PHILIPS SW9700 User Manual [nl]

© & ™ Lucaslm Ltd.
© Disney

SW9700

2

1

4

3

6

5

7

8

9

10

11

12

13

14

15

empty page before TOC

English 6

简体中文

27

English

6

Introduction

Congratulations on your purchase and welcome to
Philips! To fully benefit from the support that
Philips offers, register your product at
www.philips.com/welcome.

Please read this user manual, as it contains
information about the features of this shaver as
well as some tips to make shaving easier and more
enjoyable.

General description (Fig. 1)

1 Click-on precision trimmer attachment
2 Shaving unit with hair chamber
3 On/off button
4 Personal comfort settings decrease button
5 Personal comfort settings increase button
6 Personal comfort settings bar
7 Notification symbol
8 Cleaning reminder
9 Battery charge indicator
10 Travel lock symbol
11 Replacement reminder
12 Socket for small plug
13 Pouch
14 Small plug
15 Supply unit

Important safety information

Read this important information carefully before
you use the appliance and its accessories and
save it for future reference. The accessories
supplied may vary for different products.

English

Danger

Warning

English

- Keep the supply unit dry.

- To charge the battery, only use the detachable
supply unit (HQ8505) provided with the
appliance.

- The supply unit contains a transformer. Do not
cut off the supply unit to replace it with another
plug, as this causes a hazardous situation.

- This appliance can be used by children aged
from 8 years and above and persons with
reduced physical, sensory or mental capabilities
or lack of experience and knowledge if they
have been given supervision or instruction
concerning use of the appliance in a safe way
and understand the hazards involved. Children
shall not play with the appliance. Cleaning and
user maintenance shall not be made by
children without supervision.

- Always unplug the shaver before you clean it
under the tap.

- Always check the appliance before you use it.
Do not use the appliance if it is damaged, as
this may cause injury. Always replace a
damaged part with one of the original type.

- Do not open the appliance to replace the
rechargeable battery.

7

English

8

Caution

- Never immerse the cleaning system or the
charging stand in water and do not rinse it
under the tap.

- Never use water hotter than 60°C to rinse the
shaver.

- Only use this appliance for its intended purpose
as shown in the user manual.

- For hygienic reasons, the appliance should only
be used by one person.

- Never use compressed air, scouring pads,
abrasive cleaning agents or aggressive liquids
such as petrol or acetone to clean the
appliance.

- If your shaver comes with a cleaning system,
always use the original Philips cleaning fluid
(cartridge or bottle, depending on the type of
cleaning system).

- Always place the cleaning system on a stable,
level and horizontal surface to prevent leakage.

- If your cleaning system uses a cleaning
cartridge, always make sure the cartridge
compartment is closed before you use the
cleaning system to clean or charge the shaver.

- When the cleaning system is ready for use, do
not move it to prevent leakage of cleaning fluid.

- Water may drip from the socket at the bottom
of the shaver when you rinse it. This is normal
and not dangerous because all electronics are
enclosed in a sealed power unit inside the
shaver.

- Do not use the supply unit in or near wall
sockets that contain an electric air freshener to
prevent irreparable damage to the supply unit.

Electromagnetic fields (EMF)

- This Philips appliance complies with all
applicable standards and regulations regarding
exposure to electromagnetic fields.

General

- This shaver is waterproof. It is suitable for use in
the bath or shower and for cleaning under the
tap. For safety reasons, the shaver can
therefore only be used without cord.

- The supply unit is suitable for mains voltages
ranging from 100 to 240 volts.

- The supply unit transforms 100-240 volts to a
safe low voltage of less than 24 volts.

The display

Note: Remove any sticker or protective foil from
the display before using the product.

Start-up sequence

When you press the on/off button for the very first
time, all display indications light up in sequence.

The shaver now contains enough energy for one
shave.

Charging

Quick charge: When the battery is empty and you
connect the shaver to the wall socket, the lights of
the battery charge indicator light up red one after
the other repeatedly. When the battery contains
enough energy for one shave, the bottom light of
the battery charge indicator starts flashing red
slowly.

English

9

English

10

While the shaver continues to charge, first the
bottom light of the battery charge indicator flashes
red and then lights up red continuously. Then the
second light flashes and lights up continuously,
and so on until the shaver is fully charged.

Battery fully charged

Note: This shaver can only be used without a cord.

When the battery is fully charged, all lights of the
battery charge indicator light up red continuously.

Note: When you press the on/off button during or
after charging, you hear a sound to indicate that
the shaver is still connected to the wall socket.

Note: When the battery is full, the display switches
off automatically after 30 minutes.

Battery low

When the battery is almost empty, the bottom light
of the battery charge indicator flashes red.

Remaining battery charge

The remaining battery charge is shown by the
lights of the battery charge indicator that light up
continuously.

Personal comfort settings

The shaver has a feature that allows you to
personalize your settings. Depending on your
personal shaving needs, choose between three
settings, from low to high: comfort, dynamic or
efficiency. When you press the button on the left
or right of the display, the segment of the personal
comfort settings bar that lights up shows the
currently selected setting. To select a lower or
higher setting, press the button on the left or right
of the display.

Cleaning reminder

Clean the shaver after every shave for optimal
performance (see 'Cleaning and maintenance').
When you switch off the shaver, the cleaning
reminder flashes to remind you to clean the
shaver.

Travel lock

You can lock the shaver when you are going to
travel. The travel lock prevents the shaver from
being switched on by accident (see 'Activating the
travel lock').

English

11

Replacement reminder

For maximum shaving performance, replace the
shaving heads every two years. The shaver is
equipped with a replacement reminder which
reminds you to replace the shaving heads. The
replacement reminder lights up and the arrows
flash to indicate that you have to replace the
shaving heads (see 'Replacing the shaving heads').

English

12

Note: After replacing the shaving heads, you need
to reset the replacement reminder by pressing the
on/off button for 7 seconds.

Notification symbol

Overheating

If the shaver overheats during charging, the
notification symbol flashes. When this happens,
the shaver switches off automatically. Charging
continues once the temperature of the shaver has
decreased to the normal level.

Blocked shaving heads

If the shaving heads are blocked, the notification
symbol flashes and the shaver beeps. Clean the
shaver thoroughly before you continue to shave
(see 'Cleaning the shaver under the tap'). After
cleaning, if the notification symbol flashes and the
shaver beeps, immediately replace the shaving
heads.

Charging

Charge the shaver before you use it for the first
time and when the display indicates that the
battery is almost empty.

Charging takes approx. 1 hour. A fully charged
shaver has a shaving time of up to 60 minutes.

Note: You cannot use the shaver while it is
charging.

Charging with the supply unit

1 Make sure the shaver is switched off.

2 Put the small plug in the shaver and put the

supply unit in the wall socket.

The display of the shaver indicates that the
shaver is charging.

3 After charging, remove the supply unit from the

wall socket and pull the small plug out of the
shaver.

Using the shaver

Always check the shaver and all accessories
before using. Do not use the shaver or any
accessory if it is damaged, as this may cause
injury. Always replace a damaged part with one
of the original type.

This symbol indicates that the shaver can be used
in the bath or shower.

- Use this shaver for its intended household use
as described in this manual.

- For hygienic reasons, the shaver should only be
used by one person.

- Trimming is easier when the skin and hair are
dry.

Note: This shaver can only be used without a cord.

Switching the shaver on and off

1 To switch on the shaver, press the on/off

button once.

English

13

English

14

Shaving

The battery charge indicator lights up for a few
seconds and the notification symbol flashes.

2 To switch off the shaver, press the on/off

button once.

The battery charge indicator lights up for a few
seconds and shows the remaining battery
charge.

Skin adaptation period

Your first shaves may not bring you the result you
expect and your skin may even become slightly
irritated. This is normal. Your skin and beard need
time to adapt to any new shaving system. To allow
your skin to adapt to this new appliance, we advise
you to shave regularly (at least 3 times a week)
and exclusively with this appliance for a period of
3 weeks.

Shaving tips

For the best results on skin comfort, pre-trim your
beard if you have not shaved for 3 days or longer.

Select your personal comfort setting (see 'Personal
comfort settings').

Dry shaving

1 Switch the shaver on.
2 Move the shaving heads over your skin in both

straight and circular movements to catch all
hairs growing in different directions. Exert
gentle pressure for a close comfortable shave.

Note: Do not press too hard, this can cause skin
irritation.

3 Switch off and clean the shaver after each use.

English

The display lights up for a few seconds to show
the battery status.

Wet shaving

For a more comfortable shave, you can also use
this shaver on a wet face with shaving foam or
shaving gel.

1 Apply some water to your skin.

2 Apply shaving foam or shaving gel to your skin.

3 Rinse the shaving unit under the tap to ensure

that the shaving unit glides smoothly over your
skin.

4 Switch the shaver on.

5 Move the shaving heads over your skin in

circular movements to catch all hairs growing in
different directions. Exert gentle pressure for a
close, comfortable shave.

Note: Do not press too hard, this can cause skin
irritation.

Note: Rinse the shaving unit regularly to ensure
that it continues to glide smoothly over your
skin.

6 Dry your face.

15

English

16

7 Switch off the shaver and clean it after each

use.

Note: Make sure that you rinse all foam or shaving
gel off the shaver.

Using the click-on attachment

Removing or attaching the click-on attachment

1 Make sure the shaver is switched off.
2 Pull the attachment straight off the shaver.

Note: Do not twist the attachment while you
pull it off the shaver.

3 Insert the lug of the attachment into the slot in

the top of the shaver. Then press down the
attachment to attach it to the shaver(‘click’).

Using the precision trimmer attachment

You can use the trimmer to groom your beard,
sideburns and moustache.

1 Attach the trimmer to the shaver ('click').
2 Switch on the shaver.

3 sec.

3 Hold the trimmer perpendicular to the skin and

move it downwards while exerting gentle
pressure.

4 Clean the trimmer after use.

Travel lock

You can lock the shaver when you are going to
travel. The travel lock prevents the shaver from
being switched on by accident.

Activating the travel lock

1 Press the on/off button for 3 seconds to enter

the travel lock mode.

2 While you activate the travel lock, the

indications on the display light up briefly and
the shaver produces a short sound. When the
travel lock is activated, the travel lock symbol
flashes.

Deactivating the travel lock

1 Press the on/off button for 3 seconds.

- While you deactivate the travel lock, the
indications on the display light up briefly. When
the travel lock is deactivated, the travel lock
symbol flashes and the shaver switches on. The
shaver is now ready for use again.

Note: The shaver unlocks automatically when it is
connected to wall socket.

English

17

English

18

Cleaning and maintenance

- Regular cleaning guarantees better shaving
results.

- Never clean, remove or replace the shaving unit
while the shaver is switched on.

- Do not apply pressure to shaving head combs.

- Do not touch shaving heads with hard objects
as this may dent or damage the precision-made
slotted combs.

- Do not use abrasives, scourers or aggressive
liquids such as gasoline or acetone to clean the
shaver.

Cleaning the shaver under the tap

Clean the shaver after every shave for optimal
performance.

Always check if the water is too hot, to prevent
burning your hands.

Never dry the shaving unit with a towel or tissue,
as this may damage the shaving heads.

While rinsing the shaving unit, water may drip
out of the base of shaver. This is a normal
occurrence.

1 Switch the shaver on.
2 Rinse the shaving unit under a warm tap.

3 Switch the shaver off. Pull the shaving head

holder off the bottom part of the shaving unit.

4 Rinse the hair chamber under the tap.

5 Rinse the shaving head holder under a warm

tap.

6 Carefully shake off excess water and let the

shaving head holder air dry completely.

7 Attach the shaving head holder to the bottom

part of the shaving unit (‘click’).

Cleaning the precision trimmer attachment

Never dry the trimmer with a towel or tissue, as
this may damage the trimming teeth.

Clean the trimmer after each use.

1 Switch the shaver on.
2 Rinse the trimmer under a warm tap.
3 After cleaning, switch off the shaver.
4 Carefully shake off excess water and let the

attachment air dry completely.

English

19

1

2

English

20

Tip: For optimal performance, lubricate the
teeth of the attachment with a drop of sewing
machine oil regularly.

Replacement

Replacing the shaving heads

For maximum shaving performance, we advise you
to replace the shaving heads every two years.
Replace damaged shaving heads immediately.
Always replace the shaving heads with original
Philips shaving heads (see 'Ordering accessories').

Replacement reminder

The replacement reminder indicates that the
shaving heads need to be replaced. The
replacement reminder lights up and the arrows
flash when you switch the shaver off.

1 Switch the shaver off.

2 Pull the shaving head holder off the bottom

part of the shaving unit.

3 Turn the retaining ring anticlockwise and lift it

off the shaving head.

Repeat this process for the other retaining rings.
Place them aside in a safe place.

2

1

1

English

4 Remove the shaving heads from the shaving

head holder.

Discard the used shaving heads immediately to
avoid mixing them with the new shaving heads.

5 Place the new shaving heads in the shaving

head holder.
Note: Make sure the notches on both sides of

the shaving heads fit exactly onto the
projections in the shaving head holder.

6 Place the retaining ring on the shaving head

and turn it clockwise to reattach the retaining
ring. Repeat this process for the other retaining
rings

- Each retaining ring has two recesses that fit
exactly around the projections of the shaving
head holder. Turn the ring clockwise until you
hear a click to indicate that the ring is fixed.

Note: Hold the shaving head holder in your
hand when you reinsert the shaving heads and
reattach the retaining rings. Do not place the
shaving head holder on a surface, as this may
cause damage to the shaving heads.

21

7 sec.

English

22

7 Attach the shaving head holder to the bottom

part of the shaving unit (‘click’).

8 To reset the replacement reminder, press and

hold the on/off button for approx. 7 seconds.

Storage

Store the shaver in the pouch.
Note: Always let the shaver dry completely before

you store it in the pouch.

Ordering accessories

To buy accessories or spare parts, visit
www.shop.philips.com/service or go to your
Philips dealer. You can also contact the Philips
Consumer Care Center in your country (see the
international warranty leaflet for contact details).

The following accessories and spare parts are
available:

- SH90 Philips shaving heads

- HQ110 Philips shaving head cleaning spray

- RQ111 Philips beard styler attachment

- RQ585 Philips cleansing brush attachment

- RQ560/RQ563 Philips cleansing brush heads

- HQ8505 supply unit

English

Note: The availability of the accessories may differ
by country.

Recycling

- Do not throw away the product with the normal
household waste at the end of its life, but hand
it in at an official collection point for recycling.
By doing this, you help to preserve the
environment.

- This product contains a built-in rechargeable
battery which shall not be disposed of with
normal household waste. We strongly advise
you to take your product to an official collection
point or a Philips service centre to have a
professional remove the rechargeable battery.

- Follow your country’s rules for the separate
collection of electrical and electronic products
and rechargeable batteries. Correct disposal
helps prevent negative consequences for the
environment and human health.

Removing the rechargeable shaver battery

Only remove the rechargeable battery
when you discard the shaver. Before you
remove the battery, make sure that the
shaver is disconnected from the wall socket
and that the battery is completely empty.

Take any necessary safety precautions
when you handle tools to open the shaver
and when you dispose of the rechargeable
battery.

Be careful, the battery strips are sharp.

1 Insert the screwdriver into the slot between the

front and back panel in the bottom of the
appliance. Remove the back panel.

2 Remove the front panel.

23

English

24

3 Unscrew the two screws at the top of the inner

panel and remove the inner panel.

4 Remove the rechargeable battery with a

screwdriver.

Warranty and support

If you need information or support, please visit
www.philips.com/support or read the
international warranty leaflet.

Warranty restrictions

The shaving heads (cutters and guards) are not
covered by the terms of the international warranty
because they are subject to wear.

Troubleshooting

Shaver

Problem Possible cause Solution

The appliance
does not work
when I press the
on/off button.

The rechargeable

The travel lock is

The appliance is still
attached to the wall
socket. For safety
reasons, the
appliance can only
be used without
cord.

battery is empty.

activated.

Unplug the appliance and
press the on/off button to
switch on the appliance.

Recharge the battery (see
'Charging').

Press the on/off button for
3 seconds to deactivate the
travel lock.

English

Problem Possible cause Solution

The shaving unit is
soiled or damaged
to such an extent
that the motor
cannot run.

The appli
ance does not
shave as well as
it used to.

Hairs or dirt obstruct

To clean the shaving heads

I replaced the
shaving heads,
but the display
still shows the
replacement
reminder.

The shaving heads
are damaged or
worn.

the shaving heads.

You have not reset
the appliance.

Clean the shaving heads
thoroughly or replace
them. Also see 'Hairs or dirt
obstruct the shaving heads'
for a detailed description of
how to clean the shaving
heads thoroughly.

Replace the shaving heads
(see 'Replacement').

Clean the shaving heads in
the regular way or clean
them thoroughly.

thoroughly, remove the
shaving heads from the
shaving head holder one
by one (see
'Replacement'). Then
separate the cutter from its
guard and rinse each
matching set under the tap.
After rinsing, place the
cutter back into its
corresponding guard.
Finally, put the shaving
heads back into the
shaving head holder (see
'Replacement').

Reset the appliance by
pressing the on/off button
for approx. 7 seconds.

25

English

26

Problem Possible cause Solution

A shaving unit
symbol has
suddenly
appeared on the
display.

The notification
symbol flashes
and the shaver
beeps while the
shaver is
charging.

The notification
symbol flashes
and the shaver
beeps when I try
to shave.

The notification
symbol flashes
and the shaver
beeps after
cleaning the
shaving heads.

Water is leaking
from the bottom
of the appliance.

This symbol
reminds you to
replace the shaving
heads.

The appliance is
overheated.

The shaving heads
are soiled.

The shaving heads
are damaged.

During cleaning,
water may collect
between the inner
body and the outer
shell of the
appliance.

Replace the shaving heads
(see 'Replacement').

Disconnect the appliance
from the wall socket for
approx. 10 minutes.

Clean the shaving heads.
Also see 'Hairs or dirt
obstruct the shaving heads'
for a detailed description of
how to clean the shaving
heads thoroughly.

Replace the shaving heads
(see 'Replacement').

This is normal and not
dangerous because all
electronics are enclosed in
a sealed power unit inside
the appliance.

介绍

感谢您的惠顾，欢迎光临飞利浦！ 为了让您能充分享
受飞利浦提供的支持，请在 www.philips.com/welcome

上注册您的产品。
请阅读本用户手册，手册包含有关此剃须刀各种功能的

信息以及一些使用技巧，让您的剃须体验更轻松更舒
适。

基本说明（图 1）

1 卡入式精确修剪器附件
2 剃须刀头部件及胡茬储藏室
3 开/关按钮
4 个人舒适度设置降低按钮
5 个人舒适度设置提高按钮
6 个人舒适度设置栏
7 通知符号
8 清洗提示
9 电池充电指示灯
10 旅行锁符号
11 更换提示
12 小插头插口
13 存储袋
14 小插头
15 电源部件

重要安全信息

使用本产品及其附件之前，请仔细阅读本重要信息，并
妥善保管以供日后参考。 随附的附件可能因产品而
异。

危险

- 保持电源部件干燥。

- 警告符号注释： 禁止在打开的水龙头下进行清洗。

简体中文

27

简体中文

28

警告

警告

简体中文

- 要给电池充电，请仅使用产品随附的可拆卸电源部
件 (HQ8505)。

- 电源部件中包含一个变压器。 请勿自行更换电源部
件的插头，否则将导致严重后果。

- 本产品也可以由 8 岁或以上年龄的儿童以及肢体不
健全、感觉或精神上有障碍或缺乏相关经验和知识
的人士使用，但前提是有人对他们使用本产品进行
监督或指导，以确保他们安全使用，并且让他们明
白相关的危害。 切勿让儿童玩弄本产品。 不要让儿
童在无人监督的情况下对本产品进行清洁和保养。

- 将剃须刀手持部分与电源软线分开后，才能在水龙
头下清洗手持部分。

- 使用前，请务必检查产品。 请勿使用损坏的产品，
否则可能对人体造成伤害。 请务必用原装型号更换
损坏的部件。

- 切勿拆开本产品更换充电电池。

- 切勿将清洁系统或充电座浸入水中，也不要在水龙
头下冲洗。

- 警告符号注释： 禁止在打开的水龙头下进行清洗

- 切勿使用温度高于 60°C 的热水冲洗剃须刀。

- 只能将本产品用于用户手册中所示的原定用途。

- 出于卫生的目的，本产品只能供一个人使用。

- 切勿使用压缩气体、钢丝绒、研磨性清洁剂或腐蚀
性液体（例如汽油或丙酮）来清洁产品。

- 如果剃须刀随附清洁系统，应始终使用原装飞利浦
清洁液（滤芯或瓶，取决于清洁系统类型）。

- 清洁系统必须放在稳定、平坦的水平表面上，以防
漏液。

- 如果清洁系统采用清洁滤芯，在使用清洁系统进行
清洁或为剃须刀充电之前，应始终确保滤芯仓已关
闭。

- 清洁系统准备就绪时，切勿移动，以免清洁液漏
出。

电磁场 (EMF)

概述

显示屏

启动顺序

简体中文

- 冲洗剃须刀时，水可能从产品底部的插口漏出。 这
是正常的，而且没有危险，因为所有电子元件都封
闭在剃须刀内部的密封电源部件中。

- 请勿在包含电动空气清新器的墙壁插座上或其周围
使用电源部件，以免电源部件受到不可修复的损
坏。

- 本 Philips 产品符合所有有关暴露于电磁场的适用标
准和法规。

- 符号注释：适合于在洗澡或淋浴时使用。 允许在盛
水的浴缸、淋浴、洗脸盆或其他器皿附近使用本器
具。

- 该剃须刀具有防水性能。 适合在沐浴或淋浴时使
用，也可以放在水龙头下清洗。 出于安全原因，该
剃须刀在使用时不能连接电线。

- 电源部件适合在 100 - 240 伏的电源电压下工作。

- 该电源部件可将 100-240 伏的电压转换为 24 伏以
下的安全低电压。

注意： 使用本产品前，请先取下显示屏上的任何不干
胶标签或保护膜。

当您第一次按下开/关按钮时，所有指示灯依次亮起。
剃须刀现在所含的电量足以完成一次剃须。

29

充电

快速充电： 电池电量耗尽后，当您将剃须刀连接到电
源插座时，电池充电指示灯将逐个呈红色亮起并重复循

简体中文

30

电池已完全充满

电池电量不足

环。 如果剃须刀电池所含的电量足够完成一次剃须，
则底部的电池充电指示灯会开始呈红色缓慢闪烁。

剃须刀持续充电时，底部的电池充电指示灯先是闪烁红
色，然后会持续亮起红色。 然后，第二个指示灯闪
烁，之后持续亮起，以此类推，直至剃须刀充满电。

注意： 本剃须刀只能在不接电源的情况下使用。
电池充满电后，所有电池充电指示灯将呈红色持续亮

起。
注意： 在充电期间或之后按下开/关按钮时，您将听到

声音，表示剃须刀仍然连接到电源插座。
注意： 电池充满电后，显示屏会在 30 分钟后自动关

闭。

当电池电量几乎耗尽时，电池充电指示灯的底灯会呈红
色闪烁。

电池剩余电量

剩余的电池电量由持续亮起的充电指示灯来表示。

个人舒适度设置

清洗提示

旅行锁

更换提示

通知符号

简体中文

剃须刀提供进行个性化设置的功能。 您可以根据个人
的剃须需要，从三种设置（由低至高）中进行选择：
舒适、强劲或高效。 当您按下显示屏左侧或右侧的按
钮时，个人舒适度设置栏上亮起的部分会显示当前选择
的设置。 如需选择较低或较高设置，请按下显示屏左
侧或右侧按钮。

每次剃须后请清洁剃须刀，以获得出色性能 (请参见
'清洁和保养')。关闭剃须刀时，清洗提示符号闪烁，提
醒您需要清洁剃须刀。

您可以在携带剃须刀旅行之前将其锁住。 旅行锁可防
止剃须刀被意外 (请参见 '启用旅行锁')打开。

要获得最佳的剃须效果，请每两年更换一次剃须刀头。
剃须刀配有更换提示符号，它会提醒您更换剃须刀头。
更换指示灯亮起且箭头闪烁，这表示需要更换剃须刀头
(请参见 '更换剃须刀头')。

注意： 更换剃须刀头后，您需要通过按开/关按钮 7 秒
来重置更换提醒。

31

过热

简体中文

32

如果剃须刀在充电期间过热，通知符号会闪烁。 在这
种情况下，剃须刀会自动关闭。 一旦剃须刀温度降至
正常水平，将继续充电。

剃须刀头被阻塞

如果剃须刀头被阻塞，则通知符号会闪烁且剃须刀会发
出提示音。 请在继续剃须 (请参见 '在水龙头下冲洗剃
须刀')前彻底清洗剃须刀。 清洗后，如果通知符号闪烁
且剃须刀发出提示音，则请立即更换剃须刀头。

充电

首次使用剃须刀之前，或当显示屏指示电池电量几乎耗
尽时，请先为剃须刀充电。

充电约需 1 小时。 充满电的剃须刀最长剃须时间可达
60 分钟。

注意： 切勿在充电时使用剃须刀。

使用电源部件充电

1 确保剃须刀已关闭。
2 将小插头插入剃须刀，然后将电源部件插入电源插

3 充电之后，从电源插座上拔下电源部件，并从剃须

座。
剃须刀显示屏将显示剃须刀正在充电。

刀上拔下小插头。

使用剃须刀

使用前务必要检查剃须刀和所有配件。 如果剃须刀或
任何配件损坏，请勿再使用，否则可能对人体造成伤
害。 请务必用原装型号更换损坏的部件。

此标志表示该剃须刀可在沐浴或淋浴时使用。

- 请按照本用户手册中所述的预期家用用途使用本剃

- 出于卫生考虑，请勿共用剃须刀。

- 皮肤和毛发干燥时修剪更容易。

注意： 本剃须刀只能在不接电源的情况下使用。

打开或关闭剃须刀

1 要打开剃须刀，请按一下开/关按钮。

2 要关闭剃须刀，请按一下开/关按钮。

剃须

皮肤适应期

前几次剃须可能不会带给您预期效果，并且您的皮肤可
能会受到轻度刺激。 这是正常的。 您的皮肤和胡须需
要时间适应任何新的剃须系统。 为了让您的皮肤适应
这款新产品，我们建议您在 3 周时间内定期（至少每
周 3 次）仅使用本产品剃须。

剃须提示

如果您连续 3 天或更长时间没有剃须，为确保皮肤获
得最佳舒适感，请预先修剪胡须。

选择您的个人舒适度设置 (请参见 '个人舒适度设置')。

干剃

1 打开剃须刀。

简体中文

须刀。

电池充电指示灯亮起几秒钟且通知符号闪烁。

电池充电指示灯亮起几秒钟并显示剩余电池电量。

33

34

简体中文

2 让剃须刀头在您的皮肤上作直线和迂回运动，以刮

剃向不同方向生长的所有须发。 轻轻按压，以获取
舒适贴面的剃须感受。

注意： 不要用力按压剃须刀，这样做可能会导致皮
肤受刺激。

3 每次使用后，请关闭并清洗剃须刀。

显示屏将亮起几秒钟时间，以显示电池状态。

湿剃

要获得更舒适的剃须体验，您也可以先用剃须泡沫或剃
须啫喱对脸部进行湿润，然后再使用剃须刀。

1 用水润湿皮肤。

2 在皮肤上涂抹剃须泡沫或剃须啫喱。

3 在水龙头下冲洗一下剃须刀头部件，确保剃须刀头

部件可以在您的皮肤上顺畅滑动。

4 打开剃须刀。

5 让剃须刀头在您的皮肤上作迂回运动，以刮剃向不

同方向生长的所有须发。 轻轻按压，以获取舒适贴
面的剃须感受。

注意： 不要用力按压剃须刀，这样做可能会导致皮
肤受刺激。

注意： 定期冲洗剃须刀头部件，确保其能够继续在
您的皮肤上顺畅滑动。

6 擦干面部。
7 每次使用后，请关闭并清洗剃须刀。
注意： 确保冲净剃须刀上的所有泡沫或剃须啫喱。

使用卡入式附件

拆卸或安装卡入式附件

1 确保剃须刀已关闭。
2 将附件竖直抽出剃须刀。

注意： 将附件从剃须刀上抽出时，不要旋转。

3 将附件的凸缘插入本剃须刀顶部的槽内。 然后，按

下附件将其安装到本剃须刀上（可听到“咔哒”一
声）。

使用精确修剪器附件

您可以使用修剪器修剪胡须、鬓角和须髭。
1 将修剪器安装到剃须刀上（听到“咔哒”一声）。
2 打开剃须刀。

简体中文

35

3 sec.

简体中文

36

旅行锁

启用旅行锁

3 将修剪器垂直放在皮肤上，向下移动产品，同时轻

轻按压。

4 使用后请清洗修剪器。

您可以在携带剃须刀旅行之前将其锁住。 旅行锁可防
止剃须刀被意外打开。

1 按住开/关按钮 3 秒钟以进入旅行锁模式。

2 启用旅行锁后，显示屏上的指示灯会短暂亮起且剃

须刀会发出短促声音。 旅行锁启用后，旅行锁符号
将闪烁。

解除旅行锁

清洁和保养

1 按开/关按钮 3 秒钟。

- 当您解除旅行锁时，显示屏上的指示灯会短暂亮
起。 旅行锁禁用后，旅行锁符号将闪烁且会打开剃
须刀。 现在可以重新开始使用剃须刀。

注意： 当连接到电源插座时，剃须刀会自动解锁。

- 为保证更好的剃须效果，请定期清洗剃须刀。

- 切勿在剃须刀开启时清洗、拆除或更换剃须刀头部
件。

- 请勿对剃须刀头梳齿施加压力。

- 请勿使用硬物触碰剃须刀头，以免挫伤或损坏制作
精密的带槽梳齿。

- 切勿使用研磨剂、硬毛刷或汽油或丙酮等腐蚀性液
体清洗本剃须刀。

在水龙头下冲洗剃须刀

每次剃须后请清洁剃须刀，以获得出色性能。

切记先检查水温是否太高，以防烫手。
不要用毛巾或纸巾擦拭剃须刀头部件，因为这样可能会

损坏剃须刀头。
冲洗剃须刀头部件时，水可能会从剃须刀底座中滴出。

这属于正常现象。

1 打开剃须刀。
2 用温水冲洗剃须刀头部件。

3 关闭剃须刀。 将剃须刀头支架从剃须刀头部件的底

部抽离。

简体中文

37

4 在水龙头下冲洗胡茬储藏室。

简体中文

38

5 用温水冲洗剃须刀头支架。
6 小心地甩掉多余水分并彻底晾干剃须刀头支架。

7 将剃须刀头支架安装到剃须刀头部件的底部（可听

清洁精确修剪器附件

切勿用毛巾或纸巾擦干修剪器，否则可能会损坏修剪
齿。

每次使用后都应清洁修剪器。
1 打开剃须刀。
2 在热水龙头下冲洗修剪器。
3 清洁完成后，关闭剃须刀。
4 小心地甩掉多余水分并彻底晾干附件。

到“咔哒”一声）。

提示： 为达到最佳效果，请定期用一滴缝纫机油润
滑附件齿部。

更换

更换剃须刀头

为获得最佳剃须效果，建议每两年更换一次剃须刀头。
立即更换损坏的剃须刀头。 务必使用原装飞利浦剃须
刀头 (请参见 '订购配件')进行更换。
更换提示

1

2

简体中文

出现更换提示表示需要更换剃须刀头。 关闭剃须刀
时，更换指示灯会亮起且箭头会闪烁。

1 关闭剃须刀。

2 将剃须刀头支架从剃须刀头部件的底部抽离。

3 逆时针转动固定环，然后将它从剃须刀头中取出。

对其他固定环重复此过程。 将其存放在安全的地
方。

4 从剃须刀头支架上卸下剃须刀头。

立即丢弃用过的剃须刀头，以免与新的剃须刀头混
淆。

5 将新的剃须刀头装到剃须刀头支架中。

注意： 确保剃须刀头两侧的槽口正好卡入剃须刀头
支架上的凸起部位。

39

2

1

1

7 sec.

40

简体中文

6 将固定环放在剃须刀头上，顺时针旋转以重新安装

固定环。 对其他固定环重复此过程

- 每个固定环均具有两个凹槽，正好与剃须刀头支架
的凸缘精准啮合。 顺时针旋转固定环，直至听
到“咔哒”一声，表明固定环已就位。

注意： 当您重新插入剃须刀头并重新安装固定环
时，请将剃须刀头支架握在手中。 切勿将剃须刀头
支架放在平面上，否则可能会损坏剃须刀头。

7 将剃须刀头支架安装到剃须刀头部件的底部（可听

到“咔哒”一声）。

8 要重置更换提醒，请按住开/关按钮约 7 秒钟。

存放

订购配件

回收

简体中文

将剃须刀存放在存储袋中。
注意： 务必确保剃须刀彻底干燥，然后再将其存放在

存储袋中。

要购买附件或备件，请访问
www.shop.philips.com/service 或联系您的飞利浦经销

商。 您还可以联系所在国家/地区的飞利浦客户服务中
心（请参阅全球保修卡了解详细联系信息）。

可选配以下附件和备件：

- SH90 飞利浦剃须刀头

- HQ110 飞利浦剃须刀头清洁喷雾剂

- RQ111 飞利浦胡须造型器附件

- RQ585 飞利浦洁面刷附件

- RQ560/RQ563飞利浦洁面刷头

- HQ8505 电源部件

注意： 配件可用性可能因国家/地区而异。

- 弃置本产品时，请不要将其与一般生活垃圾放在一
起，应将其交给政府指定的回收中心。 这样做将有
利于环保。

- 此产品包含内置充电电池；请勿将充电电池与一般
生活垃圾一起弃置。 强烈建议您将自己的产品送到
官方收集点或飞利浦服务中心，让专业人士移除充
电电池。

- 遵循您的国家/地区有关分类回收电子电气产品和充
电电池的规定。 正确弃置产品有助于避免对环境和
人类健康造成不良后果。

41

мȞġĈҴˀΙĀǩ؆Ӎߒʔ

ˌɫǩ؆

ĈҴˀΙ

໾

(Pb)

᰽

(Hg)⬡(Cd)

ԣᲱ

(Cr (VI) )

Ġ⅑ԓ᧠

(PBB)

Ġ⅑ȕ᧠⓭

(PBDE)

PCB’s

מŪǗɢذ

X O O O O O

Electrical

contact pins

ǗˈǦ

X O O O O O

Power plug

Ǘ۷૝Ǽ

X O O O O O

ǕȪϜ֪֙SJ/T 11364Āܪǭৠ뺯

OȪФ˽ĈҴˀΙć˽ˌɫǨĈߴΙࠒնġĀߒʔߴćGB/T 26572ܪǭĀՄʔđŘĪ뺯

XȪФ˽ĈҴˀΙψɺć˽ˌɫĀԚĂߴΙࠒնġĀߒʔɸŜGB/T 26572ܪǭĀՄʔđ뺯

简体中文

42

卸下剃须刀的充电电池

仅在丢弃剃须刀时方可取出充电电池。 卸下电池
之前，请确保剃须刀与电源插座断开连接并且电
池电量已耗尽。

当您使用工具打开剃须刀时以及在您弃置充电电
池时，请采取必要的安全保护措施。

注意，电池带非常锋利。

1 将螺丝刀插入产品底部的前面板与后面板之间的插

槽。 拆除后面板。

2 卸下前面板。
3 拧下内侧面板顶部的两个螺丝，卸下内侧面板。
4 用螺丝刀取出充电电池。

- 该表格中所显示的“有害物质”在产品正常使用情
况下不会对人身和环境产生任何伤害。

- 该表格中所显示的“有害物质”及其存在的部件向
消费者和回收处理从业者提供相关物质的存在信
息，有助于产品废弃时的妥善处理。

保修和支持

如需信息或支持，请访问 www.philips.com/support 或
阅读国际保修卡。

保修条款

保修与服务

简体中文

由于剃须刀头（刀片和网罩）属于易磨损物品，因此不
在国际保修条款的涵盖范围之列。

This guarantee card is valid in China.
This guarantee card should be retained by The USER
此保用卡在中国适用，用户请保留此卡。

保修及服务：
此产品是一件设计精良，用高品质元件制造之家用电

器，在正常使用及保养下应能发挥其优越性能。在购买
日期后二年内，若发生任何因制造工艺或元器件造成之
损坏，飞利浦中国维修服务中心将为持证用户提供免费
门市维修服务，视情况更换零件或整个产品。

无论在保期中或保期后，只要飞利浦正式行销该产品的
任何国家皆可获得维修服务。

若飞利浦在当地无行销该项产品，飞利浦同样提供维修
服务，但可能因未储备所需零件，维修时间可能较长，
敬请见谅。请联络当地飞利浦经销商，或飞利浦服务部
门。

若您需洽询相关资讯，或遇困难事项时，请联络当地飞
利浦维修服务中心，或向飞利浦服务热线咨询。

中国顾客服务热线：4008 800 008 (用户需承担本地通
话费)。

网址：http://www.philips.com.cn
保修条例：

- 在购买日期后二年内，凡经本公司特约维修站人员
确认为正常使用情况下，因制造工艺或元器件造成
之损坏，您都将获得免费保修服务。

- 此免费服务不包括需时常更换的易耗零配件（吸尘
机纸袋，布袋，空气清新机滤网，滤芯，活性碳，
咖啡壶过滤网）及附件（如须刀网膜、刀头，咖啡
杯，食品加工机杯/刀具等），辅助装置，运输费及
维修人员上门服务费。

43

44

简体中文

- 用户请保留此联。

- 维修时请携同此证及发票正本。

- 此证若经涂改即作废。

- 此证须联同发票正本使用方为有效。

- 以下情况将不能获得免费服务
1 使用不当引起的人为损坏，例如接入不适当电

源、使用不适当配件、不适当之安装、不依说明书
使用、错误使用或疏忽而造成损坏等。因运输及其
他意外而造成之损坏。非经本公司认可之维修和改
装。其他因不可抗力（如自然灾害、电压异常等）
造成的损坏。

2 一般家庭以外使用（如工业、商业用）而造成的
损坏。

3 正常使用引起的产品老化、磨损等，但不影响产
品的正常使用。

- 此证仅在中国境内有效。

- 保修证作为在规定期限及条件之内进行免费维修的
保证，并不限制消费者的法定权利。

网上会员注册与产品注册：
1 登陆 http://www.philips.com.cn/welcome
2 点击“创建新账户”，创建您的飞利浦账号。
3 点击“注册产品“，通过产品名称或产品型号查找

产品，完成产品注册

Service information
For after-sales and maintenance service, please call

service hotline [phone]. Any comments and
enquiries during the service, please Contact our
Philips Consumer Lifestyle Customer Care Service
Office.

Philips(china)Investment Co.,Ltd. Philips
Consumer Lifestyle Philips Innovation
Campus Shanghai NO.1 Building,
NO.10, Lane 888 Tian Lin Road Shanghai,

简体中文

P. R. C. 200233
Fax: [phone]

服务须知
如需要此产品的售后服务，请拨打服务热线4008 800

008
如在维修服务过程中有任何意见，
欢迎致函飞利浦优质生活服务办事处解决疑难。
飞利浦（中国）投资有限公司
飞利浦优质生活客户服务部
中国上海市田林路888弄10号
飞利浦创新科技园1号楼
邮政编码：200233 传真：[phone]

故障处理方法

剃须刀

问题 可能的原因 解决方法

按下开/关钮时，
产品不工作。

 充电电池的电量已耗尽。给电池充电 (请参见 '充电')。

 旅行锁已被激活。 按住开/关按钮 3 秒钟以禁用

产品的剃须效果没
有以前好。

产品仍然连接着电源
插座。 出于安全原
因，该产品在使用时
不能连接电线。

剃须刀头部件被污染
或损坏，导致马达无
法运行。

剃须刀头已损坏或磨损。更换剃须刀头 (请参见 '更换

拔掉产品插头并按开/关按钮
打开产品。

旅行锁。

彻底清洁剃须刀头或将其更
换。 有关如何彻底清洗剃须
刀头的详细说明，另请参
阅“毛发或污垢堵塞了剃须刀
头”。

')。

45

简体中文

46

问题 可能的原因 解决方法

 毛发或污垢堵塞了剃

  要彻底清洁剃须刀头，请将剃

我更换了剃须刀
头，但显示屏仍然
显示更换提醒。

显示屏上突然出现
剃须刀头部件符
号。

剃须刀充电时，通
知符号闪烁且剃须
刀会发出提示音。

在我尝试进行剃须
时，通知符号闪烁
且剃须刀会发出提
示音。

清洁剃须刀头后，
通知符号会闪烁且
剃须刀会发出提示
音。

水从产品底部漏出。在清洁过程中，水可

须刀头。

产品尚未重置。 按住开/关按钮大约 7 秒钟以

此符号提醒您更换剃
须刀头。

产品过热。 断开产品与电源插座的连接大

剃须刀头被污染。 清洁剃须刀头。 有关如何彻

剃须刀头已损坏。 更换剃须刀头 (请参见 '更换

能聚集在产品的机身
内部与外壳之间。

对剃须刀头进行常规式或彻底
清洁。

须刀头从剃须刀头支架上逐一
(请参见 '更换')卸下。 然后，
分离刀片和网罩，并在水龙头
下冲洗每个刀片和网罩套装。
冲洗后，将刀片放回对应的网
罩中。 最后，将剃须刀头装
回到剃须刀头支架 (请参见
'更换')中。

重置产品。

更换剃须刀头 (请参见 '更换
')。

约 10 分钟。

底清洗剃须刀头的详细说明，
另请参阅“毛发或污垢堵塞了
剃须刀头”。

')。

这是正常现象，而且没有危
险，因为所有电子元件都封闭
在产品内部的密封电源部件
中。

保留备用

发行日期: 28/7/2017

简体中文

47

Empty page before back cover

© 2017 Koninklijke Philips N.V.

All rights reserved

保留所有权利

4222.002.7385.1 (28/7/2017)
> 75% 循环再造纸

>75% recycled paper
>75% papier recyclé
