System One Heated Humidifier
USER MANUAL
© 2016 Koninklijke Philips N.V. All rights reserved.
Table of Contents
Intended Use ........................................................................................................................................................... 2
Warnings ..................................................................................................................................................................2
Cautions ................................................................................................................................................................... 2
Contraindications .................................................................................................................................................. 3
Symbol Key .............................................................................................................................................................. 3
System Overview ................................................................................................................................................... 3
Available System One Heated Humidiers ...................................................................................................... 4
System Features and Contents ........................................................................................................................... 4
Connecting the Therapy Device ......................................................................................................................... 5
Connecting the Optional Heated Tubing .......................................................................................................... 6
Disconnecting the Optional Heated Tubing ..................................................................................................... 6
Disconnecting the Therapy Device .................................................................................................................... 7
Daily Use..................................................................................................................................................................7
Home Cleaning Instructions: Water Tank ......................................................................................................10
Home Cleaning Instructions: Humidier Base ..............................................................................................10
Home Cleaning Instructions: Heated Tubing ..................................................................................................11
Hospital and Institution Disinfection: Water Tank and Heated Tubing .....................................................11
Service .................................................................................................................................................................... 12
Traveling with the System ..................................................................................................................................12
Disposal ..................................................................................................................................................................12
How to Contact Philips Respironics ...............................................................................................................12
Troubleshooting ...................................................................................................................................................13
System One Heated Humidier Specications .............................................................................................15
Heated Tubing Specications .............................................................................................................................16
Limited Warranty ...................................................................................................................................Back Page
1
CAUTION: U. S. federal law restricts this device to sale by or on the order of a physician.
Intended Use
The System One Heated Humidier is an accessory for the Philips Respironics REMstar and BiPAP therapy devices to provide moisture
to the patient circuit. It is intended for use in spontaneously breathing patients weighing over 30 kg (66 lbs), in the home or hospital/
institutional environment, who use mask-applied positive pressure ventilation therapy.
Warnings
A warning indicates the possibility for injury to the user or the operator.
• Use the humidier only for its intended use as described in this manual. Use only with Philips Respironics full-face masks, nasal
masks and connectors.
• Periodically inspect the humidier for signs of wear or damage. Never operate the humidier if any parts are damaged, if it is not
working properly, or if the humidier has been dropped or mishandled. Do not use the humidier if the water tank is leaking or
damaged in any way. Have any damaged parts replaced before continuing use.
• Periodically inspect the humidier power cord for signs of wear or damage. If it becomes worn or damaged, contact Philips
Respironics or your home care provider for a replacement.
• The humidier must always be positioned below the breathing circuit connection at the mask and the air outlet on the device.
The humidier must be level for proper operation.
• Allow the humidier heater plate and water to cool down for approximately 15 minutes before removing the water tank. A burn
may result from: touching the heater plate, coming in contact with the heated water, or touching the tank pan.
• This equipment is not suitable for use in the presence of a ammable anesthetic mixture with air or with oxygen or nitrous oxide.
• When installing the water tank, do not allow any water to spill into the humidier or therapy device.
• If you notice any unexplained changes in the performance of this device, if it is making unusual or harsh sounds, if it has been
dropped or mishandled, if water is spilled into the enclosure, or if the enclosure is broken, disconnect the power cord from the
therapy device and discontinue use. Contact your home care provider.
• Before cleaning the humidier, always remove from the therapy device.
• Empty and clean the water tank daily to prevent mold and bacteria growth. Wipe the seal completely.
Note: Please see the “Limited Warranty” section of this manual for information on warranty coverage.
Cautions
A caution indicates the possibility of damage to the device.
• Do not place the humidier directly onto carpet, fabric, or other ammable materials.
• Do not place the device in or on any container that can collect or hold water. Take precautions to protect furniture from water damage.
• Do not ll the water tank above the maximum ll line. Damage to the humidier or therapy device may occur. If the water tank is
overlled, water may leak out of the tank inlet (located on the back of the tank) when installing the tank lid.
• Use only room temperature distilled water in the tank. Do not put any chemicals or additives into the water. Possible airway
irritation or damage to the water tank may result.
• Remove the tank, empty all water, and replace the empty tank before transporting the humidifier base.
• Do not attempt to ll the water tank while it is still inside the humidier.
• To avoid spilling, do not disconnect the humidier from the therapy device with water in the tank. Remove the water tank from
the humidier before disconnecting the therapy device.
• Do not turn the humidier on without the water tank installed. The Humidier setting must remain “off” if there is no water in
the water tank.
• The humidier door must be set in the open position before removing the water tank. Do not remove the water tank without
making sure that the humidier door locks into the open position.
• Do not move the humidier while the water tank has water in it.
• Use a mild liquid dishwashing detergent only for either hand washing or when using a dishwasher.
• Only the hospital and institution cleaning procedures listed in this manual are recommended by Philips Respironics. Use of other
cleaning and disinfecting processes, not specied by Philips Respironics, may affect the performance of the product.
2
Contraindications
Studies have shown that the following pre-existing conditions may contraindicate the use of CPAP therapy for some patients:
• Bullous Lung Disease
• Pathologically Low Blood Pressure
• Bypassed Upper Airway
• Pneumothorax
• Pneumocephalus has been reported in a patient using nasal Continuous Positive Airway Pressure. Caution should be used when
prescribing CPAP for susceptible patients such as those with: cerebral spinal uid (CSF) leaks, abnormalities of the cribriform
plate, prior history of head trauma, and/or pneumocephalus. (Chest 1989; 96:1425-1426)
The use of positive airway pressure therapy may be temporarily contraindicated if you exhibit signs of a sinus or middle ear
infection. Not for use with patients whose upper airways are bypassed. Contact your health care professional if you have any
questions concerning your therapy.
Refer to the instructions for use that accompanied your therapy device for any additional contraindications that may be specic to
the use of that device.
Symbol Key
The following symbols may appear on the device:
Symbol Definition Symbol Definition
Maximum Fill Line
Hot Water, Hot Surface Type BF Applied Part
Follow Instructions for Use
IP22
Drip Proof Equipment
System Overview
The System One Heated Humidier attaches to the therapy device and provides an air outlet port to connect a breathing circuit.
The breathing circuit is comprised of patient tubing, a mask, and in some instances a separate exhalation device. The patient tubing
can be Respironics heated tubing, 22 mm (non-heated) performance tubing or 15 mm (non-heated) performance tubing. For
information related to the mask to be used, including any need for a separate exhalation device, consult the instructions for use that
accompany both the mask and therapy device.
The System One Heated Humidier with Heated Tubing is designed to deliver humidication to provide added comfort during
therapy. This humidication level is controlled through the output of the heated humidier as well as the temperature of the
optional heated tubing. Use of these two accessories allows for a comfortable level of humidity to be maintained at the mask.
The System One Heated Humidier is comprised of the following components:
• HeatedHumidier - The heated humidier is the primary source of humidication. Humidication is controlled by adjusting
the temperature of the heater plate. The heater plate is then used to heat water found in the water tank. This manual includes
instructions that explain how to set up and take of the heated humidier. For instructions on how to adjust the output of the
heated humidier, refer to the instructions for use that accompanied the therapy device.
• WaterTank - The water tank stores the water that will be used by the heated humidier. This manual includes instructions that
cover how to ll up and take care of the water tank.
• HeatedTubing - The heated tubing is an optional accessory that is used, along with the heated humidier, to control the
provided humidication. This is accomplished by controlling the temperature of the air in order to ensure that it does not cool
down prior to reaching the mask. This manual includes instructions that cover how to connect and take care of the heated tubing.
For instructions on how to adjust the temperature of the heated tubing, refer to the instructions for use that accompanied the
therapy device.
3
AvailableSystemOneHeatedHumidiers
Humidifier Connector End
Air Inlet
Air Outlet Port
The System One Heated Humidier is available in the following congurations:
HeatedHumidier - This humidier provides moisture to the patient circuit. It has a standard air outlet port for
use with Philips Respironics 15 and 22mm tubing.
HeatedHumidierwithHeatedTubing - This humidier provides moisture to the patient circuit but also
allows for the option of heated tubing. In order to function with the heated tubing, it has a modied air outlet port
that includes both a 3-pin connector and a heated tubing locking mechanism. The heated tubing compatible System
One Heated Humidier can be seen in the “Connecting the Optional Heated Tubing” section of this manual.
System Features and Contents
IMPORTANT: Read and understand the entire manual for your therapy device before attempting to use this humidier.
Water Tank
Humidifier Door
Port
Humidifier
(connects to
Therapy Device)
Thisgureillustratesmanyofthedevicefeaturesandcontents,describedinthetablebelow.
item DeScription
Humidier Connect your therapy device here.
Air Inlet Port Connects to the outlet port on the therapy device.
Air Outlet Port (conical, 22 mm)
(Standard Port shown here)
Heater Plate Warms the water in the water tank.
Humidier Door Open the door to access the water tank.
Humidier Door Lever Lift up on the lever to open the humidier door.
Water Tank The removable water tank holds the water for humidication.
Maximum Fill Lines The ll lines indicates the maximum water level for safe operation. (Found on front and both
Flexible Heated Tubing
(optional)
Humidier Connector End Connect this end of the tubing to the humidier.
Note: This humidier is specied for use with Philips Respironics REMstar and BiPAP therapy devices only.
Connect the patient circuit here. (If you are using the optional heated tubing, this outlet port
will look slightly different. Refer to “Connecting the Optional Heated Tubing” section of this
manual.)
sides of tank.)
The optional heated tube connects from the humidier to the patient’s mask.
Heater Plate
Maximum Fill Lines
Flexible Heated Tubing
(optional accessory)
4
ConnectingtheTherapyDevice
b
Therapy Device Humidier
Slots
1. When using a humidier, the patient circuit attaches to the air outlet port on the humidier.
2. To connect the therapy device to the humidier, rst you must remove the side cover on the therapy device. Press
in the tab on the side cover and pull the cover away from the unit.
Note: Therapy device shown is an example. Actual therapy device may vary.
Therapy Device
Ta
Side Cover
3. Next, line up the components side by side. Make sure that the guides on the humidier t into the slots on the
therapy device and the air outlet port on the therapy device ts into the air inlet port on the humidier.
Air Inlet Port
Air Outlet Port
Guides
4. While holding both the therapy device and the humidier, pull the release latch (on the bottom of the humidier)
and press the two units together until they snap into place. Let go of the release latch. Make sure that the therapy
device and the humidier are completely seated against each other.
Humidifier
(bottom view)
Release Latch
Release Latch
5
ConnectingtheOptionalHeatedTubing
Heated Tubing
rt
Heated Tubing
1. To attach the optional heated tubing to the humidier, line up the humidier connector end of the tubing with the
Heated Tubing compatible air outlet port on the humidier. Make sure the 3-pin connector at the top of the tube
lines up with the opening at the top of the air outlet port. Press the tubing into place over the air outlet port until
the tabs on the side of the tube click into place in the slots on the side of the outlet port.
3 Pin Connector
Heated Tubing
Air Outlet Port
Ta bs
Slot
Note: Non-heated Philips Respironics tubing (15 or 22 mm) can still be used with this humidier with the heated tubing air
outlet port. Simply connect the tubing to the air outlet port. Refer to the therapy device manual for setup instructions.
DisconnectingtheOptionalHeatedTubing
1. To remove the heated tubing, press in the tabs on the side of the tubing connector and pull the tubing away from
the outlet port.
Heated Tubing
Air Outlet Po
Ta b
6
DisconnectingtheTherapyDevice
Release Latch
Cover Release Lever
on top and bottom
CAUTION: To avoid spilling, do not disconnect the humidier from the therapy device with water in the tank.
Remove the water tank from the humidier before disconnecting the therapy device.
1. Grasp the release latch on the bottom of the humidier.
2. While holding both the therapy device and the humidier, pull the release latch and pull the two units apart.
Humidifier
(bottom view)
Release Latch
3. If you will be using the therapy device without the humidier, reattach the side cover to the therapy device.
DailyUse
1. Place the connected therapy device with humidier on a rm, at surface lower than your sleeping position.
WARNING: The humidier must always be positioned below the breathing circuit connection at the mask and
the air outlet on the device. The humidier must be level for proper operation.
CAUTION: Do not place the humidier directly onto carpet, fabric, or other ammable materials.
CAUTION: Do not place the device in or on any container that can collect or hold water. Take precautions to
protect furniture from water damage.
CAUTION: Do not turn the humidier on without the water tank installed. The Humidier setting must remain
“off” if there is no water in the water tank.
CAUTION: Do not attempt to ll the tank while it is still inside the humidier.
WARNING: Allow the humidier heater plate and water to cool down for approximately 15 minutes before
removing the water tank. A burn may result from: touching the heater plate, coming in contact with the heated
water, or touching the tank pan.
2. Lift up on the release lever to open the humidier door until it locks in an open position. You will hear a “click”
once the door is opened far enough to remain in an open position. Remove the water tank by grasping the front of
the tank and sliding it out of the humidier base.
CAUTION: The humidier door must be set in the open position before removing the water tank. Do not
remove the water tank without making sure that the humidier door locks into the open position.
Grasp the Wa ter Ta nk
7
3. Press the tab in the hole on top of the tank in toward the front of the tank. Gently remove the tank lid from the
l
Hinges
Ta nk Base
nk Lid
Maximum Water Fill Lines
tank base and set aside. Empty any remaining water from the base of the tank.
Ta b
Ta nk Lid
Middle Sea
4. Rinse the tank with water. With the water tank sitting on a at surface, ll it with distilled water (approximately
325 ml) no higher than the maximum ll line located on the front and both sides of the tank.
Ta nk Base
Ta
Note: Clean the water tank before rst use. Refer to the “Home Cleaning” section in this manual.
CAUTION: Use only room temperature distilled water in the tank. Do not put any chemicals or additives into
the water. Possible airway irritation or damage to the water tank may result.
CAUTION: Do not ll the water tank above the maximum ll line. Damage to the humidier or therapy device
may occur. If the water tank is overlled, water may leak out of the tank inlet (located on the back of the tank)
when installing the tank lid.
8
5. Reassemble the tank by placing the hinges on the tank lid over the 2 tabs on the back of the tank base. Close the
b
Ta nk Base
lid until the tab on the lid snaps back under the lip in the tank base. Inspect the tank. When it is closed correctly,
the lid should be seated completely on the middle seal and it should sit snugly on the tank base so the tab can easily
snap back in place.
Hinges
Ta nk Lid
Middle Seal
Ta
Note: If the lid does not close easily onto the base, separate the two parts, reassemble the tank, and inspect it again.
CAUTION: Do not ll the water tank above the maximum ll line. Damage to the humidier or therapy device
may occur. If the water tank is overlled, water may leak out of the tank inlet (located on the back of the tank)
when installing the tank lid.
6. Slide the water tank back into the humidier.
WARNING: When installing the tank, do not allow any water to spill into the humidier or therapy device.
CAUTION: Do not move the humidier while the water tank has water in it.
7. Plug the power supply cord into the back of the therapy device.
8. Plug the AC power cord into the power supply provided with your therapy device, and then plug the AC power
cord into an electrical outlet that is not controlled by a wall switch.
IMPORTANT: You must use the 80W power supply when using the heated tube humidier with your therapy
device. The appropriate power supply can be identied by the symbol.
9. Attach the exible tubing from the patient circuit to the humidier’s air outlet port. (If using the optional heated
tubing, Refer to “Connecting the Optional Heated Tubing” section of this manual.)
IMPORTANT: Before each use, examine the exible tubing for any kinks, damage, or debris. If necessary, clean
the tubing to remove the debris. Replace any damaged tubing.
10. Turn on the airow on your device and begin therapy.
Note: For complete instructions on how to turn on the airow, refer to the manual included with your therapy device.
11. Put on your mask assembly when the air starts to ow.
Note: If you are having trouble with your mask, refer to the instructions included with the mask.
12. Refer to your therapy device manual for complete instructions on how to adjust both the Heated Humidier and
the optional Heated Tubing settings to achieve the desired humidity.
CAUTION: Do not turn the humidier on without the water tank installed. The Humidier setting must remain
“off” if there is no water in the water tank.
13. Refer to the manual included with your therapy device for instructions to turn off therapy.
9
UsingtheHeatedTubing
Refer to the instructions for use that accompanied the therapy device for adjusting the warming and/or
humidication level of the tubing. The heated tubing can be used with the following Philips Respironics
families of devices: System One sleep therapy devices, C-Series ventilatory support systems, and A-Series
ventilatory support systems.
HomeCleaningInstructions:WaterTank
Hand washing can be performed daily. Dishwashing can be performed once a week.
1. Turn the humidier setting off, turn the therapy device off, and allow the heater plate and water to cool.
WARNING: Allow the humidier heater plate and water to cool down for approximately 15 minutes before
removing the water tank. A burn may result from: touching the heater plate, coming in contact with the heated
water, or touching the tank pan.
2. Open the humidier door with the release lever, and then slide the water tank out of the humidier base.
3. Press the tab in the hole on top of the tank in toward the front of the tank. Gently remove the tank lid from the
tank base. Empty any remaining water from the base of the tank.
4. Wash the parts of the tank in the dishwasher (top shelf only) or in a solution of warm water and a mild liquid
dishwashing detergent. Gently wash the middle seal. Rinse the parts with clean water. Wipe the parts completely
on the top and bottom. Allow them to air dry.
CAUTION: Use a mild liquid dishwashing detergent only for either hand washing or when using a dishwasher.
WARNING: Empty and clean the water tank daily to prevent mold and bacteria growth. Wipe the seal
completely.
5. Inspect the tank and seal for damage.
Note: Never use the water tank if the tank lid does not t comfortably on the tank base.
6. Before using the tank, ll it with distilled water (per the directions in the “Daily Use” section) no higher than the
maximum ll line located on the front and sides of the tank.
7. Reassemble the tank by placing the hinges on the tank lid over the 2 tabs on the back of the tank base. Close the
lid until the tab on the lid snaps back under the lip in the tank base. Inspect the tank. When it is closed correctly,
the lid should be seated completely on the middle seal and it should sit snugly on the tank base so the tab can
easily snap back in place. Inspect the water tank for any leaks or damage. If the water tank shows signs of wear or
damage, contact your home care provider for a replacement.
Note: If the lid does not close easily onto the base, separate the two parts, reassemble the tank, and inspect it again.
HomeCleaningInstructions:HumidierBase
WARNING: Allow the humidier heater plate and water to cool down for approximately 15 minutes before
removing the water tank. A burn may result from: touching the heater plate, coming in contact with the heated
water, or touching the tank pan.
WARNING: Before cleaning the humidier, always remove from the therapy device.
1. Clean the humidier base and heater plate by wiping it with a damp cloth. Allow the platform to air dry before
reconnecting to the therapy device.
2. Inspect the humidier base for any damage and replace it if necessary.
3. Clean the humidier outlet port by using a damp bottle brush or a damp cloth. Insert the brush or cloth
approximately 7 cm (2.75 inches) into the outlet opening while cleaning.
10
HomeCleaningInstructions:HeatedTubing
Clean the heated tubing before rst use and weekly. For multi-patient use, complete the steps in the “Hospital and
Institution Disinfection” section before each new user.
1. Disconnect the heated tubing from the heated humidier. Refer to the “Disconnecting the Optional Heated
Tubing” section earlier in this manual.
2. Gently wash the heated tubing, including the connectors, using a commercially available anionic detergent (e.g.
Medizyme) to adequately remove adhering substances from the tubing.
Note: Be sure to clean the entire inner surface of the tube by ensuring it is fully immersed in the detergent
solution during gentle agitation by hand.
Note: Be sure to thoroughly rinse all soap residue from the connectors and tube, and air dry before the next use.
3. Rinse with 3 gallons (11.4 liters) of water, and allow to air dry out of direct sunlight.
4. Visually inspect the tubing, including hte connectors, for cleanliness. Repeat the cleaning steps if not visually clean.
5. Inspect the heated tubing for damage or wear (cracking, crazing, tears, punctures, etc.). Discard and replace if
necessary.
HospitalandInstitutionDisinfection:WaterTankandHeatedTubing
If using the water tank and heated tubing on multiple users, complete the following steps to clean and disinfect the
water tank and heated tubing before each new user.
CAUTION: Only the hospital and institution cleaning and disinfection procedures listed in this manual are
recommended by Respironics. Use of other disinfection procedures cannot be guaranteed to maintain the
performance or durability of the product. Follow the manufacturer’s instructions of the disinfection procedures.
Cleaning Prior to Disinfection
Clean the water tank and heated tubing before disinfection. Refer to the “Home Cleaning Instructions: Water Tank”
and “Home Cleaning Instructions: Heated Tubing” sections.
Disinfection
The following processes can be used to disinfect the water tank and heated tubing for a maximum of 60 cycles:
• Thermal Disinfection: Immersion in a (tap) water bath at 75° C ± 2° C for 30 minutes
• Cidex
Note: Thoroughly rinse the Humidier Connector End with water and air dry before the next use.
• Cidex OPA
Note: Thoroughly rinse the Humidier Connector End with water and air dry before the next use.
CAUTION: Treat the water tank and heated tubing as different medical devices when rinsing them with water.
For example, the water tank and heated tubing cannot be rinsed in the same volume of water.
CAUTION: Use 3 gallons (11.4) liters as the rinse volume when following the instructions.
After Disinfection
1. Inspect the water tank and heated tubing for damage or wear (cracking, crazing, tears, punctures, etc). Discard and
replace if necessary.
2. After the nal water rinse described in the chemical disinfection instructions, separately rinse the water tank and
heated tubing a minimum of 1 time each in at least 3 gallons (11.4 liters) of water and air dry out of direct sunlight.
11
Service
The humidier does not require routine servicing. If any part of the humidier is worn or damaged, contact Philips
Respironics or your home care provider. See the “Troubleshooting” section in this manual for additional information.
TravelingwiththeSystem
Packing the System
1. Remove the water tank and empty all water.
2. Put the empty water tank back into the device.
3. Pack your humidier in your carry-on luggage.
CAUTION: Do not move the humidier while the water tank has water in it.
When you are traveling, the optional carrying case for your therapy device can be used for carry-on luggage only. The
carrying case will not protect the humidier if it is put through checked baggage.
For your convenience at airport security stations, there is a note on the bottom of the humidier stating that it is medical
equipment. It may be helpful to bring this manual along with you to help security personnel understand the device.
If you are traveling to a country with a line voltage different than the one you are currently using with the therapy
device, a different power cord or an international plug adapter may be required to make your power cord compatible
with those where you visit. Contact your home care provider for additional information.
Disposal
Dispose of this device in accordance with local regulations.
HowtoContactPhilipsRespironics
To have your device serviced, contact your home care provider. If you need to contact Philips Respironics directly,
call the Philips Respironics Customer Service department at 1-800-345-6443 or 1-724-387-4000. You can also use the
following address:
Respironics, Inc.
1001 Murry Ridge Lane
Murrysville, PA 15668
12
Troubleshooting
The table below lists some of the problems you may experience with your humidier and possible solutions.
problem Why it happeneD What to Do
Nothing happens when
you apply power to the
humidier.
High Leak The tubing is not
The humidier LED icon on
the therapy device is ashing.
Loss of AC/DC power or
the device is unplugged.
connected correctly and
doesn’t seal properly.
The therapy device is not
seated correctly against
the humidier.
The humidier tank is not
properly seated in the
humidier.
There is no communication
between the therapy
device and the humidier.
The therapy device is not
seated properly against the
humidier.
Using the wrong power
supply.
Verify that the humidier and therapy device are properly plugged in.
Make sure the AC power cord is connected correctly to the power
supply and the power supply cord is correctly plugged into the wall.
If the problem continues to occur, contact your home care provider.
Return the humidier, therapy device, and power supply to your
provider to determine if the problem is with the therapy device,
humidier, or power supply.
Remove your mask and tubing and check for kinks or tears. If it
is torn or damaged, contact your home care provider or Philips
Respironics for replacement tubing and/or mask.
If the tubing is not damaged, reattach your tubing, turn on the
airow, and check to make sure you do not still feel air coming out
of the port area.
Remove the therapy device from the humidier and reconnect. Make
sure the air inlet port on the humidier connects securely to the air
outlet port on the device.
If high leak persists, issue may be caused by a misaligned or damaged
seal. Seals are not user-serviceable components. Please contact your
home care provider or Philips Respironics.
Remove the water tank from the humidier base, and then slide the
tank back in the humidier, making sure it is pushed back as far as it
can go.
If high leak persists, issue may be caused by a misaligned or damaged
seal. Seals are not user-serviceable components. Please contact your
home care provider or Philips Respironics.
Following the “Daily Use” section earlier in this manual, check the
outlet power and verify that the humidier and therapy device are
properly plugged in. Make sure the AC power cord is connected
correctly to the therapy device’s power supply. Make sure the AC
power cord is correctly plugged into the wall.
If the problem continues to occur, contact your home care provider.
Return the humidier, therapy device, and power supply to your
provider, to determine if the problem is with the therapy device,
humidier, or power supply.
Remove the therapy device from the humidier and reconnect it.
Make sure the air inlet port on the side of the humidier connects
securely to the air outlet port on the side of the device.
If you are using the optional heated tubing, make sure you use the
correct 80W power supply.
The humidier is cracked or
damaged.
The therapy device is
operating but the humidier’s
airow is low or stopped.
Heated tubing is not
connected properly or is
damaged.
The heater plate is not
heating.
The humidier was
dropped or mishandled.
The humidier has an
airow obstruction.
Remove the heated tubing and check for damage. If it is not
damaged, reconnect the heated tubing. If the problem continues,
contact your home care provider.
Check the power connections to the humidier. If the problem
continues, contact your home care provider or Philips Respironics.
Note: If the water is not heating, you can temporarily use the
humidier as an unheated pass-over humidier.
If the humidier does not operate properly after being dropped or
mishandled, contact your home care provider or Philips Respironics.
Contact your home care provider. Return the humidier and power
supply to your provider to determine the problem.
13
problem Why it happeneD What to Do
The water tank’s middle seal
is damaged.
Excessive condensation in
the tubing.
Heated tube is not warming. Using the wrong power
The humidier door has
been accidentally removed
from the humidier.
The seal may become
damaged during use.
The humidity level setting
is too high.
The humidier is
positioned incorrectly.
supply.
Heated Tubing setting is set
to zero.
Humidier door was lifted
past the locked open
position.
Check the seal for any tears or other damage. If it is damaged,
contact your home care provider.
Reduce the humidity level setting.
Verify that the humidier and therapy device are away from air
conditioning equipment.
Make sure you use the correct 80W power supply. The correct
power supply should have the symbol.
Make sure the Heated Tubing setting is not set to zero. Refer to your
therapy device’s user manual for instructions.
The humidier door can be easily reattached.
With the water tank removed, align the hinge side of the door with
the back of the humidier in a fully open position (see gure below).
Make sure the hinges are aligned with the grooves of the humidier.
Rotate the door closed. You will need to apply pressure until the
door snaps past the locked open position. Verify that the door is
working properly.
If further assistance is needed, contact your home care provider.
The humidier has fallen off
your table or night stand.
The humidier may not
have been properly seated
on the night stand, or the
placement of the tubing
may have caused the device
to fall.
Always make sure your humidier is placed on a hard, at surface
so the rubber feet on the bottom of the humidier base can adhere
to the surface (make sure there is no fabric under the base). The
humidier must be level for proper operation.
Also, place the humidier away from the edge of the night stand or
table, so it doesn’t accidentally get knocked off the table.
If the humidier falls and water gets into the therapy device, drain all
water out of the therapy device. Allow it to air dry to make sure it is
completely dry before reapplying power.
If the placement of the tubing causes the humidier to fall, make sure
that you use proper hose management when setting up your device.
Route the tubing behind the bed’s headboard.
If the humidier does not operate correctly after falling, contact your
home care provider or Philips Respironics.
Note: For information on troubleshooting your therapy device, see the manual included with your therapy device.
14
SystemOneHeatedHumidierSpecications
Environmental
Operating Temperature: 5° to 35° C (41° to 95° F)
Storage Temperature: -20° to 60° C (-4° to 140° F)
Relative Humidity (operating & storage): 15 to 95% (non-condensing)
Atmospheric Pressure: 77 to 101 kPa (0 - 2286 m / 0 - 7500 ft)
Physical
Dimensions: 18 x 14 x 10 cm (7” L x 5.5” W x 4” H)
Weight: Approximately 0.89 kg (1.95 lbs.)
WaterCapacity
325 ml (11 oz.) at recommended water level
StandardsComplianceThis device is designed to conform to the following standards:
IEC 60601-1 General Requirements for Safety of Medical Electrical Equipment
EN ISO 8185 General Requirements for Humidication Systems
Electrical (When the heated humidier is used with a Philips Respironics therapy device)
AC Power Consumption (with 60W power supply): 100 – 240 VAC, 50/60 Hz, 2.1 A
AC Power Consumption (with 80W power supply): 100 – 240 VAC, 50/60 Hz, 2.0 A
DC Power Consumption: 12 VDC, 6.67 A
Type of Protection Against Electric Shock: Class II Equipment
Degree of Protection Against Electric Shock: Type BF Applied Part
Degree of Protection against Ingress of Water: Drip Proof, IP22
Mode of Operation: Continuous
Electromagnetic Compatibility: The device meets the requirements of EN 60601-1-2, 2nd edition.
HeaterPlate
Max Temperature: 75° C (167° F)
PressureDropwithHumidier
Max.: 0.3 cm H2O at 60 LPM ow
Humidity
Humidity
Measured @ max ow, 35° C, 15% RH.
Output: 10 mg H2O/L
min
15
HeatedTubingSpecications
Maximum Recommended Pressure
25 cm H2O
InnerDiameter
15 mm (0.6 in.)
Length
1.83 m (6 ft.)
HeatedTubingTemperatureRange
16° to 32º C (60° to 89° F)
HeatedTubingTemperatureCut-out
≤ 41° C (≤ 106° F)
Material
Flexible plastic and electrical components
Electrical (Heated tubing is powered by the attached heated humidier)
Refer to “Electrical” section of System One Heated Humidier Specications
Environmental
Refer to “Environmental” section of System One Heated Humidier Specications
16
Limited Warranty
Respironics, Inc. warrants that the system shall be free from defects of workmanship and materials and will perform in
accordance with the product specications for a period of two (2) years from the date of sale by Respironics, Inc. to
the dealer. If the product fails to perform in accordance with the product specications, Respironics, Inc. will repair
or replace – at its option – the defective material or part. Respironics, Inc. will pay customary freight charges from
Respironics, Inc. to the dealer location only. This warranty does not cover damage caused by accident, misuse, abuse,
alteration, water ingress, and other defects not related to material or workmanship. The Respironics, Inc. Service
department shall examine any devices returned for service, and Respironics, Inc. reserves the right to charge an
evaluation fee for any returned device as to which no problem is found after investigation by Respironics, Inc. Service.
This warranty is non-transferable by unauthorized distributors of Respironics, Inc. products and reserves the right
to charge dealers for warranty service of failed product not purchased directly from Respironics, Inc. or authorized
distributors.
Respironics, Inc. disclaims all liability for economic loss, loss of prots, overhead, or consequential damages which
may be claimed to arise from any sale or use of this product. Some states do not allow the exclusion or limitation of
incidental or consequential damages, so the above limitation or exclusion may not apply to you.
This warranty is given in lieu of all other express warranties. In addition, any implied warranties – including any
warranty of merchantability or tness for the particular purpose – are limited to two years. Some states do not allow
limitations on how long an implied warranty lasts, so the above limitation may not apply to you. This warranty gives
you specic legal rights, and you may also have other rights which vary from state to state.
To exercise your rights under this warranty, contact your local authorized Respironics, Inc. dealer or contact
Respironics, Inc. at:
1001 Murry Ridge Lane
Murrysville, Pennsylvania 15668-8550
1-724-387-4000
1095653
1095419 R03
HM 4/19/2016
EN-DOM
Loading...
