatures and humidity
• Operate or store in a place where
temperature is between -15°C (5°F)
and 55°C (131 °F) (up to 90%
relative humidity.
• Battery life may be shorter in high
or low temperature conditions.
2 Your
Bluetooth
over-ear
headphones
Congratulations on your purchase, and
welcome to Philips! To fully benet
from the support that Philips oers,
register your product at
www.philips.com/welcome.
With this Philips over-ear headphones,
you can:
• enjoy convenient wireless
handsfree calls;
• enjoy and control wireless music;
• switch between calls and music.
What's in the box
Audio cable
Quick start guide
Other devices
A mobile phone or device (e.g. notebook, PAD, Bluetooth adapters, MP3
players etc) which supports Bluetooth
and is compatible to the headset (see
'Technical data' on page 8).
Philips Bluetooth over-ear headphones
Philips TAPH802
USB charging cable (for charging only)
Overview of your
Bluetooth wireless
headset
1
2
3
4
Audio jack
Microphone
LED indicator
(Power on / o / Pairing)
Micro charging slot
5
3 Get started
Charge the battery
Note
Before you use your headset for the rst time,
place the headsets in the charging case and
charge the battery for 3 hours for optimum
battery capacity and lifetime.
Use only the original USB charging cable to
avoid any damage.
Finish your call before charging the headset,
as connecting the headset for charging will
power the headset o.
Charging case
Connect the supplied USB charging
cable to:
• The micro USB charging slot on the
headphones and;
• The charger/USB port of a
computer.
LED turns red during charging and
turns o when the headphones in
fully charged.
Tip
Normally, a full charge takes 2 hours.
Pair the headphones with
your mobile phone
Before you use the headphones with
your mobile phone for the rst time, pair
it with a mobile phone. A successful
pairing establishes a unique encrypted
link between the headphones and
mobile phone. The headphones store
the last 8 devices in the memory. If you
try to pair more than 8 devices, the
earliest paired device is replaced by the
new one.
Make sure that the headphones are
fully charged and turned o.
Press and hold for 5 seconds
until the blue and red LED ashes
alternately.
The headphone remain in
pairing mode for 2 minutes.
Make sure that the mobile phone is
turned on and its Bluetooth feature
is activated.
Pair the headphones with the
mobile phone. For detailed information, refer to the user manual of
your mobile phone.
The following example shows you how
to pair the headphones with your mobile
phone.
Activate the Bluetooth feature of your
mobile phone, select Philips PH802
Philips PH802
4 Use your
headset
Manage your calls and
music
On/o
Connect the headset to
your Bluetooth device
Turn on your mobile phone/
Bluetooth device.
Press and hold the on/o button to
turn the headphones on.
The blue LED will turn on 3s.
The headphones are reconnected to the last connected
mobile phone/ Bluetooth
device automatically.
Tip
If you turn on the mobile phone/Bluetooth
device or activate the Bluetooth feature after
turning on the headphones, you have to
reconnect the headphones and mobile
phone/ Bluetooth device manually.
Note
If the headphones fail to connect to last
connected Bluetooth device within range in 2
minutes, it will change to pairing mode, then
will switch o automatically if it’s still not
connected to any Bluetooth device 8 minutes
later.
If the headphone has no any connection
history and doesn’t connect any Bluetooth
device whith 2 minutes, it will switch o
automatically.
Wired Connection
You can also use the headphones with
the audio cable provided. Connect the
supplied audio cable to the headphones and external audio device.
Task
Turn the
headphones on.
Turn the
headphones o.
Music control
Task
Play or
pause music.
Adjust volume.
Next track.
Previous track.
Call control
Task
Pick up/
hang up a
call.
Switch
caller
during a
call.
Button
On/o,
music/call
control
On/o,
music/call
control
Button
On/o,
music/call
control
Button
On/o,
music/
call control
On/o,
music/call
control
Operation
Press and hold
for 3 seconds.
Press and hold
for 3 seconds.
The blue
LED is
on and
fades
out.
Operation
Press once.
Press once.
Long press.
Long press.
Operation
Press once.
Press twice.
Tip
The function keys will be disabled when
using line-in mode.
Other headphones indicator status
Headphones status
The headphones
are connected
to a Bluetooth
device, while the
headphones in
standby mode
or while you are
listening to music.
The headphones
are ready for
pairing.
The headphones
are on but not
connected to a
Bluetooth device.
Low battery level. The red LED
Battery is fully
charged.
Indicator
The blue LED is
on.
The LED ashes
blue and red
alternately.
The red LED
ashes slowly.
If no connection
can be made, the
headphones will
turn itself o within
8 minutes.
ashes once every
2 seconds until it is
out of power
Red LED is o.
5 Technical data
Headset
Music time: 30 hours
Talk time: 30 hours
Standby time: 160 hours
Charging time: 2 hours
Rechargeable lithium polymer
battery (680 mAh)
Bluetooth version: 4.2
Compatible Bluetooth proles:
• HSP (Hands-Free Prole-HFP)
• A2DP (Advanced Audio Distribution Prole)
• AVRCP (Audio Video Remote
Control Prole)
Supported audio codec: SBC
Frequency range: 2.402-2.480 GHz
Transmitter power: < 10 dBm
Operating range: Up to 10 meters (33
feet)
Digital echo & noise reduction
Auto power o
Micro-USB port for charging
Supports SBC
Low battery warning: available
Note
Specications are subject to change without
notice.
6 Notice
Declaration of conformity
Hereby, MMD Hong Kong Holding Limited
declares that this product is in compliance with the essential requirements and
other relevant provisions of Directive
2014/53/EU. You can nd the Declaration
of Conformity on www.p4c.philips.com.
Disposal of your old
product and battery
Your product is designed and manufactured with high quality materials and
components, which can be recycled and
reused.
This symbol on a product means that
the product is covered by European
Directive 2012/19/EU.
This symbol means that the product
contains a built-in rechargeable battery
covered by European Directive
2013/56/EU which cannot be disposed
of with normal household waste. We
strongly advise you to take your product
to an ocial collection point or a Philips
service centre to have a professional
remove the rechargeable battery.
Inform yourself about the local separate
collection system for electrical and
electronic products and rechargeable
batteries. Follow local rules and never
dispose of the product and rechargeable
batteries with normal household waste.
Correct disposal of old products and
rechargeable batteries helps prevent
negative consequences for the environment and human health.
Remove the integrated battery
If there is no collection/recycling system
for electronic products in your country,
you can protect the environment by
removing and recycling the battery
before disposing the headphones.
• Make sure the headset is disconnected from the charging case
before removing the battery.
Compliance with EMF
This product complies with all applicable standards and regulations regarding
exposure to electromagnetic elds.
Environmental information
All unnecessary packaging has been
omitted. We have tried to make the
packaging easy to separate into three
materials: cardboard (box), polystyrene
foam (buer) and polyethylene (bags,
protective foam sheet.)
Your system consists of materials which
can be recycled and reused if disassembled by a specialized company. Please
observe the local regulations regarding
the disposal of packaging materials,
exhausted batteries and old equipment.
Notice of compliance
The device complies with the FCC rules,
Part 15. Operation is subject to the
following two conditions:
1. This device may not cause harmful
interference, and
2. This device must accept any
interference received, including
interference that may cause
undesired operation.
FCC rules
This equipment has been tested and
found to comply with the limits for a
Class B digital device, pursuant to part
15 of the FCC Rules. These limits are
designed to provide reasonable protection against harmful interference in a
residential installation. This equipment
generates, uses and can radiate radio
frequency energy and, if not installed
and used in accordance with the
instruction manual, may cause harmful
interference to radio communications.
However, there is no guarantee that
interference will not occur in a particular
installation. If this equipment does
cause harmful interference to radio or
television reception, which can be
determined by turning the equipment o
and on, the user is encouraged to try to
correct the interference by one or more
of the following measures:
Reorient or relocate the receiving antenna.
Increase the separation between
equipment and receiver
Connect the equipment into an outlet
on a circuit dierent from that to which
the receiver is connected.
Consult the dealer or an experienced
radio/TV technician for help.
FCC Radiation Exposure Statement:
This equipment complies with FCC
radiation exposure limits set forth for an
uncontrolled environment.
This transmitter must not be co-located
or operating in conjunction with any
other antenna or transmitter.
Caution:
changes or modications not expressly
approved by the party responsible for
compliance could void the user's
authority to operate the equipment.
Canada:
This device contains licence-exempt
transmitter(s)/receiver(s) that comply
with Innovation, Science and Economic
Development Canada’s licence- exempt
RSS(s). Operation is subject to the
following two conditions: (1) this device
may not cause harmful interference, and
(2) This device must accept any interference received, including interference
that may cause undesired operation of
the device.
CAN ICES-3(B)/NMB-3(B)
IC Radiation Exposure Statement:
This equipment complies with Canada
radiation exposure limits set forth for
uncontrolled environments.
This transmitter must not be co-located
or operating in conjunction with any
other antenna or transmitter.
The user is cautioned that
7 Trademarks
Bluetooth
The Bluetooth® word mark and logos
are registered trademarks owned by
Bluetooth SIG, Inc. and any use of such
marks by MMD Hong Kong Holding
Limited is under license. Other trademarks and trade names are those of
their respective owners.
Siri
Siri is a trademark of Apple Inc., registered in the U.S. and other countries.
8 Frequently
asked
questions
My Bluetooth headset does not turn on.
The battery level is low. Charge the
headset.
I cannot pair my Bluetooth headset with
my Bluetooth device.
The Bluetooth is disabled. Enable the
Bluetooth feature on your Bluetooth
device and turn on the Bluetooth device
before you turn on the headset.
How to reset pairing.
Let headphone stay in pairing mode (red
and blue lights ash alternately), push the
power button up to + and hold more
than 10 seconds until purple LED light on.
I hear but cannot control music on my
Bluetooth device (e.g. play/pause/skip
forward/backward).
Make sure the Bluetooth audio source
supports AVRCP (see ‘Technical data’ on
page 10).
The volume level of the headset is too low.
Some Bluetooth devices cannot link the
volume level with the headset through
volume sync. In this case, you have to
adjust the volume on your Bluetooth
device independently to achieve an
appropriate volume level.
The Bluetooth device cannot nd the
headset.
• The headset may be connected to a
previously paired device. Turn o the
connected device or move it out of
range.
• Pairing may have been reset or the
headset has been previously paired
with another device. Pair the headset
with the Bluetooth device again as
described in the user manual. (see
‘Pair the headset with your Bluetooth
device at the rst time’ on page 6).
My Bluetooth headset is connected to a
Bluetooth stereo enabled mobile phone,
but music only plays on the mobile phone
speaker.
Refer to the user manual of your mobile
phone. Select to listen to music through
the headset.
The audio quality is poor and crackling
noise can be heard.
• The Bluetooth device is out of range.
Reduce the distance between your
headset and Bluetooth device, or
remove obstacles between them.
• Charge your headset.
The audio quality is poor when streaming
from the mobile phone is very slow, or
audio streaming does not work at all.
Make sure your mobile phone not only
supports (mono) HFP but alos supports
A2DP and is BT4.0x (or higher) compatible
(see ‘Technical data’ on page 8).
For further support, visit www.philips.com/support.
Este equipamento não tem direito à proteção contra interferência prejudicial e não
pode causar interferência em sistemas devidamente autorizados.
Este produto está homologado pela ANATEL, de acordo com os procedimentos
regulamentados pela Resolução 242/2000, e atende aos requisitos técnicas
aplicados. Para maiores informações, consulte a site da ANATEL:
www.anatel.gov.br
Philips and the Philips Shield Emblem are registered trademarks of
Koninklijke Philips N.V. and are used under license. This product has been
manufactured by and is sold under the responsibility of MMD Hong Kong
Holding Limited or one of its aliates, and MMD Hong Kong Holding
Limited is the warrantor in relation to this product.
06614-19-12451
UM_TAPH802_00_EN_V0.4
Loading...
