Philips SQM6325/00 Specifications
Philips
LCD wall mount
Fixed
SQM6325
Simply Straight
Easy to mount and level your TV
This Simply Straight TV wall mount enables you to always position your LCD TV straight
on the wall. Being easy to manoeuvre and hassle free now you can realise your optimal
viewing experience yourself with the confidence of a perfect result
A Straight result guaranteed
• Exclusive arc design for easy levelling (patent pending)
Safely Mount your Flat TV
• TVs weighing up to 50 Kg/110 Lbs are supported
• Screen sizes 81–107 cm (32–42")
• (c)UL and GS safety Certified
• High strength aluminium construction
Simple to Install
• All you need is in the box
• Easy 3 step installation
• Universal application through VESA mounting support
LCD wall mount
Fixed
SQM6325/00
Specifications
Packaging dimensions
• Packaging dimensions (W x H x D):
73.7 x 19.2 x 4.6 cm
• Packaging dimensions (W x H x D):
29 x 7.6 x 1.8 inch
• Net weight: 1.8 kg
• Net weight: 3.968 lb
• Gross weight: 2.2 kg
• Gross weight: 4.85 lb
• Tare weight: 0.4 kg
• Tare weight: 0.882 lb
• EAN: 87 12581 51944 5
• Number of products included: 1
• Packaging type: Box
Accessories
• User Manual
• Included accessories: Screwdriver, Screws, Spirit
el
lev
Dimensions
• VESA wall mount compatible: 200 x 100 mm, 200
x 200 mm, 200 x 300 mm, 300 x 300 mm, 400 x
300 mm
Outer Carton
•Outer carton (L x W x H): 75.8 x 40.5 x 17.5 cm
•Outer carton (L x W x H): 29.8 x 15.9 x 6.9 inch
• Net weight: 10.8 kg
• Net weight: 23.81 lb
•Gross weight: 14 kg
• Gross weight: 30.864
• Tare weight: 3.2 kg
• Tare weight: 7.055 lb
• EAN: 87 12581 54485 0
• Number of consumer packages: 6
lb
Technical specifications
• Complies with: VESA, (c)UL and GS
• Maximum weight: 110 lbs or 50 kg
Weight and dimensions
• Wall Distance: 40 mm (1.6") and 55 mm (2.2")
•
Highlights
(c)UL and GS safety Certified
This mount meets and exceeds safety standards as
certified by official certification organisations like
(c)UL and GS.
All you need is in the box
The product is delivered with all the required
accessories that allows the consumer to enjoy the
product without having to return to the shop and
buy a part that is required.
Easy 3 step installation
By using the 1-2-3 installation steps the mount can by
easily installed by yourself with the confidence of a
straight result (drill tools not supplied)
Exclusive arc design
The exclusive arc design incorporated in this wall
mount allows you to adjust the levelling of the TV by
simply sliding the TV sideways (patent pending).
High strength aluminium alloy
The innovative aluminium alloy materials used for
the construction of this mount are of high strength
and still lightweight. The height strength enables a
small and safe design. The lightweight material
characteristic results in decreased transportation
efforts that help reduce environmental impart of this
product.
For TVs up to 50 Kg/110 Lbs
This wallmount is certified for TVs up to 50 Kg/110
Lbs
VESA compliant
This product has near universal compatibility
through its support for the VESA mounting patterns.
Screen sizes 81–107 cm/32–42"
The wall mount is capable of holding TVs with
different screen sizes.
Issue date 2013-03-03
Version: 4.2.6
12 NC: 8670 000 58826
EAN: 87 12581 51944 5
© 2013 Koninklijke Philips Electronics N.V.
All Rights reserved.
Specifications are subject to change without notice.
Trademarks are the property of Koninklijke Philips
Electronics N.V. or their respective owners.
www.philips.com
